(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

IMPORTANT

SAFETY RULES

Read, understand, and follow all

instructions carefully before

installing and using this product.

Krystal Clear Sand Filter Pump

14” (360mm)

Model SF15110

English

161

OOWWNNEERR’’SS MMAANNUUAALL

For illustrative purposes only.

Don’t forget to try these other fine Intex products: pools, pool accessories, inflatable pools and in-home toys, airbeds and boats available at fine retailers or visit our website.

IIMMPPOORRTTAANNTT!!

DO NOT RETURN PRODUCT TO STORE

To purchase parts and accessories or to obtain non-technical assistance,

Visit www.intexcorp.com

For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):

1-800-234-6839

Monday through Friday, 8:30am to 5:00pm Pacific Time

161-***-R1-1211

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

Warnings.......................................................................... 3

Parts List & References.................................................. 4-8

Setup Instructions ......................................................... 9-16

Product Specifications................................................... 11

Operating Instructions ................................................... 17-19

Intex Pools Operating Time Table.................................. 20-21

161

Non-Intex Pools Operating Time Table.......................... 22

Maintenance.................................................................... 23

Long Term Storage.......................................................... 24

Troubleshooting Guide................................................... 25

Common Pool Problems................................................. 26

General Aquatic Safety................................................... 27

Limited Warranty............................................................. 28

Intex Service Center Locations..................................... 29

TTAABBLLEE OOFF CCOONNTTEENNTTSS

SAVE THESE INSTRUCTIONS

Page 2

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

IMPORTANT SAFETY RULES

Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.

READ AND FOLLOW ALL INSTRUCTIONS

WARNING

To reduce the risk of injury, do not permit children to use this product. Always

• supervise children and those with disabilities.

• Children must stay away from this product and electrical cord(s).

• Assembly and disassembly by adults only.

• Risk of electric shock. Connect only to a grounding type receptacle, this product is provided with a ground-fault circuit interrupter. If replacement of the plug or cord is needed, use only identical replacement parts.

• Always unplug this product from the electrical outlet before removing, cleaning, servicing or making any adjustment to the product.

• The unit is provided with a ground-fault circuit interrupter (GFCI). To test the GFCI, push the test button. The GFCI should interrupt power. Push the reset button, power should be restored. If the GFCI fails to operate in this manner. The GFCI is defective. If the GFCI interrupts power to the pump without the test button being pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem corrected by a qualified service representative before using.

• Do not bury the electrical cord. Locate the cord where it will not be damaged by lawn mowers, hedge trimmers and other equipment.

• To reduce the risk of electric shock, replace damaged cord immediately. Use a qualified electrician to replace the cord.

• To reduce the risk of electric shock, do not use extension cords, timers, plug adaptors or converter plugs to connect unit to electric supply; provide a properly located outlet.

• Do not attempt to plug in or unplug this product while standing in water or when your hands are wet.

• Do not use an appliance leakage current interrupter (ALCI) in place of a GFCI since the ALCI will not protect people.

• Position this product away from pool, so as to prevent children from climbing on it and access the pool.

• Do not operate this product when pool is occupied.

• To reduce the risk of entrapment hazard, never enter the pool if suction strainer component is loose, broken, cracked, damaged or missing. Replace loose, broken, damaged, cracked or missing suction strainer components immediately.

• Never play or swim near suction fittings. Your body or hair may be trapped causing permanent injury or drowning.

• To prevent equipment damage and risk of injury, always turn pump off before changing the filter control valve position.

• Never operate this product above the maximum working pressure stated on the filter tank.

• Hazardous Pressure. Improper tank valve cover assembly could cause the valve cover to blow off and cause serious injury, property damage or death.

• This product is intended to be used only for the purposes described in the manual!

161

SSAAFFEETTYY RRUULLEESS

FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE, ELECTRIC SHOCK, ENTANGLEMENT OR OTHER SERIOUS INJURY OR DEATH.

CAUTION

This product is for use with storable pools only. Do not use with permanently-installed pools. A storable pool is constructed so that it is capable of being readily disassembled for storage and reassembled to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such that it cannot be readily disassembled for storage.

These product warnings, instructions and safety rules provided with the product represent some common risks of water recreation devices and do not cover all instances of risk and danger. Please use common sense and good judgement when enjoying any water activity.

SAVE THESE INSTRUCTIONS

Page 3

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

4 5

PARTS LIST

English

161

PPAARRTTSS LLIISSTT

10 11 12

13 14

17 18

20 2119

NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

SAVE THESE INSTRUCTIONS

Page 4

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

PARTS LIST (continued)

22 24

26 27

English

161

PPAARRTTSS LLIISSTT

28 29 30

Optional Optional

Optional

NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

SAVE THESE INSTRUCTIONS

Page 5

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

161

PARTS REFERENCE

efore assembling your product, please take a few minutes to check the contents

and become familiar with all the parts.

NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

• Consult the dealer or an experienced radio/TV technician for help.

receiver is connected.

PPAARRTTSS RREEFFEERREENNCCEE

SAVE THESE INSTRUCTIONS

Page 6

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

PARTS REFERENCE (continued)

Before assembling your product, please take a few minutes to check the contents

nd become familiar with all the parts.

23 24 25 26 27

23 24 25 26

English

161

23 28 29 30

PPAARRTTSS RREEFFEERREENNCCEE

23 28 29 31

NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

SAVE THESE INSTRUCTIONS

Page 7

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

161

PARTS REFERENCE (continued)

Before assembling your product, please take a few minutes to check the contents

and become familiar with all the parts.

REF. NO. DESCRIPTION QTY.

1 2 3 4 5 6 7 8

9 10 11 12 13 14 LEAF TRAP NUT 1 11479 15 LEAF TRAP O-RING 1 11232 16 BASKET 1 11260 17 FILTER HOUSING NUT 1 11261 18 19 SEDIMENT RELEASE VALVE 1 10460 20 VALVE O-RING 1 10264 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 LEAF TRAP COVER 1 11480 36 SAND FILTER PUMP MOTOR INLET O-RING 2 11457 37 14” SAND FILTER PUMP AND COMBO TANK 1 11498 38 14” SAND FILTER PUMP TANK BASE 1 11513

PRESSURE GAUGE 6-WAY VALVE DRAIN OUTLET COVER

LAMP

C TANK O-RING SAND SHIELD

CENTER PIPE HUB

LATERAL DRAIN VALVE CAP DRAIN VALVE O-RING L-SHAPE O-RING HOSE WITH NUTS SAND FILTER INTERCONNECTING HOSE

L-SHAPE O-RING

PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)

HOSE O-RING STEP WASHER STRAINER NUT FLAT STRAINER RUBBER WASHER

THREADED STRAINER CONNECTOR

ADJUSTABLE POOL INLET NOZZLE ADAPTOR B STRAINER CONNECTOR POOL INLET NOZZLE STRAINER GRID SCREW PUMP MOTOR & CONTROL PRE-FILTER ASSEMBLY

1 11411 1 11378 1 11131 1 1 1 11379 1 11382 1 11383

10 11384

1 1 11385 4 11228 2 11009 1 11388

1 11412

2 10747 2 10262 2 10745 2 10256 2 10255 2 11235 1 11074 2 10722 2 11070 1 11071 1 11072 2 11381 1 11387EG 1 11371

SPARE PART

1380

11456

PPAARRTTSS RREEFFEERREENNCCEE

When ordering parts, be sure to quote the model number and part numbers.

SAVE THESE INSTRUCTIONS

Page 8

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

POOL OUTLET - STRAINER & PLUNGER VALVE SETUP

The strainer grid prevents large objects from jamming and/or damaging the filter pump. If your pool has an inflatable top ring, install the strainer, nozzle and plunger valve before inflating the pool liner top ring. The part numbers here onward refer to the parts depicted in the Parts List section of this manual. To install, do the following:

1. In a counter-clockwise motion unscrew

plunger valve union from the threaded strainer connector (26) (see drawing 1). Be careful not to lose the step rubber washer (23). Place the plunger valve on the ground in a safe place.

2. In a counter-clockwise motion unscrew the strainer nut (24) from the threaded connector (26). Leave the flat washer (25) on the connector (26).

3. Install the strainer and plunger valve at the lower position of pool outlet (marked "+"). From the inside of the pool liner insert the connector (26) into one of the pre-cut holes with the washer remaining on the connector to be placed against the inside of the liner wall.

4. Before assembly, lubricate the threads with a petroleum jelly. With the flat side of the strainer nut (24) facing the outside wall of the liner in a clockwise motion screw the strainer nut (24) back onto the threaded connector (26) (see drawing 2).

5. Finger tighten the strainer nut (24) onto the threaded connector (26).

6. Grasp the plunger valve assembly. Make sure the step washer (23) is in place.

7. In a clockwise motion screw the plunger valve union back onto the threaded connector (26) (see drawing 3).

8. Examine the plunger valve to see if the handle is pushed fully down to the "0/1" position. If not, then grasp the handle at the top and push down turning the handle in a clockwise direction until the plastic protruding notch anchors in the "0/1" position. This will prevent water from flowing out during filling (see

drawings 4.1 & 4.2).

INSIDE

LINER WALL

INSIDE

LINER WALL

161

4.1

SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS

4.2

SAVE THESE INSTRUCTIONS

Page 9

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

POOL INLET - NOZZLE & PLUNGER VALVE SETUP

1. In a counter-clockwise motion unscrew

lunger valve union from the threaded

p strainer connector (26) (see drawing 5). Be careful not to lose the step rubber washer (23). Place the plunger valve on the ground in a safe place.

2. In a counter-clockwise motion unscrew the strainer nut (24) from the threaded connector (26). Leave the flat washer (25) on the connector (26).

3. Install the nozzle and plunger valve at the upper position of pool inlet. From the inside of the pool liner insert the connector (26) into one of the pre-cut holes with the washer remaining on the connector to be placed against the inside of the liner wall.

5. Finger tighten the adjustable pool inlet nozzle (27) and the strainer nut (24) onto the threaded connector (26).

6. Grasp the plunger valve assembly. Make sure the step washer (23) is in place.

7. In a clockwise motion screw the plunger valve union back onto the threaded connector (26) (see drawing 7).

drawings 8.1 & 8.2).

9. Adjust the direction of nozzle head pointing

away from the pool outlet for a better circulation result (see drawing 9).

10. The pool liner is now ready to fill with water. Consult the above-ground-pool owner’s manual for filling instructions.

English

INSIDE

LINER WALL

25 26 27

WATER

FLOW

8.1

INSIDE

LINER WALL

8.2

161

SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS

SAVE THESE INSTRUCTIONS

POOL

Page 10

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

PRODUCT SPECIFICATIONS

he sand filter removes suspended particles but does not sanitize your pool.

T Pool chemistry is a specialized area and you should consult your local pool

ervice specialist for details.

Power: 110-120 Volt AC Amperage: 3 A Maximum working pressure: 3.5 bar (50 psi) Effective filtering area: 0.1 m Maximum Flow Rate: 6056 liters/hour (1600 gallons/hour) Recommended filtering media: (Not included) range 0.45 to 0.85 mm (0.018 to 0.033 inches).

Recommended filtering media quantity:

Limited Warranty: see “Limited Warranty” NOTE: NOT SUITABLE FOR USE WITH KCP-LOW -SALT AUTOMATIC SALTWATER

SYSTEM (MODEL 6110/6220

)

(1.1 ft2)

No. 20 silica sand or glass sand. Particle size

Uniformity Coefficient less than 1.75. No. 20 silica sand 18 Kg (40 Lbs).

25 Kg (55 Lbs)

or glass sand

SETUP INSTRUCTIONS

161

TOOLS REQUIRED: One (1) Phillips screwdriver Pump location and mounting:

• The system must be installed on a solid level and vibration-free base.

• Provide a location protected from the weather, moisture, flooding and

freezing temperature.

• Provide adequate access, space and lighting for routine maintenance.

• Pump motor requires free circulation of air for cooling. Do not install

the pump in a damp or non-ventilated location.

A team of 2 or more people is recommended for setting up this product.

Motor pre-filtering assembly setup:

1. Remove the sand filter and its accessories

from the packaging carefully and inspect for any visible damage. If parts are damaged contact your local service center listed at the back of this owner’s manual.

2. In a counter-clockwise motion unscrew the

leaf trap cover (14) from the pre-filter housing. Take out the basket (16) and filter housing nut (17) (see drawing 10). Connect the pre-filter housing to the motor

water inlet. Note: Align the connector in the pre-filter housing with the water inlet on the motor (see drawing 11).

SAVE THESE INSTRUCTIONS

PPRROODDUUCCTT SSPPEECCSS && SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS

Page 11

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

160

English

SETUP INSTRUCTIONS (continued)

4. In a clockwise motion screw filter housing nut (17) onto the motor water inlet (See drawings 12.1 & 12.2).

12.1

5. Replace the basket (16) and leaf trap cover (14) back to the pre-filter housing (See drawings 13.1 & 13.2).

13.1 13.2

161

2.2

Sand tank installation:

1. Place the tank support base on the selected location.

2. Place the tank on the tank support base (See drawing 14.1).

3. Connect the motor pre-filtering assembly unit to the tank support base (See

drawing 14.2). NOTE: Ensure the pre-filter housing water inlet hose connection

is facing towards the pool.

IMPORTANT: Some countries, especially in the European community, require the product to be secured to the ground or to a base in a permanent upright position. Check your local authorities to determine if there is a regulation in your area regarding above-the-ground swimming pool filter-pumps. If yes, then the product can be mounted to a platform

using the two holes located in the base. See drawing 14.3. The product can be mounted on a cement base or onto a wooden platform to prevent accidental falling over.

• The mounting holes are 6.4 mm in diameter and spaced 160 mm

apart.

• Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.

14.1

14.2

SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS

14.3

SAVE THESE INSTRUCTIONS

Page 12

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

MAXMAX

MINMIN

MAX

MIN

English

SETUP INSTRUCTIONS (continued)

and loading:

IMPORTANT: Use No. 20 silica sand or glass sand with particle size range

.45 to 0.85 mm (0.018 to 0.033 inches) and a Uniformity Coefficient less

0 than 1.75.

NOTE: Before loading the tank with sand, ensure the center pipe hub assembly is securely in place at the bottom of the tank, and vertically centered inside the tank.

1. Place the sand shield (6) over the top of the center pipe. Pour the sand into the tank at a slow rate. (see drawing 15).

2. Fill the tank approximately half way, remove the sand shield (6) from the top. (see drawing 16).

161

3. Evenly distribute the sand inside the tank, then fill the tank with some water to

provide a cushioning effect when the remaining sand is poured in. This prevents the center pipe hub (7) from excessive shock (see drawing 17). Place the sand shield (6) back and continue to pour the sand into the tank.

4. Sand shall be filled between the “MAX” and “MIN” marked gauge on the center pipe. Evenly spread and level out the sand by hand (see drawings 17 & 18).

5. Remove the sand shield (6).

6. Wash away all sand around the top edge of the tank.

SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS

SAVE THESE INSTRUCTIONS

Page 13

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

SETUP INSTRUCTIONS (continued)

WARNING

Improper tank valve and clamp assembly could cause the valve and clamp to blow off and cause serious injury, property damage or death.

6-way valve installation:

1. Lower the 6-way valve over the tank slowly, and ensure the bypass pipe protruding

underneath the 6-way valve fits securely into the center pipe hub (7) top opening

drawing 19).

IMPORTANT: There are three hose connection ports on the 6-way valve, ensure the outlet connection (from filter to the pool) on the valve is facing towards the pool, and the inlet connection (from motor to valve) is aligned with the motor outlet (see drawing 20).

WATER

NLET

(see

161

ATER

UTLET

2. Place an L-shape o-ring (11) on the 6-way valve inlet connection and on the

pump motor outlet. In a clockwise motion connect the sand filter interconnecting hose (13) between the pump motor outlet and the 6-way valve inlet connection (see drawing 21).

3. Remove the clamp bolt, and install the clamp around the tank and 6-way valve flanges, then replace the clamp bolt and use a phillips screwdriver (not included) to tighten it (see drawings 22)

SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS

SAVE THESE INSTRUCTIONS

Page 14

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

SAND FILTER PUMP HOSE CONNECTION SETUP

WARNING

• Position this product away from the pool, so as to prevent children from climbing on it and accessing the pool.

The 6-way valve has three hose connection ports.

1. Connect one hose (12) end to the pre-filter inlet and the other end of the hose

to the lower plunger valve with the strainer. Ensure the hose nuts are securely tightened.

2. Connect the second hose (12) between the 6-way valve water outlet and the upper plunger valve with the inlet-nozzle. Ensure the hose nuts are securely tighten.

3. The third hose connection port (drain/waste outlet) on the 6-way valve shall be directed to a proper draining receptacle using a hose or pipe (not provided). Remove the drain cap before attaching the drain/waste hose or pipe.

4. The sand filter pump is now ready to filter the pool.

161

WATER

INLET

DRAIN

POWER

CORD

6-WAY VALVE

MOTOR

MOTOR WATER

OUTLET

WATER

OUTLET

PRE-

FILTER

L-SHAPE

O-RING

WATER INLET

L-SHAPE

O-RING

PLUNGER

VALVE

WATER LEVEL

ADJUSTABLE

OUTSIDE

LINER WALL

(ILLUSTRATION NOT TO SCALE)

POOL INLET

NOZZLE

THREADED

STRAINER

CONNECTOR

SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS

SAVE THESE INSTRUCTIONS

Page 15

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

SAND FILTER PUMP HOSE CONNECTION SETUP (continued)

or NON-INTEX pool:

onnect the hose (12) to the pool inlet/outlet connection with a large hose clamp.

C Tighten securely. Remove the drain cap (3) before attaching the drain/waste hose or pipe.

LARGE HOSE

CLAMP

POOL

161

For INTEX pool size 16' and below:

1. In a counter-clockwise motion unscrew plunger valve union from the threaded strainer connector (26). Be careful not to lose the step rubber washer (23).

2. Grasp the plunger valve assembly. Make sure the step washer (23) is in place. Connect adaptor B (28) to plunger valve union.

3. Remove wall plug and then insert the strainer (29 & 31) into the lower position of protruding hose connection, and the nozzle (29 & 30) into the upper position of protruding hose connection. Adaptor B (28) fits over the strainer connection (29) inserted into the connection. Tighten securely.

4. Remove the drain cap (3) before attaching the drain/waste hose or pipe.

29 & 30

POOL

29 & 31

SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS

SAVE THESE INSTRUCTIONS

Page 16

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

ETSA

ETALU

RICER

E TSAW

TALU

RICER

ETSA

ETALU

RICER

E TSAW

TALU

RICER

ETSA

TALU

RICER

ETSA

English

OPERATING INSTRUCTIONS

WARNING

• Risk of electric shock. Connect this product only to a grounding type eceptacle protected by a ground-fault circuit interrupter (GFCI) or

r residual current device (RCD). Contact a qualified electrician if you cannot verify that the receptacle is protected by a GFCI/RCD. Use a qualified electrician to install the GFCI/RCD, which has a maximum rate of 30mA. Do not use a portable residual current device (PRCD).

• To reduce the risk of electric shock, do not use extension cords, timers,

plug adaptors or converter plugs to connect unit to electric supply; provide a properly located outlet.

• Do not attempt to plug in or unplug this product while standing in water

or when your hands are wet.

• Never operate this product above the maximum working pressure stated

on the filter tank.

• Always switch off pump before changing the 6-way valve position.

• Operating this product without water flowing through the system can

cause a build up of hazardous pressure which can result in an explosive situation, serious injury, property damage or death.

• Never test this pump with compressed air. Never operate the system with

water temperature above 35° C (95° F).

161

6-way valve positions and function:

Valve Position Function Water Flow Direction

FILTER

(see drawing 23)

BACKWASH

(see drawing 24)

RINSE

(see drawing 25)

WASTE

(see drawing 26)

RECIRCULATE

(see drawing 27)

CLOSED

(see drawing 28)

Normal filtration and regular vacuuming of pool

Reverses water flow to clean

filter media

For initial startup cleaning of the sand, and leveling the sand bed after backwashing

For vacuuming directly to waste, lowering pool level or to drain the pool

For circulating water back to pool without going through the filter media

Shuts off all flow to filter and pool

“Do not use this setting with pump running”

From pump through filter media to pool

From pump through filter media to valve waste/drain outlet

From pump to valve waste/drain outlet bypassing the filter media

From pump through valve to pool bypassing the filter media

OOPPEERRAATTIINNGG IINNSSTTRRUUCCTTIIOONNSS

SAVE THESE INSTRUCTIONS

Page 17

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

ETSA

ETALU

RICER

E TSAW

TALU

RICER

ETSA

ETSAW

ETALUC

ICER

ETSAW

ETALU

RICER

E TSAW

TALU

RICER

ETSA

ETALUC

ICER

ETSAW

TALU

RICER

ETSA

ETALUC

ICER

ETSAW

English

OPERATING INSTRUCTIONS (continued)

Initial startup and operation:

Before operating, be sure that:

• All the hoses have been connected and tightened securely, and correct amount of filter sand have been loaded.

• The entire system is connected to a grounding type receptacle protected by a ground-fault circuit interrupter (GFCI) or residual current device (RCD).

CAUTION

161

The filter control valve has a closed position. The pump should never be on when the valve is in the closed position. If the pump is operated with the valve closed, explosive situation could exist.

1. Grasp plunger valve handle. Turn the handle counter-clockwise, pull up until it

stops, and then turn it clockwise until the metal protruding notch anchor is in the "0/1" position. Repeat for the second plunger valve. This opens the valves to allow water to flow into the sand filter pump

2. Ensure the drain/waste outlet on the 6-way valve is not covered and directed to a proper draining receptacle.

3. Ensure the pump is off, depress the 6-way

valve and turn it to the “BACKWASH” position (see drawings 24 & 29). IMPORTANT: To prevent damage to the

6-way valve, always depress the valve handle before turning. Always switch off pump before changing the 6-way valve position.

4. Switch on the pump (see drawing 30). Water

is circulating backward through the sand media and to waste/drain outlet. Backwash until a clear flow of water is observed in the waste/drain outlet or through the drain sediment

OOPPEERRAATTIINNGG IINNSSTTRRUUCCTTIIOONNSS

window. NOTE: The initial backwash of the filter is recommended to remove any impurities or fine

TIMER

OFF

sand particles in the sand media.

SAVE THESE INSTRUCTIONS

Page 18

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

OPERATING INSTRUCTIONS (continued)

. Switch off the pump, change the 6-way valve to “RINSE” position (see

drawing 25).

. Switch on the pump and run the pump for about one minute to level out the

sand bed after backwashing the sand media.

7. Switch off the pump, change the 6-way valve to “FILTER” position (see drawing 23).

8. Switch on the pump. The system is now operating in the normal filtering mode.

Run the pump until the desired pool water clearance is obtained and no more than 12 hours per day.

9. Record the initial pressure gauge reading when the filter media is clean. NOTE: During initial setup of the system, it may be necessary to backwash

frequently due to unusual heavy dirt present in the water and sand. After that, as the filter removes dirt and impurities from the pool water, the accumulated dirt in the sand media will cause the pressure to rise and the flow to diminish. If there is no vacuuming device attached to the system and the pressure gauge reading is in the yellow zone it is time to backwash the sand media, see “BACKWASH” under “initial startup and operation” section. Vacuuming device (i.e. Intex auto pool cleaner) attached to the system may also cause the flow to diminish and the pressure to rise. Remove any vacuuming device from the system and check if the pressure gauge reading has dropped from the yellow zone to the green zone.

161

Operating the system under “TIMER” mode or manually:

To operate the sand filter pump in “FILTER” mode under “TIMER” control:

A. Set the timer dial to the desired operating hours. See operation time table

(see drawing 31).

B. Turn on the pump by pressing the switch to “ ” position, the sand filter

pump is now filtering the water and will stop after the operating hours are completed. The built-in timer will now operate for the number of hours selected at the same time each day.

C. Operating hours can be re-adjusted if necessary. Follow step A – B.

To operate the sand filter pump manually (without the “TIMER” mode):

A. Turn on the pump by pressing the switch to “-” position, the sand filter

pump is now filtering the water.

B. To turn off the pump, press the switch to “O” position.

OOPPEERRAATTIINNGG IINNSSTTRRUUCCTTIIOONNSS

TIMER DIAL

(HOURS)

TIMER

OFF

SAVE THESE INSTRUCTIONS

Page 19

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

INTEX POOLS OPERATING TIME TABLE (WITHOUT INTEX SALTWATER SYSTEM)

This table shows the required operating time for average use of the sand filter pump with above

round pools.

Pool Size

INTEX ABOVE GROUND POOLS (AGP’s)

15' x 33" (457cm x 84cm)

15' x 36" (457cm x 91cm)

15' x 42" (457cm x 107cm)

EASY SET

POOL

ROUND

METAL

FRAME POOL

ULTRA FRAME

POOL

SEQUOIA SPIRIT

POOL SET

OVAL FRAME

POOL

RECT. ULTRA

FRAME POOL

15' x 48" (457cm x 122cm)

16' x 42"(488cm x 107cm)

16' x 48" (488cm x 122cm)

18' x 42" (549cm x 107cm)

18' x 48" (549cm x 122cm)

18' x 52" (549cm x 132cm)

15' x 36" (457cm x 91cm)

15' x 42" (457cm x 107cm)

15' x 48" (457cm x 122cm)

16' x 48" (488cm x 122cm)

18' x 48" (549cm x 122cm)

18' x 52" (549cm x 132cm)

24' x 48" (732cm x 122cm)

24' x 52" (732cm x 132cm)

16' x 48" (488cm x 122cm)

18' x 52" (549cm x 132cm)

16'8" x 49" (508cm x 124cm)

18'8" x 53" (569cm x 135cm)

18' x 10' x 42" (549cm x 305cm x 107cm)

20' x 12' x 48" (610cm x 366cm x 122cm)

24' x 12' x 48" (732cm x 366cm x 122cm)

28' x 12' x 48" (853cm x 366cm x 122cm)

18' x 9' x 52" (549cm x 274cm x 132cm)

24' x 12' x 52" (732cm x 366cm x 132cm)

32' x 16' x 52" (975cm x 488cm x 132cm)

Water Capacity (Calculated at

90% for Frame Pool and 80% for

asy Set & Oval Pool)

(Gals) (Liters) (Hours)

2587 2822 3284 3736 3754 4273 4786 5455 5894 3282 3861 4440 5061 6423

6981 11483 12481

5061

6981

5061

6981

2885

4393

5407

6420

4545

8403 14364

9792 10681 12430 14141 14209 16173 18115 20647 22309 12422 14614 16805 19156 24311 26423 43463 47241 19156 26423 19156 26423 10920 16628 20465 24300 17203 31805 54368

Sand filter pump

operating time

For one cycle)

(

161

SAVE THESE INSTRUCTIONS

Page 20

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

INTEX POOLS OPERATING TIME TABLE (WITH INTEX SALTWATER SYSTEM)

If the system is attached to an “Intex Saltwater System” unit, the filter pump running time should be longer than the required operating time of the Intex Saltwater System unit.

Saltwater System

operating Time (with

cyanuric acid 30-50ppm) (hours)

10 - 19°C

(50 - 66°F)

1 1 1 1 1 2 2 2 2 1 1 2 2 2 2 3 4 5 2 2 2 2 1 2 2 2 2 3 6

20 - 28 °C

(68 - 82 °F)

1 1 1 2 2 2 2 2 2 1 2 2 2 2 2 3 4 5 2 2 2 2 1 2 2 2 2 3 6

29 - 36 °C

(84 - 97 °F)

1 1 2 2 2 2 2 3 3 2 2 2 2 3 3 4 5 6 2 3 2 3 1 2 3 3 2 4 7

Sand Filter

Pump

Operating

Time

(hours)

4 4 4 4 4 6 6 6 6 4 4 6 6 6 8

8 12 12

8 12

Pool Size

INTEX ABOVE GROUND POOLS (AGP’s)

15' x 33" (457cm x 84cm)

15' x 36" (457cm x 91cm)

15' x 42" (457cm x 107cm)

EASY SET

POOL

CIRCULAR

METAL

FRAME POOL

ULTRA FRAME

POOL

SEQUOIA SPIRIT

POOL SET

OVAL FRAME

POOL

RECT. ULTRA

FRAME POOL

15' x 48" (457cm x 122cm)

16' x 42" (488cm x 107cm)

16' x 48" (488cm x 122cm)

18' x 42" (549cm x 107cm)

18' x 48" (549cm x 122cm)

18' x 52" (549cm x 132cm)

15' x 36" (457cm x 91cm)

15' x 42" (457cm x 107cm)

15' x 48" (457cm x 122cm)

16' x 48" (488cm x 122cm)

18' x 48" (549cm x 122cm)

18' x 52" (549cm x 132cm)

20' x 52" (610cm x 132cm)

24' x 48" (732cm x 122cm)

24' x 52" (732cm x 132cm)

16' x 48" (488cm x 122cm)

18' x 52" (549cm x 132cm)

16'8" x 49" (508cm x 124cm)

569

18'8" x 53" (

18' x 10' x 42" (549cm x 305cm x 107cm)

20' x 12' x 48" (610cm x 366cm x 122cm)

24' x 12' x 48" (732cm x 366cm x 122cm)

28' x 12' x 48" (853cm x 366cm x 122cm)

18' x 9' x 52" (549cm x 274cm x 132cm)

24' x 12' x 52" (732cm x 366cm x 132cm)

32' x 16' x 52" (975cm x 488cm x 132cm)

cm x 135cm)

Water Capacity (Calculated at

90% for Frame Pool and 80%

for Easy Set & Oval Pool)

(Gals) (Liters)

2587 2822 3284 3736 3754 4273 4786 5455 5894 3282 3 861 4440 5061 6423 6981

8638 11483 12481

5061

6981

5061

6981

2885

4393

5407

6420

4545

8403 14364

9792

10681 12430 14141

14209

16173

18115

20647

22309

12422

14614

16805

19156

24311

26423

32695

43462

47241

19156

26423

19156

26423

10920

16628

20465

24300

17203

31805

54368

161

NOTE: The “12” hours timer setting position has an additional 20 minutes over the actual setting.

SAVE THESE INSTRUCTIONS

Page 21

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

NON-INTEX POOLS OPERATING TIME TABLE

This table shows the required operating time for average use of the sand filter pump with above ground pools.

Sand filter pump operating

time (For one cycle)

Hours)

(

Gals)

(

3000 4000 5000 6000 7000 8000

9000 10000 11000 12000 13000 14000 15000 16000 17000 18000 19000

Water Capacity

Liters)

(

11355 15140 18925 22710 26495 30280 34065 37850 41635 45420 49205 52990 56775 60560 64345 68130 71915

161

SAVE THESE INSTRUCTIONS

Page 22

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

MOTOR PRE-FILTER CLEANING AND MAINTENANCE

1. Make sure the filter pump is switched off, then disconnect the power cord from he electrical outlet.

2. Grasp a plunger valve handle. Turn the handle counter-clockwise, push down

until it stops and then turn it clockwise until the plastic protruding notch anchors in the "0/1" position. Repeat for the second plunger valve. This prevents the water from flowing out of the pool.

3. Release the pressure first by opening the

sediment release valve (19) located on the lower side of the pre-filter housing

(see drawing 32).

161

4. In a counter-clockwise motion unscrew the

leaf trap cover (14), then remove the basket (16) and leaf trap o-ring (15) from the pre-filter housing (see drawing 33).

5. Empty and flush the basket using a garden hose, may use a plastic brush to

remove deposits from the basket. Do not use metal brush.

6. Clean and rinse the inside of the pre-filter housing and the leaf trap O-ring with

a garden hose.

7. Reinstall the leaf trap O-ring, basket and leaf trap cover to the pre-filter housing.

8. Close the sediment release valve (19) back.

MMAAIINNTTEENNAANNCCEE

SAVE THESE INSTRUCTIONS

Page 23

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

POOL CARE & CHEMICALS

• All pools require care to keep the water clear and hygienically clean. With proper chemical control, your filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper use of chlorine, algaecide and other chemical agents required for sparkling clear water.

• Keep pool chemicals away from children.

• Do not replenish chemicals in pool while pool is occupied. Skin or eye irritations could occur.

• Daily pH checking and chemical treatment of the water is very important and cannot be

veremphasized. Chlorine, algaecide and maintenance of proper pH levels are required

o when filling the pool as well as during the season. Consult your local swimming pool supply store for instructions.

• The season's first filling of the pool may have brackish water requiring extra water additives and extra filtering time. Do not allow swimming in pool until the pH level is balanced. Consult your local swimming pool supply store for instructions.

• Chlorinated water may damage lawns, gardens or shrubbery as children play in the pool and splash water outside the pool. Lawn areas underneath the pool liner will be destroyed. Note that some types of grass may grow through the liner.

• Filter run time depends on pool size, weather and usage level. Experiment with various run times so as to produce clean clear water.

CAUTION

Concentrated chlorine solutions may damage the pool liner. Always follow the chemical manufacturer’s directions, and the health and hazard warnings.

LONG TERM STORAGE & WINTERIZATION

161

MMAAIINNTTEENNAANNCCEE

CAUTION

Allowing the water to freeze will damage the sand filter and void the warranty. If anti-freeze solution is needed, use only propylene glycol. Propylene glycol is non-toxic and will not damage plastic system components; other anti-freezes are highly toxic and may damage plastic components in the system.

1. Before emptying your pool for long term storage, or relocation, be sure the water is

directed towards an acceptable drain water receptacle away from the house. Check local regulations for specific directions regarding disposal of swimming pool water.

2. Switch off the unit, and disconnect power cord from electrical outlet.

3. When the pool is empty, disconnect all hoses from pump and plunger valves and

remove the strainers/plunger valves from the pool wall.

4. In a counter clockwise motion unscrew the drain valve cap (9) from the drain valve to thoroughly drain the tank. The drain valve is located at the bottom of the filter tank.

5. Disassemble the pump motor from the tank base.

6. Leave sand filter pump pieces and hoses outside to thoroughly air dry.

7. Coat the following o-rings and washers with petroleum jelly for long term storage:

• L-shape o-ring (11).

• o-ring A (18).

• Pump hose O-rings (22).

• Strainer valve assembly step washers (23).

• Flat strainer rubber washers (25).

8. Depress the 6-way valve handle and rotate so as to set the pointer on the valve top “N” position. This allows the water to drain from the valve. Leave the 6-way valve in this inactive position.

It is best to place all dry pieces and pump motor in the original packaging for storage. To avoid condensation or corrosion problem, do not cover or wrap pump motor with plastic bags.

10. Store the pump motor and accessories in a dry place. The storage's temperature should be controlled, between 0 degrees Celsius (32 degrees Fahrenheit) and 40 degrees Celsius (104 degrees Fahrenheit).

SAVE THESE INSTRUCTIONS

Page 24

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

TROUBLESHOOTING GUIDE

TROUBLE CAUSE SOLUTION

FILTER MOTOR FAILS TO START

FILTER DOESN’T CLEAN POOL

FILTER DOESN’T PUMP WATER OR FLOW IS VERY SLOW

• The motor is not plugged in.

• The fuse box needs checking.

• The GFCI/RCD circuit breaker is tripped.

• Motor too hot and overload protection is shut off.

• Improper chlorine or pH levels.

• No filtering media in tank.

• Wrong 6-way valve setting position.

• Excessively dirty pool.

• The strainer screen is restricting the water flow.

• Clogged inlet or discharge.

• An air leak on the intake line.

• Excessively dirty pool.

• Sand media clogged with dirt.

• Nozzle and strainer connections are reversed.

• Crusting or caking on the filtering sand surface.

• Pool vacuuming device attached to the system.

• Line cord must be plugged into a 3 wire outlet that is protected by a Class A Ground Fault Circuit Interrupter, or RCD.

• Reset circuit breaker. If circuit breaker trips repeatedly, your electrical system may have a defect. Turn off circuit breaker and call an electrician to correct the problem.

•

Let the motor cool down and restart again.

• Adjust

• Load with filter sand, see “sand loading

• Set valve to “ FILTER” position.

• Operate

• Clean

• Clear any obstructions in the intake

• Tighten hose nuts, check hoses for

• Clean the pre-filtering basket more often.

• Backwash filter.

• Install the nozzle at the upper position

• Remove about 1” of sand if necessary.

• Remove any pool vacuuming device

the

your local swimming pool supply stores.

instructions”.

hose by discharging it inside pool wall.

damage, check pool water level.

of the pool inlet, and the strainer at the lower position of the pool outlet.

attached to the system line.

chlorine and pH level. Consult

the

strainer screen at the inlet.

English

filter for longer periods.

161

PUMP DOESN’T WORK

6-WAY VALVE/COVER LEAKING

HOSE LEAKING

TIMER IS INACCURATE OR TIMER CAN'T BE SET

PRESSURE GAUGE DOESN’T WORK

SAND IS FLOWING BACK INTO THE POOL

• Low water level.

• Strainer screen clogged up.

• An air leak on the intake hose.

• Faulty motor or the impeller is jammed.

• Sand tank o-ring missing.

• Sand tank o-ring dirty.

• Flange clamp not tight.

• 6-way valve damage.

• Hose nut not securely tight.

• Hose connection fitting o-ring/L-shape o-ring missing.

• Possible inner timer defective.

• Clogged inlet of the pressure gauge.

• Pressure gauge damage.

• Sand is too small.

• Sand bed is calcified.

• Fill pool to correct water level.

• Clean strainer screens at pool inlet.

• Tighten hose nuts, check hose for damage.

• Contact Intex service center.

•

Remove 6-way valve cover and ensure the o-ring is in place.

•

Clean sand tank o-ring with garden hose water.

•

Tighten the clamp with wrench supplied.

•

Contact Intex service center.

• Tighten/reinstall hose nut.

• Ensure o-ring/L-shape o-ring is in place and not damaged.

• Turn off the pump and restart 5 minutes later.

• Re-set the timer.

• Contact Intex service center.

• Clear any obstructions in the intake by unscrewing it from the 6-way valve.

• Contact Intex service center.

• Use only No. 20 silica sand with particle size range 0.45 to 0.85 mm (0.018 to 0.033 inches) and a Uniformity Coefficient less than 1.75.

• Change sand.

TTRROOUUBBLLEESSHHOOOOTTIINNGG GGUUIIDDEE

SAVE THESE INSTRUCTIONS

Page 25

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

COMMON POOL PROBLEMS

PROBLEM DESCRIPTION CAUSE SOLUTION

ALGAE

COLORED WATER

FLOATING MATTER IN WATER

• Greenish water.

• Green or black spots on pool liner.

• Pool liner is slippery and/or has a bad odor.

• Water turns blue, brown, or black when first treated with chlorine.

• Water is cloudy or milky.

• Chlorine and pH levels need adjustment.

• Copper, iron or maganese in water being oxidized by the added chlorine. This is Common.

• "Hard water" caused by a too high pH level.

• Chlorine content is low.

• Foreign matter in water.

• Super chlorinate with shock treatment. Correct pH to your pool store's recommended level.

• Vacuum pool bottom.

• Maintain proper chlorine level.

• Adjust pH level to the recommended level.

• Run filter until water is clear.

• Correct the pH level. Check with your pool dealer for advice.

• Adjust the chlorine level.

English

161

CHRONIC LOW WATER LEVEL

SEDIMENT ON POOL BOTTOM

SURFACE DEBRIS

• Level is lower than on previous day.

• Dirt or sand on pool floor.

• Leaves, insects etc.

• Rip or hole in pool liner or hoses.

• The drain valves are loose.

• Heavy use, getting in and out of pool.

• Pool too close to trees.

• Repair with a patch kit.

• Finger tighten all caps.

• Use Intex pool vacuum to clean bottom of pool.

• Use Intex pool skimmer.

IMPORTANT

If you continue to experience difficulty, please contact our Consumer Service Department for assistance. See back cover for contact information.

CCOOMMMMOONN PPRROOBBLLEEMMSS

SAVE THESE INSTRUCTIONS

Page 26

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

GENERAL AQUATIC SAFETY

Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions. Remember, however, that product warnings, instructions and safety guidelines cover some common risks of water recreation, but do not cover all risks and dangers.

For additional safeguards, also familiarize yourself with the following general guidelines as well as guidelines provided by nationally recognized Safety Organizations:

• Demand constant supervision. A competent adult should be appointed as a “lifeguard” or water watcher, especially when children are in and around the pool.

• Learn to swim.

• Take the time to learn CPR and first aid.

• Instruct anyone who is supervising pool users about potential pool hazards and about the use of protective devices such as locked doors, barriers, etc.

• Instruct all pool users, including children what to do in case of an emergency.

• Always use common sense and good judgement when enjoying any water activity.

• Supervise, supervise, supervise.

161

SSAAFFEETTYY GGUUIIDDEELLIINNEESS

For additional information on safety, please visit

• The Association of Pool and Spa Professionals: The Sensible Way to Enjoy Your Aboveground/Onground Swimming Pool www.nspi.org

• American Academy of Pediatrics: Pool Safety for Children www.aap.org

• Red Cross www.redcross.org

• Safe Kids www.safekids.org

• Home Safety Council: Safety Guide www.homesafetycouncil.org

• Toy Industry Association: Toy Safety www.toy-tia.org

SAVE THESE INSTRUCTIONS

Page 27

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

LIMITED WARRANTY

Your Sand Filter Pump has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only to the Sand Filter Pump and accessories listed below.

The provisions of this Limited Warranty apply only to the original purchaser and is not transferable. This Limited Warranty is valid for the period noted below from the date of the initial retail purchase. Keep your original sales receipt with this manual, as proof of purchase will be required and must accompany warranty claims or the Limited Warranty is invalid.

Sand Filter Pump Warranty – 2 Years Hoses, Plunger Valves & Fittings Warranty – 180 days

If a manufacturing defect is found within the periods noted above, please contact the appropriate Intex Service Center listed in this manual. The Service Center will determine the validity of the claim. If the Service Center directs you to return the product, please carefully package the product and send with shipping and insurance prepaid to the Service Center. Upon receipt of the returned product, the Intex Service Center will inspect the item and determine the validity of the claim. If the provisions of this warranty cover the item, the item will be repaired or replaced at no charge.

161

Any and all disputes regarding the provisions of this Limited Warranty shall be brought before an informal dispute settlement board and unless and until the provisions of these paragraphs are carried forth, no civil action may be instituted. The methods and procedures of this settlement board shall be subject to the rules and regulations set forth by the Federal Trade Commission (F.T.C.). IMPLIED WARRANTIES ARE LIMITED TO THE TERMS OF THIS WARRANTY AND IN NO EVENT SHALL INTEX, THEIR AUTHORIZED AGENTS OR EMPLOYEES BE LIABLE TO THE BUYER OR ANY OTHER PARTY FOR DIRECT OR CONSEQUENTIAL DAMAGES OR LIABILITIES. Some states, or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

This Limited Warranty does not apply if the products are subject to negligence, abnormal use or operation, accident, improper operation, improper voltage or current contrary to operating instructions, or to damage by circumstances beyond Intex’s control, including but not limited to, ordinary wear and tear and damage caused by exposure to fire, flood, freezing, rain, or other external environmental forces. This Limited Warranty applies only to those parts and components sold by Intex. The Limited Warranty does not cover unauthorized alterations, repairs or disassembly by anyone other than Intex Service Center personnel.

DO NOT GO BACK TO THE PLACE OF PURCHASE FOR RETURN OR REPLACEMENT. IF YOU ARE MISSING PARTS OR NEED ASSISTANCE, PLEASE CALL US TOLL-FREE (FOR U.S. AND CANADIAN RESIDENTS): 1-800-234-6839 OR VISIT OUR WEBSITE: WWW.INTEXSTORE.COM.

Proof of Purchase must accompany all returns or the warranty claim will be invalid.

SAVE THESE INSTRUCTIONS

Page 28

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

COUNTRIES/REGIONS SERVICE CENTER LOCATIONS

• UNITED STATES INTEX RECREATION CORP.

• CANADA 1665 Hughes Way

Long Beach, CA 90801 Tel: 1-800-234-6839 Fax: 310-549-2900 Website: www.intexcorp.com (U.S./Canada only)

onsumer Service Hours: 8:30 am to 5:00 pm

C Pacific Time, Mon. thru F

• MEXICO KAY INTERNACIONAL, S.A. DE C.V.

SAN JERONIMO # 550- INT.501 Y 502. COL. JARDINES DEL PEDREGAL. C.P. 01900 MÉXICO D.F. Tel: 01-800-347-4020 (Collect Call) Tel: 55-9172-8035 Fax: 55-9172-8047 E-mail: servicenter@kayinternacional.com Website: www.intexmexico.com.mx

• PANAMA SUPRO MUNDIAL S.A./

• PARAGUAY PRODUCTOS SUPERIORES S.A.

• ECUADOR Boulevard Andrews, Albrook,

• HONDURAS Panama, Rep. of Panama

• EL SALVADOR Tel: 507-300-3800

• NICARAGUA Fax: 507-300-3813

E-mail: suproadmin@supropanama.com

. only.

161

• COSTA RICA CENTURY USA, LLC

• DOMINICAN REPUBLIC 4731 W. Atlantic Ave., Suite B-3

• GUATEMALA Delray Beach, FL 33445, USA

• COLOMBIA Tel: 561-495-0648

• VENEZUELA Fax: 561-495-4782

E-mail: sales@centuryusa.com

• MIDDLE EAST REGION FIRST GROUP INTERNATIONAL

REGION AL MOOSA GROUP BUILDING, 1ST FLOOR,

OFFICE 102 & 103, UMM HURAIR ROAD, KARAMA, DUBAI, UAE TEL: 00971-4-800INTEX(46839) / +971-4-3373322 FAX: 00971-4-3375115 E-mail: intex@firstgroupinternational.com. Website: www.firstgroupinternational.com

• ASIA INTEX DEVELOPMENT CO. LTD.

9th Floor, Dah Sing Financial Centre 108 Gloucester Road, Wanchai, Hong Kong Tel: 852-28270000 Fax: 852-23118200 E-mail: xmservicesupport@intexcorp.com.cn Website: www.intexdevelopment.com

For answers to most frequently asked questions, please visit www.intexcorp.com. Non U.S. Residents, please visit www.intexdevelopment.com.

SAVE THESE INSTRUCTIONS

Page 29

(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 11/08/2011

English

For Residents of the U.S. & Canada:

INTEX RECREATION CORP. Attn: Consumer Service 1665 Hughes Way Long Beach, CA 90801 Phone: 1-800-234-6839 Fax: (310) 549-2900

Consumer Service Hours: 8:30 am to 5:00 pm Pacific time Monday thru Friday only Website: www.intexcorp.com

For Residents outside of the U.S. and Canada: Please refer to the Service Center Locations

©2011 Intex Marketing Ltd. - Intex Development Co. Ltd. Intex Trading Ltd. - Intex Recreation Corp. All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.

®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd.

to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the

European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., P.O. Box nr.

1075 – 4700 BB Roosendaal – The Netherlands

I N T E X

Intex SF15110 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
