Intex Ladder Owner's Manual

Download

165A

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

OWNER’S MANUAL

Ladder with Removable Steps

Owner’s Manual For: 48in (122 cm) & 52in (132 cm) models

IMPORTANT

SAFETY RULES

Read, Understand, and Follow

all Instructions Carefully before

Installing and using this Product.

Don’t forget to try these other fine Intex products: Pools, Pool Accessories, Inflatable Pools and In-Home Toys, Airbeds and Boats available at fine retailers or visit our website. Due to a policy of continuous product improvement, Intex reserves the right to change specifications and appearance, which may result in updates to the instruction manual, without notice.

For illustrative purposes only.

52 in (132cm) Shown

®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/ Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex

Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR

Roosendaal – The Netherlands www.intexcorp.com

165-*A*-R0-1706

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 2

Warnings..........................................................................................

Parts References............................................................................. 4

Setup Instructions........................................................................... 5-10

Long Term Storage.......................................................................... 11

General Aquatic Safety................................................................... 11

Limited Warranty............................................................................ 12

SAVE THE CARTON FOR STORAGE AND THE INSTRUCTIONS

FOR RE-ASSEMBLY

TABLE OF CONTENTS

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 3

IMPORTANT SAFETY RULES

Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.

• Supervise children and those with disabilities at all times.

• Always assist children when they use the ladder to avoid falls and/or serious

injury.

• Never dive or jump from this ladder.

• Locate the ladder on a level, solid base.

• One person on this ladder at a time.

• Maximum load: 300 lbs (136 kg). Complies with EN16582 strength

requirements.

• Face the ladder at all times for entry/exit of pool.

• Remove and secure ladder when pool is not occupied.

• Do not swim under, through or behind ladder.

• Check all nuts and bolts regularly to ensure ladder stays sturdy.

• If swimming at night use artificial lighting to illuminate all safety signs, ladders,

pool floor and walkways.

• Assembly and disassembly by adults only.

• This ladder is designed and manufactured for a specific pool wall height and/ or deck of the pool. Do not use with other pools.

• Failure to follow the maintenance instructions and warnings may result in adverse health effects or injury, particularly to children.

• Only use this ladder for the purposes described in this manual.

FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN BROKEN BONES, ENTRAPMENT, PARALYSIS, DROWNING OR OTHER SERIOUS INJURY.

These product warnings, instructions and safety rules provided with the

product represent some common risks of water recreation devices and do not cover all instances of risk and danger. Please use common sense and good judgment when enjoying any water activity.

WARNING

IMPORTANT

IT IS VERY IMPORTANT TO LAY OUT THE PARTS CORRECTLY AND IDENTIFY WHICH PARTS CONNECT TOGETHER BEFORE STARTING THE ASSEMBLY. ALTHOUGH SOME PARTS LOOK ALIKE, THEY ARE NOT ALWAYS INTERCHANGEABLE. REFER TO THE PARTS LIST.

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 4

PARTS REFERENCE

Before assembling your product, please take a few minutes to check the contents

and become familiar with all the parts.

NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

52in (132 cm) model

48in (122 cm) model

REF.

NO.

DESCRIPTION

LADDER SIZE &

QUANTITIES

SPARE PART

NUMBER

48in 52in 48in 52in

U-SHAPED TOP RAIL

2 2 12512 12512

TOP PLATFORM

1 1 12182 12182

SHORT FASTENER FOR U-SHAPED TOP RAIL (WITH 1 EXTRA)

5 5 10810 10810

LONG FASTENER FOR TOP PLATFORM (WITH 1 EXTRA)

5 5 10227 10227

STEP MOUNTING PIN (WITH 2 EXTRA)

26 34 10913 10913

STEP

6 8 10914 10914

A SIDE - UPPER SIDE LEG (MARKED “A1”)

1 1 12513A 12497A

A SIDE - UPPER SIDE LEG (MARKED “B1”)

1 1 12513B 12497B

A SIDE - LOWER J- LEG (MARKED “A1” )

1 1 12514A 12498A

A SIDE - LOWER J- LEG (MARKED “B1” )

1 1 12514B 12498B

B SIDE - UPPER SIDE LEG (MARKED “A2 & B2”)

2 2 12516 12520

B SIDE - LOWER SIDE LEG (MARKED “A2)

1 1 12517A 12521A

B SIDE - LOWER SIDE LEG (MARKED “B2”)

1 1 12517B 12521B

C SIDE - UPPER SIDE LEG (MARKED “C”)

2 2 12518 12522

C SIDE - LOWER U-SHAPED SIDE LEG (MARKED “C”)

1 1 12519 12523

SUPPORT BASE

2 2 11356 11356

CLASP

2 2 12190 12190

This ladder is designed and manufactured for Intex pool wall height:

Item # Pool Wall Height

28073 48in (122cm)

28074 52in (132cm)

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 5

LADDER SETUP

Estimated assembly time 30-60 minutes. (Note the assembly time is only approximate and individual assembly experience may vary.)

These assembly instructions are the same for the 3-step and 4-step ladders. The assembly drawings show the 4-step ladder. TOOLS REQUIRED: One (1) Phillips screwdriver One (1) pair of pliers or a small adjustable wrench IMPORTANT: Do not fully tighten fasterners until last assembly operation.

WARNING

ASSEMBLE THE LEGS BEFORE INSTALLING THE LADDER STEPS. FAILURE TO ASSEMBLE THE LEGS BEFORE INSTALLING THE STEPS MAY ALLOW THE LEGS TO SEPARATE FROM THE LADDER DURING USE, POSSIBLY RESULTING IN SERIOUS INJURY OR DEATH. INCORRECTLY CONNECTED PARTS MAY RESULT IN AN UNSTABLE LADDER OR LADDER FAILURE WHICH CAN CAUSE FALLING AND PERSONAL INJURY OR DEATH.

1. SIDE C LEGS ASSEMBLY

(refer to figures 1.1 through 1.4):

IMPORTANT: Make sure the legs are securely connected and locked. Check the spring pins have snapped out before proceeding to the next step.

1.1

1.2

Press,

hold and insert

1.3

Spring pin

1.4

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 6

LADDER SETUP (continued)

2. SIDE A LEGS ASSEMBLY

(refer to figures 2.1 through 2.4):

2.2

Spring pin

IMPORTANT:

Make sure the legs are securely connected and locked. Check the

spring pins have snapped out before proceeding to the next step. Ensure the J-shaped

legs are pointing outwards before installing the steps.

2.3

2.4

IMPORTANT:

Make sure all pins are securely locked.

Press,

hold and insert

$

%

$

%





2.1

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 7

LADDER SETUP (continued)

3. SIDE B LEGS ASSEMBLY

(refer to figures 3.1 through 3.4):

Press,

hold and insert

$

%





$

%

3.1

3.2

Spring pin

IMPORTANT:

Make sure the legs are securely connected and locked. Check the

spring pins have snapped out before proceeding to the next step.

3.4

3.3

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 8

LADDER SETUP (continued)

4. TOP PLATFORM INSTALLATION

(refer to figure 4):

5. U-SHAPED TOP RAIL INSTALLATION

(refer to figure 5.1 through 5.2):

IMPORTANT: One side at a time. Do not attach the other side of the ladder until the U-shaped top rail is installed. Make sure all nuts and bolts are securely tightened.

5.1

5.2

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 9

LADDER SETUP (continued)

6. SIDE B LEGS INSTALLATON

(refer to figure 6):

WARNING

BEFORE EACH USE, ENSURE THE REMOVABLE STEPS SIDE IS ANCHORED INTO THE SUPPORT BASE AND SECURELY LOCKED IN THE CLASPS LOCATED AT THE FRONT EDGE OF THE TOP PLATFORM.

7. MAINTENANCE :

Regularly check all nuts, bolts, step mounting fixtures and step

mounting pins to ensure all parts are secured properly and the ladder is sturdy.

8. BEFORE USE OF LADDER

(refer to figure 7):

With all parts now in place, verify that all fasteners/screws are fully tightened and

apply downward pressure to each step to be sure they are fully anchored in place.

IMPORTANT:

The removable steps side must be located outside of the pool.



165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 10

LADDER SETUP (continued)

9. AFTER USE OF LADDER

(refer to figure 8):

10. Removing the steps from the secured position (refer to figure 9):

a) With your right hand pull and hold the latch towards you, while at the same time

with your left hand press the white protruding buttons and simultaneously lift that

leg out of the cavity exposing the lower white protruding buttons. b) Allow the leg to rest over the top brace (make sure it does not fall back into the cavity), and quickly lift up the “removable step assembly” out of its secured

position.

c) See step 6 for re-attaching the removable steps.

Press

and Pull

Press

and Pull

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 11

WINTERIZING/LONG TERM STORAGE

Remove the “removable steps” as shown in the After Use of Ladder section, see

figure 8.

Remove the ladder from the pool, and make sure the ladder and the removable

steps are thoroughly dry before long term storage.

Bring the ladder and all its components indoors and store in a safe and dry area,

preferably between 32° F (0° C) and 104° F (40° C).

Be sure the ladder and all components are stored in a safe place away from

children’s reach.

WARNING

WHEN NOT IN USE, LADDER SHOULD BE KEPT IN SAFETY POSITION. REMOVE THE FRONT STEPS SIDE WHEN THE POOL IS NOT IN USE OR OCCUPIED. STORE THE REMOVABLE STEPS SIDE IN A SAFE PLACE AWAY FROM CHILDREN REACH. CLOSE THE CLASPS BACK.

GENERAL AQUATIC SAFETY

Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions. Remember, however, that product warnings, instructions and safety guidelines cover some common risks of water recreation, but do not cover all risks and or dangers.

For additional safeguards, also familiarize yourself with the following general guidelines as well as guidelines provided by nationally recognized Safety Organizations:

• Demand constant supervision. A competent adult should be appointed as a “lifeguard” or water watcher, especially when children are in and around the pool.

• Learn to swim.

• Take the time to learn CPR and first aid.

• Instruct anyone who is supervising pool users about potential pool hazards and about the use of protective devices such as locked doors, barriers, etc.

• Instruct all pool users, including children what to do in case of an emergency.

• Always use common sense and good judgement when enjoying any water activity.

• Supervise, supervise, supervise.

165A

SAVE THESE INSTRUCTIONS

English

(165IO) 48”, 52" LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 05/27/2016

Page 12

LIMITED WARRANTY

Your Intex Pool Ladder has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies to the Intex Pool Ladder only.

This limited warranty is in addition to, and not a substitute for, your legal rights and remedies. To the extent that this warranty is inconsistent with any of your legal rights, they take priority. For example, consumer laws across the European Union provide statutory warranty rights in addition to the coverage you receive from this limited warranty: for information on EU-wide consumer laws, please visit the European Consumer Center website at http://ec.europa.eu/consumers/ecc/contact_en/htm.

The provisions of this Limited Warranty apply only to the original purchaser and are not transferable. This Limited Warranty is valid for a period of 90 days from the date of the

initial retail purchase. Keep your original sales receipt with this document, as proof of

purchase will be required and must accompany warranty claims or the Limited Warranty will be invalid.

If you find a manufacturing defect in the Intex Pool Ladder during the warranty period, please contact the appropriate Intex Service Center listed in the separate “Authorized Service Centers” sheet. If the item is returned as directed by the Intex Service Center, the Service Center will inspect the item and determine the validity of the claim. If the item is covered by the provisions of the warranty, the item will be repaired or replaced, with the same or comparable item (at Intex’s choice) at no charge to you.

Other than this warranty, and other legal rights in your country, no further warranties are implied. To the extent possibly in your country, in no event shall Intex be liable to you or any third party for direct or consequential damages arising out of the use of your Intex Pool Ladder, or Intex or its agents’ and employees’ actions (including the manufacture of the product). If your country does not allow the exclusion or limitation of incidental or consequential damages, this limitation or exclusion does not apply to you.

You should note that this limited warranty does not apply in the following circumstances:

• If the Intex Pool Ladder is subject to negligence, abnormal use or application, accident, improper operation, improper maintenance or storage.

• If the Intex Pool Ladder is subject to damage by circumstances beyond Intex’s control, including but not limited to, ordinary wear and tear and damage caused by exposure to fire, flood, freezing, rain, or other external environmental forces;

• To parts and components not sold by Intex; and/or

• To unauthorized alterations, repairs or disassembly to the Intex Pool Ladder by anyone other than Intex Service Center personnel.

The costs associated with the loss of pool water, chemicals or water damages are not covered by this warranty. Injury or damage to any property or person is not covered by this

warranty.

Read the owner’s manual carefully and follow all instructions regarding proper operation and maintenance of your Intex Pool Ladder. Always inspect your product prior to use. This

limited warranty will be void if use instructions are not followed.
