Intesis BACnet User Manual

BACnet Server

Samsung NASA compatible Outdoor Units

USER MANUAL

Issue date: 12/2020 r1.2 ENGLISH

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

2 / 131

Important User Information

Disclaimer

The information in this document is for informational purposes only. Please inform HMS Industrial Networks of any
inaccuracies or omissions found in this document. HMS Industrial Networks disclaims any responsibility or liability
for any errors that may appear in this document.

HMS Industrial Networks reserves the right to modify its products in line with its policy of continuous product
development. The information in this document shall therefore not be construed as a commitment on the part of
HMS Industrial Networks and is subject to change without notice. HMS Industrial Networks makes no commitment
to update or keep current the information in this document.

The data, examples and illustrations found in this document are included for illustrative purposes and are only
intended to help improve understanding of the functionality and handling of the product. In view of the wide range
of possible applications of the product, and because of the many variables and requirements associated with any
particular implementation, HMS Industrial Networks cannot assume responsibility or liability for actual use based on
the data, examples or illustrations included in this document nor for any damages incurred during installation of the
product. Those responsible for the use of the product must acquire sufficient knowledge in order to ensure that the
product is used correctly in their specific application and that the application meets all performance and safety
requirements including any applicable laws, regulations, codes and standards. Further, HMS Industrial Networks will
under no circumstances assume liability or responsibility for any problems that may arise as a result from the use of
undocumented features or functional side effects found outside the documented scope of the product. The effects
caused by any direct or indirect use of such aspects of the product are undefined and may include e.g. compatibility
issues and stability issues.

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

3 / 131

Gateway for the integration of Samsung NASA compatible
systems into BACnet/IP or BACnet MSTP control and
monitoring systems.

ORDER CODES

LEGACY ORDER CODES

INBACSAM004O000

SM-ACN-BAC-4

INBACSAM008O000

SM-ACN-BAC-8

INBACSAM016O000

SM-ACN-BAC-16

INBACSAM064O000

SM-ACN-BAC-64

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

4 / 131

INDEX

1 Description ...................................................................................................................................................... 8

Introduction .............................................................................................................................................. 8

1.1 Functionality ................................................................................................................................................ 9

Capacity of Intesis ................................ ................................................................ .................................. 10

2 Protocol Implementation Conformance Statement ......................................................................................... 11

BACnet Standardized Device Profile (Annex L): ................................................................ ..................... 11

Segmentation Capability: ....................................................................................................................... 11

Data Link Layer Options: ........................................................................................................................ 11

Device Address Binding: ........................................................................................................................ 12

Networking Options: ............................................................................................................................... 12

Character Sets Supported ...................................................................................................................... 12

Gateway ................................................................ ................................................................ ................ 12

3 BACnet Interoperability Building Blocks Supported (BIBBs) ........................................................................... 13

Data Sharing BIBBs ............................................................................................................................... 13

Alarm and Event Management BIBBs .................................................................................................... 13

Scheduling BIBBs .................................................................................................................................. 14

Trending BIBBs ...................................................................................................................................... 14

Network Management BIBBs ................................................................................................................. 14

Device Management BIBBs.................................................................................................................... 15

4 Service Types ............................................................................................................................................... 16

5 Objects .......................................................................................................................................................... 17

Supported Object Types......................................................................................................................... 17

Member objects ..................................................................................................................................... 19

5.2.1 Type: Gateway ............................................................................................................................... 19

5.2.2 Type: Central control ...................................................................................................................... 19

5.2.3 Type: Indoor Unit ............................................................................................................................ 19

5.2.4 Type: HE ........................................................................................................................................ 20

5.2.5 Type: HT ........................................................................................................................................ 20

5.2.6 Type: EHS ...................................................................................................................................... 21

5.2.7 Type: AHU ...................................................................................................................................... 21

5.2.8 Type: ERV ...................................................................................................................................... 22

5.2.9 Type: ERV+ .................................................................................................................................... 22

5.2.10 Type: CHILLER ................................................................ .............................................................. 22

Objects and properties ........................................................................................................................... 23

5.3.1 Device INBACSAM---O000 (Device Object Type) ............................................................................ 24

5.3.2 OUxx_Communication Error OU (Binary Input Object Type)............................................................ 26

5.3.3 OU Addressing Error (Binary Input Object Type) ............................................................................. 27

5.3.4 On/Off (all units) (Binary Output Object Type) ................................................................................. 28

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

5 / 131

5.3.5 Mode (all units) (Multistate Output Object Type) .............................................................................. 29

5.3.6 FanSpeed (all units) (Multistate Input Object Type) ......................................................................... 31

5.3.7 Vane position swing (all units) (Binary Output Object Type)............................................................. 32

5.3.8 Temperature Setpoint (all units) (Analog Output Object Type) ......................................................... 33

5.3.9 Vent. On/Off (all units) (Binary Output Object Type) ........................................................................ 34

5.3.10 Hot Water On/Off (all units) (Binary Output Object Type)................................................................. 35

5.3.11 OxxUxx_On/Off_S (Binary Input Object Type) ................................................................................. 36

5.3.12 OxxUxx_On/Off_C (Binary Output Object Type) .............................................................................. 37

5.3.13 OxxUxx_Mode IU/AHU_S (Multistate Input Object Type) ................................................................ 38

5.3.14 OxxUxx_Mode HE/EHS_S (Multistate Input Object Type) ............................................................... 39

5.3.15 OxxUxx_Mode ERV+_S (Multistate Input Object Type) ................................................................... 40

5.3.16 OxxUxx_Mode CHILLER_S (Multistate Input Object Type).............................................................. 41

5.3.17 OxxUxx_Mode IU/AHU_C (Multistate Output Object Type).............................................................. 42

5.3.18 OxxUxx_Mode HE/EHS_C (Multistate Output Object Type) ............................................................ 44

5.3.19 OxxUxx_Mode ERV+_C (Multistate Output Object Type) ................................................................ 46

5.3.20 OxxUxx_Mode CHILLER_C (Multistate Input Object Type) ............................................................. 48

5.3.21 OxxUxx_Setpoint_S (Analog Input Object Type) ............................................................................. 50

5.3.22 OxxUxx_Setpoint_C (Analog Output Object Type) ................................................................ .......... 51

5.3.23 OxxUxx_FanSpeed_S (Multistate Input Object Type) ...................................................................... 52

5.3.24 OxxUxx_FanSpeed_C (Multistate Output Object Type) ................................................................... 53

5.3.25 OxxUxx_Vane position swing_S (Binary Input Object Type) ............................................................ 54

5.3.26 OxxUxx_Vane position swing_C (Binary Output Object Type) ......................................................... 55

5.3.27 OxxUxx_Room_Temperature (Analog Input Object Type) ............................................................... 56

5.3.28 OxxUxx_Disch.Setpoint Cool IU_S (Analog Input Object Type) ....................................................... 57

5.3.29 OxxUxx_Disch.Setpoint Cool IU_C (Analog Output Object Type) .................................................... 58

5.3.30 OxxUxx_Disch.Setpoint Cool AHU_S (Analog Input Object Type) ................................................... 59

5.3.31 OxxUxx_Disch.Setpoint Cool AHU_C (Analog Output Object Type) ................................................ 60

5.3.32 OxxUxx_Disch.Setpoint Heat IU_S (Analog Input Object Type) ....................................................... 60

5.3.33 OxxUxx_Disch.Setpoint Heat IU_C (Analog Output Object Type) .................................................... 62

5.3.34 OxxUxx_Disch.Setpoint Heat AHU_S (Analog Input Object Type) ................................................... 62

5.3.35 OxxUxx_Disch.Setpoint Heat IU_C (Analog Output Object Type) .................................................... 64

5.3.36 OxxUxx_Disch. Current Temp. S (Analog Input Object Type) .......................................................... 64

5.3.37 OxxUxx_Unit Error code (Analog Input Object Type) ....................................................................... 66

5.3.38 OxxUxx_Error Slave Chiller Unit (Analog Input Object Type) ........................................................... 67

5.3.39 OxxUxx_Slave Chiller in Error (Analog Input Object Type) .............................................................. 68

5.3.40 OxxUxx_FilterSign (Binary Input Object Type) ................................................................................ 69

5.3.41 OxxUxx_FilterReset (Binary Output Object Type)............................................................................ 70

5.3.42 OxxUxx_Communication Status (Multistate Input Object Type) ................................ ....................... 71

5.3.43 OxxUxx_RC Restriction_S (Binary Input Object Type) .................................................................... 73

5.3.44 OxxUxx_RC Restriction_C (Binary Output Object Type).................................................................. 74

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

6 / 131

5.3.45 OxxUxx_Buzzer Sound (Binary Output Object Type)....................................................................... 75

5.3.46 OxxUxx_Unit type (Multistate Input Object Type) ............................................................................ 76

5.3.47 OxxUxx_HotWater On/Off_S (Binary Input Object Type) ................................................................. 78

5.3.48 OxxUxx_HotWater On/Off_C (Binary Output Object Type) .............................................................. 79

5.3.49 OxxUxx_HotWater Mode HE/HT_S (Multistate Input Object Type) .................................................. 80

5.3.50 OxxUxx_HotWater Mode EHS_S (Multistate Input Object Type) ..................................................... 81

5.3.51 OxxUxx_HotWater Mode HE/HT_C (Multistate Output Object Type) ............................................... 82

5.3.52 OxxUxx_HotWater Mode EHS_C (Multistate Output Object Type) .................................................. 83

5.3.53 OxxUxx_HotWater Setpoint HE_S (Analog Input Object Type) ........................................................ 84

5.3.54 OxxUxx_HotWater Setpoint HT_S (Analog Input Object Type) ........................................................ 85

5.3.55 OxxUxx_HotWater Setpoint EHS_S (Analog Input Object Type) ..................................................... 86

5.3.56 OxxUxx_HotWater Setpoint HE_C (Analog Output Object Type) ..................................................... 87

5.3.57 OxxUxx_HotWater Setpoint EHS_C (Analog Output Object Type) .................................................. 88

5.3.58 OxxUxx_HotWater Current Temp. (Analog Input Object Type) ........................................................ 88

5.3.59 OxxUxx_WaterIn Temperature. (Analog Input Object Type) ............................................................ 90

5.3.60 OxxUxx_WaterOut Temperature. (Analog Input Object Type) ......................................................... 91

5.3.61 OxxUxx_WaterOut Setpoint HE_S. (Analog Input Object Type)....................................................... 92

5.3.62 OxxUxx_WaterOut Setpoint HT_S. (Analog Input Object Type) ....................................................... 93

5.3.63 OxxUxx_WaterOut Setpoint EHS_S. (Analog Input Object Type) .................................................... 94

5.3.64 OxxUxx_WaterOut Setpoint CHILL_S (Analog Input Object Type) .................................................. 94

5.3.65 OxxUxx_WaterOut Setpoint HE_C (Analog Output Object Type)..................................................... 96

5.3.66 OxxUxx_WaterOut Setpoint HT_C (Analog Output Object Type) ..................................................... 97

5.3.67 OxxUxx_WaterOut Setpoint EHS_C (Analog Output Object Type) .................................................. 98

5.3.68 OxxUxx_WaterOut Setpoint CHILL_C (Analog Output Object Type) ................................................ 99

5.3.69 OxxUxx_WaterOut Average Temp. (Analog Input Object Type)..................................................... 100

5.3.70 OxxUxx_Vent. On/Off_S (Binary Input Object Type)...................................................................... 101

5.3.71 OxxUxx_HotWater On/Off_C (Binary Output Object Type) ............................................................ 102

5.3.72 OxxUxx_Vent. Mode_S (Multistate Input Object Type) .................................................................. 103

5.3.73 OxxUxx_Vent. Mode_C (Multistate Output Object Type) ............................................................... 104

5.3.74 OxxUxx_Vent. FanSpeed_S (Multistate Input Object Type) ........................................................... 105

5.3.75 OxxUxx_Vent. FanSpeed_C (Multistate Output Object Type) ........................................................ 106

5.3.76 OxxUxx_WindFree_S (Binary Input Object Type) .......................................................................... 107

5.3.77 OxxUxx_WindFree_C (Binary Output Object Type) ....................................................................... 108

5.3.78 OxxUxx_ Air_Clean_S (Binary Input Object Type) ......................................................................... 109

5.3.79 OxxUxx_Air_Clean_C (Binary Output Object Type) ....................................................................... 110

5.3.80 OxxUxx_360_CST_Air_Flow_S (Multistate Input Object Type) ...................................................... 111

5.3.81 OxxUxx_360_CST_Air_Flow_C (Multistate Output Object Type) ................................................... 112

6 Connections ................................................................................................................................................ 113

Power device ....................................................................................................................................... 114

Connection to BACnet .......................................................................................................................... 114

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

7 / 131

6.2.1 BACnet IP .................................................................................................................................... 114

6.2.2 BACnet MSTP .............................................................................................................................. 114

Connect to Samsung NASA installation ................................................................................................ 114

Connection to the configuration tool ..................................................................................................... 115

7 Set-up process and troubleshooting............................................................................................................. 116

Pre-requisites....................................................................................................................................... 116

Intesis MAPS. Configuration & monitoring tool for Intesis BACnet series .............................................. 116

7.2.1 Introduction .................................................................................................................................. 116

7.2.2 Connection ................................................................................................................................... 116

7.2.3 Configuration tab .......................................................................................................................... 117

7.2.4 BACnet Server configuration ......................................................................................................... 117

7.2.5 Samsung NASA configuration ....................................................................................................... 118

7.2.6 Signals ......................................................................................................................................... 120

7.2.7 Sending the configuration to Intesis .............................................................................................. 121

7.2.8 Diagnostic .................................................................................................................................... 121

7.2.9 Set-up procedure .......................................................................................................................... 123

8 Electrical & Mechanical Features ................................................................................................................. 125

9 Dimensions ................................................................ ................................................................ ................. 126

10 AC Unit Types compatibility ......................................................................................................................... 127

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

8 / 131

1 Description

Introduction

This document describes the integration of Samsung NASA compatible air conditioning systems into BACnet
compatible devices and systems using gateway Intesis BACnet Server – Samsung NASA.

The aim of this integration is to monitor and control your Samsung air conditioning system, remotely, from your
Control Center using any commercial SCADA or monitoring software that includes a BACnet/IP or BACnet MSTP
driver. To do it so, Intesis allows BACnet/IP and BACnet MSTP communication, acting as a server (B-AAC profile),
allowing polling or subscription requests (COV).

Intesis makes available the Samsung air conditioning system indoor units through independent BACnet objects.
Abstraction of Samsung air conditioning system properties and functionalities as fixed BACnet Objects. Intesis

allows fixed BACnet object IDs mapping. Simple configuration is needed: just select the appropriate communication
parameters (IP address, baud rate…).

Up to 64 indoor units supported, depending on product version.
This document assumes that the user is familiar with BACnet and Samsung technologies and their technical terms.

Integration of Samsung NASA AC compatible systems into

BACnet/IP or BACnet MSTP control systems

NOTE: Take following considerations into account for Samsung’s NASA
R1/R2 network:

- Samsung NASA AC network allows for both automatic and manual
addressing. Manual addressing of both indoor and outdoor units must

be setup by Samsung installer in order that Intesis communicates
properly. Manual addressing is setup by means of DIP switches in outdoor

unit and using the remote controller or DIP switches in the indoor unit.

- Samsung NASA indoor units need to be configured to accept ‘central

control’. To do so, they need to be configured with so-called ‘installation
option code’ in which segment 5 of this code needs to be set to value ‘1’ to

allow central control.

!

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

9 / 131

1.1 Functionality

IntesisTM continuously monitors Samsung’s NASA R1/R2 network for all configured signals and keeps the updated
status of all of them in its memory, ready to be served when requested from the BACnet side.

Commands toward the R1/R2 indoor unit communication adaptor are permitted.
Each indoor unit is offered in set of BACnet objects.

Element

Object supported

Outdoor Unit

• Communication
status

• Addressing status

Indoor Unit

• Status

• Command

• Communication

status

General signals
(all units)

• Command

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

10 / 131

Capacity of Intesis

Element

Max.

Notes

Number of indoor units

64 *

Number of indoor units that can be controlled through Intesis

Number of Objects

3224 *

Number of Samsung NASA objects available into Intesis.

* There are different models of Intesis BACnet Server – Samsung NASA AC each one with different capacity. The
table above shows the capacity for the top model (with maximum capacity).

Their order codes are:

▪ INBACSAM004O000: Model supporting up to 4 indoor units
▪ INBACSAM008O000: Model supporting up to 8 indoor units
▪ INBACSAM016O000: Model supporting up to 16 indoor units
▪ INBACSAM064O000: Model supporting up to 64 indoor units

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

11 / 131

2 Protocol Implementation Conformance Statement

BACnet Protocol Implementation Conformance Statement (PICS)

Date: 2017-10-26
Vendor Name: HMS Industrial Networks S.L.U
Product Name: Intesis-BACnet-Samsung AC
Product Model Number: INBACSAM---O000
Application Software Version: 0.0.0.2
Firmware Revision: 12.1.0.3
BACnet Protocol Revision: 12

Product Description:

SAMSUNG to BACnet Gateway

Abstraction of Samsung air conditioning system properties and functionalities as BACnet Objects.
Capacity of 4, 8, 16 or 64 indoor units depending on product version.

BACnet Standardized Device Profile (Annex L):

BACnet Operator Workstation (B-OWS)
BACnet Building Controller (B-BC)
BACnet Advanced Application Controller (B-AAC)
BACnet Application Specific Controller (B-ASC)
BACnet Smart Sensor (B-SS)
BACnet Smart Actuator (B-SA)

Additional BACnet Interoperability Building Blocks Supported (Annex K):
Reference of BIBBs List

Segmentation Capability:

Segmented request supported No Yes Window Size · 16 ·
Segmented responses supported No Yes Window Size · 16 ·

Data Link Layer Options:

BACnet IP, (Annex J)
BACnet IP, (Annex J), Foreign Device
ISO 8802-3, Ethernet (Clause 7)
ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s) ____
MS/TP master (Clause 9), baud rate(s): 9600, 19200, 38400, 57600, 76800, 115200
MS/TP slave (Clause 9), baud rate(s):
Point-To-Point, EIA 232 (Clause 10), baud rate(s):
Point-To-Point, modem, (Clause 10), baud rate(s):
LonTalk, (Clause 11), medium: _____
Other:

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

12 / 131

Device Address Binding:

Is static device binding supported? (This is currently necessary for two-way communication with
MS/TP slaves and certain other devices.) Yes No

Networking Options:

Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
Annex H, BACnet Tunneling Router over IP
BACnet/IP Broadcast Management Device (BBMD)

Does the BBMD support registrations by Foreign Devices? Yes No

Character Sets Supported

Indicating support for multiple character sets does not imply that they can all be supported simultaneously.

ISO 10646 (UTF-8) IBM



/Microsoft DBCS ISO 8859-1

ISO 10646 (UCS-2) ISO 10646 (UCS-4) JIS X 0208

Gateway

If this product is a communication gateway, describe the types of non-BACnet equipment/network(s) that the gateway
supports:

Samsung NASA Air Conditioning System

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

13 / 131

3 BACnet Interoperability Building Blocks Supported (BIBBs)

Data Sharing BIBBs

BIBB Type

Active

BACnet Service

Initiate

Execute

DS-RP-A

Data Sharing-ReadProperty–A

ReadProperty

DS-RP-B

Data Sharing-ReadProperty–B

ReadProperty

DS-RPM-A

Data Sharing-ReadPropertyMultiple–A

ReadPropertyMultiple

DS-RPM-B

Data Sharing-ReadPropertyMultiple–B

ReadPropertyMultiple

DS-RPC-A

Data Sharing-ReadPropertyConditiona–A

ReadPropertyConditional

DS-RPC-B

Data Sharing-ReadPropertyConditional–B

ReadPropertyConditional

DS-WP-A

Data Sharing-WriteProperty–A

WriteProperty

DS-WP-B

Data Sharing-WriteProperty–B

WriteProperty

DS-WPM-A

Data Sharing-WritePropertyMultiple–A

WritePropertyMultiple

DS-WPM-B

Data Sharing-WritePropertyMultiple–B

WritePropertyMultiple

DS-COV-A

Data Sharing-COV–A
SubscribeCOV

ConfirmedCOVNotification

UnconfirmedCOVNotification

DS-COV-B

Data Sharing-COV–B
SubscribeCOV

ConfirmedCOVNotification

UnconfirmedCOVNotification

DS-COVP-A

Data Sharing-COVP–A
SubscribeCOVProperty

ConfirmedCOVNotification

UnconfirmedCOVNotification

DS-COVP-B

Data Sharing-COVP–B
SubscribeCOVProperty

ConfirmedCOVNotification

UnconfirmedCOVNotification

DS-COVU-A

Data Sharing-COV-Unsubscribed–A

UnconfirmedCOVNotification

DS-COVU-B

Data Sharing-COV- Unsubscribed -B

UnconfirmedCOVNotification

Alarm and Event Management BIBBs

BIBB Type

Active

BACnet Service

Initiate

Execute

AE-N-A

Alarm and Event-Notification–A
ConfirmedEventNotification

UnconfirmedEventNotification

AE-N-I-B

Alarm and Event-Notification Internal–B
ConfirmedEventNotification

UnconfirmedEventNotification

AE-N-E-B

Alarm and Event-Notification External–B
ConfirmedEventNotification

UnconfirmedEventNotification

AE-ACK-A

Alarm and Event-ACK–A

AcknowledgeAlarm

AE-ACK-B

Alarm and Event-ACK–B

AcknowledgeAlarm

AE-ASUM-A

Alarm and Event-Alarm Summary–A

GetAlarmSummary

AE-ASUM-B

Alarm and Event-Alarm Summary–B

GetAlarmSummary

AE-ESUM-A

Alarm and Event-Enrollment Summary-A

GetEnrollmentSummary

AE-ESUM-B

Alarm and Event-Enrollment Summary-B

GetEnrollmentSummary

AE-INFO-A

Alarm and Event-Information–A

GetEventInformation

AE-INFO-B

Alarm and Event-Information–B

GetEventInformation

AE-LS-A

Alarm and Event-LifeSafety–A

LifeSafetyOperation

AE-LS-B

Alarm and Event-LifeSafety–B

LifeSafetyOperation

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

14 / 131

Scheduling BIBBs

Trending BIBBs

Network Management BIBBs

BIBB Type

Active

BACnet Service

Initiate

Execute

SCHED-A

Scheduling–A
(must support DS-RP-A and DS-WP-A)

SCHED-I-B

Scheduling-Internal–B

(shall support DS-RP-B and DS-WP-B)
(shall also support ether DM-TS-B or DS-UTC-B)

SCHED-E-B

Scheduling-External–B
(shall support SCHED-I-B and DS-WP-A)

BIBB Type

Active

BACnet Service

Initiate

Execute

T-VMT-A

Trending - Viewing and Modifying Trends–A

ReadRange

T-VMT-I-B

Trending - Viewing and Modifying Trends Inernal–B

ReadRange

T-VMT-E-B

Trending - Viewing and Modifying Trends External–B

ReadRange

T-ATR-A

Trending - Automated Trend Retrieval–A
ConfirmedEventNotification

ReadRange

T-ATR-B

Trending - Automated Trend Retrieval–B
ConfirmedEventNotification

ReadRange

BIBB Type

Active

BACnet Service

Initiate

Execute

NM-CE-A

Network Management - Connection
Establishment–A

Establish-Connection-To­Network

Disconnect-Connection-To­Network

NM-CE-B

Network Management - Connection
Establishment– B

Establish-Connection-To­Network

Disconnect-Connection-To­Network

NM-RC-A

Network Management - Router Configuration–A

Who-Is-Router-To-Network

I-Am-Router-To-Network

I-Could-Be-Router-To­Network

Initialize-Routing-Table

Initialize-Routing-Table-Ack

NM-RC-B

Network Management - Router Configuration–B
Who-Is-Router-To-Network

I-Am-Router-To-Network

Initialize-Routing-Table

Initialize-Routing-Table-Ack

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

15 / 131

Device Management BIBBs

BIBB Type

Active

BACnet Service

Initiate

Execute

DM-DDB-A

Device Management - Dynamic Device Binding–A
Who-Is

I-Am

DM-DDB-B

Device Management - Dynamic Device Binding–B
Who-Is

I-Am

DM-DOB-A

Device Management - Dynamic Object Binding–A
Who-Has

I-Have

DM-DOB-B

Device Management - Dynamic Object Binding–B
Who-Has

I-Have

DM-DCC-A

Device Management - DeviceCommunicationControl–A

DeviceCommunicationControl

DM-DCC-B

Device Management - DeviceCommunicationControl–B

DeviceCommunicationControl

DM-PT-A

Device Management - PrivateTransfer–A
ConfirmedPrivateTransfer

UnconfirmedPrivateTransfer

DM-PT-B

Device Management - PrivateTransfer–B
ConfirmedPrivateTransfer

UnconfirmedPrivateTransfer

DM-TM-A

Device Management - Text Message–A
ConfirmedTextMessage

UnconfirmedTextMessage

DM-TM-B

Device Management - Text Message–B
ConfirmedTextMessage

UnconfirmedTextMessage

DM-TS-A

Device Management - TimeSynchronization–A

TimeSynchronization

DM-TS-B

Device Management - TimeSynchronization–B

TimeSynchronization

DM-UTC-A

Device Management - UTCTimeSynchronization–A

UTCTimeSynchronization

DM-UTC-B

Device Management - UTCTimeSynchronization–B

UTCTimeSynchronization

DM-RD-A

Device Management - ReinitializeDevice–A

ReinitializeDevice

DM-RD-B

Device Management - ReinitializeDevice–B

ReinitializeDevice

DM-BR-A

Device Management - Backup and Restore–A
AtomicReadFile

AtomicWriteFile

CreateObject

ReinitializeDevice

DM-BR-B

Device Management - Backup and Restore–B
AtomicReadFile

AtomicWriteFile

ReinitializeDevice

DM-R-A

Device Management - Restart–A

UnconfimedCOVNotification

DM-R-B

Device Management - Restart–B

UnconfimedCOVNotification

DM-LM-A

Device Management - List Manipulation–A
AddListElement

RemoveListElement

DM-LM-B

Device Management - List Manipulation–B
AddListElement

RemoveListElement

DM-OCD-A

Device Management - Object Creation and Deletion–A
CreateObject

DeleteObject

DM-OCD-B

Device Management - Object Creation and Deletion–B
CreateObject

DeleteObject

DM-VT-A

Device Management - Virtual Terminal–A
VT-Open

VT-Close

VT-Data

DM-VT-B

Device Management - Virtual Terminal–B
VT-Open

VT-Close

VT-Data

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

16 / 131

4 Service Types

Service type

Service name

Supported

Remarks

Alarm and Event
Services

AcknowledgeAlarm

ConfirmedCOVNotification

ConfirmedEventNotification

GetAlarmSummary

GetEnrollmentSummary

SubscribeCOV

File Access Services

AtomicReadFile

AtomicWriteFile

Object Access
Services

AddListElement

RemoveListElement

CreateObject

DeleteObject

ReadProperty

ReadPropertyConditional

ReadPropertyMultiple

ReadRange

WriteProperty

WritePropertyMultiple

Remote Device
Management
Services

DeviceComminicationControl

ConfirmedPrivateTransfer

ConfirmedTextMessage

ReinitializeDevice

Virtual Terminal
Services

VtOpen

VtClose

VtData

Security Services

Authenticate

RequestKey

Unconfirmed
Services

I-Am

I-Have

UnconfirmedCOVNotification

UnconfirmedEventNotification

UnconfirmedPrivateTransfer

UnconfirmedTextMessage

TimeSynchronization

UtcTimeSynchronization

Who-Has

Who-Is

LifeSafetyOperation

SubscribeCOVProperty

GetEventInformation

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

17 / 131

5 Objects

Supported Object Types

The objects supported are shown in the table below.

Object Type

ID

Supported

Management Point

Analog-Input

0

OxxUxx_Setpoint_S
OxxUxx_Room_Temperature
OxxUxx_Disch.Setpoint Cool IU_S
OxxUxx_Disch.Setpoint Cool AHU_S
OxxUxx_Disch.Setpoint Heat IU_S
OxxUxx_Disch.Setpoint Heat AHU_S
OxxUxx_Disch. Current Temp.
OxxUxx_Unit Error code
OxxUxx_Error Slave Chiller Unit
OxxUxx_Slave Chiller in Error
OxxUxx_HotWater Setpoint HE_S
OxxUxx_HotWater Setpoint HT_S
OxxUxx_HotWater Setpoint EHS_S
OxxUxx_HotWater Current Temp.
OxxUxx_WaterIn Temperature
OxxUxx_WaterOut Temperature, 31
OxxUxx_WaterOut Setpoint HE_S
OxxUxx_WaterOut Setpoint HT_S
OxxUxx_WaterOut Setpoint EHS_S
OxxUxx_WaterOut Setpoint CHILL_S
OxxUxx_WaterOut Average Temp.

Analog-Output

1

Temperature Setpoint (all units)
OxxUxx_Setpoint_C
OxxUxx_Disch.Setpoint Cool IU_C
OxxUxx_Disch.Setpoint Cool AHU_C
OxxUxx_Disch.Setpoint Heat IU_C
OxxUxx_Disch.Setpoint Heat AHU_C
OxxUxx_HotWater Setpoint HE_C
OxxUxx_HotWater Setpoint HT_C
OxxUxx_HotWater Setpoint EHS_C
OxxUxx_WaterOut Setpoint HE_C
OxxUxx_WaterOut Setpoint HT_C
OxxUxx_WaterOut Setpoint EHS_C
OxxUxx_WaterOut Setpoint CHILL_C

Analog-Value

2

Averaging

18

Binary-Input

3

OUxx_Communication Error OU
OU Addressing Error
OxxUxx_On/Off_S
OxxUxx_Vane position swing_S
OxxUxx_FilterSign
OxxUxx_RC Restriction_S
OxxUxx_HotWater On/Off_S
OxxUxx_Vent. On/Off_S
OXXUXX_WindFree_S
OXXUXX_Air Clean_S

Binary-Output

4

On/Off (all units)
Vane position swing (all units)
Vent. On/Off (all units)
Hot Water On/Off (all units)
OxxUxx_On/Off_C
OxxUxx_Vane position swing_C
OxxUxx_FilterReset
OxxUxx_RC Restriction_C
OxxUxx_Buzzer Sound
OxxUxx_HotWater On/Off_C
OxxUxx_Vent. On/Off_C
OXXUXX_WindFree_C

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

18 / 131

OXXUXX_Air Clean_C

Binary-Value

5

Calendar

6

Command

7

Device

8

Device INBACSAM---O000

Event-Enrollment

9

File

10

Group

11

Life-Safety-Point

21

Life-Safety-Zone

22

Loop

12

Multistate-Input

13

OxxUxx_Mode IU/AHU_S
OxxUxx_Mode HE/EHS_S
OxxUxx_Mode ERV+_S
OxxUxx_Mode CHILLER_S
OxxUxx_FanSpeed_S
OxxUxx_Communication Status
OxxUxx_Unit type
OxxUxx_HotWater Mode HE/HT_S
OxxUxx_HotWater Mode EHS_S
OxxUxx_Vent. Mode_S
OxxUxx_Vent. FanSpeed_S
OXXUXX_360 CST Air Flow_S

Multistate-Output

14

Mode (all units)
FanSpeed (all units)
OxxUxx_Mode IU/AHU_C
OxxUxx_Mode HE/EHS_C
OxxUxx_Mode ERV+_C
OxxUxx_Mode CHILLER_C
OxxUxx_FanSpeed_C
OxxUxx_HotWater Mode HE/HT_C
OxxUxx_HotWater Mode EHS_C
OxxUxx_Vent. Mode_C
OxxUxx_Vent. FanSpeed_C
OXXUXX_360 CST Air Flow_C

Multistate-Value

19

Notification-Class

15

Program

16

Schedule

17

Trend-Log

20

Trend-Log-Multiple

27

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

19 / 131

Member objects

5.2.1 Type: Gateway

Object-name

Description

Object-type

Object-instance

Device INBACSAM---O000

SAMSUNG to BACnet Gateway

Device

246

OU00_Communication Error OU

BI

0

OU01_Communication Error OU

BI

1

OU02_Communication Error OU

BI

2

OU03_Communication Error OU

BI

3

OU04_Communication Error OU

BI

4

OU05_Communication Error OU

BI

5

OU06_Communication Error OU

BI

6

OU07_Communication Error OU

BI

7

OU08_Communication Error OU

BI

8

OU09_Communication Error OU

BI

9

OU10_Communication Error OU

BI

10

OU11_Communication Error OU

BI

11

OU12_Communication Error OU

BI

12

OU13_Communication Error OU

BI

13

OU14_Communication Error OU

BI

14

OU15_Communication Error OU

BI

15

OU Addressing Error

BI

16

5.2.2 Type: Central control

Object-name

Description

Object-type

Object-instance

On/Off (all units)

BO

0

Mode (all units)

MO

0

FanSpeed (all units)

MO

1

Vane position swing (all units)

BO

1

Temperature Setpoint (all units)

AO

0

Vent. On/Off (all units)

BO

2

Hot Water On/Off (all units)

BO

3

5.2.3 Type: Indoor Unit

Object-name

Description

Object-type

Object-instance

OxxUxx_On/Off_S

BI

(xxx*100) + 0

OxxUxx_On/Off_C

BO

(xxx*100) + 0

OxxUxx_Mode IU/AHU_S

MI

(xxx*100) + 0

OxxUxx_Mode IU/AHU_C

MO

(xxx*100) + 0

OxxUxx_Setpoint_S

AI

(xxx*100) + 0

OxxUxx_Setpoint_C

AO

(xxx*100) + 0

OxxUxx_FanSpeed_S

MI

(xxx*100) + 1

OxxUxx_FanSpeed_C

MO

(xxx*100) + 1

OxxUxx_Vane position swing_S

BI

(xxx*100) + 1

OxxUxx_Vane position swing_C

BO

(xxx*100) + 1

OxxUxx_Room_Temperature

AI

(xxx*100) + 1

OxxUxx_Disch.Setpoint Cool IU_S

AI

(xxx*100) + 2

OxxUxx_Disch.Setpoint Cool IU_C

AO

(xxx*100) + 1

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

20 / 131

OxxUxx_Disch.Setpoint Heat IU_S

AI

(xxx*100) + 3

OxxUxx_Disch.Setpoint Heat IU_C

AO

(xxx*100) + 2

OxxUxx_Disch. Current Temp.

AI

(xxx*100) + 4

OxxUxx_Unit Error code

AI

(xxx*100) + 5

OxxUxx_FilterSign

BI

(xxx*100) + 2

OxxUxx_FilterReset

BO

(xxx*100) + 2

OxxUxx_Communication Status

MI

(xxx*100) + 2

OxxUxx_RC Restriction_S

BI

(xxx*100) + 3

OxxUxx_RC Restriction_C

BO

(xxx*100) + 3

OxxUxx_Buzzer Sound

BO

(xxx*100) + 4

OxxUxx_Unit type

MI

(xxx*100) + 3

OXXUXX_WindFree_S

BI

(xxx*100) + 6

OXXUXX_WindFree_C

BO

(xxx*100) + 7

OXXUXX_Air Clean_S

BI

(xxx*100) + 7

OXXUXX_Air Clean_C

BO

(xxx*100) + 8

OXXUXX_360 CST Air Flow_S

MI

(xxx*100) + 7

OXXUXX_360 CST Air Flow_C

MO

(xxx*100) + 5

5.2.4 Type: HE

Object-name

Description

Object-type

Object-instance

OxxUxx_On/Off_S

BI

(xxx*100) + 0

OxxUxx_On/Off_C

BO

(xxx*100) + 0

OxxUxx_Mode HE/EHS_S

MI

(xxx*100) + 0

OxxUxx_Mode HE/EHS_C

MO

(xxx*100) + 0

OxxUxx_Unit Error code

AI

(xxx*100) + 5

OxxUxx_Communication Status

MI

(xxx*100) + 2

OxxUxx_RC Restriction_S

BI

(xxx*100) + 3

OxxUxx_Unit type

MI

(xxx*100) + 3

OxxUxx_HotWater On/Off_S

BI

(xxx*100) + 4

OxxUxx_HotWater On/Off_C

BO

(xxx*100) + 5

OxxUxx_HotWater Mode HE/HT_S

MI

(xxx*100) + 4

OxxUxx_HotWater Mode HE/HT_C

MO

(xxx*100) + 2

OxxUxx_HotWater Setpoint HE_S

AI

(xxx*100) + 8

OxxUxx_HotWater Setpoint HE_C

AO

(xxx*100) + 3

OxxUxx_HotWater Current Temp.

AI

(xxx*100) + 9

OxxUxx_WaterIn Temperature

AI

(xxx*100) + 10

OxxUxx_WaterOut Temperature

AI

(xxx*100) + 11

OxxUxx_WaterOut Setpoint HE_S

AI

(xxx*100) + 12

OxxUxx_WaterOut Setpoint HE_C

AO

(xxx*100) + 4

5.2.5 Type: HT

Object-name

Description

Object-type

Object-instance

OxxUxx_On/Off_S

BI

(xxx*100) + 0

OxxUxx_On/Off_C

BO

(xxx*100) + 0

OxxUxx_Unit Error code

AI

(xxx*100) + 5

OxxUxx_Communication Status

MI

(xxx*100) + 2

OxxUxx_RC Restriction_S

BI

(xxx*100) + 3

OxxUxx_Unit type

MI

(xxx*100) + 3

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

21 / 131

OxxUxx_HotWater On/Off_S

BI

(xxx*100) + 4

OxxUxx_HotWater On/Off_C

BO

(xxx*100) + 5

OxxUxx_HotWater Mode HE/HT_S

MI

(xxx*100) + 4

OxxUxx_HotWater Mode HE/HT_C

MO

(xxx*100) + 2

OxxUxx_HotWater Setpoint HT_S

AI

(xxx*100) + 8

OxxUxx_HotWater Setpoint HT_C

AO

(xxx*100) + 3

OxxUxx_HotWater Current Temp.

AI

(xxx*100) + 9

OxxUxx_WaterIn Temperature

AI

(xxx*100) + 10

OxxUxx_WaterOut Temperature

AI

(xxx*100) + 11

OxxUxx_WaterOut Setpoint HT_S

AI

(xxx*100) + 12

OxxUxx_WaterOut Setpoint HT_C

AO

(xxx*100) + 4

5.2.6 Type: EHS

Object-name

Description

Object-type

Object-instance

OxxUxx_On/Off_S

BI

(xxx*100) + 0

OxxUxx_On/Off_C

BO

(xxx*100) + 0

OxxUxx_Mode HE/EHS_S

MI

(xxx*100) + 0

OxxUxx_Mode HE/EHS_C

MO

(xxx*100) + 0

OxxUxx_Unit Error code

AI

(xxx*100) + 5

OxxUxx_Communication Status

MI

(xxx*100) + 2

OxxUxx_RC Restriction_S

BI

(xxx*100) + 3

OxxUxx_Unit type

MI

(xxx*100) + 3

OxxUxx_HotWater On/Off_S

BI

(xxx*100) + 4

OxxUxx_HotWater On/Off_C

BO

(xxx*100) + 5

OxxUxx_HotWater Mode EHS_S

MI

(xxx*100) + 4

OxxUxx_HotWater Mode EHS_C

MO

(xxx*100) + 2

OxxUxx_HotWater Setpoint EHS_S

AI

(xxx*100) + 8

OxxUxx_HotWater Setpoint EHS_C

AO

(xxx*100) + 3

OxxUxx_HotWater Current Temp.

AI

(xxx*100) + 9

OxxUxx_WaterIn Temperature

AI

(xxx*100) + 10

OxxUxx_WaterOut Temperature

AI

(xxx*100) + 11

OxxUxx_WaterOut Setpoint EHS_S

AI

(xxx*100) + 12

OxxUxx_WaterOut Setpoint EHS_C

AO

(xxx*100) + 4

5.2.7 Type: AHU

Object-name

Description

Object-type

Object-instance

OxxUxx_On/Off_S

BI

(xxx*100) + 0

OxxUxx_On/Off_C

BO

(xxx*100) + 0

OxxUxx_Mode IU/AHU_S

MI

(xxx*100) + 0

OxxUxx_Mode IU/AHU_C

MO

(xxx*100) + 0

OxxUxx_Setpoint_S

AI

(xxx*100) + 0

OxxUxx_Setpoint_C

AO

(xxx*100) + 0

OxxUxx_Room_Temperature

AI

(xxx*100) + 1

OxxUxx_Disch.Setpoint Cool AHU_S

AI

(xxx*100) + 2

OxxUxx_Disch.Setpoint Cool AHU_C

AO

(xxx*100) + 1

OxxUxx_Disch.Setpoint Heat AHU_C

AI

(xxx*100) + 3

OxxUxx_Disch.Setpoint Heat AHU_C

AO

(xxx*100) + 2

OxxUxx_Disch. Current Temp.

AI

(xxx*100) + 4

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

22 / 131

OxxUxx_Unit Error code

AI

(xxx*100) + 5

OxxUxx_FilterSign

BI

(xxx*100) + 2

OxxUxx_Communication Status

MI

(xxx*100) + 2

OxxUxx_RC Restriction_S

BI

(xxx*100) + 3

OxxUxx_RC Restriction_C

BO

(xxx*100) + 3

OxxUxx_Unit type

MI

(xxx*100) + 3

5.2.8 Type: ERV

Object-name

Description

Object-type

Object-instance

OxxUxx_Unit Error code

AI

(xxx*100) + 5

OxxUxx_FilterSign

BI

(xxx*100) + 2

OxxUxx_FilterReset

BO

(xxx*100) + 2

OxxUxx_Communication Status

MI

(xxx*100) + 2

OxxUxx_RC Restriction_S

BI

(xxx*100) + 3

OxxUxx_RC Restriction_C

BO

(xxx*100) + 3

OxxUxx_Unit type

MI

(xxx*100) + 3

OxxUxx_Vent. On/Off_S

BI

(xxx*100) + 5

OxxUxx_Vent. On/Off_C

BO

(xxx*100) + 6

OxxUxx_Vent. Mode_S

MI

(xxx*100) + 5

OxxUxx_Vent. Mode_C

MO

(xxx*100) + 3

OxxUxx_Vent. FanSpeed_S

MI

(xxx*100) + 6

OxxUxx_Vent. FanSpeed_C

MO

(xxx*100) + 4

5.2.9 Type: ERV+

Object-name

Description

Object-type

Object-instance

OxxUxx_On/Off_S

BI

(xxx*100) + 0

OxxUxx_On/Off_C

BO

(xxx*100) + 0

OxxUxx_Mode ERV+_S

MI

(xxx*100) + 0

OxxUxx_Mode ERV+_C

MO

(xxx*100) + 0

OxxUxx_Unit Error code

AI

(xxx*100) + 5

OxxUxx_FilterSign

BI

(xxx*100) + 2

OxxUxx_FilterReset

BO

(xxx*100) + 2

OxxUxx_Communication Status

MI

(xxx*100) + 2

OxxUxx_RC Restriction_S

BI

(xxx*100) + 3

OxxUxx_RC Restriction_C

BO

(xxx*100) + 3

OxxUxx_Unit type

MI

(xxx*100) + 3

OxxUxx_Vent. On/Off_S

BI

(xxx*100) + 5

OxxUxx_Vent. On/Off_C

BO

(xxx*100) + 6

OxxUxx_Vent. Mode_S

MI

(xxx*100) + 5

OxxUxx_Vent. Mode_C

MO

(xxx*100) + 3

OxxUxx_Vent. FanSpeed_S

MI

(xxx*100) + 6

OxxUxx_Vent. FanSpeed_C

MO

(xxx*100) + 4

5.2.10 Type: CHILLER

Object-name

Description

Object-type

Object-instance

OxxUxx_On/Off_S

BI

(xxx*100) + 0

OxxUxx_On/Off_C

BO

(xxx*100) + 0

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

23 / 131

OxxUxx_Mode CHILLER_S

MI

(xxx*100) + 0

OxxUxx_Mode CHILLER_C

MO

(xxx*100) + 0

OxxUxx_Unit Error code

AI

(xxx*100) + 5

OxxUxx_Error Slave Chiller Unit

AI

(xxx*100) + 6

OxxUxx_Slave Chiller in Error

AI

(xxx*100) + 7

OxxUxx_Communication Status

MI

(xxx*100) + 2

OxxUxx_RC Restriction_S

BI

(xxx*100) + 3

OxxUxx_RC Restriction_C

BO

(xxx*100) + 3

OxxUxx_Unit type

MI

(xxx*100) + 3

OxxUxx_WaterOut Setpoint CHILL_S

AI

(xxx*100) + 12

OxxUxx_WaterOut Setpoint CHILL_C

AO

(xxx*100) + 4

OxxUxx_WaterOut Average Temp.

AI

(xxx*100) + 13

Objects and properties

Below you can find relevant information for the objects and properties.

Object_Identifier: In the Device Object, the value of object instance is configurable through LinkBoxBACnet.
See Table 5.1 in order to obtain the name of each object.

Table 5.1 Objects and properties variables and descriptions

Object_Name: In the Device Object, this string is configurable through LinkBoxBACnet. See Table 5.1 in order

to obtain the name of each object.

Description: In the Device Object, this string is configurable through LinkBoxBACnet. See Table 5.1 in order to
obtain the description of each object.

Relinquish_Default: In Binary Outputs, Multistate Outputs and Multistate Values, the value of

Present_Value property will be read.

Priority_Array: In Binary Outputs, Multistate Outputs and Multistate Values, Priority_Array[16] will acquire

the value of Present_Value property and Priority_Array[1]~[15] will be NULL.

State_Text: In Multistate Outputs, Multistate Outputs and Multistate Values, it cannot be read the whole

array at once, so “Array Index” must be specified in order to obtain the text of the corresponding state.

Variable

Description

"Oxx"

Outdoor Unit address (0..15)

"Uxx"

Indoor Unit address (0..63)

"xxx"

Indoor Unit identifier (1..64)

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

24 / 131

5.3.1 Device INBACSAM---O000 (Device Object Type)

Property Identifier

Property Datatype

Value

ASHRAE

IBOX

Object_Identifier

BACnetObjectIdentifier

(Device, 246)

R R Object_Name

CharacterString

"Device INBACSAM---O000"

R R Object_Type

BACnetObjectType

DEVICE (8) (Device Object Type)

R R System_Status

BACnetDeviceStatus

OPERATIONAL (0)

R

R

Vendor_Name

CharacterString

"HMS Industrial Networks S.L.U"

R R Vendor_Identifier

Unsigned16

246 R R

Model_Name

CharacterString

"INBACSAM---O000"

R R Firmware_Revision

CharacterString

"12.1.0.3"

R

R

Application_Software_
Version

CharacterString

"1.0.0.0"

R

R

Location

CharacterString

"" O - Description

CharacterString

“SAMSUNG to BACnet Gateway"

O R

Protocol_Version

Unsigned

1 R R

Protocol_Revision

Unsigned

12 R R

Protocol_Services_
Supported

BACnetServiceSupported

Refer to section 4 [Service Types]

R

R

Protocol_Object_Types_
Supported

BACnetObjectTypes
Supported

Refer to section ¡Error! No se encuentra el o
rigen de la referencia. [Object Types]

R

R

Object_List

BACnetArray[N] of
BACnetObjectIdentifier

BACnetARRAY[N]

R R Structured_Object_List

BACnetArray[N] of
BACnetObjectIdentifier

- O -

Max_APDU_Length_
Accepted

Unsigned

480 when MSTP / 1476 when BACnet/IP

R

R

Segmentation_Supported

BACnetSegmentation

SEGMENTED-BOTH (0)

R

R

Max_Segments_accepted

Unsigned

16 O R

VT_Classes_Supported

List of BACnetVTClass

- O -

Active_VT_Sessions

List of BACnetVTSession

- O -

Local_Date

Date

Current date

O R Local_Time

Time

Current time

O R UTC_Offset

INTEGER

-

O

-

Daylight_Savings_Status

BOOLEAN

-

O

-

APDU_Segment_Timeout

Unsigned

3000 R R

APDU_Timeout

Unsigned

3000 R R

Number_of_APDU_
Retries

Unsigned

3 R R

List_Of_Session_Keys

List of
BACnetSessionKey

- O -

Time_Synchronization_
Recipients

List of BACnetRecipient

- O -

Max_Master * **

Unsigned

127 R W

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

25 / 131

Max_Info_Frames *

Unsigned

1 O R

Device_Address_Binding

List of
BACnetAddressBinding

NULL (empty)

R

R

Database_Revision

Unsigned

0 R R

Configuration_Files

BACnetArray[N] of
BACnetObjectIdentifier

- O -

Last_Restore_Time

BACnetTimeStamp

- O -

Backup_Failure_Timeout

Unsigned16

- O -

Active_COV_
Subscriptions

List of
BACnetCOVSubscription

List of BACnetCOVSubscription

O

R

Slave_Proxy_Enable

BACnetArray[N] of
BOOLEAN

- O -

Manual_Slave_Address_
Binding

List of
BACnetAddressBinding

- O -

Auto_Slave_Discovery

BACnetArray[N] of
BOOLEAN

- O -

Slave_Address_Binding

BACnetAddressBinding

- O -

Last_Restart_Reason

BACnetRestartReason

- O -

Time_Of_Device_Restart

BACnetTimeStamp

- O -

Restart_Notification_
Recipients

List of BACnetRecipient

- O -

UTC_Time_
Synchronization_
Recipients

List of BACnetRecipient

- O -

Time_Synchronization_
Interval

Unsigned

- O -

Align_Intervals

BOOLEAN

- O -

Interval_Offset

Unsigned

- O -

Profile_Name

CharacterString

- O -

* Only available when MSTP is used

** Configurable through the configuration tool.

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

26 / 131

5.3.2 OUxx_Communication Error OU (Binary Input Object Type)

Property Identifier

Property Datatype

Value

ASHRAE

IBOX

Object_Identifier

BACnetObjectIdentifier

(Binary Input, 0..15)

R

R

Object_Name

CharacterString

OUxx_Communication Error OU

R

R

Object_Type

BACnetObjectType

BINARY_INPUT (3)

R

R

Present_Value

BACnetBinaryPV

INACTIVE (0) / ACTIVE (1)

R

R

Description

CharacterString

-

O -

Device_Type

CharacterString

-

O

-

Status_Flags

BACnetStatusFlags

{FALSE, FALSE/TRUE, FALSE, FALSE}

R

R

Event_State

BACnetEventState

STATE_NORMAL (0)

R

R

Reliability

BACnetReliability

NO_FAULT_DETECTED (0),
UNRELIABLE_OTHER (7)

O

R

Out_Of_Service

BOOLEAN

FALSE

R

R

Polarity

BACnetPolarity

NORMAL (0)

R

R

Inactive_Text

CharacterString

“No Error”

O

R

Active_Text

CharacterString

“Error”

O

R

Change_Of_State_Time

BACnetDatetime

- O R

Change_Of_State_Count

Unsigned

- O R Time_Of_State_Count_Reset

BACnetDatetime

- O R

Elapsed_Active_Time

Unsigned

- O R Time_Of_Active_Time_Reset

BACnetDatetime

- O R

Time_Delay

Unsigned

- O R* Notification_Class

Unsigned

- O R*

Alarm_Value

BACnetBinaryPV

- O R* Event_Enable

BACnetEventTransitionBits

-

O

R*

Acked_Transitions

BACnetEventTransitionBits

-

O

R*

Notify_Type

BACnetNotifyType

- O R*

Event_Time_Stamps

BACnetArray[N] of
BACnetTimeStamp

- O R*

Profile_Name

CharacterString

- O -

* Only available when specific object has a Notification Class configured

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

27 / 131

5.3.3 OU Addressing Error (Binary Input Object Type)

Property Identifier

Property Datatype

Value

ASHRAE

IBOX

Object_Identifier

BACnetObjectIdentifier

(Binary Input, 0..15)

R

R

Object_Name

CharacterString

OU Addressing Error

R

R

Object_Type

BACnetObjectType

BINARY_INPUT (3)

R

R

Present_Value

BACnetBinaryPV

INACTIVE (0) / ACTIVE (1)

R

R

Description

CharacterString

-

O -

Device_Type

CharacterString

-

O

-

Status_Flags

BACnetStatusFlags

{FALSE, FALSE/TRUE, FALSE, FALSE}

R

R

Event_State

BACnetEventState

STATE_NORMAL (0)

R

R

Reliability

BACnetReliability

NO_FAULT_DETECTED (0),
UNRELIABLE_OTHER (7)

O

R

Out_Of_Service

BOOLEAN

FALSE

R

R

Polarity

BACnetPolarity

NORMAL (0)

R

R

Inactive_Text

CharacterString

“OU Addressing OK”

O

R

Active_Text

CharacterString

“Manual Addr in OU required”

O

R

Change_Of_State_Time

BACnetDatetime

- O R

Change_Of_State_Count

Unsigned

- O R Time_Of_State_Count_Reset

BACnetDatetime

- O R

Elapsed_Active_Time

Unsigned

- O R Time_Of_Active_Time_Reset

BACnetDatetime

- O R

Time_Delay

Unsigned

- O R* Notification_Class

Unsigned

- O R*

Alarm_Value

BACnetBinaryPV

- O R* Event_Enable

BACnetEventTransitionBits

-

O

R*

Acked_Transitions

BACnetEventTransitionBits

-

O

R*

Notify_Type

BACnetNotifyType

- O R*

Event_Time_Stamps

BACnetArray[N] of
BACnetTimeStamp

- O R*

Profile_Name

CharacterString

- O -

* Only available when specific object has a Notification Class configured

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

28 / 131

5.3.4 On/Off (all units) (Binary Output Object Type)

Property Identifier

Property Datatype

Value

ASHRAE

IBOX

Object_Identifier

BACnetObjectIdentifier

(Binary Output, 0)

R

R

Object_Name

CharacterString

On/Off (all units)

R

R

Object_Type

BACnetObjectType

BINARY_OUTPUT (4)

R

R

Present_Value

BACnetBinaryPV

INACTIVE (0) / ACTIVE (1)

W W

Description

CharacterString

- O - Device_Type

CharacterString

- O -

Status_Flags

BACnetStatusFlags

{FALSE, FALSE, FALSE, FALSE}

R

R

Event_State

BACnetEventState

STATE_NORMAL (0)

R

R

Reliability

BACnetReliability

NO_FAULT_DETECTED (0)

O

R

Out_Of_Service

BOOLEAN

FALSE

R R

Polarity

BACnetPolarity

NORMAL (0)

R

R

Inactive_Text

CharacterString

“Off”

O

R

Active_Text

CharacterString

“On”

O

R

Change_Of_State_Time

BACnetDatetime

- O R

Change_Of_State_Count

Unsigned

- O R

Time_Of_State_Count_Reset

BACnetDatetime

- O R

Elapsed_Active_Time

Unsigned

- O R

Time_Of_Active_Time_Reset

BACnetDatetime

- O R

Minimum_Off_Time

Unsigned32

- O -

Minimum_On_Time

Unsigned32

- O -

Priority_Array

BACnetPriorityArray

BACnetPriorityArray

R

R

Relinquish_Default

BACnetBinaryPV

INACTIVE (0)

R R

Time_Delay

Unsigned

- O R*

Notification_Class

Unsigned

- O R* Feedback_Value

BACnetBinaryPV

- O W

Event_Enable

BACnetEventTransitionBits

-

O R*

Acked_Transitions

BACnetEventTransitionBits

-

O

R*

Notify_Type

BACnetNotifyType

-

O R*

Event_Time_Stamps

BACnetArray[N] of
BACnetTimeStamp

- O R*

Profile_Name

CharacterString

- O -

* Only available when specific object has a Notification Class configured

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

29 / 131

5.3.5 Mode (all units) (Multistate Output Object Type)

Property Identifier

Property Datatype

Value

ASHRAE

IBOX

Object_Identifier

BACnetObjectIdentifier

(Multi-state Output, 0)

R

R

Object_Name

CharacterString

Mode (all units)

R

R

Object_Type

BACnetObjectType

MULTISTATE_OUTPUT (14)

R

R

Present_Value

Unsigned

x W W

Description

CharacterString

-

O

-

Device_Type

CharacterString

- O -

Status_Flags

BACnetStatusFlags

{FALSE, FALSE, FALSE, FALSE}

R

R

Event_State

BACnetEventState

STATE_NORMAL (0)

R

R

Reliability

BACnetReliability

NO_FAULT_DETECTED (0)

O

R

Out_Of_Service

BOOLEAN

FALSE

R

R

Number_Of_States

Unsigned

7

R

R

State_Text

BACnetArray[N] of
CharacterString

Check Mode (all units) table below

O

R

Priority_Array

BACnetPriorityArray

BACnetPriorityArray

R

R

Relinquish_Default

Unsigned

1 R R

Time_Delay

Unsigned

- O R*

Notification_Class

Unsigned

- O R*

Feedback_Value

Unsigned

- O W

Event_Enable

BACnetEventTransitionBits

- O R*

Acked_Transitions

BACnetEventTransitionBits

- O R*

Notify_Type

BACnetNotifyType

- O R*

Event_Time_Stamps

BACnetArray[N] of
BACnetTimeStamp

- O R*

Profile_Name

CharacterString

- O -

* Only available when specific object has a Notification Class configured

Mode (all units) table

Mode interpretation is possible using the value in the following correspondence table.

Pesent_Value

Contents displayed in State_Text

1

Heat

2

Dry

3

Fan

4

Cool

5

Auto

IntesisTM BACnet Server – SAMSUNG NASA AC

User’s Manual r1.2 EN

© HMS Industrial Networks S.L.U. - All rights reserved

This information is subject to change without notice

URL https://www.intesis.com

30 / 131

6

Cool Storage

7

Hot Water
