Inter-Tech AS-21HA HDMI User Manual

Manual

Desktop HDMI KVM Switch

AS-21HA
AS-41HA
AS-22HA

AS-42HA

1 Important information ..................................................................................................... 3

1.1 Introduction ............................................................................................................ 3

1.2 Scope of delivery .................................................................................................... 3

1.3 General information ................................................................................................ 3

2 Safety ................................................................................................................................ 4

2.1 Intended use .......................................................................................................... 4

2.1.1 Environmental ........................................................................................... 4

2.1.2 Disposal .................................................................................................... 4

2.2 General information ................................................................................................ 4

2.3 Danger and protection ............................................................................................ 4

3 Product information ........................................................................................................ 5

3.1 Features ................................................................................................................. 5

3.2 Technical data ........................................................................................................ 5

4 Installation ....................................................................................................................... 7

5 Use .................................................................................................................................... 9

6 FAQ ................................................................................................................................. 11

7 Maintenance ................................................................................................................... 12

8 Disposal ......................................................................................................................... 12

9 Warranty terms .............................................................................................................. 13

10 Contact ........................................................................................................................... 13

Manual Argus HDMI Desktop KVM-Series 3 of 14

08.07.2019

1 Important Information

1.1 Introduction

Thank you for buying an Argus Desktop KVM Switch.
To enjoy this product for a long time we recommend to read this manual carefully and

especially paying attention to the security advices.

1.2 Scope of delivery

1x KVM Switch
1x QIG with safety instructions
1x CD with manual
Cable:
AS-21HA 2x HDMI + 2x USB
AS-41HA 2x HDMI + 4x USB
AS-22HA 4x HDMI + 2x USB
AS-42HA 8x HDMI + 4x USB

The HDMI Cable between KVM-Switch and monitor/s is not included.

1.3 General information

Symbols

Symbol

Meaning

Handling and effects of safety instructions

Dangerous situation, which can retighten violation or
death

Possible damage of property and other important
information.

Manual Argus HDMI Desktop KVM-Series 4 of 14

08.07.2019

2 Safety

2.1 Intended use

2.1.1 Environmental
This product is only for indoor use and connecting of computers.
Don´t use and store it inside humid rooms or near water.
Don´t use it close to source of heat. The additional heat could lead to overheating and

fire.

2.1.2 Disposal
Don´t put this device to normal waste.
Please read the instruction in chapter 8 for disposal of packaging and device.

2.2 General information

Please read this manual carefully before installing or using this product.
Keep this manual and pass it by passing of the product.
Please follow the instructions and warning of this manual before using the product.
The inobservance of this manual can effect violations and damage.
We disclaim liability for violations and damages caused by inobservance of this manual.

2.3 Danger and protection

Don´t damage the cable.
Don´t use patched or damaged cable.
Don´t put the device close to heating.
In case of strange noise or smell pull the power cord out of the socket.
Don´t open the device.
Please ensure, that all cables will be fixed permanently.
Keep the product away from children.
Don´t remove the cable with wet hands (electric strike).
Don´t use the product with wet hands (electric strike).

Manual Argus HDMI Desktop KVM-Series 5 of 14

08.07.2019

Please remove the power cord from socket in case of longer non-use (Could led to
overheating, fire hazard or electric strike).

Keep the product free of dust (Overheating or fire).
Look for sufficient airflow to avoid overheating and fire.
Leave service or cleaning only authorized qualified personnel.

3 Product information

3.1 Features

- Connects 2 or 4 computers with one keyboard and mouse and with one or two
monitors (depending model).

- Auto scan function

- Supports HDCP

- Easy Installation

- Full support for keyboard and mouse over USB.

- Switching by Hot-Keys or directly.

- LED Indicators for selection and connection.

- No software necessary.

- Compatible to all OS.

3.2 Technical data

AS-21HA

AS-41HA

AS-22HA

AS-42HA

PC-ports 2 4 2 4

Consoles

1

HDMI Version

HDMI 1.4b

Resolution

HDMI max: 4K@30Hz (3840x2610@30Hz)

VGA max: 1920x1200@60Hz (1080p) – only with opt. adapter

DVI max: DVI-Dual Link 2K – only with opt. adapter

DP max: 4K@60Hz – only with opt. adapter

HDCP support

Ja

Sound

Dolby True HD

DTS HD Master Audio

Analog Audio (via 3,5mm audio jack)

Port-control

Control keys

Hot keys

USB Emulation

Keyboard/ Mouse
