Military Acronyms
Acronym Description Acronym Description
DSCC Defense Supply Center, Columbus QML Qualified Manufacturers List
COTS Commercial Off-The Shelf QPL Qualified Products List
SMD Standard Microcircuit Drawing VID Vendor Item Drawing
Military ICs
Base Part # Device Description iSim
Screening Level Availability
/883 JM38510/ 5962
Defense ICs
Auxiliary Output
5962M95A0501QXA SMD Version Auxiliary Output Chip M95A0501QXA
5962M95A0501QYA SMD Version Auxilary Output Chip M95A0501QYA
EEPROM
5962-3826701MXAC7200 128k EEPROM MIL-STD-883, 250ns 3826701MXAC7200
5962-3826705MXAC7200 128k x 8 EEPROM, CMOS, MIL-STD-883, 150ns 3826705MXAC7200
5962-3826707MXAC7200 128k x 8 EEPROM, MIL-STD-883C, 120ns 3826707MXAC7200
5962-8863401XAC6833 32k x 8 EEPROM, High Speed, MIL-STD-883, 120ns 8863401XAC6833
5962-8863401ZCC6833 32k x 8-Bit, CMOS EEPROM, High Speed, MILSTD-883, 120ns 8863401ZCC6833
5962-8863403XAC6833 32k x 8 EEPROM, High Speed CMOS, MIL-STD-883, 90ns 8863403XAC6833
5962-9086901MYAC7060 64k x 8 EEPROM CMOS, MIL-STD-883, 250ns 9086901MYAC7060
5962-9086902MYAC7068 64k x 8 EEPROM, CMOS, MIL-STD-883, 250ns 9086902MYAC7068
5962-9086903MXAC7060 64k x 8 EEPROM, CMOS, MIL-STD-883, 200ns 9086903MXA
5962-9086905MXAC7060 64k x 8, CMOS, EEPROM, MIL-STD-883, 150ns 9086905MXA
5962-9086906MXAC7068 64k x 8 EEPROM, CMOS, MIL-STD-883, 150ns 9086906MXAC7068
5962-9086906MYAC7068 64k x 8 EEPROM, CMOS, MIL-STD-883, 150ns 9086906MYA
5962-9086907MXAC7060 64k x 8 CMOS, EEPROM, MIL-STD-883, 120ns 9086907MXA
5962-9086908MYAC7068 64k x 8 EEPROM, CMOS, 120ns 9086908MYA
Interface (RS-232)
5962-0620701Q3A ±15kV ESD Protected, +3.3V, 1µA, 250kbps, RS-232 T ransmitter/Receiver 0620701Q3A
5962-0620702Q3A ±15kV ESD Protected, +3.3V, 1µA, 250kbps, RS-232 T ransmitter/Receiver 0620702Q3A
5962-0620703Q2A ±15kV ESD Protected, +3.3V, 1µA, 250kbps, RS-232 T ransmitter/Receiver 0620703Q2A
5962-0620704Q2A ±15kV ESD Protected, +3.3V, 1µA, 250kbps, RS-232 T ransmitter/Receiver 0620704Q2A
5962-0620705Q3A ±15kV ESD Protected, +5.0V, 1µA, 250kbps, RS-232 T ransmitter/Receiver 0620705Q3A
5962-0620706Q3A ±15kV ESD Protected, +5.0V, 1µA, 250kbps, RS-232 T ransmitter/Receiver 0620706Q3A
5962-0620707Q2A ±15kV ESD Protected, +5.0V, 1µA, 250kbps, RS-232 T ransmitter/Receiver 0620707Q2A
5962-0620708Q2A ±15kV ESD Protected, +5.0V, 1µA, 250kbps, RS-232 T ransmitter/Receiver 0620708Q2A
Multiplexers
HI-506 Single 16 and 8, Differential 8-Channel and 4-Channel CMOS An alog MUXs with Active
Overvoltage Protection
HI-508 Single 16 and 8, Differential 8-Channel and 4-Channel CMOS An alog MUXs with Active
Overvoltage Protection
17-2
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
/883
/883
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Military ICs (Continued)
Base Part # Device Description iSim
HI-509 Analog Multiplexer, 4-Channel Differential, 883 Compliant /883 19008 -8513109
HI-546 Single 16 and 8, Differential 8-Channel and 4-Channel CMOS An alog MUXs with Active
Overvoltage Protection
HI-547 Single 16 and 8, Differential 8-Channel and 4-Channel CMOS An alog MUXs with Active
Overvoltage Protection
HI-548 Single 16 and 8, Differential 8-Channel and 4-Channel CMOS An alog MUXs with Active
Overvoltage Protection
HI-549 Single 16 and 8, Differential 8-Channel and 4-Channel CMOS An alog MUXs with Active
Overvoltage Protection
Operational Amplifiers
HA-5190 150MHz, Fast Settling Operational Amplifiers -8778401
HA-2539 600MHz, Very High Slew Rate Operational Amplifier Y /883 -8778701
HA-5104 Low Noise, High Performance, Quad Operational Amplifier Y /883 -8850201
HA-2544 50MHz, Video Operational Amplifier -8950201
HA-5102 Dual and Quad, 8MHz and 60MHz, Low Noise Operational Amplifiers Y -8954801
HA-5020 100MHz Current Feedback Video Amplifier With Disable Y -8962001
HA-5002 Monolithic, Wideband, High Slew Rate, High Output Current Buffer Y -8963601
HA-2520 Microcircuit, Linear, High Speed, Operational Amplifier, Monolithic Silicon Y /883 12206 -8988002
HFA1130 850MHz, Output Limiting, Low Distortion Current Feedback Operational Amplifier -9467701
HA-2400 40MHz, PRAM Four Channel Programmable Amplifiers /883 -8778301
HA-5101 Low Noise, High Performance Operational Amplifier /883 -8963501
HA-2510 High Slew Rate Operational Amplifier /883 12205
HA-2400 40MHz, PRAM Four Channel Programmable Amplifiers /883 -8778301
HA-4741 Quad Operational Amplifier /883
HA-5127 8.5MHz, Ultra-Low Noise Precision Operational Amplifier /883
5962-0623501QPC 500MHz Rail-to-Rail Amplifier 0623501QPC
5962-0623502QPC 500MHz Rail-to-Rail Amplifier 0623502QPC
5962-0623601QPC 670MHz Low Noise Amplifiers 0623601QPC
5962-0623602QPC 670MHz Low Noise Amplifiers 0623602QPC
5962-0625501QXC 350MHz Fixed Gain Amplifiers with Enable 0625501QXC
5962-0625601QXC 1.4GHz Current Feedback Amplifiers with Enable 0625601QXC
5962-0625602QXC 1.4GHz Current Feedback Amplifiers with Enable 0625602QXC
5962-0721201QXC Video Distribution Amplifier 0721201QXC
5962-0721301QXC 500MHz Rail-to-Rail Amplifiers 0721301QXC
5962-0721302QXC 500MHz Rail-to-Rail Amplifiers 0721302QXC
5962-0721303QYC 500MHz Rail-to-Rail Amplifiers 0721303QYC
Screening Level Availability
/883 JM38510/ 5962
/883 19002 -8513101
/883 19004 -8513102
/883 19005 7705202 #
/883 19006 -8513103
17
Switches
DG201A Quad SPST CMOS Analog Switch /883 12302
DG411 Monolithic Quad SPST, CMOS Analog Switches /883 9073101MEA
HI-200 Dual SPDT CMOS Analog Switch /883
17-3
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
Military/Space
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Military ICs (Continued)
Base Part # Device Description iSim
HI-201 Dual/Quad SPST, CMOS Analog Switches /883
HI-201HS High Speed, Quad SPST, CMOS Analog /883
HI-303 Dual SPDT CMOS Analog Switch /883
HI-5051 CMOS Analog Switches /883 8100622 #
HI-5043 CMOS Analog Switches /883 8100612 #
HI-5046A CMOS Analog Switches /883 8100617 #
Buffers
HA-5002 Monolithic, Wideband, High Slew Rate, High Output Current Buffer /883 -8963601
Comparators
HA-4902 Precision Quad Comparators /883 -8686001
Micro + Peripherals
HD-6409 CMOS Manchester Encoder-Decod er /883
82C52 CMOS Serial Controller Interface N
82C37A CMOS High Performance Programmable DMA Controller -9054302
82C54 CMOS Programmable Interval Timer N 8406501, 02 #
82C55A CMOS Programmable Peripheral Interface N 8406602 #
82C59A CMOS Priority Interrupt Controller N -8501601, 02
82C84A CMOS Clock Generator Driver 8406801 #
82C88 CMOS Bus Controller 8406901 #
82C89 CMOS Bus Arbiter N -9067801
MP82C55A CMOS Programmable Peripheral Interface
MQ82C55A CMOS Programmable Peripheral Interface
MS82C55A CMOS Programmable Peripheral Interface
80C286 High Performance Microprocessor with Memory Management and Protection /883 -9067801
80C86 CMOS 16-Bit Microprocessor /883
80C88 CMOS 8-Bit/16-Bit Microprocessor /883
HD-4702 CMOS Programmable Bit Rate Generator /883
HD-6402 CMOS Universal Asynchronous Receiver Transmitter (UART) /883 -9052502
Screening Level Availability
/883 JM38510/ 5962
D/A Converters
HI-565A High Speed, Monolithic D/A Converter with Reference /883
A/D Converters
HI-674A Complete, 12-Bit A/D Converters with Microprocessor Interface /883
RAM
HM-6514 1024x4 CMOS RAM /883
HM-6514B 1024x4 CMOS RAM /883
HM-65162 2kx8 Asynchronous CMOS Static RAM /883 29104 # 8403602, 06 #
HM-6551 256x4 CMOS RAM /883
HM-65642 8kx8 Asynchronous CMOS Static RAM /883
17-4
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Military ICs (Continued)
Base Part # Device Description iSim
HM-6617 2kx8 CMOS PROM /883
HM-6642 512x8 CMOS PROM /883
MicroP/C - Data Communications
HD-15530 CMOS Manchester Encoder-Decoder N 7802901 #
HD-15531 CMOS Manchester Encoder-Decoder -9054901
HS-3182 ARINC 429 Bus Interface Line Driver Circuit N -8687901
HS-3282 CMOS ARINC Bus Interface Circuit N -8688001
VID/EP
Digital Potentiometers (DCPs) - Digitally Controlled Potentiometers (DCPs) - Non-Volatile - Single - 128 Tap
ISL22316WMUEP Single Digitally Controlled Potentiometer (XDCP™), Low Noise, Low Power I2C® Bus,
128 Taps
2
ISL22326WMVEP Dual Digitally Controlled Potentiometers (XDCP™) Low Noise, Low Power, I
128 Taps
ISL22346WMVEP Quad Digitally Controlled Potentiometers (XDCP™), Low Noise, Low Power I
128 Taps
Linear Regulation - Low Power
ISL9000AMRNCEP Dual LDO with Low Noise, Very High PSRR and Low I
Q
PWM Controllers
ISL6420BMAEP Enhanced Product (EP) Advanced Single Synchronous Buck Pulse-Widt h Modulation
ISL65426MREP Enhanced Product (EP) 6.0A Dual Synchronous Buck Regulator with Integrated
ISL8840AMBEP Enhanced Product (EP) High Performance Industry Standard Single-Ended Current
ISL8841AMBEP Enhanced Product (EP) High Performance Industry Standard Single-Ended Current
ISL8842AMBEP Enhanced Product (EP) High Performance Industry Standard Single-Ended Current
ISL8843AMBEP Enhanced Product (EP) High Performance Industry Standard Single-Ended Current
ISL8844AMBEP Enhanced Product (EP) High Performance Industry Standard Single-Ended Current
ISL8845AMBEP Enhanced Product (EP) High Performance Industry Standard Single-Ended Current
(PWM) Controller
MOSFETs
Mode PWM Controllers
Mode PWM Controllers
Mode PWM Controllers
Mode PWM Controllers
Mode PWM Controllers
Mode PWM Controllers
Switching Regulation - Single Output - Integrated FET DC/DC - Buck
ISL8560MREP DC/DC Power Switching Regulator V62/08608-01XB
C® Bus,
2
C® Bus,
Screening Level Availability
/883 JM38510/ 5962
V62/08603-01XB
V62/08604-01XE
V62/08605-01XE
V62/08609-01XB
V62/07640-01XB
V62/07639-01XB
V62/07621-01XB
V62/07621-02XB
V62/07621-03XB
V62/07621-04XB
V62/07621-05XB
V62/07621-06XB
17
17-5
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
Military/Space
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Defense IC Test Flows
MIL-PRF-38535 Class Q
(Note 1)
Compliant Non-Compliant
JAN, /883,
Screening Test Conditions Method
Internal Visual Inspection Condition B 2010 X X X X X
Temperature Cycle Condition C 1010 X X X X X
Constant Acceleration Condition E, YI only 2001 X X X X X
Fine Leak Test Condition B 1014 X X X X X
Gross Leak Test Condition C 1014 X X X X X
Pre Burn-In Elec Test Per Applicable Device Specification - X X X X X
Burn-In Test 160 Hrs at 125°C or equivalent 1015 X X X X X
Post BI Elec Test at 25
Percent Defective 5%, Subgroup I - X X Note 2 Note 2 Note 2
Static Test at 125
Static Test at -55
Dynamic or Functional at 25
Dynamic or Functional at 125
Dynamic or Functional at -55
Switching Test at 25
o
C Per Applicable Device Specification - X X X X X
o
C Per Applicable Device Specification - X X X X -
o
C Per Applicable Device Specification - X X X X -
o
C Per Applicable Device Specification - X X X X X
o
C Per Applicable Device Specification - X X X X -
o
C Per Applicable Device Specification - X X X X -
o
C (Note 3) Per Applicable Device Specification - X X X X X
SMD
-8,
/8 /3 /HR /3W
QCI - Group A Inspection - - X X X Note 4 No te 5
QCI - Group B Inspection - - X Note 6 Note 6 N ote 7 No te 6
QCI - Group C Inspection (Note 8) - - X Note 6 Note 6 Note 7 Note 6
QCI - Group D Inspection (Note 8) - - X Note 6 Note 6 Note 7 Note 6
External Visual Inspection - 2009 X X X X X
NOTES:
1. See the Intersil Quality Management Plan for the latest updates on screening flows. (Section 2.2.9) http://www.intersil.com
2. For all types except CA3XXX, PDA is 5%, one reburn-in allowed at 3%. For CA3XXX series device types, PDA is 10%, one reburn-in allowed
at 7%. PDA is in accordance with MIL-PRF-38535.
3. Switching tests are not applicable for linear device types.
4. LTPD = 5 for Subgroup 17 and 9; LTPD = 7 for Subgroups 2 and 3; LTPD = 1- for Subgroups 8A and 8B.
o
5. For /3W, Group A performed at 25
6. Group B, C, and D inspection performed only when specified on purchase order. Generic data is not maintained.
7. Generic data available.
8. Group A, B, C, and D performed per MIL-PRF-38535 Class Q and the Intersil Quality Management Plan.
C only.
17-6
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Products Selection Chart
Device Description Mkt. Number SMD Number Package RH Level
Data Acquisition D/A Converters
High Speed, Monolithic Digital-To-Analog Converter HS0-565BRH-Q 5962R9675502V9A Die (Military Visual) 100krad
High Speed, Monolithic Digital-To-Analog Converter HS1-565BRH-Q 5962R9675502VJC 24 Ld SBDIP 100krad
High Speed, Monolithic Digital-To-Analog Converter HS9-565BRH-Q 5962R9675502VXC 24 Ld FlatPack 100krad
Data Acquisition Multiplexers
Single 16/Differential 8 Channel CMOS Analog Multiplexers with
Active Overvoltage Protection
Single 16/Differential 8 Channel CMOS Analog Multiplexers with
Active Overvoltage Protection
Single 16/Differential 8 Channel CMOS Analog Multiplexers with
Active Overvoltage Protection
Single 16/Differential 8 Channel CMOS Analog Multiplexers with
Active Overvoltage Protection
Single 8/Differential 4 Channel CMOS Analog Multiplexers with
Active Overvoltage Protection
16 Channel CMOS Analog Multiplexer with High-Z Analog
Input Protection
16 Channel CMOS Analog Multiplexer with High-Z Analog
Input Protection
16 Channel CMOS Analog Multiplexer with High-Z Analog
Input Protection
16 Channel CMOS Analog Multiplexer with High-Z Analog
Input Protection
16 Channel CMOS Analog Multiplexer with High-Z Analog
Input Protection
8 Channel CMOS Analog Multiplexer with Overvoltage Protection HS0-508BRH-Q 5962F9674202V9A Die (Military Visual) 300krad
8 Channel CMOS Analog Multiplexer with Overvoltage Protection HS1-508BRH-8 5962F9674202QEC 16 Ld SBDIP 300krad
8 Channel CMOS Analog Multiplexer with Overvoltage Protection HS1-508BRH-Q 5962F9674202VEC 16 Ld SBDIP 300krad
8 Channel CMOS Analog Multiplexer with Overvoltage Protection HS9-508BRH-8 5962F9674202QXC 16 Ld FlatPack 300krad
8 Channel CMOS Analog Multiplexer with Overvoltage Protection HS9-508BRH-Q 5962F9674202VXC 16 Ld FlatPack 300krad
HS0-0546RH-Q 5962D9569301V9A Die (Military Visual) 10krad
HS1B-0546RH-Q 5962D9569301VXC 28 Ld SBDIP 10krad
HS0-0547RH-Q 5962D9569302V9A Die (Military Visual) 10krad
HS1B-0547RH-Q 5962D9569302VXC 28 Ld SBDIP 10krad
HS1B-0548RH-Q 5962D9569401VEC 16 Ld SBDIP 10krad
HS0-1840ARH-Q 5962F9563002V9A Die (Military Visual) 300krad
HS1-1840ARH-8 5962F9563002QXC 28 Ld SBDIP 300krad
HS1-1840ARH-Q 5962F9563002VXC 28 Ld SBDIP 300krad
HS9-1840ARH-8 5962F9563002QYC 28 Ld FlatPack 300krad
HS9-1840ARH-Q 5962F9563002VYC 28 Ld FlatPack 300krad
Data Acquisition Switches
Single Event Hardened Quad SPST, CMOS Analog Switch HS0-201HSRH-Q 5962F9961801V9A Die (Military Visual) 300krad
Single Event Hardened Quad SPST, CMOS Analog Switch HS1-201HSRH-8 5962F9961801QEC 16 Ld SBDIP 300krad
Single Event Hardened Quad SPST, CMOS Analog Switch HS1-201HSRH-Q 5962F9961801VEC 16 Ld SBDIP 300krad
Single Event Hardened Quad SPST, CMOS Analog Switch HS9-201HSRH-8 5962F996 1801QXC 16 Ld FlatPack 300krad
Single Event Hardened Quad SPST, CMOS Analog Switch HS9-201HSRH-Q 5962F9961801VXC 16 Ld FlatPack 300krad
CMOS Dual DPST Analog Switch HS0-302RH-Q 5962R9581201V9A Die (Military Visual) 100krad
CMOS Dual DPST Analog Switch HS1-302RH-8 5962R9581201QCC 14 Ld SBDIP 100krad
CMOS Dual DPST Analog Switch HS1-302RH-Q 5962R9581201VCC 14 Ld SBDIP 100krad
CMOS Dual DPST Analog Switch HS9-302RH-8 5962R9581201QXC 14 Ld FlatPack 100krad
CMOS Dual DPST Analog Switch HS9-302RH-Q 5962R9581201VXC 14 Ld FlatPack 100krad
CMOS Dual SPDT Analog Switch HS9-303ARH-8 5962F9581304QXC 14 Ld FlatPack 300krad
CMOS Dual SPDT Analog Switch HS9-303ARH-Q 5962F9581304VXC 14 Ld FlatPack 300krad
17-7
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
17
Military/Space
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Products Selection Chart (Continued)
Device Description Mkt. Number SMD Number Package RH Level
CMOS Dual SPDT Analog Switch HS0-303ARH-Q 5962F9581304V9A Die (Military Visual) 300krad
CMOS Dual SPDT Analog Switch HS1-303ARH-8 5962F9581304QCC 14 Ld SBDIP 300krad
CMOS Dual SPDT Analog Switch HS1-303ARH-Q 5962F9581304VCC 14 Ld SBDIP 300krad
CMOS Dual SPDT Analog Switch HS1-303RH-8 5962F9581304QCC 14 Ld SBDIP 300krad
CMOS Analog Switch HS0-307RH-Q 5962R9581302V9A Die (Military Visual) 100krad
CMOS Analog Switch HS9-307RH-Q 5962R9581302VXC 14 Ld FlatPack 100krad
CMOS Dual SPDT Analog Switch HS0-390RH-Q 5962R9581303V9A Die (Military Visual) 100krad
CMOS Dual SPDT Analog Switch HS1-390RH-Q 5962R9581303VEC 14 Ld SBDIP 100krad
CMOS Dual SPDT Analog Switch HS9-390RH-8 5962R9581303QYC 14 Ld FlatPack 100krad
CMOS Dual SPDT Analog Switch HS9-390RH-Q 5962R9581303VYC 14 Ld FlatPack 100krad
Data Bus Line Drivers
Quad Differential Line Driver HS0-26C31RH-Q 5962F9666301V9A Die (Military Visual) 300krad
Quad Differential Line Driver HS1-26C31RH-8 5962F9666301QEC 16 Ld SBDIP 300krad
Quad Differential Line Driver HS1-26C31RH-Q 5962F9666301VEC 16 Ld SBDIP 300krad
Quad Differential Line Driver HS9-26C31RH-8 5962F9666301QXC 16 Ld FlatPack 300krad
Quad Differential Line Driver HS9-26C31RH-Q 5962F9666301VXC 16 Ld FlatPack 300krad
3.3V Quad Differential Line Driver HS0-26CLV31RH-Q 5962F9666302V9A Die (Military Visual) 300krad
3.3V Quad Differential Line Driver HS1-26CLV31RH-8 5962F966302QEC 16 Ld SBDIP 300krad
3.3V Quad Differential Line Driver HS1-26CLV31RH-Q 5962F9666302VEC 16 Ld SBDIP 300krad
3.3V Quad Differential Line Driver HS9-26CLV31RH-8 5962F9666302QXC 16 Ld FlatPack 300krad
3.3V Quad Differential Line Driver HS9-26CLV31RH-Q 5962F9666302VXC 16 Ld FlatPack 300krad
Quad Differential Line Driver HS0-26CT31RH-Q 5962F9563201V9A Die (Military Visual) 300krad
Quad Differential Line Driver HS1-26CT31RH-8 5962F9563201QEC 16 Ld SBDIP 300krad
Quad Differential Line Driver HS1-26CT31RH-Q 5962F9563201VEC 16 Ld SBDIP 300krad
Quad Differential Line Driver HS9-26CT31RH-8 5962F9563201QXC 16 Ld FlatPack 300krad
Quad Differential Line Driver HS9-26CT31RH-Q 5962F9563201VXC 16 Ld FlatPack 300krad
Data Bus Line Receivers
Tripl e L i ne Transmitte r, Triple L i ne Receive r, Triple P a rty-line R eceiver HS1-246RH-8 5962R9672301QCC 14 Ld SBDIP 200krad
Tripl e L i ne Transmitte r, Triple L i ne Receive r, Triple P a rty-line R eceiver HS1-246RH-Q 5962R9672301VCC 14 Ld SBDIP 200krad
Tripl e L i ne Transmitte r, Triple L i ne Receive r, Triple P a rty-line R eceiver HS9-246RH-8 5962R9672301QXC 14 Ld FlatPack 200krad
Tripl e L i ne Transmitte r, Triple L i n e R eceiver, T riple Par t y-line Re ceiver HS9-246RH - Q 5962R9672301VXC 14 Ld FlatPack 200krad
Tripl e L i ne Transmitte r, Triple L i ne Receive r, Triple P a rty-line R eceiver HS1-248RH-8 5962R9672302QCC 14 Ld SBDIP 200krad
Tripl e L i ne Transmitte r, Triple L i ne Receive r, Triple P a rty-line R eceiver HS1-248RH-Q 5962R9672302VCC 14 Ld SBDIP 200krad
Tripl e L i ne Transmitte r, Triple L i ne Receive r, Triple P a rty-line R eceiver HS9-248RH-8 5962R9672302QXC 14 Ld FlatPack 200krad
Tripl e L i ne Transmitte r, Triple L i ne Receive r, Triple P a rty-line R eceiver HS9-248RH-Q 5962R9672302VXC 14 Ld FlatPack 200krad
Quad Differential Line Receiver HS0-26C32RH-Q 5962F9568901V9A Die (Military Visual) 300krad
Quad Differential Line Receiver HS1-26C32RH-8 5962F9568901QEC 16 Ld SBDIP 300krad
Quad Differential Line Receiver HS1-26C32RH-Q 5962F9568901VEC 16 Ld SBDIP 300krad
Quad Differential Line Receiver HS9-26C32RH-8 5962F9568901QXC 16 Ld FlatPack 300krad
17-8
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Products Selection Chart (Continued)
Device Description Mkt. Number SMD Number Package RH Level
Quad Differential Line Receiver HS9-26C32RH-Q 5962F9568901VXC 16 Ld FlatPack 300krad
3.3V Quad Differential Line Receiver HS0-26CLV32RH-Q 5962F9568902V9A Die (Military Visual) 300krad
3.3V Quad Differential Line Receiver HS1-26CLV32RH-8 5962F9568902QEC 16 Ld SBDIP 300krad
3.3V Quad Differential Line Receiver HS1-26CLV32RH-Q 5962F9568902VEC 16 Ld SBDIP 300krad
3.3V Quad Differential Line Receiver HS9-26CLV32RH-8 5962F9568902QXC 16 Ld FlatPack 300krad
3.3V Quad Differential Line Receiver HS9-26CLV32RH-Q 5962F9568902VXC 16 Ld FlatPack 300krad
Quad, 5.0V Differential Line Rcvr, TTL Enable HS0-26CT32RH-Q 5962F9563101V9A Die (Military Visual) 300krad
Quad, 5.0V Differential Line Rcvr, TTL Enable HS1-26CT32RH-8 5962F9563101QEC 16 Ld SBDIP 300krad
Quad, 5.0V Differential Line Rcvr, TTL Enable HS1-26CT32RH-Q 5962F9563101VEC 16 Ld SBDIP 300krad
Quad, 5.0V Differential Line Rcvr, TTL Enable HS9-26CT32RH-8 5962F9563101QXC 16 Ld FlatPack 300krad
Quad, 5.0V Differential Line Rcvr, TTL Enable HS9-26CT32RH-Q 5962F9563101VXC 16 Ld FlatPack 300krad
Linear Comparators
Single Event Hardened Quad Voltage Comparator IS0-139ASRH-Q 5962F0151001V9A Die (Military Visual) 300krad
Single Event Hardened Quad Voltage Comparator IS9-139ASRH-8 5962F0151001QXC 20 Ld FlatPack 300krad
Single Event Hardened Quad Voltage Comparator IS9-139ASRH-Q 5962F0151001VXC 20 Ld FlatPack 300krad
Quad Voltage Comparator HS0-139RH-Q 5962F9861301V9A Die (Military Visual) 300krad
Quad Voltage Comparator HS1-139RH-8 5962F9861301QCC 14 Ld SBDIP 300krad
Quad Voltage Comparator HS1-139RH-Q 5962F9861301VCC 14 Ld SBDIP 300krad
Quad Voltage Comparator HS9-139RH-8 5962F9861301QXC 14 Ld FlatPack 300krad
Quad Voltage Comparator HS9-139RH-Q 5962F9861301VXC 14 Ld FlatPack 300krad
Dual Hign Speed Voltage Comparator ISL7119RHQF 5962F0721501QXC 10 Ld FlatPack 300krad
Dual Hign Speed Voltage Comparator ISL7119RHVF 5962F0721501VXC 10 Ld FlatP ack 300krad
Dual Hign Speed Voltage Comparator ISL7119RHVX 5962F0721501V9A Die (Military Visual) 300krad
Linear Operational Amplifiers
Ultra High Speed Current Feedback Amplifier HS0-1100RH-Q 5962F9467602V9A Die (Military Visual) 300krad
Ultra High Speed Current Feedback Amplifier HS7B-1100RH-Q 5962F9467602VPC 8 Ld SBDIP 300krad
Current Feedback Amp W/VIO Adjust HS0-1135RH-Q 5962F9676701V9A Die (Military Visual) 300krad
Current Feedback Amp W/VIO Adjust HS7B-1135RH -Q 5962F9676701VPC 8 Ld SBDIP 300krad
High Speed, Low Power Output Limiting, Closed-Loop-Buffer Amplifier HS7B-1115RH-Q 5962F9678501VPC 8 Ld SBDIP 300krad
Video Op-Amp With Output Disable HS0-1145RH-Q 5962F9683001V9A Die (Military Visual) 300krad
Video Op-Amp With Output Disable HS7B-1145RH-Q 5962F9683001VPC 8 Ld SBDIP 300krad
Dual, Wideband, High Input Impedance Uncompensated
Operational Amplifier
Dual, Wideband, High Input Impedance Uncompensated
Operational Amplifier
Programmable Low Power Op Amp HS0-3530ARH-Q 5962F9568701V9A Die (Military Visual) 300krad
Programmable Low Power Op Amp HS2-3530ARH-8 5962F9568701QGA 8 Ld Can 300krad
Programmable Low Power Op Amp HS2-3530ARH-Q 5962F9568701VGA 8 Ld Can 300krad
Programmable Low Power Op Amp HS9-3530ARH-Q 5962F9568701VXC 10 Ld FlatPack 300krad
Low Noise Quad Operational Amplifier HS0-5104ARH-Q 5962R9569001V9A Die (Military Visual) 100krad
17-9
HS0-22620RH-Q 5962F9751201V9A Die (Military Visual) 300krad
HS9-22620RH-Q 5962F9751201VXC 18 Ld FlatPack 300krad
www.intersil.com
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
17
Military/Space
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Products Selection Chart (Continued)
Device Description Mkt. Number SMD Number Package RH Level
Low Noise Quad Operational Amplifier HS1-5104ARH-Q 5962 R9569001VCC 14 Ld SBDIP 100krad
Low Noise Quad Operational Amplifier HS9-5104ARH-Q 5962 R9569001VXC 14 Ld FlatPack 100krad
Single Event Hardened Single Supply, Quad Operat ional Am plifier ISL7124SRHQF 5962F0254201QXC 14 Ld FlatPack 300krad
Single Event Hardened Single Supply, Quad Operat ional Am plifier ISL7124SRHVF 5962F0254201VXC 14 Ld FlatPack 300krad
Single Event Hardened Single Supply, Quad Operat ional Amplifier ISL7124SRHVX 5962F0254201V9A Die (Military Visual) 300krad
Very Low Noise Quad Operational Amplifier HS0-OP470ARH-Q 5962R9853301V9A Die (Military Visual) 100krad
Very Low Noise Quad Operational Amplifier HS9-OP470ARH-Q 5962R9853301VXC 14 Ld FlatPack 100krad
Linear Sample and Hold
Fast Sample and Hold HS1B-2420RH-Q 5962R9566901VCC 14 Ld SBDIP 100krad
Linear Special Function
8 Channel Source Driver IS0-2981RH-Q 5962R0052001V9A Die (Military Visual) 100krad
8 Channel Source Driver IS1-2981RH-8 5962R0052001QVC 18 Ld SBDIP 100krad
8 Channel Source Driver IS1-2981RH-Q 5962R0052001VVC 18 Ld SBDIP 100krad
Linear Transistor Arrays
Ultra High Frequency NPN-PNP Transistor Array ISL73096RHVF 5962F0721801VXC 16 Ld FlatPack 300krad
Ultra High Frequency NPN-PNP Transistor Array ISL73096RHVX 5962F0721801V9A Die (Military Visual) 300krad
Ultra High Frequency NPN-PNP Transistor Array ISL73127RHVF 5962F0721802VXC 16 Ld SBDIP 300krad
Ultra High Frequency NPN-PNP Transistor Array ISL73127RHVX 5962F0721802V9A Die (Military Visual) 300krad
Ultra High Frequency NPN-PNP Transistor Array ISL73128RHVF 5962F0721803VXC 16 Ld FlatPack 300krad
Ultra High Frequency NPN-PNP Transistor Array ISL73128RHVX 5962F0721803V9A Die (Military Visual) 300krad
Ultra High Frequency NPN Transistor Array HS0-6254RH-Q 5962F9764101V9A Die (Military Visual) 300krad
Ultra High Frequency NPN Transistor Array HS9-6254RH-Q 5962F9764101VXC 16 Ld FlatPack 300krad
Memory PROMs
8K x 8 CMOS PROM HS1-6664RH-8 5962F9562601QXC 28 Ld SBDIP 300krad
8K x 8 CMOS PROM HS1-6664RH-Q 5962F9562601VXC 28 Ld SBDIP 300krad
8K x 8 CMOS PROM HS9-6664RH-8 5962F9562601QYC 28 Ld FlatPack 300krad
8K x 8 CMOS PROM HS9-6664RH-Q 5962F9562601VYC 28 Ld FlatPack 300krad
Microprocessors
16-Bit CMOS Microprocessor HS1-80C86RH-8 5962R9572201QQC 40 Ld SBDIP 100krad
16-Bit CMOS Microprocessor HS1-80C86RH-Q 5962R9572201VQC 40 Ld SBDIP 100krad
16-Bit CMOS Microprocessor HS9-80C86RH-8 5962R9572201QXC 42 Ld FlatPack 100krad
16-Bit CMOS Microprocessor HS9-80C86RH-Q 5962R9572201VXC 42 Ld FlatPack 100krad
Microprocessor Peripherals
CMOS Static Clock Controller/Generator HS9-82C85RH-Q 5962R9582001VXC 24 Ld FlatPack 100krad
CMOS Static Clock Controller/Generator HS0-82C85RH-Q 5962R9582001V9A Die (Military Visual) 100krad
CMOS Static Clock Controller/Generator HS1-82C85RH-8 5962R9582001QJC 24 Ld SBDIP 100krad
CMOS Static Clock Controller/Generator HS1-82C85RH-Q 5962R9582001VJC 24 Ld SBDIP 100krad
CMOS Static Clock Controller/Generator HS9-82C85RH-8 5962R9582001QXC 24 Ld FlatPack 100krad
CMOS Programmable Peripheral Interface HS1-82C55ARH-8 5962R9581901QQC 40 Ld SBDIP 100krad
17-10
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Products Selection Chart (Continued)
Device Description Mkt. Number SMD Number Package RH Level
CMOS Programmable Peripheral Interface HS1-82C55ARH-Q 5962R9581901VQC 40 Ld SBDIP 100krad
CMOS Programmable Interval Timer HS1-82C54RH-8 5962R9571301QJC 24 Ld SBDIP 100krad
CMOS Programmable Interval Timer HS1-82C54RH-Q 5962R9571301VJC 24 Ld SBDIP 100krad
CMOS Programmable Interval Timer HS9-82C54RH-8 5962R9571301QXC 24 Ld FlatPack 100krad
CMOS Programmable Interval Timer HS9-82C54RH-Q 5962R9571301VXC 24 Ld FlatPack 100krad
Power Management MOSFET Drivers
Complementary Switch FET Driver IS0-1715ARH-Q 5962F0052101V9A Die (Military Visual) 300krad
Complementary Switch FET Driver IS9-1715ARH-8 5962F0052101QXC 16 Ld FlatPack 300krad
Complementary Switch FET Driver IS9-1715ARH-Q 5962F0052101VXC 16 Ld FlatPack 300krad
High Frequency Half Bridge Driver IS0-2100ARH-Q 5962F9953602V9A Die (Military Visual) 300krad
High Frequency Half Bridge Driver IS9-2100ARH-8 5962F9953602QXC 16 Ld FlatPack 300krad
High Frequency Half Bridge Driver IS9-2100ARH-Q 5962F9953602VXC 16 Ld FlatPack 300krad
Full Bridge N-Channel FET Driver HS0-4080ARH-Q 5962F9961701V9A Die (Military Visual) 300krad
Full Bridge N-Channel FET Driver HS9-4080ARH-8 5962F9961701QSC 20 Ld FlatPack 300krad
Full Bridge N-Channel FET Driver HS9-4080ARH-Q 5962F9961701VSC 20 Ld FlatPack 300krad
Dual, Inverting Power MOSFET Drivers HS9-4423BRH-8 5962F9951102QXC 16 Ld FlatPack 300krad
Dual, Inverting Power MOSFET Drivers HS9-4423BRH-Q 5962F9951102VXC 16 Ld FlatPack 300krad
Dual, Inverting Power MOSFET Drivers HS0-4423RH-Q 5962F9951102V9A Die (Military Visual) 300krad
Dual, Inverting Power MOSFET Drivers HS9-4423RH-8 5962F9951101QXC 16 Ld FlatPack 300krad
Dual, Inverting Power MOSFET Drivers HS9-4423RH-Q 5962F9951101VXC 16 Ld FlatPack 300krad
Dual, Non-Inverting Power MOSFET Drivers HS0-4424BRH-Q 5962F9956002V9A Die (Military Visual) 300krad
Dual, Non-Inverting Power MOSFET Drivers HS9-4424BRH-8 5962F9956002QXC 16 Ld FlatPack 300krad
Dual, Non-Inverting Power MOSFET Drivers HS9-4424BRH-Q 5962F9956002VXC 16 Ld FlatPack 300krad
Dual, Non-Inverting Power MOSFET Drivers HS0-4424RH-Q 5962F9956001V9A Die (Military Visual) 300krad
Dual, Non-Inverting Power MOSFET Drivers HS9-4424RH-8 5962F9956001QXC 16 Ld FlatPack 300krad
Dual, Non-Inverting Power MOSFET Drivers HS9-4424RH-Q 5962F9956001VXC 16 Ld FlatPack 300krad
9A, Non-Inverting Power MOSFET Drivers ISL74422ARHQF 5962F0152101QXC 16 Ld FlatPack 300krad
9A, Non-Inverting Power MOSFET Drivers ISL74422ARHVF 5962F0152101VXC 16 Ld FlatPack 300krad
9A, Non-Inverting Power MOSFET Drivers ISL74422ARHVX 5962F0152101V9A Die (Military Visual) 300krad
9A, Non-Inverting Power MOSFET Drivers ISL74422BRHQF 5962F0324801QXC 16 Ld FlatPack 300krad
9A, Non-Inverting Power MOSFET Drivers ISL74422BRHVF 5962F0324801VXC 16 Ld FlatPack 300krad
9A, Non-Inverting Power MOSFET Drivers ISL74422BRHVX 5962F0324801V9A Die (Military Visual) 300krad
Power Management Special Function
Power-Up/Down Microprocessor Reset Circuit IS0-705RH-Q 5962R0053801V9A Die (Military Visual) 100krad
Power-Up/Down Microprocessor Reset Circuit IS9-705RH-8 5962R0053801QXC 8 Ld FlatPack 100krad
Power-Up/Down Microprocessor Reset Circuit IS9-705RH-Q 5962R0053801VXC 8 Ld FlatPack 100krad
Power Management Voltage Reference
2.5V Reference IS0-1009RH-Q 5962F0052301V9A Die (Military Visual) 300krad
2.5V Reference IS2-1009RH-8 5962F0052301QXC 3 Ld Can 300krad
17
Military/Space
17-11
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Products Selection Chart (Continued)
Device Description Mkt. Number SMD Number Package RH Level
2.5V Reference IS2-1009RH-Q 5962F0052301VXC 3 Ld Can 300krad
2.5V Reference ISYE-1009RH-8 5962F0052301QYC 3 Ld LCC 300krad
2.5V Reference ISYE-1009RH-Q 5962F0052301VYC 3 Ld LCC 300krad
Power Management Voltage Regulator
Adjustable Positive Voltage Regulator HS0-117RH-Q 5962F9954701V9A Die (Military Visual) 300krad
Adjustable Positive Voltage Regulator HS2-117RH-8 5962F9954701QUC 3 Ld Can 300krad
Adjustable Positive Voltage Regulator HS2-117RH-Q 5962F9954701VUC 3 Ld Can 300krad
Adjustable Positive Voltage Regulator HS9S-117RH-8 5962F9954701QXC 3 Ld Can 300krad
Adjustable Positive Voltage Regulator HS9S-117RH-Q 5962F9954701VXC 3 Ld Can 300krad
Adjustable Positive Voltage Regulator HSYE-117RH-8 5962F9954701QYC 3 Ld LCC 300krad
Adjustable Positive Voltage Regulator HSYE-117RH-Q 5962F9954701VYC 3 Ld LCC 300krad
Adjustable Negative Voltage Regulator ISL7137RHQD Not Assigned 3 Ld LCC 300krad
Adjustable Negative Voltage Regulator ISL7137RHQF Not Assigned 3 Ld Can 300krad
Adjustable Negative Voltage Regulator ISL7137RHVD Not Assigned 3 Ld LCC 300krad
Adjustable Negative Voltage Regulator ISL7137RHVF Not Assigned 3 Ld Can 300krad
Adjustable Negative Voltage Regulator ISL7137RHVX Not Assigned Die (Military Visual) 300krad
Single Event Hardened High-Speed, Dual Output PWM ISL71823ASRHQD 5962F0251102QCC 16 Ld SBDIP 300krad
Single Event Hardened High-Speed, Dual Output PWM ISL71823ASRHQF 5962F0251102QXC 16 Ld FlatPack 300krad
Single Event Hardened High-Speed, Dual Output PWM ISL71823ASRHVD 5962F0251102VCC 16 Ld SBDIP 300krad
Single Event Hardened High-Speed, Dual Output PWM ISL71823ASRHVF 5962F0251102VXC 16 Ld FlatPack 300krad
Single Event Hardened High-Speed, Dual Output PWM ISL71823ASRHVX 5962F0251102V9A Die (Military Visual) 300krad
High-Speed, Dual Output PWM HS0-1825ARH-Q 5962F9955801V9A Die (Military Visual) 300krad
High-Speed, Dual Output PWM HS1-1825ARH-8 5962F9955801QEC 16 Ld SBDIP 300krad
High-Speed, Dual Output PWM HS1-1825ARH-Q 5962F9955801VEC 16 Ld SBDIP 300krad
High-Speed, Dual Output PWM HS9-1825ARH-8 5962F9955801QXC 16 Ld FlatPack 300krad
High-Speed, Dual Output PWM HS9-1825ARH-Q 5962F9955801VXC 16 Ld FlatPack 300krad
Single Event Hardened High-Speed, Dual Output PWM IS0-1825ASRH-Q 5962F0251101V9A Die (Military Visual) 300krad
Single Event Hardened High-Speed, Dual Output PWM IS1-1825ASRH-8 5962F0251101QEC 16 Ld SBDIP 300krad
Single Event Hardened High-Speed, Dual Output PWM IS1-1825ASRH-Q 5962F0251101VEC 16 Ld SBDIP 300krad
Single Event Hardened High-Speed, Dual Output PWM IS9-1825ASRH-8 5962F0251101QXC 20 Ld FlatPack 300krad
Single Event Hardened High-Speed, Dual Output PWM IS9-1825ASRH-Q 5962F0251101VXC 20 Ld FlatPack 300krad
Single Event Hardened High Speed, Current Mode PWM IS0-1845ASRH-Q 5962F0150901V9A Die (Military Visual) 300krad
Single Event Hardened High Speed, Current Mode PWM IS7-1845ASRH-8 5962F0150901QPC 8 Ld SBDIP 300krad
Single Event Hardened High Speed, Current Mode PWM IS7-1845ASRH-Q 5962F0150901VPC 8 Ld SBDIP 300krad
Single Event Hardened High Speed, Current Mode PWM IS9-1845ASRH-8 5962F0150901QXC 18 Ld FlatPack 300krad
Single Event Hardened High Speed, Current Mode PWM IS9-1845ASRH-Q 5962F0150901VXC 18 Ld FlatPack 300krad
Negative Low Dropout Adjustable Voltage Regulator ISL72991RHQF 5962F0250301QXC 28 Ld FlatPack 300krad
Negative Low Dropout Adjustable Voltage Regulator ISL72991RHVF 5962F0250301VXC 28 Ld FlatPack 300krad
Negative Low Dropout Adjustable Voltage Regulator ISL72991RHVX 5962F0250301V9A Die (Military Visual) 300krad
17-12
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Logic Selection Chart
Not Recommended for New Designs (Please contact your local sales representative for availability of die.)
Device Description Mkt. Number SMD Number Package RH Level
Digital Logic Buffers
Non-Inverting Octal Buffer/Line Driver, Three-State ACS244DMSR-02 5962F9854101VXC 20 Ld SBDIP 300krad
Non-Inverting Octal Buffer/Line Driver, Three-State ACS244HMSR-02 5962F9854101V9A Die (Military Visual) 300krad
Non-Inverting Octal Buffer/Line Driver, Three-State ACS244KMSR-02 5962F9854101 VRC 20 Ld FlatPack 300krad
Octal Buffer/Line Driver, Three-State, Inverting ACS245KMSR 5962F9670701VXC 20 Ld FlatPack 300krad
Non-Inverting Octal Buffer/Line Driver, Three-State ACS541HMSR-02 5962F9671002V9A Die (Military Visual) 300krad
Non-Inverting Octal Buffer/Line Driver, Three-State ACS541KMSR-02 5962F9671002 VXC 20 Ld FlatPack 300krad
Non-Inverting Octal Buffer/Line Driver, Three-State ACS74DMSR 5962F9679901VCC 20 Ld SBDIP 300krad
Hex Inverter ACTS04DMSR-02 5962F9671201VCC 14 Ld SBDIP 300krad
Hex Inverter ACTS04HMSR-02 5962F9671201V9A Die (Military Visual) 300krad
Hex Inverter ACTS04KMSR-02 5962F9671202VXC 14 Ld FlatPack 300krad
Octal Buffer/Line Driver, Three-State, Inverting ACTS240DMSR 5962F9671701VRC 20 Ld SBDIP 300krad
Octal Buffer/Line Driver, Three-State, Inverting ACTS240KMSR 5962F9671701VXC 20 Ld FlatPack 300krad
Octal Buffer/Line Driver, Three-State, Inverting ACTS245DMSR 5962F9671901VRC 20 Ld SBDIP 300krad
Octal Buffer/Line Driver, Three-State, Inverting ACTS245KMSR 5962F9671901VXC 20 Ld FlatPack 300krad
CMOS Quad True/Complement Buffer CD4041UBDMSR 5962R9663201VCC 14 Ld SBDIP 100krad
CMOS Quad True/Complement Buffer CD4041UBHNSR 5962R9663202V9A Die (Military Visual) 100krad
CMOS Quad True/Complement Buffer CD4041UBHSR 5962R9663201V9A Die (Military Visual) 100krad
CMOS Quad True/Complement Buffer CD4041UBKMSR 5962R9663201VXC 14 Ld FlatPack 100krad
CMOS Hex Buffer/Converter CD4049UBDMSR 5962R9663601VEC 16 Ld SBDIP 100krad
CMOS Hex Buffer/Converter CD4049UBHSR 5962R9663601V9A Die (Military Vis ual) 100krad
CMOS Hex Buffer/Converter CD4049UBKMSR 5962R9663601VXC 16 Ld FlatPack 100krad
CMOS Hex Buffer/Converter CD4049UBKNSR 5962R9663602VXC 16 Ld FlatPack 100krad
CMOS Hex Buffer/Converter CD4050BDMSR 5962R9663701VEC 16 Ld SBDIP 100krad
CMOS Hex Buffer/Converter CD4050BKMSR 5962R9663701VXC 16 Ld FlatPack 100krad
CMOS Hex Inverter CD4069UBDMSR 5962R9665301VCC 14 Ld SBDIP 100krad
CMOS Hex Inverter CD4069UBKMSR 5962R9665301VXC 14 Ld FlatPack 100krad
CMOS Hex Buffer CD4503BDMSR 5962R9664301VEC 16 Ld SBDIP 100krad
CMOS Hex Buffer CD4503BKMSR 5962R9664301VXC 16 Ld FlatPack 100krad
CMOS Hex Buffer CD4503BKNSR 5962R9664302VXC 16 Ld FlatPack 100krad
Hex Inverter HCS04DMSR 5962R9572501VCC 14 Ld SBDIP 200krad
Hex Inverter HCS04HMSR 5962R9572501V9A Die (Military Visual) 200krad
Hex Inverter HCS04KMSR 5962R9572501VXC 14 Ld FlatPack 200krad
Hex Inverter with Open Drain HCS05KMSR 5962R9580101VXC 14 Ld FlatPack 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCS240DMSR 5962R9580901VRC 20 Ld SBDIP 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCS240KMSR 5962R9580901VXC 20 Ld FlatPack 200krad
Non-Inverting Octal Buffer/Line Driver, Three-State HCS244DMSR 5962R9573101VRC 20 Ld SBDIP 200krad
Non-Inverting Octal Buffer/Line Driver, Three-State HCS244KMSR 5962R9573101VXC 20 Ld FlatPack 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCS245DMSR 5962R9679701VCC 20 Ld SBDIP 200krad
17
Military/Space
17-13
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Logic Selection Chart
Not Recommended for New Designs (Please contact your local sales representative for availability of die.) (Continued)
Device Description Mkt. Number SMD Number Package RH Level
Octal Buffer/Line Driver, Three-State, Inverting HCS245HMSR 5962R9679701V9A Die (Military Visual) 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCS245KMSR 5962R9679701VXC 20 Ld FlatPack 200krad
Hex Inverter HCTS04DMSR 5962R9573201VCC 14 Ld SBDIP 200krad
Hex Inverter HCTS04KMSR 5962R9573201VXC 14 Ld FlatPack 200krad
Hex Inverter HCTS04HMSR 5962R9573201V9A Die (Military Visual) 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCTS240ADMSR 5962R9577201VRC 20 Ld SBDIP 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCTS240AHMSR 5962R9577201V9A Die (Military Visual) 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCTS240AKMSR 5962R9577201VXC 20 Ld FlatPack 200krad
Non-Inverting Octal Buffer/Line Driver, Three-State HCTS244DMSR 5962R9574401VRC 20 Ld SBDIP 200krad
Non-Inverting Octal Buffer/Line Driver, Three-State HCTS244KMSR 5962R9574401VXC 20 Ld FlatPack 200krad
Non-Inverting Octal Buffer/Line Driver, Three-State HCTS244HMSR 5962R9574401V9A Die (Military Visual) 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCTS245DMSR 5962R9574501VRC 20 Ld SBDIP 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCTS245KMSR 5962R9574501VXC 20 Ld FlatPack 200krad
Octal Buffer/Line Driver, Three-State, Inverting HCTS245HMSR 5962R9574501V9A Die (Military Visual) 200krad
Inverting Octal Buffer/Line Driver, Three-State HCTS540KMSR 5962R9577601VXC 20 Ld FlatPack 200krad
Non-Inverting Octal Buffer/Line Driver, Three-State HCTS541DMSR 5962R9575101VRC 20 Ld SBDIP 200krad
Non-Inverting Octal Buffer/Line Driver, Three-State HCTS541HMSR 5962R9575101V9A Die (Military Visual) 200krad
Non-Inverting Octal Buffer/Line Driver, Three-State HCTS541KMSR 5962R9575101VXC 20 Ld FlatPack 200krad
Digital Logic Comparators
CMOS 4-Bit Magnitude Comparator CD4063BDMSR 5962R9675701VCC 16 Ld SBDIP 100krad
CMOS 4-Bit Magnitude Comparator CD4063BKMSR 5962R9675701VXC 16 Ld FlatPack 100krad
CMOS 4-Bit Magnitude Comparator CD4585BDMSR 5962R9667401VEC 16 Ld SBDIP 100krad
CMOS 4-Bit Magnitude Comparator CD4585BHSR 5962R9667401V9A Die (Military Visual) 100krad
CMOS 4-Bit Magnitude Comparator CD4585BKMSR 5962R9667401VXC 16 Ld FlatPack 100krad
4-Bit Magnitude Comparator HCTS85DMSR 5962R9576801VEC 16 Ld SBDIP 200krad
4-Bit Magnitude Comparator HCTS85KMSR 5962R9576801VXC 16 Ld FlatPack 200krad
Digital Logic Counters
4-Bit Synchronous Counter ACTS161DMSR 5962F9671601VEC 16 Ld SBDIP 300krad
4-Bit Synchronous Counter ACTS161KMSR 5962F9671601VXC 16 Ld FlatPack 300krad
CMOS Presettable Up/Down Counters (Dual Clock with Reset) CD40193BDMSR 5962R9660802VEC 16 Ld SBDIP 100krad
CMOS Presettable Up/Down Counters (Dual Clock with Reset) CD40193BHSR 5962R9660802V9A Die (Military Visual) 100krad
CMOS Presettable Up/Down Counters (Dual Clock with Reset) CD40193BKMSR 5962R9660802VXC 16 Ld FlatPack 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4020BDMSR 5962R9662801VEC 16 Ld SBDIP 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4020BHSR 5962R9662801V9A Die (Military Visual) 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4020BKMSR 5962R9662801VYC 16 Ld FlatPack 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4020BKNSR 5962R9662802VYC 16 Ld FlatPack 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4024BDMSR 5962R9662803VCC 14 Ld SBDIP 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4024BHSR 5962R9662803V9A Die (Military Visual) 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4024BKMSR 5962R9662803VXC 14 Ld FlatPack 100krad
17-14
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Logic Selection Chart
Not Recommended for New Designs (Please contact your local sales representative for availability of die.) (Continued)
Device Description Mkt. Number SMD Number Package RH Level
CMOS Presettable Up/Down Counter CD4029BDMSR 5962R9562101VEC 16 Ld SBDIP 100krad
CMOS Presettable Up/Down Counter CD4029BHNSR 5962R9562102V9A Die (Military Visual) 100krad
CMOS Presettable Up/Down Counter CD4029BHSR 5962R9562101V9A Die (Military Visual) 100krad
CMOS Presettable Up/Down Counter CD4029BKMSR 5962R9562101VXC 16 Ld FlatPack 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4040BDMSR 5962R9662806VCC 16 Ld SBDIP 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4040BKMSR 5962R9662806VYC 16 Ld FlatPack 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4040BKNSR 5962R9662806VYC 16 Ld FlatPack 100krad
CMOS Ripple-Carry Binary Counter/Dividers CD4040BHSR 5962R9662806V9A Die (Military Visual) 100krad
CMOS 14STG Binary Ripple Counter/DVDR/Oscillator CD4060BDMSR 5962R9660901VXC 16 Ld SBDIP 100krad
CMOS 14STG Binary Ripple Counter/DVDR/Oscillator CD4060BKMSR 5962R9660901VEC 16 Ld FlatPack 100krad
Synchronous Counter HCS161DMSR 5962R9573001VEC 16 Ld SBDIP 200krad
Synchronous Counter HCS161HMSR 5962R9573001V9A Die (Military Visual) 200krad
Synchronous Counter HCS161KMSR 5962R9573001VXC 16 Ld FlatPack 200krad
Synchronous Presettable Counter HCS163DMSR 5962R9580701VEC 16 Ld SBDIP 200krad
Synchronous Presettable Counter HCS163KMSR 5962R9580701VXC 16 Ld FlatPack 200krad
Synchronous 4-Bit Up/Down Counter HCTS193KMSR 5962R9575701VXC 16 Ld FlatPack 200krad
Synchronous 4-Bit Up/Down Counter HCTS193HMSR 5962R9575701V9A Die (Military Visual) 200krad
Dual 4-Stage Binary Counter HCTS393HMSR 5962R9575001V9A Die (Military Visual) 200krad
Dual 4-Stage Binary Counter HCTS393KMSR 5962R9575001VXC 14 Ld FlatPack 200krad
Digital Logic Decoders
Inverting 3-to-8 Line Decoder/Demultiplexer ACS138DMSR-03 5962F9853401VEC 16 Ld SBDIP 300krad
Inverting 3-to-8 Line Decoder/Demultiplexer ACS138KMSR-03 5962F9853401VXC 16 Ld FlatPack 300krad
CMOS BCD-To-Decimal Decoder CD4028BKMSR 5962R9663001VXC 16 Ld FlatPack 100krad
CMOS BCD-To-Decimal Decoder CD4028BHNSR 5962R9663002VXC Die (Military Visual) 100krad
CMOS 4-Bit Latch/4-to-16 Line Decoders CD4514BDMSR 5962R9668101VJC 24 Ld SBDIP 100krad
CMOS 4-Bit Latch/4-to-16 Line Decoders CD4514BHSR 5962R9668101V9A Die (Military Visual) 100krad
CMOS 4-Bit Latch/4-to-16 Line Decoders CD4514BKMSR 5962R9668101VXC 24 Ld FlatPack 100krad
CMOS Dual Binary to 1 of 4 Decoder/Demultiplexers CD4555BDMSR 5962R9667301VEC 16 Ld SBDIP 100krad
CMOS Dual Binary to 1 of 4 Decoder/Demultiplexers CD4555BKMSR 5962R9667301VXC 16 Ld FlatPack 100krad
Inverting 3-to-8 Line Decoder/Demultiplexer HCS138DMSR 5962R9572701VEC 16 Ld SBDIP 200krad
Inverting 3-to-8 Line Decoder/Demultiplexer HCS138HMSR 5962R9572701V9A Die (Military Visual) 200krad
Inverting 3-to-8 Line Decoder/Demultiplexer HCS138KMSR 5962R9572701VXC 16 Ld FlatPack 200krad
Dual 2-to-4 Line Decoder/Demultiplexer HCS139DMSR 5962R9580401VEC 16 Ld SBDIP 200krad
Dual 2-to-4 Line Decoder/Demultiplexer HCS139KMSR 5962R9580401VXC 16 Ld FlatPack 200krad
4-to-16 Line Decoder/Demultiplexer HCS154DMSR 5962R9572901VJC 24 Ld SBDIP 200krad
4-to-16 Line Decoder/Demultiplexer HCS154KMSR 5962R9572901VXC 24 Ld FlatPack 200krad
Inverting 3-to-8 Line Decoder/Demultiplexer HCTS138DMSR 5962R9574001VEC 16 Ld SBDIP 200krad
Inverting 3-to-8 Line Decoder/Demultiplexer HCTS138HMSR 5962R9574001V9A Die (Military Visual) 200krad
Inverting 3-to-8 Line Decoder/Demultiplexer HCTS138KMSR 5962R9574001VXC 16 Ld FlatPack 200krad
17
Military/Space
17-15
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Logic Selection Chart
Not Recommended for New Designs (Please contact your local sales representative for availability of die.) (Continued)
Device Description Mkt. Number SMD Number Package RH Level
Dual 2-to-4 Line Decoder/Demultiplexer HCTS139DMSR 5962R9575301VEC 16 Ld SBDIP 200krad
Dual 2-to-4 Line Decoder/Demultiplexer HCTS139KMSR 5962R9575301VXC 16 Ld FlatPack 200krad
Digital Logic Flip-Flops
Octal D Flip-Flop, +Edge Triggered, Three-State ACS374DMSR 5962F9565601VRC 20 Ld SBDIP 300krad
Octal D Flip-Flop, +Edge Triggered, Three-State ACS374KMSR 5962F9565601VXC 20 Ld FlatPack 300krad
Dual D Type Flip-Flop with Set and Reset, Advanced Logic, CMOS ACS74HMSR 5962F9679901V9A Die (Military Visual) 300krad
Dual D Type Flip-Flop with Set and Reset, Advanced Logic, CMOS ACS74KMSR 5962F9679901VXC 14 Ld FlatPack 300krad
Dual D Type Flip-Flop with Set and Reset, Advanced Logic, CMOS ACTS74HMSR-02 5962F9671302V9A Die (Military Visual) 300krad
CMOS Dual `D'-Type Flip-Flop CD4013BDMSR 5962R9662201VCC 14 Ld SBDIP 100krad
CMOS Dual `D'-Type Flip-Flop CD4013BHSR 5962R9662201V9A Die (Military Visual) 100krad
CMOS Dual `D'-Type Flip-Flop CD4013BKMSR 5962R9662201VXC 14 Ld FlatPack 100krad
CMOS Dual `D'-Type Flip-Flop CD4013BKNSR 5962R9662202VXC 14 Ld FlatPack 100krad
CMOS Hex `D'-Type Flip-Flop CD40174BDMSR 5962R9660501VEC 16 Ld SBDIP 100krad
CMOS Hex `D'-Type Flip-Flop CD40174BKMSR 5962R9660501VXC 16 Ld FlatPack 100krad
CMOS Hex `D'-Type Flip-Flop CD40174BHSR 5962R9660501V9A Die (Military Visual) 100krad
CMOS Dual J-K Master-Slave Flip-Flop CD4027BKMSR 5962R9662901VXC 16 Ld FlatPack 100krad
Dual JK Flip-Flop HCS109DMSR 5962R9578401VEC 16 Ld SBDIP 200krad
Dual JK Flip-Flop HCS109HMSR 5962R9578401V9A Die (Military Visual) 200krad
Dual JK Flip-Flop HCS109KMSR 5962R9578401VXC 16 Ld FlatPack 200krad
Octal D Flip-Flop HCS273DMSR 5962R9579101VRC 20 Ld SBDIP 200krad
Octal D Flip-Flop HCS273HMSR 5962R9579101V9A Die (Military Visual) 200krad
Octal D Flip-Flop HCS273KMSR 5962R9579101VXC 20 Ld FlatPack 200krad
Octal D Flip-Flop, +Edge Triggered, Three-State HCS374DMSR 5962R9579301VRC 20 Ld SBDIP 200krad
Octal D Flip-Flop, +Edge Triggered, Three-State HCS374HMSR 5962R9579301VXC Die (Military Visual) 200krad
Octal D Flip-Flop, +Edge Triggered, Three-State HCS374KMSR 5962R9579301VXC 20 Ld FlatPack 200krad
OCTAL D Flip-Flop with Reset HCTS273DMSR 5962R9576401VRC 20 Ld SBDIP 200krad
OCTAL D Flip-Flop with Reset HCTS273KMSR 5962R9576401VXC 20 Ld FlatPack 200krad
Octal D Flip-Flop, +Edge Triggered, Three-State HCTS574DMSR 5962R9575801VRC 20 Ld SBDIP 200krad
Octal D Flip-Flop, +Edge Triggered, Three-State HCTS574HMSR 5962R9575801V9A Die (Military Visual) 200krad
Octal D Flip-Flop, +Edge Triggered, Three-State HCTS574KMSR 5962R9575801VXC 20 Ld FlatPack 200krad
Dual-D Flip-Flop with Set and Reset HCTS74DMSR 5962R9576301VCC 14 Ld SBDIP 200krad
Dual-D Flip-Flop with Set and Reset HCTS74HMSR 5962R9576301V9A Die (Military Visual) 200krad
Dual-D Flip-Flop with Set and Reset HCTS74KMSR 5962R9576301VXC 14 Ld FlatPack 200krad
Digital Logic Gates
Quad 2-Input NAND Gate ACS00HMSR-02 5962F9565002V9A Die (Military Visual) 300krad
Quad 2-Input NAND Gate with Open Drain ACS03DMSR 5962F9670301VCC 14 Ld SBDIP 300krad
Quad 2-Input NAND Gate with Open Drain ACS03HMSR 5962F9670301V9A Die (Military Visual) 300krad
Quad 2-Input NAND Gate with Open Drain ACS03KMSR 5962F9670301VXC 14 Ld FlatPack 300krad
Triple 3-Input NAND Gate, CMOS ACS10HMSR-02 5962F9565202V9A Die (Military Visual) 300krad
17-16
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Logic Selection Chart
Not Recommended for New Designs (Please contact your local sales representative for availability of die.) (Continued)
Device Description Mkt. Number SMD Number Package RH Level
Quad 2-Input AND Gate ACTS08DMSR-02 5962F9565702VCC 14 Ld SBDIP 300krad
Quad 2-Input AND Gate ACTS08KMSR-02 5962F9565702VXC 14 Ld FlatPack 300krad
Quad 2-Input AND Gate ACTS08HMSR-02 5962F9565702V9A Die (Military Visual) 300krad
CMOS NOR Gate CD4001BDMSR 5962R9582602VCC 14 Ld SBDIP 100krad
CMOS NOR Gate CD4001BHSR 5962R9582602V9A Die (Military Visual) 100krad
CMOS NOR Gate CD4001BHNSR 5962R9582605V9A Die (Military Visual) 100krad
CMOS NOR Gate CD4001BKMSR 5962R9582602VXC 14 Ld FlatPack 100krad
CMOS NOR Gate CD4001BKNSR 5962R9582605VXC 14 Ld FlatPack 100krad
CMOS Dual 2-Input NAND Buffer/Driver CD40107BHSR 5962R9664401V9A Die (Military Visual) 100krad
CMOS Dual 2-Input NAND Buffer/Driver CD40107BKMSR 5962R9664401VXC 14 Ld FlatPack 100krad
CMOS NAND Gates CD4023BDMSR 5962R9662103VCC 14 Ld SBDIP 100krad
CMOS NAND Gates CD4023BHSR 5962R9662103V9A Die (Military Visual) 100krad
CMOS NAND Gates CD4023BKMSR 5962R9662103VXC 14 Ld FlatPack 100krad
CMOS NOR Gate CD4025BDMSR 5962R9582604VCC 14 Ld SBDIP 100krad
CMOS NOR Gate CD4025BKMSR 5962R9582604VXC 14 Ld FlatPack 100krad
CMOS Quad Exclusive-OR Gate CD4030BDMSR 5962R9664601VCC 14 Ld SBDIP 100krad
CMOS Quad Three-State R/S Latches CD4043BDMSR 5962R9663401VEC 16 Ld SBDIP 100krad
CMOS Quad Three-State R/S Latches CD4043BKMSR 5962R9663401VXC 16 Ld FlatPack 100krad
CMOS Quad Exclusive OR and Exclusive NOR Gates CD4070BDMSR 5962R9661101VCC 14 Ld SBDIP 100krad
CMOS Quad Exclusive OR and Exclusive NOR Gates CD4070BHSR 5962R9661101V9A Die (Military Visual) 100krad
CMOS Quad Exclusive OR and Exclusive NOR Gates CD4070BKMSR 5962R9661101VXC 14 Ld FlatPack 100krad
CMOS OR Gate CD4071BDMSR 5962R9665401VCC 14 Ld SBDIP 100krad
CMOS OR Gate CD4071BKMSR 5962R9665401VXC 14 Ld FlatPack 100krad
CMOS Triple 3-Input AND Gate CD4073BHSR 5962R9665501V9A Die (Military Visual) 100krad
CMOS Triple 3-Input AND Gate CD4073BKNSR 5962R9665504VXC 14 Ld FlatPack 100krad
CMOS Quad Exclusive OR and Exclusive NOR Gates CD4077BDMSR 5962R9661102VCC 14 Ld SBDIP 100krad
CMOS Quad Exclusive OR and Exclusive NOR Gates CD4077BKMSR 5962R9661102VXC 14 Ld FlatPack 100krad
CMOS AND Gate CD4081BDMSR 5962R9665502VCC 14 Ld SBDIP 100krad
CMOS AND Gate CD4081BKMSR 5962R9665502VXC 14 Ld FlatPack 100krad
CMOS AND Gate CD4081BKNSR 5962R9665505VXC 14 Ld FlatPack 100krad
Quad 2-Input NAND Gate HCS00DMSR 5962R9572401VCC 14 Ld SBDIP 200krad
Quad 2-Input NAND Gate HCS00HMSR 5962R9572401V9A Die (Military Visual) 200krad
Quad 2-Input NAND Gate HCS00KMSR 5962R9572401VXC 14 Ld FlatPack 200krad
Quad 2-Input NOR Gate HCS02DMSR 5962R9567901VXC 14 Ld SBDIP 200krad
Quad 2-Input NOR Gate HCS02HMSR 5962R9567901V9A Die (Military Visual) 200krad
Quad 2-Input NOR Gate HCS02KMSR 5962R9567901VCC 14 Ld FlatPack 200krad
Triple 3-Input NAND Gate, CMOS HCS10KMSR 5962R9577701VXC 14 Ld FlatPack 200krad
Triple 3-Input AND Gate HCS11DMSR 5962R9572001VCC 14 Ld SBDIP 200krad
Triple 3-Input AND Gate HCS11KMSR 5962R9572001VXC 14 Ld FlatPack 200krad
17
Military/Space
17-17
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Logic Selection Chart
Not Recommended for New Designs (Please contact your local sales representative for availability of die.) (Continued)
Device Description Mkt. Number SMD Number Package RH Level
Quad 2-Input NAND Schmitt Trigger HCS132DMSR 5962R9572601VCC 14 Ld SBDIP 200krad
Quad 2-Input NAND Schmitt Trigger HCS132HMSR 5962R9572601V9A Die (Military Visual) 200krad
Quad 2-Input NAND Schmitt Trigger HCS132KMSR 5962R9572601VXC 14 Ld FlatPack 200krad
CMOS Dual 4-Input AND Gate HCS21DMSR 5962R9577901VCC 14 Ld SBDIP 200krad
CMOS Dual 4-Input AND Gate HCS21KMSR 5962R9577901VXC 14 Ld FlatPack 200krad
Triple 3-Input NOR Gate HCS27DMSR 5962R9578001VCC 14 Ld SBDIP 200krad
Triple 3-Input NOR Gate HCS27HMSR 5962R9578001V9A Die (Military Visual) 200krad
Triple 3-Input NOR Gate HCS27KMSR 5962R9578001VXC 14 Ld FlatPack 200krad
Quad 2-Input OR Gate HCS32DMSR 5962R9578101VCC 14 Ld SBDIP 200krad
Quad 2-Input OR Gate HCS32HMSR 5962R9578101V9A Die (Military Visual) 200krad
Quad 2-Input OR Gate HCS32KMSR 5962R9578101VXC 14 Ld FlatPack 200krad
Quad 2-Input Exclusive OR Gate HCS86DMSR 5962R9578301VCC 14 Ld SBDIP 200krad
Quad 2-Input Exclusive OR Gate HCS86HMSR 5962R9578301V9A Die (Military Visual) 200krad
Quad 2-Input Exclusive OR Gate HCS86KMSR 5962R9578301VXC 14 Ld FlatPack 200krad
Quad 2-Input NOR Gate HCTS02DMSR 5962R9568201VCC 14 Ld SBDIP 200krad
Quad 2-Input NOR Gate HCTS02KMSR 5962R9568201VXC 14 Ld FlatPack 200krad
Quad 2-Input AND Gate HCTS08DMSR 5962R9568301VCC 14 Ld SBDIP 200krad
Quad 2-Input AND Gate HCTS08HMSR 5962R9568301V9A Die (Military Visual) 200krad
Quad 2-Input AND Gate HCTS08KMSR 5962R9568301VXC 14 Ld FlatPack 200krad
Dual 4-Input NAND Gate HCTS20KMSR 5962R9573301VXC 14 Ld FlatPack 200krad
8-Input NAND Gate HCTS30DMSR 5962R9573501VCC 14 Ld SBDIP 200krad
8-Input NAND Gate HCTS30KMSR 5962R9573501VXC 14 Ld FlatPack 200krad
8-Input NAND Gate HCTS30HMSR 5962R9573501V9A Die (Military Visual) 200krad
Quad 2-Input OR Gate HCTS32DMSR 5962R9573601VCC 14 Ld SBDIP 200krad
Quad 2-Input OR Gate HCTS32KMSR 5962R9573601VXC 14 Ld FlatPack 200krad
Quad 2-Input OR Gate HCTS32HMSR 5962R9573601V9A Die (Military Visual) 200krad
Quad 2-Input Exclusive OR Gate HCTS86DMSR 5962R9581401VCC 14 Ld SBDIP 200krad
Quad 2-Input Exclusive OR Gate HCTS86KMSR 5962R9581401VXC 14 Ld FlatPack 200krad
Digital Logic Latches
Octal Transparent Latch, Three-State ACS373DMSR 5962F9565501VRC 20 Ld SBDIP 300krad
Octal Transparent Latch, Three-State ACS373KMSR 5962F9565501VXC 20 Ld FlatPack 300krad
Octal Transparent Latch, Three-State ACTS373DMSR-02 5962F9566102VRC 20 Ld SBDIP 300krad
Octal Transparent Latch, Three-State ACTS373KMSR-02 5962F9566102VXC 20 Ld FlatPack 300krad
D Latch, Clocked, Quad CMOS, Logic CD4042BDMSR 5962R9663301VEC 16 Ld SBDIP 100krad
D Latch, Clocked, Quad CMOS, Logic CD4042BKMSR 5962R9663301VXC 16 Ld FlatPack 100krad
CMOS 8-Bit Addressable Latch CD4099BDMSR 5962R9661501VEC 16 Ld SBDIP 100krad
CMOS 8-Bit Addressable Latch CD4099BKMSR 5962R9661501VXC 16 Ld FlatPack 100krad
Octal Transparent Latch, Three-State HCS573KMSR 5962R9579401VXC 20 Ld FlatPack 200krad
17-18
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Logic Selection Chart
Not Recommended for New Designs (Please contact your local sales representative for availability of die.) (Continued)
Device Description Mkt. Number SMD Number Package RH Level
Digital Logic Level Shift ers
CMOS Hex Voltage Level Shifter for TTL-to-CMOS or CMOS-to-CMOS
Operation
CMOS Hex Voltage Level Shifter for TTL-to-CMOS or CMOS-to-CMOS
Operation
CMOS Hex Voltage Level Shifter for TTL-to-CMOS or CMOS-to-CMOS
Operation
Digital Logic Linear
16-Bit Parallel EDAC ACS630DMSR 5962F9671101VXC 20 Ld SBDIP 300krad
16-Bit Parallel EDAC ACS630KMSR 5962F9671101VYC 20 Ld FlatPack 300krad
Inverting 8-Bit Parallel-In/Serial-Out Shift Register HCS166DMSR 5962R9578601VEC 16 Ld FlatPack 200krad
4-Bit Full Adder with Fast Carry HCTS283DMSR 5962R9577401VEC 16 Ld SBDIP 200krad
4-Bit Full Adder with Fast Carry HCTS283KMSR 5962R9577401VXC 16 Ld FlatPack 200krad
Digital Logic Multiplexers
CMOS Analog Multiplexers/Demultiplexers CD4051BDMSR 5962R9665101VEC 16 Ld SBDIP 100krad
CMOS Analog Multiplexers/Demultiplexers CD4051BHSR 5962R9665101V9A Die (Military Visual) 100krad
CMOS Analog Multiplexers/Demultiplexers CD4051BKMSR 5962R9665101VXC 16 Ld FlatPack 100krad
CMOS Analog Multiplexers/Demultiplexers CD4051BKNSR 5962R9665104VXC 16 Ld FlatPack 100krad
CMOS Analog Multiplexers/Demultiplexers CD4052BDMSR 5962R9665102VEC 16 Ld SBDIP 100krad
CMOS Analog Multiplexers/Demultiplexers CD4052BHSR 5962R9665102V9A Die (Military Visual) 100krad
CMOS Analog Multiplexers/Demultiplexers CD4052BKMSR 5962R9665102VXC 16 Ld FlatPack 100krad
CMOS Triple 2-Channel Analog Multiplexer/Demultiplexer CD4053BDMSR 5962R9665103VXC 16 Ld SBDIP 100krad
CMOS Triple 2-Channel Analog Multiplexer/Demultiplexer CD4053BHSR 5962R9665103V9A Die (Military Visual) 100krad
CMOS Triple 2-Channel Analog Multiplexer/Demultiplexer CD4053BKMSR 5962R9665103VEC 16 Ld FlatPack 100krad
8-Input Multiplexer HCS151KMSR 5962R9572801VXC 16 Ld FlatPack 200krad
Quad 2-Input Multiplexer HCS157DMSR 5962R9580501VXC 16 Ld SBDIP 200krad
Quad 2-Input Multiplexer HCS157KMSR 5962R9580501VEC 16 Ld FlatPack 200krad
CMOS Quad 2-Input Multiplexer HCTS157DMSR 5962R9575501VEC 16 Ld SBDIP 200krad
CMOS Quad 2-Input Multiplexer HCTS157KMSR 5962R9575501VXC 16 Ld FlatPack 200krad
CD4504BDMSR 5962R9666501VEC 16 Ld SBDIP 100krad
CD4504BHSR 5962R9666501V9A Die (Military Visual) 100krad
CD4504BKMSR 5962R9666501VXC 16 Ld FlatPack 100krad
Digital Logic Multivibrators
CMOS Dual Precision Monostable Multivibrator CD14538BDMSR 5962R9670201VXC 16 Ld SBDIP 100krad
CMOS Dual Precision Monostable Multivibrator CD14538BKMSR 5962R9670201VEC 16 Ld FlatPack 100krad
CMOS Low-Power Monostable/Astable Multivibrator CD4047BDMSR 5962R9663501VCC 14 Ld SBDIP 100krad
CMOS Low-Power Monostable/Astable Multivibrator CD4047BHSR 5962R9663501V9A Die (Military Visual) 100krad
CMOS Low-Power Monostable/Astable Multivibrator CD4047BKMSR 5962R9663501VXC 14 Ld FlatPack 100krad
CMOS Low-Power Monostable/Astable Multivibrator CD4047BKNSR 5962R9663502VXC 14 Ld FlatPack 100krad
CMOS Dual Monostable Multivibrator CD4098BDMSR 5962R9661401VEC 16 Ld SBDIP 100krad
CMOS Dual Monostable Multivibrator CD4 098BKMSR 5962R9661401VXC 16 Ld FlatPack 100krad
17-19
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
17
Military/Space
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
Radiation Hardened Logic Selection Chart
Not Recommended for New Designs (Please contact your local sales representative for availability of die.) (Continued)
Device Description Mkt. Number SMD Number Package RH Level
Digital Logic Registers
CMOS FIFO Register CD40105BDMSR 5962R9660201VEC 16 Ld SBDIP 100krad
CMOS FIFO Register CD40105BKMSR 5962R9660201VXC 16 Ld FlatPack 100krad
CMOS Dual 4-Stage Static Shift Register with Serial Input/Parallel
Output
CMOS Dual 4-Stage Static Shift Register with Serial Input/Parallel
Output
CMOS Dual 4-Stage Static Shift Register with Serial Input/Parallel
Output
CMOS 8-Stage Static Shift Registers CD4021BDMSR 5962R9662302VEC 16 Ld SBDIP 100krad
CMOS 8-Stage Static Shift Registers CD4021BKMSR 5962R9662302VXC 16 Ld FlatPack 100krad
CMOS 4-Bit D-Type Registers CD4076BDMSR 5962R9665601VEC 16 Ld SBDIP 100krad
CMOS 4-Bit D-Type Registers CD4076BHSR 5962R9665601V9A Die (Military Visual) 100krad
CMOS 4-Bit D-Type Registers CD4076BKMSR 5962R9665601VXC 16 Ld FlatPack 100krad
8-Bit Serial-In/Parallel-Out Register HCS164DMSR 5962R9578501VCC 14 Ld SBDIP 200krad
8-Bit Serial-In/Parallel-Out Register HCS164KMSR 5962R9578501VXC 14 Ld FlatPack 200krad
8-Bit Serial-In/Parallel-Out Shift Register HCTS164DMSR 5962R9566301VCC 14 Ld SBDIP 200krad
8-Bit Serial-In/Parallel-Out Shift Register HCTS164KMSR 5962R9566301VXC 14 Ld FlatPack 200krad
8-Bit Universal Shift Register; Three-State HCTS299 KMSR 5962R9574601VXC 20 Ld FlatPack 200krad
CD4015BDMSR 5962R9662401VEC 16 Ld SBDIP 100krad
CD4015BKMSR 5962R9662401VXC 16 Ld FlatPack 100krad
CD4015BKNSR 5962R9662402VXC 16 Ld FlatPack 100krad
Digital Logic Schmitt Triggers
Hex Inverting Schmitt Trigger ACS14DMSR-03 5962F9862301VCC 14 Ld SBDIP 300krad
Hex Inverting Schmitt Trigger ACS14KMSR-03 5962F9862301VXC 14 Ld FlatPack 300krad
Hex Inverting Schmitt Trigger ACS14HMSR-03 5962F9862301V9A Die (Military Visual) 300krad
CMOS Schmitt Trigger, Hex, Inverting CD40106BDMSR 5962R9660301VCC 14 Ld SBDIP 100krad
CMOS Schmitt Trigger, Hex, Inverting CD40106BHSR 5962R9660301V9A Die (Military Visual) 100krad
CMOS Schmitt Trigger, Hex, Inverting CD40106BKMSR 5962R9660301VXC 14 Ld FlatPack 100krad
CMOS Schmitt Trigger, Hex, Inverting CD40106BKNSR 5962R9660302VXC 14 Ld FlatPack 100krad
Hex Inverter Schmitt Trigger HCTS14DMSR 5962R9571901VCC 14 Ld SBDIP 200krad
Hex Inverter Schmitt Trigger HCTS14KMSR 5962R9571901VXC 14 Ld FlatPack 200krad
Hex Inverter Schmitt Trigger HCTS14HMSR 5962R9571901V9A Die (Military Visual) 200krad
17-20
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
SMD Cross Reference
Mkt. Number SMD Number
ACS03DMSR 5962F9670301VCC
ACS03KMSR 5962F9670301VXC
ACS04DMSR-03 5962F9860301VCC
ACS04KMSR-03 5962F9860301VXC
ACS138DMSR-03 5962F9853401VEC
ACS138KMSR-03 5962F9853401VXC
ACS244DMSR-02 5962F9854101VRC
ACS244KMSR-02 5962F9854101VXC
ACS373DMSR 5962F9565501VRC
ACS373KMSR 5962F9565501VXC
ACS374DMSR 5962F9565601VRC
ACS374KMSR 5962F9565601VXC
ACS541KMSR-02 5962F9671002VXC
ACS74DMSR 5962F9679901VCC
ACS74KMSR 5962F9679901VXC
SMD Cross Reference (Continued)
Mkt. Number SMD Number
CD40105BDMSR 5962R9660201VEC
CD40105BKMSR 5962R9660201VXC
CD40106BDMSR 5962R9660301VCC
CD40106BKMSR 5962R9660301VXC
CD40106BKNSR 5962R9660302VXC
CD40109BDMSR 5962R9664501VEC
CD40109BKMSR 5962R9664501VXC
CD40109BKNSR 5962R9664502VXC
CD4013BDMSR 5962R9662201VCC
CD4013BHSR 5962R9662201V9A
CD4013BKMSR 5962R9662201VXC
CD4013BKNSR 5962R9662202VXC
CD4015BDMSR 5962R9662401VEC
CD4015BKMSR 5962R9662401VXC
CD4015BKNSR 5962R9662402VXC
ACTS04DMSR-02 5962F9671201VCC
ACTS04KMSR-02 5962F9671202VXC
ACTS08DMSR-02 5962F9565702VCC
ACTS08KMSR-02 5962F9565702VXC
ACTS161DMSR 5962F9671601VEC
ACTS161KMSR 5962F9671601VXC
ACTS240DMSR 5962F9671701VRC
ACTS240KMSR 5962F9671701VXC
ACTS244DMSR-02 5962F9671802VRC
ACTS244KMSR-02 5962F9671802VXC
ACTS245DMSR 5962F9671901VRC
ACTS245KMSR 5962F9671901VXC
ACTS373DMSR-02 5962F9566102VRC
ACTS373KMSR-02 5962F9566102VXC
ACTS74HMSR-02 5962F9671302V9A
CD14538BDMSR 5962R9670201VEC
CD14538BKMSR 5962R9670201VXC
CD40174BDMSR 5962R9660501VEC
CD40174BKMSR 5962R9660501VXC
CD40193BDMSR 5962R9660802VEC
CD40193BHSR 5962R9660802V9A
CD40193BKMSR 5962R9660802VXC
CD4020BDMSR 5962R9662801VEC
CD4020BHSR 5962R9662801V9A
CD4020BKMSR 5962R9662801VYC
CD4020BKNSR 5962R9662802VYC
CD4021BDMSR 5962R9662302VEC
CD4021BKMSR 5962R9662302VXC
CD4023BDMSR 5962R9662103VCC
CD4023BHSR 5962R9662103V9A
CD4023BKMSR 5962R9662103VXC
CD4024BDMSR 5962R9662803VCC
CD4024BKMSR 5962R9662803VXC
CD4025BDMSR 5962R9582604VCC
17
CD4001BDMSR 5962R9582602VCC
CD4001BHSR 5962R9582602V9A
CD4001BKMSR 5962R9582602VXC
CD4001BKNSR 5962R9582605VXC
CD4008BKMSR 5962R9661901VXC
CD4025BKMSR 5962R9582604VXC
CD4027BKMSR 5962R9662901VXC
CD4028BKMSR 5962R9663001VXC
CD4029BDMSR 5962R9562101VEC
CD4029BHNSR 5962R9562102V9A
17-21
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
Military/Space
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
SMD Cross Reference (Continued)
Mkt. Number SMD Number
CD4029BHSR 5962R9562101V9A
CD4029BKMSR 5962R9562101VXC
CD4030BDMSR 5962R9664601VCC
CD4040BDMSR 5962R9662805VEC
CD4040BKMSR 5962R9662805VYC
CD4040BKNSR 5962R9662806VYC
CD4042BDMSR 5962R9663301VEC
CD4042BKMSR 5962R9663301VXC
CD4043BDMSR 5962R9663401VEC
CD4043BKMSR 5962R9663401VXC
CD4047BKMSR 5962R9663501VXC
CD4047BKNSR 5962R9663502VXC
CD4049UBDMSR 5962R9663601VEC
CD4049UBHSR 5962R9663601V9A
CD4049UBKMSR 5962R9663601VXC
SMD Cross Reference (Continued)
Mkt. Number SMD Number
CD4071BKMSR 5962R9665401VXC
CD4073BHSR 5962R9665501V9A
CD4073BKNSR 5962R9665504VXC
CD4076BDMSR 5962R9665601VEC
CD4076BHSR 5962R9665601V9A
CD4076BKMSR 5962R9665601VXC
CD4077BDMSR 5962R9661102VCC
CD4077BKMSR 5962R9661102VXC
CD4081BDMSR 5962R9665502VCC
CD4081BKMSR 5962R9665502VXC
CD4081BKNSR 5962R9665505VXC
CD4093BDMSR 5962R9664101VCC
CD4093BHSR 5962R9664101V9A
CD4093BKMSR 5962R9664101VXC
CD4093BKNSR 5962R9664102VXC
CD4049UBKNSR 5962R9663602VXC
CD4050BDMSR 5962R9663701VEC
CD4050BKMSR 5962R9663701VXC
CD4051BDMSR 5962R9665101VEC
CD4051BKMSR 5962R9665101VXC
CD4051BKNSR 5962R9665104VXC
CD4052BDMSR 5962R9665102VEC
CD4052BHSR 5962R9665102V9A
CD4052BKMSR 5962R9665102VXC
CD4053BDMSR 5962R9665103VEC
CD4053BHSR 5962R9665103V9A
CD4053BKMSR 5962R9665103VXC
CD4060BDMSR 5962R9660901VEC
CD4060BKMSR 5962R9660901VXC
CD4063BKMSR 5962R9675701VXC
CD4066BDMSR 5962R9665201VCC
CD4066BKMSR 5962R9665201VXC
CD4098BDMSR 5962R9661401VEC
CD4098BKMSR 5962R9661401VXC
CD4099BDMSR 5962R9661501VEC
CD4099BKMSR 5962R9661501VXC
CD4503BDMSR 5962R9664301VEC
CD4503BKMSR 5962R9664301VXC
CD4503BKNSR 5962R9664302VXC
CD4504BDMSR 5962R9666501VEC
CD4504BKMSR 5962R9666501VXC
CD4512BDMSR 5962R9666701VEC
CD4512BKMSR 5962R9666701VXC
CD4514BDMSR 5962R9668101VJC
CD4514BHSR 5962R9668101V9A
CD4514BKMSR 5962R9668101VXC
CD4520BHSR 5962R9666902V9A
CD4555BDMSR 5962R9667301VEC
CD4555BKMSR 5962R9667301VXC
CD4069UBDMSR 5962R9665301VCC
CD4069UBKMSR 5962R9665301VXC
CD4070BDMSR 5962R9661101VCC
CD4070BKMSR 5962R9661101VXC
CD4071BDMSR 5962R9665401VCC
CD4585BDMSR 5962R9667401VEC
CD4585BKMSR 5962R9667401VXC
HCS00DMSR 5962R9572401VCC
HCS00KMSR 5962R9572401VXC
HCS02DMSR 5962R9567901VCC
17-22
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
SMD Cross Reference (Continued)
Mkt. Number SMD Number
HCS02KMSR 5962R9567901VXC
HCS05KMSR 5962R9580101VXC
HCS08DMSR 5962R9568001VCC
HCS08KMSR 5962R9568001VXC
HCS109DMSR 5962R9578401VEC
HCS109KMSR 5962R9578401VXC
HCS10KMSR 5962R9577701VXC
HCS11DMSR 5962R9572001VCC
HCS11KMSR 5962R9572001VXC
HCS132DMSR 5962R9572601VCC
HCS132KMSR 5962R9572601VXC
HCS138DMSR 5962R9572701VEC
HCS138KMSR 5962R9572701VXC
HCS139DMSR 5962R9580401VEC
HCS139KMSR 5962R9580401VXC
SMD Cross Reference (Continued)
Mkt. Number SMD Number
HCS373KMSR 5962R9579201VXC
HCS374DMSR 5962R9579301VRC
HCS374KMSR 5962R9579301VXC
HCS573KMSR 5962R9579401VXC
HCS86DMSR 5962R9578301VCC
HCS86KMSR 5962R9578301VXC
HCTS00DMSR 5962R9563701VCC
HCTS00KMSR 5962R9563701VXC
HCTS04DMSR 5962R9573201VCC
HCTS04KMSR 5962R9573201VXC
HCTS08DMSR 5962R9568301VCC
HCTS08KMSR 5962R9568301VXC
HCTS138DMSR 5962R9574001VEC
HCTS138KMSR 5962R9574001VXC
HCTS139DMSR 5962R9575301VEC
HCS151KMSR 5962R9572801VXC
HCS154DMSR 5962R9572901VJC
HCS154KMSR 5962R9572901VXC
HCS161DMSR 5962R9573001VEC
HCS161KMSR 5962R9573001VXC
HCS163DMSR 5962R9580701VEC
HCS163KMSR 5962R9580701VXC
HCS164DMSR 5962R9578501VCC
HCS164KMSR 5962R9578501VXC
HCS166DMSR 5962R9578701VEC
HCS166KMSR 5962R9578701VXC
HCS240DMSR 5962R9580901VRC
HCS240KMSR 5962R9580901VXC
HCS245DMSR 5962R9679701VRC
HCS245KMSR 5962R9679701VXC
HCS273DMSR 5962R9579101VRC
HCS273KMSR 5962R9579101VXC
HCTS139KMSR 5962R9575301VXC
HCTS153KMSR 5962R9575401VXC
HCTS157DMSR 5962R9575501VEC
HCTS157KMSR 5962R9575501VXC
HCTS164DMSR 5962R9566301VCC
HCTS164KMSR 5962R9566301VXC
HCTS191DMSR 5962R9575601VEC
HCTS191KMSR 5962R9575601VXC
HCTS193KMSR 5962R9575701VXC
HCTS20KMSR 5962R9573301VXC
HCTS240ADMSR 5962R9577201VRC
HCTS240AKMSR 5962R9577201VXC
HCTS245DMSR 5962R9574501VRC
HCTS245KMSR 5962R9574501VXC
HCTS283DMSR 5962R9577401VEC
HCTS283KMSR 5962R9577401VXC
HCTS299KMSR 5962R9574601VXC
17
HCS27DMSR 5962R9578001VCC
HCS27KMSR 5962R9578001VXC
HCS32DMSR 5962R9578101VCC
HCS32KMSR 5962R9578101VXC
HCS373DMSR 5962R9579201VRC
HCTS30DMSR 5962R9573501VCC
HCTS30KMSR 5962R9573501VXC
HCTS32DMSR 5962R9573601VCC
HCTS32KMSR 5962R9573601VXC
HCTS393KMSR 5962R9575001VXC
17-23
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
Military/Space
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
SMD Cross Reference (Continued)
Mkt. Number SMD Number
HCTS540KMSR 5962R9577601VXC
HCTS541DMSR 5962R9575101VRC
HCTS541KMSR 5962R9575101VXC
HCTS574DMSR 5962R9575801VRC
HCTS574KMSR 5962R9575801VXC
HCTS74DMSR 5962R9576301VCC
HCTS74KMSR 5962R9576301VXC
HCTS85DMSR 5962R9576801VEC
HS1-139RH-8 5962F9861301QCC
HS1-139RH-Q 5962F9861301VCC
HS1-1825ARH-8 5962F9955801QEC
HS1-1825ARH-Q 5962F9955801VEC
HS1-1840ARH-8 5962F9563002QXC
HS1-1840ARH-Q 5962F9563002VXC
HS1-201HSRH-8 5962F9961801QEC
SMD Cross Reference (Continued)
Mkt. Number SMD Number
HS1-390RH-Q 5962R9581303VEC
HS1-508BRH-8 5962F9674202QEC
HS1-508BRH-Q 5962F9674202VEC
HS1-5104ARH-Q 5962R9569001VCC
HS1-5104ARH-T 5962R9569001TCC
HS1-6664RH-8 5962F9562601QXC
HS1-6664RH-Q 5962F9562601VXC
HS1-80C86RH-8 5962R9572201QQC
HS1-80C86RH-Q 5962R9572201VQC
HS1-82C54RH-8 5962R9571301QJC
HS1-82C54RH-Q 5962R9571301VJC
HS1-82C55ARH-8 5962R9581901QQC
HS1-82C55ARH-Q 5962R9581901VQC
HS1-82C85RH-8 5962R9582001QJC
HS1-82C85RH-Q 5962R9582001VJC
HS1-201HSRH-Q 5962F9961801VEC
HS1-246RH-8 5962R9672301QCC
HS1-246RH-Q 5962R9672301VCC
HS1-248RH-8 5962R9672302QCC
HS1-248RH-Q 5962R9672302VCC
HS1-26C31RH-8 5962F9666301QEC
HS1-26C31RH-Q 5962F9666301VEC
HS1-26C32RH-8 5962F9568901QEC
HS1-26C32RH-Q 5962F9568901VEC
HS1-26CLV31RH-8 5962F966302QEC
HS1-26CLV31RH-Q 5962F9666302VEC
HS1-26CLV32RH-8 5962F9568902QEC
HS1-26CLV32RH-Q 5962F9568902VEC
HS1-26CT31RH-8 5962F9563201QEC
HS1-26CT31RH-Q 5962F9563201VEC
HS1-26CT31RH-T 5962R9563201TEC
HS1-26CT32RH-8 5962F9563101QEC
HS1B-0546RH-Q 5962D9569301VXC
HS1B-0547RH-Q 5962D9569302VXC
HS1B-0548RH-Q 5962D9569401VEC
HS1B-2420RH-Q 5962R9566901VCC
HS2-117RH-8 5962F9954701QUC
HS2-117RH-Q 5962F9954701VUC
HS2-2520RH-Q 5962D9568501VGA
HS2-2700RH-Q 5962D9567002VGA
HS2-3530ARH-8 5962F9568701QGA
HS2-3530ARH-Q 5962F9568701VGA
HS4-1825ARH-8 5962F9955801Q2C
HS4-1825ARH-Q 5962F9955801V2C
HS7B-1100RH-Q 5962F9467602VPC
HS7B-1115RH-Q 5962F9678501VPC
HS7B-1135RH-Q 5962F9676701VPC
HS7B-1145RH-Q 5962F9683001VPC
HS7B-2510RH-Q 5962D9568601VPC
HS1-26CT32RH-Q 5962F9563101VEC
HS1-26CT32RH-T 5962R9563101TEC
HS1-302RH-8 5962R9581201QCC
HS1-302RH-Q 5962R9581201VCC
HS1-390RH-8 5962R9581303QEC
HS7B-2520RH-Q 5962D9568501VPC
HS7B-2622RH-Q 5962D9568802VPC
HS9-139RH-8 5962F9861301QXC
HS9-139RH-Q 5962F9861301VXC
HS9-1825ARH-8 5962F9955801QXC
17-24
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
SMD Cross Reference (Continued)
Mkt. Number SMD Number
HS9-1825ARH-Q 5962F9955801VXC
HS9-1840ARH-8 5962F9563002QYC
HS9-1840ARH-Q 5962F9563002VYC
HS9-201HSRH-8 5962F9961801QXC
HS9-201HSRH-Q 5962F9961801VXC
HS9-22620RH-Q 5962F9751201VXC
HS9-246RH-8 5962R9672301QXC
HS9-246RH-Q 5962R9672301VXC
HS9-248RH-8 5962R9672302QXC
HS9-248RH-Q 5962R9672302VXC
HS9-2510RH-Q 5962D9568601VXC
HS9-26C31RH-8 5962F9666301QXC
HS9-26C31RH-Q 5962F9666301VXC
HS9-26C32RH-8 5962F9568901QXC
HS9-26C32RH-Q 5962F9568901VXC
SMD Cross Reference (Continued)
Mkt. Number SMD Number
HS9-4424BRH-Q 5962F9956002VXC
HS9-4424RH-8 5962F9956001QXC
HS9-4424RH-Q 5962F9956001VXC
HS9-508BRH-8 5962F9674202QXC
HS9-508BRH-Q 5962F9674202VXC
HS9-5104ARH-Q 5962R9569001VXC
HS9-5104ARH-T 5962R9569001TXC
HS9-6254RH-Q 5962F9764101VXC
HS9-6664RH-8 5962F9562601QYC
HS9-6664RH-Q 5962F9562601VYC
HS9-80C86RH-8 5962R9572201QXC
HS9-80C86RH-Q 5962R9572201VXC
HS9-82C54RH-8 5962R9571301QXC
HS9-82C54RH-Q 5962R9571301VXC
HS9-82C85RH-8 5962R9582001QXC
HS9-26CLV31RH-8 5962F9666302QXC
HS9-26CLV31RH-Q 5962F9666302VXC
HS9-26CLV32RH-8 5962F9568902QXC
HS9-26CLV32RH-Q 5962F9568902VXC
HS9-26CT31RH-8 5962F9563201QXC
HS9-26CT31RH-Q 5962F9563201VXC
HS9-26CT31RH-T 5962R9563201TXC
HS9-26CT32RH-8 5962F9563101QXC
HS9-26CT32RH-Q 5962F9563101VXC
HS9-26CT32RH-T 5962R9563101TXC
HS9-302RH-8 5962R9581201QXC
HS9-302RH-Q 5962R9581201VXC
HS9-3530ARH-Q 5962F9568701VXC
HS9-390RH-8 5962R9581303QYC
HS9-390RH-Q 5962R9581303VYC
HS9-4080ARH-8 5962F9961701QSC
HS9-4080ARH-Q 5962F9961701VSC
HS9-82C85RH-Q 5962R9582001VXC
HS9-OP470ARH-Q 5962R9853301VXC
HS9S-117RH-8 5962F9954701QXC
HS9S-117RH-Q 5962F9954701VXC
HSYE-117RH-8 5962F9954701QYC
HSYE-117RH-Q 5962F9954701VYC
IS0-2100ARH-Q 5962F9953602VXC
IS1-1825ASRH-8 5962F0251101QEC
IS1-1825ASRH-Q 5962F0251101VEC
IS1-2981RH-8 5962R0052001QVC
IS1-2981RH-Q 5962R0052001VVC
IS2-1009RH-8 5962F0052301QXC
IS2-1009RH-Q 5962F0052301VXC
IS7-1845ASRH-8 5962F0150901QPC
IS7-1845ASRH-Q 5962F0150901VPC
IS9-139ASRH-8 5962F0151001QXC
IS9-139ASRH-Q 5962F0151001VXC
17
HS9-4423BRH-8 5962F9951102QXC
HS9-4423BRH-Q 5962F9951102VXC
HS9-4423RH-8 5962F9951101QXC
HS9-4423RH-Q 5962F9951101VXC
HS9-4424BRH-8 5962F9956002QXC
IS9-1715ARH-8 5962F0052101QXC
IS9-1715ARH-Q 5962F0052101VXC
IS9-1825ASRH-8 5962F0251101QXC
IS9-1825ASRH-Q 5962F0251101VXC
17-25
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
Military/Space
www.intersil.com
www.intersil.com/military/
www.BDTIC.com/Intersil
SMD Cross Reference (Continued)
Mkt. Number SMD Number
IS9-1845ASRH-8 5962F0150901QXC
IS9-1845ASRH-Q 5962F0150901VXC
IS9-2100ARH-8 5962F9953602QXC
IS9-2100ARH-Q 5962F9953602VXC
IS9-705RH-8 5962R0053801QXC
IS9-705RH-Q 5962R0053801VXC
ISL7124SRHQF 5962F0254201QXC
ISL7124SRHVF 5962F0254201VXC
ISL72991RHQF 5962F0250301QXC
ISL72991RHVF 5962F0250301VXC
ISL72991RHVX 5962F0250301V9A
ISL74422ARHQF 5962F0152101QXC
ISL74422ARHVF 5962F0152101VXC
ISYE-1009RH-8 5962F0052301QYC
ISYE-1009RH-Q 5962F0052301VYC
17-26
1-888-INTERSIL or 1-888-468-3774 | Copyright © 2008 Intersil Americas Inc. All rights reserved.
www.intersil.com
Loading...
