intersil ISL90842 DATA SHEET

®

www.BDTIC.com/Intersil

Quad Digitally Controlled Variable Resistors

ISL90842

Data Sheet January 16, 2006

Low Noise, Low Power I2C® Bus, 256 Taps

The ISL90842 integrates four digitally controlled
potentiometers (DCP) configured as variable resistors on a
monolithic CMOS integrated circuit.

The digitally controlled potentiometers are implemented with
a combination of resistor elements and CMOS switches. The
position of the wipers are controlled by the user through the

2

I

C bus interface. Each potentiometer has an associated
Wiper Register (WR) that can be directly written to and read
by the user. The contents of the WR controls the position of
the wiper.

The DCPs can be used as two-terminal variable resistors in
a wide variety of applications including control, parameter
adjustments, and signal processing.

FN8096.1

Features

• Four variable resistors in one package

• 256 resistor taps - 0.4% resolution

•I2C serial interface

• Wiper resistance: 70Ω typical @ 3.3V

• Standby current <5µA max

• Power supply: 2.7V to 5.5V

•50kΩ, 10kΩ total resistance

• 14 Lead TSSOP

• Pb-free plus anneal available (RoHS compliant)

Pinout

ISL90842

(14 LEAD TSSOP)

TOP VIEW

RW0

RH3

RW3

SCL

SDA

GND

RW2

RH2

1

2

3

4

5

6

7

14

RH0

13

VCC

12

A1

11

A0

10

RH1

9

RW1

8

Ordering Information

PART NUMBER PART MARKING

ISL90842UIV1427Z (Notes 1 & 2) 90842UI27Z 50K -40 to +85 14 Ld TSSOP (Pb-Free)

ISL90842WIV1427Z (Notes 1 & 2) 90842WI27Z 10K -40 to +85 14 Ld TSSOP (Pb-Free)

NOTES:

1. Intersil Pb-free plus anneal products employ special Pb-free material sets; molding compounds/die attach materials and 100% matte tin plate
termination finish, which are RoHS compliant and compatible with both SnPb and Pb-free soldering operations. Intersil Pb-free products are MSL
classified at Pb-free peak reflow temperatures that meet or exceed the Pb-free requirements of IPC/JEDEC J STD-020.

2. Add “-TK” suffix for Tape and Reel.

1

RESISTANCE OPTION

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 1-888-468-3774

XDCP is a trademark of Intersil Americas Inc. Copyright Intersil Americas Inc. 2005, 2006. All Rights Reserved

(Ω)

| Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.

TEMP RANGE

(°C) PACKAGE

Functional Diagram

www.BDTIC.com/Intersil

SCL

ISL90842

V

CC

R

H0

R

H1

R

H2

R

H3

Block Diagram

SDA

SCL

A1

A0

SDA

A0

A1

I2C INTERFACE

I2C

INTERFACE

GND R

POWER-UP,

INTERFACE,

CONTROL

AND STATUS

R

L

LOGIC

W0

R

L

V

CC

R

W1

WR3

WR2

WR1

WR0

R

L

R

W2

DCP3

DCP2

DCP1

DCP0

R

L

R

W3

R

H3

R

W3

*

R

H2

R

W2

*

R

H1

R

W1

*

R

H0

R

W0

*

GND

PINS OF EACH DCP ARE LEFT FLOATING

* THE R

L

Pin Descriptions

TSSOP PIN SYMBOL DESCRIPTION

1 RH3 “High” terminal of DCP3

2 RW3 “Wiper” terminal of DCP3

2

3SCLI

4 SDA Serial data I/O for the I

5 GND Device ground pin

6 RW2 “Wiper” terminal of DCP2

7 RH2 “High” terminal of DCP2

8 RW1 “Wiper” terminal of DCP1

9 RH1 “High” terminal of DCP1

10 A0 Device address for the I

11 A1 Device address for the I

12 VCC Power supply pin

13 RH0 “High” terminal of DCP0

14 RW0 “Wiper” terminal of DCP0

C interface clock

2

C interface

2

C interface

2

C interface

2

FN8096.1

January 16, 2006

ISL90842

www.BDTIC.com/Intersil

Absolute Maximum Ratings Recommended Operating Conditions

Storage temperature . . . . . . . . . . . . . . . . . . . . . . . .-65°C to +150°C

Voltage at any digital interface pin

with respect to GND . . . . . . . . . . . . . . . . . . . . . . -0.3V to V

V

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to +6V

CC

Voltage at any DCP pin with

respect to GND. . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to V

Lead temperature (soldering, 10s). . . . . . . . . . . . . . . . . . . . . . 300°C

(10s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±6mA

I

W

Latchup . . . . . . . . . . . . . . . . . . . . . . . . . . Class II, Level B at +85°C

ESD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >2kV Human Body Model

CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.

Analog Specifications Over recommended operating conditions unless otherwise stated.

SYMBOL PARAMETER TEST CONDITIONS MIN

R

TOTAL

R

C

H/CL/CW

I

LkgDCP

RESISTOR MODE (Measurements between R

RINL

(Note 5)

RDNL

(Note 4)

Roffset

(Note 3)

R

MATCH

(Note 6)

TC

(Note 7)

RH to RW resistance W option, wiper counter = 00h 10 kΩ

U option, wiper counter = 00h 50 kΩ

to RW resistance tolerance Wiper counter = 00h -20 +20 %

R

H

Wiper resistance VCC = 3.3V @ 25°C, wiper current =

W

Potentiometer capacitance (Note 15) 10/10/25 pF

Leakage on DCP pins (Note 15) Voltage at pin from GND to V

Integral non-linearity DCP register set between 20 hex and FF

Differential non-linearity -0.5 0.5 MI

Offset U option 0 1 7 MI

DCP to DCP matching Any two DCPs at the same tap position with

Resistance temperature coefficient DCP register set between 20 hex and FF hex ±45 ppm/°C

R

V

i and RHi, i = 0, 1, 2 or 3)

W

hex; monotonic over all tap positions

W option 0 0.5 2 MI

the same terminal voltages

+0.3

CC

CC

CC/RTOTAL

Industrial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to +85°C

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.7V to 5.5V

V

CC

Power rating of each DCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5mW

Wiper current of each DCP . . . . . . . . . . . . . . . . . . . . . . . . . . ±3.0mA

TYP

(NOTE 1) MAX UNIT

70 200 Ω

CC

-1 1 MI

-2 2 MI

0.1 1 µA

(Note 2)

(Note 2)

(Note 2)

(Note 2)

(Note 2)

Operating Specifications Over the recommended operating conditions unless otherwise specified.

SYMBOL PARAMETER TEST CONDITIONS MIN

I

CC1

I

SB

I

LkgDig

VCC supply current (volatile write/
read)

VCC current (standby) V

Leakage current, at pins A0, A1, SDA,
and SCL

f

= 400kHz; SDA = Open; (for I2C, active,

SCL

read and write states)

= +5.5V, I2C interface in standby state 5 µA

CC

= +3.6V, I2C interface in standby state 2 µA

V

CC

Voltage at pin from GND to V

CC

3

TYP

(NOTE 1) MAX UNIT

1mA

-10 10 µA

FN8096.1

January 16, 2006

ISL90842

www.BDTIC.com/Intersil

Operating Specifications Over the recommended operating conditions unless otherwise specified. (Continued)

SYMBOL PARAMETER TEST CONDITIONS MIN

t

DCP

(Note 8)

DCP wiper response time SCL falling edge of last bit of DCP data byte

to wiper change

SERIAL INTERFACE SPECS

V

A1, A0, SDA, and SCL input buffer

IL

-0.3 0.3*V

LOW voltage

V

IH

Hysteresis

(Note 8)

V

OL

(Note 8)

Cpin

(Note 8)

f

SCL

t

IN

(Note 8)

t

AA

(Note 8)

t

BUF

(Note 8)

A1, A0, SDA, and SCL input buffer
HIGH voltage

SDA and SCL input buffer hysteresis 0.05*

SDA output buffer LOW voltage,
sinking 4mA

A1, A0, SDA, and SCL pin
capacitance

SCL frequency 400 kHz

Pulse width suppression time at SDA
and SCL inputs

SCL falling edge to SDA output data
valid

Time the bus must be free before the
start of a new transmission

Any pulse narrower than the max spec is
suppressed

SCL falling edge crossing 30% of V
SDA exits the 30% to 70% of V

SDA crossing 70% of V
condition, to SDA crossing 70% of V

during a STOP

CC

window

CC

CC

CC

, until

0.7*V

V

CC

00.4V

1300 ns

during the following START condition

t

LOW

t

HIGH

t

SU:STA

t

HD:STA

t

SU:DAT

t

HD:DAT

Clock LOW time Measured at the 30% of VCC crossing 1300 ns

Clock HIGH time Measured at the 70% of VCC crossing 600 ns

START condition setup time SCL rising edge to SDA falling edge; both

crossing 70% of V

CC

START condition hold time From SDA falling edge crossing 30% of VCC

to SCL falling edge crossing 70% of V

CC

Input data setup time From SDA exiting the 30% to 70% of VCC

600 ns

600 ns

100 ns
window, to SCL rising edge crossing 30% of
V

CC

Input data hold time From SCL rising edge crossing 70% of VCC

to SDA entering the 30% to 70% of V

CC

0ns

window

t

SU:STO

t

HD:STO

t

DH

(Note 8)

t

R

STOP condition hold time From SCL rising edge crossing 70% of VCC,

to SDA rising edge crossing 30% of V

STOP condition hold time for read, or
volatile only write

From SDA rising edge to SCL falling edge.
Both crossing 70% of V

CC

Output data hold time From SCL falling edge crossing 30% of V

until SDA enters the 30% to 70% of V
window

SDA and SCL rise time From 30% to 70% of V

CC

CC

CC

CC

(Note 8)

t

(Note 8)

Cb

(Note 8) Capacitive loading of SDA or SCL Total on-chip and off-chip 10 400 pF

Rpu

(Note 8)

SDA and SCL fall time From 70% to 30% of V

F

SDA and SCL bus pull-up resistor off­chip

Maximum is determined by t
For Cb = 400pF, max is about 2~2.5kΩ

CC

and t

R

F

600 ns

600 ns

0ns

,

20 +

0.1 * Cb

20 +

0.1 * Cb

1kΩ

For Cb = 40pF, max is about 15~20kΩ

TYP

(NOTE 1) MAX UNIT

1µs

CC

VCC+0.3 V

10 pF

50 ns

900 ns

250 ns

250 ns

CC

V

V

4

FN8096.1

January 16, 2006

ISL90842

www.BDTIC.com/Intersil

Operating Specifications Over the recommended operating conditions unless otherwise specified. (Continued)

SYMBOL PARAMETER TEST CONDITIONS MIN

t

SU:A

t

HD:A

A1 and A0 setup time Before START condition 600 ns

A1 and A0 hold time After STOP condition 600 ns

TYP

(NOTE 1) MAX UNIT

SDA vs SCL Timing

SCL

t

SU:STA

(INPUT TIMING)

(OUTPUT TIMING)

SDA

SDA

A0 and A1 Pin Timing

SCL

SDA IN

A0, A1

t

HD:STA

t

F

START

t

SU:DAT

t

SU:A

t

HIGH

CLK 1

t

LOW

t

HD:DAT

t

R

t

SU:STO

t

t

DH

AA

STOP

t

HD:A

t

BUF

NOTES:

1. Typical values are for T

|R

2. MI =

3. Roffset = R

4. RDNL = (R

5. RINL = [R

6. R

MATCH

7. for i = 32 to 255, T = -40°C to 85°C. Max ( ) is the maximum value of the resistance and Min ( ) is the

TC

– R

255

0

/ MI, when measuring between RW and RH.

255

– R

i

i-1

– (MI • i) – R0] / MI, for i = 32 to 255.

i

= (R

– R

i,x

Max Ri()Min Ri()–[]

------------------------------------------------------------ --- -

R

Max Ri()Min Ri()+[]2⁄

= 25°C and 3.3V supply voltage.

A

| / 255. R

and R0 are the measured resistances for the DCP register set to FF hex and 00 hex, respectively.

255

) / MI, for i = 32 to 255.

) / MI, for i = 0 to 255, x = 0 to 3 and y = 0 to 3.

i,y

---------------- -

×=

125°C

6

10

minimum value of the resistance over the temperature range.

8. This parameter is not 100% tested.

5

FN8096.1

January 16, 2006

Typical Performance Curves

www.BDTIC.com/Intersil

ISL90842

160

140

VCC=2.7, T=-40°C

120

100

80

60

40

WIPER RESISTANCE (Ω)

VCC=5.5, T=-40°C

20

0

0 50 100 150 200 250

VCC=2.7, T=+85°C

VCC=5.5, T=+25°C

TAP POSITION (DECIMAL)

VCC=2.7, T=+25°C

VCC=5.5, T=+85°C

FIGURE 1. WIPER RESISTANCE vs TAP POSITION

[I(R

) = V

W

0.3

0.2

0.1

0

DNL (LSB)

-0.1

-0.2

-0.3
32 82 132 182 232

V

VCC=5.5, T=+85°C

/ R

CC

=5.5, T=+25°C

CC

VCC=2.7, T=-40°C

TAP POSITION (DECIMAL)

] FOR 50kΩ (U)

TOTAL

=5.5, T=-40°C

V

CC

VCC=2.7, T=+25°C

VCC=2.7, T=+85°C

1.8

1.6

1.4

1.2

(µA)

CC

1

0.8

0.6

STANDBY I

0.4

0.2

0

2.7 3.2 3.7 4.2 4.7 5.2

+25°C

FIGURE 2. STANDBY I

0.5

0.3

0.1

-0.1

INL (LSB)

-0.3

-0.5
32 82 132 182 232

=2.7, T=+85°C

V

CC

VCC=5.5, T=+25°C

-40°C

(V)

V

CC

vs Vcc

CC

VCC=2.7, T=+25°C

VCC=5.5, T=-40°C

VCC=5.5, T=+85°C

TAP POSITION (DECIMAL)

+85°C

VCC=2.7,

T=-40°C

FIGURE 3. DNL vs TAP POSITION FOR 50kΩ (U) FIGURE 4. INL vs TAP POSITION FOR 50kΩ (U)

1.5

1

2.7V

0.5

CHANGE (%)

5.5V

0

TOTAL

-0.5

-1

END TO END R

-1.5

-40 -20 20 40 60 80

FIGURE 5. END TO END R

0

TEMPERATURE (°C)

% CHANGE vs

TOTAL

35

25

15

5

TC (ppm/°C)

-5

-15

-25
32 82 132 182 232

TAP POSITION (DECIMAL)

FIGURE 6. TC IN ppm

TEMPERATURE

6

FN8096.1

January 16, 2006

Typical Performance Curves (Continued)

www.BDTIC.com/Intersil

ISL90842

INPUT

OUTPUT

TAP POSITION = MID POINT
R

=9.4K

TOTAL

FIGURE 7. FREQUENCY RESPONSE (2.2MHz) FIGURE 8. LARGE SIGNAL SETTLING TIME

Principles of Operation

The ISL90842 is an integrated circuit incorporating four
DCPs with their associated registers, and an I
interface providing direct communication between a host
and the DCPs.

DCP Description

Each DCP is implemented with a combination of resistor
elements and CMOS switches. The physical ends of each
DCP are equivalent to the fixed terminals of a mechanical
potentiometer. The R
intermediate nodes, and is equivalent to the wiper terminal
of a mechanical potentiometer. The position of the wiper
terminal within the DCP is controlled by an 8-bit volatile
Wiper Register (WR). Each DCP has its own WR. When the
WR of a DCP contains all zeroes (WR<7:0>: 00h), its wiper
terminal (R

) is closest to its RL terminal. When the WR of a

W

DCP contains all ones (WR<7:0>: FFh), its wiper terminal
(R

) is furthest from the RH terminal. As the value of the

W

WR increases from all zeroes (00h) to all ones (255
decimal), the wiper moves monotonically from the position
furthest from R

H

the resistance between R
monotonically. Note that the R
not connected (left floating).

While the ISL90842 is being powered up, all four WRs are
reset to 80h (128 decimal), which locates R
position which yields a rheostat setting that is about 1/2 of
R

TOTAL

.

The WRs can be read or written directly using the I
interface as described in the following sections. The I
interface Address Byte has to be set to 00h, 01h, 02h, and
03h to access the WR of DCP0, DCP1, DCP2, and DCP3,
respectively.

pin of each DCP is connected to

W

to a position closer to RH. At the same time,

and RW decreases

H

terminals for all four pots are

L

2

C serial

roughly at a

W

2

C serial

2

C

SCL

SIGNAL AT WIPER
(WIPER UNLOADED
MOVEMENT FROM
ffh TO 00h)

I2C Serial Interface

The ISL90842 supports a bidirectional bus oriented protocol.
The protocol defines any device that sends data onto the
bus as a transmitter and the receiving device as the receiver.
The device controlling the transfer is a master and the
device being controlled is the slave. The master always
initiates data transfers and provides the clock for both
transmit and receive operations. Therefore, the ISL90842
operates as a slave device in all applications.

All communication over the I
sending the MSB of each byte of data first.

Protocol Conventions

Data states on the SDA line must change only during SCL
LOW periods. SDA state changes during SCL HIGH are
reserved for indicating START and STOP conditions (See
Figure 9). On power-up of the ISL90842 the SDA pin is in the
input mode.

2

All I

C interface operations must begin with a START
condition, which is a HIGH to LOW transition of SDA while
SCL is HIGH. The ISL90842 continuously monitors the SDA
and SCL lines for the START condition and does not
respond to any command until this condition is met (See
Figure 9). A START condition is ignored during the power-up
of the device.

2

All I

C interface operations must be terminated by a STOP
condition, which is a LOW to HIGH transition of SDA while
SCL is HIGH (See Figure 9). A STOP condition at the end of
a read operation, or at the end of a write operation places
the device in its standby mode.

An ACK, Acknowledge, is a software convention used to
indicate a successful data transfer. The transmitting device,
either master or slave, releases the SDA bus after
transmitting eight bits. During the ninth clock cycle, the

2

C interface is conducted by

receiver pulls the SDA line LOW to acknowledge the reception of the eight bits of data (See Figure 10).

7

FN8096.1

January 16, 2006

ISL90842

www.BDTIC.com/Intersil

The ISL90842 responds with an ACK after recognition of a
START condition followed by a valid Identification Byte, and
once again after successful receipt of an Address Byte. The
ISL90842 also responds with an ACK after receiving a Data
Byte of a write operation. The master must respond with an
ACK after receiving a Data Byte of a read operation

A valid Identification Byte contains 01010 as the five MSBs,
and the following two bits matching the logic values present
at pins A1 and A0. The LSB is the Read/Write

SCL

SDA

START DATA DATA STOP

FIGURE 9. VALID DATA CHANGES, START, AND STOP CONDITIONS

SCL FROM

MASTER

bit. Its value is

STABLE CHANGE

“1” for a Read operation, and “0” for a Write operation (See
Table 1).

TABLE 1. IDENTIFICATION BYTE FORMAT

Logic values at pins A1, and A0 respectively

01010A1A0R/W

(MSB) (LSB)

DATA

STABLE

81 9

SDA OUTPUT FROM

TRANSMITTER

SDA OUTPUT FROM

RECEIVER

SIGNALS FROM

SIGNAL AT SDA

SIGNALS FROM

HIGH IMPEDANCE

START ACK

FIGURE 10. ACKNOWLEDGE RESPONSE FROM RECEIVER

WRITE

S

THE MASTER

THE ISL90842

T
A

IDENTIFICATION

R
T

BYTE

00011

ADDRESS

BYTE

000 0A0A100000

A
C
K

A
C
K

FIGURE 11. BYTE WRITE SEQUENCE

DATA

BYTE

HIGH IMPEDANCE

S
T

O

P

A
C
K

8

FN8096.1

January 16, 2006

ISL90842

www.BDTIC.com/Intersil

SIGNALS

FROM THE

MASTER

SIGNAL AT SDA

SIGNALS FROM

THE SLAVE

S
T
A

IDENTIFICATION

R

BYTE WITH

T

R/W

00011

ADDRESS

=0

A
C
K

BYTE

0000 000 A1A0

A
C
K

FIGURE 12. READ SEQUENCE

Write Operation

A Write operation requires a START condition, followed by a
valid Identification Byte, a valid Address Byte, a Data Byte,
and a STOP condition. After each of the three bytes, the
ISL90842 responds with an ACK. At this time, the device
enters its standby state (See Figure 11).

Read Operation

A Read operation consist of a three byte instruction followed
by one or more Data Bytes (See Figure 12). The master
initiates the operation issuing the following sequence: a
START, the Identification byte with the R/W
Address Byte, a second START, and a second Identification
byte with the R/W

bit set to “1”. After each of the three bytes,
the ISL90842 responds with an ACK. Then the ISL90842
transmits Data Bytes as long as the master responds with an
ACK during the SCL cycle following the eighth bit of each
byte. The master terminates the read operation (issuing a
STOP condition) following the last bit of the last Data Byte
(See Figure 12).

bit set to “0”, an

S
T
A

IDENTIFICATION

R

BYTE WITH

T

R/W

010110A1A0

A

A

C

C

K

=1

A
C

FIRST READ

K

DATA BYTE

K

LAST READ

DATA BYTE

S
T
O
P

The Data Bytes are from the registers indicated by an
internal pointer. This pointer initial value is determined by the
Address Byte in the Read operation instruction, and
increments by one during transmission of each Data Byte.
After reaching the memory location 03h the pointer “rolls
over” to 00h, and the device continues to output data for
each ACK received.

9

FN8096.1

January 16, 2006

Packaging Information

www.BDTIC.com/Intersil

ISL90842

14-Lead Plastic, TSSOP, Package Code V14

.025 (.65) BSC

0° - 8°

.0075 (.19)
.0118 (.30)

.193 (4.9)
.200 (5.1)

.019 (.50)
.029 (.75)

Detail A (20X)

.169 (4.3)
.177 (4.5)

.041 (1.05)

.002 (.05)
.006 (.15)

.010 (.25)

Gage Plane

Seating Plane

.252 (6.4) BSC

.031 (.80)

.041 (1.05)

See Detail “A”

NOTE: ALL DIMENSIONS IN INCHES (IN PARENTHESES IN MILLIMETERS)

All Intersil U.S. products are manufactured, assembled and tested utilizing ISO9000 quality systems.

Intersil Corporation’s quality certifications can be viewed at www.intersil.com/design/quality

Intersil products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design, software and/or specifications at any time without
notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be accurate and
reliable. However, no responsibility is assumed by Intersil or its subsidiaries for its use; nor for any infringements of patents or other rights of third parties which may result
from its use. No license is granted by implication or otherwise under any patent or patent rights of Intersil or its subsidiaries.

For information regarding Intersil Corporation and its products, see www.intersil.com

10

FN8096.1

January 16, 2006
