Data Sheet September 22, 2005

S

N

IG

S

ISL6744

FN9147.8

Intermediate Bus PWM Controller

The ISL6744 is a low cost, primary side, double-ended
controller intended for applications using full and half-bridge
topologies for unregulated DC/DC converters. It is a voltage­mode PWM controller designed for half-bridge and full­bridge power supplies. It provides precise control of
switching frequency, adjustable soft-start, precise deadtime
control with deadtimes as low as 35ns, and overcurrent
shutdown.

Low start-up and operating currents allow for easy biasing in
both AC/DC and DC/DC applications. This advanced
BiCMOS design features low start-up and operating
currents, adjustable switching frequency up to 1MHz, 1A
FET drivers, and very low propagation delays for a fast
response to overcurrent faults.

Ordering Information

TEMP.

PART NUMBER

ISL6744AU -40 to 105 8 Ld MSOP M8.118
ISL6744AUZ

(Note)
ISL6744AB -40 to 105 8 Ld SOIC M8.15
ISL6744ABZ

(Note)

Add “-T” suffix for tape and reel.
NOTE: Intersil Pb-free plus anneal products employ special Pb-free

material sets; molding compounds/die attach materials and 100%
matte tin plate termination finish, which are RoHS compliant and
compatible with both SnPb and Pb-free soldering operations. Intersil
Pb-free products are MSL classified at Pb-free peak reflow
temperatures that meet or exceed the Pb-free requirements of
IPC/JEDEC J STD-020.

RANGE (°C) PACKAGE

-40 to 105 8 Ld MSOP
(Pb-free)

-40 to 105 8 Ld SOIC
(Pb-free)

PKG.

DWG. #

M8.118

M8.15

Features

• Precision Duty Cycle and Deadtime Control

• 100µA Start-up Current

• Adjustable Delayed Overcurrent Shutdown and Restart

• Adjustable Oscillator Frequency Up to 2MHz

• 1A MOSFET Gate Drivers

• Adjustable Soft-Start

• Internal Over Temperature Protection

• 35ns Control to Output Propagation Delay

• Small Size and Minimal External Component Count

• Input Undervoltage Protection

• Pb-Free Plus Anneal Available (RoHS Compliant)

Applications

• Telecom and Datacom Isolated Power

• DC Transformers

• Bus Converters

Pinout

ISL6744 (SOIC, MSOP)

TOP VIEW

SS

RTD

CS
CT

1

2
3
4

8
7
6
5

VDD
OUTB
OUTA
GND

1

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 1-888-468-3774

| Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.

Copyright © Intersil Americas Inc. 2004-2005. All Rights Reserved

Internal Architecture

www.BDTIC.com/Intersil

V

DD

GND

2

BG

UVLO

+

­INTERNAL

OT SHUTDOWN

130 - 150 C

V

BIAS

5.00 V

V

FL

V

BIAS

Q

T

Q

PWM TOGGLE

DD

OUTA

OUTB

V

BIAS

70uA

ON

V

BIAS

SS CLAMP

R

TD

I

RTD

V

BIAS

160 uA

ON

C

T

RTD

= 55 x I

DCH

I

CS

2.0 V

-

2.8 V

0.8 V

I

DCH

ON

PEAK

+

-

VALLEY

+

+

-

0.6 V

SRQ

Q

RESET
DOMINANT

OC DETECT

CLK

­+

4.0 V

50 µS

RETRIGGERABLE

ONE SHOT

SRQ

Q

PWM LATCH

SET
DOMINANT

+

SS CHARGED

-

SRQ

Q

OC LATCH

Q

Q

V

UV

BIAS

4.65V ↓ 4.80V ↑

+

-

3.9 V

FAULT LATCH

SET DOMINANT

SRQ

FL

Q

-

+

BG

+

-

SS

SS

15 uA

ISL6744

0.27 VSS LOW

V

BIAS

September 22, 2005

C

T

FN9147.8

SS COMPARATOR

+

-

0.8

SS

Typical Application using ISL6744 - 48V Input DC Transformer, 12V @ 8A Output

www.BDTIC.com/Intersil

VIN+

L1

C2

3

C1

TP1

QH

L3

C13

R10

T2

SP1

QR1

T1

C11

QR3

R8

C9

L2

R9

+12V

C8

RTN

VIN-

R1

TP6

QR2

U1

ISL6744

R6

SS
CS

C

T

R

TD

U4

ISL6700

V

DD

HB
HO
HS

QL

C14

CR1

TP4

LO

V

SS

LI

HI

TP5

D2

C15

R11

CR2

R5

GND
OUTB
OUTA
V

DD

R2

CR3

C3

C7

C4

C5

R7

Q5

QR4

C18

C12

C10

TP2

ISL6744

September 22, 2005

D1

FN9147.8

C6

C16

R12

ISL6744

www.BDTIC.com/Intersil

Absolute Maximum Ratings Thermal Information

Supply Voltage, VDD . . . . . . . . . . . . . . . . . . . GND - 0.3V to +20.0V

OUTA, OUTB. . . . . . . . . . . . . . . . . . . . . . . . . . . GND - 0.3V to V

Signal Pins. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GND - 0.3V to 5V

Peak GATE Current. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1A

ESD Classification

Human Body Model (Per MIL-STD-883 Method 3015.7) . . .2000V

Machine Model (Per EIAJ ED-4701 Method C-111). . . . . . . .100V

Charged Device Model (Per EOS/ESD DS5.3, 4/14/93) . . .1000V

DD

Thermal Resistance (Typical, Note 1) θ

8 Lead MSOP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

8 Lead SOIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Maximum Junction Temperature . . . . . . . . . . . . . . . .-55°C to 150°C

Maximum Storage Temperature Range. . . . . . . . . . .-65°C to 150°C

Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . . 300°C

Operating Conditions

Temperature Range

ISL6744AU . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to 105°C

Supply Voltage Range (Typical). . . . . . . . . . . . . . . . . . . . 9-16 VDC

CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.

NOTES:

is measured with the component mounted on a high effective thermal conductivity test board in free air. See Tech Brief TB379 for details.

1. θ

JA

2. All voltages are to be measured with respect to GND, unless otherwise specified.

(°C/W)

JA

Electrical Specifications Recommended operating conditions unless otherwise noted. Refer to Block Diagram and Typical Application

schematic. 9V < V

= 25°C

T

A

PARAMETER TEST CONDITIONS MIN TYP MAX UNITS

SUPPLY VOLTAGE

Start-Up Current, I
Operating Current, I

UVLO START Threshold 5.9 6.3 6.6 V
UVLO STOP Threshold 5.3 5.7 6.3 V
Hysteresis -0.6- V

CURRENT SENSE

Current Limit Threshold 0.55 0.6 0.65 V
CS to OUT Delay (Note 4) - 35 - ns
CS Sink Current 810-mA
Input Bias Current -1 - 1 μA

PULSE WIDTH MODULATOR

Minimum Duty Cycle V
Maximum Duty Cycle C

to SS Comparator Input Gain (Note 4) - 1 - V/V

C

T

SS to SS Comparator Input Gain (Note 4) - 0.8 - V/V

DD

DD

< 16V, RTD = 51.1kΩ, CT = 470pF, TA = -40°C to 105°C (Note 4), Typical values are at

D

VDD < START Threshold - - 175 μA
R

, C

LOAD

C

OUTA,B

< CT Offset - - 0 %

ERROR

= 470pF, RTD = 51.1kΩ -94-%

T

= 470pF, RTD = 1.1kΩ (Note 4) - 99 - %

C

T

= 0 - 2.89 - mA

OUTA,B

= 1nF - 5 8.5 mA

4

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

Electrical Specifications Recommended operating conditions unless otherwise noted. Refer to Block Diagram and Typical Application

schematic. 9V < V
T

= 25°C (Continued)

A

PARAMETER TEST CONDITIONS MIN TYP MAX UNITS

OSCILLATOR

Charge Current 143 156 170 μA

Voltage 1.925 2 2.075 V

R

TD

Discharge Current Gain 45 - 65 μA/μA

Valley Voltage 0.75 0.8 0.85 V

C

T

Peak Voltage 2.70 2.80 2.90 V

C

T

SOFT-START

Charging Current 45 - 68 µA

SS Clamp Voltage 3.8 4.0 4.2 V
Overcurrent Shutdown Threshold Voltage (Note 4) - 3.9 - V
Overcurrent Discharge Current 12 15 23 μA
Reset Threshold Voltage (Note 4) 0.25 0.27 0.30 V

OUTPUT

High Level Output Voltage (VOH) V

Low Level Output Voltage (VOL) I
Rise Time C
Fall Time C

THERMAL PROTECTION

Thermal Shutdown (Note 4) - 145 - °C
Thermal Shutdown Clear (Note 4) - 130 - °C
Hysteresis, Internal Protection (Note 4) - 15 - °C

NOTES:

3. Specifications at -40°C are guaranteed by design, not production tested.

4. Guaranteed by design, not 100% tested in production.

< 16V, RTD = 51.1kΩ, CT = 470pF, TA = -40°C to 105°C (Note 4), Typical values are at

D

- V

DD

I

OUT

= 100mA - 0.5 1.0 V

OUT

GATE
GATE

or V

OUTA

= -100mA

= 1nF, VDD = 12V - 17 60 ns
= 1nF, VDD = 12V - 20 60 ns

OUTB

,

-0.52.0V

5

FN9147.8

September 22, 2005

Typical Performance Curves

www.BDTIC.com/Intersil

65

ISL6744

1-10

4

60

55

50

45

CT DISCHARGE CURRENT GAIN

40

0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09 0.1
RTD CURRENT (mA)

3

1-10

DEADTIME (ns)

100

10

CT =

1000pF

680pF
470pF

CT = 270pF

CT = 100pF

10 20 30 40 50 60 70 80 90 100

RTD (kΩ)

FIGURE 1. OSCILLATOR CT DISCHARGE CURRENT GAIN FIGURE 2. DEADTIME vs CAPACITANCE

600

500

400

300

200

100

OSCILLATOR FREQUENCY (kHz)

0
100 200 300 400 500 600 700 800 900 1000

CT (pF)

FIGURE 3. CAPACIT ANCE vs OSCILLA TOR FREQUENCY

1.03

1.02

1.01

1.00

0.99

0.98

0.97

0.96

NORMALIZED CHARGING CURRENT

0.95

-40 -25 -10 5 35 50 65 80 95 110

20

TEMPERATURE (°C)

FIGURE 4. CHARGE CURRENT vs TEMPERATURE

(RTD = 49.9kΩ)

1.07

1.06

1.05

1.04

1.03

1.02

1.01

1.00

NORMALIZED VOLTAGE

0.99

0.98
0 102030 5060708090100

40

RTD (kΩ)

FIGURE 5. TIMING CAPACITOR VOLTAGE vs RTD

6

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

Pin Descriptions

VDD - VDD is the power connection for the IC. To optimize
noise immunity, bypass V
capacitor as close to the V

The total supply current, I
applied to outputs OUTA and OUTB. Total I
sum of the quiescent current and the average output current.
Knowing the operating frequency, Fsw, and the output
loading capacitance charge, Q, per output, the average
output current can be calculated from:

I

R

2QFsw••=

OUT

- This is the oscillator timing capacitor discharge current

TD

control pin. A resistor is connected between this pin and
GND. The current flowing through the resistor determines
the magnitude of the discharge current. The discharge
current is nominally 55x this current. The PWM deadtime is
determined by the timing capacitor discharge duration.

C

- The oscillator timing capacitor is connected between

T

this pin and GND.
CS - This is the input to the overcurrent protection comparator.

The overcurrent comparator threshold is set at 0.600V nominal.
The CS pin is shorted to GND at the end of each switching
cycle. Depending on the current sensing source impedance, a
series input resistor may be required due to the delay between
the internal clock and the external power switch.

Exceeding the overcurrent threshold will start a delayed
shutdown sequence. Once an overcurrent condition is
detected, the soft-start charge current source is disabled.
The soft-start capacitor begins discharging through a 15µA
current source, and if it discharges to less than 3.9V
(Sustained Overcurrent Threshold), a shutdown condition
occurs and the OUTA and OUTB outputs are forced low.
When the soft-start voltage reaches 0.27V (Reset
Threshold) a soft-start cycle begins.

If the overcurrent condition ceases, and then an additional
50µs period elapses before the shutdown threshold is
reached, no shutdown occurs. The SS charging current is
re-enabled and the soft-start voltage is allowed to recover.

GND - Reference and power ground for all functions on this
device. Due to high peak currents and high frequency
operation, a low impedance layout is necessary. Ground
planes and short traces are highly recommended.

OUTA and OUTB - Alternate half cycle output stages. Each
output is capable of 1A peak currents for driving power
MOSFETs or MOSFET drivers. Each output pro vi d es very
low impedance to overshoot and undershoot.

SS - Connect the soft-start timing capacitor between this pin
and GND to control the duration of soft-start. The value of the
capacitor determines the rate of increase of the duty cycle
during start-up, controls the overcurrent shutdown del ay, and
the overcurrent and short circuit hiccup restart period.

to GND with a ceramic

DD

and GND pins as possible.

DD

, will be dependent on the load

DD

current is the

DD

(EQ. 1)

Functional Description

Features

The ISL6744 PWM is an excellent choice for low cost bridge
topologies for applications requiring accurate frequency and
deadtime control. Among its many features are 1A FET
drivers, adjustable soft-start, overcurrent protection and
internal thermal protection, allowing a highly flexible design
with minimal external components.

Oscillator

The ISL6744 has an oscillator with a frequency range to
2MHz, programmable using a resistor R

The switching period may be considered to be the sum of
the timing capacitor charge and discharge durations. The
charge duration is determined by C
source (assumed to be 160

μA in the formula). The discharge

duration is determined by R

1.254×10 CT•≈ s

T

C

---------------------------------------------------------------------------- -

T

D

CTDisch eCurrentGainarg

T

== s(EQ. 4)

OSCTCTD

1

1

--------------- -

+

F

OSC

T

and CT.

TD

• CT•≈ s

R

TD

where TC and TD are the approximate charge and discharge
times, respectively, T
period, and F

OSC

is the oscillator free running

OSC

is the oscillator frequency. One output
switching cycle requires two oscillator cycles. The actual
times will be slightly longer than calculated due to internal
propagation delays of approximately 5ns/transition. This
delay adds directly to the switching duration, and also
causes overshoot of the timing capacitor peak and valley
voltage thresholds, effectively increasing the peak-to-peak
voltage on the timing capacitor. Additionally, if very low
charge and discharge currents are used, there will be an
increased error due to the input impedance at the C

The above formulae help with the estimation of the
frequency. Practically, effects like stray capacitances that
affect the overall C

capacitance, variation in R

T

and charge current over temperature, etc. exist, and are best
evaluated in-circuit. Equation 2 follows from the basic
capacitor current equation, . In this case, with
variation in dV with R

(Figure 5), and in charge current

TD

×=

iC

dV

(Figure 4), results from Equation 2 would differ from the
calculated frequency. The typical performance curves may
be used as a tool along with the above equations as a more
accurate tool to estimate the operating frequency more
accurately.

The maximum duty cycle, D, and deadtime, DT, can be
calculated from:

DTCT

DT 1 D–()T

⁄= (EQ. 5)

OSC

⋅= s(EQ. 6)

OSC

and capacitor CT.

TD

and the internal current

(EQ. 2)

(EQ. 3)

pin.

T

voltage

TD

td

7

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

Soft-Start Operation

The ISL6744 features a soft-start using an external capacitor
in conjunction with an internal current source. Soft-start
reduces stresses and surge currents during start-up.

The oscillator capacitor signal, C
soft-start voltage, SS, in the SS comparator which drives the
PWM latch. While the SS voltage is less than 3.5V, duty
cycle is limited. The output pulse width increases as the
soft-start capacitor voltage increases up to 3.5V. This has
the effect of increasing the duty cycle from zero to the
maximum pulse width during the soft-start period. When the
soft-start voltage exceeds 3.5V, soft-start is completed.
Soft-start occurs during start-up and after recovery from an
overcurrent shutdown. The soft-start voltage is clamped
to 4V .

, is compared to the

T

Gate Drive

The ISL6744 is capable of sourcing and sinking 1A peak
current, and may also be used in conjunction with a
MOSFET driver such as the ISL6700 for level shifting. To
limit the peak current through the IC, an external resistor
may be placed between the totem-pole output of the IC
(OUTA or OUTB pin) and the gate of the MOSFET. This
small series resistor also damps any oscillations caused by
the resonant tank of the parasitic inductances in the traces of
the board and the FET’s input capacitance.

Overcurrent Operation

Overcurrent delayed shutdown is enabled once the soft-start
cycle is complete. If an overcurrent condition is detected, the
soft-start charging current source is disabled and the soft­start capacitor is allowed to discharge through a 15µA
source. At the same time a 50µs retriggerable one-shot timer
is activated. It remains active for 50µs after the overcurrent
condition ceases. If the soft-start capacitor discharges to

3.9V, the output is disabled. This state continues until the
soft-start voltage reaches 270mV, at which time a new soft­start cycle is initiated. If the overcurrent condition stops at
least 50µs prior to the soft-start voltage reaching 3.9V, the
soft-start charging currents revert to normal operation and
the soft-start voltage is allowed to recover.

Thermal Protection

An internal temperature sensor protects the device should
the junction temperature exceed 145°C. There is
approximately 15°C of hysteresis.

Ground Plane Requirements

Careful layout is essential for satisfactory operation of the
device. A good ground plane must be employed. V
be bypassed directly to GND with good high frequency
capacitance.

DD

should

Typical Application

The Typical Application Schematic features the ISL6744 in
an unregulated half-bridge DC/DC converter configuration,
often referred to as a DC Transformer or Bus Converter.

The input voltage is 48V ±10% DC. The output is a nominal
12V when the input voltage is at 48V. Since this is an
unregulated topology, the output voltage will vary
proportionately with input voltage. The load regulation is a
function of resistance between the source and the converter
output. The output is rated at 8A.

Circuit Elements

The converter design is comprised of the following functional
blocks:

Input Filtering: L1, C1, R1
Half-Bridge Capacitors: C2, C3
Isolation Transformer: T1
Primary Snubber: C13, R10
Start Bias Regulator: CR3, R2, R7, C6, Q5, D1
Supply Bypass Components: C15, C4
Main MOSFET Power Switch: QH, QL
Current Sense Network: T2, CR1, CR2, R5, R6, R11, C10,

C14
Control Circuit: U1, C18, C16, D2
Output Rectification and Filtering: QR1, QR2, QR3, QR4,

L2, C9, C8
Secondary Snubber: R8, R9, C11, C12
FET Driver: U4
Bootstrap components for driver: CR4, C5
ZVS Resonant Delay (Optional): L3, C7

Design Specifications

The following design requirements were selected for
evaluation purposes:

Switching Frequency, Fsw: 235kHz
V

: 48 ± 10% V

IN

V

: 12V (nominal)

OUT

I

: 8A (steady state)

OUT

P

: 100W

OUT

Efficiency: 95%
Ripple: 1%

8

FN9147.8

September 22, 2005

n

www.BDTIC.com/Intersil

SR

n

n

P

FIGURE 6. TRANSFORMER SCHEMATIC

S

n

S

n

SR

ISL6744

Since the converter is operating open loop at nearly 100%
duty cycle, the turns ratio, N, is simply the ratio of the input
voltage to the output voltage divided by 2.

N

V

IN

------------------------ -

V

OUT

48

---------------

2•

12 2•

2===

(EQ. 7)

The factor of 2 in the denominator is due to the half-bridge
topology. Only half of the input voltage is applied to the
primary of the transformer.

Transformer Design

The design of a transformer for a half-bridge application is a
straightforward affair, although iterative. It is a process of
many compromises, and even experienced designers will
produce different designs when presented with identical
requirements. The iterative design process is not presented
here for clarity.

The abbreviated design process follows:

• Select a core geometry suitable for the application.
Constraints of height, footprint, mounting preference, and
operating environment will affect the choice.

• Determine the turns ratio.

• Select suitable core material(s).

• Select maximum flux density desired for operation.

• Select core size. Core size will be dictated by the
capability of the core structure to store the required
energy, the number of turns that have to be wound, and
the wire gauge needed. Often the window area (the space
used for the windings) and power loss determine the final
core size.

• Determine maximum desired flux density. Depending on
the frequency of operation, the core material selected, and
the operating environment, the allowed flux density must
be determined. The decision of what flux density to allow
is often difficult to determine initially. Usually the highest
flux density that produces an acceptable design is used,
but often the winding geometry dictates a larger core than
is indicated based on flux density alone.

• Determine the number of primary turns.

• Select the wire gauge for each winding.

• Determine winding order and insulation requirements.

• Verify the design.

For this application we have selected a planar structure to
achieve a low profile design. A PQ style core was selected
because of its round center leg cross section, but there are
many suitable core styles available.

A PC44HPQ20/6 “E-Core” plus a PC44PQ20/3 “I-Core” from
TDK were selected for the transformer core. The ferrite
material is PC44.

The core parameter of concern for flux density is the
effective core cross-sectional area, Ae. For the PQ core
pieces selected:

Ae = 0.62cm

2

or 6.2e -5m

2

Using Faraday’s Law, V = N dΦ/dt, the number of primary
turns can be determined once the maximum flux density is
set. An acceptable Bmax is ultimately determined by the
allowable power dissipation in the ferrite material and is
influenced by the lossiness of the core, core geometry,
operating ambient temperature, and air flow. The TDK
datasheet for PC44 material indicates a core loss factor of
~400mW/cm

3

with a ± 2000 gauss 100kHz sinusoidal
excitation. The application uses a 235kHz square wave
excitation, so no direct comparison between the application
and the data can be made. Interpolation of the data is
required. The core volume is approximately 1.6cm

3

, so the

estimated core loss is

f

P

loss

mW

-----------

cm

3

cm

3

act

---------------

•• 0.4 1.6
f

meas

200kHz

---------------------

••=≈ 1.28= W
100kHz

(EQ. 8)

1.28W of dissipation is significant for a core of this size.
Reducing the flux density to 1200 gauss will reduce the
dissipation by about the same percentage, or 40%.
Ultimately, evaluation of the transformer’s performance in
the application will determine what is acceptable.

From Faraday’s Law and using 1200 gauss peak flux density
(ΔB = 2400 gauss or 0.24 tesla)

N

•

V

INTON

----------------------------- -

ΔB••

2A

e

53210

-----------------------------------------------------

26.210

6–

••

5–

0.24•••

3.56== =turns

(EQ. 9)

Rounding up yields 4 turns for the primary winding. The peak
flux density using 4 turns is ~1100 gauss. From EQ. 7, the
number of secondary turns is 2.

The volts/turn for this design ranges from 5.4V at V
to 6.6V at V

IN

(SR) windings may be set at 1 turn each with proper FET
selection. Selecting 2 turns for the synchronous rectifier

9

= 43V

IN

= 53V. Therefore, the synchronou s rect if ie r

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

windings would also be acceptable, but the gate drive losses
would increase.

The next step is to determine the equivalent wire gauge for
the planar structure. Since each secondary winding
conducts for only 50% of the period, the RMS current is

I

RMSIOUT

D• 10 0.5• 7.07===A

(EQ. 10)

where D is the duty cycle. Since an FR-4 PWB planar
winding structure was selected, the width of the copper
traces is limited by the window area width, and the number
of layers is limited by the window area height. The PQ core
selected has a usable window area width of 0.165 inches.
Allowing one turn per layer and 0.020 inches clearance at
the edges allows a maximum trace width of 0.125 inches.
Using 100 circular mils(c.m.)/A as a guideline for current
density, and from EQ. 10, 707c.m. are required for each of
the secondary windings (a circular mil is the area of a circle

0.001 inches in diameter). Converting c.m. to square mils
yields 555mils

2

(0.785 sq. mils/c.m.). Dividing by the trace
width results in a copper thickness of 4.44mils (0.112mm).
Using 1.3mils/oz. of copper requires a copper weight of

3.4oz. For reasons of cost, 3oz. copper was selected.
One layer of each secondary winding also contains the

synchronous rectifier winding. For this layer the secondary
trace width is reduced by 0.025 inches to 0.100 inches(0.015
inches for the SR winding trace width and 0.010 inches
spacing between the SR winding and the secondary
winding).

The primary windings have an RMS current of approximately
5 A (I

x NS/NP at ~ 100% duty cycle). The primary is

OUT

configured as 2 layers, 2 turns per layer to minimize the
winding stack height. Allowing 0.020 inches edge clearance
and 0.010 inches between turns yields a trace width of

0.0575 inches. Ignoring the terminal and lead-in resistance,
and using EQ. 11, the inner trace has a resistance of

4.25mΩ, and the outer trace has a resistance of 5.52mΩ.
The resistance of the primary then is 19.5mΩ at 20°C. The
total DC power loss for the primary at 20°C is 489mW.

Improved efficiency and thermal performance could be
achieved by selecting heavier copper weight for the
windings. Evaluation in the application will determine its
need.

The order and geometry of the windings affects the AC
resistance, winding capacitance, and leakage inductance of
the finished transformer. To mitigate these effects,
interleaving the windings is necessary. The primary winding
is sandwiched between the two secondary windings. The
winding layout appears below.

The choice of copper weight may be validated by calculating
the DC copper losses of the secondary winding. Ignoring the
terminal and lead-in resistance, the resistance of each layer
of the secondary may be approximated using EQ. 11.

2πρ

----------------------- -

R

= Ω

r

⎛⎞

2

---- -

ln•

t

⎜⎟

r

⎝⎠

1

(EQ. 11)

where

R = Winding resistance
ρ = Resistivity of copper = 669e-9Ω-inches at 20°C
t = Thickness of the copper (3 oz.) = 3.9e-3 inches
r

= Outside radius of the copper trace = 0.324 or 0.299

2

inches
r1 = Inside radius of the copper trace = 0.199 inches

The winding without the SR winding on the same layer has a
DC resistance of 2.21mΩ. The winding that shares the layer
with the SR winding has a DC resistance of 2.65mΩ. With
the secondary configured as a 4 turn center tapped winding
(2 turns each side of the tap), the total DC power loss for the
secondary at 20°C is 486mW.

FIGURE 7A. TOP LAYER: 1 TURN SECONDARY AND SR

WINDINGS

FIGURE 7B. INT. LAYER 1: 1 TURN SECONDARY WINDING

10

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

∅0.689

∅0.358

0.807

0.639

0.403

0.169

FIGURE 7C. INT. LAYER 2: 2 TURNS PRIMARY WINDING

FIGURE 7D. INT. LAYER 3: 2 TURNS PRIMARY WINDING

FIGURE 7E. INT. LAYER 4: 1 TURN SECONDARY WINDING

0.000

1.0540.7740.4790.1840.000

FIGURE 7G. PWB DIMENSIONS

MOSFET Selection

The criteria for selection of the primary side half-bridge FETs
and the secondary side synchronous rectifier FET s is largely
based on the current and voltage rating of the device.
However, the FET drain-source capacitance and gate
charge cannot be ignored.

The zero voltage switch (ZVS) transition timing is dependent
on the transformer’s leakage inductance and the
capacitance at the node between the upper FET source and
the lower FET drain. The node capacitance is comprised of
the drain-source capacitance of the FETs and the
transformer parasitic capacitance. The leakage inductance
and capacitance form an LC resonant tank circuit which
determines the duration of the transition. The amount of
energy stored in the LC tank circuit determines the transition
voltage amplitude. If the leakage inductance energy is too
low, ZVS operation is not possible and near or partial ZVS
operation occurs. As the leakage energy increases, the
voltage amplitude increases until it is clamped by the FET
body diode to ground or V
conducts. When the leakage energy exceeds the minimum
required for ZVS operation, the voltage is clamped until the
energy is transferred. This behavior increases the time
window for ZVS operation. This behavior is not without
consequences, however. The transition time and the period
of time during which the voltage is clamped reduces the
effective duty cycle.

, depending on which FET

IN

The gate charge affects the switching speed of the FETs.
Higher gate charge translates into higher drive requirements
and/or slower switching speeds. The energy required to
drive the gates is dissipated as heat.

The maximum input voltage, V
determines the voltage rating required. With a maximum
input voltage of 53V for this application, and if we allow a
10% adder for transients, a voltage rating of 60V or higher

FIGURE 7F. BOTTOM LAYER: 1 TURN SECONDARY AND SR

WINDINGS

11

will suffice.

, plus transient voltage,

IN

September 22, 2005

FN9147.8

ISL6744

www.BDTIC.com/Intersil

The RMS current through each primary side FET can be
determined from EQ. 10, substituting 5A of primary current
for I

(assuming 100% duty cycle). The result is 3.5A

OUT

RMS. Fairchild FDS3672 FET s, rated at 100V and 7.5A
(r

= 22mΩ), were selected for the half-bridge

DS(ON)

switches.
The synchronous rectifier FETs must withstand

approximately one half of the input voltage assuming no
switching transients are present. This suggests that a device
capable of withstanding at least 30V is required. Empirical
testing in the circuit revealed switching transients of 20V
were present across the device indicating a rati ng of at least
60V is required.

The RMS current rating of 7.07A for each SR FET requires a
low r

to minimize conduction losses, which is difficult to

DS(ON)

find in a 60V device. It was decided to use two devices in
parallel to simplify the thermal design. T wo Fai rchild FDS5670
devices are used in parallel for a total of four SR FETs. The
FDS5670 is rated at 60V and 10A (r

DS(ON)

= 14mΩ).

Oscillator Component Selection

The desired operating frequency of 235kHz for the converter
was established in the Design Criteria section. The
oscillator frequency operates at twice the frequency of the
converter because two clock cycles are required for a
complete converter period.

During each oscillator cycle the timing capacitor , C
charged and discharged. Determining the required
discharge time to achieve zero voltage switching (ZVS) is
the critical design goal in selecting the timing components.
The discharge time sets the deadtime between the two
outputs, and is the same as ZVS transition time. Once the
discharge time is determined, the remainder of the period
becomes the charge time.

The ZVS transition duration is determined by the
transformer’s primary leakage inductance, L
Coss, by the transformer’s parasitic winding capacitance,
and by any other parasitic elements on the node. The
parameters may be determined by measurement,
calculation, estimate, or by some combination of these
methods.

π Llk2C

------------------------------------------------------------------- -

t

≈ s

zvs

+()•

ossCxfrmr

2

Device output capacitance, Coss, is non-linear with applied
voltage. To find the equivalent discrete capacitance, Cfet, a
charge model is used. Using a known current source, the
time required to charge the MOSFET drain to the de si re d
operating voltage is determined and the equivalent
capacitance is calculated.

Ichg t•

------------------- -

Cfet

= F

V

, must be

T

, by the FET

lk

(EQ. 12)

(EQ. 13)

Once the estimated transition time is determined, it must be
verified directly in the application. The transformer leakage
inductance was measured at 125nH and the combined
capacitance was estimated at 2000pF. Calculations indicate
a transition period of ~25ns. Verification of the performance
yielded a value of T

closer to 45ns.

D

The remainder of the switching half-period is the charge
time, T

where F

, and can be found from

C

1

--------------------

T

C

–

•

2F

Sw

is the converter switching frequency.

Sw

T

D

1

----------------------------------

••

2 235 10

9–

•– 2.08== =μs

45 10

3

(EQ. 14)

Using Figure 3, the capacitor value appropriate to the
desired oscillator operating frequency of 470kHz can be
selected. A C

value of 100pF, 150pF, or 220pF is

T

appropriate for this frequency. A value of 150pF was
selected.

To obtain the proper value for R

, EQ. 3 is used. Since

TD

there is a 10ns propagation delay in the oscillator circuit, it
must be included in the calculation. The value of R

TD

selected is 10kΩ.

Output Filter Design

The output filter inductor and capacitor selection is simple
and straightforward. Under steady state operating conditions
the voltage across the inductor is very small due to the large
duty cycle. Voltage is applied across the inductor only during
the switch transition time, about 45ns in this application.
Ignoring the voltage drop across the SR FETs, the voltage
across the inductor during the on time with V

V

–

LVSVOUT

V

INNS

----------------------------------------------- -

2N

1D–()••

P

250≈== mV

where

is the inductor voltage

V

L

VS is the voltage across the secondary winding

V

is the output voltage

OUT

If we allow a current ramp, ΔI, of 5% of the rated output
current, the minimum inductance required is

•

V

------------------------ -

≥

L

LTON

ΔI

0.25 2.08•

---------------------------- -

0.5

1.04==μH

An inductor value of 1.5μH, rated for 18A was selected.
With a maximum input voltage of 53V, the maximum output

voltage is about 13V . The closest higher voltage rated
capacitor is 16V . Under steady state operating conditions the
ripple current in the capacitor is small, so it would seem
appropriate to have a low ripple current rated capacitor.
However, a high rated ripple current capacitor was selected

= 48V is

IN

(EQ. 15)

(EQ. 16)

12

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

based on the nature of the intended load, multiple buck
regulators. To minimize the output impedance of the filter, a
SANYO OSCON 16SH150M capacitor in parallel with a
22μF ceramic capacitor were selected.

Current Limit Threshold

The current limit threshold is fixed at 0.6V nominal, which is
the reference to the overcurrent protection comparator. The
current level that corresponds to the overcurrent threshold
must be chosen to allow for the dynamic behavior of an open
loop converter. In particular, the low inductor ripple current
under steady state operation increases significantly as the
duty cycle decreases.

14

13

12

11

10

9

reduction of the average current through the inductor. The
implication is that the converter can not supply the same
output current in current limit that it can supply under steady
state conditions. The peak current limit setpoint must take
this behavior into consideration. A 5.11Ω current sense
resistor was selected for the rectified secondary of current
transformer T2 for the ISL6744Eval 1, corresponding to a
peak current limit setpoint of about 11A.

Performance

The major performance criteria for the converter are
efficiency, and to a lesser extent, load regulation. Efficiency,
load regulation and line regulation performance are
demonstrated in the following Figures.

As expected, the output voltage varies considerably with line
and load when compared to an equivalent converter with a
closed loop feedback. However, for applications where tight
regulation is not required, such as those applications that
use downstream DC/DC converters, this design approach is
viable.

100

95

8

0.9950 0.9960 0.9970 0.9980 0.9990 1.000

V (L1:1)

I (L1)

FIGURE 8. STEADY STATE SECONDARY WINDING

VOLTAGE AND INDUCTOR CURRENT

15

10

5

0.986 0.988 0.990 0.992 0.994 1.000

V (L1:1)
I (L1)

FIGURE 9. SECONDARY WINDING VOLTAGE AND

INDUCTOR CURRENT DURING CURRENT LIMIT
OPERATION

TIME (ms)

0.996 0.998

TIME (ms)

Figures 8 and 9 show the behavior of the inductor ripple
under steady state and overcurrent conditions. In this
example, the peak current limit is set at 11A. The peak
current limit causes the duty cycle to decrease resulting in a

90

85

85

EFFICIENCY (%)

75

70

0 2345678910

1

LOAD CURRENT (A)

FIGURE 10. EFFICIENCY vs LOAD VIN = 48V

12.5

12.25

12

11.75

11.5

OUTPUT VOLTAGE (V)

11.25

11

0 2345678910

1

LOAD CURRENT (A)

FIGURE 11. LOAD REGULATION AT VIN = 48V

13

FN9147.8

September 22, 2005

13.5

www.BDTIC.com/Intersil

13

12.5

12

11.5

OUTPUT VOLTAGE (V)

11

10.5
42 44 45 46 47 48 49 50 51 53

43

INPUT VOLTAGE (V)

ISL6744

52

FIGURE 12. LINE REGULATION AT I

OUT

= 1A

Waveforms

Typical waveforms can be found in the following Figures.
Figure 13 shows the output voltage ripple and noise at a 5A.

FIGURE 13. OUTPUT RIPPLE AND NOISE - 20MHz BW

FIGURE 14. FET DRAIN-SOURCE VOLTAGE

FIGURE 15. FET D-S VOLTAGE NEAR-ZVS TRANSITION

Figures 14 and 15 show the voltage waveforms at the
switching node shared by the upper FET source and the
lower FET drain. In particular, Figure 15 shows near ZVS
operation at 5A of load when the upper FET is turning off
and the lower FET is turning on. ZVS operation occurs
completely, implying that all the energy stored in the node
capacitance has been recovered. Figure 16 shows the
switching transition between outputs, OUTA and OUTB
during steady state operation. The deadtime duration of

46.9ns is clearly shown.
A 2.7V zener is added between the Vdd pins of ISL6700 and

ISL6744, in order to ensure that the PWM turns on only after
the driver has turned on, thereby ensuring the soft-start
function. Figure 17 shows the soft-start operation.

FIGURE 16. OUTA - OUTB TRANSITION

14

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

FIGURE 17. OUTPUT SOFT-START

Component List

REFERENCE

DESIGNATOR VALUE DESCRIPTION

C1 1.0µF Capacitor, 1812, X7R, 100V, 20%

C2, C3 3.3µF Capacitor, 1812, X5R, 50V, 20%

C4 1.0µF Capacitor, 0805, X5R, 16V, 10%
C5 0.1µF Capacitor, 0603, X7R, 16V, 10%

C6, C15 4.7µF Capacitor, 0805, X5R, 10V, 20%

C7 Open Capacitor, 0603, Open or Optional Discrete Stray Capacitance
C8 22µF Capacitor, 1812, X5R, 16V, 20%
C9 150µF Capacitor, Radial, Sanyo 16SH150M

C10, C11, C12,

C13, C14

C16 150pF Capacitor, 0603, COG, 16V, 5%
C18 0.01µF Capacitor, 0603, X7R, 16V, 10%

CR1, CR2 Diode, Schottky, BAT54S, 30V

CR3 Diode, Schottky, BAT54, 30V
CR4 Diode, Schottky, SMA, 100V, 2.1A

D1 Zener, 10V,Zetex BZX84C10ZXCT-ND
D2 Zener, 2.7V, BZX84C2V7

L1 190nH Pulse, P2004T
L2 1.5µH Bitech, HM73-301R5
L3 Short Jumper or Optional Discrete Leakage Inductance

1000pF Capacitor, 0603, X7R, 50V, 10%

P1, P2, P3, P4 Keystone, 1514-2

Q5 NPN Transistor, ON MJD31C

QL, QH FET, Fairchild FDS3672, 100V

15

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

Component List (Continued)

REFERENCE

DESIGNATOR VALUE DESCRIPTION

QR1, QR2, QR3,

QR4

R1 3.3 Resistor, 2512, 1%
R2 3.01K Resistor, 2512, 1%
R5 5.11 Resistor, 0603, 1%
R6 205 Resistor, 0603, 1%
R7 75.0K Resistor, 0805, 1%

R8, R9 20.0 Resistor, 0805, 1%

R10 18 Resistor, 2512, 1%

R11 100 Resistor, 0603, 1%

R12 10.0K Resistor, 0603, 1%

T1 Custom Midcom 31718
T2 Custom Midcom 31719R

TP1, TP2, TP4,

TP5, TP6

SP1 Tektronix Scope Jack, 131-4353-00

5002 Keystone

FET, Fairchild FDS5670, 60V

U1 Intersil ISL6744AU, MSOP8
U4 Intersil ISL6700IB, SOIC

16

FN9147.8

September 22, 2005

ISL6744

www.BDTIC.com/Intersil

Mini Small Outline Plastic Packages (MSOP)

N

EE1

INDEX

AREA

AA1A2

TOP VIEW

-H-

SIDE VIEW

12

b

e

D

NOTES:

1. These package dimensions are within allowable dimensions of
JEDEC MO-187BA.

2. Dimensioning and tolerancing per ANSI Y14.5M-1994.

3. Dimension “D” does not include mold flash, protrusions or gate
burrs and are measured at Datum Plane. Mold flash, protrusion
and gate burrs shall not exceed 0.15mm (0.006 inch) per side.

4. Dimension “E1” does not include interlead flash or protrusions
and are measured at Datum Plane. Interlead flash and
protrusions shall not exceed 0.15mm (0.006 inch) per side.

5. Formed leads shall be planar with respect to one another within

0.10mm (0.004) at seating Plane.

6. “L” is the length of terminal for soldering to a substrate.

7. “N” is the number of terminal positions.

8. Terminal numbers are shown for reference only.

9. Dimension “b” does not include dambar protrusion. Allowable
dambar protrusion shall be 0.08mm (0.003 inch) total in excess
of “b” dimension at maximum material condition. Minimum space
between protrusion and adjacent lead is 0.07mm (0.0027 inch).

- H -

-A -

.

10. Datums and to be determined at Datum plane

11. Controlling dimension: MILLIMETER. Converted inch dimen­sions are for reference only.

-B-

0.20 (0.008) A

GAUGE

PLANE

SEATING

PLANE

0.10 (0.004) C

-A-

0.20 (0.008) C

- B -

0.25

(0.010)

-C-

SEATING
PLANE

a

0.20 (0.008) C

- H -

B

4X θ

C

D

4X θ

L1

C

C

L

E

1

END VIEW

R1

R

L

-B-

M8.118 (JEDEC MO-187AA)

8 LEAD MINI SMALL OUTLINE PLASTIC PACKAGE

INCHES MILLIMETERS

SYMBOL

A 0.037 0.043 0.94 1.10 -

A1 0.002 0.006 0.05 0.15 -

A2 0.030 0.037 0.75 0.95 -

b 0.010 0.014 0.25 0.36 9

c 0.004 0.008 0.09 0.20 -

D 0.116 0.120 2.95 3.05 3

E1 0.116 0.120 2.95 3.05 4

e 0.026 BSC 0.65 BSC -

E 0.187 0.199 4.75 5.05 -

L 0.016 0.028 0.40 0.70 6

L1 0.037 REF 0.95 REF -

N8 87

R 0.003 - 0.07 - -

R1 0.003 - 0.07 - -

05

α

o

o

0

15

o

o

6

o

5

o

0

15

o

o

6

Rev. 2 01/03

NOTESMIN MAX MIN MAX

-

-

17

FN9147.8

September 22, 2005

Small Outline Plastic Packages (SOIC)

www.BDTIC.com/Intersil

ISL6744

N

INDEX
AREA

123

-A-

E

-B-

SEATING PLANE

D

A

-C-

0.25(0.010) BM M

H

L

h x 45°

α

e

B

0.25(0.010) C AM BS

NOTES:

1. Symbols are defined in the “MO Series Symbol List” in Section 2.2 of
Publication Number 95.

2. Dimensioning and tolerancing per ANSI Y14.5M-1982.

3. Dimension “D” does not include mold flash, protrusions or gate burrs.
Mold flash, protrusion and gate burrs shall not exceed 0.15mm (0.006
inch) per side.

4. Dimension “E” does not include interlead flash or protrusions. Inter­lead flash and protrusions shall not exceed 0.25mm (0.010 inch) per
side.

5. The chamfer on the body is optional. If it is not present, a visual index
feature must be located within the crosshatched area.

6. “L” is the length of terminal for soldering to a substrate.

7. “N” is the number of terminal positions.

8. Terminal numbers are shown for reference only.

9. The lead width “B”, as measured 0.36mm (0.014 inch) or greater
above the seating plane, shall not exceed a maximum value of

0.61mm (0.024 inch).

10. Controlling dimension: MILLIMETER. Converted inch dimensions
are not necessarily exact.

M

A1

C

0.10(0.004)

M8.15 (JEDEC MS-012-AA ISSUE C)

8 LEAD NARROW BODY SMALL OUTLINE PLASTIC PACKAGE

INCHES MILLIMETERS

SYMBOL

A 0.0532 0.0688 1.35 1.75 -

A1 0.0040 0.0098 0.10 0.25 -

B 0.013 0.020 0.33 0.51 9

C 0.0075 0.0098 0.19 0.25 -

D 0.1890 0.1968 4.80 5.00 3

E 0.1497 0.1574 3.80 4.00 4

e 0.050 BSC 1.27 BSC -

H 0.2284 0.2440 5.80 6.20 -

h 0.0099 0.0196 0.25 0.50 5

L 0.016 0.050 0.40 1.27 6

N8 87

α

0° 8° 0° 8° -

NOTESMIN MAX MIN MAX

Rev. 1 6/05

All Intersil U.S. products are manufactured, assembled and tested utilizing ISO9000 quality systems.

Intersil Corporation’s quality certifications can be viewed at www.intersil.com/design/quality

Intersil products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design, software and/or specifications at any time without
notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be accurate and
reliable. However, no responsibility is assumed by Intersil or its subsidiaries for its use; nor for any infringements of patents or other rights of third parties which may result
from its use. No license is granted by implic atio n or other wise u nde r any p a tent or patent rights of Intersil or it s sub sidi ari es.

For information regarding Intersil Corporation and its products, see www.intersil.com

18

FN9147.8

September 22, 2005
