intersil ISL6422 DATA SHEET

®

www.BDTIC.com/Intersil

ISL6422

Data Sheet

Dual Output LNB Supply and Control
Voltage Regulator with I2C Interface for
Advanced Satellite Set-Top Box Designs

The ISL6422 is a highly integrated voltage regulator and
interface IC, specifically designed for supplying power and
control signals from advanced satellite set-top box (STB)
modules to the low noise blocks (LNBs) of two antenna
ports. The device is consists of two independent
current-mode boost PWMs and two low-noise linear
regulators along with the circuitry required for 22kHz tone
generation, modulation and I
makes the total LNB supply design simple, efficient and
compact with low external component count.

Two independent current-mode boost converters provide the
linear regulators with input voltages that are set to the final
output voltages, plus typically 0.8V to insure minimum power
dissipation across each linear regulator. This maintains
constant voltage drops across each linear pass element
while permitting adequate voltage range for tone injection.

The final regulated output voltages are available at two
output terminals to support simultaneous operation of two
antenna ports for dual tuners. The outputs for each PWM
can be controlled in two ways:

• Full control from I
and VBOT12 bits, or

• Set the I
higher range (18V/19V) with the SELVTOP1 or
SELVTOP2 pin.

All the functions on this IC are controlled via the I
writing 8-bit words onto the System Registers (SR). The
same register can be read back, and 4-bits per output will
report the diagnostic status. Sepa ra t e en a b le c om m a n d s s en t
on the I
each PWM and linear combination, disabling the output into
shut d ow n m od e . Each output channel is capable of providing
750mA of continuous current. The overcurrent limit can be
digitally programmed.

The External modulation input EXTM1, EXTM2 can accept a
modulated Diseqc command and transfer it symmetrically to
the output. Alternatively, the EXTM1 or EXTM2 pin can be
used to modulate the continuous internal tone.

The FLT
an over temperature, overcurrent or backwards overcurrent
fault conditions is detected by the LNB controller or when
both channels are disabled by the I
nature of the fault can be read of the I

2

C to the lower range (13V/14V) and switch to the

2

C bus provide independent standby mode control for

pin serves as an interrupt for the processor when

2

C using the VTOP1, VTOP2, VBOT1,

2

C device interface. The device

2

C bus by

2

C EN bits set low. The

2

C registers.

August 10, 2007

FN9190.2

Features

• Single Chip Power Solution

- True Dual Operation for 2-Tuner/2-Dish Applications

- Both Outputs May be Enabled Simultaneously at
Maximum Power

- Integrated DC/DC Converter and I

• Switch-Mode Power Converter for Lowest Dissipation

- Boost PWMs with >92% Efficiency

- Selectable 13.3V or 18.3V Outputs

- Digital Cable Length Compensation (1V)

2

C and Pin controllable output

-I

• Output Back Bias Capability of 28V

2

C Compatible Interface for Remote Device Control

•I

• Four level Slave Address 0001 00XX

• 2.5V, 3.3V, 5V Logic Compatible

• External Pins to Toggle Between V and H Polarization.

• Supports DiSEqC 2.0 Protocol

• Built-In Tone Oscillator Factory Trimmed to 22kHz

- Facilitates DiSEqC (EUTELSAT) Encoding

- External Modulation Input

• Internal Over-Temperature Protection and Diagnostics

• Internal OV, UV, Overload and Over-Temperature Flags
(Visible on I

Signal

•FLT

• LNB Short-Circuit Protection and Diagnostics

• QFN, EPTSSOP Packages

• Pb-Free Plus Anneal Available (RoHS Compliant)

2

C)

2

C Interface

Applications

• LNB Power Supply and Control for Satellite Set-Top Box

Ordering Information

PART NUMBER

(Note)

ISL6422ERZ* ISL6422 ERZ -20 to +85 40 Ld 6x6 QFN L40.6x6
ISL6422EVEZ* ISL6422 EVEZ -20 to+ 85 38 Ld EPTSSOP M38.173B

*Add “-T” suffix for tape and reel.
NOTE: Intersil Pb-free plus anneal products employ special Pb-free

material sets; molding compounds/die attach materials and 100% matte tin
plate termination finish, which are RoHS compliant and compatible with
both SnPb and Pb-free soldering operations. Intersil Pb-free products are
MSL classified at Pb-free peak reflow temperatures that meet or exceed
the Pb-free requirements of IPC/JEDEC J STD-020.

PART

MARKING

TEMP.

RANGE

(°C)

PACKAGE

(Pb-free)

PKG.

DWG . #

1

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 1-888-468-3774

| Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.

Copyright Intersil Americas Inc. 2006, 2007. All Rights Reserved

Pinouts

www.BDTIC.com/Intersil

EXTM2

SGND

NC

FLT

SDA

SCL

ADDR0

ADDR1

EXTM1

BYP

ISL6422

(40 LD QFN)

TOP VIEW

SELVTOP2

TXT2

CS2

NC

NC

VSW2

ISL6422ERZ

CS1

VSW1

TXT1

SELVTOP1

GATE2

PGND2

39 38 37 36 35 34 33 32 31

40

1

2

3

4

5

6

7

8

9

10

11 12 13 14 15 16 17 18 19 20

GATE1

PGND1

TCAP1 TCAP2

NC

AGND

VOUT2

VOUT1

ISL6422

VOUT2

30

29

TDIN2

28

TDOUT2

27

CPVOUT

26

CPSWOUT

CPSWIN

25

24

VCC

23

TDOUT1

TDIN1

22

VOUT1

21

CS2
VSW2
VSW2

GATE2

PGND2

EXTM2

SGND

FLT

SDA

SCL

ADDR0
ADDR1

EXTM1

BYP

PGND1

GATE1

VSW1
VSW1

CS1

ISL6422

(38 LD EPTSSOP)

TOP VIEW

1
2
3
4
5
6
7
8
9

ISL6422EVEZ

10
11
12
13
14
15
16
17
18
19

TXT2

38

SELVTOP2

37

TCAP2

36

NC

35

VOUT2

34

TDIN2

33

TDOUT2

32

CPVOUT

31
30

CPSWOUT
CPSWIN

29

VCC

28

TDOUT1

27
26

TDIN1
VOUT1

25

AGND

24

TCAP1

23

SELVTOP1

22
21

NC
TXT1

20

2

FN9190.2

August 10, 2007

Block Diagram

www.BDTIC.com/Intersil

17

5

8

4

76

COUNTER

GATE1

12

3

PGND1

11

CS1

15

TDOUT1

23

TONE

DECODER

TDIN1

22

VSW1

14

19

24

2

NOTE:

VOUT1

AGND

VCC

SGND

20, 21

August 10, 2007

FN9190.2

OVERCURRENT

PROTECTION

LOGIC SCHEME 1

ILIM1

CS
AMP

ON CHIP

LINEAR

UVLO

POR

SOFT-START

BYP

10

PWM

LOGIC

Q

S

COMPENSATION

TXT1

INT 5V
SOFT-START

EN1/EN2

∑

OLF1

DCL1

OC1

CLK1

+

SLOPE

TXT1

16

-

­+

VREF1

SELVTOP1

+

-

BAND GAP

REF VOLTAGE

REF

VOLTAGE

ADJ1

SCL

SDA

SDA

SCL

ISEL1L AND
ISEL1H

EN1
ENT1
OTF

VTOP1

BGV

TONE

INJ

CKT 1

MSEL1

TCAP1

18

EXTM1

OLF1

FLT

FLT

ADDR0

OLF2

ADDR1

ADDR1

I2C

INTERFACE

VBOT1 VBOT2

CLK1

MSEL2

EXT TONE CKT

9

OSC.

1.1MHz

DIV AND

WAVE SHAPING

INT

TONE

ENT1

EXTM2

1

CLK2

ENT2

ADDR0

OUVF11

ISEL2L AND

TCAP2

33

OUVF1

OUVF2

ISEL2H

VTOP2

TONE

INJ

CKT 2

OUVF2

EN2

ENT2

DCL

OTF

TXT2

35

OLF2

DCL2

OC2

CLK2

BGV

REF

VOLTAGE

ADJ2

THERMAL

SHUTDOWN

OVERCURRENT

PROTECTION

LOGIC SCHEME 2

PWM

LOGIC

Q

S

­+

SLOPE

COMPENSATION

+

VREF2

+

-

CHARGE PUMP

ILIM2

∑

-

CPVOUT

27

COUNTER

PGND2

CS

AMP

SELVTOP2

TXT2

TDOUT2

TONE

DECODER

CPSWIN

CPSWOUT

26

GATE2

CS2

VSW2

VOUT2

TDIN2

39

40

36

ISL6422

34

37

30, 31

28

29

25

1. Pinouts shown are for the QFN package.

Typical Application Schematic QFN

www.BDTIC.com/Intersil

4

ISL6422

August 10, 2007

FN9190.2

ISL6422

www.BDTIC.com/Intersil

Absolute Maximum Ratings Thermal Information

Supply Voltage, VCC . . . . . . . . . . . . . . . . . . . . . . . . . . 8.0V to 18.0V

Logic Input Voltage Range

(SDA, SCL, ENT, DSQIN1 and DSQIN2,

SEL18V1 and SEL18V2) . . . . . . . . . . . . . . . . . . . . . . -0.5V to 7V

CAUTION: Do not operate at or near the maximum ratings listed for extended periods of time. Exposure to such conditions may adversely impact product reliability and
result in failures not covered by warranty.

NOTES:

is measured in free air with the component mounted on a high effective thermal conductivity test board with “direct attach” features. See

2. θ

JA

Tech Brief TB379.

3. For θ

4. The device junction temperature should be kept below +150°C. Thermal shut-down circuitry turns off the device if junction temperature exceeds

, the "case temp" location is the center of the exposed metal pad on the package underside.

JC

+150°C typically.

Thermal Resistance (Typical, Notes 2, 3) θ

EPTSSOP Package. . . . . . . . . . . . . . . 29 4

QFN Package. . . . . . . . . . . . . . . . . . . . 34 6

Maximum Junction Temperature (Note 4) . . . . . . . . . . . . . . .+150°C

Maximum Storage Temperature Range. . . . . . . . . .-40°C to +150°C

Pb-free reflow profile . . . . . . . . . . . . . . . . . . . . . . . . . .see link below

http://www.intersil.com/pbfree/Pb-FreeReflow.aspOperating

Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . .-20°C to +85°C

(°C/W) θJC (°C/W)

JA

Electrical Specifications V

PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNITS

Operating Supply Voltage Range 81214 V
Standby Supply Current EN1 = EN2 = L 1.5 3.0 mA
Supply Current I

UNDERVOLTAGE LOCKOUT

Start Threshold 7.5 7.95 V
Stop Threshold 7.0 7.55 V
Start to Stop Hysteresis 350 400 500 mV

SOFT-START

COMP Rise Time (Note 5) (Note 5) 8196 Cycles
Output Voltage (Note 5) V

Line Regulation DV

Load Regulation DV

= 12V, TA = -20°C to +85°C, unless otherwise noted. Typical values are at TA = +25°C. EN1 = EN2 = H,

CC

VTOP1 = VTOP2 = L, ENT1 = ENT2 = L, DCL = L, DSQIN1 = DSQIN2 = L, I
noted. See “ISL6422 Software Description” on page 12 for I

EN1 = EN2 = VTOP1 = VTOP2 = VBOT1 =
VBOT2 = ENT1 = ENT2 = H, No Load

(Refer to Table 11) 13.04 13.3 13.56 V
(Refer to Table 11) 14.02 14.3 14.58 V
(Refer to Table 11) 17.94 18.3 18.66 V
(Refer to Table 11) 19.00 19.3 19.68 V
(Refer to Table 15) 13.04 13.3 13.56 V
(Refer to Table 15) 14.02 14.3 14.58 V
(Refer to Table 15) 17.94 18.3 18.66 V
(Refer to Table 15) 19.00 19.3 19.68 V
VIN = 8V to 14V; V

= 8V to 14V; V

V

IN

IO = 12mA to 350mA 50 80 mV

= 12mA to 750mA 100 200 mV

I

O

OUT1
OUT1

, V

, V

OUT2
OUT2

V
V
V
V
V
V
V

DV

DV

IN

OUT1
OUT1
OUT1
OUT1
OUT2
OUT2
OUT2
OUT2

OUT1,

OUT2

OUT1,

OUT2

2

C access to the system.

= 13V 4.0 40.0 mV
= 18V 4.0 60.0 mV

= 12mA, unless otherwise

OUT

4.0 8.0 mA

5

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

Electrical Specifications V

PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNITS

Dynamic Output Current Limiting
(Note 8)

Dynamic Overload Protection Off Time t
Dynamic Overload Protection On Time t
Static Output Current Limiting I
Cable Fault CABF Asserted High I

TONE OSCILLATOR

Tone Frequency f
Tone Amplitude V
Tone Duty Cycle dc
Tone Rise or Fall Time t

TONE DECODER

Input Amplitude Vtdin 200 1000 mV
Frequency Capture Range Ftdin 17.5 26.5 kHz
Input Impedance Z
Detector Output Voltage V
Detector Output Leakage I
Tone Decoder Rx Threshold V
Tone Decoder Tx Threshold V

LINEAR REGULATOR

Drop-out Voltage I
Output Backward Leakage Current I
Output Backward Leakage Current I
Output Backward Current Threshold I
Output Backward Voltage I
Output Undervoltage

(Asserted high during soft-start)
Output Overvoltage

(Asserted high during soft-start)

= 12V, TA = -20°C to +85°C, unless otherwise noted. Typical values are at TA = +25°C. EN1 = EN2 = H,

CC

VTOP1 = VTOP2 = L, ENT1 = ENT2 = L, DCL = L, DSQIN1 = DSQIN2 = L, I
noted. See “ISL6422 Software Description” on page 12 for I

I

MAX

OFF

ON
MAX
CAB

tone

tone

tone

, t

r

DET

TDOUT_L

TDOUT_H

RXth
TXth

OBK
OBK

OBKTH

OBK

DCL = 0, ISEL1H and ISEL2H = 0,
ISEL1L and ISEL2L = 0,
ISEL1R and ISEL2R = 0

DCL = 0, ISEL1H and ISEL2H = 0,
ISEL1L and ISEL2L = 0,
ISEL1R and ISEL2R = 1

DCL = 0, ISEL1H and ISEL2H = 0,
ISEL1L and ISEL2L = 1,
ISEL1R and ISEL2R = 1

DCL = 0, ISEL1H and ISEL2H = 1,
ISEL1L and ISEL2L = 0,
ISEL1R and ISEL2R = 1

DCL = 0, ISEL1H and ISEL2H = 1,
ISEL1L and ISEL2L = 1,
ISEL1R and ISEL2R = 1

DCL = L, Output Shorted (Note 8) 900 ms

DCL = 1 (Note 8) 990 mA
EN1 and EN2 = 1; 2 10 20 mA

ENT1 and ENT2 = H 20.0 22.0 24.0 kHz
ENT1 and ENT2 = H, I
ENT1 and ENT2 = H 40 50 60 %
ENT1 and ENT2 = H 5 10 14 μs

f

Tone Present, I
Tone absent, VO = 6V 10 μA
TXT1 and TXT2 = L 100 150 200 mV
TXT1 and TXT2 = H 400 450 500 mV

= 750mA 0.8 1.0 V

OUT

EN1 and EN2 = 0; V
EN1 and EN2 = 0; V
EN1 and EN2 = 1; V
EN1 and EN2 = 0 27 V
OUVF1, OUVF2 bit is asserted high,

measured from the typ output set value
OUVF1, OUVF2 bit is asserted high,

measured from the typ output set value

LOAD

= 5mA 500 680 800 mV

OUT

= 3mA 0.4 V

= 27V 2.0 3.0 mA

OBK

= 28V 15.0 17.0 mA

OBK

= 19V (Note 7) 125 mA

OFAULT

2

C access to the system. (Continued)

270 305 345 mA

350 388 422 mA

515 570 630 mA

635 705 775 mA

800 890 980 mA

-6 2 %

+2 +6 %

= 12mA, unless otherwise

OUT

20 ms

8.6 kΩ

6

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

Electrical Specifications V

PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNITS

TXT1 AND TXT2, EXTM1 AND EXTM2, SELVTOP1 AND SELVTOP2, ADDR0 AND ADDR1 INPUT PINs (Note 8)

Asserted LOW 0.8 V
Asserted HIGH 1.7 V
Input Current 25 μA

CURRENT SENSE (CS pin)

Input Bias Current I
Overcurrent Threshold V

ERROR AMPLIFIER

Open Loop Voltage Gain A
Gain Bandwidth Product

PWM

Maximum Duty Cycle 90 93 %
Minimum Pulse Width 20 ns

OSCILLATOR

Oscillator Frequency f
Thermal Shutdown
Temperature Shutdown Threshold 150 °C
Temperature Shutdown Hysteresis 20 °C

FLT

FLT (released) VO = 6V 10 µA

(asserted) I

FLT

NOTES:

5. Internal digital soft-start.

6. The EXTM1 and EXTM2, SELVTOP1 and SELVTOP2, TXT1 and TXT2, and ADDR0 and ADDR1 pins have 200k internal pull-downs.

7. On exceeding this dynamic back current limit threshold for a period of 100µs, the device enters the dynamic current limit mode, and the BCF I
bit is set. The dynamic back current limit duty during a BCF is ON = 100µs or OFF = 5ms.

8. In the dynamic back current limit mode, the output is ON for 20ms and OFF for 900ms, but remains continuously ON in the Static mode. When
tone is ON, the minimum current limit is 50mA lower than the values indicated in the table. While in the dynamic mode of current limit, the trip
level is momentarily increased to 990mA during the 20ms ON time to facilitate recovery from overload conditions.

= 12V, TA = -20°C to +85°C, unless otherwise noted. Typical values are at TA = +25°C. EN1 = EN2 = H,

CC

VTOP1 = VTOP2 = L, ENT1 = ENT2 = L, DCL = L, DSQIN1 = DSQIN2 = L, I
noted. See “ISL6422 Software Description” on page 12 for I

BIAS

CS

OL

GBP

Static current mode, DCL = H 325 450 500 mV

o

Fixed at (20) (f

= 3.2mA (1.5k pull-up resistor to 5V) 0.4 V

SINK

) 396 440 484 kHz

tone

2

C access to the system. (Continued)

= 12mA, unless otherwise

OUT

700 nA

88 dB
14 MHz

2

C

7

FN9190.2

August 10, 2007

Tone Waveform

www.BDTIC.com/Intersil

ENT1/2

2

C

I

MSEL1/2

2

C

I

EXTM1/2

PIN

VOUT1/2

PIN

22kHz 22kHz 22kHz 22kHz22kHz 22kHz

ISL6422

Internal Tone

= 10µs typ

t

r

= 10µs typ

t

r

Returns to nominal V
after the last EXTM rising edge

OUT

~1 period

= 10µs typInternal Tone

t

r

Internal Tone

t >55µs

FIGURE 1. TONE WAVEFORM

NOTES:

9. The logic presented to the signal pins TXT1 and TXT2 changes the decoder threshold during tone Transmit and Receive. TTH1 and TTH2 allow
threshold control through the I

2

C provided that TXT1 and TXT2 = 0.

10. The tone rise and fall times are not shown due to resolution of graphics. It is 10µs typ for 22kHz.

11. The EXTM1 and EXTM2 pins have input thresholds of V

IL(max)

= 0.8V and V

IH(min)

= 1.7V

Typical Performance Curves

IN A

OUT

I

0.82

0.81

0.80

0.79

0.81

0.76

IN A

OUT

I

0.71

0.78
020406080

TA (°C)

FIGURE 2. OUTPUT CURRENT DERATING 38 LD HTSSOP:

I

_max vs T

OUT

A

0.66
020406080

FIGURE 3. OUTPUT CURRENT DERATING 40 LD 6x6 QFN:

NOTE: With both channels in simultaneous operation at rated output.

\

8

I

OUT

_max vs T

T

(°C)

A

A

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

Functional Pin Descriptions

SYMBOL FUNCTION

2

SDA Bidirectional data from/to I

2

OUT

C bus.

.

SCL Clock from I
VSW1 and VSW2 Input of the linear post-regulator.
PGND1 and PGND2 Dedicated ground for the output gate driver of respective PWM.
CS1 and CS2 Current sense input; connect the sense resistor Rsc at this pin for desired overcurrent value for respective PWM.
SGND Small signal ground for the IC.
TCAP1 and TCAP2 Capacitor for setting rise and fall time of the output of LNB A and LNB B respectively. Typical value is 0.22µF.
BYP Bypass capacitor for internal 5V.
TXT1 and TXT2 TXT1 and TXT2 are the Tone T ransmit signal inputs used to change the tone decoder threshold. The threshold is 200mV

max for the Rx mode when the TXT1 and TXT2 are set low. The threshold is 400mV min in the Tx mode when TXT1
and TXT2 are set high. If Tx/Rx mode is set by I

(5V) by an on-chip driver.
VCC Main power supply to the chip.
GATE1 and GATE2 These are the device outputs of PWM A and PWMB respectively. These high current driver outputs are capable of

VOUT1 and VOUT2 Output voltage for LNB A and LNB B respectively.
ADDR0 and ADDR1 Address pins select four different device addresses per Table 19.
EXTM1 and EXTM2 These pins can be used in two ways:

FLT This is an open drain output from the controller. When the FLT goes low, it indicates that an Over-Temperature has

CPVOUT, CPSWIN,
CPSWOUT

SELVTOP1 and
SELVTOP2

TDIN1 and TDIN2
TDOUT1 and TDOUT2

AGND Analog ground for the IC.

driving the gate of a power FET. These outputs are actively held low when V

1. As an input for externally modulated DiSEqC tone signal that is transferred symmetrically onto V

2. Alternatively apply a DiSEqC modulation envelope that modulates an internal tone and then transfers it symmetrically
onto V

occurred. The processor should then look at the I
indicates that the device is functioning normally.

A 47nF charge pump cap is connected to CPVOUT. Connect a 1.5nF capacitor between CPSWIN and CPSWOUT.

The following description applies to both pins and both bits.
When this pin is low, the V
When this pin is high, the 18V/19V range is selected by the I
The voltage select pin voltage VSPEN1 and VSPEN2 I
to be active. Setting VSPEN1 and VSPEN2 high disables these pins and voltage selection will be done using the I
bits VBOT1 and VBOT2 and VTOP1 and VTOP2 only.

TDIN1 and TDIN2 are the tone decoder inputs for Channels 1 and 2.
TDOUT1 and TDOUT2 are the tone detector outputs for Channels 1 and 2. TDOUT1 and TDOUT2 are open drain ou tputs.

C bus.

2

C bit TTH(1 ,2), when TTH(1, 2) = 1, then TXT(1, 2) will be driven high

is below the UVLO threshold.

CC

2

C register to get the actual cause of the error. A high on the FLT

is in the 13V/14V range selected by the I2C bit VBOT1 and VBOT2.

OUT

2

C bit VTOP1 and VTOP2.

2

C bit must be set low for the SELVTOP1 and SELVTOP2 pins

OUT

.

2

C

9

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

Functional Description

The ISL6422 dual output voltage regulator makes an ideal
choice for advanced satellite set-top box and personal video
recorder applications. Both supply and control voltage
outputs for two low-noise blocks (LNBs) are available
simultaneously in any output configuration. The device
utilizes built-in DC/DC step up converters that, from a single
supply source ranging from 8V to 14V, generate the voltages
that enable the linear post-regulators to work with a
minimum of dissipated power. An undervoltage lockout
circuit disables the device when VCC drops below a fixed
threshold (7.5V typical).

DiSEqC Encoding

The internal oscillator is factory-trimmed to provide a tone of
22kHz in accordance with DiSEqC (EUTELSAT) standards.
No further adjustment is required. The tone oscillator can be
controlled either by the I
a dedicated pin (EXTM1 or EXTM2) that allows immediate
DiSEqC data encoding separately for each LNB. All the
functions of this IC are controlled via the I
the system registers. The same registers can be read back,
and four bits will report the diagnostic status. The internal
oscillator operates the converters at twenty times the 22k tone
frequency . The device offers full I
supports 2.5V, 3.3V or 5V logic, and up to 400kHz operation.

If the Tone Enable bits (ENT1 and ENT2) are set LOW and
the MSEL1 and MSEL2 bits set LOW through I
EXTM1 and EXTM2 terminal activates the internal tone
signal, modulating the DC output with a 680mV
symmetrical tone waveform. The presence of this signal
usually provides the LNB with information about the band to
be received.

Burst coding of the tone can be accomplished due to the fast
response of the EXTM1 and EXTM2 input and rapid tone
response. This allows implementation of the DiSEqC
(EUTELSAT) protocols.

When the ENT1 or ENT2 bit is set HIGH, a continuous
22kHz tone is generated regardless of the EXTM1 and
EXTM2 pin logic status for the corresponding regulator
channel (LNB-A or LNB-B). The ENT1 or ENT2 bit must be
set LOW when the EXTM1 and/or EXTM2 pin is used for
DiSEqC encoding.

The EXTM1 and EXTM2 pins also accept an externally
modulated tone command when the MSEL1 or MSEL2 I
bit is set high.

DiSEqC Decoder

TDIN1 and TDIN2 are the inputs to the tone decoders of
Channels 1 and 2 respectively. They accept the tone signal
derived from the V
capacitor. The detector threshold can be set to 200mV
maximum in the Receive mode and to 400mV minimum in
the Transmit mode by means of the logic presented to the

2

C interface (ENT1 or ENT2 bit) or by

2

C bus by writing to

2

C compatibility and

through the 10nF decoupling

OUT

2

C, then the

typ

P-P

2

C

TXT1 or TXT2 pin. If tone is detected, the open drain pin
TDOUT1 or TDOUT2 is asserted low. This also enables the
tone diagnostics to be performed, apart from the normal tone
detection function.

Linear Regulator

The output linear regulator will sink and source current. This
feature allows full modulation capability into capacitive loads
as high as 0.75µF. In order to minimize the power
dissipation, the output voltage of the internal step-up
converter is adjusted to allow the linear regulator to work at
minimum dropout.

When the device is put in the shutdown mode (EN1 and
EN2 = LOW), both PWM power blocks are disabled (that is,
when EN1 = 0, PWM1 is disabled, and when EN2 = 0,
PWM2 is disabled).

When the regulator blocks are active (EN1 and EN2 = HIGH,
and VSPEN1 and VSPEN2 = LOW), the output can be
controlled via I
between 18V and 19V (typical) by means of the Voltage
Select bits (VTOP1, VTOP2, VBOT1, and VBOT2) for
remote controlling of non-DiSEqC LNBs.

When the regulator blocks are active (EN1 and EN2 = HIGH,
and VSPEN1 and VSPEN2 = HIGH), the VBOT1 and
VBOT2 bits and the SELVTOP1 and SELVTOP2 pins will
control the output between 13V and 14V and the VTOP1 and
VTOP2 and the SEL VT OP1 and SELVTOP2 pins will control
the output between 18V and 19V.

2

C logic to be between 13V and 14V or

Output Timing

The output voltage rise and fall times can be set by an the
external capacitor on the TCAP1 and TCAP2 pins. The
output rise and fall times is given by Equation 1:

270()t

---------------- -

C

=

ΔV

where:

• C is the TCAP value in nF

• t is the required slew rate in ms, and

• ΔV is the differential transition voltage from low output
voltage range to the high output range in Volts.

Rise and fall time will typically be the same.
The maximum recommended value for TCAP1 and TCAP2

would be the base on the maximum transition time allowed
in the system application. Too small a value of TCAP1 and
TCAP2 can cause high peak currents in the boost circuit. For
example, a 10V/ms slew on a 80µF VSW capacitor with an
inductor of 15µH can cause a peak inductor current of
approximately 2.3A.

(EQ. 1)

10

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

Current Limiting

The dynamic back current limit block has five thresholds that
can be selected by the following bits of the SR.

• ISEL1H and ISEL2H

• ISEL1L and ISEL2L

• ISEL1R and ISEL2R
See Table 8 and Table 9 for threshold selection using these

bits. The DCL1 and DCL2 bits have to be set to low for this
mode of operation. In this mode, the overcurrent protection
circuit works dynamically 23µs after an overload is detected,
and the output is shutdown for a time t
Simultaneously, the OLF1 or OLF2 bit of the System
Register is set to HIGH. After this time has elapsed, the
output is resumed for a time t
device output will be current limited to a 990mA typ level. If
the overload is still detected, the protection circuit will cycle
again through t
no overload is detected, normal operation is resumed and
the OLF1 or OLF2 bit is reset to LOW. Typical t
time is 920ms as determined by an internal timer. This
dynamic operation can greatly reduce the po wer dissipation
in a short circuit condition, still ensuring excellent power-on
start-up in most conditions.

However, there could be some cases in which a highly
capacitive load on the output may cause a difficult start-up
when the dynamic protection is chosen. This can be solved
by initiating any power start-up in static mode (DCL = HIGH)
and then switching to the dynamic mode (DCL = LOW) after
a chosen amount of time. When in static mode, the OLF1 or
OLF2 bit goes HIGH when the peak current sense threshold
is reached and returns LOW when the overload condition is
cleared. The OLF1, OLF2, BCF1, and BCF2 bits will be LOW
at the end of initial power-on soft-start. In the static mode the
output current through the linears is limited to 990mA typ.

When a 19.3V line is connected onto a VOUT1 or VOUT2
pin that has been set to 13.3V, the linear will then enter a
dynamic back current limit state. When a dynamic back
current limit of greater that 125mA typ is sensed at the lower
FET of the linear for a period greater that 100µs, the output
is disabled for a period of 5ms and the BCF1 and BCF2 bits
are set. If the 19.3V remains connected, the output will cycle
through the ON = 100µs/OFF = 5ms. The output will recover
when the fault is removed.

and tON. At the end of a full tON, in which

OFF

= 20ms. During tON, the

ON

, typically 900ms.

OFF

ON+tOFF

Thermal Protection

This IC is protected against overheating. When the junction
temperature exceeds +150°C (typical), the step-up converter
and the linear regulator are shut off and the OTF bit of the
SR is set HIGH. Normal operation is resumed and the OTF
bit is reset LOW when the junction is cooled down to +130°C
(typical).

The FLT
an over temperature, overcurrent or backwards overcurrent
fault is detected by the LNB controller or when both channels
are disabled by the I
Should the I
to ground), it is designed to power up with all control bits set
to 0 (particularly the EN1 and EN2 bits). This prevents the
device from coming back up in a state not desired by the
host controller. If the host controller sees a FLT
should read the I
When it desires one or both to be high, it should re-write the

2

I

pin serves as an interrupt for the processor when

2

2

C lose power (for example by shorting BYP pin

C to the desired state.

C EN1 and EN2 bits being set low.

2

C bits and find both EN1 and EN2 bits low.

low, it

External Output Voltage Selection

The output voltage can be selected by the I2C bus.
Additionally, the package offers two pins (SELVTOP1 and
SELVTOP2) for independent 13 through 19V output voltage
selection.

TABLE 1.

VSPEN1,
VSPEN2

0 X 0 0 13.3V
0 X 1 0 14.3V
0 0 X 1 18.3V
0 1 X 1 19.3V
1 0 0 X 13.3V
1 0 1 X 14.3V
1 1 0 X 18.3V
1 1 1 X 19.3V

VTOP1,

VTOP2

VBOT1,

VBOT2

SELVTOP1,

SELVTOP2

VOUT1,

VOUT12

I2C Bus Interface for ISL6422

(Refer to Phillips I2C Specification, Rev. 2.1)
Data transmission from the main microprocessor to the

ISL6422 and vice versa takes place through the two-wire I
bus interface, consisting of the two lines SDA and SCL. Both
SDA and SCL are bidirectional lines. They are connected to a
positive supply voltage via a pull-up resistor. (Pull-up resistors
to positive supply voltage must be externally connected). When
the bus is free, both lines are HIGH. The output stages of
ISL6422 will have an open drain/open collector in order to
perform the wired-AND function. Data on the I
transferred up to 100kbps in the standard mode or up to
400kbps in the fast mode. The level of logic “0” and logic “1”
depends on the value of V
Specifications” table on page5. One clock pulse is generated
for each data bit transferred.

as per the “Electrical

DD

2

C bus can be

2

C

11

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

Data Validity

The data on the SDA line must be stable during the HIGH
period of the clock. The HIGH or LOW state of the data line
can change only when the clock signal on the SCL line is
LOW. Refer to Figure 4.

SDA

SCL

DATA LINE

STABLE

DATA VALID

FIGURE 4. DATA VALIDITY

CHANGE
OF DATA

ALLOWED

START and STOP Co nditions

As shown in Figure 5, the START condition is a HIGH to
LOW transition of the SDA line while SCL is HIGH.

The STOP condition is a LOW to HIGH transition on the SDA
line while SCL is HIGH. A STOP condition must be sent
before each START condition.

SDA

The ISL6422 will not generate the acknowledge if the
POWER OK signal from the UVLO is LOW.

SCL

8

9

ACKNOWLEDGE

FROM SLAVE

SDA

START

1

MSB

FIGURE 6. ACKNOWLEDGE ON THE I2C BUS

2

Transmission Without Acknowledge

Avoiding detection of the acknowledgement, the
microprocessor can use a simpler transmission; it waits one
clock pulse without checking the slave acknowledging and
sends the new data. Although, this approach is less
protected from error and decreases the noise immunity.

ISL6422 Software Description

Interface Protocol

The interface protocol is comprised of the following, as
shown in Table 2:

• Start condition (S)

SCL

SP

START

CONDITION

FIGURE 5. START AND STOP WAVEFORMS

STOP

CONDITION

Byte Format

Every byte put on the SDA line must be eight bits long. The
number of bytes that can be transmitted per transfer is
unrestricted. Each byte has to be followed by an
acknowledge bit. Data is transferred with the most significant
bit first (MSB).

Acknowledge

The master (microprocessor) puts a resistive HIGH level on
the SDA line during the acknowledge clock pulse (see
Figure 6). The peripheral that acknowledges has to pull
down (LOW) the SDA line during the acknowledge clock
pulse, so that the SDA line is stable LOW during this clock
pulse. (Set-up and hold times must also be taken into
account).

The peripheral which has been addressed has to generate
an acknowledge after the reception of each byte, otherwise
the SDA line remains at the HIGH level during the ninth
clock pulse time. In this case, the master transmitter can
generate the STOP information in order to abort the transfer.

• Chip address byte (MSB on left; the LSB bit determines
read (1) or write (0) transmission) (the assigned I

2

C slave

address for the ISL6422 is 0001 00XX)

• Sequence of data (1 byte + Acknowledge)

• Stop condition (P)

TABLE 2. INTERFACE PROTOCOL

S0001000R/WACK Data (8 bits) ACKP

System Register Format

• R, W = Read and Write bit

• R = Read-only bit

• X = Unused

All bits reset to 0 at Power-On

TABLE 3. STATUS REGISTER 1 (SR1)

R, W R, W R, W R R R R R

SR1H SR1M SR1L OTF CABF1 OUVF1 OLF1 BCF1

TABLE 4. TONE REGISTER 2 (SR2)

R, W R, W R, W R, W R, W R, W R, W R, W

SR2H SR2M SR2L ENT1 MSEL1 TTH1 X X

TABLE 5. COMMAND REGISTER 3 (SR3)

R, W R, W R, W R, W R, W R, W R, W R, W

SR3H SR3M SR3L DCL1 VSPEN1 ISEL1RXISEL1H ISEL1L

12

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

TABLE 6. CONTROL REGISTER 4 (SR4)

R, W R, W R, W R, W R, W R, W R, W R, W

SR4H SR4M SR4L EN1 X X VTOP1 VBOT1

TABLE 7. STATUS REGISTER 5 (SR5)

R, WR, WR, WXRRRR

SR5H SR5M SR5L X CABF2 OUVF2 OLF2 BCF2

TABLE 8. TONE REGISTER 6 (SR6)

R, W R, W R, W R, W R, W R, W R, W R, W

SR6H SR6M SR6L ENT2 MSEL2 TTH2 X X

R, W R, W R, W R, W R, W R, W R, W R, W

SR7H SR7M SR7L DCL2 VSPEN2 ISEL2R ISEL2H ISEL2L

R, W R, W R, W R, W R, W R, W R, W R, W

SR8H SR8M SR8L EN2 X X VTOP2 VBOT2

Transmitted Data (I

When the R/W bit in the chip is set to 0, the main
microprocessor can write on the system registers (SR1
through SR8) of the ISL6422 via I

TABLE 9. COMMAND REGISTER 7 (SR7)

TABLE 10. CONTROL REGISTER 8 (SR8)

2

C bus WRITE mode)

written by the microprocessor as shown in the following. The
spare bits of registers can be used for other functions.

TABLE 11. STATUS REGISTER SR1 CONFIGURATION

SR1H SR1M SR1L OTF CABF1 OUVF1 OLF1 BCF1 FUNCTION

000XXXXXSR1 is selected
000XXX0XI
000XXX1XI
000XXXX0I
000XXXX1I
000XX0XXV
000XX1XXV
0 0 0 X 0 X X X Cable is connected, I
0 0 0 X 1 X X X Cable is open, I
0000XXXXT
0001XXXXT

NOTE: X indicates “Read Only” and is a “Don’t Care” for the Write mode.

≤set limit, Normal Operation

OUT

>Static/Dynamic Limiting Mode/Power blocks disabled

OUT

≤set limit, Normal Operation

OBCK

>Dynamic Limiting Mode/Power blocks disabled

OBCK

IN/VOUT
IN/VOUT

J
J

within specified range
is not within specified range

is >20mA

OUT

<2mA

OUT

≤+130°C, Normal operation
>+150°C, Power blocks disabled

2

C bus. These will be

TABLE 12. TONE REGISTER SR2 CONFIGURATION

SR2H SR2M SR2L ENT1 MSEL1 TTH1 X X FUNCTION

001XXXXXSR2 is selected
00100XXXInternal Tone = 22kHz, modulated by EXTM1, t
00101XXXExt 22k modulated input, tr, tf = 10µs typ
00110XXXInternal Tone = 22kHz, modulated by the ENT1 bit, t
0 0 1 X X 0 X X TXT = 0; Decoder Rx threshold is set at 200mV max
0 0 1 X X 1 X X TXT = 0; Decoder Tx threshold is set at 400mV min

NOTE: X is a “Don’t Care” for the Write mode.

13

, tf = 10µs typ

r

, tf = 10µs typ

r

August 10, 2007

FN9190.2

ISL6422

www.BDTIC.com/Intersil

TABLE 13. COMMAND REGISTER SR3 CONFIGURATION

SR3H SR3M SR3L DCL1 VSPEN1 ISEL1R ISEL1H ISEL1L FUNCTION

0 1 0 X X X X X SR3 is selected
0100X0XXI
0100X100I
0100X101I
0100X110I
0100X111I
0 1 0 1 X X X X Dynamic current limit NOT selected
0 1 0 0 X X X Dynamic current limit selected
0 1 0 X 0 X X X SELVTOP H/W pin Enabled
0 1 0 X 1 X X X SELVTOP H/W pin Disabled

NOTE: X is a “Don’t Care” for the Write mode.

TABLE 14. CONTROL REGISTER SR4 CONFIGURATION

SR4H SR4M SR4L EN1 X X VTOP1 VBOT1 FUNCTION

0111XX00SR4 is selected
0 1 1 1 X X 0 0 VSPEN1 = SELVTOP1 = 0, V

0 1 1 1 X X 0 1 VSPEN1 = SELVTOP1 = 0, V

0 1 1 1 X X 1 0 VSPEN1 = SELVTOP1 = 0, V

0 1 1 1 X X 1 1 VSPEN1 = SELVTOP1 = 0, V

0 1 1 1 X X 0 0 VSPEN1 = 0, SELVTOP1 = 1, V

0 1 1 1 X X 0 1 VSPEN1 = 0, SELVTOP1 = 1, V

0 1 1 1 X X 1 0 VSPEN1 = 0, SELVTOP1 = 1, V

0 1 1 1 X X 1 1 VSPEN1 = 0, SELVTOP1 = 1, V

0 1 1 1 X X 0 0 VSPEN1 = 1, SELVTOP1 = X, V

0 1 1 1 X X 0 1 VSPEN1 = 1, SELVTOP1 = X, V

0 1 1 1 X X 1 0 VSPEN1 = 1, SELVTOP1 = X, V

0 1 1 1 X X 1 1 VSPEN1 = 1, SELVTOP1 = X, V

0110XXXXPWM and Linear for Channel 1 disabled

NOTE: X is a “Don’t Care” for the Write mode.

= 275mA maximum

OUT1

= 350mA maximum

OUT1

= 515mA maximum

OUT1

= 635mA maximum

OUT1

= 800mA maximum

OUT1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

= 13V + V

= 14V + V

= 13V + V

= 14V + V

= 18V + V

= 18V + V

= 19V + V

= 19V + V

= 13V + V

= 14V + V

= 18V + V

= 19V + V

V

V

V

V

V

V

V

V

V

V

V

V

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

OUT1

DROP

= 13V,

= 14V,

= 13V,

= 14V,

= 18V,

= 18V,

= 19V,

= 19V,

= 13V,

= 14V,

= 18V,

= 19V,

14

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

TABLE 15. STATUS REGISTER SR5 CONFIGURATION

SR5H SR5M SR5L CABF2 OUVF2 OLF2 BCF2 FUNCTION

1 0 0 X X X X X SR5 is selected
100XXX0XI
100XXX1XI
100XXXX0I
100XXXX1I
100XX0XXV
100XX1XXV
1 0 0 X 0 X X X Cable is connected, I
1 0 0 X 1 X X X Cable is open, I

NOTE: X indicates “Read Only” state.

TABLE 16. TONE REGISTER SR6 CONFIGURATION

SR6H SR6M SR6L ENT2 MSEL2 TTH2 X X FUNCTION

1 0 1 X X X X X SR2 is selected
1 0 1 0 0 X X X Int Tone = 22kHz, modulated by EXTM2, T
1 0 1 0 1 X X X Ext 22k modulated input, T
1 0 1 1 0 X X X Int Tone = 22kHz, modulated by ENT2 bit, T
1 0 1 X X 0 X X TXT2 = 0; Decoder Rx threshold is set at 200mV max
1 0 1 X X 1 X X TXT2 = 0; Decoder Tx threshold is set at 400mV min

NOTE: X is a “Don’t Care” for the Write mode.

≤ set limit, Normal Operation

OUT

> Static/Dynamic Limiting Mode/Power blocks disabled

OUT

≤ set limit, Normal Operation

OBCK

> Dynamic Limiting Mode/Power blocks disabled

OBCK

IN/VOUT
IN/VOUT

within specified range
is not within specified range

is >20mA

OUT

<2mA

OUT

, Tf = 10µs typ

r

r

, Tf = 10µs typ

, Tf = 10µs typ

r

TABLE 17. COMMAND REGISTER SR7 CONFIGURATION

SR7H SR7M SR7L DCL2 VSPEN2 ISEL2R ISEL2H ISEL2L FUNCTION

1 1 0 X X X X X SR7 is selected
1100X0XXI
1100X100I
1100X101I
1100X110I
1100X111I
1 1 0 1 X X X X Dynamic current limit NOT selected
1 1 0 0 X X X X Dynamic current limit selected
1 1 0 X 0 X X X SELVTOP H/W pin Enabled
1 1 0 X 1 X X X SELVTOP H/W pin Disabled

NOTE: X is a “Don’t Care” for the Write mode.

1 = 275mA max.

OUT

1 = 350mA max.

OUT

1 = 515mA max.

OUT

1 = 635mA max.

OUT

1 = 800mA max.

OUT

15

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

TABLE 18. CONTROL REGISTER SR8 CONFIGURATION

SR8H SR8M SR8L EN2 X X VTOP2 VBOT2 FUNCTION

1 1 1 1 X X 0 0 SR4 is selected
1 1 1 1 X X 0 0 VSPEN2 = SELVTOP2 = 0, V

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

BOOST1

= 13V + V

= 14V + V

= 13V + V

= 14V + V

= 18V + V

= 18V + V

= 19V + V

= 19V + V

= 13V + V

= 14V + V

= 18V + V

= 19V + V

DROP

DROP

DROP

DROP

DROP

DROP

DROP

DROP

DROP

DROP

DROP

DROP

V

1 1 1 1 X X 0 1 VSPEN2 = SELVTOP2 = 0, V

V

1 1 1 1 X X 1 0 VSPEN2 = SELVTOP2 = 0, V

V

1 1 1 1 X X 1 1 VSPEN2 = SELVTOP2 = 0, V

V

1 1 1 1 X X 0 0 VSPEN2 = 0,SELVTOP2 = 1, V

V

1 1 1 1 X X 0 1 VSPEN2 = 0, SELVTOP2 = 1, V

V

1 1 1 1 X X 1 0 VSPEN2 = 0, SELVTOP2 = 1, V

V

1 1 1 1 X X 1 1 VSPEN2 = 0, SELVTOP2 = 1, V

V

1 1 1 1 X X 0 0 VSPEN2 = 1, SELVTOP2 = X, V

V

1 1 1 1 X X 0 1 VSPEN2 = 1, SELVTOP2 = X, V

V

1 1 1 1 X X 1 0 VSPEN2 = 1, SELVTOP2 = X, V

V

1 1 1 1 X X 1 1 VSPEN2 = 1, SELVTOP2 = X, V

V

1 1 1 0 X X X X PWM and Linear for channel 1 disabled

NOTE: X is a “Don’t Care” for the Write mode.

OUT1

OUT1

OUT1

OUT1

OUT1

OUT1

OUT1

OUT1

OUT1

OUT1

OUT1

OUT1

= 13V,

= 14V,

= 13V,

= 14V,

= 18V,

= 18V,

= 19V,

= 19V,

= 13V,

= 14V,

= 18V,

= 19V,

Received Data (I

2

C bus READ MODE)

The ISL6422 can provide to the master a copy of the system
register information via the I

2

C bus in read mode. The read
mode is master-activated by sending the chip address with
the R/W bit set to 1. At the following master-generated clock
bits, the ISL6422 issues a byte on the SDA data bus line
(MSB transmitted first).

At the ninth clock bit, the MCU master can:

• Acknowledge the reception, thus starting the transmission

of another byte from the ISL6422.

• Not acknowledge, thus stopping the read mode

communication.

While the whole register is read back by the microprocessor,
the following read-only bits convey diagnostic information
about the ISL6422.

• OUC1 and OUC2 (Over or Undercurrent bits)

• UV1 and UV2 (Over or Undervoltage bits)

• TPR1 and TPR2 (Tone present bits)

• OTF (Over-temperature fault bit).

Power–On I2C Interface Reset

The I2C interface built into the ISL6422 is automatically reset
at power-on. The I
logic signal from the UVLO circuit. This signal will go HIGH
when chip power is OK. As long as this signal is LOW, the
interface will not respond to any I
system register SR1 and SR2 are initialized to all zeros, thus
keeping the power blocks disabled. Once the V
above UVLO, the POWER OK signal given to the I
interface block will be HIGH, the I
operative and the SRs can be configured by the main
microprocessor. About 400mV of hysteresis is provided in
the UVLO threshold to avoid false triggering of the power-on
reset circuit. (I
the same time as (or later than) all other I
PWM becomes valid).

2

C interface block will receive a Power OK

2

C commands and the

rises

CC

2

2

C interface becomes

2

C comes up with EN = 0; EN goes HIGH at

2

C data for that

C

16

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

ADDR0 and ADDR1 Pins

Connecting either ADDR0 or ADDR1 to GND, the chip I2C
interface address is 0001000, but it is possible to choose
between four different addresses simply by setting the logic
as indicated in Table 19.

TABLE 19. ADDRESS PIN CHARACTERISTICS

V

ADDR

V

-1

ADDR

“0001000”

V

-2

ADDR

“0001001”

-3

V

ADDR

“0001010”

-4

V

ADDR

“0001011”

ADDR1 ADDR0

00

01

10

11

I2C Electrical Characteristics

TABLE 20. I2C SPECIFICATIONS

PARAMETER TEST CONDITION MIN TYP MAX

Input Logic High, VIH SDA, SCL 2.0V
Input Logic Low, VIL SDA, SCL 0.8V
Input Logic Current, IIL SDA, SCL;

0.4V < V
Input Hysterisis SDA, SCL 165mV 200mV 235mV
SCL Clock Frequency 0 100kHz 400kHz

DD

< 3.3V

10μA

I2C Bit Description

TABLE 21.

BIT NAME DESCRIPTION

EN1 and EN2 ENable Output for Channels 1 and 2
VTOP1 and VTOP2 Voltage TOP Select (that is, 18V/19V for Channels 1 and 2)
VBOT1 and VTOP2 Voltage BOTtom Select (that is, 13V/14V for Channels 1 and 2)
ENT1 and ENT2 ENable Tone for Channels 1 and 2
MSEL1 and MSEL2 Modulation SELect for Channels 1 and 2
TFR1 and TFR2 Tone Frequency and Rise time select for Channels 1 and 2
DCL1 and DCL2 Dynamic Current Limit select for Channels 1 and 2
VSPEN1 and VSPEN2 Voltage Select Pin ENable for Channels 1 and 2
ISEL1H and ISEL2H, ISEL1L and

ISEL2L, ISEL1R and ISEL2R
OTF Over-Temperature Fault bit
CABF1, CABF2 CABle Fault or open status bit for Channels 1 and 2
OUVF1, OUVF2 Over and Undervoltage Fault status bit for Channels 1 and 2
OLF1, OLF2 Over Load Fault status bit for Channels 1 and 2
BCF1, BCF2 Backward Current Fault Bit for Channels 1 and 2
TTH1, TTH2 Tone THreshold is the OR of the signal pin TXT1 or TXT2

Current limit “I” SELect high and low bits for Channels 1 and 2

17

FN9190.2

August 10, 2007

Package Outline Drawing

www.BDTIC.com/Intersil

L40.6x6

40 LEAD QUAD FLAT NO-LEAD PLASTIC PACKAGE
Rev 3, 10/06

6.00

6

PIN 1

INDEX AREA

ISL6422

A

B

6.00

4X

4.5

0.50

36X

31

30

40

6

PIN #1 INDEX AREA

1

4 . 10 ± 0 . 15

(4X)

( 5 . 8 TYP )

( 4 . 10 )

0.15

TOP VIEW

TYPICAL RECOMMENDED LAND PATTERN

0 . 90 ± 0 . 1

( 36X 0 . 5 )

( 40X 0 . 23 )

( 40X 0 . 6 )

21

20

40X 0 . 4 ± 0 . 1

BOTTOM VIEW

SIDE VIEW

C

0 . 2 REF

0 . 00 MIN.
0 . 05 MAX.

DETAIL "X"

5

10

4

0 . 23 +0 . 07 / -0 . 05

SEE DETAIL "X"

C

0.10

BASE PLANE

SEATING PLANE

B0.1011MAC

C

0.08

C

NOTES:

Dimensions are in millimeters.1.
Dimensions in ( ) for Reference Only.

Dimensioning and tolerancing conform to AMSE Y14.5m-1994.

2.

3.

Unless otherwise specified, tolerance : Decimal ± 0.05
Dimension b applies to the metallized terminal and is measured

4.
between 0.15mm and 0.30mm from the terminal tip.

Tiebar shown (if present) is a non-functional feature.

5.

The configuration of the pin #1 identifier is optional, but must be

6.
located within the zone indicated. The pin #1 indentifier may be

either a mold or mark feature.

18

FN9190.2

August 10, 2007

ISL6422

www.BDTIC.com/Intersil

Thin Shrink Small Outline Exposed Pad Plastic Packages (EPTSSOP)

N

INDEX
AREA

123

TOP VIEW

0.05(0.002)

-A­D

e

b

0.10(0.004) C AM BS

123

N

P

BOTTOM VIEW

E1

E

-B-

SEATING PLANE

A

-C-

A1

M

P1

0.25(0.010) BM M

GAUGE
PLANE

0.25

0.010

α

0.10(0.004)

A2

M38.173B

38 LEAD THIN SHRINK SMALL OUTLINE PLASTIC PACKAGE

INCHES MILLIMETERS

SYMBOL

A - 0.047 - 1.20 -

L

c

A1 0.002 0.006 0.05 0.15 -

A2 0.031 0.051 0.80 1.05 -

b 0.0075 0.0106 0.17 0.27 9

c 0.0035 0.0079 0.09 0.20 -

D 0.378 0.386 9.60 9.80 3

E1 0.169 0.177 4.30 4.50 4

e 0.0197 BSC 0.500 BSC -

E 0.246 0.256 6.25 6.50 -

L 0.0177 0.0295 0.45 0.75 6

N38 387

o

α

P - 0.256 - 6.5 11

P1 -0.126-3.2 11

NOTES:

1. These package dimensions are within allowable dimensions of
JEDEC MO-153-BD-1, Issue F.

2. Dimensioning and tolerancing per ANSI Y14.5M-1982.

3. Dimension “D” does not include mold flash, protrusions or gate
burrs. Mold flash, protrusion and gate burrs shall not exceed

0.15mm (0.006 inch) per side.

4. Dimension “E1” does not include interlead flash or protrusions.
Interlead flash and protrusions shall not exceed 0.15mm (0.006
inch) per side.

5. The chamfer on the body is optional. If it is not present, a visual
index feature must be located within the crosshatched area.

6. “L” is the length of terminal for soldering to a substrate.

7. “N” is the number of terminal positions.

8. Terminal numbers are shown for reference only.

9. Dimension “b” does not include dambar protrusion. Allowable
dambar protrusion shall be 0.08mm (0.003 inch) total in excess
of “b” dimension at maximum material condition. Minimum
space between protrusion and adjacent lead is 0.07mm (0.0027
inch).

10. Controlling dimension: MILLIMETER. Converted inch dimen­sions are not necessarily exact. (Angles in degrees)

11. Dimensions “P” and “P1” are thermal and/or electrical enhanced
variations. Values shown are maximum size of exposed pad
within lead count and body size.

0

o

8

o

0

o

8

NOTESMIN MAX MIN MAX

-

Rev. 0 9/06

All Intersil U.S. products are manufactured, assembled and tested utilizing ISO9000 quality systems.

Intersil Corporation’s quality certifications can be viewed at www.intersil.com/design/quality

Intersil products are sold by description only. Intersil Corporation reserves the right to make changes in circuit design, software and/or specifications at any time without
notice. Accordingly, the reader is cautioned to verify that data sheets are current before placing orders. Information furnished by Intersil is believed to be accurate and
reliable. However, no responsibility is assumed by Intersil or its subsidiaries for its use; nor for any infringements of patents or other rights of third parties which may result
from its use. No license is granted by implic atio n or other wise u nde r any p a tent or patent rights of Intersil or its subsidiaries.

For information regarding Intersil Corporation and its products, see www.intersil.com

19

FN9190.2

August 10, 2007
