Intersil ISL39200C User Manual

Preliminary User manual

FCC ID: OSZ39200C1 Page 1 of 7

Intersil ISL39200C

IEEE 802.11a/g WLAN Cardbus32 Card

User Manual

Version 0.3

Preliminary User manual

FCC ID: OSZ39200C1 Page 2 of 7

Table of Contents

0-INTRODUCTION ....................................................................................................3

1-INSTALLATION PROCEDURE ...........................................................................3

1.1 INSTALLING THE CARDBUS32 CARD INTO THE ACCESS POINT .........................3

1.2 WIRELESS LAN INSTALLATION GUIDE LINES AND AUTHORIZATION FOR USE .4

2-REGULATORY INFORMATION......................................................................... 4

2.1 FCC INFORMATION TO USER .............................................................................4

2.2 FCC GUIDELINES FOR HUMAN EXPOSURE ........................................................4

2.3 FCC ELECTRONIC EMISSION NOTICES..............................................................4

2.4 FCC RADIO FREQUENCY INTERFERENCE STATEMENT.....................................5

2.5 EXPORT RESTRICTIONS .......................................................................................5

2.6 EUROPE - EU DECLARATION OF CONFORMITY.................................................6

3-TECHNICAL SPECIFICATIONS.........................................................................7

Preliminary User manual

FCC ID: OSZ39200C1 Page 3 of 7

0-Introduction

The Intersil ISL39200C WLAN NIC is a complete wireless high speed Network Interface Card (NIC).
It conforms to the IEEE 802.11g and IEEE 802.11a protocol and operates in the 2.45 GHz and
5150-5350MHz, 5470-5725MHz and 5725-5825 MHz frequency bands.

It provides a complete reference design evaluation platform of hardware and software to system
providers or integrators requiring wireless data communications capability and is ideal for integration
into Access Points.

• Fully compliant with the IEEE 802.11g and IEEE 802.11a WLAN standards

• FCC Certified Under Part 15 (pending) to Operate in the 2.45 GHz and 5150-5350MHz,
5725-5825 MHz Bands

• ETSI Certified Under RTTE directive (pending) to Operate in the 2.45 GHz and 5150-5350MHz,
5470-5725MHz and 5725-5825 MHz Bands

• Support for 54, 48, 36, 24, 18, 12, 9, and 6 Mbps OFDM, 11 and 5.5 Mbps CCK and legacy 2 and
1 Mbps data rates

This Cardbus card is only intended to be used in combination with the integrated firmware/drivers of
Access Points. The firmware in this Cardbus card will not allow an user to install this Cardbus card into
other devices than Access Points and/or use this Cardbus card in combination with other drivers than
those which are readily available in Access Points.

1-Installation procedure

1.1 Installing the Cardbus32 card into the Access Point

Turn the Access Point off and then insert Cardbus card into the Cardbus slot of the Access Point.
Further details of how to install the Cardbus card into the Access Point and how to configure the
Cardbus card for proper operation may be found in the installation manual of the Access Point.

CAUTION:
1-- This assembly is designed to operate with a supply voltage of 3.3V in Access Points supporting the
CARDBUS32 standard.

2-- Do not force engagement of the card in the CARDBUS32 slot. It is mechanically designed to prevent
improper insertion.
