Internode TG-789 Quick Setup Manual

TG-789 Broadband Gateway

Quick Setup Guide for NBN™ Fibre-to-the-Curb (FTTC)

2

Plug in for NBN™ FTTC

1. Using the power cable supplied, connect the Power port on the back of your

modem to your power outlet.

2. Using the Ethernet cable supplied, connect the red WAN port on the back of the

modem to the yellow GAT E WAY port on your NBN™ Connection Box.

3. If you wish to use your VoIP phone service, connect your phone handset to the

Phone1 port on the back of your modem.

4. Using an additional Ethernet cable, you can connect your computer to any of the 4

LAN ports on the back of your modem. Alternatively, follow the steps later in this
guide to connect WiFi devices such as computers, tablets and smartphones.

DSL LAN WAN Power

Port

Power

Button

ResetPhone

Before you get started...

If you received a new NBN™
Connection Box along with your
modem, please follow its setup
guide to get it plugged in and
turned on before you set up your
modem.

3

Plug in for NBN™ FTTC

GatewayWall Socket ResetPower

Power Socket Wall Socket

Power Cables

Phone Cable

Ethernet Cable

NBN™ Connection

Box

Ethernet Cable

Plug into yo ur computer’s

Ethernet Port (Optional)

Phone Cable

Handset (Optional)

4

Powering On Your Modem

Switch your modem on using the power button located on the back. By default, your
broadband settings should configure automatically once your NBN™ service is active and
your modem is powered on for 15 minutes.

1. The Internet light on the front of your modem should be green.

2. The Phone light on the front of your modem should be solid green if you have an

active VoIP phone service and a handset connected to the modem. See page 6 of
this guide for more details.

Is the internet light off?

Ensure that you received an email
from us advising that your NBN™
service is ACTIVE.

If you have, please turn to page
7 to log in to your modem’s
interface and enter the settings
manually.

If you haven’t received the email,
your NBN™ connection is not
ACTIVE yet. Please check your
last email from us for advice on
your connection appointment. It
will include a reference number
in case you need to call with any
concerns.
