Bulletin PD-2.256 rev. B 05/02
183NQ...(R) SERIES
SCHOTTKY RECTIFIER
Major Ratings and Characteristics
Characteristics 183NQ... Units
I
Rectangular 180 A
F(AV)
waveform
V
range 80 to 100 V
RRM
I
@ tp = 5 µs sine 22,000 A
FSM
VF@ 180Apk, TJ=125°C 0.75 V
TJrange - 55 to 175 °C
180 Amp
D-67
Description/ Features
The 183NQ high current Schottky rectifier module series has
been optimized for low reverse leakage at high temperature.
The proprietary barrier technology allows for reliable operation up to 175° C junction temperature. Typical applications
are in switching power supplies, converters, free-wheeling
diodes, and reverse battery protection.
175° C TJ operation
Unique high power, Half-Pak module
Replaces three parallel DO-5's
Easier to mount and lower profile than DO-5's
High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
Low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
183NQ100
Lug Terminal Anode
www.irf.com
Base Cathode
183NQ100R
Lug Terminal Cathode
Base Anode
Outline D-67 HALF PAK Module
Dimensions in millimeters and (inches)
1
183NQ...(R) Series
Bulletin PD-2.256 rev. B 05/02
Voltage Ratings
Part number 183NQ080 183NQ090 183NQ100
VRMax. DC Reverse Voltage (V)
V
Max. Working Peak Reverse Voltage (V)
RWM
80 90 100
Absolute Maximum Ratings
Parameters 183NQ Units Conditions
I
Max. Average Forward Current 180 A 50% duty cycle @ TC = 116° C, rectangular wave form
F(AV)
* See Fig. 5
I
Max. Peak One Cycle Non-Repetitive 22,000 5µs Sine or 3µs Rect. pulse
FSM
Surge Current * See Fig. 7 1550 10ms Sine or 6ms Rect. pulse
EASNon-Repetitive Avalanche Energy 15 mJ TJ = 25 °C, I
A
= 1 Amps, L = 30 mH
AS
IARRepetitive Avalanche Current 1 A Current decaying linearly to zero in 1 µsec
Frequency limited by T
J
Following any rated
load condition and
with rated V
RRM
max. VA = 1.5 x VR typical
applied
Electrical Specifications
Parameters 183NQ Units Conditions
VFMMax. Forward Voltage Drop (1) 0.95 V @ 180A
* See Fig. 1 1.14 V @ 360A
0.75 V @ 180A
0.89 V @ 360A
IRMMax. Reverse Leakage Current (1) 4.5 mA TJ = 25 °C
* See Fig. 2 60 mA TJ = 125 °C
CTMax. Junction Capacitance 4150 pF VR = 5VDC, (test signal range 100Khz to 1Mhz) 25 °C
LSTypical Series Inductance 6.0 nH From top of terminal hole to mounting plane
dv/dt Max. Voltage Rate of Change 10000 V/ µs
(Rated VR)
(1) Pulse Width < 300µs, Duty Cycle < 2%
TJ = 25 °C
TJ = 125 °C
VR = rated V
R
Thermal-Mechanical Specifications
Parameters 183NQ Units Conditions
TJMax. Junction Temperature Range -55 to 175 °C
T
Max. Storage Temperature Range -55 to 175 °C
stg
R
Max. Thermal Resistance Junction 0.30 °C/W DC operation * See Fig. 4
thJC
to Case
R
Typical Thermal Resistance, Case to 0.15 °C/W Mounting surface , smooth and greased
thCS
Heatsink
wt Approximate Weight 25.6 (0.9) g (oz.)
T Mounting Torque Min. 40 (35) Non-lubricated threads
Max. 58 (50)
Terminal Torque Min. 58 (50)
Max. 86 (75)
Case Style HALF PAK Module
2
Kg-cm
(Ibf-in)
www.irf.com
183NQ... Series
Bulletin PD-2.256 rev. B 05/02
1000
100
F
T = 175°C
J
T = 125°C
J
T = 25°C
10
Instantaneous Forward Current - I (A)
J
1000
R
Reverse Current - I (mA)
T = 175°C
J
100
10
1
.1
.01
.001
150°C
125°C
100°C
75°C
50°C
25°C
0 20406080100
Reverse Volt age - V (V)
Fig. 2 - Typical Values of Reverse Current
Vs. Reverse Voltage
10000
T
1000
T = 25°C
J
Junction Capacitance - C (pF)
R
1
0.2.4.6.811.21.4
Forward Vol tage Drop - V (V)
Fig. 1 - Maximum Forward Voltage Drop Characteristics
1
D = 0 .5 0
D = 0 .3 3
.1
thJC
Ther mal Impedance - Z (°C/W)
D = 0 .2 5
D = 0 .1 7
D = 0 .0 8
.01
Singl e Pulse
(Thermal Resi stance)
.001
.00001 .0001 .001 . 01 . 1 1 10 100
t , Rectangular Pulse Duration (Seconds)
1
Fig. 4 - Maximum Thermal Impedance Z
www.irf.com
100
0 102030405060708090100110
FM
Reverse Vol tage - V (V)
R
Fig. 3 - Typical Junction Capacitance
Vs. Reverse Voltage
P
DM
t
1
t
Not es:
1. Duty f actor D = t / t
2. Peak T = P x Z + T
Characteristics
thJC
2
1
2
JDMthJC
C
3
183NQ...(R) Series
Bulletin PD-2.256 rev. B 05/02
180
170
160
150
140
130
120
Al l owable Case Temperature - (°C)
110
0 40 80 120 160 200 240 280
Average Forward Curr ent - I (A)
183NQ
R (DC) = 0. 30°C/ W
thJC
DC
F(AV)
Fig. 5 - Maximum Allowable Case Temperature
Vs. Average Forward Current
100000
FSM
10000
Average Power Loss - (Watts)
At Any Rated Load Condition
And With Rated V Applied
Following Surge
RRM
200
D = 0 .0 8
175
D = 0 .1 7
D = 0 .2 5
150
D = 0 .3 3
D = 0 .5 0
125
100
RMS Li mit
75
50
25
0
0 40 80 120 160 200 240 280
Average Forward Current - I (A)
DC
F(AV)
Fig. 6 - Forward Power Loss Characteristics
Non-Repetitive Surge Current - I (A)
1000
10 100 1000 10000
Square Wave Pulse Duration - t (microsec)
p
Fig. 7 - Maximum Non-Repetitive Surge Current
L
HIGH-SPEED
DUT
CURRENT
MONITOR
IRFP460
Rg = 25 ohm
SW ITCH
FREE-WHEEL
DIOD E
40HFL40S02
Vd = 25 Volt
+
Fig. 8 - Unclamped Inductive Test Circuit
4
www.irf.com
183NQ... Series
Bulletin PD-2.256 rev. B 05/02
This product has been designed and qualified for Industrial Level.
Data and specifications subject to change without notice.
Qualification Standards can be found on IR's Web site.
IR WORLD HEADQUARTERS: 233 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105
TAC Fax: (310) 252-7309
Visit us at www.irf.com for sales contact information. 05/02
www.irf.com
5
