BANQUET SERVICE CARTS
“Queen Mary”
• Rugged Construction: All welded, 16-gauge,
300 Series, stainless steel unitized construction,
with 2" (51mm) hemmed edges.
• Control: Three-Point-Control Handle is designed
with the user in mind. Ergonomically designed
for pushing and pulling from both the side and
the front. Optional Swing-up handle provides
additional control and visibility when moving
the cart.
• Flexible: Available in 5- and 6-shelf
configurations with either flat or ledged shelves.
• Accessible: 91/2" (241mm) and 121/4" (311mm)
shelf spacing provides maximum access and
storage on shelves.
• Maneuverability: Large 8" (203mm) casters
provide optimal rollability. Optional swivel-lock
caster system allows the cart to be moved inand-out-of-line without dragging. Rigid casters
can be made to swivel for movement in tight
spaces and automatically switch back to rigid
when needed for moving down halls.
• Versatile: Can be used for banquet service,
bussing, general back-of-the-house
transportation, and mobile storage.
• Durable: Wraparound bumper is non-marking
and will protect the cart, wall, and equipment
from damage.
Item # ______________________________________________
Item # ______________________________________________
Job ________________________________________________
Job ________________________________________________
MQ-609L
(Shown with optional swing-up handle)
Banquet Service Carts — “Queen Mary”
InterMetro Industries Corporation
North Washington Street
Wilkes-Barre, PA 18705
www.metro.com
12.50
Page 2
Job ________________________________________________Job ________________________________________________
65.750
63.625
1.500
9.500
57.441
MQ-609L
MQ-609F
30.625
24.441
63.625
12.250
1.500
57.441
MQ-512L
MQ-512F
57.441
24.441
30.625
24.441
12.50
BANQUET SERVICE CARTS
Specifications
Construction: Welded, hemmed, stainless
steel construction.
Material: Polished, 300 Series stainless steel.
Shelves: 16-gauge stainless steel with 2" (51mm)
hemmed edge. Each shelf is 24" (610mm) wide x
57" (1447mm) long (usable space).
Uprights: 11-gauge stainless steel.
Casters: Four 8" (203mm) polyurethane casters.
Two rigid, two swivel with brakes.
Handle: Unique Three-Point-Control Handle.
1" (25mm) diameter stainless steel construction.
Bumper: Non-marking, solid vinyl bumper mounted
to 1/8" (3.1mm) thick aluminum support channel with
closed corners.
Load Rating: 200 Ibs. (91kg) equally distributed
per shelf; 1,000 Ibs. (455kg) per cart.
(Shown with optional swing-up handle)
Dimensions
Approx.
Length/Width/Height Pkd. Wt.
Cat. No. Description (in.) (mm) (lbs.) (kg)
MQ-512F Five Shelves — Flat 63.625x30.625x65.75 1616x778x1670 300 136
MQ-609F Six Shelves — Flat 63.625x30.625x65.75 1616x778x1670 325 147
MQ-512L Five Shelves — Ledged* 63.625x30.625x65.75 1616x778x1670 300 136
MQ-609L Six Shelves — Ledged* 63.625x30.625x65.75 1616x778x1670 325 147
*Top shelf is flat.
For swivel lock caster upgrade, add “-SL” to the part number. Example: MQ-609F-SL.
For swing-up handle, add “-H” to the part number. Example: MQ-609F-H.
Add “-SL-H” for both.
Banquet Service Carts — “Queen Mary”
All Metro Catalog Sheets are available on our Web Site: www.metro.com
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA 18705
Phone: 570-825-2741 • Fax: 570-825-2852
For Product Information Call: 1-800-433-2232
Printed in U.S.A. 5/08
Information and specifications are subject to change
without notice. Please confirm at time of order.
Copyright © 2008 InterMetro Industries Corp.
