User’s Manual

700 Series Color Mobile Computer

User’s Manual

700 Series Color Mobile Computer

S NOTICE The information contained herein is proprietary and is provided solely for the purpose of allowing

customers to operate and service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.

DisclaimerofWarranties.Thesamplesourcecodeincludedinthisdocumentispresentedfor reference only. The code does not necessarily represent complete, tested programs. The code is provided “ASISWITHALLFAULTS.”ALLWARRANTIESAREEXPRESSLY

DISCLAIMED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

We welcome your comments concerning this publication. Although every effort has been made to keep it free of errors, some may occur. When reporting a specific problem, please describe it briefly and include the book title and part number, as well as the paragraph or figure number and thepagenumber.

Send your comments to: Intermec Technologies Corporation Publications Department 550 Second Street SE Cedar Rapids, IA 52401

ANTARES, INTERMEC, NORAND, NOR*WARE, PEN*KEY, ROUTEPOWER, TRAKKER, and TRAKKER ANTARES are registered trademarks and ArciTech, ENTERPRISE WIRELESS LAN, i-gistics, INCA, Mobile Framework, MobileLAN, TE 2000, UAP, and UNIVERSAL ACCESS POINT are trademarks of Intermec Technologies Corporation.

Acknowledgments

ActiveSync, ActiveX, Microsoft, MS, MS-DOS, Outlook, Pocket Outlook, Pocket PC, Windows, Windows NT,andtheWindows logo are registered trademarks and MSDN, SQL Server, Visual Basic, Visual C++,andWindows for Pen are trademarks of Microsoft Corporation in the United

States and/or other countries. Microsoft products are licensed to OEMs by Microsoft Licensing, Inc., a wholly owned subsidiary of Microsoft Corporation.

Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A.

CDMA2000 is a trademark of the Telecommunications Industry Association (TIA).

GSM is a registered trademark of the GSM Association.

Microclean II is a registered trademark of Foresight International.

MultiMediaCard is a trademark of Infineon Technologies AG, Germany, and is licensed to

MMCA (MultiMediaCard Association).

SanDisk is a trademark of SanDisk Corporation.

Siemens is a registered trademark of Siemens AG. Siemens product names are either trademarks or

registered trademarks of Siemens or Siemens AG.

This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://www.openssl.org/)

This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)

Contents

Before You Begin xv....................................................................

Introduction

Contents

Warranty Information xv...................................................

Safety Summary xv........................................................

Warnings, Cautions, and Notes xvi...........................................

About This Manual xvi....................................................

Format Conventions for Input From a Keyboard or Keypad xvii......................

Related Publications xviii...................................................

Global Services and Support xviii.............................................

Web Support xviii........................................................

About the 700 Series Color Mobile Computer 2...............................................

Audio System 2...........................................................

Speaker 2...................................................

Internal Microphone 2........................................

External Headset Jack 2........................................

Battery 2................................................................

Low Battery Shutdown 3.......................................

System Status Maintained 4....................................

CAB Files Within 700C Software Tools CD 4...................................

Modem Support 4.........................................................

Network Support 4........................................................

Removeable Card Support 5.................................................

CompactFlash Cards 5........................................

SecureDigital Cards 5.........................................

MultiMediaCards 5...........................................

Software Build V ersion 5....................................................

What’ s New 6.........................................................................

iii700 Series Color Mobile Computer User’s Manual

Contents

Pocket PC 2002

Introduction 8.........................................................................

Premium versus Professional Editions 8......................................................

Where to Find Information 10............................................................

Basic Skills 11.........................................................................

Buttons and Stylus 11......................................................

Today Screen 11..........................................................

Programs 13.............................................................

Navigation Bar and Command Bar 14.........................................

Pop-up Menus 15.........................................................

Notifications 15..........................................................

Enter Information on Your 700 Series Computer 16...............................

Typing With the Soft Keyboard 17...............................

Using Block Recognizer 17.....................................

Using Letter Recognizer 18.....................................

Using Transcriber 18..........................................

Selecting Typed Text 18........................................

Writing on the Screen 19....................................................

Selecting the Writing 19.......................................

Converting Writing to Text 20..................................

Drawing on the Screen 22...................................................

Creating a Drawing 22........................................

Selecting a Drawing 22........................................

Recording a Message 23....................................................

Creating a Recording 23.......................................

Using My Text 24.........................................................

Finding and Organizing Information 25........................................

Customizing Your 700 Series Computer 26......................................

Adjusting Settings 26.........................................

Adding or Removing Programs 26................................

Microsoft ActiveSync 29.................................................................

Microsoft Pocket Outlook 31.............................................................

Calendar: Scheduling Appointments and Meetings 31.............................

Creating an Appointment 32....................................

Using the Summary Screen 33..................................

Creating Meeting Requests 33...................................

Scheduling a Meeting 33.......................................

Contacts: Tracking Friends and Colleagues 34...................................

Creating a Contact 34.........................................

Finding a Contact 35.........................................

Using the Summary Screen 36..................................

Tasks: Keeping a To Do List 37...............................................

Creating a Task 38...........................................

Using the Summary Screen 39..................................

Notes: Capturing Thoughts and Ideas 40.......................................

Creating a Note 41...........................................

iv 700 Series Color Mobile Computer User’s Manual

Contents

Inbox: Sending and Receiving E-mail Messages 42................................

Synchronizing E-mail Messages 42...............................

Connecting Directly to an E-mail Server 42........................

Using the Message List 43......................................

Composing Messages 45.......................................

Managing E-mail Messages and Folders 46.........................

Folder Behavior With a Direct Connection to an E-mail Server 46.......

Companion Programs 47................................................................

Pocket Word 47...........................................................

Creating a Document 47.......................................

Typ i ng Mo d e 49.............................................

Writing Mode 50............................................

Drawing Mode 51............................................

Recording Mode 51...........................................

Pocket Excel 52...........................................................

Creating a Workbook 52.......................................

Tips for Working in Pocket Excel 53..............................

MSN Messenger 53........................................................

Setting Up 54...............................................

Working with Contacts 54.....................................

Chatting with Contacts 55.....................................

Windows Media Player for Pocket PC 57.......................................

Microsoft Reader 58.......................................................

Getting Books on Your 700 Series Computer 58.....................

Using the Library 59..........................................

Reading a Book 60...........................................

Using Reader Features 61......................................

Removing a Book 61..........................................

Pocket Internet Explorer 62...............................................................

The Mobile Favorites Folder 62...............................................

Favorite Links 62..........................................................

Mobile Favorites 62........................................................

Using AvantGo Channels 64.................................................

Using Pocket Internet Explorer 65.............................................

Viewing Mobile Favorites and Channels 66........................

Browsing the Internet 66.......................................

Getting Connected 67...................................................................

Transferring Items Using Infrared 67...........................................

Sending Information 67.......................................

Receiving Information 67......................................

Connecting to an Internet Service Provider 68...................................

Creating a Modem Connection to an ISP 68.......................

Creating an Ethernet Connection to an ISP 69......................

Connecting to Work 70.....................................................

Creating a Modem Connection to Work 70........................

Creating an Ethernet Connection to Work 71.......................

Ending a Connection 72....................................................

Connecting Directly to an E-mail Server 72.....................................

Setting Up an E-mail Service 73..............................................

v700 Series Color Mobile Computer User’s Manual

Contents

Installing Applications

Packaging an Application 76..............................................................

Installing Applications 76................................................................

Using Microsoft ActiveSync 77...............................................

Using the FTP Server 78....................................................

Using the Application Manager in Unit Manager 78...............................

Using a Storage Card 78....................................................

Copying to a CompactFlash Card 78.............................

Copying to a SecureDigital Storage Card 79........................

Updating the System Software 79..........................................................

Application Migration 80................................................................

Cabinet File Installation 82...............................................................

Network Support

CORE 84............................................................................

Network Adapters 85...................................................................

Ethernet Communications 86................................................

802.11b Communications 87................................................

Profiles 87..................................................

Import/Export 96............................................

Scan List 97.................................................

Network Selection APIs 98.....................................

Function Summary 101.......................................

802.11b Radio CORE Module 107..............................

WWAN Radio Options 110.................................................

GSM/GPRS 110.............................................

CDMA/1xRTT SB555 110....................................

WAN Radio CORE Module 111................................

AT Command Interface 115....................................

Wireless Printing 120......................................................

Documentation 120..........................................

Bluealps CORE Module 120....................................

AutoIP/DHCP 122.....................................................................

SNMP Configuration 123................................................................

The Focus was “Simple” 123.................................................

Using SNMP 123.........................................................

Retrieval of Management Information 124......................................

An Early Approach to Getting More than One Item at a Time 124...................

Conclusion 124...........................................................

SNMP Configuration on the 700 Series Computer 125............................

Management Information Base 125..............................

Object Identifiers 126.........................................

Configuring with SNMP 126...................................

vi 700 Series Color Mobile Computer User’s Manual

Printer Support

Contents

Printing ASCII 128.....................................................................

Directly to a Port 128......................................................

Directly to a Generic Serial Port 128...........................................

IrDA Printer Driver 128.................................................................

NPCP Printer Driver 129................................................................

About NPCP 129.........................................................

NPCP Driver Installation and Removal 129.....................................

Opening the NPCP Driver 130..............................................

Closing the NPCP Driver 130...............................................

Reading from the NPCP Driver 130...........................................

Writing to the NPCP Driver 130.............................................

NPCP Driver I/O Controls 131..............................................

NPCP Printer Communications 132...........................................

Sample Code 132.........................................................

NPCP Error Codes 133....................................................

O’ Neil Printer Driver 134...............................................................

DTR Driver Installation and Removal 134......................................

Opening the DTR Driver 135...............................................

Closing the DTR Driver 135................................................

Writing to the DTR Driver 135..............................................

DTR Printer Communications 135............................................

Scanner Support

Scanner Control and Data Transfer 138.....................................................

Automatic Data Collection COM Interfaces 138..............................................

Multiple ADC COM Object Support 139......................................

How to Create and Use the ADC COM Interfaces 140............................

Read-Ahead Bar Code Data Access 140............................

Grid Data Filtering 141........................................

Filter Expression Values 142....................................

Editing Expression Values 144..................................

ADC Connection 145.........................................

2D Imager Overview 146...................................................

Data Collection Features 146...................................

Image Acquisition Features 147..................................

Create and Delete ADC COM Object Functions 149.............................

ITCDeviceOpen 149.........................................

ITCDeviceClose 150..........................................

vii700 Series Color Mobile Computer User’s Manual

Contents

IADC Functions 151......................................................

IADC::CancelReadRequest 152.................................

IADC::Initialize 153..........................................

IADC::QueryAttribute 154....................................

IADC::QueryData 155........................................

IADC::Read 156.............................................

IADC::SetAttribute 157.......................................

IBarCodeReaderControl Functions 159........................................

IBarCodeReaderControl::CancelReadRequest 160...................

IBarCodeReaderControl::ControlLED 161.........................

IBarCodeReaderControl::Initialize 162............................

IBarCodeReaderControl::IssueBeep 163...........................

IBarCodeReaderControl::QueryAttribute 164.......................

IBarCodeReaderControl::Read 165...............................

IBarCodeReaderControl::SetAttribute 167.........................

IBarCodeReaderControl::TriggerScanner 171.......................

IS9CConfig Functions 172..................................................

IS9CConfig::GetCodabar 173...................................

IS9CConfig::SetCodabar 174...................................

Codabar Default Settings 175...................................

Codabar Enumerations 175....................................

IS9CConfig::GetCode39 176...................................

IS9CConfig::SetCode39 177....................................

Code 39 Default Settings 177...................................

Code 39 Enumerations 178....................................

IS9CConfig::GetCode93 179...................................

IS9CConfig::SetCode93 179....................................

Code 93 Default Settings 179...................................

Code 93 Enumerations 180....................................

IS9CConfig::GetCode128 180..................................

IS9CConfig::SetCode128 181...................................

Code 128/EAN 128 Default Settings 181..........................

Code 128 Enumerations 182...................................

IS9CConfig::GetI2of5 183.....................................

IS9CConfig::SetI2of5 184......................................

Interleaved 2 of 5 Default Settings 184............................

Interleaved 2 of 5 Enumerations 185..............................

IS9CConfig::GetMatrix2of5 185................................

IS9CConfig::SetMatrix2of5 186.................................

Matrix 2 of 5 Default Settings 186...............................

Matrix 2 of 5 Enumerations 186.................................

IS9CConfig::GetMSI 187......................................

IS9CConfig::SetMSI 187......................................

MSI Default Settings 187......................................

MSI Enumerations 188........................................

IS9CConfig::GetPDF417 188..................................

IS9CConfig::SetPDF417 189...................................

PDF 417 Default Settings 190..................................

PDF 417 Enumerations 190....................................

IS9CConfig::GetPlessey 192....................................

IS9CConfig::SetPlessey 192....................................

Plessey Default Settings 193....................................

Plessey Enumerations 193......................................

IS9CConfig::GetStandard2of5 194...............................

IS9CConfig::SetStandard2of5 195...............................

viii 700 Series Color Mobile Computer User’s Manual

Contents

Standard 2 of 5 Default Settings 196..............................

Standard 2 of 5 Enumerations 196...............................

IS9CConfig::GetTelepen 197...................................

IS9CConfig::SetTelepen 197....................................

Telepen Default Settings 197....................................

Telepen Enumerations 198.....................................

IS9CConfig::GetUpcEan 198...................................

IS9CConfig::SetUpcEan 200...................................

UPC/EAN Default Settings 201.................................

UPC/EAN Enumerations 201...................................

IS9CConfig2 Functions 204.................................................

IS9CConfig2::GetCode11 205..................................

IS9CConfig2::SetCode11 205...................................

Code 11 Default Settings 206...................................

Code 11 Enumerations 206....................................

IS9CConfig2::GetCustomSymIds 207............................

IS9CConfig2::SetCustomSymIds 208.............................

Custom Identifier Assignments 209..............................

Custom Identifier Default Settings 210............................

Custom Identifier Example 210.................................

IS9CConfig2::GetGlobalAmble 211..............................

IS9CConfig2::SetGlobalAmble 212..............................

Postamble and Preamble Defaults 212.............................

IS9CConfig2::GetPDF417Ext 213...............................

IS9CConfig2::SetPDF417Ext 213...............................

PDF 417 Extended: Micro PDF 417 Default Settings 214.............

IS9CConfig2::GetSymIdXmit 214...............................

IS9CConfig2::SetSymIdXmit 214................................

Symbology ID Transmission Option 215..........................

IS9CConfig3 Functions 216.................................................

ISCP Commands 216.........................................

ISCP::GetConfig 217.........................................

ISCP::SetConfig 218..........................................

AIM Symbology ID Defaults 219.............................................

IImage Interface 221....................................................................

IImage::ReadSigCapBuffer 221...............................................

IImage::ReadSigCapFile 224.................................................

IImage::ReadImage 225....................................................

IImage::CancelReadImage 226...............................................

IImage::Start 226.........................................................

IImage::Stop 227..........................................................

IImage::Open 227.........................................................

IImage::Close 228.........................................................

Data Collection Configuration 229.........................................................

ix700 Series Color Mobile Computer User’s Manual

Contents

Tethered Scanner 230...................................................................

Enabling and Disabling 230.................................................

Changing Comm Settings 231...............................................

Tethered Scanner 231.........................................

Sabre 1551E or 1553 Tethered Scanner 232........................

Welch Allyn 1470 Imager Settings 232............................

Error Message 232.........................................................

Scanner Cabling 232...................................................

Limitations and Capabilities 233..........................................

Programming

Creating CAB Files 236.................................................................

Creating Device-Specific CAB Files 236........................................

Creating an .INF File 236......................................

Sample .INF File 245.........................................

Using Installation Functions in SETUP.DLL 248.................................

After the CAB File Extraction 248............................................

Creating CAB Files with CAB Wizard 249......................................

Troubleshooting the CAB Wizard 250.........................................

FTP Server 251........................................................................

Configurable Parameters Via the Registry Editor 252..............................

BlockSize 252...............................................

DeviceName 253.............................................

DeviceURL 253.............................................

IDNATarget 254.............................................

ManifestName 254...........................................

PauseAtStartup 255...........................................

Root 255...................................................

Transferring Files Over TCP/IP Networks 256...................................

Stopping the FTP Server from Your Application 260...............................

Autostart FTP 260........................................................

Full Screen 262........................................................................

Kernel I/O Controls 264.................................................................

IOCTL_HAL_GET_DEVICE_INFO 264.....................................

IOCTL_HAL_ITC_READ_PARM 265.......................................

IOCTL_HAL_ITC_WRITE_SYSPARM 270...................................

IOCTL_HAL_GET_DEVICEID 272.........................................

IOCTL_HAL_GET_OAL_VERINFO 273.....................................

IOCTL_HAL_GET_BOOTLOADER_VERINFO 274...........................

IOCTL_HAL_WARMBOOT 275............................................

IOCTL_HAL_COLDBOOT 275............................................

IOCTL_HAL_GET_RESET_INFO 276.......................................

IOCTL_HAL_GET_BOOT_DEVICE 277.....................................

IOCTL_HAL_REBOOT 278...............................................

IOCTL_PROCESSOR_INFORMATION 279..................................

IOCTL_GET_CPU_ID 280................................................

x 700 Series Color Mobile Computer User’s Manual

Contents

Reboot Functions 280...................................................................

IOCTL_HAL_REBOOT 280...............................................

IOCTL_HAL_COLDBOOT 280............................................

IOCTL_HAL_WARMBOOT 280............................................

Remapping the Keypad 281..............................................................

Unshifted Plane 281.......................................................

Gold Plane 281...........................................................

Alpha Plane 281..........................................................

Key Values 282...........................................................

How Key Values Are Stored in Registry 282.....................................

Change Notification 283....................................................

Advanced Keypad Remapping 283............................................

Scan Codes 283...........................................................

Sample View of Registry Keys 284............................................

Control Panel Applets

Configuration Parameters 286.............................................................

Changing a Parameter Setting 286............................................

About Configuration Parameters 287..........................................

Data Collection Control Panel Applet 288...................................................

Symbologies 289..........................................................

Code 39 290................................................

Standard 2 of 5 291...........................................

Codabar 292................................................

UPC/EAN 293..............................................

Code 93 294................................................

Code 128 295...............................................

Plessey 298.................................................

MSI 299...................................................

PDF 417 300...............................................

Interleaved 2 of 5 303.........................................

Matrix 2 of 5 304............................................

Telepen 305.................................................

Code 11 306................................................

QR Code 307...............................................

Data Matrix 308.............................................

Symbology Options 309....................................................

Symbology ID 309...........................................

Prefix 315..................................................

Suffix 316..................................................

Beeper/LED 317..........................................................

Beeper Volume 318...........................................

Beeper Frequency 320.........................................

Good Read Beeps 321.........................................

Good Read Beep Duration 322..................................

Imager 323..............................................................

Aimer LED duration 323......................................

Image Dimension 324.........................................

xi700 Series Color Mobile Computer User’s Manual

Contents

Virtual Wedge 325........................................................

Virtual Wedge 325...........................................

Preamble 326...............................................

Postamble 327...............................................

Grid 328...................................................

Code Page 329..............................................

SNMP Control Panel Applet 330..........................................................

Security 331.............................................................

Read Only Community 331....................................

Read/Write Community 332....................................

Read Encryption 333.........................................

Write Encryption 334.........................................

Encryption Key 335..........................................

Tr a p s 336...............................................................

Authentication 336...........................................

Threshold 337...............................................

Identification 338.........................................................

Contact 338................................................

Name 339..................................................

Location 340................................................

Unit Information Control Panel Applet 341..................................................

Versions 342.............................................................

Battery Status 343.........................................................

CAB Files 344............................................................

Unit Manager

Data Collection 348....................................................................

Symbologies 348..........................................................

Symbology ID 349........................................................

Beeper/LED 349..........................................................

Imager 350..............................................................

Virtual Wedge 350........................................................

SNMP 350...........................................................................

Security 350.............................................................

Tr a p s 351...............................................................

Identification 351.........................................................

Unit 352.............................................................................

Date/Time 352...........................................................

Backlight Timeout 353.....................................................

Key Clicks 354...........................................................

Automatic Shutoff 355.....................................................

Volume 356..............................................................

Using Reader Commands 357.............................................................

Change Configuration 357..................................................

Set Time and Date 358.....................................................

xii 700 Series Color Mobile Computer User’s Manual

Bar Codes

Contents

Bar Code Symbologies 360...............................................................

UPC 362................................................................

EAN 362................................................................

Codabar 362.............................................................

Code 11 363.............................................................

Code 39 363.............................................................

Encoded Code 39 (Concatenation) 363........................................

Encoded Code 39 (Full ASCII) 363...........................................

Code 93 364.............................................................

Code 128 364............................................................

I 2 of 5 (Interleaved) 366...................................................

S2of5(Standard2of5) 366................................................

Plessey 367..............................................................

MSI Code (Variant of Plessey) 367............................................

Bar Code Labels 368....................................................................

Audio Volume 368........................................................

Automatic Shutoff 369.....................................................

Backlight Timeout 369.....................................................

Key Clicks 370...........................................................

Virtual Wedge Grid, Preamble, Postamble 371...................................

Grid 371...................................................

Preamble 371...............................................

Postamble 371...............................................

Index

Classes and Functions 374...............................................................

General Index 377......................................................................

Files Index 398........................................................................

xiii700 Series Color Mobile Computer User’s Manual

Contents

xiv 700 Series Color Mobile Computer User’s Manual

Before You Begin

Warranty Information

Safety Summary

Before You Begin

This section introduces you to standard warranty provisions, safety precautions, warnings and cautions, document formatting conventions, and sources of additional product information. A documentation roadmap is also provided to guide you in finding the appropriate information.

To receive a copy of the standard warranty provision for this product, contact your local Intermec support services organization. In the U.S. call 1-800-755-5505, and in Canada call 1-800-668-7043. If you live outside of the U.S. or Canada, you can find your local Intermec support services organization on the Intermec Web site at www.intermec.com.

Note: Opening this product may void the warranty. The internal workings of this product can only be accessed by Intermec service personnel. Radio replacements and upgrades require Intermec service personnel.

Your safety is extremely important. Follow these guidelines:

S Read and follow all warnings and c autions in this book before handling

and operating Intermec equipment. You can be seriously injured, and equipment and data can be damaged if you do no follow the safety warnings and cautions.

S Do not repair or adjust energized equipment alone under any circum-

stances. Someone capable of providing f irst aid must always be present foryoursafety.

S Always obtain first aid or medical attention immediately after an injury.

Never neglect an injury, no matter how slight it seems.

S Begin resuscitation immediately if someone is injured and stops breath-

ing. Any delay could result in death. To work on or near high voltage, you should be familiar with approved industrial first aid methods.

S Never work on energized equipment unless authorized by a responsible

authority. Energized electrical equipment is dangerous. Electrical shock from energized equipment can cause death. If you must perform authorized emergency work on energized equipment, be sure that you comply strictly with approved safety regulations.

xv700 Series Color Mobile Computer User’s Manual

Before You Begin

Warnings, Cautions, and Notes

The warnings, cautions, and notes in this manual use this format:

A warning alerts you of an operating procedure, practice, condition, or statement that must be strictly observed to avoid death or serious injury to the persons working on the equipment.

Attention D anger: Un avertissement vous avertit d’une procédure de fonctionnement, d’une méthode, d’un état ou d’un rapport qui doit être strictement respecté pour éviter l’occurrence de mort ou de blessures graves aux personnes manupulant l’équipement.

A caution alerts you to an operating procedure, practice, condition, or statement that must be strictly observed to prevent equipment damage or destruction, or corruption or loss of data.

Attention: Une précaution vous avertit d’une procédure de fonctionnement, d’une méthode, d’un état ou d’un rapport qui doit être strictement respecté pour empêcher l’endommagement ou la destruction de l’équipement, ou l’altération ou la perte de données.

About This Manual

Note: Notes are statements that either provide extra information about a topic or contain special instructions for handling a particular condition or set of circumstances.

The 700 Series Color Mobile Computer User’ s Manual provides you with information about the features of the 700 Series Color Mobile Computer and how to configure, troubleshoot, and support it. You must be familiar with your host PC, your network, and your other Intermec equipment.

S Chapter 1 — Introduction

Introduces the 700 Series Color Mobile Computer.

S Chapter 2 — Pocket PC 2002

Introduces the Pocket PC 2002 operating system from Microsoft Corporation, and explains how to use its Outlook, ActiveSync, Internet Explorer, and other companion programs.

S Chapter 3 — Installing Applications

Provides methods to install applications and CAB files, also covers application migration.

S Chapter 4 — Network Support

Introduces the CORE application, network adapters such as Ethernet,

802.11b radios, GSM/GPRS or CDMA/1xRTT embedded radio modules, and wireless printing equipped with a Bluetooth module, SNMP configuration, and Network Selection APIs.

S Chapter 5 — Printer Support

Provides information on printing ASCII to either a port or to a generic serial port, and on working with IrDA, NPCP, and O’ Neil printer drivers.

xvi 700 Series Color Mobile Computer User’s Manual

Before You Begin

S Chapter 6 — Scanner Support

Provides Automatic Data Collection COM and IImage interfaces and lists settings via Data Collection parameters.

S Chapter 7 — Programming

Programming information that includes creating CAB files, the FTP Server, Full Screen, Kernel I/O Control Functions, Reboot Functions, and remapping the keypad.

S Appendix A — Control Panel Applets

Contains detailed information about the Data Collection, SNMP, and Unit Information control panel applets.

S Appendix B — Unit Manager

Describes how to configure some parameters via the Unit Manager application and includes reader commands.

S Appendix C — Bar Codes

Describes some of the more common bar code symbologies and includes bar code labels that can be scanned to configure your 700 Series Computer.

Format Conventions for Input From a Keyboard or Keypad

This table describes the formatting conventions for input from PC or host computer keyboards and device keypads.

Format Conventions

Convention Description

text

Special

Italic text Indicates a variable that you must replace the parameter with a value.

text

Bold

where This word introduces a list of parameters and explains the values you

Shows the command as you should enter it into the device.

Indicates the keys you must press on a PC or host computer keyboard. For example, “press “Enter” on the PC or host computer keyboard.

can specify for them.

Enter

” means you press the key labeled

xvii700 Series Color Mobile Computer User’s Manual

Before You Begin

Related Publications

To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. Following are related Inter mec manuals, CD-ROMs, and part numbers (P/N). For other versions and languages, consult your Intermec sales representative.

S 700 Series Color Mobile Computer Quick Start Guide

(P/N: 962-054-053)

S 700 Color Recovery CD PPC 2002 Professional Edition WWE

(P/N: 235-100-001 Kit)

S 700 Color Recovery CD PPC 2002 Premium Edition WWE

(P/N: 235-101-001 Kit)

S 700 Series Color Software Tools CD (P/N: 235-099-001)

S Windows 95 and Windows CE Configuration Utilities Reference Manual

(P/N: 978-054-010)

Global Services and Support

Web Support

Select any of the following services available from Intermec Technologies Corporation:

S Factory Repair and On-site Repair

To request a return authorization number for one of our authorized service centers, or to request an on-site repair technician, call 1-800-755-5505, then select option 1.

S Technical Support

For technical support on your Intermec product, call 1-800-755-5505, then select option 2.

S Service Contract Status

To inquire about an existing contract, or to renew a contract, call 1-800-755-5505, then select option 3.

S Schedule Site Surveys or Installations

To schedule a site survey, or to request a product or system installation, call 1-800-755-5505, then select option 4.

Visit our Web site at http://www.intermec.com to download many of our current manuals in PDF format.

Visit our technical knowledge base (Knowledge Central) at http://intermec.custhelp.com to review technical information or to request technical help for all Intermec products.

xviii 700 Series Color Mobile Computer User’s Manual

Introduction

This chapter introduces the 700 Series Color (700C) Mobile Computer, developed by Intermec Technologies Corporation to enhance wireless connectivity needs.

1700 Series Color Mobile Computer User’s Manual

IntroductionChapter —1

About the 700 Series Color Mobile Computer

Battery

The 700 Series Computer comes equipped with a nominal 14.4 Watt-hour, 7.2V (two 2000 mAh cells), replaceable Lithium-Ion (LiIon) battery. To view the status of this battery from the 700 Series Computer, tap Start → Settings → the System tab → the Power icon to view the current status of both the main battery and the backup battery. Tap ok to exit this information.

2 700 Series Color Mobile Computer User’s Manual

Introduction—Chapter 1

Note: The Unit Information control panel applet is only available in the 700 Series Computer if Intermec Content is enabled, the Plus region is enabled and installed, and a laser scanner is installed.

You can also view the battery status for the 700 Series Computer by accessing the Unit Information control panel applet. Tap the Unit Information icon, then tap the Battery Status tab to view the current status. Tap ok to exit this information.

Low Battery Shutdown

If your computer shuts down because of low battery conditions, your computer will not operate. This is done to ensure that data is protected. Although the battery will protect the data against loss for several hours, you should connect your computer to a power source when you first detect a low battery condition.

Your computer contains an internal super capacitor, a temporary power storage device, that protects data for up to ten minutes. This is to give you time to replace the main battery pack before that data is lost. Be sure to put

the computer in a suspend mode before doing so.

The battery power fail level is set so that after the system shuts down in a low battery condition, there is still sufficient charge to allow the unit to remain configured, keep proper time, and maintain DRAM (Dynamic Random Access Memory) for at least 72 hours at room temperature if the main battery remains in the mobile computer. The configuration and time are lost if:

S The battery discharges beyond this level.

S The battery is removed when the computer is not in suspend mode.

S A cold reset is performed on the computer.

3700 Series Color Mobile Computer User’s Manual

IntroductionChapter —1

System Status Maintained

System status is maintained in “suspend” when the main battery is removed:

S 10 minutes for 64 MB low-power chips

S 5 minutes for 128 MB low-power chips

CAB Files Within 700C Software Tools CD

If you leave the default destination while you install the “\700 Color Mgmt Tools” directory onto your desktop PC, then “C:\Intermec\Intermec 700 Color Mgmt Tools\Cab Files” will be the default directory. There are folders within the “\Cab Files” directory that contain demos and program files. See the 700 Series Color Software Tools CD User’ s Manual for more information about these files.

Modem Support

Modem PC Cards are not supported by the 700 Series Computer. However, modem options do include the following:

Network Support

S Switchable dock that includes a built-in modem and a serial port be-

tween which an application can switch.

S Mini-Landline Modem that can be tethered to the port on the bottom

of the 700 Series Computer.

S Other external modems that may be connected to the bottom of the

700 Series Computer or to the dock.

Radio CompactFlash Cards cannot be installed by a user. The 700 Series Computer must be serviced to install or replace radios. See Chapter 4, “Network Support” for more information.

S 802.11b radio

S Integrated GSM/GPRS radio

S CDPM/1xRTT radio

S Wireless printing equipped with a Bluetooth qualified module by Socket

Communications

4 700 Series Color Mobile Computer User’s Manual

Removeable Card Support

To access either the CompactFlash (CF) or SecureDigital (SD) card slot, locate the access door at the top of the 700 Series Computer, remove its two screws, then remove the door.

CompactFlash Cards

Support is limited to one CompactFlash (CF) Storage Card in the 700 Series Computer, either for storage or for the 802.11b radio.

SecureDigital Cards

Support is limited to one SecureDigital (SD) Storage Card in the 700 Series Computer for storage.

MultiMediaCards

MultiMediaCards (MMCs) are not supported in the 700 Series Computers because current technology shows that SD cards will quickly surpass MMC cards in storage capacity.

Introduction—Chapter 1

Software Build Version

To check to see if your 700 Series Computer has the latest build, select Start → Internet Explorer → the Intermec logo.

The latest software build version is displayed beneath the Patent Informa- tion title. This information will be useful should you need customer assistance.

5700 Series Color Mobile Computer User’s Manual

IntroductionChapter —1

You c an also view the latest software build version on your 700 Series Computer by accessing the Unit Information control panel applet. Select

Start → Settings → the System tab → the Unit Information icon → the Versions tab to view the current build version on your 700 Series

Computer.

What’s New

The newest functionality is available in software build versions 1.30 or greater. The following changes have occurred since the last release of this manual:

S Applied new publications standards to this manual.

S Adapted instructions using Ethernet connections to fit Intermec require-

ments in Chapter 2, “Pocket PC 2002.”

S Moved “Updating System Software” and “EFlash” information to the Re-

covery CD User’ s Manual from Chapter 3, “Installing Applications.”

S Removed several 802.11 APIs not related to the 700 Series Color Com-

puter from Chapter 4, “Network Support.”

S Added the Siemens MC45 radio module to Chapter 4, “Network Sup-

port.”

S Added tethered scanner information to Chapter 6, “Scanner Support.”

S Added CAB extraction information and FTP Server parameters to

Chapter 7, “Programming.”

S Added imager option information via the Data Collection control panel

applet to Appendix A, “Control Panel Applets.” Note that this is for 700

Series Computers using an imager.

6 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002

This chapter introduces the Pocket PC 2002 operating system from Microsoft Corporation.

7700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Introduction

Congratulations on purchasing a Pocket PC. Due to the size and capabilities of this 700 Series Color Mobile Computer, you can keep your most important business and personal information up-to-date and close at hand. Microsoft ActiveSync increases the power of your 700 Series Computer by allowing you to synchronize the information on your desktop or laptop computer with your 700 Series Computer. Picture yourself in the following situations:

S A Calendar reminder alerts you that it is time to catch the bus. You grab

your 700 Color Pocket PC Mobile Computer and catch the bus just in time. Because ActiveSync keeps the information on your 700 Series Computer up-to-date, you leisurely review your task list, make notes about the new books and CDs you want to buy, and read and respond to e-mail messages. When you get back to the office, ActiveSync transfers any task changes you made, your notes, and your e-mail message responses to your desktop computer. For more information on ActiveSync, see “Microsoft ActiveSync” on page 29.

S While walking with a colleague, your 700 Color Pocket PC Mobile

Computer rings. You look at the caller ID and see it is your manager who is calling. She asks if you two are free this afternoon for an emergency meeting. While your colleague fumbles through his paper organizer, you press a button on your 700 Series Computer and instantly see a list of today’ s appointments and meetings. You are quickly able to tell your manager your available times, and make a note of the new meeting while on the call. You hang up, send an e-mail with a schedule request for the three of you at the desired location. For more information on scheduling appointments and meetings, see “Microsoft Pocket Outlook” on page 31.

S You are meeting your friends tonight for dinner and a movie. You

download the latest movie information from the Internet to your desktop computer and then synchronize it with your 700 Series Computer. At dinner, you pull out your 700 Color Pocket PC Mobile Computer and review your movie options with your friends. For more information on downloading Web pages to your 700 Series Computer, see “Pocket Internet Explorer” on page 62.

Premium versus Professional Editions

Your 700 Series Computer will have either the Premium Edition or the Professional Edition of Pocket PC 2002. Do the following to determine which edition of Pocket PC 2002 is on your unit.

1 Select Start → Internet Explorer → the Intermec logo.

8 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

2 Note the “Software Build” information displayed beneath the Version

Information title.

Note: If you have an older software build, your unit may say either

“PREM” (which indicates the Premium Edition) or “PRO” (which indicates the Professional Edition).

3 Tap t he Close icon in the top right corner to exit the Internet Explorer.

Below is a list of components for each edition of Pocket PC 2002:

Premium

Component

Microsoft ActiveSync Client (page 29) XX

Microsoft Pocket Outlook (page 31) X X

Pocket Word (page 47) XX

Pocket Excel (page 52) X X

MSN Messenger (page 53) X

Windows Media Player for Pocket PC (page 57) X RAM

Microsoft Reader (page 58) XRAM

Pocket Internet Explorer (page 62) X X

Edition

Professional Edition

Note: Components marked with “RAM” are provided on a Companion CD for download into RAM rather than burned into Flash ROM.

9700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Where to Find Information

This chapter describes your 700 Series Computer hardware, provides an overview of the programs on your 700 Series Computer, and explains how to connect your 700 Series Computer to a desktop computer, a network, or the Internet. For instructions on setting up your 700 Series Computer and installing ActiveSync, see the Quick Start Card. The following is a guide to more information to assist you use your 700 Series Computer.

For information on: See this source:

Programs on your mobile computer. This chapter and mobile computer Help. To view Help,

tap

Start → Help

Additional programs that can be installed on the mobile computer.

Connecting to and synchronizing with a desktop com puter.

Last-minute updates and detailed technical information. The Read Me files, located in the Microsoft ActiveSync

Up-to-date information on your Pocket PC. http://www.microsoft.com/mobile/pocketpc

The Pocket PC Companion CD.

The Quick Start Card or AutoSync Help on your desktop computer. To view Help, click

veSync Help

folder on the desktop computer and on the Pocket PC Companion CD.

Help → Microsoft Acti-

Pocket PC and many of the technologies supported by the 700 Series Computer are not from Intermec Technologies. Many of the utilities and features on a Pocket PC device come directly from Microsoft without any modification from Intermec Technologies. There may be certain Microsoft-specific issues that Intermec Technologies would not be able to support, so you will have to contact Microsoft Corporation. Use these URLs to determine your Microsoft support options:

S http://msdn.microsoft.com/support/

S http://support.microsoft.com/

S news://news.microsoft.com (a free support option)

10 700 Series Color Mobile Computer User’s Manual

Basic Skills

Buttons and Stylus

Pocket PC 2002—Chapter 2

Learning to use your 700 Series Computer is easy. This describes the basic concepts of using and customizing your 700 Series Computer.

Your 700 Series Computer has hardware buttons that control actions and scroll functions, and a stylus for selecting items and entering information. On the 700 Series Computer, the stylus replaces the mouse.

S Tap:

Touch the screen once with the stylus to open items and select options.

S Drag:

Hold the stylus on the screen and drag across the screen to select text and images. Drag in a list to select multiple items.

S Tap and hold:

Tap and hold the stylus on an item to see a list of actions available for that item. On the pop-up menu that appears, tap the action to be performed.

Today Screen

When you turn on your 700 Series Computer for the first time each day (or after four hours of inactivity), you will see the Today screen. You can also display it by tapping the Start flag (shown left) and then Today.On the Today screen, you can see at a glance important information for the day.

11700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Following are some of the status icons you may see:

Status Icon Meaning:

Turns all sounds on and off.

Backup battery is low.

Main batteries are charging.

Main batteries are low.

Main batteries are very low.

Main batteries are full.

Connection is active.

Synchronization is beginning or ending.

Synchronization is occurring.

Notification or one or more instant messages received.

Notification of one or more e-mail messages received.

If more notification icons need to be displayed than there is room to display them, the Notification icon (shown left) will display. Tap the icon to view all notification icons.

12 700 Series Color Mobile Computer User’s Manual

Programs

Pocket PC 2002—Chapter 2

You can switch from one program to another by selecting it from the Start menu. (You can customize which programs you see on this menu. For information, see “Adjusting Settings” on page 26.) To access some programs, tap Start→Programs, and then the program name.

You can also switch to some programs by pressing a program button. Your 700 Series Computer has one or more program buttons located on the front or side of the computer. The icons on the buttons identify the programs to which they switch.

Note: Some programs have abbreviated labels for check boxes and dropdown menus. To see the full spelling of an abbreviated label, tap and hold the stylus on the label. Drag the stylus off the label so that the command is not carried out.

The following is a partial list of programs that are on your 700 Series Computer. Look on the Pocket PC Companion CD for additional programs that you can install onto your 700 Series Computer.

ActiveSync

Synchronize information between your 700 Series Computer and desktop computer .

Calendar

Keep track of your appointments and create meeting requests.

Contacts

Keep track of your friends and colleagues.

Inbox

Send and receive e-mail messages.

Pocket Internet Explorer

Browse Web and WAP (Wireless Application Protocol) sites, and download new programs and files from the Internet.

Notes

Create handwritten or typed notes, drawings, and recordings.

Tasks

Keep track of your tasks.

Pocket Excel

Create new workbooks or view and edit Excel workbooks created on your desktop computer.

MSN Messenger

Send and receive instant messages with your MSN Messenger contacts.

Pocket Word

Create new documents or view and edit Word documents created on your desktop computer.

13700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Navigation Bar and Command Bar

The navigation bar is located at the top of the screen. It displays the active program and current time, and allows you to switch to programs and close screens.

Use the command bar at the bottom of the screen to perform tasks in programs. The command bar includes menu names, buttons, and the Input Panel button. To create a new item in the current program, tap New.To see the name of a button, tap and hold the stylus on the button. Drag the stylus off the button so that the command is not carried out.

14 700 Series Color Mobile Computer User’s Manual

Pop-up Menus

Pocket PC 2002—Chapter 2

With pop-up menus, you can quickly choose an action for an item. For example, you can use the pop-up menu in the contact list to quickly delete a contact, make a copy of a contact, or send an e-mail message to a contact. The actions in the pop-up menus vary from program to program. To access a pop-up menu, tap and hold the stylus on the item name that you want to perform the action on. When the menu appears, lift the stylus, and tap the action you want to perform. Or tap anywhere outside the menu to close the menu without performing an action.

Notifications

Your 700 Series Computer reminds you in a variety of ways when you have something to do. For example, if you have set up an appointment in Calendar, a task with a due date in Tasks, or an alarm in Clock, you will be notified in any of the following ways:

S A message box appears on the screen.

S A sound, which you can specify, is played.

S A light flashes on your 700 Series Computer.

S A vibrator resonates from the 700 Series Computer.

To choose reminder types and sounds for your 700 Series Computer, tap Start→Settings→the Personal tab→Sounds & Notifications. The options you choose here apply throughout the 700 Series Computer.

15700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Enter Information on Your 700 Series Computer

You have several options for entering new information:

S Use the input panel to enter typed text, either by using the soft key-

board or other input method.

S Write directly on the screen.

S Draw pictures on the screen.

S Speak into your 700 Series Computer microphone to record a message.

S Use Microsoft ActiveSync to synchronize or copy information from

your desktop computer to your 700 Series Computer. For more information on ActiveSync, see ActiveSync Help on your desktop computer.

Use the input panel to enter information in any program on your 700 Series Computer. You can either type using the soft keyboard or write using Block Recognizer, Letter Recognizer,orTranscriber. In either case, the characters appear as typed text on the screen.

To show or hide the input panel, tap the Input Panel button. Tap the arrow next to the Input Panel button to see your choices.

16 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

When you use the input panel, your 700 Series Computer anticipates the word you are typing or writing and displays it above the input panel. When you tap the displayed word, it is inserted into your text at the insertion point. The more you use your 700 Series Computer, the more words it learns to anticipate.

Note: To change word suggestion options, such as the number of words suggested at one time, tap Start → Settings → the Personal tab → Input → the Word Completion tab.

Typing With the Soft Keyboard

1 Tap the arrow next to the Input Panel button, and then Keyboard.

2 On the soft keyboard that is displayed, tap the keys with your stylus.

Using Block Recognizer

With Block Recognizer, you can input character strokes using the stylus that are similar to those used on other 700 Series Computers.

1 Tap the arrow next to the Input Panel button, then Block Recognizer.

2 Write a letter in the box.

When you write a letter, it is converted to typed text that appears on the screen. For specific instructions on using Block Recognizer, with Block Recognizer open, tap the question mark next to the writing area.

17700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Using Letter Recognizer

With Letter Recognizer, you can write letters using the stylus just as you would on paper.

1 Tap the arrow next to the Input Panel button, then Letter Recognizer .

2 Write a letter in the box.

When you write a letter, it is converted to typed text that appears on the screen. For specific instructions on using Letter Recognizer, with Letter Recognizer open, tap the question mark next to the writing area.

Using Transcriber

With Transcriber, you can write anywhere on the screen using the stylus just as you would on paper. Unlike Letter Recognizer and Block Recognizer, you can write a sentence or more of information. Then, pause and let Transcriber change the written characters to typed characters.

1 Tap the arrow next to the Input Panel button, and then Transcriber.

2 Write anywhere on the screen.

For specific instructions on using Transcriber, with Transcriber open, tap the question mark in the lower right hand corner of the screen.

Selecting Typed Text

If you want to edit or format typed text, you must select it first.

S Drag the stylus across the text you want to select.

You can cut, copy, and paste text by tapping and holding the selected words and then tapping an editing command on the pop-up menu, or by tapping the command on the Edit menu.

18 700 Series Color Mobile Computer User’s Manual

Writing on the Screen

Pocket PC 2002—Chapter 2

In any program that accepts writing, such as the Notes program, and in the Notes tab in Calendar, Contacts, and Tasks, you can use your stylus to write directly on the screen. Write the way you do on paper. You can edit and format what you have written and convert the information to text at a later time.

S Tap t he Pen button to switch to writing mode. This action displays lines

on the screen to help you write.

Note: Some programs that accept writing may not have the Pen button. See the documentation for that program to find out how to switch to writing mode.

Selecting the Writing

If you want to edit or format writing, you must select it first.

1 Tap and hold the stylus next to the text you want to select until the in-

sertion point appears.

2 Without lifting, drag the stylus across the text you want to select.

If you accidentally write on the screen, tap Tools→Undo and try again. You can also select text by tapping the Pen button to deselect it and then dragging the stylus across the screen.

You can cut, copy, and paste written text in the same way you work with typed text: tap and hold the selected words and then tap an editing command on the pop-up menu, or tap the command on the Edit menu.

19700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Converting Writing to Text

S Tap Tools→Recognize.

If you want to convert only certain words, select them before tapping Rec- ognize on the Tools menu (or tap and hold the selected words and then tap Recognize on the pop-up menu). If a word is not recognized, it is left as writing.

20 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

If the conversion is incorrect, you can select different words from a list of alternates or return to the original writing. To do so, tap and hold the incorrect word (tap one word at a time). On the pop-up menu, tap Alterna- tes. A menu with a list of alternate words appears. Tap the word you want to use, or tap the writing at the top of the menu to return to the original writing.

Tips for getting good recognition:

S Write neatly.

S Write on the lines and draw descenders below the line. Write the cross

of the “t” and apostrophes below the top line so that they are not confused with the word above. Write periods and commas above the line.

S For better recognition, try increasing the zoom level to 300% using the

Tools menu.

S Write the letters of a word closely and leave big gaps between words so

that the 700 Series Computer can easily tell where words begin and end.

S Hyphenated words, foreign words that use special characters such as ac-

cents, and some punctuation cannot be converted.

S If you add writing to a word to change it (such as changing a “3” to an

“8”) after you attempt to recognize the word, the writing you add will not be included if you attempt to recognize the writing again.

21700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Drawing on the Screen

You c an draw on the screen in the same way that you write on the screen. The difference between writing and drawing on the screen is how you select items and how they can be edited. For example, selected drawings can be resized, while writing cannot.

Creating a Drawing

S Cross three ruled lines on your first stroke. A drawing box appears. Sub-

sequent strokes in or touching the drawing box become part of the drawing. Drawings that do not cross three ruled lines will be treated as writing.

Note: You may want to change the zoom level so that you can more easily work on or view your drawing. Tap Tools and then a zoom level.

Selecting a Drawing

If you want to edit or format a drawing, you must select it first.

S Tap and hold the stylus on the drawing until the selection handle ap-

pears. To select multiple drawings, deselect the Pen button and then drag to select the drawings you want.

You can cut, copy, and paste selected drawings by tapping and holding the selected drawing and then tapping an editing command on the pop-up menu, or by tapping the command on the Edit menu. To resize a drawing, make sure the Pen button is not selected, and drag a selection handle.

22 700 Series Color Mobile Computer User’s Manual

Recording a Message

Pocket PC 2002—Chapter 2

In any program where you can write or draw on the screen, you can also quickly capture thoughts, reminders, and phone numbers by recording a message. In Calendar, Tasks, and Contacts, you can include a recording in the Notes tab. In the Notes program, you can create a stand-alone recording or include a recording in a written note. If you want to include the recording in a note, open the note first. In the Inbox program, you can add a recording to an e-mail message.

Creating a Recording

1 Hold your computer’ s microphone near your mouth or source of

sound.

2 Press and hold the Record hardware button on your 700 Series Com-

puter until you hear a beep.

3 While holding down the Record button, make your recording.

4 To stop recording, release the Record button. Two beeps will sound.

The new recording appears in the note list or as an embedded icon.

Note: You can also make a recording by tapping the Record button on the Recording toolbar.

To play a recording, tap it in the list or tap its icon in the note.

23700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Using My Text

When using Inbox or MSN Messenger, use My Text to quickly insert preset or frequently used messages into the text entry area. To insert a message, tap My Text and tap a message.

Note: You can add text after inserting a My Text message before sending it.

To edit a My Text message, in the Tools menu, tap Edit→My Text Messages. Select the message you wish to edit and make desired changes.

24 700 Series Color Mobile Computer User’s Manual

Finding and Organizing Information

The Find feature on your 700 Series Computer helps you quickly locate information.

Tap Start → Find. Enter the text you want to find, select a data type, and then tap Go to initiate the search.

Note: To quickly find information that is taking up storage space on your 700 Series Computer, select Larger than 64 KB in Type.

You can also use the File Explorer to find files on your 700 Series Computer and to organize these files into folders. Tap Start → Programs→File Explorer.

Pocket PC 2002—Chapter 2

Note: You can move files in File Explorer by tapping and holding the item you want to move, and then tapping Cut or Copy and Paste on the popup menu.

25700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Customizing Your 700 Series Computer

You can customize your 700 Series Computer by adjusting settings and installing additional software.

Adjusting Settings

You can adjust settings to suit the way you work. To see available options, tap Start→Settings→either the Personal tab or the System tab located at the bottom of the screen. You might want to adjust the following:

S Clock:

To change the time or to set alarms.

S Menus:

To customize what appears on the Start menu, and to enable a pop-up menu from the New button.

S Owner Information:

To enter your contact information.

S Password:

To limit access to your 700 Series Computer.

S Power:

To maximize battery life.

S Today:

To customize the look and information displayed on the Today screen.

Adding or Removing Programs

Programs added to your 700 Series Computer at the factory are stored in ROM (Read Only Memory). You cannot remove this software, and you will never accidentally lose ROM contents. ROM programs can be updated using special installation programs with a *.XIP extension. All other programs and data files added to your 700 Series Computer after factory installation are stored in RAM (Random Access Memory).

You can install any program created for your 700 Series Computer, as long as your 700 Series Computer has enough memory. The most popular place to find software for your 700 Series Computer is on the Pocket PC Web site (http://www.microsoft.com/mobile/pocketpc ).

Adding Programs Using ActiveSync

You will need to install the appropriate software for your 700 Series Computer on your desktop computer before installing it on your 700 Series Computer.

1 Determine your 700 Series Computer and processor type so that you

know which version of the software to install. Tap Start→Settings the System tab→About→the Version tab, then make a note of the information in Processor.

2 Download the program to your desktop computer (or insert the CD or

disk that contains the program into your desktop computer). You may see a single *.XIP, *.EXE, or *.ZIP file, a SETUP.EXE file, or several versions of files for different 700 Series Computer types and processors. Be sure to select the program designed for the Pocket PC and your 700 Series Computer processor type.

→

26 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

3 Read any installation instructions, Read Me files, or documentation that

comes with the program. Many programs provide special installation instructions.

4 Connect your 700 Series Computer and desktop computer.

5 Double-click the *.EXE file.

S If the file is an installer, the installation wizard will begin. Follow the

directions on the screen. Once the software has been installed on your desktop computer, the installer will automatically transfer the software to your 700 Series Computer.

S If the file is not an installer, you will see a n error message stating that

the program is valid but it is designed for a different type of computer. You will need to move this file to your 700 Series Computer. If you cannot find any installation instructions for the program in the Read Me file or documentation, use ActiveSync Explore to copy the program file to the Program Files folder on your 700 Series Computer. For more information on copying files using ActiveSync, see Acti- veSync Help.

Once installation is complete, tap Start→Programs, and then the program icon to switch to it.

Adding a Program Directly from the Internet

1 Determine your 700 Series Computer and processor type so that you

know which version of the software to install. Tap Start→Settings the System tab→About→the Version tab, then make a note of the information in Processor.

2 Download the program to your 700 Series Computer straight from the

Internet using Pocket Internet Explorer. You may see a single *.XIP, *.EXE, or *.ZIP file, a SETUP.EXE file, or several versions of files for different 700 Series Computer types and processors. Be sure to select the program designed for the Pocket PC and your 700 Series Computer processor type.

3 Read any installation instructions, Read Me files, or documentation that

comes with the program. Many programs provide installation instructions.

4 Tap the file, such as a *.XIP or *.EXE file. The installation wizard will

begin. Follow the directions on the screen.

→

27700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Adding a Program to the Start Menu

Tap Start→Settings→Menus→the Start Menu tab, and then the check box for the program. If you do not see the program listed, you can either use File Explorer on the 700 Series Computer to move the program to the Start Menu folder, or use ActiveSync on the desktop computer to create a shortcut to the program and place the shortcut in the Start Menu folder.

S Using File Explorer on the 700 Series Computer:

Tap Start→Programs→File Explorer, and locate the program (tap the folder list, labeled My Documents by default, and then My Device to see a list of all folders on the 700 Series Computer). Tap and hold the program and tap Cut on the pop-up menu. Open the Start Menu folder located in the Windows folder, tap and hold a blank area of the window, and tap Paste on the pop-up menu. The program will now appear on the Start menu. For more information on using File Explorer, see “Finding and Organizing Information” on page 25.

S Using ActiveSync on the desktop computer:

Use the Explorer in ActiveSync to explore your 700 Series Computer files and locate the program. Right-click the program, and then click Create Shortcut. Move the shortcut to the Start Menu folder in the Windows folder. The shortcut now appears on the Start menu. For more information, see ActiveSync Help.

Removing Programs

S Tap Start→Settings→the System tab→Remove Programs.

If the program does not appear in the list of installed programs, use File Explorer on your 700 Series Computer to locate the program, tap and hold the program, and then tap Delete on the pop-up menu.

28 700 Series Color Mobile Computer User’s Manual

Microsoft ActiveSync

Visit the following Microsoft Web site for the latest in updates, technical information, and samples:

S http://www.microsoft.com/mobile/pocketpc/downloads/activesync.asp

Using Microsoft ActiveSync, you can synchronize the information on your desktop computer with the information on your 700 Series Computer. Synchronization compares the data on your 700 Series Computer with your desktop computer and updates both computers with the most recent information. For example:

S Keep Pocket Outlook data up-to-date by synchronizing your 700 Series

Computer with Microsoft Outlook data on your desktop computer.

S Synchronize Microsoft Word and Microsoft Excel files between your

700 Series Computer and desktop computer. Your files are automatically converted to the correct format

Note: By default, ActiveSync does not automatically synchronize all types of information. Use ActiveSync options to turn synchronization on and off for specific information types.

Pocket PC 2002—Chapter 2

With ActiveSync, you can also:

S Back up and restore your 700 Series Computer data.

S Copy (rather than synchronize) files between your 700 Series Computer

and desktop computer.

S Control when synchronization occurs by selecting a synchronization

mode. For example, you can synchronize continually while connected to your desktop computer or only when you choose the synchronize command.

S Select which information types are synchronized and control how much

data is synchronized. For example, you can choose how many weeks of past appointments you want synchronized.

Before you begin synchronization, install ActiveSync on your desktop computer from the Pocket PC Companion CD. For more information on installing ActiveSync, see your Quick Start card. ActiveSync is already installed on your 700 Series Computer.

After installation is complete, the ActiveSync Setup Wizard helps you connect your 700 Series Computer to your desktop computer, set up a partnership so you can synchronize information between your 700 Series Computer and your desktop computer, and customize your synchronization settings. Your first synchronization process will automatically begin when you finish using the wizard.

After your first synchronization, take a look at Calendar, Contacts, and Tasks on your 700 Series Computer. You will notice that information you have stored in Microsoft Outlook on your desktop computer has been copied to your 700 Series Computer, and you did not have to type a word. Disconnect your 700 Series Computer from your computer and you are ready to go!

29700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Once you have set up ActiveSync and completed the first synchronization process, you can initiate synchronization from your 700 Series Computer. To switch to ActiveSync on your 700 Series Computer, tap Start

→

ActiveSync. Note that if you have a wireless LAN card, you can synchronize remotely from your 700 Series Computer.

For information about using ActiveSync on your desktop computer, start ActiveSync on your desktop computer, and then see ActiveSync Help.

For more information about ActiveSync on your 700 Series Computer, switch to ActiveSync, then tap Start→Help.

30 700 Series Color Mobile Computer User’s Manual

Microsoft Pocket Outlook

Note: The Professional Edition of Microsoft Pocket Outlook does not include a spell checker.

Microsoft Pocket Outlook includes Calendar, Contacts, Tasks, Inbox, and Notes. You can use these programs individually or together. For example, e-mail addresses stored in Contacts can be used to address e-mail messages in Inbox.

Using ActiveSync, you can synchronize information in Microsoft Outlook or Microsoft Exchange on your desktop computer with your 700 Series Computer. You can also synchronize this information directly with a Microsoft Exchange server. Each time you synchronize, ActiveSync compares the changes you made on your 700 Series Computer and desktop computer or server and updates both computers with the latest information. For information on using ActiveSync, see ActiveSync Help on the desktop computer.

You can switch to any of these programs by tapping them on the Start menu.

Pocket PC 2002—Chapter 2

Calendar: Scheduling Appointments and Meetings

Use Calendar to schedule appointments, including meetings and other events. You can check your appointments in one of several views (Agenda, Day, Week, Month, and Year) and easily switch views by using the View menu.

31700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Note: You can customize the Calendar display, such as changing the first day of the week, by tapping Options on the Tools menu.

Creating an Appointment

1 If you are in Day or Week view, tap the desired date and time for the

appointment.

2 Tap New.

3 Using the input panel, enter a description and a location. Tap f irst to

select the field.

4 If needed, tap the date and time to change them.

5 Enter other desired information. You will need to hide the input panel

to see all available fields.

6 To add notes, tap the Notes tab. You can enter text, draw, or create a

recording. For more information on creating notes, see “Notes: Capturing Thoughts and Ideas” on page 40.

7 When finished, tap OK to return to the calendar.

Note:IfyouselectRemind me in an appointment, your 700 Series Com-

puter will remind you according to the options set in Start → Settings → the Personal tab → Sounds & Reminders.

32 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Using the Summary Screen

When you tap an appointment in Calendar, a summary screen is displayed. To change the appointment, tap Edit.

Creating Meeting Requests

You can use Calendar to set up meetings with users of Outlook or Pocket Outlook. The meeting request will be created automatically and sent either when you synchronize Inbox or when you connect to your e-mail server. Indicate how you want meeting requests sent by tapping Tools → Options. If you send and receive e-mail messages through ActiveSync, select ActiveSync.

Scheduling a Meeting

1 Create an appointment.

2 In the appointment details, hide the input panel, and then tap

Attendees.

3 From the list of e-mail addresses you have entered in Contacts, select the

meeting attendees.

The meeting notice is created automatically and placed in the Outbox folder.

For more information on sending and receiving meeting requests, see Calendar Help and Inbox Help on the 700 Series Computer.

33700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Contacts: Tracking Friends and Colleagues

Contacts maintains a list of your friends and colleagues so that you can easily find the information you are looking for, whether you are at home or on the road. Using the 700 Series Computer infrared (IR) port, you can quickly share Contacts information with other 700 Series Computer users.

Note: To change the way information is displayed in the list, tap Tools → Options.

Creating a Contact

1 Tap New.

2 Using the input panel, enter a name and other contact information. You

will need to scroll down to see all available fields.

3 To assign the contact to a category, scroll to and tap Categories and se-

lect a category from the list. In the contact list, you can display contacts by category.

4 To add notes, tap the Notes tab. You can enter text, draw, or create a

recording. For more information on creating notes, see “Notes: Capturing Thoughts and Ideas” on page 40.

34 700 Series Color Mobile Computer User’s Manual

5 When finished, tap OK to return to the contact list.

Pocket PC 2002—Chapter 2

Finding a Contact

There are four ways to find a contact:

S In the contact list, enter a contact name in the box under the navigation

bar. To show all contacts again, clear text from the box or tap the button to the right of the box.

S In the contact list, tap the category list (labeled All Contacts by default)

and select the type of contact that you want displayed. To show all contacts again, select All Contacts. To view a contact not assigned to a category, select None.

S To view the names of companies your contacts work for, in the contact

list, tap View → By Company. The number of contacts that work for that company will be displayed to the right of the company name.

S Tap Start → Find, enter the contact name, select Contacts for the type,

and then tap Go.

35700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Using the Summary Screen

When you tap a contact in the contact list, a summary screen is displayed. To change the contact information, tap Edit .

36 700 Series Color Mobile Computer User’s Manual

Tasks: Keeping a To Do List

Use Tasks to keep track of what you have to do.

Pocket PC 2002—Chapter 2

Note: To change the way information is displayed in the list, tap Tools → Options.

37700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Creating a Task

1 Tap New.

2 Using the input panel, enter a description.

3 You can enter a start date and due date or enter other information by

first tapping the field. If the input panel is open, you will need to hide it to see all available fields.

4 To assign the task to a category, tap Categories and select a category

from the list. In the task list, you can display tasks by category.

5 To add notes, tap the Notes tab. You can enter text, draw, or create a

recording. For more information on creating notes, see “Notes: Capturing Thoughts and Ideas” on page 40.

6 When finished, tap OK to return to the task list.

Note: To quickly create a task with only a subject, tap Entry Bar on the Tools menu. Then, tap Tap here to add a new task and enter your task

information.

38 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Using the Summary Screen

When you tap a task in the task list, a summary screen is displayed. To change the task, tap Edit.

39700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Notes: Capturing Thoughts and Ideas

Quickly capture thoughts, reminders, ideas, drawings, and phone numbers with Notes. You can create a written note or a recording. You can also include a recording in a note. If a note is open when you create the recording, it will be included in the note as an icon. If the note list is displayed, it will be created as a stand-alone recording.

40 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Creating a Note

1 Tap New.

2 Create your note by writing, drawing, typing, and recording. For more

information about using the input panel, writing and drawing on the screen, and creating recordings, see “Basic Skills” on page 11.

41700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Inbox: Sending and Receiving E-mail Messages

Use Inbox to send and receive e-mail messages in either of these ways:

S Synchronize e-mail messages with Microsoft Exchange or Microsoft

Outlook on your desktop computer.

S Send and receive e-mail messages by connecting directly to an e-mail

server through an Internet Service Provider (ISP) or a network.

Synchronizing E-mail Messages

E-mail messages can be synchronized as part of the general synchronization process. You will need to enable Inbox synchronization in ActiveSync. For information on enabling Inbox synchronization, see ActiveSync Help on the desktop computer. During synchronization:

S Messages are copied from the mail folders of Exchange or Outlook on

your desktop computer to the ActiveSync folder in Inbox on your 700 Series Computer. By default, you will receive messages from the past three days only, the first 100 lines of each message, and file attachments of less than 100 KB in size.

S E-mail messages in the Outbox folder on your 700 Series Computer are

transferred to Exchange or Outlook, and then sent from those programs.

S E-mail messages in subfolders must be s elected in ActiveSync on your

desktop computer in order to be transferred.

Connecting Directly to an E-mail Server

In addition to synchronizing e-mail messages with your desktop computer, you can send and receive e-mail messages by connecting to an e-mail server using a modem or network card connected to your 700 Series Computer. You will need to set up a remote connection to a network or an ISP, and a connection to your e-mail server. For more information, see “Getting Con- nected” on page 67.

When you connect to the e-mail server, new messages are downloaded to the 700 Series Computer Inbox folder, messages in the 700 Series Computer Outbox folder are sent, and messages that have been deleted on the e-mail server are removed from the 700 Series Computer Inbox folder.

Messages that you receive directly from an e-mail server are linked to your e-mail server rather than your desktop computer. When you delete a message on your 700 Series Computer, it is also deleted from the e-mail server the next time you connect based on the settings selected in ActiveSync.

You can work online or offline. When working online, you read and respond to messages while connected to the e-mail server. Messages are sent as soon as you tap Send , which saves space on your 700 Series Computer.

When working offline, once you have downloaded new message headers or partial messages, you can disconnect from the e-mail server and then decide which messages to download completely. The next time you connect, Inbox downloads the complete messages you have marked for retrieval and sends the messages you have composed.

42 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Using the Message List

Messages you receive are displayed in the message list. By default, the most recently received messages are displayed first in the list.

43700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

When you receive a message, tap it to open it. Unread messages are displayed in bold.

When you connect to your e -mail server or synchronize with your desktop computer, by default, you will receive messages from the last five days only, the first 100 lines of each new message, and file attachments of less than 100 KB in size. The original messages remain on the e-mail server or your desktop computer.

You can mark the messages that you want to retrieve in full during your next synchronization or e-mail server connection. In the message list, tap and hold the message you want to retrieve. On the pop-up menu, tap Mark for Download. The icons in the Inbox message list give you visual indications of message status.

You specify your downloading preferences when you set up the service or select your synchronization options. You can change them at any time:

S Change options for Inbox synchronization using ActiveSync options.

For more information, see ActiveSync Help.

S Change options for direct e-mail server connections in Inbox on your

700 Series Computer. Tap Tools → Options → the Service tab, then tap the service you want to change. Tap and hold the service and select Delete to remove a service.

44 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Composing Messages

To compose a message:

1 Tap New.

2 In the To field, enter an e-mail or SMS address of one or more recipi-

ents, separating them with a semicolon, or select a name from the contact list by tapping the Address Book button. All e-mail addresses entered in the e-mail fields in Contacts appear in the Address Book.

3 Compose your message. To enter preset or frequently used messages, tap

My Text and select a message.

4 Tap Send when you have finished the message. If you are working of-

fline, the message is moved to the Outbox folder and will be sent the next time you connect.

If you are sending an SMS message and want to know if it was received, tap Edit → Options → Request SMS text message delivery notification before sending the message.

45700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Managing E-mail Messages and Folders

By default, messages are displayed in one of five folders for each service you have created: Inbox, Deleted Items, Drafts, Outbox, and Sent Items. The Deleted Items folder contains messages that have been deleted on the 700 Series Computer. The behavior of the Deleted and Sent Items folders depends on the options you have chosen. In the message list, tap Tools → Options → the Message tab, then select your options.

If you want to organize messages into additional folders, tap Tools → Manage Folders to create new folders. To move a message to another folder, in the message list, tap and hold the message and then tap Move to on the pop-up menu.

Folder Behavior With a Direct Connection to an E-mail Server

The behavior of the folders you create depends on whether you are using ActiveSync, SMS, POP3, or IMAP4.

S If you use ActiveSync :

E-mail messages in the Inbox folder in Outlook will automatically be synchronized with your 700 Series Computer. You can select to synchronize additional folders by designating them for ActiveSync. The folders you create and the messages you move will then be mirrored on the server. For example, if you move two messages from the Inbox folder to a folder named Family, and you have designated Family for synchronization, the server creates a copy of the Family folder and copies the messages into that folder. You can then read the messages while away from your desktop computer.

S If you use SMS:

Messages are stored in the Inbox folder.

S If you use POP3:

and you move e-mail messages to a folder you created, the link is broken between the messages on the 700 Series Computer and their copies on the mail server. The next time you connect, the mail server will see that the messages are missing from the 700 Series Computer Inbox and delete them from the server. This prevents you from having duplicate copies of a message, but it also means that you will no longer have access to messages that you move to folders created from anywhere except the 700 Series Computer.

S If you use IMAP4:

The folders you create and the e-mail messages you move are mirrored on the server. Therefore, messages are available to you anytime you connect to your mail server, whether it is from your 700 Series Computer or desktop computer. This synchronization of folders occurs whenever you connect to your mail server, create new folders, or rename/delete folders when connected.

46 700 Series Color Mobile Computer User’s Manual

Companion Programs

The companion programs consist of Microsoft Pocket Word, Microsoft Pocket Excel, Windows Media Player for Pocket PC, and Microsoft Reader. To switch to a companion program on your 700 Series Computer, tap Start → Programs, then tap the program name.

Pocket Word

Pocket Word works with Microsoft Word on your desktop computer to give you easy access to copies of your documents. You can create new documents on your 700 Series Computer, or you can copy documents from your desktop computer to your 700 Series Computer. Synchronize documents between your desktop computer and your 700 Series Computer so that you have the most up-to-date content in both locations.

Creating a Document

Use Pocket Word to create documents, such as letters, meeting minutes, and trip reports. To create a new file, tap Start → Programs → Pocket Word → New. A blank document appears. Or, if you have selected a template for new documents in the Options dialog box, that template appears with appropriate text and formatting already provided. You can open only one document at a time; when you open a second document, you will be asked to save the first. You can save a document you create or edit in a variety of formats, including Word (.DOC), Pocket Word (.PSW), Rich Text Format (.RTF), and Plain Text (.TXT).

Pocket PC 2002—Chapter 2

47700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Pocket Word contains a list of the files stored on your 700 Series Computer. Tap a file in the list to open it. To delete, make copies of, and send files, tap and hold a file in the list. Then, select the appropriate action on the pop-up menu.

You can enter information in Pocket Word in one of four modes (typing, writing, drawing, and recording), which are displayed on the View menu. Each mode has its own toolbar, which you can show and hide by tapping the Show/Hide Toolbar button on the command bar.

Note: You can change the zoom magnification by tapping View → Zoom, then select the percentage you want. Select a higher percentage to enter text and a lower one to see more of your document.

If you are opening a Word document created on a desktop computer, select Wrap to Window on the View menu so that you can see the entire document.

48 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Typing Mode

Using the input panel, enter typed text into the document. For more information on entering typed text, see “Basic Skills” on page 11.

To format existing text and to edit text, first select the text. You can select text as you do in a Word document, using your stylus instead of the mouse to drag through the text you want to select. You can search a document to find text by tapping Edit → Find/Replace.

49700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Writing Mode

In writing mode, use your stylus to write directly on the screen. Ruled lines are displayed as a guide, and the zoom magnification is greater than in typing mode to allow you to write more easily. For more information on writing and selecting writing, see “Basic Skills” on page 11.

Note: If you cross three ruled lines in a single stylus stroke, the writing becomes a drawing, and can be edited and manipulated as described in “Drawing Mode” on the next page.

Written words are converted to graphics (metafiles) when a Pocket Word document is converted to a Word document on your desktop computer.

50 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Drawing Mode

In drawing mode, use your stylus to draw on the screen. Grid lines appear as a guide. When you lift your stylus off the screen after the first stroke, you will see a drawing box indicating the boundaries of the drawing. Every subsequent stroke within or touching the drawing box becomes part of the drawing. For more information on drawing and selecting drawings, see “Basic Skills” on page 11.

Recording Mode

In recording mode, embed a recording into your document. Recordings are saved as .WAV files. For more information on recording, see “Basic Skills” on page 11.

For more information on using Pocket Word, tap Start → Help.

51700 Series Color Mobile Computer User’s Manual

Pocket Excel

Pocket PC 2002Chapter —2

Pocket Excel works with Microsoft Excel on your desktop computer to give you easy access to copies of your workbooks. You can create new workbooks on your 700 Series Computer, or you can copy workbooks from your desktop computer to your 700 Series Computer. Synchronize workbooks between your desktop computer and your 700 Series Computer so that you have the most up-to-date content in both locations.

Creating a Workbook

Use Pocket Excel to create workbooks, such as expense reports and mileage logs. To create a new file, tap Start → Programs → Pocket Excel → New. A blank workbook appears. Or, if you have selected a template for new workbooks in the Options dialog box, that template appears with appropriate text and formatting already provided. You can open only one workbook at a time; when you open a second workbook, you will be asked to save the first. You can save a workbook you create or edit in a variety of formats, including Pocket Excel (.PXL) and Excel (.XLS).

Pocket Excel contains a list of the files stored on your 700 Series Computer. Tap a file in the list to open it. To delete, make copies of, and send files, tap and hold a file in the list. Then select the appropriate action from the pop-up menu.

Pocket Excel provides fundamental spreadsheet tools, such as formulas, functions, sorting, and filtering. To display the toolbar, tap View → Toolbar.

52 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Note: If your workbook contains sensitive information, you can protect it with a password. To do so, open the workbook, tap Edit → Password.Every time you open the workbook, you will need to enter the password, so choose one that is easy for you to remember but hard for others to guess.

Tips for Working in Pocket Excel

Note the following when working in large worksheets in Pocket Excel:

S View in full-screen mode to see as much of your worksheet as possible.

Tap View → Full Screen. To exit full-screen mode, tap Restore.

S Show and hide window elements. Tap View and then tap the elements

youwanttoshoworhide.

S Freeze panes on a worksheet. First select the cell where you want to

freeze panes. Tap View → Freeze Panes. You might want to freeze the top and leftmost panes in a worksheet to keep row and column labels visible as you scroll through a sheet.

S Split panes to view different areas of a large worksheet. Tap View →

Split. Then drag the split bar to where you want it. To remove the split, tap View → Remove Split.

MSN Messenger

S Show and hide rows a nd columns. To hide a hidden row or column, se-

lect a cell in the row or column you want to hide. Then tap Format ,

Row or Column → Hide. To show a hidden row or column, tap Tools → Go To, and then type a reference that is in the hidden row or co-

lumn. Then tap Format → Row or Column → Unhide.

For more information on using Pocket Excel, tap Start → Help.

Note: MSN Messenger is only available on the Premium Edition of Pocket PC 2002.

MSN Messenger on your 700 Series Computer is an instant messaging program that lets you:

S See who is online.

S Send and receive instant messages.

S Have instant message conversations with groups of contacts.

To use MSN Messenger, you must have a Microsoft Passport account or a Microsoft Exchange e-mail account. You must have a Passport to use MSN Messenger Service. If you have a Hotmail or MSN account, you already have a Passport. Once you have obtained either a Microsoft Passport or a Microsoft Exchange account, you are ready to set up your account.

S Sign up for a Microsoft Passport account at http://www.passport.com.

S Get a free Microsoft Hotmail e-mail address at http://www.hotmail.com.

To switch to MSN Messenger, tap Start → Programs → MSN Messenger.

53700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Setting Up

Before you can connect, you must enter Passport or Exchange account information. To set up an account and sign in:

1 In the Tools menu, tap Options.

2 In the Accounts tab, enter your Passport or Exchange account informa-

tion.

3 To sign in, tap the sign-in screen and enter your e-mail address and pass-

word.

Note: If you already use MSN Messenger on your desktop computer, your contacts will show up on your 700 Series Computer without being added again.

Working with Contacts

The MSN Messenger window shows all of your messenger contacts at a glance, divided into Online and Not Online categories. From this view, while connected, you can chat, send e-mail, block the contact from chatting with you, or delete contacts from your list using the pop-up menu.

Note: To see others online without being seen, in the Tools menu, tap My Status → Appear Offline.

If you block a contact, you will appear offline but will remain on the blocked contact’ s list. To unblock a contact, tap and hold the contact, then tap Unblock on the pop-up menu.

54 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Chatting with Contacts

Tap a contact name to open a chat window. Enter your message in the text entry area at the bottom of the screen, or tap My Text to enter a preset message, and tap Send. To invite another contact to a multi-user chat, in the Tools menu, tap Invite and tap the contact you want to invite.

Note: To switch back to the main window without closing a chat, tap the Contacts button. To revert back to your chat window, tap Chats and select

the person whom you were chatting with.

55700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

To know if the contact you are chatting with is responding, look for the message under the text entry area.

For more information on using MSN Messenger, tap Start → Help.

56 700 Series Color Mobile Computer User’s Manual

Windows Media Player for Pocket PC

Use Microsoft Windows Media Player for Pocket PC to play digital audio and video files that are stored on your 700 Series Computer or on a network. To switch to Windows Media Player for Pocket PC, tap Start → Programs → Windows Media.

Use Microsoft Windows Media Player on your desktop computer to copy digital audio and video files to your Pocket PC. You can play Windows Media and MP3 files on your Pocket PC.

Pocket PC 2002—Chapter 2

For more information about using Windows Media Player for Pocket PC, tap Start → Help.

57700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Microsoft Reader

Use Microsoft Reader to read eBooks on your 700 Series Computer. Download books to your desktop computer from your favorite eBook Web site. Then, use ActiveSync to copy the book files to your activated 700 Series Computer. The books appear in the Reader Library, where you can tap them in the list to open them. Each book consists of a cover page, an optional table of contents, and the pages of the book. You can:

S Page through the book by using the Up/Down control on your 700 Se-

ries Computer or by tapping the page number on each page.

S Annotate the book with highlighting, bookmarks, notes, and drawings.

S Search for text and look up definitions for words.

The Guidebook contains all the information you will need to use the software. To open the Guidebook, tap Help on the Reader command bar. Or, on a book page, tap and hold on the book title, and then tap Help on the pop-up menu. To switch to Microsoft Reader, tap Start → Programs → Microsoft Reader.

Getting Books on Your 700 Series Computer

You can download book files from the Web. Just visit your favorite eBook retailer and follow the instructions to download the book files.

Sample books and a dictionary are also included in the MSReader folder in the Extras folder on the Pocket PC Companion CD.

Use ActiveSync to download the files from your desktop computer to your activated mobile computer as described in the Read Me file in the MSReader folder.

58 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Using the Library

The Library is your Reader home page; it displays a list of all books stored on your 700 Series Computer or storage card. To open the Library:

1 On the Reader command bar, tap Library.

2 On a book page, tap the book title, then tap Library on the pop-up

menu.

3 To open a book, tap its title in the Library list.

59700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Reading a Book

Each book consists of a cover page, an optional table of contents, and the pages of the book. Navigation options are listed in the bottom portion of the cover page.

The first time you open a book, you will probably want to go to the first page or to the table of contents, if there is one. Subsequently, whenever you open the book, you will be automatically taken to the last page read.

In addition to the text, each book page includes a page number and book title.

You can also page through a book by using the Up/Down control on your 700 Series Computer.

60 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

Using Reader Features

Reading a book electronically gives you several options not available with paper books. These options are available from any book page.

Select text by dragging across the text on the page. Then, tap an option on the pop-up menu, as described here:

S Searching for Text

Find text in a book by tapping Find on the pop-up menu. Enter the word you want to search for, and tap the desired Find option. Reader highlights found text on the page. To close Find, tap outside the box. To return to your original page, tap the title and then tap Return on the pop-up menu.

S Copying Text

You can copy text from books that support this feature into any program that accepts text. On a book page, select the text you want to copy. Then, tap Copy Text on the pop-up menu. The text can be pasted into the program of your choice.

S Adding Bookmarks

When you add a bookmark to a book, a color-coded bookmark icon appears in the right margin. You can add multiple bookmarks to a book. Then, from anywhere in the book, tap the bookmark icon to go to the bookmarked page.

S Highlighting Text

When you highlight text, it appears with a colored background.

S Attaching Notes to Text

When you attach a note to text, you enter the text in a notepad that appears on top of the book page. A Note icon will display in the left margin. To show or hide the note, tap the icon.

S Adding Drawings

When you add a drawing, a Drawing icon appears in the bottom-left corner of the page, and drawing tools appear across the bottom of the page. Draw by dragging your stylus.

S Annotations Index

To see a list of a book’ s annotations, including bookmarks, highlights, text notes, and drawings, tap Annotations Index on the book’ s cover page. You can tap an entry in the list to go to the annotated page.

Removing a Book

When you finish reading a book, you can delete it to conserve space on your 700 Series Computer. If a copy of the book is stored on your desktop computer, you can download it again at any time.

To remove a book from your 700 Series Computer, tap and hold the title in the Library list, and then tap Delete on the pop-up menu.

61700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Pocket Internet Explorer

Note: The Professional Edition of Pocket Internet Explorer does not support WAP pages.

Use Microsoft Pocket Internet Explorer to view Web or WAP pages in either of these ways:

S During synchronization with your desktop computer, download your

favorite links and mobile favorites that are stored in the Mobile Favorites subfolder in Internet Explorer on the desktop computer.

S Connect to an ISP or network and browse the Web. To do this, you will

need to create the connection first, as described in “Getting Connected” on page 67.

When connected to an ISP or network, you can also download files and programs from the Internet or intranet.

To switch to Pocket Internet Explorer, tap Start → Internet Explorer.

The Mobile Favorites Folder

Favorite Links

Mobile Favorites

Only items stored in the Mobile Favorites subfolder in the Favorites folder in Internet Explorer on your desktop computer will be synchronized with your 700 Series Computer. This folder was created automatically when you installed ActiveSync.

During synchronization, the list of favorite links in the Mobile Favorites folder on your desktop computer is synchronized with Pocket Internet Explorer on your 700 Series Computer. Both computers are updated with changes made to either list each time you synchronize. Unless you mark the favorite link as a mobile favorite, only the link will be downloaded to your 700 Series Computer, and you will need to connect to your ISP or network to view the content. For more information on synchronization, see ActiveSync Help on the desktop computer.

If you are using Microsoft Internet Explorer 5.0 or later on your desktop computer, you can download mobile favorites to your 700 Series Computer. Synchronizing mobile favorites downloads Web content to your 700 Series Computer so that you can view pages while you are disconnected from your ISP and desktop computer.

Use the Internet Explorer plug-in installed with ActiveSync to create mobile favorites quickly. To create a mobile favorite:

1 In Internet Explorer on your desktop computer, click Tools → Create

Mobile Favorite.

2 To change the link name, enter a new name in the Name box.

3 Optionally, in Update, select a desired update schedule.

62 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

4 Click OK. Internet Explorer downloads the latest version of the page to

your desktop computer.

5 If you want to download the pages that are linked to the mobile favorite

you just created, in Internet Explorer on the desktop computer, right-click the mobile favorite just created and then click Properties.In the Download tab, specify the number of links deep you want to download. To conserve 700 Series Computer memory, go only one level deep.

6 Synchronize your 700 Series Computer and desktop computer. Mobile

favorites that are stored in the Mobile Favorites folder in Internet Explorer are downloaded to your 700 Series Computer.

Note: If you did not specify an update schedule in step 3 above, you will need to manually download content to keep the information updated on your desktop computer and 700 Series Computer. Before synchronizing with your 700 Series Computer, in Internet Explorer on your desktop computer , click Tools→Synchronize. You will see the last time content was downloaded to the desktop computer, and you can manually download content if needed.

You can add a button to the Internet Explorer toolbar for creating mobile favorites. In Internet Explorer on your desktop computer, click View

→

Toolbars→Customize.

Mobile favorites take up storage memory on your 700 Series Computer. To minimize the amount of memory used:

S In the settings for the Favorites information, type in ActiveSync options,

turn off pictures and sounds, or stop some mobile favorites from being downloaded to the 700 Series Computer. For more information, see Ac- tiveSync Help.

S Limit the number of downloaded linked pages. In Internet Explorer on

the desktop computer, right-click the mobile favorite you want to change and then Properties .IntheDownload tab, specify “0” or “1” for the number of linked pages you want to download.

63700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Using AvantGo Channels

AvantGo is a free interactive service that gives you access to personalized content and thousands of popular Web sites. You subscribe to AvantGo channels directly from your 700 Series Computer. Then, you synchronize your 700 Series Computer and desktop computer, or connect to the Internet to download the content. For more information, visit the AvantGo Web site. To sign up for AvantGo:

1 In ActiveSync options on the desktop computer, turn on synchroniza-

2 In Pocket Internet Explorer on your 700 Series Computer, tap the Fa-

3 Tap t he AvantGo Channels link.

4 Tap t he Activate button.

5 Follow the directions on the screen. You will need to synchronize your

tion for the AvantGo information type.

vorites button to display your list of favorites.

700 Series Computer with your desktop computer and then tap the My Channels button to complete the AvantGo setup.

When synchronization is complete, tap the AvantGo Channels link in your list of favorites to see a few of the most popular channels. To add or remove channels, tap the Add or Remove link.

64 700 Series Color Mobile Computer User’s Manual

Using Pocket Internet Explorer

You can use Pocket Internet Explorer to browse mobile favorites and channels that have been downloaded to your 700 Series Computer without connecting to the Internet. You can also connect to the Internet through an ISP or a network connection and browse the Web.

Pocket PC 2002—Chapter 2

65700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Viewing Mobile Favorites and Channels

1 Tap t he Favorites button to display your list of favorites.

2 Tap the page you want to view.

You will see the page that was downloaded the last time you synchronized with your desktop computer. If the page is not on your 700 Series Computer, the favorite will be dimmed. You will need to synchronize with your desktop computer again to download the page to your 700 Series Computer, or connect to the Internet to view the page.

Browsing the Internet

1 Set up a connection to your ISP or corporate network using Connec-

tions, as described in “Getting Connected” on page 67.

2 To connect and start browsing, do one of the following:

S Ta p t he Favorites button, and then tap the favorite you want to view.

S Ta p View → Address Bar. In the address bar that appears at the top

of the screen, enter the Web address you want to visit and then tap

Go. Tap the arrow to choose from previously entered addresses.

Note: To add a favorite link while using the 700 Series Computer, go to the page you want to add, tap and hold on the page, and tap Add to Favorites.

66 700 Series Color Mobile Computer User’s Manual

Getting Connected

You can use your 700 Series Computer to exchange information with other 700 Series Computers as well as your desktop computer, a network, or the Internet. You have the following connection options:

S Use the infrared (IR) port on your 700 Series Computer to send and

S Connect to your ISP. Once connected, you can send and receive e-mail

S Connect to the network at your company or organization where you

Pocket PC 2002—Chapter 2

receive files between two 700 Series Computers. If this is the method you want to use, see “Transferring Items Using Infrared”below.

messages by using Inbox and view Web or WAP pages by using Pocket Internet Explorer. The communication software for creating an ISP connection is already installed on your 700 Series Computer. Your service provider will provide software needed to install other services, such as paging and fax services. If this is the method you want to use, see “Con- necting to an Internet Service Provider” on page 68.

work. Once connected, you can send and receive e-mail messages by using Inbox, view Web or WAP pages by using Pocket Internet Explorer, and synchronize with your desktop computer. If this is the method you want to use, see “Connecting to Work” on page 70.

S Connect to your desktop computer to synchronize remotely. Once con-

nected, you can synchronize information such as your Pocket Outlook information. If this is the method you want to use, see ActiveSync Help on your desktop computer or Connections Help on the 700 Series Computer.

Transferring Items Using Infrared

Using infrared (IR), you can send and receive information, such as contacts and appointments, between two 700 Series Computers.

Sending Information

1 Switch to the program where you created the item you want to send and

locate the item in the list.

2 Align the IR ports so that they are unobstructed and within a close

range.

3 Tap and hold the item, and tap Beam Item on the pop-up menu.

Note: You can also send items, but not folders, from File Explorer. Tap

and hold the item you want to send, and then tap Beam File on the popup menu.

Receiving Information

1 Align the IR ports so that they are unobstructed and within a close

range.

2 Have the owner of the other 700 Series Computer send the information

to you. Your 700 Series Computer will automatically receive it.

67700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Connecting to an Internet Service Provider

You can connect to your ISP, and use the connection to send and receive e-mail messages and view Web or WAP pages. You can connect to your ISP in one of two ways:

S Create a modem connection. If this is the method you want to use, see

“Creating a Modem Connection to an ISP”below.

S Use an Ethernet card and a net tap to connect to the network. If this is

the method you want to use, see “Creating an Ethernet Connection to an ISP” on page 69.

Creating a Modem Connection to an ISP

1 Obtain the following information from your ISP. Some ISPs require in-

formation in front of the user name, such as MSN/username.

S ISP dial-up access telephone number

S User name

S Password

S TCP/IP settings

2 If your 700 Series Computer does not have a built-in modem, install a

modem card, or use or use a NULL modem cable and appropriate adapters to connect an external modem to your 700 Series Computer through the serial port.

3 Tap Start → Settings → the Connections tab → Connections.Under

The Internet settings, select Internet Settings → Modify.

4 In the Modem tab, tap New.

5 Enter a name for the connection, such as “ISP Connection.”

6 In Select a modem list, select your modem type. If your modem type

does not appear, try reinserting the modem card. If you are using an external modem that is connected to your 700 Series Computer with a cable, select “Hayes Compatible on COM1.”

7 You should not need to change any settings in Advanced.MostISPs

now use a dynamically-assigned address. If the ISP you are connecting to does not use a dynamically-assigned address, tap Advanced → the TCP/IP tab, then enter the address. When finished, tap OK → Next.

8 Enter the access phone number, and tap Next.

9 Select other desired options, and tap Finish.

10 In the Dialing Locations tab, specify your current location and phone

type (most phone lines are tone). These settings will apply to all connections you create.

68 700 Series Color Mobile Computer User’s Manual

Pocket PC 2002—Chapter 2

To start the connection, simply start using one of the following programs. Your 700 Series Computer will automatically begin connecting. Once connected, you can:

S Send and receive e-mail messages by using Inbox. Before you can use

Inbox, you need to provide the information it needs to communicate with the e-mail server. For specific instructions, see “Connecting Directly to an E-mail Server” on page 72.

S Visit Web and WAP pages by using Pocket Internet Explorer. For more

information, see “Pocket Internet Explorer” on page 62.

S Send and receive instant messages with MSN Messenger. For more in -

formation, see “MSN Messenger” on page 53.

Creating an Ethernet Connection to an ISP

1 You do not need to create a new connection on your 700 Series Com-

puter. Instead, you must purchase a dock to enable on-board Ethernet or purchase a CompactFlash Ethernet card that is compatible with your 700 Series Computer.

2 Obtain the following information from your ISP:

S User name

S Password

S Domain name

3 Insert the Ethernet card into your 700 Series Computer. For instruc-

tions on inserting and using the Ethernet card, see the owner’ s manual.

If using an on-board Ethernet, place your 700 Series Computer in a dock, tap Start → Today, then look in the System Tray for the Ethernet icon (shown left). If not there, then tap the antenna icon for the NDISTRAY pop-up menu and select Built-in Ethernet from the menu.

4 The first time you insert the card, Network Settings will appear

automatically so that you can configure the Ethernet card. Most networks use DHCP, so you should not have to change these settings unless your network administrator instructs you to do so. Tap OK.(Ifit does not appear or to change settings later, tap Start → Settings → the Connections tab → Network, tap the adapter you want to change, and then tap Properties.)

S If using an on-board Ethernet, then select Start → Settings → the

Connections tab → Network Adapters. Select “NE2000 Compatible Ethernet Driver” from the list of adapters installed, then tap Properties to configure the Ethernet driver.

69700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

Connecting to Work

5 Connect the Ethernet card or dock to the network by using a network

cable. For information, see your owner’ s manual.

6 Tap Start → Settings → the Connections tab → Connections.From

the My network card connects to list, select “Internet.”

To start the connection, simply start using one of the programs listed in the preceding section. Once connected, you can perform the same activities as listed in the preceding section.

If you have access to a network at work, you can send e-mail messages, view intranet pages, synchronize your 700 Series Computer, and possibly access the Internet. You can connect to work in one of two ways:

S Create a modem connection by using a RAS (Remote Access Server) ac-

count. Before you can create this modem connection, your network administrator will need to set up a RAS account for you. If this is the method you want to use, see “Creating a Modem Connection to Work” below. Your network administrator may also give you VPN settings.

S Use an Ethernet card and a net tap to connect to the network. If this is

the method you want to use, see “Creating an Ethernet Connection to Work” on page 71.

Creating a Modem Connection to Work

1 Get the following information from your network administrator:

S Dial-up access telephone number

S User name

S Password

S Domain name

S TCP/IP settings

2 If your 700 Series Computer does not have a built-in modem, install a

modem card.

3 Tap Start → Settings → the Connections tab → Connections.Under

The Internet settings, select Internet Settings and tap Modify.

4 In the Modem tab, tap New.

5 Enter a name for the connection, such as “Company Connection.”

6 In the Select a modem list, select your modem type. If your modem

type does not appear, try reinserting the modem card. If you are using an external modem that is connected to your 700 Series Computer with a cable, select “Hayes Compatible on COM1.”

7 You should not need to change any settings in Advanced. Most servers

now use a dynamically-assigned address. If the server you are connecting to does not use a dynamically-assigned address, tap Advanced→the

TCP/IP tab and then enter the address. When finished, tap OK Next.

70 700 Series Color Mobile Computer User’s Manual

→

Pocket PC 2002—Chapter 2

8 Enter the access phone number, and tap Next.

9 Select other desired options, and tap Finish.

10 In the Dialing Locations tab, specify your current location and phone

type (most phone lines are tone). These settings will apply to all connections you create.

To start the connection, start using one of the following programs. Your 700 Series Computer will automatically begin connecting. Once connected, you can:

S Send and receive e-mail messages by using Inbox. Before you can use

Inbox, you need to provide the information it needs to communicate with the e-mail server. For specific instructions, see “Connecting Directly to an E-mail Server” on page 72.

S Visit Internet or intranet Web or WAP pages via Pocket Internet Explor-

er.

S Send and receive instant messages with MSN Messenger. For more in -

formation, see “MSN Messenger” on page 53.

S Synchronize. For more information, see ActiveSync Help on the desktop

computer .

Creating an Ethernet Connection to Work

1 You do not need to create a new connection on your 700 Series Com-

puter. Instead, you must purchase a dock to enable on-board Ethernet or purchase a CompactFlash Ethernet card that is compatible with your 700 Series Computer.

2 Obtain the following information from your ISP:

S User name

S Password

S Domain name

3 Insert the Ethernet card into your 700 Series Computer. For instruc-

tions on inserting and using the Ethernet card, see the owner’ s manual.

S If using an on-board Ethernet, place your 700 Series Computer in a

dock, tap Start → Today, then look in the System Tray for the Ethernet icon (shown left). If not there, then tap the antenna icon for the NDISTRAY pop-up menu and select Built-in Ethernet from the menu.

71700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

4 The first time you insert the card, Network Settings will appear

S If using an on-board Ethernet, then select Start → Settings → the

Connections tab → Network Adapters. Select “NE2000 Compatible Ethernet Driver” from the list of adapters installed, then tap Properties to configure the Ethernet driver.

5 Connect the Ethernet card or dock to the network by using a network

cable. For information, see your owner’ s manual.

6 To synchronize your 700 Series Computer, tap Start → ActiveSync.In

the Tools menu, tap Options. → the PC tab, select Include PC when synchronizing remotely and connect to, and select your computer’ s name. Remote synchronization with a desktop computer will work only if a partnership is set up with that computer through ActiveSync and ActiveSync is set to allow remote connections. Other restrictions apply. For more information, see ActiveSync Help on the desktop computer.

To start the connection, simply start using one of the programs listed in the preceding section. Once connected, you can perform the same activities as listed in the preceding section.

Ending a Connection

To disconnect, do one of the following:

S When connected via dial-up or VPN, tap the Connection icon (shown

left) on your navigation bar, and then tap End.

S When connected via cable or cradle, detach your 700 Series Computer

from the cable or cradle.

S When connected via Infrared, move the 700 Series Computer away

from the PC.

S When connected via a network (Ethernet) card, remove the card from

your 700 Series Computer.

Connecting Directly to an E-mail Server

You can set up a connection to an e-mail server so that you can send and receive e-mail messages by using a modem or network connection and Inbox on your 700 Series Computer.

Note: The ISP or network must use a POP3 or IMAP4 e-mail server and an SMTP gateway.

You can use multiple e-mail services to receive your messages. For each email service you intend to use, first set up and name the e-mail service. If you use the same service to connect to different mailboxes, set up and name each mailbox connection.

72 700 Series Color Mobile Computer User’s Manual

Setting Up an E-mail Service

S In Inbox on your 700 Series Computer, tap Services → New Service.

Follow the directions in the New Service wizard.

For an explanation of a screen, tap Start → Help. When finished, to connect to your e-mail server, tap Services → Connect. For more information on using the Inbox program, see “Inbox: Sending and Receiving E-mail Mes- sages” on page 42.

Pocket PC 2002—Chapter 2

73700 Series Color Mobile Computer User’s Manual

Pocket PC 2002Chapter —2

74 700 Series Color Mobile Computer User’s Manual

Installing Applications

There are multiple ways to get an application to your 700 Series Color Mobile Computer; just as there are multiple ways to package the application for delivery.

75700 Series Color Mobile Computer User’s Manual

Installing ApplicationsChapter —3

Packaging an Application

Use any of the following methods to package an application for installation:

S For very simple applications, the application itself might be the only file

that needs to be delivered.

S It could be a directory structure that contains the application, support-

ing files like ActiveX controls, DLLs, images, sound files, and data files.

S Via a CAB file.

Consider either of the following when choosing a location into which to store your application:

S In the basic 700 Series Computer, there are no built-in storage options

other than the Object Store. The Object Store is RAM that looks like a disk. Anything copied here will be deleted when a cold-boot is performed on the 700 Series Computer.

S If the optional SecureDigital or CompactFlash storage card is in the sys-

tem, then consider this card the primary location for placing an applications install files. The following folders represent either card:

S The SecureDigital storage card creates the “\SDMMC Disk” folder.

S The CompactFlash storage card creates the “\Storage Card” folder.

S Files copied to either of these locations will be safe when a cold-boot is

performed on a 700 Series Computer - providing the AutoRun system is installed onto the storage card. You can find this system on the Recovery

CD. Copying a CAB file to the “\CABFILES” folder on one of these cards will automatically extract that CAB file on every cold boot to ensure that your system is properly set up. See page 82 for more details on how this works.

Installing Applications

Consider any of the following options to get the package to the preferred location on your 700 Series Computer.

S Microsoft ActiveSync

S FTP Server (page 78)

S Application Manager in Unit Manager (page 78)

S SecureDigital or CompactFlash storage card (page 78)

76 700 Series Color Mobile Computer User’s Manual

Using Microsoft ActiveSync

Note: These instructions assume that the 700 Color Management Tools portion of the 700 Series Color Software Tools CD was installed onto your desktop.

The Microsoft ActiveSync tool is located on the 700C Companion CD, which contains Microsoft products, such as Outlook and ActiveSync. See Chapter 2, “Pocket PC 2002,” for information about this tool as provided by Microsoft Corporation.

This can be a serial, USB, Ethernet, InfraRed, or 802.11b ActiveSync connection. Files can then be copied using File Explorer on a PC or a laptop computer. This option is usually only good when updating a few 700 Series Computers.

These instructions assume that Microsoft ActiveSync had been installed onto your desktop computer and is up and running. If not, go to Chapter 2, “Pocket PC 2002,” for an URL from which you can download the latest application.

1 Connect your 700 Series Computer to your desktop computer via an

ActiveSync cable or IrDA.

Installing Applications—Chapter 3

2 Wait for a “Connected” message to appear in the Microsoft ActiveSync

application to signal a connection to the 700 Series Computer. If necessary, select File → Get Connected to initiate a connection.

3 Click Explore to access the Mobile Device directory on your 700 Series

Computer.

77700 Series Color Mobile Computer User’s Manual

Installing ApplicationsChapter —3

Using the FTP Server

4 From your desktop, select Start → Windows Explorer, then browse the

applicable path for any of the system files needed for your 700 Series Computer (listed with their paths). Select to highlight the appropriate file, right-click the file for a pop-up menu, then select Copy.

S Base operating system files:

“C:\Intermec\Intermec 700 Color Mgmt Tools\Drive Images”

S CAB files:

“C:\Intermec\Intermec 700 Color Mgmt Tools\Cab Files”

5 Within the Mobile Device directory, go to the directory where you want

the files located on the 700 Series Computer, do a right-click for a popup menu, then select Paste.

6 When all of the files are pasted, perform a warm-boot on the 700 Series

Computer. When the computer reboots, wait for the LED on the top left of your keypad to stop blinking. Tap Start → Programs → File Ex- plorer to locate the newly copied executable files, then tap these files to activate their utilities.

The 700 Series Computer has a built-in FTP Server that connects to a network via Ethernet or 802.11b. This “ftp”s to the IP address of the 700 Series Computer and places files. The benefit of using FTP is that a script can be created that will automate the process of copying files to the 700 Series Computer. This option is good for when a large number of 700 Series Computers need to be updated. See Chapter 7, “Programming,” for more information.

Using the Application Manager in Unit Manager

This requires the 700 Series Computer to connect to the network via Ethernet or 802.11b. The process is still manual so it would take longer than the FTP method but it would still be a better option than ActiveSync where many 700 Series Computers need to be updated. The Unit Manager applications are available on the 700 Series Color Unit Manager CD-ROM. For more information, consult your Intermec sales representative.

Using a Storage Card

The following steps pertain to installing an application using a storage card.

Copying to a CompactFlash Card

Follow the steps below to install your application on the device using a CompactFlash storage card:

1 Suspend the 700 Series Color Mobile Computer and remove its Com-

pactFlash drive, which holds a SanDisk CompactFlash storage card.

2 Using a CompactFlash Adapter card, place the CompactFlash Drive in

your desktop PC card drive.

78 700 Series Color Mobile Computer User’s Manual

Installing Applications—Chapter 3

3 Create a subdirectory on the PCMCIA CompactFlash drive in which to

store your application.

4 Add the autorun system to the storage card using the CEImager

application. See the Software Tools User’ s Manual for information about CEImager.

5 Copy your application, data files, and all required DLLs and drivers to

the subdirectory created on the CompactFlash drive.

6 Add your application to the AUTOUSER.DAT file on the

“\Storage Card\2577” directory that contains the following statement, where your directory is the directory on the CompactFlash storage card where the application was installed, and yourapp.exe is the name of your application. Finish the “RUN=” statement with a carriage return linefeed combination. There may be multiple run statements in the file.

RUN=\<your directory>\<yourapp.exe>

7 Remove the CompactFlash drive from your desktop computer and rein-

stall it into the 700 Series Computer.

8 Warm-boot the 700 Series Computer to add these files to the Compact-

Flash storage card.

If the AUTOUSER.DAT file is found and the “RUN=” statement is correct, then the task manager will launch and execute your program on startup.

Copying to a SecureDigital Storage Card

Do the same steps as for the CompactFlash storage Card, except replace the “\Storage Card\2577” directory with the “\SDMMC Disk\2577” directory.

Updating the System Software

You c an use the Recovery CD to reinstall or update the operating system software on the 700 Series Color Computer. For more information, contact your Intermec sales representative.

79700 Series Color Mobile Computer User’s Manual

Installing ApplicationsChapter —3

Application Migration

Note: These instructions assume that the 700 Color Management Tools portion of the 700C Software Tools CD was installed onto your desktop and that a storage card has been added to the base configuration of the 700 Color Computer.

The following steps are required to ensure that the following will happen on a cold-boot:

S CAB files can be restored,

S applications will automatically start,

S and the registry will be restored.

Do the following for the cold-boot procedure:

1 From your desktop, double-click the Intermec CE Imager desktop icon

to access the Intermec CEImager application. If this icon is not on your desktop, then double-click the CEIMAGER.EXE executable from the “C:\Intermec\Intermec 700 Color Mgmt Tools\Tools\CEImager” folder.

2 Click Default under Components List to activate the components.

3 Click (+) to expand the AutoRun System component, click (+) to ex-

pand the Destination Media option, then select either the CompactFlash Card option or the SecureDigital Card option. Do not select both

storage cards, as the AutoRun files copied will work for one storage card, but not work on the other storage card.

80 700 Series Color Mobile Computer User’s Manual
