Intermec Technologies NOVCDPD User Manual

Intermec Technologies Corporation FCC ID: EHANOVCDPD EMC Test Lab REPORT NO: 20020117-1 DOC. NO.: 577-501-008 Page 1 of 18 700 CDPD, FCC 2.1053 Radiated Spurious Emissions, Appendix A
MEASUREMENT/TECHNICAL REPORT
Technologies Corporation
EMC Test Laboratory Cedar Rapids, IA
700 With Novatel CDPD
Cellular Radio Module
REPORT NO: 20020117-1
DATE: January 17, 2002
APPENDIX A
NOVATEL USERS MANUAL
EXPEDITE
WIRELESS IP MODEM
HARDWARE INTERFACE
SPECIFICATION
OM - 01016529
Revision 3
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
1 of 17
REV:
3.0
REVISION HISTORY
REV# ECO# EFF. DATE DESCRIPTION PREPARED APPROVED 1 99007 Initial release.
P. Faubert S. Smilar 2 99024 990709 Change order of pins 21 and 22 P. Faubert S. Smilar 3 99047 990809 Add mounting instructions K. Frayn S. Smilar
NOVATEL WIRELESS
TITLE:
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
2 of 17
3.0
The information disclosed herein is the exclusive property of NOVATEL WIRELESS TECHNOLOGIES LTD. and is not to be disclosed without the written consent of NOVATEL WIRELESS TECHNOLOGIES LTD. No part of this publication may be reproduced or transmitted in any form or by any means including electronic storage, reproduction, execution or transmission without the prior written consent of NOVATEL WIRELESS TECHNOLOGIES LTD. The recipient of this document by its retention and use, agrees to respect the security status of the information contained herein.
The information disclosed herein is the exclusive property of Novatel Wireless Technologies Ltd. and is not to be disclosed without the written consent of Novatel Wireless Technologies Ltd. No part of this publication may be reproduced or transmitted in any form or by any means including electronic storage, reproduction, execution or transmission without the prior written consent of Novatel Wireless Technologies Ltd. The recipient of this document by its retention and use, agrees to respect the security status of the information contained herein.
This document is intended for limited circulation.
The information contained in this document is subject to change without notice and should not be construed as a commitment by NOVATEL WIRELESS TECHNOLOGIES LTD. unless such commitment is expressly given in a covering document.
© Copyright NOVATEL WIRELESS TECHNOLOGIES LTD. (1999)
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
3 of 17
REV:
3.0
Table of Contents
1 WARNING........................................................................................................................................6
2 INTRODUCTION.............................................................................................................................. 6
3 SCOPE.............................................................................................................................................6
4 SPECIFICATIONS ...........................................................................................................................6
4.1 Physical Interface......................................................................................................................6
4.1.1 Data/Power Connection ......................................................................................................7
4.1.2 RF Antenna Connector Type...............................................................................................8
4.1.3 Pin Descriptions ..................................................................................................................9
4.2 Host Interface Specifications ...................................................................................................10
4.2.1 Serial Data Rate and Format ............................................................................................10
4.3 Radio Specifications................................................................................................................10
4.3.1 Airlink Data Rate...............................................................................................................10
4.3.2 Recommended Antenna Type...........................................................................................10
4.3.3 Frequency Range .............................................................................................................10
4.3.4 Duplex Mode ....................................................................................................................10
4.3.5 RF Power Class................................................................................................................10
4.4 Electrical Specifications...........................................................................................................11
4.5 Mechanical Specifications........................................................................................................12
4.5.1 Dimensions....................................................................................................................... 12
4.5.2 Weight..............................................................................................................................12
4.6 Environmental Specifications...................................................................................................12
4.6.1 Temperature Range ..........................................................................................................12
4.6.2 Humidity...........................................................................................................................12
4.6.3...............................................................................................................................................12
4.6.4 Shock Stability..................................................................................................................13
4.6.5 Vibration Stability..............................................................................................................13
4.6.6 Regulatory compliance .....................................................................................................13
4.6.7 ESD Protection.................................................................................................................13
4.7 CDPD Part 409 Compliance ....................................................................................................14
5 INSTALLATION INSTRUCTIONS..................................................................................................15
5.1 Antenna Mounting....................................................................................................................15
5.2 Antenna...................................................................................................................................15
5.3 Labeling...................................................................................................................................15
5.4 User Manual............................................................................................................................15
6 PACKAGING REQUIREMENTS ....................................................................................................17
NOVATEL WIRELESS
TITLE:
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
4 of 17
3.0
6.1 Shipping Packaging.................................................................................................................17
6.2 Labeling...................................................................................................................................17
NOVATEL WIRELESS
TITLE:
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
5 of 17
3.0
1 WARNING
All persons must be at least 20 cm from the antenna when transmitter operating to meet FCC RF exposure requirements. Refer to the Installation Instructions section for specific requirements for the antenna used with module.
2 INTRODUCTION
This document describes the hardware interface for the Novatel Wireless Expedite Wireless IP Modem. The Expedite Wireless IP Modem is an OEM module designed for integration into a host product to provide two-way wireless data communication capability via the CDPD (Cellular Digital Packet Data) Network.
3 SCOPE
The scope of this document includes all pertinent information for describing the capabilities and operating requirements for the product in order to determine suitability for specific market applications. Internal design issues, detailed operating instructions and cost information is not included in this document.
4 SPECIFICATIONS
4.1 Physical Interface
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
6 of 17
REV:
3.0
4.1.1 Data/Power Connection
One connector is used to physically connect the power supply and 3.3 volt logic level host communication interface signals to the Expedite Wireless IP Modem.
4.1.1.1 Data/Power Connector Type
Description: 24-pin, 1.27 mm pitch, SMT, double row low profile socket type Samtec part number: CLP-112-02-F-D
Some interface connector options are provided here for reference. Contact Samtec for the latest connector mating options.
NOVATEL WIRELESS
TECHNOLOGIES LTD.
DOCUMENT NO.:
Calgary, Alberta
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
7 of 17
3.0
4.1.1.2 Surface Mount Mating Connector Options
Description: 24-pin, 1.27 mm pitch, SMT, double row, zero profile, pin type header Samtec part number: DIS5-112-52-F-D-VS NOTE: This connector provides the lowest profile interface solution.
Description: 24-pin, 1.27 mm pitch, SMT, double row, low profile, pin type header Samtec part number: FTS-112-03-F-DV
4.1.1.3 Through-Hole Mating Connector Options
Description: 24-pin, 1.27 mm pitch, T/H, double row, zero profile, pin type header Samtec part number: DIS5-112-52-F-D
Description: 24-pin, 1.27 mm pitch, T/H, double row, low profile, pin type header Samtec part number: FTS-112-03-F-D
4.1.2 RF Antenna Connector Type
Expedite Wireless IP Modem antenna connector: Description - MMCX Coaxial Connector
Manufacturer - Huber and Suhner Part Number - 82MMCX-S50-0-2 NOTE: An equivalent connector by the same or another manufacturer may be used.
Impedance - 50 ohm Expedite Wireless IP Modem mating antenna connector: Mating connector: - AEP 8905-1521-003 or equivalent with RG316 cable.
NOVATEL WIRELESS
TITLE:
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
8 of 17
3.0
4.1.3 Pin Descriptions
Pin # Name Direction Power-on
13, 14 Vcc1 POWER POWER SUPPLY CONNECTION TO THE MODEM FOR ALL 15, 16 Vcc2 POWER POWER SUPPLY CONNECTION TO THE MODEM FOR THE RF 1,2 &
23,24 3 PWR_IND OUTPUT POWER INDICATOR:
5 SM_IND OUTPUT SLEEP MODE INDICATOR:
4 WKUP INPUT WAKE UP INPUT: (ACTIVE HI PULSE)
6 DTM INPUT DATA TO MODEM:
7 DFM OUTPUT DATA FROM MODEM:
11 RTS INPUT READY TO SEND: 10 CTS OUTPUT CLEAR TO SEND: 8 DTR INPUT DTE READY: 9 DSR OUTPUT DCE READY: 12 GPIO1 BI­17 GPIO2 BI­18 GPIO3 BI­19 GPIO4 BI­20 GPIO5 BI­21 GPIO6 BI­22 ADC_IN ANALOG
GND POWER MODEM GROUND
DIRECTIONAL DIRECTIONAL DIRECTIONAL DIRECTIONAL DIRECTIONAL DIRECTIONAL INPUT
Reset State
INPUT WITH PULLUP INPUT WITH PULLUP INPUT WITH PULLDOWN INPUT WITH PULLUP INPUT WITH PULLDOWN INPUT WITH PULLUP ADC INPUT ADC INPUT:
Description
CIRCUITRY EXCEPT FOR THE RF POWER AMPLIFIER. POWER AMPLIFIER ONLY
HI: INDICATES THAT THE MODEM IS ON LO INDICATES THAT THE MODEM IS OFF
HI: INDICATES THAT THE MODEM IS IN SLEEP MODE LO INDICATES THAT THE MODEM IS NOT IN SLEEP MODE
A PULSE APPLIED TO THIS PIN WILL TURN ON THE MODEM IF THE MODEM IS OFF, OR WAKE UP THE MODEM IF THE MODEM IS IN SLEEP MODE. REFER TO THE APPLICATIONS INFORMATION SECTION FOR MORE DETAILS ON USING THE WAKE UP PIN.
(3.3 VOLT LOGIC LEVEL) IN RS232 TERMS, THIS IS CALLED "TXD".
(3.3 VOLT LOGIC LEVEL) IN RS232 TERMS, THIS IS CALLED "RXD".
(3.3 VOLT LOGIC LEVEL) (3.3 VOLT LOGIC LEVEL) (3.3 VOLT LOGIC LEVEL) (3.3 VOLT LOGIC LEVEL)
GENERAL PURPOSE CONFIGURABLE INPUT OR OUTPUT: REFER TO THE AT COMMAND SET FOR THE DEFAULT STATE. GENERAL PURPOSE CONFIGURABLE INPUT OR OUTPUT: REFER TO THE AT COMMAND SET FOR THE DEFAULT STATE. GENERAL PURPOSE CONFIGURABLE INPUT OR OUTPUT: REFER TO THE AT COMMAND SET FOR THE DEFAULT STATE. GENERAL PURPOSE CONFIGURABLE INPUT OR OUTPUT: REFER TO THE AT COMMAND SET FOR THE DEFAULT STATE. GENERAL PURPOSE CONFIGURABLE INPUT OR OUTPUT: REFER TO THE AT COMMAND SET FOR THE DEFAULT STATE. GENERAL PURPOSE CONFIGURABLE INPUT OR OUTPUT: REFER TO THE AT COMMAND SET FOR THE DEFAULT STATE.
THIS PIN IS CONNECTED TO ONE CHANNEL OF AN 8-BIT ADC. REFER TO THE AT COMMAND SET ON HOW TO READ THIS ADC VALUE.
NOVATEL WIRELESS
TITLE:
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
9 of 17
3.0
4.2 Host Interface Specifications
4.2.1 Serial Data Rate and Format
The Expedite supports asynchronous data transmission of the following rate and format:
Baud Rate (bits/second) 1200, 2400, 4800, 9600, 19200, 38400 Data bits 7, 8 Parity Even, None, Odd Mark Stop Bits
1, 2
4.3 Radio Specifications
4.3.1 Airlink Data Rate
Rate - 19200 bits per second Error correction - Reed Solomon (63,47) Transmission standard (CDPD System Specification Part 401, Section 4.5.)
4.3.2 Recommended Antenna Type
Type - Half-Wave Dipole Impedance - 50 ohm nominal VSWR - 1.5:1 nominal, 2.0:1 maximum
Note that the module is aligned assuming a 1.2 dB antenna gain (cable loss included in antenna gain).
4.3.3 Frequency Range
Mode Frequency Range Transmit 824 MHz - 849 MHz Receive 869 MHz - 894 MHz
4.3.4 Duplex Mode
Full-Duplex (CDPD System Specification Version 1.1 part 409, paragraph 4.2)
4.3.5 RF Power Class
Class III (0.6 Watt ERP)
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
10 of 17
REV:
3.0
(CDPD System Specification Version 1.1 part 409, paragraph 4.3)
4.4 Electrical Specifications
4.4.1.1 Operating Characteristics (Ta = 0ºC to 60ºC, VCC1 & VCC2 = 3.6V, unless
otherwise noted.)
SYMBOL PARAMETER / CONDITIONS MIN TYPICAL MAX UNITS
VCC1 MODEM SUPPLY VOLTAGE 3.45 3.6 4.5 V VCC2 RF POWER AMPLIFIER SUPPLY VOLTAGE 3.45 3.6 4.5 V ICC1
ICC2
TWAKEUP WAKE-UP PULSE WIDTH
VIL1(NOTE 1) INPUT VOLTAGE – LOW (EXCEPT FOR WKUP)
VIH1(NOTE 1) INPUT VOLTAGE - HIGH (EXCEPT FOR WKUP)
VIL2(NOTE 2) INPUT VOLTAGE - LOW (WKUP ONLY) WKUP ONLY -0.5 0 0.5 V VIH2(NOTE 2) INPUT VOLTAGE - HIGH (WKUP ONLY) 3.0 4.5 V VOL(NOTE 1) OUTPUT VOLTAGE - LOW (IOL = 1.0mA) 0.78 V VOH(NOTE 1) OUTPUT VOLTAGE - HIGH (IOH = -200µA) 2.6 3.3 3.4 V IOL(NOTE 1) MAXIMUM SINK CURRENT -1.0 mA IOH(NOTE 1) MAXIMUM SOURCE CURRENT 1.0 mA VADC ADC INPUT VOLTAGE
RESADC ADC RESOLUTION 8 BITS 24 mV REFADC ADC REFERENCE VOLTAGE 2.048 V DIVADC ADC DIVIDER RATIO 1:3 ZADC ADC INPUT IMPEDANCE 300k OHMS
NOTE 1 - The specifications apply to all pins on the serial interface connector except for the following pins: GND, VCC1, VCC2 & ADC_IN. All pins have except VCC1, VCC2 and GND are filtered via a 470pF shunt capacitor and a 330 ohm series resistor which affects the sink and source capability of the pin.
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
MODEM OFF
VCC1 = 3.6V
SLEEP MODE
VCC1 = 3.6V
RECEIVE MODE
VCC1 = 3.6V
TRANSMIT MODE
VCC1 = 3.6V
MODEM OFF
VCC2 = 3.6V
SLEEP MODE
VCC2 = 3.6V
RECEIVE MODE
VCC2 = 3.6V
TRANSMIT MODE
VCC2 = 3.6V FROM SLEEPMODE
FROM POWER UP MODEM ON
MODEM OFF MODEM ON
MODEM OFF
ADC READABLE VOLTAGE RANGE ABSOLUTE MAXIMUM INPUT VOLTAGE
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
11 of 17
5 µA 8 mA 130 175 mA 5 µA 5 µA 5 µA
50 725 mA
10
500
-0.5
2.0
1.5
mSec
0
3.3
mA
0.8 0
3.7
0.0
5.50
8.50
V
V
V
REV:
3.0
NOTE 2 - The WKUP pin is not connected directly to the CPU, it is connected though a resistor to the base of an NPN transistor.
4.5 Mechanical Specifications
4.5.1 Dimensions
5.00 mm x 54.00 mm x 72.91 mm
4.5.2 Weight
Approximately: 27g
4.6 Environmental Specifications
4.6.1 Temperature Range
The temperature is defined as per the CDPD System Specification Version 1.1 part 409, paragraph 5.2.1
Mode Lower Limit Upper Limit Operating (Compliant) 0 Degrees C +60 Degrees C Operating (De-rated) -20 Degrees C +60 Degrees C Storage -40 Degrees C +85 Degrees C
4.6.2 Humidity
CDPD Part 409 paragraph 5.2.2 50 degrees C 40% RH 8 hours
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
12 of 17
3.0
4.6.3 Shock Stability
CDPD Part 409 paragraph 5.2.3.1 Half sine wave, 20g peak acceleration, 7 to 11 ms 3 impact on each of 6 faces
4.6.4 Vibration Stability
CDPD Part 409 par. 5.2.3.2 (non-operational) Sinusoidal vibration at 1.5g acceleration swept through 5Hz to 500Hz, 0.1 octave/second
4.6.5 Regulatory compliance
FCC title 47, parts 15 (class B) and 22. Resubmission is not required for the changes made in this product, including the changes made to name and part number.
4.6.6 ESD Protection
No ESD protection is provided for the Expedite Wireless IP Modem. Expedite is intended to be used in an OEM application. It is the responsibility of the OEM manufacturer to provide the necessary ESD protection for their application.
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
13 of 17
REV:
3.0
output power in
4.7 CDPD Part 409 Compliance
The module will meet the CDPD System Specification Part 409, Small Form-Factor Devices.
CDPD
Part 409
7.1.2.2 RX sensitivity in AWGN
7.1.2.3 RX sensitivity in Raleigh fading
7.2.3 Co-channel interference rejection
7.3.3 Adjacent/Alternate channel
7.4.3 Intermodulation spurious
7.5.3 RSSI + 6 dB absolute
7.6.1.2 Radiated spurious emissions 25 - 70 MHz
7.6.2.2 Conducted spurious emissions 450 kHz - 2600 MHz
8.1.3 Frequency stability +2.5 PPM - 2.5 PPM
8.2.3 Phase noise 1 kHz
8.3.3 Emission spectrum adjacent channel
8.4.3 Channel switching time 40 ms
8.5.3.3 Power stability (PA power levels) +2 dBm -4 dBm
8.5.4.3 Switching time requirements – on
8.5.5.3 Release time requirements 2 ms
8.6.1.3 Modulation type 0.5 + 5%
8.7.1.3 Radiated harmonic and spurious
8.7.2.3 Conducted harmonic and
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
Specification Parameter Condition Upper Limit Lower limit
(Note a: small form factor M-ES) (Note b: small form factor M-ES)
and delay selectivity response
to off
emissions
spurious emissions
less than 5% block error rate
-8 km/hr, 1% ber
-50 km/hr, 1% ber
-100 km/hr, 1% ber 8 us delay 17 dB rejection
+/-30 kHz from carrier +/-60 kHz from carrier 57 dB
70 - 130 MHz 130 - 174 MHz 174 - 260 MHz 260 - 470 MHz 470 - 1000 MHz
869.01 - 893.07 MHz
824.01 - 848.97 MHz
10 kHz alternate channel
second alternate channel
2 ms
43 + 10 log(mean
43 + 10 log(mean
-111 dBm
-98 dBm
-100 dBm
-101 dBm
16 dB
+ 3 dB relative
-45 dBm
-41 dBm
-41 to -32 dBm
-32 dBm
-32 to -26 dBm
-21 dBm
-47 dBm
-80 dBm
-60 dBm
-55 dBc/Hz
-75 dBc/Hz
-26 dBc
-45 dBc
-60 dBc / – 23dBm (whichever is lower)
19.2kbps + 50ppm
60 dB
- 6 dB absolute
- 3 dB relative
0.5 – 5%
19.2kbps – 50ppm
output power in Watts) dB
TITLE:
Hardware Interface Specification for
Expedite Wireless IP Modem
OM-01016529
SHEET:
14 of 17
REV:
3.0
CDPD
Part 409
Specification Parameter Condition Upper Limit Lower limit
Watts) dB
5 INSTALLATION INSTRUCTIONS
Unless the final product satisfies SAR (Specific Absorption Ratio) compliance through separate FCC approval, integration of this module into other products has some requirements which are outlined below.
5.1 Antenna Mounting
The antenna must be mounted at a location such that no person(s) can come closer than 20 cm (7.9 inches) to the antenna when the transmitter is operating.
5.2 Antenna
This module is limited to operate with an antenna with maximum of 2.15 dBi nominal gain or not to exceed 1.5 Watts ERP for any type of remotely mounted outdoor external antenna.
5.3 Labeling
The following label, visible to all persons exposed to the transmitter, must be provided on the end product unless SAR compliance can be demonstrated:
46.00mm.
25.40mm.
Warning
be at least 20 cm from antenna when transmitter operating to meet FCC RF exposure requirements
:
All persons must
5.4 User Manual
You must also provide the above warning in the user manual for the end product and also include the following:
Do not substitute any antenna for the one supplied by the manufacturer. You may be exposing person(s) to harmful radiation. contact the supplier or manufacturer for further instruction.
NOVATEL WIRELESS
TITLE:
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
15 of 17
3.0
5.5 Mounting
Several methods are available for mounting the Expedite modem. The simplest for space constrained applications is a pressure fit. For applications where vibration is not an issue, double sided adhesive works well, although makes disassembly difficult. For applications where vibration is a concern, two mounting straps are available, a surface mount soldered version (Novatel part number 649496 00233 6) and a through – hole soldered version ( Novatel part number 649496 00232 9).
NOVATEL WIRELESS
TITLE:
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
REV:
16 of 17
3.0
6 PACKAGING REQUIREMENTS
6.1 Shipping Packaging
Packaging shall be appropriate for the shipping method. If the modem is to leave the ESD controlled environment, it should be packaged in an antistatic bag.
6.2 Labeling
The modem labeling shall include: Product Label with FCC ID, country of origin, serial number, part number, and FCC compliance statement.
NOVATEL WIRELESS
TECHNOLOGIES LTD.
Calgary, Alberta
DOCUMENT NO.:
TITLE:
OM-01016529
Hardware Interface Specification for
Expedite Wireless IP Modem
SHEET:
17 of 17
REV:
3.0
Loading...
