Intermec Technologies 802MIG2 User Manual
Preliminary OEM installation manual
Intersil ISL38001M
IEEE 802.11g MiniPCI WLAN Card
OEM installation Manual
Version 0.1
Page 1 of 10
Preliminary OEM installation manual
Table of Contents
0-INTRODUCTION....................................................................................................3
1-OEM INSTALLATION PROCEDURE ................................................................ 3
1.1 INSTALLING THE MINIPCI CARD INTO THE HOST PC NOTEBOOK ....................3
1.2 INSTALLING THE SOFTWARE DRIVERS................................................................3
1.3 WIRELESS LAN INSTALLATION GUIDE LINES AND AUTHORIZATION FOR USE .7
2-REGULATORY INFORMATION ........................................................................7
2.1 FCC INFORMATION TO USER .............................................................................7
FCC GUIDELINES FOR HUMAN EXPOSURE........................................................ 7
2.2
2.3
FCC ELECTRONIC EMISSION NOTICES.............................................................. 7
2.4 FCC RADIO FREQUENCY INTERFERENCE STATEMENT.....................................8
2.5 EXPORT RESTRICTIONS....................................................................................... 8
2.6 EUROPE - EU DECLARATION OF CONFORMITY .................................................9
3-TECHNICAL SPECIFICATIONS.......................................................................10
Page 2 of 10
Preliminary OEM installation manual
0-Introduction
The Intersil ISL38001M WLAN NIC is a complete wireless high speed Network Interface Card (NIC).
It conforms to the IEEE 802.11g protocol and operates in the 2.45 GHz ISM frequency bands.
It provides a complete reference design evaluation platform of hardware and software to system
providers or integrators requiring wireless data communications capability and is ideal for integration
into computer platforms.
• Fully compliant with the IEEE 802.11g WLAN standards
• FCC Certified Under Part 15 (pending) to Operate in the 2.45 Bands
• Support for 54, 48, 36, 24, 18, 12, 9, and 6 Mbps OFDM, 11 and 5.5 Mbps CCK and legacy 2 and 1
Mbps data rates
• Driver Supports Microsoft Windows ® 98/SE, ME, XP and 2000 (SR1)
1-OEM Installation procedure
1.0 Host PC Notebook
The Intersil ISL38001M WLAN MiniPCI Card is authorized to be installed into the following host PC
notebooks:
1—IBM Thinkpad type R30 series
1.1 Installing the miniPCI card into the host PC Notebook
a-open miniPCI slot cover of host PC Notebook housing (please observe the necessaru ESD
precautions).
b-insert miniPCI card into miniPCI slot
c-connect the host PC notebook antennas to the miniPCI card antenna connectors (Hirose type UFL
connector)
d-close miniPCI slot cover of host PC Notebook housing
1.2 Installing the software drivers
a-Start windows
b-When windows detects new hardware and asks for drivers, point to directory where the Intersil driver
is located (for example floppy drive, cdrom , harddisk) to install.
c-after drivers are installed, restart windows
d-the Intersil WLAN icon will appear in system tray on the bottom right of the screen (see yellow
arrow in fig. 01)
fig, 01: Intersil WLAN icon
Page 3 of 10
