Mobile Computer
For Windows Embedded Handheld 6.5
User’s Manual
Contents
DRAFT
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Global Services and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Warranty Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Web Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Send Feedback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Who Should Read This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Patent Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
About the Computer Features 1
About the CN51 Mobile Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About Language Provisioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
About the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Charge the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Change the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
About Battery Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
About Battery Life and Conservation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Contents
About the Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
About the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Configure the Keypad Backlight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
About the Color-Coded Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
How to Capitalize Characters on the QWERTY Keypad . . . . . . . . . . . . . . . . . . . . .14
How to Capitalize Characters on the Numeric Keypad . . . . . . . . . . . . . . . . . . . . . . 15
About the Power Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
About the Screen Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Configure the Screen Backlight Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
About the Audio Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Adjust the Speaker Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
About the Imager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Read Bar Codes with the Imager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Connect a Bluetooth Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
CN51 Mobile Computer User Manual - DRAFT i
Contents
DRAFT
Insert a MicroSD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
How to Transfer Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Set Up the Computer as a Mass Storage Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
CN51 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
About the User Interface and Intermec Applications 25
About the User Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
About the Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
About Screen Gestures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Title Bar Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Configure the Screen Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Calibrate the Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
About Intermec Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Intermec Applications on the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Downloadable Intermec Applications for the Computer. . . . . . . . . . . . . . . . . . . . .32
About Features Demo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
About Intermec Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
About Intermec HTML5 Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
About Intermec Launcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
About Intermec Terminal Emulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
About SmartSystems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Use the Phone 35
About the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Activate the UMTS Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
About Worldwide UMTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Activate the CDMA Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Make a Phone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Make an Emergency Phone Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Configure Phone Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
About Adding and Switching Between Network Carriers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Enable Automatic Configuration of Carrier Settings . . . . . . . . . . . . . . . . . . . . . . . . 43
Switch Carriers Using Intermec Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
ii CN51 Mobile Computer User Manual - DRAFT
Use the Camera 45
DRAFT
About the Color Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
How to Take Pictures and Record Videos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Take a Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Record a Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Save Pictures and Videos to a microSD Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Configure or Create Camera Scenes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Configure Camera Settings for Pictures and Videos . . . . . . . . . . . . . . . . . . . . . . . . . 51
How To Read Bar Codes With the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Enable or Disable Reading Bar Codes With the Camera . . . . . . . . . . . . . . . . . . . . . 62
Read Bar Codes With the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Camera Settings for Reading Bar Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
How to Perform Document Capture With the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Enable or Disable Document Capture With the Camera . . . . . . . . . . . . . . . . . . . . . 66
Perform Document Capture With the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Camera Settings for Document Imaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Use GPS 69
Scene Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Camera Settings for Pictures and Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
About the Integrated GPS on Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Use the GPSID Installed on the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
About the GPS Module Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Improve GPS Performance on the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Configure the Computer 73
How to Configure the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
About Intermec Settings on the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Start Intermec Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
About the Structure of Intermec Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
How to Navigate in Intermec Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Enable Intermec Settings Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Restore Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Configure the Computer Remotely with SmartSystems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
CN51 Mobile Computer User Manual - DRAFT iii
About Network Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
DRAFT
Configure 802.11 Radio Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
About Bluetooth Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Turn On the Bluetooth Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Connect a Bluetooth Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Create a Configuration Bar Code with EasySet . . . . . . . . . . . . . . . . . . . . . 85
Connect to a Bluetooth Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Connect a Bluetooth Audio Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
About Serial and USB Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
About Wireless Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Load a Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
How to Make Your Security Choice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Select a Funk Security Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Configure WPA or WPA2 Enterprise (802.1x) Security with Funk Securi-
ty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Configure WPA or WPA2 Personal (PSK) Security with Funk Security92
Configure 802.1x Security with Funk Security . . . . . . . . . . . . . . . . . . . . . . 93
Configure LEAP Security with Funk Security . . . . . . . . . . . . . . . . . . . . . . .94
Configure Static WEP Security with Funk Security. . . . . . . . . . . . . . . . . .94
Use Open (No Security) Associations with Funk Security . . . . . . . . . . . .95
Select Microsoft as Your Security Choice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Configure WPA or WPA2 Enterprise (802.1x) Security with Microsoft Se-
curity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Configure WPA or WPA2 Personal (PSK) Security with Microsoft Securi-
ty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Configure 802.1x Security with Microsoft Security. . . . . . . . . . . . . . . . . . 97
Configure Static WEP Security with Microsoft Security . . . . . . . . . . . . .98
Use Open (No Security) Associations with Microsoft Security. . . . . . . . 98
Manage the Computer 101
About Managing the Computer in Your Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
How to Manage the Computer Using CloneNGo . . . . . . . . . . . . . . . . . . . . . . . . . .102
How to Manage the Computer Using SmartSystems . . . . . . . . . . . . . . . . . . . . . . .102
How to Develop and Install Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
About Packaging Your Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Install Applications Using SmartSystems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Install Applications Using Microsoft Synchronization Software. . . . . . . . . . . . .104
Install Applications Using a microSD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
How to Launch Applications Automatically . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
How to Update the System Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Update the Computer Using SmartSystems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
iv CN51 Mobile Computer User Manual - DRAFT
Update the Computer Using a microSD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
DRAFT
Troubleshoot and Maintain the Computer 109
About the Intermec Dashboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
About Troubleshooting the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Wi-Fi Connection Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Check Wi-Fi Network Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
802.1x Security Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Troubleshoot the Scanner with Scan Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . .115
Problems Reading Bar Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Problems Using the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Call Product Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Locate Your Configuration Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Locate Your Operating System Version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
How to Restart the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Reboot the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Cold Boot the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Clean Boot the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Clean the Computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
Specifications 123
Physical and Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
EA31 Typical Reading Distances - Extended Reading Range . . . . . . . . . . . . . . . .126
EA31 Imager Minimum Reading Distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
EA31 Imager Typical Reading Distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128
EA30 Typical Reading Distances - Extended Reading Range . . . . . . . . . . . . . . . .130
EA30 Area Imager Minimum Reading Distances . . . . . . . . . . . . . . . . . . . . . . . . . . .131
EA30 Imager Typical Reading Distances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
Keypads and Keystrokes 135
Standard Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136
CN51 Keypads and Keystrokes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136
CN51 Mobile Computer User Manual - DRAFT v
DRAFT
vi CN51 Mobile Computer User Manual - DRAFT
Before You Begin
DRAFT
This section provides you with safety information, technical support
information, and sources for additional product information.
Safety Information
Your safety is extremely important. Read and follow all warnings and
cautions in this document before handling and operating Intermec
equipment. You can be seriously injured, and equipment and data can
be damaged if you do not follow the safety warnings and cautions.
This section explains how to identify and understand dangers,
warnings, cautions, and notes that are in this document. You may also
see icons that tell you when to follow ESD procedures and when to
take special precautions for handling optical parts.
A caution alerts you to an operating procedure, practice,
condition, or statement that must be strictly observed to prevent
equipment damage or destruction, or corruption or loss of data.
Before You Begin
Note: Notes either provide extra information about a topic or contain
special instructions for handling a particular condition or set of
circumstances.
Global Services and Support
Warranty Information
To understand the warranty for your Intermec product, visit the
Intermec web site at www.intermec.com and click Support >
Returns and Repairs > Warranty.
Disclaimer of warranties: The sample code included in this document
is presented for reference only. The code does not necessarily
represent complete, tested programs. The code is provided “as is with
all faults.” All warranties are expressly disclaimed, including the
implied warranties of merchantability and fitness for a particular
purpose.
CN51 Mobile Computer User Manual - DRAFT vii
Before You Begin
DRAFT
Web Support
Visit the Intermec web site at www.intermec.com to download our
current manuals (in PDF).
Visit the Intermec technical knowledge base (Knowledge Central) at
www.intermec.com and click Support > Knowledge Central to
review technical information or to request technical support for your
Intermec product.
Send Feedback
Your feedback is crucial to the continual improvement of our
documentation. To provide feedback about this manual, please
contact the Intermec Technical Communications department directly
at TechnicalCommunications@intermec.com.
Telephone Support
In the U.S.A. and Canada, call 1-800-755-5505.
Outside the U.S.A. and Canada, contact your local Intermec
representative. To search for your local representative, from the
Intermec web site, click About Us > Contact Us.
Who Should Read This Manual
This user manual is for the person who is responsible for installing,
configuring, and maintaining the CN51.
This document provides you with information about the features of
the CN51, and how to install, configure, operate, maintain, and
troubleshoot it.
Before you work with the CN51, you should be familiar with your
network and general networking terms, such as IP address.
Related Documents
The Intermec web site at www.intermec.com contains our
documents (as .pdf files) that you can download for free.
To do wnload docume nts
1 Visit the Intermec web site at www.intermec.com.
2 Click the Products tab.
viii CN51 Mobile Computer User Manual - DRAFT
3 Using the Products menu, navigate to your product page. For
DRAFT
example, to find the CN51 computer product page, click
Computers > Handheld Computers > CN51.
4 Click the Manuals tab.
If your product does not have its own product page, click Support >
Manuals. Use the Product Category, the Product Family, and
Product to find your documentation.
Patent Information
Product is covered by one or more of the following patents:
x,xxx,xxx; x,xxx,xxx; x,xxx,xxx.
There may be other U.S. and foreign patents pending.
Before You Begin
CN51 Mobile Computer User Manual - DRAFT ix
Contents
DRAFT
x CN51 Mobile Computer User Manual - DRAFT
1
DRAFT
About the Computer Features
This chapter introduces the CN51 Mobile Computerwith
Windows® Embedded Handheld 6.5operating system. Use this
chapter to learn about basic computer features and functions,
as well as the available accessories for it.
1
Chapter 1 — About the Computer Features
DRAFT
About the CN51 Mobile Computer
The Intermec CN51 Mobile Computer is the class-leading mid-range
rugged mobile computer that empowers mobile workers with the
resources to satisfy and delight customers efficiently today and earn
new business tomorrow.
The CN51 is available with the following features:
• Windows Embedded Handheld 6.5 operating system
• 1.5 GHz dual-core multi-engine processing with long battery life
• 1 GB DRAM, 16 GB Flash memory
• Large, outdoor-viewable WVGA display with full-size keypad
• Resistive multi-touch touch panel
• Bluetooth radio
• UMTS/HSPA+/CDMA or UMTS/HSPA+ WAN radio options;
both options support voice and data
• IEEE 802.11a/b/g/n on computers without a cellular radio, IEEE
802.11b/g/n on computers with a cellular radio
• Customer-accessible microSD slot for removable memory cards
(up to 32 GB)
• High-performance EA30 or EA31 area imager options, for reading
bar codes and capturing signatures
• HTML5 support
• Integrated GPS receiver (with WAN radio option)
• Accelerometer that can automatically sense the angle of the
computer and rotate the display between portrait and landscape
• 5-megapixel color camera
2 Document Title
/PUJGJDBUJPO-&%
*NBHFS
$BNFSB
#BUUFSZ
SFMFBTFUBC
4JEFTDBO
CVUUPO
3FDPSE
CVUUPO
DRAFT
1PXFSCVUUPO
CN51 Front View
Chapter 1 — About the Computer Features
4QFBLFS
(PPESFBE-&%
4DBOCVUUPO
7PMVNFCVUUPOT
#BUUFSZTUBUVT-&%
.JDSPQIPOF
CN51 Back View
Document Title 3
Chapter 1 — About the Computer Features
DRAFT
About Language Provisioning
You are prompted to select a language provision when the computer
starts for the first time. It may take up to 15 minutes to load your
language. Once loaded, your selected language will persist through all
boot scenarios (warm, cold, or clean).
Make sure you select the correct language before you tap Provision. If
you need to change the language provisioning, you must reinstall the
operating system and restart the computer. When the computer
restarts, select your new language.
About the Battery
The CN51 uses a Model 1015AB01 battery as its main power source.
The battery has a 14.4 Watt hour capacity. Several factors determine
the life of your battery, such as display brightness, display timeout,
input devices, extreme temperatures, and your usage.
Fully charge the battery before you use the CN51. When you change
the battery, the computer automatically goes into a power-off state
and then cold boots.
Caution: The battery used in this device may present a fire or
chemical burn hazard if it is mistreated. Do not disassemble it,
heat it above 100 ºC (212 ºF) or incinerate it. Dispose of used
batteries promptly. Keep away from children.
Contact your Intermec representative for replacement batteries.
Charge the Battery
Make sure you fully charge the battery (Model 1015AB01) before you
use your CN51. You can charge the battery before or after you install it
in the CN51. A fully discharged battery charges in approximately 6
hours.
• Insert the battery into a quad battery charger, a single dock, or a
multidock, or attach external power to the CN51 with the battery
installed.
The battery is fully charged when the battery status LED shows a
steady green.
4 Document Title
Use these Intermec accessories to charge the CN51 batteries:
DRAFT
• Quad Battery Charger (Model AC21)
• Charge-Only Multidock (Model AD23)
• Ethernet Multidock (Model AD24)
• Single Dock (Model AD27)
• Vehicle Power Adapter (Model AE36)
• AC Power Adapter (Model AE37)
Change the Battery
When the battery in the CN51 has a low charge, replace it with a
charged battery.
Note: When you remove a battery from the computer, Intermec
recommends that you install a charged battery within five minutes to
maintain your network connections.
1 Save your files and close all open applications.
2 Press the Power button, and then select Hibernatefrom the menu.
3 If necessary, disconnect the handstrap from the top of the
computer.
Chapter 1 — About the Computer Features
4 Push forward on the battery release tab until the battery releases,
and then lift the battery away from the computer.
Document Title 5
Chapter 1 — About the Computer Features
DRAFT
5 Insert the bottom of a fully charged battery into the CN51, and
press down on the top until it clicks into place.
6 If necessary, reattach the handstrap.
About Battery Status
Use the battery icon on the Title bar to view the power status of the
battery.
Battery Status Icons
Icon Status
Battery is fully charged.
Battery has medium charge.
Battery is low. You need to replace the battery soon.
Battery is critically low. You need to replace the battery now.
Battery is charging.
6 Document Title
Chapter 1 — About the Computer Features
#BUUFSZ
TUBUVT-&%
DRAFT
The Battery status LED below the computer screen indicates the
charging status of the battery.
Battery LED States
LED State Description
Steady green The computer is connected to a charger and the
battery is more than 95% charged.
Blinking green The computer is connected to a charger and the
battery is between 60% and 95% charged.
Steady red The computer is connected to a charger and the
battery is less than 60% charged.
Blinking red The battery is very low. The computer will soon go
into Suspend mode. Charge or replace the battery.
Amber There is a battery error. The battery is not charging
Off No battery is installed. The CN51 does not turn on if
Document Title 7
because it is missing, faulty, or outside the allowable
charging temperature range. If it is outside the
charging temperature range, charging will resume
when the battery temperature returns to the
acceptable range of 0 °C to 45°C (32 °F to 113 °F).
no battery is installed.
Chapter 1 — About the Computer Features
DRAFT
About Battery Life and Conservation
Batteries that are stored outside the computer for long periods of time
slowly discharge. Intermec recommends storing the battery in a
charger to maintain battery performance.
Battery Conservation Tips
When You Want to: Do this to Save Battery Power:
Use the computer and the low
battery status icon appears or the
battery light turns on.
Stop using the computer for 5
minutes or longer.
Store the computer for more than
a day.
Store the battery outside the
computer.
• Connect the computer to an external
• Or, save your data, press the Power
Make sure that the low battery status icon
is not on the screen and the battery status
LED is not on. Press the Powerbutton
and select Suspend to suspend the
computer.
If you have enabled the Sleep face down
feature in Intermec Settings, the CN51
automatically suspends when you lay the
computer face down.
• If you are storing the computer for a
• If you are storing the computer for
• If you store the battery for several
Store the battery in a charger.
power source.
button, and select Hibernate. After
the computer turns off, remove the
battery and insert a fully charged
battery.
few days, like over the weekend, install
a charged battery or connect the
computer to a power source.
longer, remove and charge the battery,
and then store both the battery and
computer in a cool location.
months, recharge the battery to keep it
at peak performance.
8 Document Title
About the Status LEDs
DRAFT
The status LEDs turn on, turn off, or blink to indicate a specific
activity on your computer.
Chapter 1 — About the Computer Features
Status LED Locations
Main Status LED Descriptions
Callout LED Color Description
1 Notification Orange Windows Mobile 6.5 notification.
2 Good Read Green Good read of a bar code.
Document Title 9
Blinking
red
Blinking
green
Bad read of a bar code.
The data collection engine is
processing or starting up.
Chapter 1 — About the Computer Features
DRAFT
Main Status LED Descriptions (Continued)
Callout LED Color Description
2 Intermec
Ready-to-Work
™ indicator
3 Battery status Steady
Blue If Intermec Terminal Emulator (ITE)
is installed, the application is
running and is connected to the
host.
If you do not have ITE, you can
configure the Ready-to-Work
indicator to turn on or off to
indicate a healthy state.
Blinking
blue
Off ITE is not installed or not running.
green
Blinking
green
Steady red The computer is connected to a
Blinking
red
Amber There is a battery error. The battery
Off The computer is not on external
ITE is running but not connected to
the host. The computer is unhealthy.
The computer is healthy.
The computer is connected to a
charger and the battery is more than
95% charged.
The computer is connected to a
charger and the battery is between
60% and 95% charged.
charger and the battery is charging.
The battery is very low, and the
computer will go into Suspend mode
soon. Charge or replace the battery.
is not charging because it is missing,
faulty, or outside the allowable
charging temperature range. If it is
outside the charging temperature
range, charging will resume when
the battery temperature returns to
the acceptable range of 0 °C to 45 °C
(32 °F to 113 °F).
power and the battery is operating
normally.
10 Document Title
Chapter 1 — About the Computer Features
DRAFT
Location of Orange and Green Key LEDs
Orange and Green Key Status LEDs
Callout LED Color Description
4 Orange key status Orange The Orange shift plane is
enabled. You can type
characters or access functions
printed in orange on the
keypad.
4 Orange/green key
status
Document Title 11
Orange or
green
When the LED is orange, the
Orange shift plane is enabled.
You can type characters or
access functions printed in
orange on the keypad.
When the LED is green, the
Green shift plane is enabled.
You can type characters or
access functions printed in
green on the keypad.
Chapter 1 — About the Computer Features
DRAFT
Orange and Green Key Status LEDs (Continued)
Callout LED Color Description
5 Green key status Green The Green shift plane is
About the Keypad
The CN51 comes with either a numeric keypad or a QWERTY keypad:
• The numeric keypad is for applications that require mainly
numeric data. This keypad also lets you enter special characters,
including the alphabet, by pressing color-coded key sequences.
• The QWERTY keypad is designed for applications that require
primarily alphabetic data. This keypad also lets you enter special
characters by pressing color-coded key sequences.
enabled. You can type
characters or access functions
printed in green on the
keypad.
CN51 Numeric Keypad
12 Document Title
CN51 QWERTY Keypad
DRAFT
Configure the Keypad Backlight
You can configure the keypad backlight to always turn on, always stay
off, or turn on depending on the lighting level of your work
environment.
1 Start Intermec Settings.
2 Tap Device Settings > Backlight > Keypad.
Chapter 1 — About the Computer Features
3 Select the options you want for the keypad backlight:
• Select Always offto prevent the keypad backlight from turning
on.
• Select Automatic to turn on the keypad backlight
automatically based on the ambient light level.
• Select On With the Display to turn on the keypad backlight
only the display is on. When the CN51 suspends, the keypad
backlight turns off to save power.
• Select Always on to turn the keypad backlight on all the time.
4 Tap OK.
About the Color-Coded Keys
Note:The CN51 with QWERTY keypad does not have a green key.
Document Title 13
Chapter 1 — About the Computer Features
M
DRAFT
Use the orange key and the green key to access additional
characters, symbols, and functions printed on the keypad overlay.
After you understand how to use the color-coded keys and key
sequences, you can access all of the additional features printed on the
keypad overlay.
The default setting for the Green/Orange keys is Press twice to lock.
You can also set the keys to Press once to lock if you do not want the
Green/Orange keys to lock after pressing them twice. The information
in this section assumes that you are using the default setting for the
Green/Orange keys lock options. To change the setting for the
Green/Orange keys, go to Start > Settings > System > Intermec
Settings > Device Settings > Keypad.
How to Use the Color-Coded Keys
You Want To Press Example
Use an orange
character or
function printed
above a key.
Use a green
character or
function printed
above a key.
Unlock the green or
orange key.
(LED turns on), and then
the key with the character or
function printed above it
(LED stays on).
(LED turns on), and then
the key with the character or
function printed above it
(LED stays on).
or once. Press or once to
On the alphanumeric
keypad, press , then
press to type the
number 9.
On the numeric keypad,
press , then press to
type a backslash (\).
unlock the key. The LED
turns off.
How to Capitalize Characters on the QWERTY Keypad
If your CN51 has the QWERTY keypad, you can capitalize characters
individually, or you can type all capital letters by enabling Caps Lock:
• To capitalize a single character, press the Shift key, and then the
character.
• To enable Caps Lock, press the Shift key and then .
• When Caps Lock is enabled, press Shift again to disable Caps Lock.
14 Document Title
Chapter 1 — About the Computer Features
DRAFT
How to Capitalize Characters on the Numeric Keypad
If your CN51 has the numeric keypad, you can capitalize characters
individually, or you can type all capital letters by enabling Caps Lock:
• To capitalize a single character, press the key, and then the <1>
key. Select the key with the letter you want to capitalize. Press <1>
again to return to lowercase letters.
• To enable Caps Lock, press and then press .
• To disable Caps Lock, press again.
About the Power Button
When you press and release the Power button, the Intermec Power
Options screen appears with a list of power options. If you do not
select a power options setting, the currently selected action (the button
outlined in bold) occurs after the timeout. Hibernate does not appear
as an option if the computer is connected to external power.
The Intermec Power Options Default Screen
Use the next table to understand the Intermec Power Options and
what settings are available for your computer.
Document Title 15
Chapter 1 — About the Computer Features
DRAFT
Intermec Power Options
Option Description
Hibernate (battery swap) High power saving mode. The computer
Suspend Medium power saving mode. When on
Reboot The computer does not save the current
Cancel Cancels the Intermec Power Options
Screen Off Lowest power saving mode. The screen
Shutdown Very high power saving mode. The
saves the current system state, registry,
and file system and then powers off all
radios and internal devices. You can wake
the computer by pressing the Power
button or connecting the computer to
external power.
battery power, Suspend mode saves the
current system state and then turns off
most radios and internal devices. The
WWAN radio remains in a lower power
state and can still receive calls. When the
computer is connected to external power,
Suspend mode turns off the screen but
leaves all radios on. You can wake the
computer by pressing the Power button,
pulling the scanner trigger, or scheduling
an event such as an alarm. If the
computer is on battery power during
Suspend mode, you can also wake the
computer by connecting it to external
power.
system state, but the registry and file
systems are saved. The computer shuts
down all running processes and restarts.
menu.
turns off, but the radios and internal
devices stay on. Tap the screen to turn it
back on.
computer turns off everything. You must
press Power or apply external power to
restart the computer.
16 Document Title
Chapter 1 — About the Computer Features
DRAFT
If you are using WPA or 802.1x security, the computer may need to
reauthenticate before it resumes your application. The Real Time
Clock (RTC) will persist through all of the power options as long as it
receives power from the Real Time Clock battery.
The Intermec Power Options screen is customizable. You can use
Intermec Settings to determine which options are available to end
users, the timeout until the default choice is selected, the default
action if no option is selected, or to disable the Power Options Screen.
About the Screen Backlight
The display has an ambient light sensor that automatically adjusts the
backlight intensity to conserve power and ensure the display is
readable. You can set the backlight intensity levels as needed for your
environment.
Configure the Screen Backlight Brightness
Use Intermec Settings to configure the brightness of the screen
backlight.
1 Tap Start > Settings > System > Intermec Settings.
2 Tap Device Settings > Backlight > Display.
3 Select a brightness level. The default value is +1.
4 Tap OK and exit Intermec Settings.
About the Audio Features
Your mobile computer has a speaker, a microphone, and several
software tools for configuring the volume of sounds.
Adjust the Speaker Volume
The computer volume includes sounds you hear when you tap the
screen or scan bar codes with a scanner.
1 Tap the Title bar at the top of the screen.
2 Tap the Volume icon .
Document Title 17
Chapter 1 — About the Computer Features
DRAFT
3 Use your stylus to adjust the volume slider.
4 Tap OK.
5 Tap the Title bar.
6 Tap the Volume icon .
7 Adjust the volume slider.
About the Imager
The computer has an EA30 or EA31 area imager that can read 1D and
2D bar code symbologies, composite symbologies, and postal codes.
You can also use the imager to take pictures as if it were a camera.
You can also use Bluetooth communications to connect the computer
to cordless scanners, such as the SF51 and SR61.
Read Bar Codes with the Imager
All of the imagers have an aiming beam to help you correctly frame bar
codes and they support omni-directional (360°) scanning.
Before you start reading bar codes, use Intermec Settings to:
• enable only the bar code symbologies that you need.
• choose the predefined imager mode that best suits your
environment.
Predefined Mode For Scanning
1D Only 1D labels.
1D and 2D Standard (Default) All types of bar code labels.
1D and 2D Bright Environment In high ambient light, such as outdoors
in sunshine.
1D and 2D Reflective Surface Glossy Labels.
1 Point the imager window at the bar code and hold the computer
steady a few inches from the label.
2 Press the Scan button or pull the scan handle trigger. The
illumination beam, laser pointer, or frame appear.
18 Document Title
Chapter 1 — About the Computer Features
DRAFT
For near or close-in scanning distances of 30 cm (11.8 in) or less,
use the laser pointer as a guide and aim slightly to the right of the
center of the bar code. Make sure the illumination beam covers the
bar code you are trying to decode.
For standard and long range scanning distances of 30 cm (11.8 in)
or more, use the laser pointer as a guide and aim toward the middle
of the bar code. Make sure that the illumination beam covers the
bar code you are trying to decode.
When the imager successfully reads a bar code label, you hear a
high beep, and the Good Read LED turns on briefly.
3 Release the Scan button or trigger.
Document Title 19
Chapter 1 — About the Computer Features
DRAFT
Connect a Bluetooth Scanner
You can connect the computer to an Intermec Bluetooth scanner, such
as the SF51 or SR61. Make sure that the Bluetooth radio in the
computer is turned on before you try to connect to a scanner.
1 Tap Start > Settings > System > Wireless Scanning.
2 Tap Add Device.
3 Select Quick Connect, Search, or Manual. Follow the
instructions on the screen to add a Bluetooth scanner.
After you add a Bluetooth scanner, you can configure scanner
settings and parameters in Intermec Settings.
Insert a MicroSD Card
You can use a micro Secure Digital (SD) card to increase file storage
capacity or to install software. The CN51 supports an optional 32 GB
maximum capacity microSD™ card. The card slot is located in the
battery compartment.
1 Remove the battery and open the card access door in the battery
compartment.
2 Slide the SIM card holder to the left to unlatch it, and lift the
holder to open it and access the microSD card holder.
20 Document Title
Chapter 1 — About the Computer Features
DRAFT
3 Slide the microSD card holder towards the top of the CN51 to
unlatch it, and lift the holder to open it.
4 Place the microSD card in the holder with the contacts facing away
from the holder.
5 Close and latch the microSD card holder.
Document Title 21
Chapter 1 — About the Computer Features
DRAFT
6 Close and latch the SIM card holder, and close the card access door
until it snaps shut.
7 Install the battery and turn on the computer.
You should now be able to navigate to the Storage Card folder and
view the contents of the microSD card.
How to Transfer Files
To transfer files you need to physically connect your mobile computer
to your PC and install either Microsoft ActiveSync (Windows XP or
earlier) or Windows Mobile Device Center (Windows Vista or Windows
7) on your PC. ActiveSync and Windows Mobile Device Center are free
applications available from the Microsoft website at
www.microsoft.com/downloads.
Use one of these accessories to connect your mobile computer to your
PC:
• USB cable (P/N 236-297-001)
• CN51 USB Snap-On Adapter
• CN51 Desktop USB Adapter
• AD27 Single Dock
22 Document Title
Chapter 1 — About the Computer Features
DRAFT
Set Up the Computer as a Mass Storage Device
Use the computer as a mass storage device so you can easily copy files
to and from the mobile computer and your desktop PC.
1 Go to www.datalight.com and download the Reliance Nitro
Windows Driver (RNWD).
2 Connect the mobile computer to your desktop PC using a USB
cable or USB-capable accessory.
3 On the mobile computer, tap Start > Settings > System >
Intermec Settings.
4 Tap Device Settings > USB.
5 From the USB function driver menu, select Mass storage - Flash
File Store and tap OK.
6 Copy files to and from your desktop PC to the mobile computer.
CN51 Accessories
The CN51 ships with a battery. All other accessories are sold and
ordered separately. For help, contact your local Intermec sales
representative.
Accessory Description
CN51 AC Power Adapter (Model
AE37)
CN51 Battery (Model 1015AB01) The battery provides power to the CN51.
CN51 Charge-Only Multidock
(Model AD23)
Document Title 23
The CN51 AC Power Adapter provides a
connection for external AC power to the
CN51. To use this adapter, you need to
purchase a country-specific power cord.
Keep a spare battery pack on hand.
Use the charge-only multidock to hold up
to four CN51s with batteries installed,
charge batteries, and provide power to the
computers.
Chapter 1 — About the Computer Features
DRAFT
Accessory Description
DX1 Desktop Dock, DX2 Dual
Dock, DX4 Quad Dock
Ethernet Adapter Use the Ethernet adapter to connect the
CN51 Ethernet Multidock
(Model AD24)
CN51 Replacement Handstrap Use a replacement handstrap to replace a
CN51 Magnetic Stripe Reader
(Model AR9)
CN51 Quad Charger (Model
AC21)
CN51 RS-232 Adapter This accessory snaps on to the CN51 and
CN51 Single Dock (Model AD27) Use the single dock to hold a CN51 with
CN51 Tethered Stylus
Replacement
CN51 Vehicle docks (AV6, AV9) Use the vehicle docks to hold and charge
CN51 Vehicle Power Adapter
(Model AE36)
Use these docks to charge the battery
while it is installed in the CN51, or to
charge the battery separately. The DX1
includes USB connectivity, and the DX2
and DX4 are available in Ethernet and
charge-only versions.
CN51 to your Ethernet network.
Use the multidock to hold up to four
CN51s with the batteries installed. The
multidock charges the batteries and
provides power and Ethernet connections
to each computer.
worn-out handstrap. <NEED TO
REWRITE>
This accessory snaps on to the CN51 and
provides magnetic stripe reading
capabilities.
Use the quad battery charger to charge up
to four batteries.
provides serial connectivity.
its battery installed, charge a spare
battery pack, charge the main battery
pack, and provide power to the mobile
computer. The dock has USB host and
client connectors. Optional modules are
available to convert the USB host to
Ethernet or to a landline modem.
Use a replacement stylus to replace a lost
or broken stylus.
the CN51 while using it on a vehicle.
Use the vehicle power adapter to charge
the battery installed in the CN51 from
your vehicle.
24 Document Title
2
DRAFT
About the User Interface and Intermec Applications
Use this chapter to learn about the Windows Embedded
Handheld user interface and how to interact with the screen.
You can also use this chapter to learn about the Intermec
applications on your computer, as well as additional
applications you can download.
25
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
About the User Interface
The Windows Embedded Handheld 6.5 operating system provides a
touch-friendly and easy to navigate user interface.
About the Home Screen
When you turn on your mobile computer, the Home screen is the first
screen that appears after language provisioning is complete.
Windows Embedded Handheld 6.5 Home Screen
26 Document Title
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
Home Screen Navigation Bars
Callout Navigation Bar Description
1 Title bar Use the Title bar icons to view the current
status of information such as signal strength
and battery power remaining.
2 Horizontal scroll bar A horizontal scroll bar appears when you tap
the Title bar. The horizontal scroll bar makes
it easy to access the applications associated
with the Tile bar icons. The horizontal scroll
bar also contains a magnifier which improves
the touch experience by making parts of the
screen large enough to tap with your finger.
The horizontal scroll bar also replaces tabs
within Windows screens and allows for easier
navigation.
3 Tile bar Use the Tile bar to access the Start menu,
navigate within applications, and open the
SIP.
The Clock & Alarms screen shows how the horizontal scroll bar
appears when you open an application.
Document Title 27
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
Clock & Alarms Screen with Horizontal Scroll Bar
About Screen Gestures
The Windows Embedded Handheld 6.5 interface supports the use of
gestures with the finger or stylus to move around the screen.
Screen Gestures
Gesture Description
Tap Represents the left click of a mouse.
Double-tap Represents the left double-click of a mouse.
Hold Represents the right click of a mouse when you press and
hold on the screen and a context menu appears.
Flick Initiates scrolling in the direction (horizontal or vertical) the
finger or stylus moves across the screen.
Pan Press and hold on the screen and then drag in any direction.
Title Bar Status Icons
Tappable icons on the Title bar immediately show you the status of
your network, the volume, the battery, and the time.
Title Bar Status Icons
Icon Description
You have a new notification.
You have a new text message.
You have a new email message.
You have a new instant message.
An alarm is set.
Microphone is on.
Internet call is in progress.
28 Document Title
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
Title Bar Status Icons (Continued)
Icon Description
Bluetooth is on.
Bluetooth headset is detected.
ActiveSync connection is established.
ActiveSync synchronization is in progress.
There is a problem with the ActiveSync synchronization.
Connected to a Wi-Fi network.
Connected to a Wi-Fi network, and other networks are
detected.
Wi-Fi synchronization is in progress.
Other Wi-Fi networks are detected.
Information about a new Wi-Fi network is available.
Wi-Fi is on, but not connected to a network, and other
networks are detected.
Wi-Fi is on, but not connected to a network, and no networks
are detected.
A network connection is active.
A network connection is inactive.
The volume is on.
The volume is off.
The battery has full charge.
The battery has a high charge.
The battery has a medium charge.
Document Title 29
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
Title Bar Status Icons (Continued)
Icon Description
The battery has a low charge.
The battery has a very low charge.
The computer is attached to external power and the battery is
charging.
No battery is installed in the computer.
Configure the Screen Brightness
You can configure the screen brightness from the Start menu.
1 Tap Start > Settings > System > Backlight.
2 Adjust the slider to the desired brightness level.
3 Tap OK.
Calibrate the Screen
If the touch screen does not respond as expected when you tap it with
the stylus, you may need to calibrate the screen.
1 Tap Start > Settings > Systems > Screen.
2 Tap Align Screen and follow the instructions to align the screen.
3 Tap OK.
About Intermec Applications
Intermec provides many useful applications to help you configure,
troubleshoot, and connect your computer to other devices and
networks. You can also download additional applications from the
Intermec website to help you use all of the features of your computer.
Intermec Applications on the Computer
Intermec applications help you configure, troubleshoot, and connect
your computer to other devices and networks.
30 Document Title
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
Intermec Applications Available on the Computer
Icon Application Description
Bluetooth Audio Use the Bluetooth Audio application to
connect to a Bluetooth headset or hands-free
device.
CloneNGo Use CloneNGo to configure basic device
settings on multiple client computers from
one master computer. For more information,
see the
Intermec Settings Use Intermec Settings to configure your
computer. You can use Intermec Settings to
individually configure a computer or you can
use it through SmartSystems to configure all
of your computers.
ISpyWiFi Use ISpyWiFi to check your 802.11 status and
diagnose issues with the connection.
Profile Settings Use Profile Settings to easily configure the
computer for a specific use. You can choose
predefined values for the Power, Camera, and
Scanning settings.
ScanDiagnostic Use the ScanDiagnostic application to
troubleshoot problems with the internal or
external scanner.
CloneNGo User Guide.
Sensor Calibration Use the Sensor Calibration application to
calibrate the accelerometer.
Wireless Center Use the Wireless Center to turn the phone
and radios (Wi-Fi, Bluetooth) on and off and
configure settings for each radio.
Wireless Printing Use the Wireless Printing application to
connect to a Bluetooth printer.
Wireless Scanning Use the Wireless Scanning application to
connect to a Bluetooth scanner.
Document Title 31
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
Downloadable Intermec Applications for the Computer
You can download Intermec applications to extend the capabilities of
the computer. You may need to purchase an Intermec license to run
some applications. To find an application, go to www.intermec.com
> Support > Downloads.
About Features Demo
Intermec Features Demo provides a simple way to explore the key
features of your mobile computer. Features Demo applications
demonstrate scanning, document imaging, image capture, and
printing functionality. Many of the applications that are part of
Features Demo also have separate full-featured versions that you can
download and license for your computer. For more information on
Features Demo, see Intermec Features Demo User Guide.
About Intermec Browser
Intermec Browser is a web browser designed for Intermec computers
and is compatible with Microsoft® Internet Explorer® 6 (IE6) and
Pocket Internet Explorer (PIE). This locked-down application
deliberately limits normal web browser functionality. For example,
users cannot exit the program, type URLs, or use the Back button. You
can configure Intermec Browser for your specific application
requirements and you can design your own web pages.
You can download and use Intermec Browser for free for a 60-day
evaluation period. After the evaluation period expires, you need to
purchase a license. For more information on Intermec Browser, see the
Intermec Browser User Manual.
About Intermec HTML5 Browser
Intermec HTML5 Browser provides a free open-platform application
environment for Intermec computers.You can now run the same
cross-platform web applications on an Intermec computer that you
can run on iOS and Android devices. Intermec HTML5 Browser also
lets you run applications while the computer is connected to the web
or while it is offline. For more information on the HTML5 Browser, see
the Intermec HTML5 Browser User Guide.
32 Document Title
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
About Intermec Launcher
Intermec Launcher is a Microsoft Windows application, designed for
Intermec mobile computers, that provides a platform from which
other applications may be launched while attempting to provide a
locked-down environment. You can configure Intermec Launcher for
your specific application requirements. You can download and use
Intermec Launcher for a 60-day evaluation period. After the evaluation
period expires, you will need to purchase a license. For more
information on Intermec Launcher, see the Intermec Launcher
Version 2.00 User Guide.
About Intermec Terminal Emulator
Intermec Terminal Emulator (ITE) is Intermec’s popular terminal
emulation client designed for enterprise-level data collection. In a
single client, ITE supports multiple emulation protocols. Its features
include session persistence, remote management and configuration,
and multiple security options. ITE provides a consistent user interface
and a common menu structure (Intermec Settings), simplifying the
use and management of applications running on Intermec mobile
computers.
You can download and use ITE for free for a 60-day demo period.
During the demo period, a demo mode message box appears each time
you launch ITE. Press Enter to close the message box. When the demo
period expires, you need to purchase a license. For more information
on ITE, see the Intermec Terminal Emulator (ITE) User Guide.
About SmartSystems
Intermec SmartSystems™ is an easy-to-use centralized software
platform. With SmartSystems, IT Administrators and Integrators can
perform hands-free provisioning and deploy and manage Intermec
devices.
SmartSystems provides a consistent way to manage Intermec devices
located on-site or remotely to maximize IT resources and lower the
total cost of ownership for Intermec data collection equipment.
SmartSystems Foundation can be downloaded at no charge from the
Intermec website. For more information, visit
www.intermec.com/SmartSystems.
Document Title 33
Chapter 2 — About the User Interface and Intermec Applications
DRAFT
34 Document Title
3
DRAFT
Use the Phone
You can use the phone feature to make and receive telephone
calls, as well as transmit data through cellular wide-area
networks (WANs).
35
Chapter 3 — Use the Phone
DRAFT
About the Phone
Phone features on the computer include a speaker and a microphone.
You can also use a Bluetooth headset or hands-free kit. The phone
feature is enabled by default.
The WAN radio in your computer determines the supported network
types:
• If your computer includes the UMTS/HSPA+ WAN radio, you can
connect to UMTS networks in all regions supporting this
technology.
• If your computer includes the Flexible Network Radio, you can
connect to CDMA or UMTS networks in all regions that support
these technologies. The Flexible Network Radio is a
software-defined radio (SDR) that can be configured for CDMA or
UMTS depending on your wireless communication needs.
Intermec currently supports these CDMA network carriers:
• Sprint (United States only)
• Verizon (United States only)
For other carriers, contact Intermec Product Support.
After you turn on the phone and activate service with your wireless
carrier, you can customize the phone features and network settings.
Note: Both WAN radios support Network Information and Time
Zone (NITZ) messages to automatically set the system time.
Activate the UMTS Phone
You use a SIM card to activate the UMTS phone on the CN51. You can
purchase the SIM card from your network provider.
1 Press to turn off the CN51.
2 Disconnect the handstrap from the top of the computer.
3 Push forward on the battery release tab until the battery releases,
and then lift the battery away from the computer.
36 Document Title
Chapter 3 — Use the Phone
DRAFT
4 Open the card access door and slide the SIM card holder to the left
to open it.
5 Place the SIM card in the holder.
Document Title 37
Chapter 3 — Use the Phone
DRAFT
6 Close the SIM card holder and slide it to the right to secure it, and
then close the card access door.
7 Insert the battery and press down until it clicks in place.
8 Reconnect the handstrap.
9 Press to turn on the CN51. This screen (or similar) appears:
38 Document Title
Chapter 3 — Use the Phone
DRAFT
10 If your computer has the UMTS-only WAN radio, tap Yes. The
computer atttempts to connect to your UMTS network. When the
connection is successful, a confirming message appears. Tap OK to
close the message. The phone is ready to use.
If your computer has the software-defined radio, tap No. The
Home screen appears and the phone is ready to use. If you plan to
add additional carriers, you need to enable automatic
configuration of carrier settings in Intermec Settings.
Note: Data connections are to the public domain on your network.
About Worldwide UMTS
If your computer has the UMTS-only WAN radio, when you perform a
clean boot all user-created network connections are deleted, and only
the generic Worldwide UMTS remains. After you perform a clean boot,
you can find more information about Worldwide UMTS by tapping
Start > Settings > Connections > Connections > Tasks tab >
Manage Existing Connections > Modem tab.
Document Title 39
Chapter 3 — Use the Phone
DRAFT
Activate the CDMA Phone
To activate the CDMA phone in your mobile computer, you need to
contact your wireless carrier and set up an account.
You also need to provide the carrier with the Mobile Equipment
Identifier (MEID) for the computer. You can find the MEID:
• on a label located in the battery compartment.
• on the outside of the computer shipping box.
Note: For the CDMA phone, settings are permanently stored in the
WAN radio after activation. CDMA settings persist through a cold
boot.
The activation process is slightly different for each CDMA carrier.
Your carrier sales contact and an Intermec representative can guide
you through the process. In general, you activate the CDMA phone as
follows:
1 Contact your wireless provider and give the provider the MEID for
the computer.
2 If your carrier is Sprint, reboot the computer. As soon as the Sprint
network detects your phone, Hands-Free Activation (HFA) begins,
and a series of notification messages appear. When activation is
complete, a completion message appears and the WAN radio
reboots. The phone is ready to use.
If your carrier is Verizon, tap Start > Phone, enter *228 on the
phone keypad, and press Talk. After a short wait, a message
appears, confirming either success or failure of the activation. After
successful activation, the phone is ready to use.
3 (Optional) If you plan to use the network for data connections
(such as browsing the web), you should enable automatic
configuration of carrier settings in Intermec Settings.
Note: Data connections are to the public domain on your network.
40 Document Title
Make a Phone Call
DRAFT
After you activate your UMTS or CDMA phone, you are ready to start
making phone calls.
1 Press Phone.
2 Tap the keys to enter the telephone number you want to call, and
tap Talk.
Make an Emergency Phone Call
You can use the phone to make an emergency phone call, even if the
SIM card is missing from your UMTS phone or if you do not have a
valid CDMA account. In either case, the phone shows that you have no
service. However, if you dial certain emergency numbers (such as 112,
911, 000, 08, 118, 119, or 999) the call will go through.
Configure Phone Sounds
You can customize the ringtone, keypad sounds, and voicemail
notification sounds for the phone.
Chapter 3 — Use the Phone
1 Tap Start > Phone > the Menu button > Options.
Document Title 41
Chapter 3 — Use the Phone
DRAFT
2 Select options for the phone sounds:
• Select a Ring type from the list.
• Select a Ring tone from the list. To hear the selected ring tone,
tap the Play button.
• Select a Keypad sound from the list.
• Enter the name of the sound you want to use for voicemail
notifications in the Voicemail field.
3 Tap OK.
About Adding and Switching Between Network Carriers
If your computer includes the software-defined radio, you can easily
add carriers and switch between them as needed. When you enable
automatic configuration of carrier settings through Intermec Settings,
you only need to select a different carrier to change networks.
42 Document Title
Chapter 3 — Use the Phone
DRAFT
If you plan to add a carrier, you should enable automatic
configuration of carrier settings before you activate the phone for the
new carrier. This feature is disabled by default.
Enable Automatic Configuration of Carrier Settings
If you plan to add another WAN radio network carrier, you should
enable automatic confguration of carrier settings before you activate
the phone for the new carrier.
Note: Your computer must have the software-defined radio to use this
feature.
1 Tap Start > Settings > System > Intermec Settings.
2 Tap Communications > WWAN > Carrier Settings Auto
Config.
3 Select Enabled and tap OK.
Switch Carriers Using Intermec Settings
Use Intermec Settings to quickly change your WAN radio network
carrier.
Note:Your computer must have the software-defined radio to switch
carriers using this method.
1 Tap Start > Settings > System > Intermec Settings >
Communications > WWAN > Carrier Choice.
2 Select a Carrier and tap OK.
If the update is successful, your new carrier appears in the WWAN
settings list.
If the update is unsuccessful, the carrier does not change.
3 Tap Ok to exit Intermec Settings.
Document Title 43
Chapter 3 — Use the Phone
DRAFT
44 Document Title
4
DRAFT
Use the Camera
Learn to use the color camera to take pictures and record
videos, read bar codes, perform document capture, or perform
signature capture.
45
Chapter 4 — Use the Camera
DRAFT
About the Color Camera
The camera and flash are located on the back of the computer. You can
use the camera for several tasks, including:
• Taking pictures and videos
• Reading bar codes
• Signature capture
• Document imaging
How to Take Pictures and Record Videos
You use the Pictures & Videos application to use the camera for taking
pictures or recording videos, and to configure still photo and video
recording settings.
Note: While the Pictures & Videos application is running, you cannot
use the imager.
In the Pictures & Videos application, you can:
• take, view, and edit pictures.
• switch between Still (camera) mode and Video mode.
• record and launch video clips stored on the computer or a microSD
card.
• configure camera settings for taking pictures and videos.
Note: You must use Intermec Settings to configure camera settings for
reading bar codes, document imaging, or signature capture.
You can send pictures and videos to others or save an image as the
background on the Home screen.
Take a Picture
You run the Pictures & Videos application to use the camera for taking
pictures. When you take a picture, the image is saved as a .jpg file and
stored in the /My Documents/My Pictures folder.
1 Tap Start > Pictures & Videos.
46 Document Title
Record a Video
DRAFT
You run the Pictures & Videos application to use the camera for
recording videos. Recorded video is saved as an .mp4 file and stored in
the /My Documents/My Pictures folder.
Chapter 4 — Use the Camera
2 Tap the Camera icon in the grid, tap Camera on the taskbar, or
press Enter.
3 Using the screen as a viewfinder, move the camera until you have
the image you want to take a picture of.
4 Hold the computer as still as possible, and press Enter to take and
save the picture.
If you select to save pictures to the main memory, the pictures are
saved to permanent storage on the computer.
1 Tap Start > Pictures & Videos.
2 Tap the Camera icon in the grid or the Camera button on the Tile
bar.
3 Tap Menu > Video.
4 Using the screen as a viewfinder, move the computer until you see
the scene you want to record.
5 Press Enter to start recording.
6 When you are done, tap Stop or press Enter to stop recording and
save the video.
If you choose to save your videos to main memory, the videos are
saved to permanent storage on the computer.
Save Pictures and Videos to a microSD Card
By default, pictures and videos are saved to the /My Documents/My
Pictures folder on the computer. You can save your pictures and video
to a microSD card to easily transport them to another device.
1 Install a microSD card in the computer.
2 Tap Start > Pictures & Videos.
3 Tap the Camera icon.
Document Title 47
Chapter 4 — Use the Camera
DRAFT
4 Tap Menu > Options.
5 From the Save file to list, select SD card and tap OK.
Configure or Create Camera Scenes
Camera scenes are sets of preset values for camera settings. You can
select or create a scene to accommodate your specific needs.
1 Tap Start > SceneEditor.
2 Select a Scene to configure and then tap .
Or, to create a new scene, tap New.
3 Configure the necessary settings.
If you are creating a new scene, type the name in the Scene box.
4 Tap Save.
5 When you are prompted to save the settings, tap Yes. The changes
you made are saved.
6 Tap ok to close the message box.
Scene Settings
When you use SceneEditor to create a scene for the camera, you can
configure these settings.
48 Document Title
Chapter 4 — Use the Camera
DRAFT
Scene Settings
Setting Description
Exposure Metering The area of the image the camera uses to
determine optimal exposure:
• Whole screen avg: Uses the image as a
whole.
• Center weighted avg: Uses the entire
image but places empahsis on the
center quarter of the image.
• Center 1/4 averaged (default): Uses the
center quarter of the image.
• Lower 1/4 averaged: Uses the lower
quarter of the image.
• Upper 1/4 averaged: Uses the upper
quarter of the image.
• Lower 1/2 averaged: Uses the lower
half of the image.
• Upper 1/2 averaged: Uses the upper
half of the image.
Exposure Compensation Exposure level of the image. Values are
from -2.5 (darker, underexposed) to +2.5
(lighter, overexposed) in increments of
0.5. Default is 0.
Focus Determines if the focus is continuous,
single shot, or manual. If you select
manual focus, you need to set the Focus
Distance.
Focus Distance The distance at which the camera focuses.
Values are 2.5 in, 4.5 in, 7.5 in, 1-3 ft, 3-9
ft, and Infinity (focuses the lens so that an
infinitely distant object is in focus).
Brightness Brightness level of the image. Manual
settings are from -4 (very dark) to +4 (very
light) in increments of 1. Default is Auto.
Contrast Amount of contrast in the image. Manual
settings are from -4 (least contrast) to +4
(most contrast) in increments of 1.
Default is Auto.
Document Title 49
Chapter 4 — Use the Camera
DRAFT
Scene Settings (Continued)
Setting Description
Sharpness Sharpness of the image. Manual settings
Saturation Color saturation level. Manual settings
White Balance Compensates for specific lighting
Torch The state of the camera flash depending
Flash The state of the camera flash when you
Flash Profile Controls the amount of flash for a
are from -4 (very soft) to +4 (very sharp) in
increments of 1. Default is Auto.
are from -4 (black and white) to +4
(maximum color) in increments of 1.
Default is Auto.
conditions to produce true color images:
• Auto (default): Automatic White
Balance (AWB) control.
• Daylight: Outdoors in bright, midday
sunny conditions.
• Cloudy: Outdoors with a completely
overcast, cloudy sky.
• Tungsten: Indoors lit with tungsten
light bulbs.
• Office: Indoors lit with fluorescent
light bulbs.
on the lighting conditions: automatic,
on, or off.
take a picture: automatic, on, or off.
specific condition:
• 0: Reserved.
• 1 (default): Document imaging in
light to moderately light ambient
conditions.
• 2: Dark, semi-reflective environments,
such as a vehicle interior or dimly lit
room.
• 3: Dark, non-reflective large or
outdoor environments. Provides very
long flash durations.
• 4: Reserved.
50 Document Title
Chapter 4 — Use the Camera
DRAFT
Scene Settings (Continued)
Setting Description
Noise Reduction Controls the amount of noise or
graininess in the image:
• Disabled: Disables noise reduction.
• Normal: Use normal noise reduction.
• Enhanced: Enhance the nose
reduction.
Configure Camera Settings for Pictures and Videos
Use the Pictures & Videos application to configure the camera.
Note: You must use Intermec Settings to configure camera settings for
reading bar codes, document imaging, or signature capture.
1 Tap Start > Pictures & Videos.
2 Tap the Camera icon.
3 Tap Menu.
Document Title 51
Chapter 4 — Use the Camera
DRAFT
By default, all settings in the list apply to still pictures. To configure
settings for taking videos, tap Video at the top of the list.
4 Select a setting to configure.
Camera Settings for Pictures and Videos
You can configure camera settings to meet the needs of your operating
environment. In the Pictures & Videos application, camera settings are
available from the menu when the camera is operating. Certain
settings are only available when taking either Video or Still pictures,
but not for both.
Note: You must use Intermec Settings to configure camera settings for
reading bar codes, document imaging, or signature capture.
52 Document Title
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Still)
Setting Description Choices
Mode Determines the camera operating
mode.
Zoom Sets the amount of digital zoom.
Scenes Selects a Scene for the camera.
Scenes are sets of preset values for
the camera, optimized for
different environments.
Settings Brightness
• Normal: Takes one
picture.
• Burst: Takes a series of
three pictures.
• Timer: Waits 10
seconds before taking
the picture.
• 1.0x
• 1.5x
• 2.0x
• 2.5x
• 3.0x
• 3.5x
• 4.0x
• 6.0x
• 8.0x
• Manual
• Auto
• Manual
• Van Interior
• Office Store
• Warehouse
• Daylight
• Night
• Cloudy
• Check
• DocCap
• +100
• +50
• 0
• Manual
Document Title 53
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Still) (Continued)
Setting Description Choices
Contrast
Sharpness
Saturation
Color Effects
• +100
• +50
• 0
• -50
• -100
• Manual
• +100
• +50
• 0
• -50
• -100
• Manual
• +100
• +50
• 0
• -50
• -100
• Manual
• None
• Negative
• Solarize
• Sepia
• Gray
• Natural
• Vivid
• Color Swap
• Black Board
• White Board
• Aqua
• Posterize
• Black White
54 Document Title
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Still) (Continued)
Setting Description Choices
White Balance
• Auto
• DayLight
• Cloudy
• Shade
• Tungsten
• Fluorescent
• Incandescent
• Horizon
• Twilight
• Warm Fluorescent
• Sunset
Exposure Compensation From +2.5 to -2.5 in .5
increments.
ISO Speed
• Auto
• 100
• 200
• 400
• 800
Exposure - Auto Exposure Auto Exposure:
• Auto
• Night
• Spot Light
• Sport
• Snow
• Beach
• Aperture
• Small Aperture
Exposure - Manual Exposure Manual Exposure:
• 1/200
• 1/100
• 1/50
• 1/33
• 1/20
• 1/8
Document Title 55
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Still) (Continued)
Setting Description Choices
Torch Sets whether or not to use the
Flash Sets when to use the flash.
Focus Sets the focus mode for the
Full Screen When enabled, this setting hides
Options
(Camera tab)
Exposure - Metering Metering:
• Whole Average
• Whole Center Weight
• Center 1/4 Average
• Lower 1/4 Average
• Upper 1/4 Average
• Lower 1/2 Average
• Upper 1/2 Average
• Off
lighting LED.
• On
• Auto
• Off
• On
• Auto
• FillIn
• RedEye
• Auto (default)
camera when shooting video.
• Continuous
• Touch
• Macro
• Potrait
• Extended
• Infinite
the task bar. To view the task bar,
double-tap the bottom of the
screen.
Image filename prefix Default is img.
Location for saved still picture
files
• Main Memory (default)
• Flash File Store
• RAM Drive
Flicker <???>
56 Document Title
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Still) (Continued)
Setting Description Choices
Resolution
• 1936 x 2592 (5.0 mp)
• 1536 x 2048 (3.2 mp)
• 1200 x 1600 (2.0 mp)
• 1072 x 1920 (2.2 mp)
• 960 x 1280 (1.2 mp)
• 720 x 1280 (0.9 mp)
• 768 x 1024 (0.8 mp)
• 592 x 800 (0.5 mp)
• 480 x 800 (0.4 mp)
• 480 x 640 (0.3 mp)
• 288 x 352 (0.1 mp)
• 240 x 320 (0.1 mp)
• 144 x 176
• 112 x 160
• 96 x 128
JPEG quality
• High quality
• Normal quality
(default)
• Low quality
• Custom quality. If you
select Custom, eneter a
value in the Custom
field.
Post processing
• Disable
• Noise Filter
Burst mode number of pictures to
take
Timer mode hold duration (in
seconds)
Hold snapshot (seconds) <???>
Variable frame rate <??? - for stills?>
Default is 5.
Default is 5.
Document Title 57
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Video)
Setting Description Choices
Mode Determines the camera operating
mode.
Zoom Sets the amount of digital zoom.
Scenes Selects a Scene for the camera.
Scenes are sets of preset values for
the camera, optimized for
different environments.
Settings Brightness:
Contrast
• Normal: Takes one
picture.
• Timer: Waits 10
seconds before taking
the picture.
• 1.0x
• 1.5x
• 2.0x
• 2.5x
• 3.0x
• 3.5x
• 4.0x
• 6.0x
• 8.0x
• Manual
• Auto
• Manual
• Van Interior
• Office Store
• Warehouse
• Daylight
• Night
• Cloudy
• Check
• DocCap
• +100
• +50
• 0
• Manual
• +100
• +50
• 0
• -50
• -100
• Manual
58 Document Title
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Video) (Continued)
Setting Description Choices
Sharpness
• +100
• +50
• 0
• -50
• -100
• Manual
Saturation
• +100
• +50
• 0
• -50
• -100
• Manual
Color Effects
• None
• Negative
• Solarize
• Sepia
• Gray
• Natural
• Vivid
• Color Swap
• Black Board
• White Board
• Aqua
• Posterize
• Black White
White Balance
• Auto
• DayLight
• Cloudy
• Shade
• Tungsten
• Fluorescent
• Incandescent
• Horizon
• Twilight
• Warm Fluorescent
• Sunset
Document Title 59
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Video) (Continued)
Setting Description Choices
Torch Sets whether or not to use the
Exposure Compensation From +2.5 to -2.5 in .5
increments.
ISO Speed
• Auto
• 100
• 200
• 400
• 800
Exposure - Auto Exposure Auto Exposure:
• Auto
• Night
• Spot Light
• Sport
• Snow
• Beach
• Aperture
• Small Aperture
Exposure - Manual Exposure Manual Exposure:
• 1/200
• 1/100
• 1/50
• 1/33
• 1/20
• 1/8
Exposure - Metering Metering:
• Whole Average
• Whole Center Weight
• Center 1/4 Average
• Lower 1/4 Average
• Upper 1/4 Average
• Lower 1/2 Average
• Upper 1/2 Average
• Off
lighting LED.
• On
• Auto
60 Document Title
Chapter 4 — Use the Camera
DRAFT
Camera Settings (Video) (Continued)
Setting Description Choices
Full Screen When enabled, this setting hides
the task bar. To view the task bar,
double-tap the bottom of the
screen.
Options
(Video tab)
Video filename prefix Default is vid.
Location for saved video files
• Main Memory (default)
• Flash File Store
• RAM Drive
Include audio when encoding
video files
Video resolution
Enable or disable.
• 720 x 1280 (720p)
(Default)
• 768 x 1024 (XGA)
• 480 x 800 (WVGA)
• 480 x 640 (VGA)
• 288 x 352 (CIF)
• 240 x 320 (QVGA)
Video encoder
• H263
• H264 (default)
• MPEG4
• WMV
Video file format
• *.3gp
• *mp4
<What is “Hold record”?> ???
Enable video stabilization Check the box to enable
video stabilization.
Enable video noise filtering Check the box to enable
video noise filtering.
Enable video noise filtering Check the box to enable
video noise filtering.
Frame rate
• 15 fps
• 30 fps (default)
• Custom. Adjust the
frame rate with the
slider.
Document Title 61
Chapter 4 — Use the Camera
DRAFT
How To Read Bar Codes With the Camera
You can use the camera to read bar codes. When you read bar codes
with the camera, the computer treats the camera as it would any input
device, such as a Bluetooth scanner, and bar code data is sent to an
application as if it came from a scanner or imager.
There are two ways to enable reading bar codes with the camera:
• You can use the Profile Settings application to enable bar code
reading. The computer uses the current symbology decode settings
to read bar code data.
• You can configure individual parameters in Intermec Settings to
enable bar code reading.
Note: To read bar codes using the camera, you must use Intermec Settings to
configure bar code symbology decode settings.
Enable or Disable Reading Bar Codes With the Camera
You use the Profile Settings application to enable or disable reading
bar codes with the camera. Reading bar codes with the camera is
disabled by default.
Note: You can also enable reading bar codes by setting parameters in
Intermec Settings.
1 Tap Start > ProfileSettings.
2 Tap Camera.
3 In the Camera menu, tap Enable bar code scan or Disable bar
code scan as necessary.
4 Tap OK.
Read Bar Codes With the Camera
After you enable reading bar codes with the camera, the computer
sends bar code data to applications as keyboard input.
1 Start the application that is to receive the bar code data.
62 Document Title
2 Position the computer about 20 cm (8 in) over the bar code you
DRAFT
want to read. Make sure nothing is blocking the camera lens.
3 Press and hold the Scan button. The screen turns into a viewfinder
with an aiming bar across the middle of the screen.
4 Center the aiming bar over the bar code and release the Scan
button. The bar code is read and the data appears in the active
application.
If the computer does not read the bar code right away, release the
Scan button and try again. You may need to move the computer
closer to or further away from the bar code for best results.
Camera Settings for Reading Bar Codes
To use the camera for reading bar codes, you must use the Intermec
Settings application to configure the camera. From the main screen of
Intermec Settings, select Data Collection > Camera > Camera
Settings.
Optimized Imager Mode (Advanced) Settings and Descriptions
Setting Description Choices
Chapter 4 — Use the Camera
Imager decode
mode
• Linear imager
emulation
• 2D imager
Lighting mode
• Illumination
LED priority
• Aperture priority
Lighting goal Default is 30.
Illumination level Default is 3.
Initial 1D search
area
• Center
• Full
• Smart raster
Damaged 1D codes
• Disable
• Enable
Document Title 63
Chapter 4 — Use the Camera
DRAFT
File Property Settings and Descriptions
Setting Description Choices
Image file location Path to the directory where the
image is stored.
Folder memory
limit (MBytes)
Enable tagging
location data
Maximum size (in MB) of the
directory where images are stored.
Enables location data for images
(increases file size?).
Default is \My
documents\MDI.
Default is 13 MB.
Default is disabled.
Viewfinder and Focus Settings and Descriptions
Setting Description Choices
Enable viewfinder Enable or disable.
Focus mode Sets the focus mode for the
camera when reading bar codes
<HOW ABOUT SigCaps, or
Imaging?>
• Manual
• Continuous
autofocus
• Single shot
autofocus
• Macro
• Extended (10 cm
to infinity)
Manual focus value When Focus Mode is set to
Manual, this value sets the
manual focus level.
Default is 65.
Lighting Settings and Descriptions
Setting Description Choices
Torch
• Off
• On
• Auto
64 Document Title
Chapter 4 — Use the Camera
DRAFT
How to Perform Document Capture With the Camera
You can use the camera to perform document capture. Document
capture is a specialized feature for taking a picture of a document, and
automatically applying keystone correction to the image so that only
the document appears in the image.
Document Capture Image with No Keystone Correction
Document Capture Image with Keystone Correction
There are two ways to enable document imaging with the camera:
• You can use the Profile Settings application to enable document
capture. The computer uses the current document capture settings
to apply keystone correction (and other postprocessing features if
specified).
• You can configure individual parameters in Intermec Settings to
enable document capture.
Document Title 65
Chapter 4 — Use the Camera
DRAFT
Note: To perform document capture using the camera, you must use Intermec
Settings to configure all document capture settings.
Enable or Disable Document Capture With the Camera
You use the Profile Settings application to enable or disable document
capture with the camera. Performing document capture with the
camera is disabled by default.
Note: You can also enable document capture by setting parameters in
Intermec Settings.
1 Tap Start > ProfileSettings.
2 Tap Camera.
3 In the Camera menu, tap Enable document image to enble
document capture.
To disable document capture, tap Disable bar code scan.
4 Tap OK.
Perform Document Capture With the Camera
After you enable document capture with the camera, document
capture images are saved to the MyDocuments\MDI directory on the
computer by default.
1 Place your document on a flat surface.
2 Position the computer a few inches above the center of the
document.
3 Press and hold the Scan button. The video preview and camera
viewfinder frame appear.
<ILLUSTRATION?>
When the viewfinder tries to detect the document edges, the
viewfinder frame is red and pulses slightly.
4 Move the camera to align the document edges with the viewfinder.
When the viewfinder detects the document edges, the viewfinder
66 Document Title
frame turns white and a red target appears. The camera tries to
DRAFT
focus on the center of the document.
<ILLUSTRATION?>
When the focus and distance are correct, the target turns white and
the document image is captured.
5 To view the document capture image, you can browse to
MyDocuments\MDI and tap the image file to view it.
Camera Settings for Document Imaging
To use the camera for document imaging, you must use the Intermec
Settings application to configure the camera. From the main screen of
Intermec Settings, select Data Collection > Camera > Camera
Settings > Document Imaging.
Settings Description Choices
Enable
document
imaging
Focus check Sets the acceptable focus level for
Image/area to
capture ratio
Output
compression
Output
compression
quality
Perspective
correction
Color
conversion
Enables or disables document
imaging.
document imaging.
Sets the image compression level.
Sets the output compression
quality level.
Corrects the document image for
perspective.
Chapter 4 — Use the Camera
• Disab le
• Enable without
decode
• Disable (no focus
check)
• Medium level
• High level
Default is 30.
• Bitmap
• JPEG
• TIFFG4
Default is 60.
Enable (default) or
disable.
• None (default)
• Monochrome
• Enhanced
monochrome (TIFF)
Document Title 67
Chapter 4 — Use the Camera
DRAFT
Settings Description Choices
Conversion
threshold
Contrast
enhancement
Text
enhancement
Noise
reduction
Image rotation <CW or CCW?>
Image lighting
correction
Document file
name
Sets the noise reduction level. Default is 0.
Name for the document image
file.
• Very dark (default)
• Dark
• Normal
• Bright
• Very bright
• None (default)
• Photo
• Black on white
• White on black
• None
• Low
• Medium (default)
• High
• None (default)
• 90 degrees
• 180 degrees
• 270 degrees
Default is disabled.
Default is doc_$(num).
68 Document Title
5
DRAFT
Use GPS
The computer comes equipped with an integrated Global
Positioning System (GPS) receiver if your computer has phone
capability (WWAN radio). The GPS receiver can deliver
standards-based National Marine Electronics Association
(NMEA) data strings to GPS applications.
69
Chapter 5 — Use GPS
DRAFT
About the Integrated GPS on Your Computer
Intermec recommends that you use the GPS Intermediate Driver
(GPSID) instead of directly accessing the GPS hardware. The GPSID is
a Microsoft hardware component that interacts between applications
and the GPS hardware.
As a Microsoft software component, the GPSID:
• allows multiple applications to simultaneously access the GPS data
stream.
• provides access to GPS data without requiring applications to
recognize and parse NMEA syntax.
Use the GPSID Installed on the Computer
To use the GPSID installed on your mobile computer, you need to
configure the GPSID settings.
1 Tap Start > Settings > System > External GPS. The GPS Settings
screen appears with Programs selected.
2 Select the COM port that you want your program to use to get GPS
data from your computer.
3 Tap Access in the horizontal scroll bar and select the Manage GPS
automatically check box.
70 Document Title
4 Tap OK.
DRAFT
About the GPS Module Operating Modes
The integrated GPS module has three operating modes:
• Standalone
• MS Assisted (Mobile Station Assisted)
• gpsOneXTRA™ (UMTS computers only)
In Standalone mode, the GPS module relies solely on GPS satellites to
determine position.
Chapter 5 — Use GPS
Note:The CN51 also supports GLONASS.
In MS Assisted mode, the computer can determine position without
receiving GPS signals directly from satellites. Instead, the computer
receives GPS signals and information provided by the cellular network.
Even when the computer can receive a satellite signal, MS Assisted can
improve position accuracy and reduce the time to determine initial
position (Time-to-first-Fix). Check with your cell phone carrier for
availability and pricing for MS Assisted service.
Document Title 71
Chapter 5 — Use GPS
DRAFT
Qualcomm’s gpsOneXTRA Assistance technology provides enhanced
operation for Standalone GPS. This option enables the UMTS-enabled
computer to automatically download a small assistance data file from
the XTRA servers through a brief internet access session. To use this
option, you must have a valid and activated WAN data connection.
Note: Internet connection fees may apply.
Another option you can configure with iGPS is the fix interval. The fix
interval defines how often the GPS provides new information. Larger
intervals use less power, but many applications require small intervals
to work correctly. The default for fix interval, in seconds, is 4. The
Flexible Network Radio has a maximum interval of 4.
Improve GPS Performance on the Computer
Use the iGPS application to improve the performance of the GPS on
your computer. Any time you change the GPS settings, the phone
automatically resets.
1 Go to Start > Settings > System > iGPS.
2 In the Fix Interval tab, enter a value for the fix interval. The default
setting is 4 and should be optimized for most applications.
3 Tap the Fix Type tab and select one of these options: Standalone
(1), MS assisted (2), or Enable gpsOneXTRA (check box).
Note: GLONASS reception is enabled by default. Intermec
recommends that you keep GLONASS enabled for better accuracy. To
disable GLONASS, make sure that Enable Glonass is not selected.
4 Tap OK.
72 Document Title
6
DRAFT
Configure the Computer
Use this chapter to learn about the available methods for
configuring your computer and how to use Intermec Settings.
You can also use this chapter to learn how to configure
network communications and wireless security.
73
Chapter 6 — Configure the Computer
DRAFT
How to Configure the Computer
You can configure many parameters on the computer such as the bar
code symbologies it decodes or the network settings. The values you
set for these parameters determine how the computer operates.
There are several ways to configure the computer:
• Directly on the computer. You can use Intermec Settings directly
on the computer to change only the settings on that computer.
• Remotely using Intermec SmartSystems. With SmartSystems, you
can remotely configure all of your mobile computers as well as
other SmartSystems-enabled Intermec devices and peripherals.
• Using a third-party device management product that supports the
computer and Intermec Settings, such as Soti MobiControl or
Wavelink Avalanche.
• Using configuration bundles that you create with SmartSystems.
About Intermec Settings on the Computer
Use Intermec Settings to configure parameters for Intermec
applications on the computer, as well as some device-specific
parameters like volume. You can configure parameters for important
functions like data collection and communications. You can also
password protect Intermec Settings to prevent users from making
changes to the configuration settings.
Start Intermec Settings
Use Intermec Settings to configure parameters for Intermec
applications and some device-specific parameters. Intermec Settings is
located on the System screen.
• Tap Start > Settings > System > Intermec Settings. The Intermec
Settings Main Menu appears.
74 Document Title
Chapter 6 — Configure the Computer
DRAFT
About the Structure of Intermec Settings
Use the following tables to help find the parameters in Intermec
Settings that you want to configure. Each table contains the
parameters for one of the Intermec Settings Main Menu options.
Most parameters are saved as soon as you tap OK. Some settings, such
as Security Choice, require you to reboot the computer for the changes
to take effect.
Data Collection Menu
Data Collection Options Parameters You Can Configure
Internal Scanner
Document Title 75
• Enable Scanner Port
• Symbologies
• Symbology Options
• Scanner Settings
• Imager Settings
• Decode Security
Chapter 6 — Configure the Computer
DRAFT
Data Collection Menu (Continued)
Data Collection Options Parameters You Can Configure
Bluetooth Scanners
Camera
Magstripe Reader
• BT-Configure on Connect
When Bluetooth scanners are connected,
you can also configure:
• Enable scanner port
• Symbologies
• Symbology Options
• Scanner settings
• Bluetooth scanner settings
• Imager settings
• Decode security
• Enable camera port
• Symbologies
• Symbology Options
• Scanner Settings
• Camera Settings
• Decode Security
• Enable Magstripe Reader
• Magstripe Reader Settings
Communications Menu
Communications Options Parameters You Can Configure
Device Name Device Name
802.11 Radio
• Radio Enabled
• Security Choice
• Security Settings (Funk or Microsoft)
• IP Settings
• Certificates
• Radio Bands
• Allow Security Changes
Ethernet Adapter IP Settings
Bluetooth Bluetooth Settings
76 Document Title
Chapter 6 — Configure the Computer
DRAFT
Communications Menu (Continued)
Communications Options Parameters You Can Configure
WWAN
• Radio State
• Carrier Choice
• Carrier Settings
• Information
Device Settings
Device Settings Options Parameters You Can Configure
Backlight Display and Keypad Settings
Date and Time Date and Time Settings
Features Disabled by Policy
Good Read
• Internal Scanner
• Bluetooth Scanner
IDL Runtime Versions (Read-only) IDL runtime file versions
(ITC50, ITCScan)
Keypad
• Button Remapping
• Green/Orange keys lock option
Power Management
• Power Button
• Battery Power
• External Power
• Device Off Sensor
Profile Settings Application Sets whether these parameter options
appear in Profile Settings:
• Camera
• Power
• Scanning
Screen
• Screen Rotation
• Screen Rotation Sensor
Security Enables or disables ActiveSync, the SD
card, A USB external drive, and image
capture.
Document Title 77
Chapter 6 — Configure the Computer
DRAFT
Device Settings (Continued)
Device Settings Options Parameters You Can Configure
Sounds
System Component Versions Read-only
USB USB function driver
Printers Menu
Printer Options Parameters You Can Configure
Printer (connected through
Bluetooth)
Note: The Printers menu displays settings for Bluetooth connected
printers. The settings that appear in the menu are dependent on the
printer that is paired with the device. The printer needs to be using the
Wireless Printing application.
• Beeper and Voice
• Good read vibrate intensity
• Headset beeper
• Screen Taps
• Key Clicks
Printer Settings
GPS Menu
GPS Options Parameters You Can Configure
Bread Crumbing Enable or disable bread crumbing.
Core Messaging Service Menu
Core Messaging Service Options Parameters You Can Configure
Server IP Read-only
Associated Server IP Associated Server IP
Broadcast Name Broadcast name
Port Read-only
Keep Alive Ping Interval Keep Alive Ping Interval
78 Document Title
Chapter 6 — Configure the Computer
DRAFT
SmartSystems Information Menu
SmartSystems Information Options Parameters You Can Configure
Identity Identity Information (hardware
version, firmware version, OS version,
and so on) (Read-only)
Administrator Administrator Settings (name, phone,
and email)
Location Location Settings (country, state, city,
campus, and detail)
Information Device Notes (Read-only)
Device Monitor Menu
Device Monitor Options Parameters You Can Configure
Device Health Controls
• Enable Health Data Collection
• Enable Device Health Application
• Enable Blue Light (LED)
• Set Rule File Location
• Set Data Refresh Periods
Device Health Screen Captures
• Directory
• Screen Captures Allowed
Disabled Executables Read-only
Device Wipe
• Enable Wipe
• Interval
License Manager Menu
License Manager Options Parameters You Can Configure
About Read-only
License Vault Read-only
Virtual Wedge Menu
Virtual Wedge Options Parameters You Can Configure
Enable Virtual Wedge Enable Virtual Wedge
Document Title 79
Chapter 6 — Configure the Computer
DRAFT
Virtual Wedge Menu (Continued)
Virtual Wedge Options Parameters You Can Configure
Virtual Wedge Method Virtual Wedge Method (Adapt to
application, character mode, or block
mode)
Barcode Scanner Wedge
Magstripe Reader Wedge Magstripe Reader Grid
Location Services Menu
Location Services Options Parameters You Can Configure
Server
Virtual GPS Virtual GPS Settings
• Barcode Scanner Grid
• Label Encoding (Code Page)
• Port
• Enable Server
How to Navigate in Intermec Settings
You can easily navigate through the screens in Intermec Settings to
find the parameters you need to configure:
• Tap inside a text field to be able to enter text into it.
• Tap a field once to select it.
• If you see a ... next to a menu item, there is only one more screen
available. Tap the menu item to access this screen.
• If you see a > next to a menu item, there are more screens available
in the next level. Tap the menu item to access these screens.
• Use the up and down arrow keys to move up and down the menu.
• To move back a level in the menu, tap Back or Cancel on the Tile
bar.
• To exit Intermec Settings, tap Menu > Exit or OK.
Enable Intermec Settings Password
You can protect Intermec Settings from other users by enabling a
password.
1 Start Intermec Settings.
80 Document Title
2 Tap Menu > Enter Password.
DRAFT
3 Select the Enable password checkbox.
4 Type your password in the Enter: text box.
5 Retype your password in the Confirm: text box.
6 (Optional) Select the Use password to protect CAB Installation
if you want to restrict the installation of .cab files.
7 Tap OK.
Restore Default Settings
The easiest way to restore default settings on your computer is to use
Intermec Settings. You can restore all default settings on your
computer or restore default settings for a specific menu item in
Intermec Settings.
Note: When you restore default settings, only the settings for visible
menu items are restored. The settings for hidden menu items are not
affected.
1 Start Intermec Settings.
Chapter 6 — Configure the Computer
2 Restore the default settings:
• To restore all default settings, tap Menu > Restore all
Defaults.
• To restore default settings for one menu item, navigate to the
menu and tap Menu > Restore Menu Defaults.
3 When prompted, tap Yes to restore the default settings.
If you are prompted to refresh the computer, tap Yes.
Document Title 81
Chapter 6 — Configure the Computer
DRAFT
Configure the Computer Remotely with SmartSystems
You can use Intermec Settings from a SmartSystems console to
remotely configure all the Intermec computers. For help using
Intermec Settings, click Help > Contents. For information on all the
parameters in Intermec Settings, see the Intermec Settings
Command Reference Manual.
1 In the SmartSystems console, select a computer and then
right-click on it. A list appears.
2 Select Start Intermec Settings.
3 Configure the settings you want to change. As you select
parameters, help for each parameter appears in the upper right
pane.
4 When you are done making changes, select File > Save Settings.
About Network Communications
You can use the mobile computer in your wireless or wired data
collection network. You can connect your computer using:
• 802.11 radio communications.
• Ethernet communications.
• Bluetooth communications.
• USB and serial communications.
Configure 802.11 Radio Communications
Caution:Make sure all components with antennas are at least 30
cm (1 ft) apart when power is applied. Failure to comply could
result in equipment damage.
The CN51 has an 802.11b/g/n or 802.11a/b/g/n radio to transfer data
using wireless communications. Before you configure radio
communications, you need to have your wireless network set up
including your access points.
82 Document Title
By default, the 802.11 radio is disabled. Use the following procedure to
DRAFT
enable the Wi-Fi radio using Intermec Settings.
1) Tap Start > Settings > System > Intermec Settings.
2) From the Intermec Settings main menu, tap Communications >
802.11 Radio > Radio Enabled.
3) Select the Radio Enabled check box and tap OK. By default, the
computer uses Funk security and enables DHCP.
Note: To enable both the 2.4 GHz and 5.0 GHz bands for the
802.11a/b/g/n radio, from the Intermec Settings 802.11 Radio menu,
tap Radio Bandsand select a/b/g (2.4 and 5.0 GHz).
4) Use Intermec Settings to configure the parameters you need to use
for communications with your network.
5) Configure 802.11 security.
About Bluetooth Communications
The CN51 is Bluetooth-enabled, which lets you connect to other
Bluetooth devices such as:
Chapter 6 — Configure the Computer
• scanners.
• printers.
• audio devices.
You need to turn on the Bluetooth radio before you can discover and
connect to Bluetooth devices. By default, the radio is turned off.
The Bluetooth radio maintains its current state through a warm or
cold boot and maintains virtual COM ports. If you clean boot the
computer, you must recreate pairings to devices.
System bar icons indicate Bluetooth status.
Turn On the Bluetooth Radio
You need to turn on the Bluetooth radio in the mobile computer
before you can discover and connect to Bluetooth devices. By default
the radio is turned off.
1 Tap Start > Settings > Bluetooth > Mode tab.
Document Title 83
Chapter 6 — Configure the Computer
DRAFT
2 Tap Turn on Bluetooth.
3 (Optional) If you want this computer to be visible to other
Bluetooth devices, tap Make this device visible to other devices.
4 Tap OK.
Connect a Bluetooth Scanner
You can connect the computer to an Intermec Bluetooth scanner, such
as the SF51 or SR61. Make sure that the Bluetooth radio in the
computer is turned on before you try to connect to a scanner.
1 Tap Start > Settings > System > Wireless Scanning.
84 Document Title
Chapter 6 — Configure the Computer
DRAFT
2 Tap Add Device.
3 Select Quick Connect, Search, or Manual. Follow the
instructions on the screen to add a Bluetooth scanner.
After you add a Bluetooth scanner, you can configure scanner
settings and parameters in Intermec Settings.
Create a Configuration Bar Code with EasySet
To connect a Blueooth scanner to the computer, you can read a
configuration bar code with the scanner. You create the bar code using
Intermec EasySet.
Note: To create the configuration bar code, you need the computer
Bluetooth address. The address is on the labels located on the outside
of the computer shipping box, and on the packet of information that
ships with the computer.
1 Go to the Intermec website at www.intermec.com.
2 Click the Products tab.
3 On the Products page, click Computers > Handheld Computers
> your computer model number > the Downloads tab > Easyset
ver. 5.x.x.x.
4 Follow the instructions to download and install EasySet.
Document Title 85
Chapter 6 — Configure the Computer
DRAFT
5 Open EasySet and select Interface > Bluetooth >
Connect/disconnect > Compose BT address. The Bluetooth -
Connect/disconnect - Compose BT address screen appears.
6 Enter the BT address listed on the labels that shipped with your
computer.
7 Click OK.
Connect to a Bluetooth Printer
You can connect the computer to a Bluetooth printer and use the
computer to wirelessly print to the printer. Make sure that the
Bluetooth radio in the computer is turned on before you try to connect
to an Intermec Bluetooth printer, such as the PB21, PB50, or PR3. To
configure your computer for printing wirelessly using Bluetooth, you
need to:
• create an application that opens the wireless printing COM port on
the computer. For help, see the Bluetooth Resource Kit, which is
part of the Intermec Developer Library (IDL), available from the
Intermec website at www.intermec.com/idl.
• select the current Bluetooth printer on the computer. For help, see
the next procedure.
Note:You can also print wirelessly using Microsoft APIs with
Bluetooth extensions for Winsock and Bluetooth virtual COM ports.
For help, see the Bluetooth Resource Kit documentation.
1 Tap Start > Settings > System > Wireless Printing.
86 Document Title
Chapter 6 — Configure the Computer
DRAFT
2 Tap Search to find a printer, or tap Manual to enter a device
address. Follow the onscreen instructions to select the current
Bluetooth printer.
3 (Optional) Tap Print Test Page. The printer prints out a test page.
Connect a Bluetooth Audio Device
Use the Bluetooth Audio applet to discover, activate, and connect to
Bluetooth audio devices such as a headset.
1 Select Start > Settings > System > Bluetooth Audio. The
Bluetooth Audio screen appears.
Document Title 87
Chapter 6 — Configure the Computer
DRAFT
2 Follow the onscreen instructions to discover and connect to a
Bluetooth audio device.
Note: If a wired audio device such as a headset is already connected to
the computer, Bluetooth audio receives priority when a Bluetooth
audio device is connected.
About Serial and USB Communications
You can use these accessories to transmit data to and receive data from
another device through serial or USB communications:
• AV10 vehicle dock
• AA21 RS-232 adapter
• AD27 single dock
• Desktop USB adapter
• USB snap-on adapter
• RS-232 DEX adapter
For information on these accessories, contact your local Intermec
representative.
88 Document Title
About Wireless Security
DRAFT
The computer provides these security solutions for your wireless
network:
• Wi-Fi Protected Access 2 (WPA2™)
• Wi-Fi Protected Access (WPA)
• 802.1x
• LEAP (Funk security only)
• WEP
You use either Funk or Microsoft security to implement your wireless
security solution. Intermec recommends WPA2 security with PSK
(Personal) or 802.1x (Enterprise) key management.
Before you set security, you need to enable the radio, set the date, and
set the SSID on your computer. To use 802.1x security, you need to
load a root certificate on your computer. To use transport layer
security (TLS) with 802.1x security, you also need to load a user
certificate.
Load a Certificate
Chapter 6 — Configure the Computer
To use transport layer security (TLS) with 802.1x security, you need a
unique client certificate on the computer and a trusted root certificate
authority (CA) certificate.
1 Start Intermec Settings.
2 Select Communications > 802.11 Radio > Certificates.
Document Title 89
