Docks and Modules
CN51
CN50
Accessory Guide
Accessory Name Part Number Description
4-Bay Multi-Dock, Ethernet 871-032-201 Charge and transfer data for up to 4 devices
with Ethernet interface.
Requires AC adapter (851-082-205
everywhere except EMEA; 851-095-131
is required for use in EMEA) and country
specific power cord.
4-Bay Multi-Dock, Charge Only
Single Dock 871-033-021 USB Host and Client Support with bay
Single Dock Ethernet Module 871-238-011 Ethernet Module interfaces with USB
871-032-102 Charge up to 4 devices.
Requires AC adapter (851-082-205
everywhere except EMEA; 851-095-131
is required for use in EMEA) and country
specific power cord.
for charging a spare battery pack.
(8.9”L x 4.5”W x 2”T) Requires AC adapter
(851-061-502) and country-specific
power cord. Optional: Single Dock
Ethernet Module (871-238-011).
Host connector on Single Dock,
(871-033-001). (1.5”L x 2.5”W x 1”T).
Vehicle Holder 805-664-001 Non-Powered vehicle holder for
hands-free communications.
Holder can be used with or without
vehicle power adapter.
Requires mount (805-611-001).
Vehicle USB & Power Adapter,
CN50 Series
Vehicle Dock Install Kit 203-802-001 For connection of Vehicle USB & Power
871-037-001 Requires Vehicle Holder (805-664-001).
Power connection directly to vehicle
battery is available. Requires Vehicle
Dock Install Kit (203-802-001).
Cabled RS232 or USB Host support is also
available. Requires use of RS232 Serial cable
(225-737-001) or USB cable (VE011-2016).
Must order Vehicle Holder, Vehicle Dock
Install Kit, and cables separately.
Adapter (871-037-001) directly to vehicle
battery. Includes power cables and cable
mounting hardware. Order instructions
(962-000-021) separately.
Vehicle Dock Serial Cable 225-737-001 Adapts CN50 Series Vehicle USB
& Power Adapter communications
connector to RS232 Serial (DB9M) for
connectivity to serial peripherals.
1
CN51
CN50
Accessory Guide
Docks and Modules (cont’d)
Accessory Name Part Number Description
Vehicle Dock Mounting Kit 805-611-001 Allows for mounting of Vehicle
Holder (805-664-001) in route vehicle
applications. Consists of one 4 ¾”
adjustable pivot arm with two 1 ½”
stainless steel balls and assembly
hardware. Due to wide range of possible
applications, this kit doesn’t include
hardware for securing mount to vehicle.
Requires holder (805-664-001).
Snap-on Adapter, MSR,
CN50 Series
Snap-on Adapter, RS232/DEX,
CN50 Series
Snap-on Adapter, USB,
CN50 Series
DEX Adapter, CN50 Series 852-923-001 Adapts CN50 Series devices for DEX
850-573-001 Attaches to the heel of CN50 Series devices
and provides magnetic stripe reader.
850-578-001 Attaches to the heel of CN50
Series devices and provides RS232
communications via DB9M connector.
Must order cables, including DEX
cable 236-194-001, separately.
850-581-001 Attaches to the heel of CN50 Series
devices and provides USB Host
communications via HDB15M connector.
Requires USB cable VE011-2016 (Host).
Must order cables separately.
communications.
Desktop Adapter, USB,
CN50 Series
2
852-073-001 Desktop adapter with Micro-AB USB port
provides USB Host and Client connectivity
for CN50 and CN51, and charging (via USB)
for CN51.
Must order cables and power adapters
separately.
CN51
CN50
Batteries and Chargers
Accessory Name Part Number Description
Battery Pack, CN50
318-039-002 Spare or replacement battery pack for
CN50 (one pack included with each
mobile computer), 3900 mAH, 3.7 V Li-Ion
Prismatic Cell. Provides 14.4 watt hours.
Accessory Guide
Battery Pack, CN51
Quad Battery Charger 852-068-011 Simultaneously charge up to 4 batteries.
AC Adapter for Multi-Dock 851-082-205;
AC Adapter for Quad Battery
Charger and Single Dock
318-052-001 Spare or replacement battery pack for
CN51 (one pack included with each mobile
computer), 3920 mAH, 3.7 V, Li-Ion
Prismatic Cell. Provides 14.5 watt hours.
Requires AC adapter (851-061-502)
and country specific power cord.
AC adapter for multi-docks (871-032-101)
851-095-131 is required
for use in EMEA
851-061-502 AC adapter for quad charger (852-068-001)
and (871-032-002).
Not for Quad Battery Charger (852-068-001)
Requires country specific power cord (page 4).
and single dock (871-033-001).
Not to be used for the “Ethernet” multi-dock
(871-032-101) and the “charge only”
multi-dock (871-032-002)
Requires country specific power cord (page 4).
AC Power Adapter 851-093-311 Desktop AC power and communication
adapter with USB port, enabling
desktop charging and data transfer.
Requires country specific power cord (page 4).
Vehicle Power Adapter 852-070-011 Vehicle 12V–24V adapter for
charging on the go.
Can be used as a heel clip on CN50 Series
devices or it can be permanently mounted
to the bottom of the vehicle holder.
Universal AC Charger Kit,
w/Cable, CN51
3
213-029-001 Supporting universal USB charging
(5V, 10W, Level V RoHS, microUSB) this kit
comes with 4 snap-on plugs expanding the
“universal” functionality by supporting usage
for the most common outlets. More unique
outlets would require local purchase of adaptors.
Requires Desktop USB Adapter (852-073-001).
(Note: Charge times will be longer.)
CN51
CN50
Accessory Guide
Power Cords
Accessory Name Part Number Description
AC Power Cord 321-470-001
321-500-001
071918
1-974027-025
1-974028-025
1-974029-020
1-974030-025
321-471-002
321-501-002
321-502-002
AC Power Cord, Switzerland
AC Power Cord, Japan
AC Power Cord, China RoHS
AC Power Cord, Europe RoHS
AC Power Cord, US RoHS
AC Power Cord, UK RoHS
AC Power Cord, Australia RoHS
AC Power Cord, Italy RoHS
AC Power Cord, Denmark RoHS
AC Power Cord, India/S Africa RoHS
Data Cables
Accessory Name Part Number Description
USB Data Cable 236-209-001
USB Data Cable Product Links
DB9 to DEX Cable 236-194-001
Cable, Single USB Host VE011-2016
USB-A to USB Micro-B Plug (2 meters)
Connects the desktop adapter (851-093-001)
to PC USB port enabling quick data transfer.
Micro USB (Male) to Standard USB (Female)
For connecting an accessory
such as a memory stick.
See Digi-key # H11576-ND
For use with RS232/DEX Adapter
(850-578-001). Includes thumb
screws for secure attachment.
For use with USB Snap-on Adapter
(850-581-001) to USB-A Female receptacle
for connectivity to USB peripherals. Includes
thumb screws for secure attachment.
4
CN51
CN50
Accessory Guide
Handles and Holsters
Accessory Name Part Number Description
Scan Handle, CN51 805-679-001 Snaps easily on or o CN51. Ergonomic
handle which angles mobile computer
to enable viewing while scanning.
Not compatible with CN50, Vehicle
Docks or Vehicle Holder.
Belt Holster, CN50 Series 815-066-001 Belt holster for CN50 Series devices
without Scan Handle.
Holster, CN50 Series 815-089-001 Holster, CN50 Series devices
without Scan Handle
Holster, CN51 w/Scan Handle 815-090-001 Holster, CN51 with Scan Handle
Replacement Parts
Accessory Name Part Number Description
Kit – Handstrap, CN50 203-899-001 Handstrap replacement for CN50 (5 Pack)
Kit – Handstrap, CN51 213-008-001 Handstrap replacement for CN51 (5 Pack)
Kit – Handstrap,
Stretch-Limiter, CN51
Kit – Stylus Tethered, CN50 203-900-002
Kit – Stylus Tethered, CN51 213-025-001
Kit – Screen Protector, CN50 346-069-104 Clear plastic LCD overlays for CN50. Same
Kit - Screen Protector, CN51 346-085-001 Clear plastic LCD overlays for CN51 (10 Pack)
213-024-001 Handstrap replacement for CN51 (5 Pack)
Stylus tethered replacement for CN50 (5 pack)
Stylus tethered replacement for CN51 (5 Pack)
as CK3. (10 Pack)
5
CN51
CN50
Accessory Guide
FlexDock Supplies
Accessory Name Part Number Description
Quad Dock-Ethernet DX4A1555510 Accommodates four mobile
computers. Includes power supply,
North American Power Cord. Features
100Base-T Ethernet connectivity;
front view
Quad Dock-Ethernet DX4A1555500 Accommodates four mobile computers.
back view
Quad Dock-Charge Only DX4A2555510 Accommodates four mobile computers –
provides 2 – RJ45 jacks for upstream
connections and downstream “daisy-chain”
connections of up to 10 docks.
Includes power supply. Order power cord
separately. Features 100Base-T Ethernet
connectivity; provides 2 – RJ45 jacks for
upstream connections and downstream
“daisy-chain” connections of up to 10
docks. Country specific power cords must
be ordered separately.
CHARGE ONLY. Includes power supply and
North American Power Cord.
Quad Dock-Charge Only DX4A2555500 Accommodates four mobile computers –
CHARGE ONLY. Includes power supply.
Country specific power cords must be
ordered separately.
Mobile Computer Cup,
CN50 Series
203-918-001 Supports (1) mobile computer when
snapped into a bay of base unit.
