Quick Start Guide
700
Mobile Computer
Battery Pack
Charger
Page 2
The Model 700 Battery Charger is suitable for use
only with Intermec battery pack part numbers
318-011-001, 318-011-002, 318-011-003, and
318-011-004. Use of any other battery pack may
present risk of fire or explosion hazard.
French:
Le modèle de chargeur de batterie 700 peut être utilisé avec les
numéros de référence de bloc de batterie Intermec suivants,
318-011-001, 318-011-002, 318-011-003, et 318-011-004.
L’utilisation de tout autre bloc de batterie présente un risque
d’incendie ou d’explosion.
German:
Das Batterieladegerät Modell 700 ist nur zum Laden der Intermec Batteriesätze mit den Teilenummern 318-011-001,
318-011-002, 318-011-003, und 318-011-004 geeignet. Bei
Verwendung eines anderen Batteriesatzes besteht Brand- oder
Explosionsgefahr.
Spanish:
El Cargador de batería Modelo 700 debe ser utilizado solo con
los paquetes de batería Intermec N/P 318-011-001,
318-011-002, 318-011-003, y 318-011-004. El uso de cualquier otro paquete de batería puede ocasionar riesgos de incendio o
explosión.
Power Usage
Each charger power supply (p/n: 851-060-002) uses approximately 0.5 amps of current.
You can have 40 battery pack chargers plugged into one 20 amp
circuit assuming no other loads are drawing off that circuit breaker.
2 700 Mobile Computer Battery Pack Charger Quick Start Guide
Page 3
Instructions
Insert battery pack into charging compartments. A complete
charge takes four hours.
Charging status LED indicates:
Off = no battery installed or battery completely run
down. Remains off until battery reaches an initial
charge capacity of 5%.
Red = charging
Green = charge complete
Blinking Red =
pack may not be installed in compartment properly
(remove and reinsert).
packmaybebad.IfonchargerforfivehoursandLEDgoes
from solid red to blinking red, the pack is bad (replace pack).
Battery Pack
Battery Pack Compartment(s)
Push down to “click” into place
Charge Status LEDs
700 Mobile Computer Battery Pack Charger Quick Start Guide
3
Page 4
Corporate Headquarters
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel 425.348.2600
fax 425.355.9551
www.intermec.com
E 2002 by Intermec Technologies Corporation. All rights reserved.
700 Mobile Computer Battery Pack Charger Quick Start G uide February 2004
*962000034A*
PN: 962000034A
4 700 Mobile Computer Battery Pack Charger Quick Start Guide
