Inter-m OT-4240, OT-4960, OT-4480 Operation Manual

Download
OT-4240/4480/4960 Output Transformer Unit
OUTPUT TRANSFORMER UNIT
4960
OT
Contents
Contents
Welcome
Unpacking......................................................................................................................................2
Installation
Important Safety Instructions.............................................................................................................2
Features............................................................................................................................................3
Accessories.....................................................................................................................................3
Operation........................................................................................................................................3
Rear Panel.......................................................................................................................................4
Applications ....................................................................................................................................5
Block Diagram................................................................................................................................6
Specifications..................................................................................................................................8
Service
Procedures......................................................................................................................................9
Parts List .........................................................................................................................................9
Variations and Options.................................................................................................................9
Warranty .........................................................................................................................................9
1
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
Welcome
Welcome
A personal welcome to you from the management and employees of Inter-M
All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
We sincerely trust this product will provide years of satisfactory service, but if anything is not to your complete satisfaction, we will endeavor to make things right.
Welcome to Inter-M, and thank you for becoming part of our worldwide extended family!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
*Do not install this equipment in a confined space such as a book case or similar unit. *The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such vases, shall be placed on the apparatus. *Worded: “WARNING FOR YOUR PROTECTION PLEASE READ THE FOLLOWING-WATER AND MOISTURE: Unit should not be used
near water(e.g. near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so than objects do not fall and liquids are not spilled into the enclosure through openings.”
This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important operation and maintenance (servicing) instructions in the literature accompanying the appliance.
Caution: To prevent electric shock do not use this (polarized) plug with
an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de courant on une autre sortie de courant, sauf si les lames peuvent étre insérées à fond sans en laisser aucune partie à découvert.
2
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
Unpacking
Although this unit is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation.
As with most electronic devices, we strongly recommend you retain the original packaging. In the unlikely event the product must be returned for servicing, the original packaging (or reasonable equivalent) is required.
Installation
Installation
Environment
Never place this product in an environment which could alter its performance or reduce its service life. Such environments usually include high levels of heat, dust, moisture, and vibration.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
S3125A
S3125A
3
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
Features
Features
- BRING DISTRIBUTED AUDIO TO YOUR SYSTEM
Transforms the 4Ω output of the Inter-M QD-4240/4480/4960 to a 70V or 100V output level for use with high- impedance speaker systems.
- FLEXIBLE OPERATION
Four independent channels allow for four mono or two stereo zones.
- EXPANDABLE AND ADAPTABLE
Line Out expansion port for additional OT-4240/4480/4960 units.
Operation
Operation
Make certain that speakers and input sources are properly connected before switching on.
Keep volume levels turned down before switching on.
4
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
Rear Panel
Rear Panel
1. AMP INPUT TERMINALS
These terminals are connected to the output of a low-impedance amplifier like the Inter-M OT-4240 (4Ω/60W), OT-4480 (4Ω/120W) or OT-4960 (4Ω/240W).
2. SPEAKER OUTPUT TERMINALS
These output terminals may be connected with high-impedance distributed speaker systems.
For 120VAC operation, the 70V output terminal is recommended. For 230VAC operation, the 100V or 70V terminals may be used.
The chart below shows recommended impedances.
100V 70V 25V
OT-4240 / 120VAC 81.7Ω 10.4Ω OT-4240 / 230VAC 166.7Ω 81.7Ω OT-4480 / 120VAC 40.8Ω 5.2Ω OT-4480 / 230VAC 83.3Ω 40.8Ω OT-4960 / 120VAC 20.4Ω OT-4960 / 230VAC 41.6Ω 20.4Ω
5
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
Applications
Applications
QD-4960
OT-4960
Block Diagram
Block Diagram
(OT-4240/4480)
6
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
7
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
Block Diagram
Block Diagram
(OT-4960)
240W 100V(41.6 ohm)
70V(20.4 ohm)
COM
4ohm
8
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
Specifications
Specifications ..........................................................
0dB=0.775Vrms
- ELECTRICAL
Rated Output
OT-4240 ....................................................................................25V(10.4Ω), 70V(81.7Ω), 100V(166.7Ω)
OT-4480 ........................................................................................25V(5.2Ω), 70V(40.8Ω), 100V(83.3Ω)
OT-4960 ..........................................................................................................70V(20.4Ω), 100V(41.6Ω)
Input
OT-4240....................................................................................................................................4Ω/60W
OT-4480..................................................................................................................................4Ω/120W
OT-4960..................................................................................................................................4Ω/240W
Frequency Response ..................................................................................................................20Hz-20kHz
- GENERAL
Weight ..................................................................................................................OT-4240: 11.5kg/25.3lb
................................................................................................................................OT-4480: 14.5kg/32lb
.............................................................................................................................OT-4960: 21.5kg/47.4lb
Dimensions ..................................OT-4240/4480: 482(W) x 88(H) x 310(D)mm/19(W) x 3.5(H) x 12.2 (D)in
...............................................................OT-4960: 482(W) x 132(H) x 310(D)mm/19(W) x 5.2(H) x 11(D)in
* Specifications and design subject to change without notice.
9
OT-4240/4480/4960
OUTPUT TRANSFORMER UNIT
Service
Service
Procedures
Ensure the problem is not related to operator error, or system devices that are external to this unit. Information provided in the troubleshooting portion of this manual may help with this process. Once it is certain that the problem is related to the product contact your warranty provider as described in the warranty section of this manual.
Schematic
A Schematic is available by contacting your warranty provider.
Parts List
A Parts List is available by contacting your warranty provider.
Variations and Options
Variations and Options
Variations
Products supplied through legitimate sources are compatible with local AC power requirements.
Options
No optional items are available for this product.
Warranty
Warranty
Warranty terms and conditions vary by country and may not be the same for all products. Terms and conditions of warranty for a given product may be determined first by locating the appropriate country which the product was purchased in, then by locating the product type.
To obtain specific warranty information and available service locations contact Inter-M directly(in Korea or the USA) or the authorized Inter-M Distributor for your specific country or region.
Inter-M, Ltd. (Korea) began operations in 1983.
Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world.
Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
The company is no longer just a Korean company, but rather a global company that is truly international in scope, with factories and offices in Korea and China, and sales and marketing operations located in Japan, Europe, and the U.S.A.
With more than 850 employees around the globe, Inter-M is well-poised for further growth and expansion.
INTER-M AMERICAS, INC.
1 EAST BEACON LIGHT LANE CHESTER, PA USA 19013-4409 TEL : 1-610-874-8870, FAX : 1-610-874-8890 Home Page : http://www.inter-m.net, E-mail : service@inter-m.net
INTER-M Corporation
SEOUL OFFICE:653-5 BANGHAK-DONG, DOBONG-KU, SEOUL, KOREA TEL : 82-2-2289-8140~8, FAX : 82-2-2289-8149 Home Page : http://www.inter-m.com, E-mail : export@inter-m.com
November 2005 9007908811 A
MADE IN KOREA
