PORTABLE 2WAY LOUDSPEAKER SYSTEMS
IX SERIES
IX8/8H/12/12H/15/15H
IX
Technical Features
High-quality Driver
IX Series is designed using high quality drivers ensuring consistent
quality and high durability. The IX Series offers reliable operation can be
used in a variety of environments.
Crossover network optimization
The cross-over network incorporates a high
frequency driver protection circuitry to prevent
damage to the transducer and extend speaker life.
Set-up System
The IX Series can be used and mounted to meet a variety of applications. A bottom
standard pole mount allows for easy portable installation on speaker stands. Four T-nut
inserts points on both the bottom and top of the cabinet allow for ease rigging in fixed
installation. The IX Series offers high-power and dynamic sound for a variety of applications
at an affordable price.
Multi Purpose Speaker System
IX Series is a compact 2-way high power
portable loudspeaker. Its wide dispersion
and frequency range make the IX Series
an ideal speaker in a large range of
applications. Its bright sound and ‘punchy’
base will accurately reproduce music and
voice.
Floor Monitor Floor Standing Suspended Pole Mount
IX Series
Portable 2way passive Loudspeaker System
IX Series Speakers are 2-way point source type speakers that can be used in a variety of applications. With their wide and
dynamic frequency response the IX series accurately reproduce a wide range of frequency including a tight and powerful
base.
Features
•High-Quality Woofer
•Ultra-small, ultra-light, high-powered, portable speaker
•Wide coverage and rich sound
•Horn driver protection circuitry and crossover network
•High-strength ABS injection molded port enclosure
•High-density sound-absorbing materials suppression of the internal resonance
•Ultra-light enclosure for portable or fixed install
•Stand mounted with built in pole socket
Applications
•Multipurpose venues
•Church
•Meeting rooms
•School / classroom audio-visual
•Literary / sports facilities / aerobics
•Live band / Events
•Portable speaker system
Technology of INTER-M
STANDARD
international standards including KS, IEC, AES and EIA. All measurements
and technical specifications found on data sheets and manuals have been
measured using international standardized processes in an anechoic
chamber using B&K, ClIO, LMS and MLSSA speaker testing equipment.
This process also ensures the development of higher quality products and
standards. (IX-8H/12H/15H obtained KS accreditation.)
FACTORY
testing and tuning software. The speakers are fully assembled using
high quality control standards. They are manufactured using precision
CNC machinery and are ROHS compliant. The cabinets are fitted with
the highest quality components for optimum performance at reasonable
prices.
Inter-M ensures conformity in specifications to all
Inter-M speakers are designed using high precision
Inter-M ensures conformity in specifications to all international
R&D
standards including KS, IEC, AES and EIA. All measurements and
technical specifications found on data sheets and manuals have been
measured using international standardized processes in an anechoic
chamber using B&K, ClIO, LMS and MLSSA speaker testing equipment.
This process also ensures the development of higher quality products
and standards.
Our rigorous testing and quality control process ensures a uniformity
QC
and consistency in frequency, impedance and SPL. Speakers are tested
beginning at the component level throughout the assembly process and
all the way to the finished product. All test results are stored in a database
where the quality process can be tracked. Speakers are tested for power
and durability. A 100 hour test to KS Standard and eight hour test to AES
standard is also performed. Finally a TRUE-RMS voltage and current is
also measured.and current is also measured.
IX-H Series
Polar Pattern
IX8H
Vertical
IX12H
Vertical
IX15H
Horizontal
Horizontal
Vertical
Horizontal
Quality + Price
= IX Series
Quality
Portable speaker made with plastic has been recognized
as a low-quality speakers in the market. The newly
released INTER-M IX Series boast a high quality designed
through the tuning of the network and the long-term
simulation. In order to improve the quality of the speakers.
It is high quality speaker system attained by making every
effort at each stage QC, R & D, production, testing to have
sufficient durability and designing around the sound quality
of each component.
Price
IX Series is proud of reasonable price.
IX Series is supplied with the affordable price and high quality.
Inter-M will continue to further expand line-up like IX
series in order to provide “High quality products with
reasonable price”.
Sound Quality
Durability
Mobility
High-intensity of ABS emission enclosure
IX Series is highly durable as desined with high-intensity ABS emission
enclosure.Sturdy enclosure is suitable for any outdoor uses as it can protect
interior driver and network from exterior impact.
IX Series
270 260
440
Drawings
IX8
IX15
IX12
IX Series
Type
Frequency Range (-10dB) 60Hz ~ 18kHz 50Hz ~ 18kHz 45Hz ~ 20kHz
Transducer
Power Handling 125W AES, 600W Peak 200W AES, 800W Peak 300W AES, 1200W Peak
Sensitivity ( 1M / 1W ) 95dB SPL 95dB SPL 98dB SPL
Maximum SPL 122dB 124dB 129dB
Nominal Impedance 8ohm 8ohm 8ohm
Nominal Dispersion 80°x50°(HxV) 90°x60°(HxV) 90°x60°(HxV)
Connectors 2 X Speakon NL4 Compatible
Enclosure Material ABS RESIN ABS RESIN ABS RESIN
Fitting 1x35mm Pole with Locking Screw Socket
Weight 6.4kg / 14.1lbs. 15.45kg / 34.0lbs. 19.57kg / 43.1lbs.
Dimension (W×H×D)
Specications
Portable 2way
loudspeaker systems
LF.203mm(8")woofer
HF.25.4mm(1")tweeter
270 x 440 x 260mm
10.6 x 17.3 x 10.2in
IX8 IX12 IX15
Portable 2way
loudspeaker systems
LF.305mm(12")woofer
HF.25.4mm(1")tweeter
424 x 640 x 342mm
16.6 x 25.1 x 13.4in
Portable 2way
loudspeaker systems
LF.381mm(15")woofer
HF.25.4mm(1")tweeter
480 x 710 x 384mm
18.8 x 27.9 x 15.1in
IX-H Series
270 260
440
Drawings
IX8H
IX15H
IX12H
IX-H Series
Type
Frequency Range (-10dB) 60Hz ~ 20kHz 48Hz ~ 20kHz 39Hz ~ 20kHz
Frequency Response (±3dB) 70Hz - 20kHz 60Hz ~ 20kHz 45Hz ~ 20kHz
Transducer
Power Handling 225W AES, 900W Peak 425W AES, 1700W Peak 625W AES, 2500W Peak
Sensitivity ( 1M / 1W ) 95dB SPL 97dB SPL 98dB SPL
Maximum SPL 122dB 129dB 131.8dB
Nominal Impedance 8ohm 8ohm 8ohm
Nominal Dispersion 60°x50°(HxV) 60°x50°(HxV) 60°x50°(HxV)
Connectors 2 X Speakon NL4 Compatible
Enclosure Material ABS RESIN ABS RESIN ABS RESIN
Fitting 1x35mm Pole with Locking Screw Socket
Weight 7.9kg / 17.4lbs . 15.45kg / 34.0lbs. 24kg / 52.9lbs.
Dimension (W×H×D)
Specications
Multi-purpose Plastic 8" 2way
Passive Loudspeaker
LF.8" Vented cooling driver
HF.1" exit titanium compression
driver
270 x 430 x 260mm
10.6 x 16.9 x 10.2in
IX8H IX12H IX15H
Multi-purpose Plastic 12" 2way
Passive Loudspeaker
LF.12" Vented cooling driver
HF.1" exit titanium compression
driver
424 x 640 x 342mm
16.6 x 25.1 x 13.4in
Multi-purpose Plastic 15" 2way
Passive Loudspeaker
LF.15" Vented cooling driver
HF.1" exit titanium compression
driver
480 x 705 x 386mm
18.8 x 27.7 x 15.1in
APPLICATIONS
이동형 시스템 블럭도
이동형 시스템 구성
POWER AMP
V2-3000
STAGE MO. SPEAKER
POWER AMP
V2-2000
Movable Rack
이동형 랙
MICROPHONE
MD-50S
WIRELESS RECEIVER
WRX-F902
WIRELESS HAND MIC
WHT-F901
WIRELESS BELT MIC
WBT-F901
Diagram of the Movable System
AUDIO MIXER
MX-1646
EQUALIZER
GEQ-231
MULTI SOURCE PLAYER
CD-610U
Construction of Movable System
이동형 시스템 구성
Procedure of Movable
이동형 랙 장착 순서
Rack Installation
AUDIO MIXER
MX-1646
STAGE MO. SPEAKER
IX12
POWER AMP
V2-3000
MAIN SPEAKER
IX15H
MAIN SPEAKER
IX15H(625W)
SPEAKER STAND
SPEAKER STAND
별도구매
For Additional Purchase
WIRELESS RECEIVER
WRX-F902
MULTI SOURCE PLAYER
CD-610U
EQUALIZER
GEQ-231
POWER AMP
V2-2000
STAGE MO. SPEAKER
IX12(200W)
POWER AMP
V2-2000
POWER AMP
V2-3000
Inter-M Corp. (IMK)
719, Dobong-ro, Dobong-gu, Seoul, Korea
Overseas Sales Team
Tel_ +82-2-2289-8141~7 Fax_ +82-2-2289-8149 E-mail_ overseas@inter-m.com www.inter-m.com
※ Design and specication are subject to be changed for the improvement of product quality without pre notice.
