FS-30/FS-52/
FS-60/FS-100
Monitor Speaker
Copyright 2004 Inter-M Corporation
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
Contents
Welcome ..................................................................................................................................... 3
Unpacking ............................................................................................................................... 3
Warnings .................................................................................................................................. 3
Monitor Speaker...................................................................................................................... 5
Features ....................................................................................................................................... 5
Setup and Operation.................................................................................................................. 6
Connecting your Speaker System ............................................................................................ 7
Choosing the Correct Speaker Cable................................................................................... 7
Speaker Connection Procedures .......................................................................................... 7
Maintaining Proper Polarity .................................................................................................... 7
Choosing the Correct Amplification...................................................................................... 7
Using Multiple Loudspeakers.................................................................................................. 8
Directional Curves ...................................................................................................................... 9
Specifications............................................................................................................................ 10
2
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
Welcome
A personal welcome to you from the management and employees of Inter-M
Thank you for purchasing this fine Inter-M product. All of us here at Inter-M are dedicated
to providing you with the highest quality products and the best value.
We sincerely trust this product will provide you with years of satisfactory service, but if
anything is not to your complete satisfaction, we will endeavor to make things right.
Welcome to Inter-M, and thank you for becoming a part of our worldwide extended
family!
Unpacking
Although your FS-Series Monitor Speaker is neither complicated nor difficult to operate,
we recommend you take a few minutes to read this brief manual and familiarize yourself
with the important information regarding product features, setup and operation.
We strongly recommend you retain the original packaging. In the unlikely event the
product must be returned for servicing, the original packaging (or reasonable
equivalent) is required.
Warnings
Environment
Never place this product in an environment that could alter its performance or reduce its
service life. Such environments are usually characterized by high levels of heat, dust,
moisture, or vibration.
Safety
1. Read these instructions carefully.
2. Follow all instructions.
3. Keep all warnings.
4. Clean only with a damp cloth.
5. Install only in accordance with the instructions in this manual.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other
devices (including amplifiers) that produce heat.
7. Use only the attachments/accessories specified.
3
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
8. Use only with a cart, stand, tripod, bracket, or table specified, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid overturning.
9. Unplug this apparatus during lightning storms or when unused for long periods of
time.
10. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
4
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
FS-30/FS-52/FS-60/FS-100
Monitor Speaker
Features
Superior Performance
• The FS-series Monitor Speakers are designed for high-fidelity professional sound
reproduction.
Switchable Impedance
• The FS-30/FS-60/FS-100 models incorporate an impedance switch for connection to a
low impedance (8Ω) or high impedance distributed (70V/100V) system.
Overload Protection
• The FS-52 model incorporates an electronic overload circuit to protect the tweeter.
High Efficiency Two-Way Design
• Full-range two-way speaker system for high efficiency PA system performance.
Easy Installation
• Installs easily with included bracket.
5
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
Setup and Operation
Your FS-Series Monitor Speakers may be used as free-standing speakers, or attached to a
wall or other secure surface with the supplied mounting bracket. The illustration below
shows the preferred method of securing the speaker.
WARNING: under no circumstances should any loudspeaker be mounted or suspended
in a public place unless the mounting method has been approved and certified by a
qualified engineer. Failure to properly secure the system can result in damage to the unit
or personal injury.
6
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
Connecting your Speaker System
Always switch off the power to the amplifier before connecting speakers.
Choosing the Correct Speaker Cable
It is important to choose cabling designated for audio use and good quality connectors.
Using guitar cable or zip cord (designed for lamps and other electrical use) or poor
quality connectors will degrade your loudspeakers’ audio performance. For distributed
loudspeaker systems, we recommend stranded twisted pair speaker cable with an
overall vinyl jacket (plenum rated when installed in required installations).
Always use the appropriate gauge of speaker cable. For cable runs of less than 25 feet
(7.5 meters), 18- gauge cable is adequate. For longer cables, we suggest 16-gauge
stranded cable.
Speaker Connection Procedures
After removing approximately 10mm (1/4-inch) of insulation from the ends of the speaker
cables, twist the strands tightly and then twist together with the distribution cable(s), using
an appropriate cable connector.
Make certain the wires do not protrude from the cable connector and touch any metal
on the speaker chassis, or any other adjacent metal.
Maintaining Proper Polarity
It is very important to wire your speakers consistently in order to maintain proper
polarity. All quality cables are manufactured with clear markings to identify the
different conductors – normally by color-coding, printed markings, or textured ribbing
on the cable’s jacket material. Failing to do so will cause your speakers to operate
out of phase, resulting in significantly reduced low-frequency output from your
system.
Choosing the Correct Amplification
When selecting an amplifier for use with your distributed speaker system, it is important to
choose an amplifier which has sufficient power output.
Choosing an amplifier that does not have adequate rated power may result in pushing
the amp beyond its limits, producing distortion or “clipping” of the signal. This can irritate
the listener and may cause damage to the speaker.
Choosing an amplifier that is over-powered can result in over-driving the speaker system.
7
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
Using Multiple Loudspeakers
It is important to consider the overall speaker load (impedance) when connecting
distributed speaker systems to an amplifier. Some distributed loudspeakers are marked in
load impedance; others show the wattage taps. Whatever the case, it is easy to
compute the total impedance (or wattage load) that is possible for a given amplifier.
8
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
Directional Curves
FS-30/FS-60/FS-100
FS-52
9
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
Specifications
ELECTRICAL
Rated Input
FS-30 30W
FS-52 50W
FS-60 60W
FS-100 100W
Input Impedance
FS-30 8Ω/330Ω
FS-52 8Ω/200Ω
FS-60 8Ω/167Ω
FS-100 8Ω/100Ω
Frequency Response 180Hz-13kHz
GENERAL
Dimensions 175(W) x 300(H) x 158.5(D) mm
6.89(W) x 11.8(H) x 6.24(D) in.
Specifications and design subject to change without notice for improvements.
10
FS-30/FS-52/FS-60/FS-100 Monitor Speaker
Inter-M, Ltd. (Korea) began operations in 1983.
Since then, Inter-M has grown to become one of the largest manufacturers
of professional audio and commercial sound electronics equipment in the world.
Inter-M has gained worldwide recognition for its own branded products,
as well as private label manufacturing of electronics sold under other names (OEM).
The company is no longer just a Korean company, but rather a global company
that is truly international in scope, with factories and offices in Korea and China,
and sales and marketing operations located in Japan, Europe, and the U.S.A.
With more than 850 employees around the globe, Inter-M is well-poised for further growth and
expansion.
INTER-M AMERICAS, INC.
1 EAST BEACON LIGHT LANE, CHESTER, PA, USA 19013-4409
TEL: (610) 874-8870, FAX: (610) 874-8890
Home Page:http://www.inter-m.net, E-mail: service@inter-m.net
INTER-M Corporation
SEOUL OFFICE: 653-5 BANGHAK-DONG, DOBONG-KU, SEOUL, KOREA
TEL: 82-2-2289-8140~8, FAX: 82-2-2289-8149
Home Page:http://www.inter-m.com, E-mail: export@inter-m.com
0804FS305260100 PRINTED IN KOREA
