Digital paging and broadcasting solution
Inter-M provides leading digital broadcasting solution as
one of leading companies in Korea.
Oriented from the analogue audio system evolved into network
based digital AV PA system based on world best technology and service for
the future of human and company.
IPC System Introduction 4
Feature and Merit 5
Model and Feature 6
(Basic / Additional System )
System Application 8
(Central, Local, Fiber, TCP/IP, Multi CH Amp)
System Drawing 12
Operation Software Introduction 14
Contents
IPC System....
IPC System Introduction
IPC System provides to cover 16 x 6 Matrix, Max 256 zone with easy installation
and user friendly interface.
Using CAT5 cable to install easily, LCD touch screen and PC control is
advantage of user operating IPC system for middle and small scale.
Based on Inter-M transmission
solution of fiber optic and TCP/IP,
IPC system provides de-centralized
system and multi channel control
4
Feature
• 16 x 6 matrix, Max 160 zone paging address independently
Max 160 zone, 16 x 6 simultaneous Broadcasting
(BGM, Paging, EM, RM, MP3, CD)
• Local MIC paging by PC
Local control by PC and paging by MIC built in PC Mic input via network.
• De-centralized and network solution
De-centralized solution with IPC digital amplifier. It also provides the fiber optic and
TCP/IP solution to cover local building and site with 15km.
• Easy to install
All cable between each device is linked only UTP Cat 5 in IPC system.
5
UPDATED INFORMATION
Audio Mixing(Input 8CH)
Key grouping function in remote
mic station.
Dual EM paging mode
(Evacuation / warning)
One touch macro
Individual zone real-time
Volume and EQ control
MP3 selection function
Schedule edit and save
function
Basic System Configuration
SI-100 System Integration Main Controller
8CH audio input combo
(XLR and 55mm phone jack) jack applied
8CH remote Mic station support
(SR-100 x 8)
12CH audio input input level Volume and
5band EQ control
THD....................................below 1%
SN over (720kHz, LPF) ...............65dB
Frequency response......100Hz~15kHz
SM-100 System Monitor
15 LCD touch screen operation
Built-in panel emergency Mic
Built-in Input and output zone monitoring speaker
UI control scroll button on control panel
SP-100 System Amplifier
6CH/60watt digital amp applied
1CH Cat 5 cable for 6Bus
CH Volume and 5 band EQ control
function
THD 1%, AES 17 Filter ...60watt(100V)
Frequency Response........80Hz - 20Hz
THD(AES 17 Filter)............below 0.3%
SN(AES 17 Filter)................over 85dB
PP-100A System Amplifier
6CH pre amp applied
1CH Cat 5 cable for 6Bus
CH Volume and 5 band EQ control
function
SR-100 System Remote Mic Station
Mic / Aux / Speaker Vr control
Cat 5 Ethernet cable system installation
Push to talk one touch broadcasting
Built-in zone monitoring speaker
SN (720kHz, LPF)
• Mic : -63dB • AUX : -70dB
Frequency Response
• MIC...........................100Hz-10kHz
• AUX..........................300Hz-15kHz
Line Output ................................0dBv
Frequency Response .......50Hz~20kHz
THD(AES 17 Filter)............below 0.1%
SN(AES17 Filter).................over 85dB
IPC System....
6
Additional System Application(List package system with basic unit)
SR-100KP Extension Keypad
SR-100 key extension pad
Keypad 1set provide 12zone extension
7
FT/R-100M Fiber Optic Multi Mode
Audio and Data transmission via Fiber optic Cable
Maximum 2Km audio and data transmission
FT/R-100S Fiber Optic Single Mode
Audio and data transmission via Fiber optic cable
Maximum 15km audio and data transmission
AOE-212 TCP/IP Network Transmission
Audio and data transaction(TX/RX) via Ethernet.
Audio two communication (WAN 1:1, LAN 1:20)
DPA-5075M Multi CH Amp
4CH x 75watt output + spare amp 1CH (75watt)
CH bridge available upto 300watt
Independent SMPS design into individual CH
DM-75 Multi CH Amp Module
DPA-5075M Amp Module
DPA-430H Multi CH Amp
4CH 300watt/100V power out.
Independent SMPS design into individual CH
1U rack size compact design
IPC System....
8
System Application 1(Single building – Basic configuration)
– In the case of single building or the distance in between building within 100m
– Elementary School, Office, Government office, Department store
Application Explanation :
The basic application of IPC system providing single size building which has cabling distance within 100m
system application. 6CH zone application by amp unit is the basic concept of the system. Remote paging unit
SR-100 can be installed anywhere within the system such as information desk, operation room, board member
room and etc. Also IPC system provides touch screen control and remote PC control software. Also system wired
only by CAT 5 cable.
Installation and System Application
1) School
Short distance of building such as elementary, middle, high school will be suitable market of IPC-1.
2) Company and Government Office
Single or Short distance of building but has subsidiary building where need BGM broadcasting.
3) Hospital
Single size building but has individual independent floor such as complex hospital.
SM-100
SI-100
SP-100
SR-100
SR-100
Operation Room
Information Desk
9
System Application 2
(Single/Complex building and need fiber optic system configuration)
–
Central and spread application within the building distance 15km
EX) University/Factory/Military Camp facilities
System Explanation :
IPC system provides fiber optic solution for wide range of application. It is very suitable for central control system
required market such as university and etc. IPC system fiber optic solution provides within the distance 15Km and
central and individual audio control is available. IPC system provides cost effective installation by unified one
control system for local area control by total digital system application.
Installation and System Application
1) University
In the application of distance in between buildings within 15Km which need central & individual management.
2) Training Center and other facilities
In the application in between Training Center and other facilities which need central & individual management.
3) Military facilities
In the application of distance in between headquarter and camp building within 15Km.
PP-100A
FR-100S
FT-100S
DPA-430H
DPA-430L
SM-100
SI-100
SP-100
SR-100
FT-100S
SP-100
FR-100S
FT-100S
SP-100
FR-100S
FT-100S
Sport Complex
Main Building
Library
Test Laboratory
IPC System....
10
System Application 3(Wide spread building system by TCP/IP network)
–
In the application of Head office and branch office or capital City and local cities.
EX) Department store, Chain Store and etc (Dedicated network line)
System Configuration Explanation :
IPC system network application provides much wider range of system configuration than local area network
such as head office and branch office in other cities. The basic network connection is consist of AOE-212 network
adaptor, and provide remote broadcasting by PC. IPC network connection developed based on Inter-M IT
infrastructure and provide the best quality of wide area remote broadcasting solution.
SM-100
SP-100
PP-100A
SR-100
AOE-212
AOE-212
AOE-212
AOE-212
AOE-212
DPA-430H
Speaker
AOE-212
DPA-430H
AOE-212
DPA-430H
AOE-212
DPA-430H
Installation and System Application
1) Commercial operation
In the case of real-time communication between head office and branch office
2) Coffee Chain Store
In the case of BGM broadcasting from the head office to coffee chain stores.
Head Office
C Branch Office
Speaker
Speaker
Speaker
A Branch Office
B Branch Office
D Branch Office
11
System Application 4(Central/Spread type building with multi CH amplifier)
–
In the case of auto system restoration for system stability for certain purpose.
EX) Power Plant & Social major facilities
System Explanation :
The system auto restoration feature of IPC system could supply solution to power plant or other major social
facilities for safety of system. The spare amplifier system which provides from multi CH amp is supplying instant
reaction of operation in the situation of faulty system or failure. Especially, no turn-off power of system provides
shortest restoration time in the time of repairing.
SM-100
SI-100
PP-100A
SR-100
DPA-5075M
SR-100
Installation and System Application
1) Power plant & major social facilities
The market where auto failure restoration application needed for public announcement
Office
Security Office
System Application
12
SM-100
Touch Screen for System Control
Built-in monitor speaker
Built-in Emergency manual microphone
SR-100
24 zone control and group/macro remote microphone station
Built-in output zone monitoring speaker
Mixing BGM input
SI-100
Main controller 16x6 output matrix
Sensor input 64CH
CD/MP3 player included
SP-100
6CHx60w output digital amplifier
Individual CH Volume and EQ included
PP-100A
6CH pre amp
Individual CH Volume and EQ included
PC-9335AD
DECK
CD-660
6CD Changer
PD-9359
TU-610
Stereo Tuner
Power Distributor
IPC System....
13
SR-100 #1
SR-100 #2
SR-100 #8
SPEAKER
Fiber-optic cable
(2KM)
Adaptor DC 12V
Main Software/Explanation & Function
14
1. Main operation screen
Sound source and zone control main screen. Built-in CD, MP3, Preset, grouping,
EM/BGM/RM broadcasting.
2. Schedule setup
Convenient date and schedule reservation of BGM and timer broadcasting by 100
different scenarios in a day and max 700 scenario in a week.
3. Input volume and EQ control of amp out
Maximum 16 input source volume control and monitoring and amp out (SP-100/
PP-100A) volume and EQ control.
4. System Status
Monitoring the status of SI-100 (Main system) and SP-100 (Digital zone amp).
5. Broadcasting Monitoring
Providing BGM monitoring.
IPC System....
www.inter-m.com
Inter-M Corporation (IMK)
653-5 Banghak-Dong, Dobong-Ku, Seoul, Korea
Overseas Sales Team
Tel : +82-2-2289-8141~7 / Fax : +82-2-2289-8149 / E-mail : overseas@inter-m.com
* Specifications and design subject to change without notice.
