Inter-M CS-20, CS-30, CS-80 Brochure

Output Power : 60W(RMS) @<1% THD High fidelity mic mixing amplifier 4 ohm direct output 70V, 100V transformer coupled output Tone (treble / bass) control Input signal display with LED External mute and TEL IN Dedicated microphone INPUT1 (Phone [Front] or XLR connector) Phone jack for INPUT2 (MIC/LINE selectable) Phone jack and RCA jack for INPUT3 Power source : 100~120VAC or 220~240VAC ; 50/60Hz Power consumption : 24W Weight : 3.0kg/6.6lb Dimensions (WxHxD) : 300x44x230mm/11.8x1.7x9in
Output Power MA-206 : 60W(RMS) @<1% THD
MA-212 : 120W(RMS) @<1% THD
MA-224 : 240W(RMS) @<1% THD High fidelity mic mixing amplifier 4ohm, 70V and 100V transformer coupled output 5 Zone output and all zone selectable 5 Band graphic equalizer 3 microphone input or line input (XLR connector) 2 microphone input or line input (Phone jack) Switchable phantom power supply (MIC1~3) RCA jack for line input 6 VCA (Voltage Controlled Amplifier) External mute and TEL IN Chime/Siren signal output Channel input level display with LED Output level display with LED Power Source : 100~120VAC or 220~240VAC ; 50/60Hz Power Consumption MA-206 : 38W, MA-212 : 50W, MA-224 : 75W Weight : 4.8kg/10.6lb Dimensions (WxHxD) : 420x88x320mm/16.5x3.5x12.6in
PAM series Module. CD/USB/DRP(Digital Record and Playback : SD Memory 1GB)/MP3 CD+USB, DRP(SD Memory) potable FM TUNER CD Long-Life Function CD COPY function (CD USB or DRP) USB Hosting Function (USB DRP) FM 30 Memories Power source : DC 18V/22V Weight : 950g/2.1Ib Dimensions (WxHxD) : 184x55x180mm/7.2x2.2x7.1in
Contains a premium grade speaker unit Best reliability The beautiful and graceful cabinet design Easy installing and convenience Full range of 1 way speaker system (6 inch unit) Multi-tap switch offers an easy way to change taps
on a transformer
Rated power CS-3 : 3W, CS-6 : 6W,
CS-12 : 12W
Weight CS-3 : 700g/1.5lb
CS-6 : 710g/1.6lb CS-12 : 740g/1.6lb
Dimensions ( xD) : 220x100mm/8.7x4in
Contains a premium grade speaker unit Best reliability The beautiful and graceful cabinet design Easy installing and convenience 2 Way speaker system (6inch -2way coaxial type) Multi-tap switch offers an easy way to change taps
on a transformer
Rated power CS-20 : 20W, CS-30 : 30W,
CS-80 : 80W
Weight CS-20 : 2kg/4.4lb
CS-30 : 2.7kg/6lb CS-80 : 3.7kg/8.2lb
Dimensions ( xD) : 230x180mm/9x7in
OUTDOOR INDOOR
OUTDOOR INDOOR
Horn Unit(CU-920HV/940HV), Tweeter unit(CU-920H/940H) Simple and clear design with their rounded corners and edges Top quality durable units are applied for high sound pressure level
and excellent sound reproduction performance Strong aluminum frame which guarantees the strength of the cabinet The highest grade of twitter speakers are used to achieve the best
of the sound User based design for fast installation Weatherproof, dampproof materials ensure this speaker suitable
for working in the harsh outdoor environments Speaker Terminal added for easy installing and convenience
Horn Unit(CU-900V Series) cleare speech for the distance,
Tweeter unit (CU-900 series) profound BGM quality Simple and clear design with their tweeter unit corners and edges Top quality durable units are applied for high sound pressure level
and excellent sound reproduction performance Strong aluminum frame which guarantees the strength of the cabinet The highest grade of twitter speakers are used to achieve the best
of the sound User based design for fast installation Speaker Terminal added for easy installing and convenience
User based design for fast installation Simple and clear design with their rounded corners and edges Top quality durable units are applied for excellent sound reproduction
performance
Direction adjustable with bracket
User based design for fast installation Simple and clear design with their rounded corners and edges Top quality durable units are applied for excellent sound reproduction
performance Direction adjustable with bracket
Inter-M Corp. (IMK) 653-5 Banghak-Dong, Dobong-Ku, Seoul, Korea / Overseas Sales Team
Tel: +82-2-2289-8141~7 Fax: +82-2-2289-8149 E-mail: overseas@inter-m.com
March 2010
Design and specification are subject to be changed without pre notice.
