Interlogix XL LCD Keypad Plus User Manual

LCD Keypad User's Guide

rev1.3

Attention: Security Representative / Installer, Please give this guide to the customer before beginning work on the system.

Contents

For topics not listed here, please see the Index

Welcome.....................................................................................................................................1

The xL LCD Keypad ............................................................................................................................. 2

Alarms, Turning Protection On and Off..................................................................................5

Alarm Monitoring Features ................................................................................................................... 6

Audible Keypad Tones.......................................................................................................................... 6

Sirens ................................................................................................................................................... 7

Dealing with Alarms (what to do if the keypad is beeping).................................................................... 7

Silencing a False Alarm ........................................................................................................................ 7

Using the Emergency Keys .................................................................................................................. 8

Worklate: Extending the Scheduled Closing Time............................................................................... 8

Suspending Schedules for an Area or Areas........................................................................................ 9

Turning Protection ON, STAY, or Viewing the Present Arming-Level................................................... 9

Turning Protection OFF ...................................................................................................................... 10

Turning Protection On by Area Groups, a Group of Areas or Individual Areas................................... 10

Area Priority Protection On/Off ........................................................................................................... 11

Common Area Protection On/Off........................................................................................................ 11

Turning ON an Area’s Protection using an Access TOKEN................................................................ 11

Turning OFF an Area’s Protection using an Access TOKEN.............................................................. 11

UK System Operation......................................................................................................................... 12

UK and European System Operation ................................................................................................. 12

Checking Status and Controlling Items................................................................................15

Status and Control Features............................................................................................................... 16

Using the Function Keys..................................................................................................................... 16

Checking the System Status (monitored conditions for a system control unit) ................................... 16

Checking the Status of Sensors (Points) and Areas........................................................................... 17

Bypassing or Isolating a Faulty Sensor............................................................................................... 17

Checking Status or Controlling Readers or Doors .............................................................................. 18

Checking the Status or Controlling an Elevator Reader ..................................................................... 19

Checking the Status of an Application Module (POD) ........................................................................ 19

Administration and Maintenance Tasks ...............................................................................21

Changing Your Own PIN .................................................................................................................... 22

Adding a User to the System .............................................................................................................. 22

Default Authority Settings ................................................................................................................... 23

Viewing or Changing Settings for a User............................................................................................ 24

Deleting a User................................................................................................................................... 26

Setting the Date and Time .................................................................................................................. 26

Manually calling the Director PC from the LCD Keypad: .................................................................... 27

Viewing the History............................................................................................................................. 27

Printing the History Log ...................................................................................................................... 28

Changing the Printed History Language ............................................................................................. 28

Testing Monitored Sensors (Performing a Walk Test) ....................................................................... 29

Testing Panic Buttons (Performing a Hold-up Test) ........................................................................... 30

Testing Sirens (System Test) ............................................................................................................. 30

Reference Topics ....................................................................................................................31

System Information............................................................................................................................. 32

Residential Fire Safety / Evacuation Plan........................................................................................... 34

Arming Station Reference .................................................................................................................. 36

Wireless Keypad Reference ............................................................................................................... 39

Error Messages and Trouble Indications ............................................................................................ 40

Things to Do to Prevent False Alarms ................................................................................................ 41

Index.........................................................................................................................................42

 These instructions are used for both the Open xL and Monitor xL versions of xL Security Equipment.  A red dot on xL equipment and its packing material will identify it as the Open xL version.  Model numbers ending with a “T” will identify the Open xL equipment versions.  Open xL and Monitor xL versions of xL Security Equipment can not be used together.  VBUS devices can be used with both Open xL and Monitor xL versions of xL Security Equipment. VBUS

devices are not used with ISM equipment.

 Only Monitor xL Security Equipment can be used to upgrade a Monitor ISM security system. The Open

xL version is not used with Monitor ISM equipment.

 Only Monitor xL Director Software can be used to upgrade Director Software that communicates with a

Monitor ISM security system. The Open xL Director Software is not used with Monitor ISM equipment.

 Open xL, Monitor xL and ISM systems can communicate to the same HSC-IP Receiver. However, the

Open xL system will require an Open xL HSC-IP Module to communicate with the HSC-IP Receiver.

 A regular IP Module (non HSC-IP) can be used by an Open xL, Monitor xL or ISM system if they are only

communicating to the Monitor xL or Open xL Director Software.

 Only Monitor xL Director Software can be used with a Monitor xL Security System.  Only Open xL Director Software can be used with an Open xL Security System.  Confirm that the correct firmware is used when upgrading a security system’s firmware. Upgrading an

Open xL security system firmware with Monitor xL firmware can disrupt operations on a system wide scale. An Open xL system must be upgraded with Open xL firmware. The same applies to only using Monitor xL firmware to upgrade a Monitor xL system.

ii xL LCD Keypad User's Guide 21-3600E rev1.3

About This Guide

This guide provides details on performing various tasks in a xL system using an LCD keypad.

To locate a desired topic, refer to the table of contents (near the front of this guide), or the Index (near the back of this guide).

Tip: The bottom of each odd-numbered page also gives an indication as to your general position within this guide.

Also See (Related Documents)

For details on using the Director software, refer to the on-line help or User's Guide provided with the software.

Copyrights and Trademarks

™ Pentium is a trademark of Intel Corporation ™ ® Microsoft, Windows, Windows2000, and Windows XP, are trademarks or registered trademarks of the Microsoft Corporation.

Disclaimer

In the interests of ongoing improvement in quality and design, we reserve the right to change product specifications without prior notification. All software, firmware, drawings, diagrams, specifications, catalogues, literature, manuals and other materials relating to the design, use, and service of related products shall constitute the proprietary information of the manufacturer.

Industry Canada Customer Information

NOTICE: This equipment meets the applicable Industry Canada Terminal Equipment Technical Specifications. This is confirmed by the registration number. The abbreviation, IC, before the registration number signifies that registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were met. It does not imply that Industry Canada approved the equipment.

/ Sécurité CSG Inc.

The Ringer Equivalence Number (REN) assigned to each terminal equipment provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed five.

The REN for the xL using the North American Modem is 0.1 The REN for the Modem is 0.0

Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. The precaution may be particularly important in rural areas.

Caution: Users should not attempt to make

such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.

xL using the Worldwide

NORTH AMERICA: Customer Instructions Pertaining to

FCC Regulations

This equipment complies with the Federal Communications Commission (FCC) rules and regulations governing telephone equipment and the Technical Requirements for Connection to the Telephone Network published by the industry’s Administrative Council for Terminal Attachments (ACTA). On modem board of this equipment is a label that contains, among other information, a product identifier in the format US:AAAEQ##TXXXX. If requested, this number must be provided to the telephone company.

This equipment is designed to be connected to the telephone network or premises wiring

using a hard wired connection that does NOT

rely on a modular jack. If a modular jack is

21-3600E rev1.3 xL LCD Keypad User's Guide iii

installed, it is the responsibility of the installing company to ensure that the jack and/or plug is compliant with the criteria of the telecommunication industry.

The Ringer Equivalence Number (or REN) is used to determine the number of devices that may be connected to a telephone line. Excessive REN’s on a telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of REN’s should not exceed five (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total REN’s, contact the local telephone company.

The REN for the xL using the North American Modem is 0.2 The REN for the xL using the Worldwide Modem is 0.0

CAUTION: If this equipment (xL) is deemed

potentially harmful to the telephone network, the telephone company will attempt to notify you in advance of discontinuing service. . If advance notice is not practical, the telephone company will notify you as soon as possible. If service is disconnected, you will be advised of your right to file a complaint with the Federal Communications Commission (FCC) should you believe it necessary.

The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operation of this equipment. Should this occur, advance notice you be provided in order for you to make necessary modifications to maintain uninterrupted service.

If trouble is experienced with this equipment (xL), for repair or warranty information, please contact the installing company.

If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.

There are no user serviceable parts which may be repaired by the customer. All repairs must be performed by an authorized dealer representative.

This equipment cannot be used on public coin phone service provided by the telephone company. Connection to party line service is

subject to state tariffs. (Contact the state public utility commission, public service commission or corporation commission for information.)

WARNING NOTICE:

NORTH AMERICA AUSTRALIA

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at their own expense.

This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate protection measures.

WARNING: Changes or Modifications not expressly approved by VEREX Technology could void the user’s authority to operate this equipment.

Restrictions and Requirements for UL Listed Systems

• Access control is not permitted for UL

listed residential systems.

• The system must be tested on a weekly

basis, including all fire initiating devices. Please see “Testing Monitored Sensors” in this manual for details.

• Detectors and fire initiating devices will

be disabled while making programming changes to the system.

iv xL LCD Keypad User's Guide 21-3600E rev1.3

CE – Conformity

The xL System described in this manual conforms to the requirements of the Council Directive 89/336/EEC – The EMC Directive and 73/23/EEC – The Low Voltage Directive. 1999/5/EC-The R&TTE Directive. To maintain compliancy with this directive, it is essential to adhere to the installation recommendations described within this manual.

Standards to which Conformity is Declared:

• CISPR 11:2003 / EN55011:2003 – Class A – Limits and methods of measurements of radio

disturbance characteristics for industrial, scientific and medical (ISM) radio-frequency equipment.

• CISPR 22:2003 / EN55022:2003 Class A – Limits and methods of measurement of radio

disturbance characteristics of information technology equipment.

• EN 50130-4:1995 – Electromagnetic compatibility – product family standard: Immunity requirements

for components of fire, intruder and social alarm systems.

• EN 60950-1: 2001 – Safety of Information Technology

• TBR21:1998 – Terminal Equipment Attachment requirements for the connection to the analogue

PSTN

Standard Description Severity Applied Performance

IEC 1000-4-2 EN 61000-4-2 IEC 1000-4-3 EN61000-4-3 ENV 50140/240 IEC 1000-4-4 EN 61000-4-4 IEC 1000-4-5 EN 61000-4-5

IEC 1000-4-6 EN 61000-4-6 ENV 50141

IEC 1000-411 EN61000-411

IEC 1000-3-2 EN61000-3-2

IEC 1000-3-3 EN61000-3-3

Not verified by UL

Electrostatic Discharge Radiated RF Immunity

Electrical Fast Transient Surge Withstand Immunity

Conducted RF Immunity

Dip

Dropouts

Voltage Variation Harmonic Current Emissions Voltage Fluctuation and Flicker in Low-Voltage Supply Systems

6kV Contact Discharge (direct and indirect) 8kV Air Discharge 10V/m, 80-2000 MHz, 1 kHz 80% AM modulation 10V/m 80-2000 MHz, Pulse Modulation with 1 Hz Square +/-2kV on AC lines +/-1kV on DC & I/O lines +/-2kV Common Mode on AC lines +/- 1kV Differential Mode on AC Line

+/-2kV Common Mode on I/O lines.

10Vrms, 0.15-100 MHz, 1kHz 80% AM modulation on AC lines 10Vrms, 0.15-100 MHz, 1kHz 80% AM modulation on I/O lines 10Vrms, 0.15-100 MHz, Pulse Modulation with 1 Hz Square. 60% for 0.5, 1, 5 & 10 cycles repeated 3 times every 10s 30% for 0.5, 1, 5 & 10 cycles repeated 3 times every 10s 100% for 0.5, 1, 5 & 10 cycles repeated 3 times every 10s.

+10%, -15% for AC from nominal Class A (Other), Class B (Portable Equipment), Class C (Lighting Equipment) or Class D (Special Current Waveform) Voltage Fluctuation Flicker

Criteria

A A A

A A A A A A

PASS

PASS PASS

21-3600E rev1.3 xL LCD Keypad User's Guide v

Welcome

Dear Customer,

• It is recommended that you review the different operating procedures in this guide

while your system is being installed. explain any questions that you may have about the various topics.

• It is important to check the section at the back of this booklet that will list information

about your alarm system named “Reference Topics”. Ask your Security Representative / Installer to supply the information that should be entered into this section.

Thank-you.

Ask your Security Representative / Installer to

21-3600E rev1.3

Welcome Alarm Status Admin Reference

The xL LCD Keypad

Keypad Lights

Red Flashing: Protection ON Solid: Partial protection (STAY)

The xL LCD (liquid crystal display) keypad provides an integrated 2-line display and multifunction backlit keypad. (The keypad is hidden behind a hinged access cover.)

What You can do with the LCD Keypad

xL LCD keypads provide a convenient local interface that allows:

• Turning protection on and off;

• Checking status of items;

• Controlling / commanding items;

• Performing administrative tasks;

• Some models can act as a card reader to

permit access to locked doors.

Keypad Display and Buttons

The display is your 'window' into the xL system.

Red

Green

Yellow

WELCOME

Enter

- #

Green On Always with power present.

ID:

ABC

JKL

TUV

Z_Q

Yellow On when trouble condition present. Flashing when there is no AC mains.

DEF

MNOGHI

WXYPRS

When you enter your user ID and/or PIN, you will be given access to all menus and features as assigned through your user authorities.

Buttons under the Display Screen

The buttons directly under the display screen allow selecting associated items on the display screen. This means the item displayed on the screen above each button.

Like the rest of the keypad, these buttons are backlit for use in poor lighting conditions.

The Numeric Keypad

The main keypad (in the bottom-left portion of the unit) provides a convenient way to enter numbers, and letters as well (when applicable).

The  Key

This is the "escape" key, which allows you to return to a previous screen, or exit from a menu altogether (log out).

The ◄ arrow ► Keys on the Keypad

These keys allow selecting different items and topics. When available, the left ◄ or right ► arrow keys will appear on-screen.

Emergency Keys and Programmed Function Keys

Pressing a number and the ƒ key at the same time will perform the action as programmed for that key-sequence. The emergency keys at the bottom of the keypad each transmit a specific emergency message (to the central monitoring station).

For more information on the emergency keys, refer to "Using the Emergency Keys" in the "Alarms…" chapter.

For details on the programmable function keys, refer to "Using the Function Keys" in the "Status & Control" chapter.

2 xL LCD Keypad User's Guide 21-3600E rev1.3

If You Are Being Forced to Enter Protected Premises

A duress (panic) alarm is triggered when you enter your PIN with the last two digits reversed. This can be done at reader keypads, system LCD keypads, and Suite Security LED keypads.

: 1 2 3 4

: 1 2 4 3

Normal PIN Example If being forced to Enter

This feature will be available unless it was disabled by your service technician when the system was initially set up.

Logging Into the Keypad (User ID and/or PIN)

NOTE: Your Security Representative /

Installer will supply you with your User ID and PIN number for pressing into the keypad and logging in to the system.

(The default Master user ID and PIN is: e.g. ID: 01 or 001, PIN: 7793)

"Logging In" provides you with access to the features of the LCD keypad. To log in:

Open the keypad cover, and press in your user ID number and/or PIN number as indicated on the display.

When finished viewing or entering items, you can use the  key to exit (press multiple times as

needed--until the "login" screen appears). Tip: You will also be logged out automatically if you do not press any keys for approximately one (1) minute.

Welcome Enter ID: _ _ _

Your Name Appears

Enter PIN:

_ _ _ _

Overview of Screens (Topics)

When logged in, you will see only the topics that you have the authority to use. Some or all of the following topics will be available:

Selecting a Topic: Press the "►" key until your desired topic appears on-screen. Then press the key directly under your topic to select it.

Off // Stay // On:

The first screen that you'll see allows you to arm or disarm the area(s) as desired, or to access other topics.

Only two of arm/disarm selections will appear at a time—depending on the present armingstate of the area(s).

all intrusion protection fully off.

Off: Stay:

partial protection. Internal motion detectors disabled. Only perimeter protection on. For users to remain inside the protected area.

all protection fully on. No one remaining in

On: the protected area.

Status: This allows checking the status of

various items in the system, or commanding items into different states.

Please ignore uncommon status screens that may show up like “Comms, Modem, Licns”. They are for a service technician’s purposes.

Bypass: This allows bypassing faulty

sensor(s) so the system ignores them, and/or to allow arming the system.

History: This allows viewing a record of the

tasks that users have performed (disarm areas, bypass sensors, etc.)

My PIN: This allows the person who is logged

in to change their password.

Users: This allows adding or deleting 'users'

from the system, or viewing or editing settings for specific users.

A "User" is a person who has the authority to login to system keypads, and/or to gain entry at accesscontrolled doors.

Push ► for Menus ↓Stay ↓On

21-3600E rev1.3

Welcome Alarm Status Admin Reference

Test: This allows testing different aspects of

the system.

Verify: This allows a person to prove they are

present. This lets a monitoring facility know that you are present after accidentally tripping a sensor, and/or silencing a false alarm.

Schdule: This allows extending the scheduled

closing time for an area (the "work-late"

feature), or suspending a schedule altogether. Arm/Disarm: Re-enters the screen for turning

the system to Off, Stay or On. Time: This allows changing the time and/or

date for a system panel.

Keypad Entry Basics

Use the buttons directly under the display screen when the arrow “È“ beside desired subjects on the screen is pointing down to the corresponding keypad buttons.

◄ and ► buttons allow you to view

The additional topics--when available. ("

◄" and/or "►" will appear on the display

screen to indicate these keys can be used).

Use the “ your present menu / topic to return to the main screen or back out of inner screens.

” escape key when finished with

Entering Letters (e.g., for a user's name)

The numeric keypad allows entering numbers-and letters as well--for items that support this.

When required, press the specific key multiple times until the desired letter appears:

Pressing "2" multiple times produces: 2 A B C on the screen.

Pressing "3" multiple times produces: 3 D E F on the screen.

...etc. (look for the letters on each key).

Tip: The "_" on the 0 key (zero) represents a space.

4 xL LCD Keypad User's Guide 21-3600E rev1.3

Alarms, Turning Protection On and Off

21-3600E rev1.3

Welcome

Alarm Status Admin Reference

Alarm Monitoring Features

Depending on how the system is set up, specific alarms may be indicated by any of the following items:

• An alarm message will appear on specific

keypad(s);

• Keypad 'sonalerts' (beepers) may sound;

• A local siren may be triggered;

UL Listed Systems: For UL listed systems, a local siren must be triggered.

• An alarm message may be transmitted to a

monitoring station (and/or to a management PC running the Director software);

UL Listed Systems: For UL listed systems, an alarm message must be transmitted.

• A programmable "output" may be triggered

(this can cause a horn to sound, or perform any other type of automated 'switching' function);

• A numeric pager may be called to let the

wearer know that a specific type of alarm has occurred.

These actions can be fully customized for each type of event--for each arming level that the system can be in at any time (Off, Stay or fully ON).

Fire Alarm

Standard and Alternative Operation: A quick on and off tone.

Burglary Alarm, Trouble Condition Standard Operation:

Steady continuous tone.

Alternative Operation:

Slow on off tones

Entry and Exit Delay

protected area is entered or protection is turned on before leaving)

(tones generated when the

Standard Operation:

Slow on off tones until the last 15 seconds of the delay when the tones speed up and become more immediate to indicate that protection should be turned off or exiting should be done to prevent a false alarm.

Alternative Operation:

Continuous tone.

Entry Delay after the System has been in Alarm or during an Alarm Condition

Standard and Alternative Operation:

Very fast on and off beeps.

Exit Delay with a Protection Point Insecure Standard and Alternative Operation:

Fast on and off beeps

Confirm Exit Delay (the exit delay is shortened

Audible Keypad Tones

• The following audible keypad tones

accompany keypad visual indications like lights and screen messages.

• There are 2 versions for some of the tones to

operate:

Standard: regular tone operation. Alternative: opposite to regular operation.

New systems will use Standard Tone Operation. Alternative tone operation must be especially programmed by a security representative.

when the exit door is exited before the end of the exit delay)

Standard and Alternative Operation:

Fast on and off beeps

Closing Time Soon

will sound a warning when the time for the protection to turn on is approaching)

(a system that has a schedule

Standard and Alternative Operation: 30 minutes before the scheduled protected area’s protection should turn on, the keypad will make 3 short beeps. In the final 15 minutes, the tones will gradually get faster.

These tones also apply to the ones emitting

Chime

from an Arming Station. See the section on

the Arming Station Reference in this manual.

Pressing Keypad Keys/Buttons

Single short beep

Error Tones for Wrong Keys Pressed

(see “Function Key Reference” in this manual)

When the chime feature is turned on and a door is opened.

Standard and alternative operation: Three short low sounding beeps.

6 short beeps

6 xL LCD Keypad User's Guide 21-3600E rev1.3

Sirens

Conventional Siren

Fire Alarm: Intermittent Tone (the same as a Fire Alarm in the previous keypad tone details).

Burglar Alarm

: Steady Tone.

Voice Siren (optional)

Fire Alarm: Steady tone, followed by

optional voice Fire Alarm Message. (e.g. “FIRE! FIRE! ... Leave Immediately!”)

Burglar Alarm: On and off tone, followed

by optional voice Burglar Alarm Message. (e.g. “Intrusion! Intrusion! ... The police have

been called, leave immediately”).

Dealing with Alarms (what to do if the keypad is beeping)

If an alarm occurs, you must first decide if it is a valid alarm (break-in, battery failure, etc.), or a false alarm. If a valid alarm occurs, be sure to notify the appropriate persons, and/or take steps to either deal with the item yourself--if appropriate, or get yourself and others to safety.

Silencing a False Alarm

An authorized user can Cancel a false alarm,

disarm the system and inform the monitoring station not to dispatch the respective emergency service.

This feature may not be available in all areas. Consult your local security representative / installer for more information.

However, fire alarms can not be cancelled.

The following steps assume that you have accidentally triggered a false alarm. If an alarm has been generated, the LCD display will show the alarm, and the keypad 'sounder' will probably also be making a steady tone.

Steps:

Enter your user ID

and/or password to log into the keypad.

2. Select Yes to

silence the alarm.

3. Select Yes again

to verify who you are.

4. Enter your PIN

when prompted. This will signal the monitoring facility that you want to cancel the false alarm.

5. To disarm area(s),

select "Off".

6. Select Yes to turn

all areas off, if desired.

7. If there was a

false alarm, the

!! In Alarm !! Enter ID: _ _ _

Silence System? ↓Yes ↓No View↓

Verify User? ↓Yes ↓No

To Verify User Enter PIN: _ _ _ _

Push ► for menus ↓Off ↓Stay

All Areas Off? ↓Yes ↓No

Area XX Had an Alarm

following screen will appear.

8. Select Ack to

acknowledge the alarm and disarm the system.

XXX: refers to the number for the monitored sensor (input point) that was in alarm.

xxx: Sensor Name Status ↓Ack

9. Press this key to

perform another function.

Disarming... ↓Next Function

To return to the main screen (log out), press

“ escape key a few times, or let the

the “ system time-out (1 minute).

The entry tones will now stop sounding and the selected areas are now fully disarmed.

If the Verify option is used, it must be done within 1 minute of the false alarm occurring, for the station to acknowledge the signal.

21-3600E rev1.3

Welcome

Alarm Status Admin Reference

Using the Emergency Keys

There are three emergency keys that will cause an emergency alarm. This will be transmitted to the monitoring station, and may also turn on a local alarm, a programmable output, and/or cause a numeric pager message to be sent (depending on how the system is set up).

To transmit an emergency alarm, press the

button on both sides of the specific symbol at

the same time.

WELCOME

Enter

- #

Alert Keys

Fire, press the “F” function key

(discussed in “Using the Function Keys”) the left arrow key ◄

Panic/Police Alarm, press the left and

right arrow keys ◄ ► at the same time.

Emergency (Non medical), press the

left arrow key ► and the “ the same time.

Alert Keys are only available if they have been ordered by you and supplied by your Security Representative.

ID:

ABC

JKL

TUV

Z_Q

at the same time.

DEF

MNOGHI

WXYPRS

“ Escape key at

and

Worklate: Extending the Scheduled Closing Time

A Schedule represents when e.g. a

commercial system is open for normal business hours. If the scheduled closing time is approaching when the protection is turned on, and you wish to remain in the area, you can extend the 'closing' time.

Steps:

Enter your user ID

and/or PIN to log into the keypad.

2. Press the

◄►arrow keys

until you see

"Schdule". Then select Schdule.

3. Select Schd to

change the Schedule for the

selected area (e.g. Office) or select Next

Area to select a different area.

4. Select WorkLate

to change the closing time for your selected area.

5. Select "+" or "-"

to adjust (Adj) the closing time as desired.

The "+" and "-" (Adj) keys adjust the closing time by increments of 30 minutes.

6. Once the

scheduled closing time is correct,

select Ok.

To return to the main screen (log out), press

“ escape key a few times, or let the

the “ system time-out (1 minute).

An authorized user may only change the WorkLate Schedule for the current day. 15 minutes before a Schedule ends, the system will chime indicating that a scheduled closing is pending. At this stage, an authorized user may change the WorkLate time to suspend the system closing until a specified time.

Welcome Enter ID: _ _ _

Menu Options

◄ Schdule ► ↓Ok

AreaName.....Off

↓Schd ↓Next Area

Close -> 09:30pMo ↓Worklate Susp↓

..until 17:30pFr ↓Ok ↓+ Adj -↓

..Until 17:30pFr ↓Ok ↓+ Adj -↓

8 xL LCD Keypad User's Guide 21-3600E rev1.3

Suspending Schedules for an Area or Areas

A schedule can be blocked altogether if you do not want a scheduled closing to occur.

Steps:

Enter your user

ID and/or PIN to log into the keypad.

2. Press the ► keys

until you see "Schedule". Then press the key under "Schedule" to select it.

3. Select Schd to

suspend the Schedule for the

selected area (e.g. Office) or select Next

Area to select a different area.

4. Select Susp to

suspend the Schedule for the selected area.

5. Select Ok to

suspend the schedule and

return to the main screen. Select Resume to

reinstate the schedule.

To return to the main screen (log out), press

“ escape key a few times, or let the

the “ system time-out (1 minute).

WARNING: A Schedule will remain suspended indefinitely until “Resume” is selected .

Welcome Enter ID: _ _ _

Menu Options

◄ Schdule ► ↓Ok

Area..........Off

↓Schd ↓Next Area

Close by 17:30pMo ↓Worklate Susp↓

Suspended ↓Ok Resume↓

Turning Protection ON, STAY, or Viewing the Present Arming-Level

With the appropriate authority, you can arm and disarm the system, or specific area(s) using an LCD keypad.

Steps:

Enter your user ID

and/or PIN to log into the keypad.

2. Select the button

for your desired protection level.

If all areas are currently OFF, only STAY and ON are shown. If STAY is not an authorized function, only ON will be shown.

The "Stay" arming-level refers to the perimeter sensors being monitored, but not the interior ones. This is typically used when someone is inside the facility or protected area.

3. Select No to

choose an Area to view or change (or

Yes for all areas ON).

4. Press the left

to set the

button

arming-level.

Select Nxt to choose a different area, or select Done to exit.

5. Select OK to

confirm. (Review

allows you to change your mind.)

6. If points are currently bypassed, in tamper,

in alarm, or not Ok, the following screen will appear when you are attempting to arm an area (to Stay or ON).

7. Select Ok? to arm

the system, or

View to list points

that are currently not Ok.

Welcome Enter ID: _ _ _

Push ► for menus ↓Stay ↓On

All Areas ON? ↓Yes ↓No

AreaName.....Off

↓On ↓Nxt Done↓

Area(s) to....ON

↓OK ↓Review

Pts in Bypass! ↓Ok? ↓View

21-3600E rev1.3

Welcome

WARNING: Selecting OK will arm the system with point(s) not secure.

Alarm Status Admin Reference

Select View to view

points that are currently bypassed or not Ok. At this time the system will indicate points that are not OK and force you to either bypass or secure these points in order to arm the system.

Select the desired topic:

• Pts: Bypassable points (sensors) in the

displayed area;

• Next: Show the

next area;

• All: All bypassable

points regardless of area.

When a point/sensor is displayed, you'll have these options:

• "◄►": Press the arrow keys to scan through

the sensors (points) in the system (or the selected area);

• Bypass: Select this

for the system to ignore (bypass) the selected sensor

• "?" jumps to the next point that is not OK.

Once all points have been bypassed or

Points not Ok! ↓View

AreaName.....Off

↓Pts ↓Next All↓

xxx:► Sensor Name Status ↓Bypass ↓?

Arming...Bypass ↓Next Function

Area(s) arming Please Leave

secured, the system will automatically arm.

After arming (On), leave immediately by the designated exit route!

The tone you will hear is a reminder for you to quickly leave the area or premises. During the last 15 seconds this intermittent tone will speed up. The exit tones will now stop sounding and the selected areas are now fully armed.

Turning Protection OFF

1. When you have entered the area with THE

protection ON, the keypad will beep and the screen will display:

2. Enter your user ID and/or PIN to log into

the keypad.

To Disarm Enter ID: _ _ _

3. This screen will display, to choose turning

the area fully off or put in Stay for

Push ► for menus ↓Off ↓Stay

partial protection.

4. After making your

selection, this

All Areas Off? ↓Yes ↓No

screen will ask if the protection for all areas should be changed, if there is more then one area. If “No” is selected, this screen will display the

Area 1.........On

↓Off ↓Nxt Done↓

current condition of the available areas e.g. “On” and selections for that area. Selections for other areas are displayed by pressing ”Nxt” or just change the protection level for the area you are in. Pressing the button below “Done” will process the selections you made.

Turning Protection On by Area Groups, a Group of Areas or Individual Areas.

Check with your Security Representative / Installer to have this feature added to your system. You must have the proper Authority to control additional protected areas.

1. Enter your user ID

and/or PIN to log into the keypad.

2. Select the button

for your desired protection level. Selecting “Stay” will supply selections for the areas separately. Selecting “On” will supply the special way to turn area protection on.

3. Select Yes if an

authorized user has been assigned with the authority level to turn on a certain group or groups of areas at the same time.

4. If authorized,

select No to

choose individual Area Groups or Areas to turn on.

Welcome Enter ID: _ _ _

Push ► for menus ↓Stay ↓On

All Areas ON? ↓Yes ↓No

Choose Area by? ↓Group ↓Area

10 xL LCD Keypad User's Guide 21-3600E rev1.3

Area Priority Protection On/Off

Priority Arming requires that areas are armed and disarmed in order of their priority. If protection for Area 1 is turned on first, then area 2 and then 3, disarming the areas would then require area 3 to be turned off first, then area 2 and then 1. This sequence can vary and it is necessary to learn the order from your Security Representative / Installer or System Administrator.

• If protection for

areas is not turned on, off in their proper sequence, this error screen will appear and the process will not occur. It will have to be repeated properly.

AREA 1 Priority Fail

Common Area Protection On/Off

A common entrance used by e.g. a user who has authority for only certain areas in a multiple area system, must be able to enter the entrance to reach their areas. At the same time, a user who only has authority for their particular areas beyond the same entrance must also be able to enter. This can make this main entrance a “common area”. Both users can have authority for this common area to reach their particular areas. This allows them to be able to turn the protection on and off to this common area when their authorized areas are in use. Check with your Security Representative / Installer Administrator for information and authority for a Common Area.

or System

Turning ON an Area’s Protection using an Access TOKEN

Check with your Security Representative / Installer to have this feature added to your system. You must have the proper Authority to control additional protected areas.

1. Place and hold

the token in front of the keypad within 2 -3 inches (78mm).

2. The exit delay

will start and the keypad will sound its exit delay beeps.

Welcome Enter ID: _ _ _

Arming... ↓Next Function

Turning OFF an Area’s Protection using an Access TOKEN

1. If you have entered the area with protection

on, the keypad will beep and the screen will display:

2. Repeat holding the token in front of the

keypad within 2 -3 inches (78mm).

3. The screen will

display:

Protection will be off.

To Disarm Enter ID: _ _ _

Disarming... ↓Next Function

21-3600E rev1.3

Welcome

Alarm Status Admin Reference

UK System Operation

The following is required to ensure conformity with the ACPO, DD243:2002 Standard.

UL Listed Systems: Not to be used for UL listed systems.

If this screen displays after disarming … the system has had a Confirmed Alarm and the following procedure must be done:

Resetting Confirmed Alarms Once a confirmed alarm occurs at a site, the

user will be able to disarm and silence the system. The confirmed alarm strobe display, if it is part of the system’s equipment, will also turn off. However, arming will be blocked until reset by an Engineer during a service call in the following manner:

1. The main panel cabinet must be opened to

activate the ‘tamper sensor’

2. The system will generate a tamper alarm; the

authorized user must first silence this.

3. Next, the Service user ID and Pin must be

entered followed by the ID and Pin of the authorized user.

(Master end user ID and PIN default: e.g. ID: 01 or 001, PIN: 7793)

4. Select “Reset Confirmed Alarm”.

5. Close the main panel cabinet to secure the

tamper sensor.

If there is an attempt made to arm the system and this reset procedure has not been done, this screen will appear momentarily…

External Arming Button When attempting to arm the system and exiting the protected area the “external arming button”

must be pressed. Failure to do so will result in a “Failed to Exit” condition. The protection will disarm at the end of the arming delay and a failed to exit report will be logged in the system’s History log.

Confirmed Alarm! Enter ID: _ _ _

!! Cannot Arm !!

Confirmed Alarm!

UK and European System Operation

UL Listed Systems: Not to be used for UL listed

systems.

Restoring Tampers Once a tamper condition occurs it will be

logged in the system’s History log. Any authorized users can silence tampers

Was in Tamper! Enter ID: _ _ _

however; the following system message will scroll on the LCD display to indicate that a tamper condition had occurred… This message will only appear when the tamper condition has been restored. The yellow “trouble” light on the keypad will also turn off.

1. This message can only be cleared during a

service call in the following manner.

2. The main panel cabinet must be opened to

activate the ‘tamper sensor’

3. The system will generate a tamper alarm; the

authorized user must first silence this.

4. Next, the Service user ID and Pin must be

entered followed by the ID and Pin of the authorized user.

(Master end user ID and PIN default: e.g. ID: 01 or 001, PIN: 7793)

This screen message will display to prompt for the master authority user to enter their ID and Pin.

After the reset procedure has been completed, the system Status can be checked to ensure that the only tamper condition still displaying is the open main panel cabinet.

5. Close the main panel cabinet to secure the

tamper sensor.

Arming / Disarming Conditions If at the time of arming, certain system faults are

present, arming will be blocked. The red armed light on the keypad will only stay

on for 30 seconds from the time of any arming. This is to prevent the condition of the system from being easily visible.

2nd Service User Enter ID: _ _ _

12 xL LCD Keypad User's Guide 21-3600E rev1.3

To view the armed state of the system, log in from the “Enter ID:” screen. If all areas are ON this screen will display:

If one or some areas are armed this screen will display:

If a trouble condition occurred since the last arming, this screen will display on disarming… When this screen is acknowledged (Ack) the problem condition can only be seen by checking system Status. If fault conditions are present, than arrangements should be made to have them corrected.

All on Menus ► ↓Off ↓Stay

Partially Armed ► ↓Off ↓Stay

System Fault or Tampered ↓Ack

Remote Reset

For customers who would rather reset the ACPO alarm themselves, instead of a service/engineer person attending and doing it.

• When the ACPO alarm occurs, the LCD

keypad screen will display a 6 digit code.

• The customer notifies the monitoring

station with this number.

• The monitoring station enters the number

in this program’s “Customer Input:” box and generates a response 6 digit number.

• The monitoring station gives this response

number to the customer who enters it into the keypad and can reset the ACPO alarm.

21-3600E rev1.3

Welcome

Alarm Status Admin Reference

14 xL LCD Keypad User's Guide 21-3600E rev1.3

Checking Status and Controlling Items

21-3600E rev1.3

Welcome Alarm

Status Admin Reference

Status and Control Features

NOTE: Status will display certain options e.g.

“Comms, Modem, Licns” that will not appear familiar because they are not covered in this publication. These options should be ignored by the end user because they are for a technician’s use only.

Using an LCD keypad, you can:

• Check the status of various items in the system

and view the present arming-level of desired area(s).

• Bypass faulty sensors to allow arming the

system and/or specific area(s);

• Command doors to Unlock, relock, or change

operating characteristics;

• Use the function keys to perform pre-

programmed signalling and/or switching functions.

Using the Function Keys

LCD keypads provide 10 function keys that can perform various signalling and/or switching

functions. Consult with your security

representative / installer to learn what the ones you may have ordered do.

To use function key 1, 2, 3, 4, or 5, simply press and hold the “F” key, and press the desired number at the same time.

- #

For function keys 6, 7, 8, 9, and 0, a user with function-key authority may need to enter their ID/PIN numbers to be allowed to use these function keys.

This requirement can be assigned as necessary to any areas. Check with your security representative.

ABC

JKL

TUV

Z_Q

DEF

MNOGHI

WXYPRS

To log in, open the keypad cover, and key in your user ID number and/or PIN number as indicated

Welcome Enter ID: _ _ _

Your Name Appears

Enter PIN:

_ _ _ _

on the display.

Then press and hold the “F” key, and press the desired number at the same time.

Checking the System Status

(monitored conditions for a system control unit)

The system status feature shows the status of all conditions such as (tamper, low battery, etc.) that are being monitored for the control unit associated with your keypad.

These items may also be referred to as "Equipment" conditions.

Steps:

1. Enter your user ID

and/or PIN to log into the keypad.

2. Select ► to

access other functions.

3. Use the ◄ and ►

arrow buttons to scan through the listed items. When ”Status" appears, press Ok.

4. Use the ◄ and ►

arrow buttons to scan through the

listed items and press Ok.

To return to the main screen (log out), press the

“ escape key a few times, or let the system

“ time-out (1 minute).

For details on the possible status messages, refer to "Error Messages and Trouble Indications" in the reference section near the back of this guide.

Welcome Enter ID: _ _ _

Push ► for menus ↓Stay ↓On

Menu Options

◄ Status ► ↓Ok

Status Options

◄ System ► ↓Ok

16 xL LCD Keypad User's Guide 21-3600E rev1.3

Checking the Status of Sensors (Points) and Areas

The Points-status feature allows checking the status of sensors in the system (and viewing the arming-level for areas).

Steps:

1. Enter your user

ID and/or PIN to log into the keypad.

2. Select ► to

access other functions.

3. Use the ◄ ►

arrow buttons to scroll the items

4. Select Points

press Ok.

5. Select the desired

topic:

• Pts: Protection

Points (sensors) in the displayed area;

• Next: Show the next area;

• All: All points regardless of area.

When a point/sensor is displayed, you'll have these options:

• "►": Press the right arrow key to scan through

the sensors (points) in the system (or the selected area);

• Bypass / Delbyp: Select Bypass to have the

system ignore the sensor

a "Bypass" that is in effect). Also see

• "?" jumps to the next point that is not OK.

Bypass appears only for points that are bypassable. An Entrance Door must be specially programmed to be bypassable. Ask your Security

Representative. An area’s sensor cannot be bypassed if the area is ON.

If all points are OK, you will see an "All Secure" message.

To return to the main screen (log out), press the ““ escape key a few times, or let the system time-out (1 minute).

: Bypassing a faulty sensor, to follow.

Welcome Enter ID: _ _ _

Push ► for menus ↓Stay ↓On

Menu Options

◄ Status ► ↓Ok

Status Options

◄ Points ► ↓Ok

AreaName.....Off

↓Pts ↓Next All↓

xxx: Sensor Name Status ↓Bypass ↓?

(or "Delbyp" to remove

All points in area are secure

Bypassing or Isolating a Faulty Sensor

If the system (or a specific area) needs to be armed with a faulty or insecure sensor, you will need to bypass the problem sensor.

Steps:

1. Enter your user ID

and/or PIN to log into the keypad.

2. Scroll the ◄ ►

left and right

arrow keys until

“Bypass” appears on the display. Press Ok

An area’s sensor cannot be bypassed if the area is ON. You can also bypass sensors through the Pointsstatus screens (see the preceding topic for details).

3. Select the desired

topic:

• Pts: Bypassable

points (sensors) in the displayed area;

• Next: Show the next area;

• All: All bypassable points in all areas.

4. When a

point/sensor is displayed, you'll have these options:

• "►": Press this key to scan through the sensors

(points) in the system (or the selected area);

• Bypass / Delbyp: Select Bypass to have the

system ignore the sensor

a "Bypass" that is in effect).

• "?" jumps to the next point that is not OK.

5. If all bypassable

points are secure, you will see a related message.

A bypass is lifted the next time the area is turned off, provided the user has the proper authority.

Isolate a Sensor

With “Isolate” authority, a sensor can be permanently bypassed until the bypass is manually lifted.

Welcome Enter ID: _ _ _

Menu Options

◄ Bypass ► ↓Ok

AreaName.....Off

↓Pts ↓Next All↓

xxx: Sensor Name Status ↓Bypass ↓?

(or "Delbyp" to remove

No bypassable points insecure

21-3600E rev1.3

Welcome Alarm

Status Admin Reference

1. Select Bypass.

2. Select an area

and “Pts” to view Points in that area.

3. Select “Cmd”,

(Command). Pressing the button under the question mark will indicate bypassable points in the area that are insecure.

4. Use the arrow

keys to do a regular Bypass or Isolate the point. Follow the same procedure to delete “Isolate” for a point.

WARNING: The keypad will indicate there is a

point in Bypass or “Isolate” every time protection is turned on. A point in “Isolate” will never supply protection and the “Isolate” will not be removed the next time the area is turned off. A point in “Isolate” must have its Isolate deleted in order for it to supply protection again.

To return to the main screen (log out), press the ““ escape key a few times, or let the system time-out (1 minute).

Menu Options

◄ Bypass ► ↓Ok

Office........Off

↓Pts

002►LOBBY MOTION Ok ↓Cmd ?↓

002►LOBBY MOTION ↓Isolate

◄►

Checking Status or Controlling Readers or Doors

The Door status screens allow persons with the appropriate authority to:

• Check the status of doors in the system (or

specific areas);

• Command doors to unlock, relock, or change

operating characteristics.

Steps:

1. Enter your user ID

and/or PIN to log into the keypad.

2. Select ► to

access other functions.

Welcome Enter ID: _ _ _

Push ► for menus ↓Stay ↓On

3. Use the ◄ ► left

and right arrow buttons to scroll the items

4. Select Doors and

press Ok.

5. Select the desired

topic:

• Door: For doors in

the displayed area;

• Next: Show the next area;

• All: All doors regardless of area.

6. Now select Door,

or Readers, as

desired:

• "►": Press this key to scan through the doors

in the system (or the selected area);

• Door: Door status, or commands to unlock or

relock the door, or lockout (or reinstate) all cards;

• Readers: Will indicate the current reader

conditions in the system and lets you change the condition (e.g., Card+PIN, dual custody, etc.).

7. If you selected

Door, the door

state will be shown, and you'll have these options:

• "►": Press this key to scan through the doors

in the system (or the selected area);

• Select the door state: Then, you can use the

◄ ► left and right arrow buttons to access a command

to select it)

• "?" jumps to the next door that is not OK.

(and press the key under the command

;

8. If you selected

Readers, the

reader mode will be shown, and you'll have these options:

• "►": Press this key to view the second reader

for the selected door (if applicable);

• Cmd: Provides access to the reader mode

Menu Options

◄ Status ► ↓Ok

Status Options

◄ Doors ► ↓Ok

AreaName.....Off

↓Door ↓Next All↓

D0x: Door Name ↓Door ↓Readers

D0x: Door Name

↓DoorState ?↓

D0x: Area Name ↓Cmd RdrModes

18 xL LCD Keypad User's Guide 21-3600E rev1.3

selections that follow.

9. Your Cmd

choices are shown below:

• Mode: Access modes including "Normal

"Dual Custody needed to enter), and "Escort identified as a "Escort" must present their card first, then a 2nd person with a valid card);

• Card: This includes various card-mode

selections (i.e., card and/or UID and PIN);

• Lock: This allows you to lockout or reinstate

card-access at this reader.

To return to the main screen (log out), press the ““ escape key a few times, or let the system time-out (1 minute).

R0x: Area Name

↓Mode ↓Card ↓Lock

" (two users/access cards

" (a user

Checking the Status or Controlling an Elevator Reader

UL Listed Systems: Not evaluated to UL104 –

Elevator Door Locking Devices and Contacts.

For systems that include elevators, the "Status" menus will include an "Elev" selection for elevators and their associated readers. The available selections will be the same as for standard readers preceding section.

Attention: All floor status and control

functions are available only through the

Director software. It is recommended that all

elevator reader status and control tasks be performed through the software as well.

Exception: Checking a specific aspect of an elevator reader can be performed through the keypad (such as checking if it is in Card Plus PIN mode), but you will have to log in at a Director software PC to see if the floors are secure.

, as described in the

Checking the Status of an Application Module (POD)

You can check the status of any "application" modules in the system. (An application module provides increased functionality such as Printer capability.)

POD (definition): "Module" - a controller that e.g. connects a Printer to the system.

Steps:

1. Enter your user ID

and/or PIN to log into the keypad.

2. Select ► to

access other functions.

3. Use the ◄ ► left

and right arrow buttons to scroll the items.

4. Select App to

view status of an

Application

Module. Press Ok.

5. Select Yes to

view the status of the indicated

module (e.g. “HSC” for Printer), or use the ►

right arrow button to select another module.

6. Select HSC and

then Printer to

view the status of the Printer.

7. The status screen

will indicate if the system device is Ok or disabled and any device related information.

Select Next to view status of the next module.

Welcome Enter ID: _ _ _

Push ► for menus ↓Stay ↓On

Menu Options

◄ Status ► ↓Ok

Status Options

◄ App ► ↓Ok

ModuleName/Type ► ↓Yes ↓No

Pod Status . . . .

↓Printer

PRN(printer):OK POD:OK

To return to the main screen (log out), press the ““ escape key a few times, or let the system time-out (1 minute).

21-3600E rev1.3

Welcome Alarm

Status Admin Reference

20 xL LCD Keypad User's Guide 21-3600E rev1.3

Administration and Maintenance Tasks

21-3600E rev1.3

Welcome Alarm Status

Admin Reference

Changing Your Own PIN

The person who is logged in can change their PIN number at any time.

Steps:

1. Enter your user

ID and/or PIN to log into the keypad.

2. Press ► to scroll

to the PIN option.

3. Select My PIN to

change your PIN. Press Ok

4. Enter your new 4-

digit or 5-digit PIN.

TIP: You can use the letters on the keypad to 'spell' a word as a reminder of your PIN.

Re-enter the new PIN a second time when prompted for this (this helps to protect against typing errors).

Note: The last two digits of the PIN can not be identical. Do not use consecutive numbers such as

1234. For security reasons, duplicate PINs are not allowed on systems with a PIN only user code. If the message “PIN not allowed” appears, select a different PIN.

The “PIN changed” screen displays and then returns to the system standby screen.

Welcome Enter ID: _ _ _

Push ► for menus ↓Stay ↓On

Menu Options

◄ My Pin ► ↓Ok

New PIN _ _ _ _

For User: UID#

PIN Changed

Adding a User to the System

New users can be added to the system as needed.

A User is a person who can use system keypads, and/or gain entry at access-controlled doors.

Steps:

1. Log into the

keypad by entering your user ID and/or PIN as indicated on-screen.

2. Press ► until

"Users" appears, & press Ok.

3. Enter an available

user number (and

select Ok), or select Ok, and then press ► until a user

number appears with "Add and Delete).

4. Undfnd

(Undefined)

Select Add.

?: In this screen, "?" refers to systems with Suite Security keypads (allows viewing the user’s Suite related abilities for the selected user number). Note: Suite Security assignments for a user are set up through the Director software.

Refer to the details that follow while working with any of the listed topics:

Aut: Use the Next and Prev(ious)

buttons to select an

authority profile for the user. (Select Ok when

finished).

This determines what doors the user can enter (and at what time of day), and the tasks they will be able to perform at system keypads. This selection cannot be Undfnd (Undefined).

Consult your Security Representative / Installer to make changes to the authority levels.

Welcome Enter ID: _ _ _

Menu Options

◄ Users ► ↓Ok

0xx ↓OK Select User

" (instead of Edit

0xx ► Undfnd ↓Add

0xx AuthProfile ↓Ok ↓Next ↓Prev

22 xL LCD Keypad User's Guide 21-3600E rev1.3

Default Authority Settings

Intrusion

Emergency Off

Isolate

Bypass

Auto-lift Bypass

Test

Service Test

Silence Alarm

Status

History

Function Key Authorization

Work Late

Suspend Schedule

Off

Stay

Auto Disarm to Off

Auto Disarm all Areas

Access

Access when Area is Off/On/Stay

Escort

Master Override

Reset Door Alarm

Door Command

Class A

Class B

Class C

Master

9 9 9 9 9 9 9 9 9 9 9 9 9 9

Supervisor

Employee

Worker

9 9 9 9 9 9 9 9 9 9 9 9 9 9 9

9 9 9 9 9

9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9

Cleaner

21-3600E rev1.3

Welcome Alarm Status

Admin Reference

System / Suite (Condo): For

systems with

Suite Security keypads, this screen

0xx UserName ↓System ↓Condo

0xx AuthProfile ↓Ok ↓Next ↓Prev

allows accessing the

System authority screen (same as the previous Aut “Authority”) or, the Suite

Security (Condo) authority screen.

Tip: Press the ““ escape key if you do not want to

use this screen.

Use the Next and Prev buttons to select a

Suite Security authority profile for the user.

(Select Ok when finished).

Suite Authority of "Undfnd": This is a reserved suite user (that can be edited by a user with Suite "Master" authority).

Suite Security Authority assignments for a user are set up through the Director software.

: Provides access to additional screens.

Name

: Use the

keypad to enter the

. . . .

↓OK

user's name, and

select Ok when finished.

Tip: Check the letters on the numeric keypad. Then, for each letter of the name, press the specific key until the letter appears (e.g., pressing 2 makes a 2, A, B, C; 0 provides 0, Z, _ <space>, Q, etc).

To move to the next letter-position, use the ► right arrow button, or wait 2 seconds. To retype a previous letter, use the ◄ ► left or right arrow keys, and then enter the letter as before.

Card

: Enter the card

version number (if

0xx UserName ↓OK vv_nnnnnnnnn

applicable), and the access-card/token number for this user, and

select Ok when finished.

If card-access (entry at controlled doors) does not apply, leave the card number as "000000000".

Card Version number support is supplied by your Security Representative.

Firmware revisions needed for 9-digit card IDs, or cards with version numbers: Panel firmware ≥ V3.2, and door/elevator controller firmware ≥ V1.5.

: This allows

setting or changing

the P

ersonal ID

umber for this user. (You'll be asked to enter

New PIN - - - -

For User 0xx

it twice--to help protect against typing errors.)

The last two digits of the PIN must be different. Also, do not use consecutive numbers like 1234.

Lang / Chal: This

screen allows setting

0xx..Lng:Eng.C:N ↓OK ↓Lang ↓Chal

the LCD language for this user, and whether or not the "physicallychallenged" unlock times and door-held-open times apply to this user.

Select Lang to 'toggle' the language, or Chal

to 'toggle' the "Challenged" setting. When

finished, select Ok.

Watch the screen for the settings to change. (You will remain in this same screen.)

Lng:Eng means Language is English C:N means Challanged? – No.

To return to the main screen (log out), press the

“ escape key a few times, or let the system

“ time-out (1 minute).

Viewing or Changing Settings for a User

For an existing user, you can view or edit their settings as desired.

A User is a person who can use system keypads, and/or gain entry at access-controlled doors.

Steps:

1. Log into the

keypad by entering your user ID and/or PIN as indicated on-screen.

2. Press ► until

"Users" appears, & press Ok.

3. Enter the specific

user number

(and select Ok),

select Ok first, and then press ► until the

desired user appears on-screen.

Welcome Enter ID: _ _ _

Menu Options

◄ Users ► ↓Ok

0xx Select User ↓OK

24 xL LCD Keypad User's Guide 21-3600E rev1.3

4. Select Edit.

↓?: refers to systems with Suite Security (Condo) keypads (allows viewing the suite user assignments for your selected user number). Note: Suite user assignments can only be set up through the Director software.

0xx ► UserName ↓Edit ↓Delete ↓?

Refer to the details that follow while working with any of the listed topics:

More: Provides access to additional screens. Card

: Enter the card

version number (if

0xx UserName ↓OK vv_nnnnnnnnn

applicable), and the access-card/token number for this user, and

select Ok when finished.

If card-access (entry at controlled doors) does not apply, leave the card number as "000000000".

Card Version number support is supplied by your Security Representative.

Firmware revisions needed for 9-digit card IDs, or cards with version numbers: Panel firmware ≥ V3.2, and door/elevator controller firmware ≥ V1.5.

: This allows

setting or changing

the P

ersonal ID

umber for this user. (You'll be asked to enter

New PIN For User 0xx

- -

it twice--to help protect against typing errors.)

The last two digits of the PIN must be different. Also, do not use consecutive numbers like “1234”.

Name: Use the

keypad to enter the user's name, and

UserName . . . .

↓OK

select Ok when finished.

Tip: Check the letters on the numeric keypad.

Then, for each letter of the name, press the specific key until the letter appears (e.g., pressing 2 makes a 2, A, B, C; 0 provides 0, Z, _ <space>, Q, etc).

To move to the next letter-position, use the ► key, or wait 2 seconds. To retype a previous letter, use the

◄ ► keys, and then enter the letter as before.

Aut

: Use the Next

and Prev buttons to

0xx AuthProfile ↓Ok ↓Next ↓Prev

select an authority

profile for the user. (Select Ok when finished).

This determines what doors the user can enter (and at what time of day), and the tasks they will be able to perform at system keypads.

Setting this as Undfnd will delete the user!

User authority profiles themselves are normally set up by your service technician (service PIN needed).

System / Condo

Security): For

systems with suite security keypads, this

(Suite

0xx UserName ↓System ↓Condo

0xx AuthProfile ↓Ok ↓Next ↓Prev

screen allows

accessing the System authority screen (same as Aut, above), and the Condo (Suite

Security) authority screen.

Tip: Press ““ escape key if you do not want to use this screen.

Use the Next and Prev buttons to select an authority profile for the user. (Select Ok when

completed).

Condo (Suite Security) Authority of "Undfnd": This is a reserved suite user (that can be edited by a user with suite "Master" authority).

Suite Security Authority assignments for a user are set up through the Director software.

Lang / Chal: This

screen allows setting

0xx..Lng:Eng.C:N ↓OK ↓Lang ↓Chal

the LCD language for this user, and whether or not the "physicallychallenged" unlock times and door-held-open times apply to this user.

Select Lang to 'toggle' the language, or Chal

to 'toggle' the "Challenged" setting. When

finished, select Ok.

Watch the screen for the settings to change. (You will remain in this same screen.)

To return to the main screen (log out), press the

“ escape key a few times, or let the system

“ time-out (1 minute).

21-3600E rev1.3

Welcome Alarm Status

Admin Reference

Deleting a User

Users can be deleted from the system when necessary.

To allow tracking card-usage, you can alternatively leave the user in the system, but set them to an authority profile that provides no access to doors or keypads. (See the preceding topic for more info.)

Note: Setting the authority to "undefined" will delete the user (equivalent to selecting Delete).

Steps:

1. Log into the

keypad by entering your user ID and/or PIN as indicated on-screen.

2. Use the ◄ ► left

and right arrow buttons to scroll

the items until "Users" appears and press

Ok.

3. Enter the specific

user number (and

select Ok), or select Ok first, and then press ► until the

desired user appears on-screen.

4. With the desired

user on-screen,

select Delete.

5. Then, select Yes

to delete the user,

or Cancel to stop

the action.

To return to the main screen (log out), press the “

“ escape key a few times, or let the system

time-out (1 minute).

Welcome Enter ID: _ _ _

Menu Options

◄ Users ► ↓Ok

0xx Select User ↓OK

0xx ► UserName ↓Edit ↓Delete ↓?

Del? ↓Yes ↓Cancel

Setting the Date and Time

The panel date and time can be set through an LCD keypad if necessary.

"Service Test" authority is required to set the date and/or time.

For a reference of the dates to automatically switch between standard time and daylight-savings time, refer to "Holidays and Time-Change Dates" (in the

Reference section).

Steps:

1. Enter your user

ID and/or PIN to log into the keypad.

2. Use the ◄ ► left

and right arrow buttons to scroll

the items until "Time" appears and press Ok.

3. Enter the current

Date and Time.

4. Watch the flashing cursor as you enter the

year, month, day, hours, and minutes (2 digits each).

When finished, select Ok.

NOTE: Enter the hours as 00-23 (24-hr. clock).

Example: Noon = 12:00, 1PM = 13:00, 2 PM = 14:00 to 11PM = 23:00, Midnight = 00:00, 1 AM = 01:00, 2 AM = 02:00 etc.

You can use the (◄ ►) keys to scroll back or forward within the date or time as needed.

To return to the main screen (log out), press

“ escape key a few times, or let the

the “ system time-out (1 minute).

Welcome Enter ID: _ _ _

Menu Options

◄ Time ► ↓Ok

Date YY-MM-DD Time HH:MM ↓Ok

26 xL LCD Keypad User's Guide 21-3600E rev1.3

Manually calling the Director PC from the LCD Keypad:

• This operation is for systems that can

communicate with the Director software.

• If the system configurations have been

changed example: by the customer to add a new user, it will be necessary to update the Director configurations for the system.

1. Enter your user ID and/or PIN to log into the

keypad.

2. Push the arrow keys for Menu Selections.

3. Use the ◄ ► left

and right arrow buttons to scroll

the items until Director appears and press

Ok.

4. “Director

Options”, “Update Config” will display. Press Ok.

5. “Updating Config,

Please Wait” will

appear and then change to “Connecting”

Menu Options

◄ Director ► ↓Ok

Director Options

◄ Update Cfg ► ↓Ok

Updating Config

Please wait......

Updating Config

Connecting......

6. When the system

is communicating with the Director software, “In Progress” will appear with a rotating bar next to it.

Download Config

In Progress.... –

7. An asterisk: “” will appear between the

hour and the minute display on the time and date main screen until the communication is complete.

Viewing the History

All activity that occurs in the system can be viewed one event at a time. This includes area (alarms) /door activity, as well as the tasks that users have performed at a keypad.

Depending on your system type and licensing permissions, up to 65 536 events will be recorded.

Viewing an area's history requires authority for that area.

Steps:

1. Enter your user ID

and/or PIN to log into the keypad.

2. Use the ◄ ► left

and right arrow buttons to scroll

the items until History appears and press

Ok.

3. Select All for a

complete list, or

Category for

history referring to an Area

Security) keypad, or Application module

(e.g., Printer). Press Ok.

4. If you selected

Category your desired topic

(such as by Area). (Condo: Suite Security)

If you selected "All" the area or other item associated with each event will be shown on the screen.

, select

Welcome Enter ID: _ _ _

Menu Options

◄ History ► ↓Ok

View History of:

◄ All ► ↓Ok

, Condo (Suite

View History of: ↓Area ↓Condo ↓App

5. If you selected by

, the arming-

Area level for the first area will be shown, and you can select:

• Hist: Shows the log of events for the

displayed area;

• Next Area: Jumps to the next area.

6. To cycle through

the History press

the (◄►) right or left arrow keys. For more details about this event select ". . .↓ ".

AreaName.....Off

↓Hist ↓Next Area

xxx ► 1:23pMar

Event Displays ...↓

Press any of these keys to continue viewing the History.

"T / L" next to the time indicates that the date/time had not been set when the event occurred.

To return to the main screen (log out), press the “

“ escape key a few times, or let the

system time-out (1 minute).

21-3600E rev1.3

Welcome Alarm Status

Admin Reference

Printing the History Log

If your system includes a printer-capable module, you can print the history log. (This will be sorted by date).

Steps:

1. Ensure the printer is turned on, and has

paper loaded.

2. Enter your user

ID and/or PIN to log into the keypad.

3. Use the ◄ ► left

and right arrow buttons to scroll

the items until History appears and press

Ok.

4. When Category

appears, press Ok.

5. Select App

(Application Module) to access the module with printer functions.

6. Select SMA or

HSC which are

other related equipment selections for use by a technician only. However, they will both permit access to the Printer selection.

7. Select Printer to

access the printer menu.

Choose from the following selections:

• Start: Enables the

printer (if required).

• Pause / Resume: Pauses or resumes a printout;

• Cnc: Cancels a printout. Tip: You may also need

to turn the printer off to clear its memory.

• Plog: Prints the entire history log.

To return to the main screen (log out), press

“ escape key a few times, or let the

the “

system time-out (1 minute).

Welcome Enter ID: _ _ _

Menu Options

◄ History ► ↓Ok

View History of:

◄ Category ► ↓Ok

View History of: ↓Area ↓Condo ↓App

Menu Option ↓SMA ↓HSC

Select Option... ↓Printer ↓Lang

Printer On-Line ↓Pause ↓Cnc ↓Plog

Changing the Printed History Language

You can change the language for the printed history log when needed.

Check with you Security Representative / Installer to confirm your system version is capable of this feature.

Steps:

Follow steps 1 to 6 from the previous “Printing

the History Log”

7. At step 7, select

Lang to change

the printing language for this application module.

The present printed language will be indicated on the first line next to "Lang:”.

8. Select Change to

change the language. Press

Ok when completed.

To return to the main screen (log out), press

“ escape key a few times, or let the

the “

system time-out (1 minute).

Select Option... ↓Printer ↓Lang

Lang: Language ↓Ok ↓Change

28 xL LCD Keypad User's Guide 21-3600E rev1.3

Testing Monitored Sensors (Performing a Walk Test)

A Walk Test allows you to test specific

sensors (protection points) in the system, to ensure that they are functioning properly.

A walk test can be done by users with "System Test" authority. A walk test must be completed within 15 minutes.

Emergency points (i.e. smoke, fire alarm, panic, etc.) on a Monitored system, display as Armed and should not be tested during a Walk Test. The monitoring station must be notified if these points will be tested.

UL Listed Systems: Fire sensors must be tested once per week for UL listed systems.

When tested successfully, Emergency points will indicate PASS and Armed will change to Alarm.

"Pass" indicates that an intrusion point is functioning correctly (i.e. the sensor is operating properly), while "Fail" indicates that a problem may exist with that point or that the point was not tripped.

All points except Emergency points may be bypassed during the Review for convenience. Restore any bypassed points before turning protection on or they will reduces system security.

Steps:

1. Enter your user ID

and/or PIN to log into the keypad.

2. Use the ◄ ► left

and right arrow buttons to scroll

the items until Test appears and press Ok.

3. When Area

appears, press Ok.

Welcome Enter ID: _ _ _

Menu Options

◄ Test ► ↓Ok

Test? ↓Area ↓System

NOTE: If any fire sensors or 24 hour type inputs

must be tested and it is a reporting system, the monitoring station must be notified.

The walk test must be completed within 15 minutes.

7. After activating

points in the tested

Area in walk test ↓Review ↓End

area, return to the

keypad and select Review to view the results

of the Walk Test.

8. The tested points

and the results

xxx ► ItemName Status ...↓

(Pass/Fail) will be displayed.

9. Press the ". . .↓ " key to view all points that

passed during the test. Another method is to use the ◄ ► left and right arrow buttons to scroll through the results of all points tested in the area.

To return to the main screen (log out), press the “

“ escape key a few times, or let the system

time-out (1 minute).

4. Choose from the following selections:

• Test: To test the

displayed area;

• Next Area: To

jump to the next area.

5. Select Walk to

perform a Walk Test of this area.

AreaName.....Off

↓Test ↓Next Area

Select test type ↓Walk ↓Holdup

6. At this time you can proceed to test the

protection points in the selected area (i.e. open doors, walk in front of motion detectors, etc.).

21-3600E rev1.3

Welcome Alarm Status

Admin Reference

Testing Panic Buttons (Performing a Hold-up Test)

UL Listed Systems: Not evaluated to UL636 –

Holdup Alarm Units and Systems.

A Hold-up Test allows you to test "hold-up /

panic” devices in the system, to ensure they are functioning correctly.

NOTE: Using the Hold-up test selection will

prevent hold-up signals from being transmitted to the monitoring station.

A hold-up test can be done by users with "System Test" authority.

Steps:

1. Enter your user ID

and/or PIN to log into the keypad.

2. Use the ◄ ► left

and right arrow buttons to scroll

the items until Test appears and press Ok.

3. Select Area.

4. Choose from the

following selections:

• Test: To test the displayed area;

• Next Area: To jump to the next area.

5. Select Hold-up to

perform a 'hold-up' test of this area.

At this time you can proceed to Test the Holdup devices in the selected area. Like press in panic buttons, etc.

NOTE: Using the Hold-up test selection will

prevent hold-up signals from being transmitted to the monitoring station.

When activating hold-up devices in the tested area, the system will emit a chime when the hold-up points are activated, if functioning correctly. If no chime is emitted when testing the points, you may need to inquire about it with your Security Representative.

6. Select End when

finished viewing and/or to select another area to test.

Welcome Enter ID: _ _ _

Menu Options

◄ Test ► ↓Ok

Test? ↓Area ↓System

AreaName.....Off

↓Test ↓Next Area

Select test type ↓Walk ↓Holdup

Trip holdup pts! ↓End

To return to the main screen (log out), press

“ escape key a few times, or let the

the “ system time-out (1 minute).

Testing Sirens (System Test)

Test Your System Once a Week

Weekly testing of the system’s siren/bell is

required. A System Test allows you to test

the entire system to ensure security components are functioning properly. This test will turn on the keypad’s lights, sounder and the system’s siren for 5 seconds to make sure their all okay.

Should any part of the system appear not to be working correctly, notify your Security Representative / Installer immediately for assistance.

UL Listed Systems: This test must be performed once per week for UL listed systems.

Steps:

1. Enter your user

ID and/or PIN to log into the keypad.

2. Use the ◄ ► left

and right arrow buttons to scroll

the items until Test appears and press Ok.

3. Select System.

All Sirens will sound for 5 seconds and all keypad lights will turn on to indicate that the system is functioning correctly.

4. During the system

test, this message will appear.

Please ignore this ChxSum message. It is for technical personnel use.

To return to the main screen (log out), press the “ system time-out (1 minute).

Welcome Enter ID: _ _ _

Menu Options

◄ Test ► ↓Ok

Test? ↓Area ↓System

System Testing ChxSum [xxxxx]

“ escape key a few times, or let the

30 xL LCD Keypad User's Guide 21-3600E rev1.3

Reference Topics

21-3600E rev1.3

Welcome Alarm Status Admin

Reference

System Information

Your alarm system has specific information. This information should be recorded below at the time of your system’s installation.

Contact Information

Security Representative:

___________________________________

Monitoring Station Phone Number:

Protected Area Names:

Area 1: _____________________________

Area 2: _____________________________

Area 3: _____________________________

Area 4: _____________________________

Area 5: _____________________________

___________________________________

Your System Number:

___________________________________

When to Contact the Monitoring Station

• When an accidental alarm happens.

• When major work is being done on the

premises that could interfere with the alarm.

• If you loose your system number and

password.

• When doing a periodic test that may involve

testing panic buttons, some sensors or with all the protection turned on.

When to Contact your Security Representative

• If there appears to be a fault with the system.

• To order additional protection equipment for

installation. Like, a contact for a new door, smoke sensors, motion detector for a new room addition etc.

Area 6: _____________________________

Area 7: _____________________________

Area 8: _____________________________

Area 9: _____________________________

Area 10: _____________________________

Area 11: _____________________________

Area 12: _____________________________

Area 13: _____________________________

Area 14: _____________________________

Area 15: _____________________________

Area 16: _____________________________

32 xL LCD Keypad User's Guide 21-3600E rev1.3

System Details:

Entry and Exit Delays:

Entry Delay:_______ Exit Delay:_______

Miscellaneous Features:

Yes No

Duress PIN entry supported

Entry Delay in Stay

Arm to Stay if Failure to Exit

Terminate Exit Delay

Alarm if Failure to Exit

 

Emergency Keys that are Available:

Yes No

Fire

Police

Emergency (non medical)

 

Function Key Reference

The Function key ( F ) is pressed and held in

while pressing specific number keys for customized functions.

Note: Function keys are not active until they have been added to the system by your Security Representative.

Function keys 1 – 5 can be used by anyone. Function keys 6, 7, 8, 9 and 0 may require a user (with function key authority) to enter their user numbers before they can operate the function keys.

Function Key Assignments:

F + 1 = _________________________ F + 2 = _________________________ F + 3 = _________________________ F + 4 = _________________________ F + 5 = _________________________

(also turns "chime" on and off)

F + 6 = _________________________ F + 7 = _________________________ F + 8 = _________________________

21-3600E rev1.3

F + 9 = _________________________ F + 0 = _________________________

Door Chime Feature:

The "Door Chime" feature refers to LCD keypads emitting tones when a perimeter door is opened to alert the person(s) inside that someone has entered. This feature can be used when the system is turned off or while it is in perimeter protection (doors only) referred to as "Stay". The system has to be programmed for “Allow User Entry at the Front Door in Stay“ by the installer.

Pressing keypad keys F and 5 simultaneously

always toggles the "Chime" feature on and off. This function key sequence can also be programmed for an additional function that can turn on or off, when the chime is turned on or off.

Welcome Alarm Status Admin

Reference

Residential Fire Safety / Evacuation Plan

No fire detection system should be considered 100 percent foolproof.

This fire alarm system can provide early warning of a developing fire. Such a system, however, does not ensure protection against property damage, or loss of life resulting from a fire. Any fire alarm system can fail to warn for a number of reasons such as: smoke not reaching a detector that is behind a closed door.

When considering smoke alarms for residential applications, refer to NFPA standard 72, "The National Fire Alarm Code", or the equivalent for your area.

The NFPA version is available at a nominal fee, from: The National Fire Protection Association, 1 Batterymarch Park, P.O. Box 9101, Quincy, MA 02269-9101.

Residential Installations

Adherence to the NFPA Standard 72 can lead to reasonable fire safety when the following items are practiced:

• Minimize Hazards: Avoid the three traditional

fire killers--smoking in bed, leaving children home alone, and cleaning with flammable liquids.

• Provide a Fire Warning System: Most fire

deaths occur in the home. The majority, during sleeping hours. The minimum level of protection requires working smoke detectors outside each separate sleeping area, and on

each additional floor of the dwelling.

Notice: Never try to fight a large fire on your own, and never use water when dealing with a kitchen (grease) fire. (For a small grease fire, use baking soda, or a fire extinguisher that is approved for this.)

34 xL LCD Keypad User's Guide 21-3600E rev1.3

Practicing Fire Safety

Fire can grow and spread through your home very quickly. In a typical home fire, you may have as little as two minutes to escape from the time the smoke alarm sounds. Knowing how to use those minutes wisely can make a life-saving difference. That´s why home fire escape planning is so important. Developing and practicing a home fire escape plan will help you snap into action immediately if the smoke alarm sounds, so you can get out quickly and safely.

Escape Plan Guidelines:

• Make sure to have at least one smoke alarm

on each level of the home and in or near each sleeping area. Test the alarms every month by pushing the test button, and replace the batteries once a year or when the alarm chirps, warning that the battery is low. (Note: Newer smoke alarms have a signal repetition pattern of three beeps, followed by a one and a half second pause.) The majority of today’s smoke sensors are interconnected with alarm control units (such as this one) and get their power from them.

• When entering other buildings, including other

people's homes, ask what type of emergency alarm system is in place. If it sounds, act immediately.

• Draw a floor plan

doors and windows, and the location of each smoke alarm. If windows or doors have security bars, equip them with quick-release devices.

• Locate two escape routes from each room. The

first way out would be the door and the second way out could be a window.

• As you exit your home, close all doors behind

you to slow the spread of fire and smoke.

• If your exit is blocked by smoke or fire, use

your second exit to escape. If you must escape through smoke, stay low and crawl under the smoke to safety. Smoke will rise to the ceiling, leaving cooler, cleaner air close to the floor. Crawl on your hands and knees, not belly, because heavier poisons will settle in a

of your home, marking all

thin layer on the floor.

• If you live in a high-rise building, use the stairs

— never the elevator — in case of fire.

• Choose a meeting place a safe distance from

your home and mark it on the escape plan. A good meeting place would be a tree, telephone pole, or a neighbour’s home. In case of fire, everyone should gather at the meeting place.

• Make sure the street number/address of your

home is visible to firefighters.

• Memorize the emergency number of the local

fire department. Once outside, call that number immediately from a nearby or neighbour’s phone, or use a portable or cellular phone you can grab quickly on the way out.

• Practice your escape drill at least twice a year.

• NEVER go back inside a burning building!

Apartment buildings, dormitories, and high-rises

If you live in an apartment building or dormitory (up to four stories), make sure it's protected by building-wide fire detection and alarm systems, and check with your apartment manager to ensure that those systems are regularly tested and working properly.

If you live in a high-rise, count the number of doors between your apartment and the two nearest exits. If you discover fire, sound the fire alarm and call the fire department. Leave the area quickly, taking your key and closing all doors behind you. If the building has a voice enunciation system, follow its instructions precisely, unless doing so puts you in immediate danger. If fire or smoke blocks your exits, stay in your apartment and cover all cracks and vents (using wet towels, duct tape, linens, clothing, and so forth) where smoke could enter. Telephone the fire department, even if firefighters are already at the building, and tell them where you are. Signal to firefighters for help with a light cloth. If possible, open the window at the top and bottom, but be ready to shut the window immediately.

Messages for young children

To be safe from a fire in your home, you need three things:

1. Smoke Alarms: Make sure you have at

least one smoke alarm on each level of your home. A smoke alarm makes a loud noise. When you hear a smoke alarm beep, it's telling you that there is smoke and you need to get out of your home.

Questions: How many of you have a smoke alarm in your home? Have you ever heard your smoke alarm? What does it sound like? Do you know what the smoke alarm is telling you?

2. A Home Fire Escape Plan: Make a home

fire escape plan with your parents or the grown-ups in your home. You'll need two ways out of every room. One way out would be the door, and the second way out may be a window. After you make your plan, practice it!

3. A Meeting Place: Pick a place outside your

home where everyone will meet after exiting. A good meeting place would be a tree, light or telephone pole, or mailbox.

21-3600E rev1.3

Welcome Alarm Status Admin

Reference

Arming Station Reference

(option)

The optional Arming Station allows many system tasks to be performed without having to login at the LCD Keypad. The following is an overview of the available commands.

For more information on entering at a controlled door and/or disarming the system, refer to the "Welcome"

and "Alarm" chapters.

<login> represents the form of user

identification used e.g. badging card and or ID – PIN entry.

Be sure to enter all digits of your user-ID and/or PIN (e.g., 023).

Command Result

<login> only

(Momentary unlock of a door)

Command Result

 1 <login>

Command Result

 1 0 <login>

ENSURE ALL PROTECTION POINTS ARE SECURE WHEN ARMING AT THE ARMING STN If arming to STAY or ON occurs while any number of non-bypassable protection points are insecure, the Arming Station will warn the user with audible and visual indications. The arming station will make a long buzz and the left and right lights will flash back and forth. This will also cause an alarm condition. The user must turn OFF, locate and correct the problem and attempt arming again. If the protection point is bypassable, it will be automatically bypassed when arming is done at the station. Unless specially programmed, all points

except the entry/exit door ARE bypassable.

Command Result

 2 <login>

Access

Turn Area Off

Turn all Areas Off

Turn area to Stay

Command Result

 3 <login>

Command Result

 3 0 <login>

Command Result

 5 <login>

Door Commands If area is off and door unlocked, door is locked. If area is off and door locked, door is unlocked. Disarm Area If area is on, door locked and user is authorized, area turns off and door is unlocked.

Command Result

 6 <login>

Turn area On

Turn all Areas On

Door Commands and Disarm area

Work Late in area by 2 hours at a time from the current time.

Scheduled area only. This command can only be used again at the end of the first entered 2 hours when the arming station will indicate closing time again with the work late LED flashing and tones. At that time, this command can be used again to extend the closing time another 2 hours.

Command

 6 n <login>

Work Late in this area for “ n “ hours where n = 1 – 9 hours Scheduled area only.

Command Result

 7 <login>

Armed light is Green for Area OFF, Armed light is solid red for Area in STAY Armed light is flashing red for Area ON.

Command Result

 9 <login>

Result Worklate in area for n hrs.

Use Armed light to view area condition for 20 seconds .

Silence alarm (in all areas)

36 xL LCD Keypad User's Guide 21-3600E rev1.3

Command Result

# #

Command

Result

Cancels any keys previously entered.

If performing a “” command with UID/PIN, insert a "#" key between command and UID/PIN entry (e.g. “

 1 # 341

4141 ” for user 341, pin=4141 trying to arm the

area:

1).

No Commands (Simple Access)

Door Mode <Login> Notes

Card Only <card> If a UID/PIN is entered, it will be

ignored

Card & PIN <card> <pin> UID is not required since the card

automatically identifies the <uid> Card or UID/PIN <card> or <uid> <pin>

UID/PIN Only <uid> <pin> If card is presented, it will be ignored.

<uid> – User ID

With Commands

Door Mode <cmd> <Login> Notes

Card Only <cmd> <card> If a UID/PIN is entered, it will be

ignored

Card & PIN <cmd> <card> <pin> Card badging must always be done

before the PIN entry.

Card or UID/PIN <cmd> <card> or

<cmd> # <uid> <pin>

Pressing “#” is required between the command and uid/pin entry.

UID/PIN Only <cmd> # <uid> <pin> Pressing “#” is required between the

command and uid/pin entry. (Note <cmd> # <pin> in PIN Only systems)

<cmd> – Command

21-3600E rev1.3

Welcome Alarm Status Admin

Reference

xL Arming Station Lights

The optional xL Arming Station has three lights to indicate door, system and arming status. The following list indicates the light messages and audible results from the Arming Station. For detailed information on Keypad Tones, see

Audible Keypad Tones.

Work Late Light

Yellow light on solid within 15 minutes of the scheduled closing time.

Off if the area is not scheduled or there are more than 15 minutes to the scheduled closing time.

Door State Light

This icon

on key 9 is for

the command to silence an alarm

9 <login>

Lights

Red light on solid if the door is locked. Same light solid green if the door is unlocked. Flashing red while protection turning off if there was

an alarm in the area.

Armed Light

On solid green if the area is disarmed (Off). On solid red if the area is set to the "Stay" arming-

level (only the perimeter sensors being monitored). Flashing red if the area is armed (On)

Tone/Siren Result

Entry / Exit Tones Quick turning on and

off beep.

Fire Siren A repeating tone that

turns on for 5 seconds off for 5 seconds. After this happens 3 times there is a delay and the same sequence repeats.

Burglary Siren Continuous tone Bad Command Double short beeps Command

Single long beep

Accepted Not authorized to

Double long beep

Perform Command

38 xL LCD Keypad User's Guide 21-3600E rev1.3

Wireless Keypad Reference

Not evaluated by UL

xL Wireless Keypad (option)

The optional xL Wireless Handheld Keypad allows system commands to be performed using the wireless keypad. Below is a list of the available Wireless Keypad commands, and their proper Key sequences.

“login” refers to entering your User ID and PIN.

Command Result

“login” + command key +1

Command Result

“login” + command key +2

Command Result

“login” + command key +3

Command Result

“login” + command key +4

Turns area fully Off

Turns area to Stay

Turns area fully On

Performs a System Test

All Sirens will sound and all lights turn on for 5 seconds to indicate that the system is functioning

correctly.

Command Result

“login” + command key +9

Command Result

“login” + function key +1 to 9

Command Result

Clears or Silences Alarms

Activates selected function key

Cancels any keys entered

21-3600E rev1.3

Welcome Alarm Status Admin

Reference

Error Messages and Trouble Indications

Keypad Screen Display Error Messages

This section contains a list of error messages that may appear on the keypad’s display screen. The condition responsible for each message is explained below.

Power Failure: AC Failure. System Trouble: Control Unit or Module

Tamper condition, module Communications failure, Fuse Failure, Fire Circuit Faults.

Battery Trouble: Low voltage from Control

Unit or module battery or missing / disconnected.

Phone Trouble: Trouble with Communications

to the monitoring station.

Report Trouble: Trouble with

Communications to the monitoring station.

Area in Test: Walk Test or Hold-up Test In-

Progress.

Program Lost: Alarm System Operations

Configuration Lost.

Program Error: Error in Alarm System

Configuration on Control Unit, Error in Configuration on module.

HSC Comms: Alarm Communications

Trouble.

If a trouble condition persists, contact your Security Representative / Installer to investigate.

Keypad Yellow Trouble Light

The Yellow Trouble Light on the keypad may turn on when the following system conditions occur:

System Tamper, Battery Trouble, AC Failure (Flashing), Phone Line Trouble, Report Delay, Time Lost, Time Changed, Program Error, Fuse Trouble, Module Trouble, Module Program Error, Misc. (Test Failure), HSC Trouble, Fire Circuit Faults.

System Status Trouble

The following conditions may appear when viewing the system status:

System Tampr, LoNoBattery, AC Failure, No PhoneLine, Report Delay, Time Lost, Time Change, Program Edit, Prog Error, Fuse(s) Fail, Pod Trouble, Pod Battery, Pod ProgEdit, Pod ProgErr, HSC (alarm communications) Trouble

"POD" refers to a "Module". (Protection Point expander, door controller, keypad, etc.).

If any of these trouble conditions persist, contact your Security Representative / Installer to investigate.

40 xL LCD Keypad User's Guide 21-3600E rev1.3

Things to Do to Prevent False Alarms

Please do your part to prevent false alarms. This ensures that authorities will take your emergency seriously.

• Familiarize yourself with the control unit. Carefully read and review your operator’s manual or

user guide. If there is anything you do not understand, contact your Security Representative Installer to explain it further.

• Enter and leave only through predefined Entry/Exit Routes.

• Do not turn the protection on with people on the premises; unless, you select STAY to only turn

the perimeter protection on.

• Check the protected area to make sure all doors are closed and no one is left inside before

turning on the protection.

• Always have your system number and pass number ready when calling the monitoring station.

• Keep your system number and pass number confidential.

• Notify the monitoring station if you did not turn the protection off before the “entry time”

countdown expires.

• Notify the monitoring station immediately if someone accidentally activates a panic button or

emergency key.

• Notify the monitoring station immediately if you have accidentally caused a false alarm.

• Notify the monitoring station before performing a live test. E.g. pushing emergency keys or

causing detection devices to alarm with protection turned on.

• Request service from your Security Representative / Installer in the event of an unexplained

alarm or any system problems.

• Explain the system’s operation in detail to any new user.

• Do not leave pets on protected premises when the protection is fully ON, unless the system was

planned for it.

• Quickly repair any damaged doors or windows that have excessive play or do not lock.

• Do not place space heaters, moving objects or leave windows open in the path of motion

detectors when protection is on.

21-3600E rev1.3

Welcome Alarm Status Admin

Reference

Index

Access Token ON, OFF.................................. 11

ACPO Confirmed Alarm Remote Reset .......... 13

ACPO Resetting Confirmed Alarms................12

ACPO Restoring Tampers ..............................12

Activity logs...............................................27, 28

Adding

Users ..........................................................22

Adding a User ................................................. 22

Administration and maintenance tasks ...........21

Alarm monitoring features.................................6

Alarms

Dealing with ..................................................7

Area arm/disarm status..................................... 9

Area Groups protection On ............................. 10

Area Priority Turning On / Off .........................11

Areas, individual protection On ....................... 10

Arming ..............................................................9

Arming Station Reference...............................36

Arming Station Tones .......................................6

Audible Tones...................................................6

Authority Abilities ............................................22

Beeping (what to do if the keypad is beeping ...7

Bypassing a faulty sensor...............................17

Cancelling A False Alarm..................................7

Changing settings for

Users ..........................................................24

Changing Your Own PIN.................................22

Check status or control

Monitored sensors (input points)................. 17

Chime Door Feature .......................................33

Common Area Turning On / Off ......................11

Control and status features.............................16

Controlling doors............................................. 18

Copyrights and Trademarks............................. iii

Date and Time for the panel, setting...............26

Deleting users.................................................26

Director PC, keypad calling.............................27

Disarming........................................................10

Disclaimers ...................................................... iii

Doors

Check status ...............................................18

Controlling...................................................18

Door Chime.................................................33

Duress Alarm .................................................... 3

Emergency keys

Using.............................................................8

Error Messages ..............................................40

Evacuation plan ..............................................34

Event logs ................................................. 27, 28

False Alarm

Cancelling .....................................................7

False Alarm Prevention.............................30, 41

Faulty sensor, bypassing ................................17

Faulty sensor, Isolating ...................................17

Fire safety .......................................................34

Function keys

Using...........................................................16

Function Keys Reference................................33

Group of Areas protection On .........................10

History, printing...............................................28

History, viewing...............................................27

Holdup test......................................................30

ID number, PIN number ..............................3, 12

Isolating a faulty sensor ..................................17

Keypad and Access Token ON, OFF..............11

Keypad calling Director PC .............................27

Keypad entry basics..........................................4

Keypad Error Messages .................................40

Keypad Lights, Buttons .....................................2

Keypad Tones...................................................6

Burglar Alarm ................................................7

Fire Alarm .....................................................6

Keypad, wireless.............................................39

Language for the printed history logs..............28

Lights on an Arming Station ............................38

Maintenance tasks ..........................................21

Monitoring Station, when to contact ................32

OFF, Protection...............................................10

ON, OFF, Access Token and Keypad.............11

ON, STAY .........................................................9

Panic buttons, testing (holdup test).................30

Performing Other Functions ..............................3

Reverse digits to indicate duress ..................3

PIN number, ID number ..............................3, 12

PIN, changing .................................................22

Point (sensor), bypassing................................17

Points (sensors), checking the status of .........17

Printer .............................................................19

Printing the History..........................................28

Priority Arming ................................................11

Protection OFF................................................10

Protection ON, STAY ........................................9

Readers, check status or controlling ...............18

Schedules

Adjusting .......................................................8

Suspending ...................................................9

Security Representative, when to contact.......32

42 xL LCD Keypad User's Guide 21-3600E rev1.3

Sensor, bypassing ..........................................17

Sensors (points), checking the status of .........17

Setting the Date and Time ..............................26

Setting, Unsetting the Alarm .............................9

Siren .................................................................7

Sirens................................................................7

Sirens, testing .................................................30

Status and control

Application module (Printer)........................19

Checking sensors (points)...........................17

Checking the status of doors.......................18

Monitored sensors (input points).................17

Status and control features .............................16

Status of System, Checking............................16

STAY, ON .........................................................9

Suspending schedules ......................................9

System information (areas, authorities, etc.....32

System test .....................................................30

Testing sirens..................................................30

Testing the Entire System...............................30

Testing the System

Panic buttons (holdup test) .........................30

Walk Test ....................................................29

Time and date for the panel, setting................26

Trademarks and copyrights.............................. iii

Trouble Light Indications .................................40

Trouble messages ..........................................40

Turning On / Off Common Area ......................11

Turning On / Off Priority ..................................11

Unlock/relock doors ........................................18

Users

Adding.........................................................22

Deleting.......................................................26

View or Edit.................................................24

Using Emergency keys .....................................8

View area arm/disarm status.............................9

Viewing

User settings ...............................................24

Viewing the History .........................................27

Voice Siren........................................................7

Walk Test........................................................29

When to contact the Monitoring Station ..........32

When to contact your Security Representative

....................................................................32

Wireless keypad..............................................39

Work-late...........................................................8

21-3600E rev1.3

Welcome Alarm Status Admin

Reference

N3459

Interlogix XL LCD Keypad Plus User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

About This Guide

Also See (Related Documents)

Copyrights and Trademarks

Disclaimer

The xL LCD Keypad

What You can do with the LCD Keypad

Keypad Display and Buttons

Buttons under the Display Screen

The Numeric Keypad

The ◄ arrow ► Keys on the Keypad

Emergency Keys and Programmed Function Keys

If You Are Being Forced to Enter Protected Premises

Logging Into the Keypad (User ID and/or PIN)

Overview of Screens (Topics)

Keypad Entry Basics

Entering Letters (e.g., for a user's name)

Alarm Monitoring Features

Audible Keypad Tones

Conventional Siren

Voice Siren (optional)

Dealing with Alarms (what to do if the keypad is beeping)

Silencing a False Alarm

Using the Emergency Keys

Alert Keys

Worklate: Extending the Scheduled Closing Time

Suspending Schedules for an Area or Areas

Turning Protection ON, STAY, or Viewing the Present Arming-Level

Turning Protection OFF

Turning Protection On by Area Groups, a Group of Areas or Individual Areas.

Area Priority Protection On/Off

Common Area Protection On/Off

Turning ON an Area’s Protection using an Access TOKEN

Turning OFF an Area’s Protection using an Access TOKEN

UK and European System Operation

Status and Control Features

Using the Function Keys

Checking the Status of Sensors (Points) and Areas

Bypassing or Isolating a Faulty Sensor

Checking Status or Controlling Readers or Doors

Checking the Status or Controlling an Elevator Reader

Checking the Status of an Application Module (POD)

Changing Your Own PIN

Adding a User to the System

Default Authority Settings

Viewing or Changing Settings for a User

Setting the Date and Time

Viewing the History

Changing the Printed History Language

Testing Monitored Sensors (Performing a Walk Test)

Testing Panic Buttons (Performing a Hold-up Test)

Testing Sirens (System Test)

System Information

Contact Information

Miscellaneous Features:

Emergency Keys that are Available:

Function Key Reference

Residential Fire Safety / Evacuation Plan

Residential Installations

Practicing Fire Safety

Apartment buildings, dormitories, and high-rises

Messages for young children

Arming Station Reference

(option)

xL Arming Station Lights

Wireless Keypad Reference

Not evaluated by UL

xL Wireless Keypad (option)

Error Messages and Trouble Indications

Keypad Screen Display Error Messages

Keypad Yellow Trouble Light

System Status Trouble

Things to Do to Prevent False Alarms

Index
