Interlogix VR1001 User Manual

VR1001
VR1001-R3

IFS Fiber Module
Installation & Operation
Instructions

P/N 1062821 • REV B • ISS 01JUL11

GAIN 1

NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.

VR1001

DUAL VIDEO RECEIVER

MANUAL GAIN

Simplex multimode
fiber optic cables

OPTICAL INPUT 1

From VT1101M, VT1001AC

or VT1001

series module

}

LEVEL DETECT 1

GAIN 2

LEVEL DETECT 2

POWER

ifs

International

Fiber

Systems

Incorporated

VIDEO OUTPUT 1

OPTICAL INPUT 2

VIDEO OUTPUT 2

24 VAC
CENTER
TAPPED

AC - 3

CT- 2
AC- 1

Coax cable

Blue
Green
Brown

Video

Monitor

Video

Monitor
