Interlogix TVP-WBS User Manual

TVP-WBS Stainless Steel PTZ Wall Mount

Dimensions

326 mm (12.83 in.)

212 mm (8.35 in.)

136 mm

(5.35 in.)

185 mm

(7.28 in.)

Weight:

A

Drill template

Mounting plate

Expa

Used to install the TVP
mounting surface.

55 mm (2.17 in.)

80 mm (3.15 in.)

20 mm

(0.79 in.)

1.2 mm

(

0

.05

in.)

8 mm

(0.31 in.)

M10 mm

(0

.

39 in

.)

16 mm

(0.63 in.)

Nut

Used to mount the pipe assembly to the mounting plate

Nut:

Flat washer:

Split washer:

Installation Instructions

nsion anchors: M10 x 80 mm (4 pcs)

Specifications

:

212 × 136 × 326 mm
(8.35 × 5.35 × 12.83 in.)

(4 pcs), flat washer (4 pcs), and split washer (4 pcs) A

-WBS stainless wall mount to the

2.30 kg (5.07 lbs.)

ccessories:

: 1 pcs

: 1 pcs

185 x 136 mm (7.27 x 5.35 in.)

Supported cameras

The stainless steel wall mount can be used with following
cameras:

Stainless Steel PTZ Dome: TVP-5201

Installation

To install the stainless steel PTZ dome to the TVP-WBS:

1. Using the drill template mark the mounting surface. Drill
four mounting holes and insert the expansion anchors.

2. Secure the mounting plate to the mounting surface using
the expansion anchors.
