TruVision® IP Megapixel Bullet IR Cameras by Interlogix bring high
definition images to the mass video surveillance market. With 2MPx,
4MPx or 8MPx (4K) resolution options, these cameras provide
flexibility for a wide variety of applications.
The IP Megapixel Bullet IR Cameras adhere to ONVIF
G open communications standards as well as CGI command set
support for simple integration into standard IP systems. By utilizing
an integrated browser and micro SD memory card storage capability,
these cameras simplify remote, live monitoring/playback of edgerecorded audio and video. Memory card recording also helps protect
data in the event of network disruptions.
Cross line, intrusion, face detection, and privacy masking provide
additional flexibility when monitoring key areas of a facility. These
features alert the user when key exceptions are triggered, reducing
the amount of time and effort required when responding to alarms.
Network security features include network disconnect, IP address
conflict and illegal login detection. These features in addition to
integrated motion and tamper detection provide a secure video
solution.
®
Profile S and
STAN DAR D FE ATU R ES
Video
• 2MPx, 4MPx or 8MPx (4K) resolution options
• H.265/H.264/MJPEG (on substream) compression technology
with triple-streaming capability
• 4mm fixed lens / 2.8-12mm motorized varifocal lens options
• ONVIF Profile S and G open communications standards
compatibility
Video Enhancements
• WDR 120 dB
• True D/N functionality and infrared illuminators
• 98 ft. (30m) to 164 ft. (50m) IR range on select models
Alarm Intelligence
• Integrated motion and tamper detection
• Network disconnected and IP address conflict detection
• Illegal login detection
Edge Recording
• Edge recording on up to 128GB micro SD/SDHC/SDXC card for
video playback (card not included)
Installation and Environment
• IP67 Environmental rating on select models
• IK10 Vandal rating on select models
• TruVision Device Manager software to access newly added system
devices
• Cable management back box available as an accessory for the
fixed lens camera
Warranty
• 3-year warranty
interlogix.com/truvision
Page 2
Specifications
PART NO.
Housing
Sensor 1/2.8" Progressive Scan CMOS
Resolution 2MPx 4MPx 8MPx (4K) 2MPx 4MPx 8MPx (4K)
Day/Night True D/N, IR cut filter
IP Compression/Standard H.265 / H.264 / MJPEG
Main Stream H.265 / H.264
Substream H.265 / H.264 / MJPEG
3rd Stream H.265 / H.264
Multiple Streaming Triple Stream
Maximum Resolution 1920 x 1080 2560 x 1440 3840 x 2160 1920 x 1080 2560 x 1440 3840 x 2160
Main Steam Real-Time Resolution
Substream Real-Time Resolution
Camera
3rd Stream Real-Time Resolution
Video Bit Rate
Wide Dynamic Range
Digital Noise Reduction
Minimum Illumination
Digital S/N Ratio 50 dB (AGC Off)
Auto Exposure (shutter) 1/3 s to 1/100,000 s
Lens
Focus Fixed Motorized Varifocal
IR Range 98 ft. (30m) 164 ft. (50m)
Video Output N/A Composite (NTSC/PAL) (for video test monitor service cable)
Video Connector N/A 1 - 75W / BNC (for video test monitor service cable)
Ethernet Port 1 RJ45 10M/100M auto-negotiate
Network Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP
Network
Media Micro SD/SDHC/SDXC Card
Local
Capacity 128GB (card not included)
Storage
Input N/A 1 input (line in / mic in, 3.5mm)
Output N/A 1 output (line out, 3.5mm), mono sound
Audio
Audio bit rate (protocol) N/A G.711 / G.722.1 / G.726 / MP2L2 / PCM
Intelligence
Alarms
Camera
Input/Output N/A 1 in / 1 out (up to 12VDC, 30mA)
TVB-5601 TVB-5602 TVB-5603 TVB-5604 TVB-5605 TVB-5606
Gray
1/2.5" Progressive
Scan CMOS
50Hz:
50Hz:
25 fps (1920 x 1080,
1280 x 960,
1280 x 720)
60Hz:
30 fps (1920 x 1080,
1280 x 960,
1280 x 720)
50Hz:
25 fps (1920 x 1080,
1280 x 720,
640 x 360, 352 x 288)
60Hz:
30 fps (1920 x 1080,
1280 x 720,
640 x 360, 352 x 240)
Color: 0.01 lux @
(f1.2, AGC On), 0.028
lux @ (f2.0, AGC On),
0 lux with IR
4mm: horizontal FOV:
86°, vertical FOV: 46°,
diagonal FOV: 102°
Motion detection, Face detection, Cross line detection (up to 4 lines), Intrusion detection (up to 4 regions), Privacy mask, Video tampering,
50Hz:
25fps (2560 x 1440,
2304 x 1296,
1920 x 1080)
60Hz:
30 fps (2560 x 1440,
2304 x 1296,
1920 x 1080)
25 fps (1280 x 720, 640 x 360, 352 x 288)
30 fps (1280 x 720, 640 x 360, 352 x 240)
Color: 0.01 lux @
(f1.2, AGC On), 0.018
lux @ (f1.6, AGC On),
0 lux with IR
4mm: horizontal FOV:
78°, vertical FOV: 42°,
diagonal FOV: 93°
Network disconnected, IP address conflict, Illegal login, HDD full, HDD error
12.5 fps (3840 x 2160);
20 fps (3072 x 1728);
25 fps (2560 x 1440,
1920 x 1080,
1280 x 720)
60Hz:
15 fps (3840 x 2160);
20 fps (3072 x 1728);
30 fps (2560 x 1440,
1920 x 1080,
1280 x 720)
50Hz: 25 fps (704 x 576, 640 x 480, 640 x 360, 320 x 240)
60Hz: 30 fps (704 x 480, 640 x 480, 640 x 360, 320 x 240)
50Hz:
60Hz:
32 Kbps to 16 Mbps
120 dB
Color: 0.01 lux @
(f1.2, AGC On), 0.028
lux @ (f2.0, AGC On),
0 lux with IR
4mm: horizontal FOV:
79°, vertical FOV: 42°,
diagonal FOV: 95°
3D DNR
1/2.8" Progressive Scan CMOS
50Hz:
25 fps (1920 x 1080,
1280 x 960,
1280 x 720)
60Hz:
30 fps (1920 x 1080,
1280 x 960,
1280 x 720)
50Hz:
25 fps (1920 x 1080,
1280 x 720,
640 x 360, 352 x 288)
60Hz:
30 fps (1920 x 1080,
1280 x 720,
640 x 360, 352 x 240)
Color: 0.01 lux @ (f1.2, AGC On), 0.018 lux @ (f1.6, AGC On), 0 lux with IR
2.8 to 12mm:
horizontal FOV: 110°
to 31°, vertical FOV:
58° to 18°, diagonal
FOV: 136° to 36°
50Hz:
25 fps (2560 x 1440,
2304 x 1296,
1920 x 1080)
60Hz:
30 fps (2560 x 1440,
2304 x 1296,
1920 x 1080)
25 fps (1280 x 720, 640 x 360, 352 x 288)
30 fps (1280 x 720, 640 x 360, 352 x 240)
2.8 to 12mm:
horizontal FOV: 98° to
28°, vertical FOV: 51°
to 16°, diagonal FOV:
115° to 32°
™
, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour
12.5 fps (3840 x 2160);
50Hz:
60Hz:
to 34.5°, vertical FOV:
1/2.5" Progressive
Scan CMOS
50Hz:
20 fps (3072 x 1728);
25 fps (2560 x 1440,
1920 x 1080,
1280 x 720)
60Hz:
15 fps (3840 x 2160);
20 fps (3072 x 1728);
30 fps (2560 x 1440,
1920 x 1080,
1280 x 720)
2.8 to 12mm:
horizontal FOV: 105°
55° to 19°, diagonal
FOV: 125° to 40°
Standard ONVIF Profile (S, G), CGI, ISAPI
erability
Interop-
Page 3
PART NO.
Display Mode Rotate mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
Display
On Screen Display (OSD) Text overlay
Voltage Input 12VDC ± 25%, PoE (IEEE 802.3-af) 12VDC ± 25%, PoE+ (IEEE 802.3-at)
Power Consumption
Auxiliary Output NA
Electrical/
Dimensions 2.76 x 6.1 in. (70 x 155.03mm) 5.7 x 13.1 in. (144.13 x 332.73mm)
Mechanical
Weight 0.9 lbs. (410g) 3.8 lbs. (1740g)
Storage Temperature -22°F to +140°F (-30°C to +60°C)
Operating Temperature -22°F to +140°F (-30°C to +60°C), Humidity 95% or less (non-condensing)
Environmental Rating IP67
Vandal Rating N/A IK10
Environmental
Compliance EMC USA, EMC Europe, UL/cUL, WEEE, LVD, RoHS, REACH, China RoHS
Regulation
Dimensional Diagrams
TVB-5601 TVB-5602 TVB-5603 TVB-5604 TVB-5605 TVB-5606
PoE (802.3-af, 37V to 57V), 0.2A to 0.1A, max. 7.5W
12VDC, 0.5A, max. 6W
PoE+ (802.3-at, 42.5V to 57V), 0.43A to 0.3A, max. 18W
12VDC, 1.2A, max. 14.5W
TVB-5601, TVB-5602, TVB-5603 Fixed Lens Bullet Camera
6.1 in. (155.03mm)
3.19 in.
(81.09mm)
2.17 in.
(55mm)
TVB-5604, TVB-5605, TVB-5606 Motorized Varifocal Lens Bullet Camera
(mounting adapter plate included, image shown below)
13.1 in. (332.73mm)
2.76 in.
(70mm)
5.7 in.
(144.13mm)
Page 4
2MPx, 4MPx and 8MPx (4K)
IP Bullet IR Cameras
Series 6 IP Cameras
Ordering Information
®
TVB-5601
TVB-5602
TVB-5603
TVB-5604
TVB-5605
TVB-5606
TruVision
WDR, 30m IR, Micro SD/SDHC/SDXC Slot, PoE (802.3-af)/12VDC, IP67
TruVision 4MPx, H.265/H.264, IP Fixed Lens Bullet Camera, 4mm, True D/N, WDR,
30m IR, Micro SD/SDHC/SDXC Slot, PoE (802.3-af)/12VDC, IP67
TruVision 8MPx/4K, H.265/H.264, IP Fixed Lens Bullet Camera, 4mm, True D/N,
WDR, 30m IR, Micro SD/SDHC/SDXC Slot, PoE (802.3-af)/12VDC, IP67
TruVision 2MPx, H.265/H.264, IP VF Bullet Camera, 2.8~12mm Motorized,
True D/N, WDR, 50m IR, Audio, I/Os, Micro SD/SDHC/SDXC Slot, PoE+
(802.3-at)/12VDC, IP67, IK10
TruVision 4MPx, H.265/H.264, IP VF Bullet Camera, 2.8~12mm Motorized,
True D/N, WDR, 50m IR, Audio, I/Os, Micro SD/SDHC/SDXC Slot, PoE+
(802.3-at)/12VDC, IP67, IK10
TruVision 8MPx/4K, H.265/H.264, IP VF Bullet Camera, 2.8~12mm Motorized,
True D/N, WDR, 50m IR, Audio, I/Os, Micro SD/SDHC/SDXC Slot, PoE+
(802.3-at)/12VDC, IP67, IK10
2MPx, H.265/H.264, IP Fixed Lens Bullet Camera, 4mm, True D/N,
Accessories
For Fixed Lens Bullets (TVB-5601, TVB-5602, TVB-5603)
TVB-BB1
TVB-2G-AD
TruVision Bullet Back Box (for fixed lens bullet only)
TruVision Double Gang Box Adapter Plate (for fixed lens bullet or LWB wall mount)
interlogix.com
Specifications subject to change without notice.
© 2019 United Technologies Corporation.
All rights reserved.
Interlogix is part of UTC Climate, Controls & Security,
a unit of United Technologies Corporation.
2019/01 (GSP-2725)
