Interlogix D2315 User Manual

D1315
D1315WDM
D2315
D2315WDM

IFS Fiber Module
Installation & Operation
Instructions

P/N 1062851 • REV B • ISS 01AUG11

D1315 / D2315

4 - Wire RS485

Connection

4
3
2
1

- Data Output
+ Data Output

- Data Input
+ Data Input

DATA
REC

D1315
RS485

OUTPUT

INPUT

- DATA - 4

+ DATA - 3

- DATA- 2

+ DATA- 1

}

DATA
XTMR

POWER

Duplex multimode
fiber optic cable

ifs

International

Fiber

Systems

Incorporated

POWER

GRD- 2

12VAC/12VDC- 1

Black wire

Black with
white stripe

To D1315 or D2315

series module
