Interlogix BB-1GS, BB-2, BB-2XL Specsheet

Barrier Bars

®

For Hard to Secure Windows

www.GE-Interlogix.com

GE Magnetic Contacts

Product Information

Standard Features

Springload design installs in seconds

Alarm protection and visual deterrent

Strong, epoxy-based adhesive mount

Fits 12-inch (305mm) to 40-inch+ (1016mm+) openings

Works with hardwire or wireless systems

Barrier bars safeguard hard-to-protect windows. Basement

windows, jalousies, air-conditioning ducts or attic vents…

preventing unauthorized entry into these kinds of perimeter

openings has always been a tough challenge. Not for our Barrier

Bars – they’re made for securing hard-to-protect perimeter

openings. The unique design of Barrier Bars protects a building in

two ways. First, their sturdy appearance deters unauthorized entry.

Second, any attempt to remove the bar triggers an alarm. This

combination of visual deterrent and alarm system effectively

discourages would-be intruders from unauthorized access to a

building anytime, day or night.

Overview

Barrier Bars

®

For Hard to Secure Windows

©2003 GE Interlogix. Barrier Bars is a trademark of GE Interlogix. All trademarks are properties of their owners.
C-3806-RevC-0103

GE Interlogix

www.GE-Interlogix.com 2266 Second Street North

North St. Paul, MN 55109
Phone: [phone]
USA & Canada: 800-777-5484
Technical Service: 800-777-2624

12345 SW Leveton Drive
Tualatin, OR 97062
Phone: [phone]
USA & Canada: 800-547-2556
Technical Service: 800-648-7424
Faxback: 800-483-2495

Barrier Bars Install Fast.

The springloaded assembly snaps quickly into place with no
screws or drilling. And, Barrier Bars can be either surface or
frame-mounted. The self-adhesive, epoxy-based switch
adheres to brick or cement surfaces, forming a strong,
permanent bond. Barrier Bars fit windows or other perimeter
openings from 12 inches to over 40 inches wide. Once
installed, they do not restrict window access: you can
partially open the window for ventilation without loss of
protection. Or you may quickly remove the bars if needed.

Barrier Bars Give You a Choice.

The BB-1GS Pressure-Sensitive Barrier Bar, the BB-2
Mercury Switch Barrier Bar, and the BB-2XL Mercury Switch
Barrier Bar (metal with vertical cross bars for larger
perimeter openings.)

Barrier Bars are Made to Last.

Solid, durable construction ensures that our Barrier Bars will
safeguard your building indefinitely. Quality components
comprise each Barrier Bar – from the gold contact
snap-action switch to the stainless steel spring, to the
armored cable and tough PVC telescope tube assembly –
each component is made to exacting specifications for
lasting perimeter protection.

Our patented Barrier Bars are the no-hassle, cost effective
perimeter protection device you install in a minute.

BB-1GS Pressure Sensitive Switch

BB-1GS

BB-2

BB-2XL

AMB-1

not UL listed

Ordering Information

Barrier Bar Pressure Sensitive Switch*

Barrier Bar Mercury Tilt Switch*

Barrier Bar Mercury Tilt Switch-Metal*

Angle Mounting Brackets for mounting Barrier Bar on shallow or slanted window frames

* Must be ordered in 20-pack quantities

Model Description

BB-2 Mercury Tilt Switch

BB-2XL with vertical cross bars

armored cable

tamper cover

extra inside tube spacer for windows
bigger than 32" (812.8 mm)

gold contact

GS switch

mercury tilt

switch inside tube

extra inside tube spacer for windows
bigger than 32" (812.8 mm)

BB-1XL and
BB-2XL:
horizontal
Barrier Bar and
vertical bars

OVB-1:

vertical bars

only

U

L



LISTED
