Interlogix 48VDC User Manual

IFS 48VDC DIN Rail Power
Supply User Manual

P/N 1072691 • REV A • ISS 10JAN14

r

A

y

Copyright © 2013 United Technologies Corporation

Interlogix is part of UTC Climate Controls & Security, a unit of United
Technologies Corporation. All rights reserved.

Trademarks and patents The IFS POE302-EX name and logo are trademarks of United Technologies.

Other trade names used in this document may be trademarks or registered
trademarks of the manufacturers or vendors of the respective products.

Manufacture

Intended use

Certification

FCC compliance

Interlogix

3211 Progress Drive, Lincolnton, NC 28092 USA

Authorized EU manufacturing representative:
UTC Climate Controls & Security B.V.,
Kelvinstraat 7, 6003 DH Weert, Netherlands

Use this product only for the purpose it was designed for; refer to the data sheet
and user documentation for details. For the latest product information, contact
your local supplier or visit us online at www.interlogix.com.

N4131

This equipment has been tested and found to comply with the limits for a Class

digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment gene rates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to
radio communications.

You are cautioned that any changes or modifications not expressly approved b
the party responsible for compliance could void the user's authority to operate
the equipment.

ACMA compliance Notice! This is a Class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take
adequate measures.

Canada

This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme á la norme NMB-003du

Canada.

European Union

directives

2004/108/EC (EMC Directive): Hereby, UTC Climate Controls & Security

Corporation, Inc. declares that this device is in compliance with the essential

requirements and other relevant provisions of Directive 2004/108/EC.

Contact Information

For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.

TABLE OF CONTENTS

9IFS 48VDC DIN RAIL POWER SUPPLY USER MANUAL..............................................10H1

3H11HINTRODUCTION ..............................................................................................................12H4

4H13HDin Rail Features:................................................................................................................................. 14H4

5H15HInstallation:............................................................................................................................................ 16H4

6H17HPS48VDC480W-DIN............................................................................................................................. 18H5

7H19HPS48VDC240W-DIN............................................................................................................................. 20H7

8H21HPS48VDC100W-DIN............................................................................................................................. 22H9

3

IFS 48VDC DIN Rail Power Supply User Manual

Introduction

Din Rail Features:

• 48VDC Din-Rail power supplies, AC Input 100~240V AC - 50/60Hz.

• High efficiency and Low power dissipation

• Built-in active PFC function, PF>0.93

• Over load protections: Short Circuit/Overload/Over Voltage/ Over temperature

• Cooling by Free Air convection

• Can be installed on DIN Rail TS-35/7.5 or 35/15

• UL 508 (industrial control equipment) approved

• EN61000-6-2 (EN50082-2) industrial immunity level

• Built-in DC OK Relay contact

• 100% full load burn-in tested

• 2 year warranty

Installation:

Din-Rail supplies can be mounted on admissible DIN-RAIL TS35/7.5 or TS35/15

4
