Interactive Toy Concepts Storm Wolf User Manual

Main Rotor Blades:

REPLACING DAMAGED ROTOR BLADES -Continued:

ISSUE:

TROUBLESHOOTING

CAUSE:

CORRECTIVE ACTION:

ISSUE:

TROUBLESHOOTING -Continued

CAUSE:

CORRECTIVE ACTION:

TM

1. Locate the broken Rotor Blade and use a fine Philips screw-driver (not included) to unscrew the tiny screw that
holds the Rotor Blade in place on the Hub Mount. Be careful not to lose the screw as it is tiny.

2. Pull the damaged Rotor Blade horizontally out and away from its location on the Hub Mount.

3. Install a new Rotor Blade in the same location on the Hub Mount by sliding it in horizontally. The holes for the
screw have to align. It is very important that the correct Rotor Blade is installed as the Upper and Lower Main
Rotor Blades may appear to be similar but are in fact very different. The Storm-Wolf Helicopter will not be able to
fly if the incorrect Rotor Blades are installed.

4. Fasten the new Rotor Blade to its Hub Mount with the same tiny screw that was pulled out earlier. Do not over
tighten the screw as the Rotor Blade needs to be able to spin freely inside its Hub Mount. Your Storm-Wolf
Helicopter is ready to fly again!

Tail Rotor:

1. Locate the broken Tail Rotor on the end of the Storm-Wolf Helicopter’s boom.

2. Remove the broken Tail Rotor by gently pulling it upwards off of the Tail Motor’s Axle Shaft.

3. Install the replacement Tail Rotor (Included with the Storm-Wolf) by sliding it onto the Tail Motor’s Axle Shaft in
the reverse process as outlined in step 2.

4. Gently press down on the replacement Tail Rotor until it is firmly in place.

REPLACING THE BALANCE-BAR-TO-UPPER-ROTOR CONNECTOR:

There is a small Connector which connects the Upper Rotor to the Balance Bar. In the event that this Connector
becomes disconnected, broken, or lost, it will need to be reconnected or replaced. A replacement Balance-Bar­To-Upper-Rotor Connector is not included with the Storm-Wolf Helicopter. A replacement connector can be
purchased separately as part of the Storm-Wolf Replacement Parts Kit. Replacement is easy with the following
steps.

Storm-Wolf Helicopter will
not start, LED on
Storm-Wolf Helicopter is
off.

Storm-Wolf Helicopter will
not start, LED on
Storm-Wolf Helicopter is
ON.

Storm-Wolf Helicopter will
not start, LED on
Storm-Wolf Helicopter is
flashing.

Storm-Wolf Helicopter is
flying too high

Storm-Wolf Helicopter is
flying too low.

1. Storm-Wolf Helicopter is not
turned on.

2. Battery is not charged.

3. Storm-Wolf Helicopter was not set
to off during charging.

4. Rotors locked for overload
protection.

1. Storm-Wolf Helicopter's infrared
link is not established with the IR
Controller.

2. IR Controller is not turned on.

3. Storm-Wolf Helicopter’s battery is
low.

1. Motor stall protection is activated.

2. Storm-Wolf Helicopter's Internal
Battery power is low.

1. You need to reduce the Throttle
Input.

1. Needs more power (Throttle Input).

2. The battery in the Storm-Wolf
Helicopter is low.

1. Turn Storm-Wolf Helicopter on.

2. Charge Internal Storm-Wolf Helicopter Battery.

3. Ensure Storm-Wolf Helicopter is off and charge
Internal Storm-Wolf Helicopter Battery.

4. Slide Storm-Wolf Helicopter's On / Off Switch to Off,
then switch it On again.

1. Push Left Stick (Throttle) completely UP, then back
DOWN to initialize infrared link and throttle control.

2. Turn on IR Controller.

3. Ensure Storm-Wolf Helicopter is off and charge
Internal Storm-Wolf Helicopter Battery.

1. Reset the Storm-Wolf Helicopter by turning its power
off and on.

2. Ensure the Storm-Wolf Helicopter is Off and
recharge the Internal Battery.

1. Push the Left Stick (Throttle) gradually down.

1. Push the Left Stick (Throttle) gradually up.

2. Ensure the Storm-Wolf Helicopter is off and charge
the Internal Storm-Wolf Helicopter Battery.

Storm-Wolf Helicopter
always turns.

The Main Rotor Blades
spin erratically causing
unpredictable flight
characteristics.

1. Trim Control is not set correctly.

2. The Main Rotor Blades have
sustained damage / or wear from use.

1. The Balance-Bar-to-Upper-Rotor
Connector is either broken or missing.

1. Adjust the Trim Control Knob on the IR Controller.

2. Replace the damaged Rotor Blades! It is danger­ous to fly with damaged Rotor Blades! Replacement
Rotor Blades are not included, but can be purchased
separately as part of the Storm-Wolf Replacement Part
Kit.

1. Install a new Connector using the instructions in the
“REPLACING THE BALANCE-BAR-TO-UPPER­ROTOR CONNECTOR” section. Replacement Connec­tors are not included, but can be purchased separately
as part of the Storm-Wolf Replacement Part Kit.

IMPORTANT SAFETY INFORMATION

Keep the Storm-Wolf Helicopter away from face, eyes and hair at all times. Keep fingers away from moving
rotors or propellers. Do not fly the Storm-Wolf Helicopter near or at other people or animals. Use caution when
flying, make sure people around you know that you are playing with the Storm-Wolf Helicopter. Recommended
for use indoors only in rooms without obstacles, breakable objects or fans. The IR Controller's built-in Charger
provided in this package is for charging the Storm-Wolf Helicopter ONLY. Do not use any other source to charge
the Storm-Wolf Helicopter. Do not attempt to overcharge your Storm-Wolf Helicopter. Follow the charging
instructions provided in this Instruction Manual. Do not attempt to replace the Internal Lithium Polymer Recharge­able Battery inside the Storm-Wolf Helicopter! The Storm-Wolf Helicopter’s Lithium Polymer Rechargeable
Internal Battery is sealed inside the unit and is not replaceable. Any attempts to repalce the Storm-Wolf Helicop­ter's Lithium Polymer Rechargeable Internal Battery will void the warranty.

TM

Congratulations on the purchase of your BladeRunner
Storm-Wolf Helicopter. The Storm-Wolf brings advanced,
3-Channel, hobby-level flying technology to flyers who are
looking for great performance from an indoor Helicopter. The Storm-Wolf
has built-in advanced gyroscope technology for providing an ultra-smooth flight

8+

Item# 44072

and balance control assistance. In addition, the Storm-Wolf Helicopter has digital
proportional control. The Storm-Wolf is available in Infrared Control Channels A and
B. The compact and stylish design of the IR Controller has an integrated charging mechanism
so that only 6 AA Batteries in total are required to charge and operate the Storm-Wolf Helicopter.
Do not throw away this instruction manual as it contains valuable information for the operation of
your Storm-Wolf Helicopter as well as warranty information. The helpful tips in this Instruction
Manual will improve your skill and enhance your experience. Look for these symbols for
extra help.

1. The Connector is attached by 2 simple ball joints. Remove the broken Connector by disconnecting it from the
Upper Rotor Hub Mount and the Balance Bar and pull it away. Once removed, the ball joints will be exposed. A
ball joint will be visible on both sides of the Upper Rotor Hub Mount, and a ball joint will be visible on both sides of
the Balance Bar. There will be a total of 4 ball joints visible!

2. Install the new connector following the reverse of step 1. The connector only needs to connect 2 of the 4 ball
joints. The Connector must connect a set of ball joints that are in vertical alignment only. Gently but firmly press
the Connector into position, connecting the Upper Rotor and the Balance Bar. The Connector will just snap into
the 2 ball joints as shown.

STORING THE STORM-WOLF HELICOPTER:

It is a good idea to store the Storm-Wolf Helicopter, IR Controller and this Instruction Manual together so no
components become misplaced or lost. Please respect the below points to extend the operational life of your
Storm-Wolf Helicopter during storage.

1. Product may be damaged or performance may be adversely affected if the Storm-Wolf Helicopter is not prop­erly stored.

2. Never place any items on top of any components of the Storm-Wolf Helicopter.

3. Always keep your Storm-Wolf Helicopter in a cool dry place. Do not allow your Storm Wolf Helicopter to get
wet as it is not water resistant.

4. Keep the Storm-Wolf Helicopter away from pets and other household animals.

5. Do not rest your Storm-Wolf Helicopter on any potential heat source such as electronic equipment or a radiator.

Storm-Wolf Helicopter
doesn’t hover.

Helicopter doesn't fly
forward fast enough.

Storm-Wolf Helicopter
doesn’t fly backwards

Storm-Wolf Helicopter is
flying too low.

Storm-Wolf Helicopter
doesn't move forward fast
enough.

1. The Storm-Wolf Helicopter drifts
forwards/backwards.

1. The Storm-Wolf Helicopter is not
designed for fast flight as it is an
indoor toy.

1. The Storm-Wolf Helicopter only
flies backwards briefly then spins to fly
forward.

1. Needs more power (Throttle Input).

2. The battery in the Storm-Wolf
Helicopter is low.

1. The Internal Battery charge is
getting low.

2. The Tail Rotor is damaged.

3. The Storm-Wolf Helicopter center
of gravity is no longer correct.

1. Push the right stick up or down to compensate and
hold the Storm-Wolf Helicopter in position.

1) If desired, add a small amount of weight to the
bottom front area of the body by taping a paper clip or
something similar in weight and size onto it. However,
note that this will reduce the ability of the Storm-Wolf
Helicopter to fly backwards.

1. Aerodynamics make flying backwards more difficult
than flying forwards and this flight pattern is normal.
Practice flying backward and control the left / right
turning motion of the Storm-Wolf Helicopter to keep the
tail pointed in the direction you desire.

1. Push the Left Stick (Throttle) gradually up.

2. Ensure the Storm-Wolf Helicopter is off and charge
the Internal Storm-Wolf Helicopter Battery.

1. Turn the Storm-Wolf Helicopter off and charge the
Internal Storm-Wolf Helicopter Battery.

2. Replace the Tail Rotor with a new one included with
your Storm-Wolf Helicopter, or from the Storm-Wolf
Replacement Part Kit (available in stores)

3. Use light adhesive tape to mount a clip on the front
bottom of the Storm-Wolf Helicopter to add weight and
adjust the center of gravity. See also “Storm-Wolf
Helicopter doesn’t hover” issue.

PLEASE! DO NOT RETURN THIS

PLEASE! DO NOT RETURN THIS

PRODUCT TO ANY RETAIL STORE!

PRODUCT TO ANY RETAIL STORE!

For any questions or problems with this product please contact us at:

Email: [e-mail]

Phone: Inside North America: [phone]

Outside North America: 1-866-214-2220

Address: Interactive Toy Concepts,

17 Vulcan Street, Toronto, Ontario, Canada. M9W 1L3

Web site: www.interactivetoy.com

Limited 30-day warranty

Product is warranted by Interactive Toy Concepts Limited against
manufacturing defects in material and workmanship under normal use
for (30) days from the date of purchase.

Warranty is validated upon receipt of proof or purchase
and confirmation of UPC code.

BladeRunner is a registered trademark of Interactive Toy Concepts Ltd. © 2011 All Rights Reserved.

Storm-Wolf is a trademark of Interactive Toy Concepts Ltd. © 2011.

Manufactured by and distributed by Interactive Toy Concepts Ltd. Conforms to Safety Standards ASTM F963-03 Regulatory Requirements.

Products and colors may vary. MADE IN CHINA.

Proof of Purchase

INS-55078-110614-US

INSTRUCTION MANUAL

INSTRUCTION MANUAL

UNPACKING YOUR BLADERUNNER STORMWOLF HELICOPTER:

WARNING: The Storm-Wolf is a delicate machine, before removing it from the packaging please read the
instructions! To prevent damage during shipping, the Storm-Wolf is securely fastened in the package.
Please ensure that all of the tie-down and fastening locations are unfastened before attempting to remove
the Storm-Wolf Helicopter from the package. Be very careful when removing the Storm-Wolf to prevent
damaging the Helicopter.

COMPLETE PACKAGE CONTENTS AND COMPONENT BREAKDOWN:

1. BladeRunner Storm-Wolf Helicopter

2. IR Controller

3. Instruction Manual

4. 1 Replacement Tail Rotor

IR Control Emitter Window

Left Stick

- Up / Down - Throttle

Charge

LED

Charge Cable

Compartment Door

Trim Control Knob

Right Stick

- Left / Right Steering
Direction Control

Power Button

and Power LED

LED Light

Landing Gear

Balance bar

Top Rotor

Bottom Rotor

On / Off Switch

(other side)

Charging Port

Tail Rotor

Tail Boom

Tail Motor

QUICK-START INSTRUCTIONS:

CHARGING THE BLADERUNNER STORM-WOLF HELICOPTER: -Contunied

FLYING THE STORM-WOLF HELICOPTER:

FLYING THE STORM-WOLF HELICOPTER: -Continued

1. The Storm-Wolf Helicopter needs to be charged once it is taken out of the box for the purposes of its first flight
for optimal performance. It is necessary to charge the Storm-Wolf Helicopter for all subsequent flights where the
Internal Battery has been depleted on the previous flight. Refer to the section “CHARGING YOUR BLADERUN­NER STORM-WOLF HELICOPTER” for further information on recharging.

2. Turn on the Storm-Wolf Helicopter once fully charged and the IR Controller once the 6 AA Batteries are
installed. Ensure that the Storm-Wolf Helicopter is positioned on a safe, sturdy, flat and level, indoor launching
surface.

3. Push the Left Stick all the way up and down to initialize the throttle control between the IR Controller and the
Storm-Wolf Helicopter.

4. Push the Left Stick up again gradually. The Main Rotors will start to spin and the Storm-Wolf Helicopter will lift
off the ground.

5. If the Storm-Wolf Helicopter's body is spinning in the air, adjust this by dialling the Trim Control knob to counter
the unwanted rotation.

6. Use the Right Stick to control the Forward, Reverse, and Left / Right steering of the Storm-Wolf Helicopter.

7. When finished flying, land your Storm-Wolf Helicopter by gently pushing the Left Stick all the way down.

IMPORTANT BATTERY INFORMATION:

Use only batteries recommended in this manual. Do not mix old and new batteries, different types of batteries,
standard, carbon zinc, alkaline or rechargeable batteries of different capacities. Battery installation should be
performed by an adult. Rechargeable batteries are only to be charged under adult supervision. Batteries should
not be left unattended during recharging. Please respect the correct polarity (-) or (+). Do not try to recharge
non-rechargeable batteries. Do not throw batteries into the fire. Replace all batteries of the same type/brand at
the same time. The supply terminals are not to be short-circuited. Remove exhausted batteries from the toy.
Remove batteries if the toy is not going to be played with for some time. Rechargeable batteries are to be
removed from the toy before they are charged. Never leave a battery unattended in the presence of children.
The BladeRunner Storm-Wolf requires 6 AA Batteries (sold separately) only.

INSTALLING BATTERIES:

Your Storm-Wolf Helicopter has a built-in, non-removable, non-replaceable, rechargeable Lithium-Polymer
battery. Do not tamper with this battery. Tampering with this battery is dangerous and will void the warranty.
The Storm-Wolf IR Controller requires 6 AA Batteries (sold separately). Install the Batteries as shown:

1. Unscrew the Retaining Screw on the bottom of the Battery Compartment Door using a Philips Screwdriver (not
included). Open the Battery Compartment door on the bottom of the IR controller.

2. Insert the 6 AA Batteries as shown. Make sure to respect the polarity.

3. Replace the Battery Compartment door and tighten the Retaining Screw with the Philips Screwdriver. Do not
over tighten.

CHARGING THE BLADERUNNER STORM-WOLF HELICOPTER:

The Storm-Wolf Helicopter is partially charged out of the box but it is recommended to charge your Storm-Wolf
Helicopter prior to its first flight for optimal performance. Once the Internal Battery is depleted after your first flight
and all subsequent flights, it will be necessary to recharge the Storm Wolf Helicopter. Your IR Controller also
serves a dual purpose as a Charger for your Storm-Wolf Helicopter. Follow the simple instructions directly below
to charge your Storm-Wolf Helicopter.

1. Ensure the Storm-Wolf Helicopter's On/Off Switch is in the OFF position. The LED at the bottom front of the
Storm-Wolf Helicopter will turn off when the Storm-Wolf Helicopter is turned off.

2. Locate the Charge Cable Compartment Door at the bottom front of the IR Controller. Place your thumb on the
grip area of the Charge Cable Compartment Door and slide down to completely remove it.

3. Once the Charge Cable Compartment Door is removed, the Charge Cable will be completely exposed. Pull
the Charge Cable out of the Charge Cable Compartment and pull it downwards gently.

Continued

4. Replace the Charge Cable Compartment Door back onto the IR Controller's Charge Cable Compartment,
ensuring that the Charge Cable is able to protrude through the small opening at the bottom of the Charge Cable
Compartment Door. Note, the small opening is just below the thumb grip area on the Charge Cable Compartment
Door. This way you will be able to have the Charge Cable exposed and you will not misplace your Charge Cable
Compartment Door.

5. Insert the Charge Cable's Connector onto the mating Charging Port located on the left side of the Storm-Wolf
Helicopter.

6. Press the Power Button on the IR Controller. The Power Button will light up in Red. the Green Charge LED
will also light up directly below the Power Button. Charging will start automatically. Note, the Red LED at the
bottom front of the Storm-Wolf helicopter will remain turned off during charging.
Charging will take 30 – 45 minutes for up to 5 minutes of flight.

7. Once the charging is complete, the green LED on the IR Controller will turn off.

8. Unplug the Charge Cable from the Storm-Wolf Helicopter. The Storm-Wolf Helicopter is now ready to fly.

9. Conceal the IR Controller's Charge Cable in its location behind the Charge Cable Compartment Door. Con­cealment of the Charge Cable is the reverse of steps 2, 3, and 4.

10. Unless you plan on flying your Storm-Wolf Helicopter right away, press the Power Button on the IR Controller
to turn it off. When the Red LED behind the Power Button goes out, you know the IR Controller is turned off.
Storm-Wolf IR Controller LED functions:

Red LED is On: Power Button is in "On" position.
Red LED is Off: Power Button is in "Off" position.
Green LED is ON: The Storm-Wolf Helicopter is charging.
Green LED is Flashing: The Storm-Wolf Helicopter is almost fully charged.
Green LED is OFF: The Storm-Wolf Helicopter is fully charged or is not connected
to the IR Controller's Charge Cable.

Storm-Wolf Helicopter LED Functions:

LED is off: Storm-Wolf Helicopter is turned off and is either charging or not charging. It is also possible that the
Storm-Wolf Helicopter is turned on, but the Internal Battery charge is depleted.
LED flashes rapidly: The Storm-Wolf Helicopter is turned on and is initializing its Gyro or the Internal Battery
charge is low.
LED is on: Storm-Wolf Helicopter is turned on.

CHARGE TIME VARIES BASED ON HELICOPTER’S INTERNAL BATTERY CHARGE CONDITIONS.
TYPICALLY AFTER A 5 MINUTE FLIGHT THE HELICOPTER WILL NEED A 30 – 45 MINUTE CHARGE.

YOU DO NOT NEED TO WAIT FOR THE CHARGE TO BE COMPLETE TO FLY. SHORTER CHARGE
TIMES = SHORTER FLIGHT TIMES. FOR THE LONGEST FLIGHT TIMES PLEASE LET THE STORM-WOLF
HELICOPTER FINISH ITS CHARGE CYCLE.

CHOOSING A FLYING LOCATION:

Please note that the Storm-Wolf Helicopter is intended to be flown indoors only. The Indoor flying area should
ideally be roughly 16’ x 16’ (5 meters x 5 meters) with the standard household ceiling height as a minimum. The
Infrared control range of your Storm-Wolf helicopter is up to 20’ (6 meters), and varies depending on interference
within the operational environment. The IR Controller uses a safe infrared beam to communicate with the Storm­Wolf Helicopter. An infrared beam is very similar to a beam of light so it is important to stay in visual range of the
Storm-Wolf Helicopter at all times during flight or control will be lost. When flying your Storm-Wolf Helicopter be
careful to avoid contact with any objects such as furniture, plants, electronics, and any other items which can
break easily. The Storm-Wolf Helicopter has Rotor Blades that spin at relatively high speeds and could potentially
damage some household objects. Avoid operating the Storm-Wolf Helicopter around pets or people, and espe­cially crowds. If the Storm-Wolf is stepped on or otherwise crushed, it will sustain damage that would not be
covered under warranty. Ensure that people around you are aware that you are playing with the Storm-Wolf
Helicopter. Be aware of changes in your operational environment and play safe!

WARNING:

The spinning Rotors of the Storm-Wolf Helicopter are capable of damaging or injuring plants, furniture, pets or
people so fly carefully.

WARNING:
Check the condition of all the rotor blades prior to each flight. Do not try to operate the Storm-Wolf Helicopter if
any Rotor Blade has been damaged. Broken or damaged rotor blades may have sharp edges or corners and
they will be spinning fast with a potential for injury! Flying the Storm-Wolf Helicopter with broken Rotor Blades
can also make the it fly in an unstable or uncontrollable manner. This may cause damage to furniture and other
property, as well as injury to plants, animals and people. Broken Rotor Blades can be easily replaced as
described in the “REPLACING DAMAGED ROTOR BLADES” section elsewhere in this Instruction Manual.

Once you have installed Batteries into your IR Controller and your Storm-Wolf Helicopter's Internal Battery has a
sufficient charge, you are ready to fly your Storm-Wolf Helicopter. Follow the steps below to start flying:

1. Slide the On / Off Switch on your Storm-Wolf Helicopter to the On position. The LED on the bottom front of the
Storm-Wolf Helicopter will turn on.

2. Position the Storm-Wolf Helicopter on a safe, sturdy, and level launching surface. The LED on the Helicopter
will flash on and off for a few seconds as the Storm-Wolf Helicopter's Gyro initiates itself.

3. Press the Power Button on the IR Controller. The Power LED will light up.

4. Push the Left Stick all the way up and then back down to initialize throttle control. This is a safety feature to
prevent accidental starts. The Storm-Wolf Helicopter will not move when you do this, but it will now be ready to
fly.

5. Push the Left Stick up again gradually. This will start the Top and Bottom Rotors spinning. The Storm-Wolf will
rise up off the ground and into the air. Increase or decrease throttle by pushing the Left Stick up and down. An
increase or decrease in throttle will result in an increase or decrease in altitude (height). Adjust the Left Stick until
you have reached your desired flight altitude.

-Push the Left Stick up to increase Throttle and gain altitude.

-Push the Left Stick down to decrease Throttle and lose altitude.

6. Once flying at the desired altitude the Storm-Wolf Helicopter may be spinning under the Main Rotors instead
of holding a heading. Adjust the Trim Control Knob so that the Storm-Wolf Helicopter body does not spin. Use
the below points as a guide for Trim Control adjustment.

-Dial the Trim Control Knob to the left if the body is spinning right (Clockwise)

-Dial the Trim Control Knob to the right if the body is spinning left (Counter Clockwise).

Many factors affect the Trim of the Storm-Wolf Helicopter such as Internal Battery condition, throttle setting and
Rotor Blade wear. It may be required to adjust the Trim Control Knob more than once during a flight. Once

trimmed, minor corrections can be managed using the steering control (Right Stick). See the "FLYING TIPS"
section for more information.

7. Steering your Storm-Wolf Helicopter is accomplished by pushing the Right Stick sideways, left or right.

-Push the Right Stick to the left to steer the Storm-Wolf Helicopter to the left.

-Push the Right Stick to the right to steer the Storm-Wolf Helicopter to the right.

WHEN THE HELICOPTER IS FLYING TOWARDS YOU, THE STEERING WILL APPEAR TO REVERSE.
WHEN YOU PUSH THE RIGHT STICK TO THE RIGHT, THE STORM-WOLF HELICOPTER WILL TURN TO
THE LEFT. WHEN YOU PUSH THE RIGHT STICK TO THE LEFT, THE STORM-WOLF HELICOPTER WILL
TURN TO THE RIGHT. THIS IS NORMAL AND JUST TAKES SOME PRACTICE TO CONTROL.

8. Forward and reverse control of your Storm-Wolf Helicopter is accomplished by pushing the Right Stick up and
down.

-Push the Right Stick up to make the Storm-Wolf Helicopter fly forward or increase forward speed.

-Push the Right Stick down to make the Storm-Wolf Helicopter fly backwards.

9. Congratulations! You are flying your Storm-Wolf Helicopter. Enjoy!

10. To land your Storm-Wolf Helicopter, gently and gradually push the Left Stick all the way down. This will slow
the rotation of the Main Rotors and the Storm-Wolf Helicopter will land. It is very important to NOT push the Left
Stick all the way down suddenly, as the Main Rotors will stop spinning instantly and the Storm-Wolf Helicopter will
fall and possibly sustain damage.

11 - A. To fly again, it may or may not be necessary to recharge your Storm-Wolf Helicopter, depending on the
charge that is remaining in the Storm-Wolf Helicopter’s Internal Lithium-Polymer Battery. Simply follow the steps
described in the “CHARGING YOUR BLADERUNNER STORM-WOLF HELICOPTER” section above, to recharge

your Storm-Wolf Helicopter.

11 - B. If you are finished playing, slide the Storm-Wolf Helicopter’s On / Off Switch to the Off position to turn it
off. Then turn off the IR Controller by pressing the Power Button.

FLYING TIPS!:

Altitude Control - the Left Stick Throttle Control is a digital proportional system, therefore fine movement of the
Left Stick will produce minor changes in the Storm-Wolf Helicopter’s altitude.

TAKE TIME TO PRACTICE CONTROLLING THE ALTITUDE AND GETTING ACCUSTOMED TO THE
THROTTLE SENSITIVITY.

Trimming - Once flying at the desired height, the Storm-Wolf Helicopter may be spinning under the Rotors instead
of holding a heading. Adjust the Trim Control Knob so that the Storm-Wolf Helicopter body does not spin. If the
Storm-Wolf Helicopter is spinning to the left (counter clockwise) when it shouldn’t, dial the Trim Control Knob to
the right (clockwise). If the Storm-Wolf Helicopter is spinning to the right (clockwise) when it shouldn’t, dial the
Trim Control Knob to the left (counter-clockwise).

MANY FACTORS AFFECT THE TRIM OF THE STORM-WOLF HELICOPTER SUCH AS INTERNAL BAT­TERY CONDITION, THROTTLE SLIDER SETTING AND WEAR ON THE ROTORS. IT MAY BE REQUIRED TO
ADJUST THE TRIM CONTROL KNOB MORE THAN ONCE DURING A FLIGHT. ONCE TRIMMED, MINOR
CORRECTIONS CAN BE MANAGED USING THE RIGHT STICK'S STEERING INPUTS IN CONJUNCTION
WITH THE TRIM CONTROL KNOB.

THE STORM-WOLF HELICOPTER SHOULD NEVER BE FLOWN WITH DAMAGED ROTOR BLADES.
FLYING THE STORM-WOLF HELICOPTER WITH DAMAGED ROTOR BLADES IS VERY DANGEROUS. SEE
“TROUBLESHOOTING” AND “REPLACING DAMAGED ROTOR BLADES” SECTIONS FOR MORE INFORMA­TION.

Forward Flight - The best forward flight motion is achieved by gently pushing the Right Stick up. Sharp or abrupt
movements can cause the Storm-Wolf Helicopter to "porpoise" or swing, but might be required to overcome a
slight wind or draft.

Direction Control - Direction Control convention is based as if you were sitting in the pilot's seat of the Storm-Wolf
Helicopter.

Control Reversal - When the Storm-Wolf Helicopter is flying towards you, the steering will appear to reverse. This
is normal and just takes some practice to control.

Infrared Control - The IR Controller uses a safe infrared beam to communicate flight instructions to the Storm­Wolf Helicopter. An infrared beam is very similar to a beam of light so it is important to stay in visual range of the
Storm-Wolf Helicopter at all times during flight or control will be lost.

REPLACING DAMAGED ROTOR BLADES:

In the event that your main Rotor Blades or Tail Rotor sustain damage, they are very easy to replace by following
these easy steps. (Note, replacement Main Rotor Blades not included, but can be purchased separately as part
of the Storm-Wolf Replacement Part Kit.) (Note, 1 replacement Tail Rotor is included, and additional Tail Rotors
can be purchased as part of the Storm-Wolf Replacement Kit.)
