Interactive Toy Concepts Heli Sphere User Manual

REPLACING DAMAGED ROTOR BLADES -Continued:

Main Rotor Blades (continued):

ISSUE:

TROUBLESHOOTING

CAUSE:

CORRECTIVE ACTION:

ISSUE:

TROUBLESHOOTING -Continued

CAUSE:

CORRECTIVE ACTION:

2. Pull the damaged Rotor Blade horizontally out and away from its location on the Hub Mount.

3. Install a new Rotor Blade in the same location on the Hub Mount by sliding it in horizontally. The holes for the screw have to align. It is very important that the correct Rotor Blade is installed as the Upper and Lower Main Rotor Blades may appear to be similar but are in fact very different. The HELI SPHERE Helicopter will not be able to fly if the incorrect Rotor Blades are installed.

4. Fasten the new Rotor Blade to its Hub Mount with the same tiny screw that was pulled out earlier. Do not over tighten the screw as the Rotor Blade needs to be able to spin freely inside its Hub Mount. Your HELI SPHERE Helicopter is ready to fly again!

Forward / Backward Control Rotor:

1. Locate the broken Forward / Backward Control Rotor on the top of the HELI SPHERE Helicopter’s Sphere-Cage.

2. Remove the broken Forward / Backward Control Rotor by gently pulling it off of the Forward / Backward Motor’s Axle Shaft.

3. Install the replacement Forward / Backward Control Rotor (Included with the HELI SPHERE) by sliding it onto the Forward / Backward Motor’s Axle Shaft in the reverse process as outlined in step 2.

4. Gently press down on the replacement Forward / Backward Control Rotor until it is firmly in place.

REPLACING THE BALANCE-BAR-TO-UPPER-ROTOR CONNECTOR:

REPLACING THE BALANCE BAR CONNECTORS:

There are 2 small Balance Bar Connectors which connect the Upper Rotor to the Balance Bar. In the event that either Balance Bar Connector becomes disconnected, broken, or lost, it will need to be reconnected or replaced. 2 replacements Balance Bar Connector are included with the HELI SPHERE Helicopter. Replacement Bar Connectors Connector also can be purchased separately as part of the HELI SPHERE Replacement Parts Kit. Replacement is easy with the following steps.

1. The Balance Bar Connector is attached by 2 simple ball joints. Remove the broken Balance Bar Connector by disconnecting it from the Upper Rotor Hub Mount and the Balance Bar and pull it away. Once removed, the ball joints will be exposed. A ball joint will be visible on both sides of the Upper Rotor Hub Mount, and a ball joint will

be visible on both sides of the Balance Bar. There will be a total of 4 ball joints visible!

2. Install the new Balance Bar Connector following the reverse of step 1. The Balance Bar Connector only needs to connect 2 of the 4 ball joints. The Balance Bar Connector must connect a set of ball joints that are in vertical alignment only. Gently but firmly press the Balance Bar Connector into position, connecting the Upper Rotor and the Balance Bar. The Balance Bar Connector will just snap into the 2 ball joints as shown.

STORING THE HELI SPHERE HELICOPTER:

It is a good idea to store the HELI SPHERE Helicopter, IR Controller and this Instruction Manual together so no components become misplaced or lost. Please respect the below points to extend the operational life of your HELI SPHERE Helicopter during storage.

1. Product may be damaged or performance may be adversely affected if the HELI SPHERE Helicopter is not properly stored.

2. Never place any items on top of any components of the HELI SPHERE Helicopter.

3. Always keep your HELI SPHERE Helicopter in a cool dry place. Do not allow your HELI SPHERE Helicopter to get wet as it is not water resistant.

4. Keep the HELI SPHERE Helicopter away from pets and other household animals.

5. Do not rest your HELI SPHERE Helicopter on any potential heat source such as electronic equipment or a radiator.

HELI SPHERE Helicopter will not start, LEDs on HELI SPHERE Helicopter are off.

HELI SPHERE Helicopter will not start, LEDs on HELI SPHERE Helicopter are ON.

HELI SPHERE Helicopter will not start, LEDs on HELI SPHERE Helicopter are flashing.

HELI SPHERE Helicopter is flying too high.

HELI SPHERE Helicopter is flying too low.

HELI SPHERE Helicopter doesn’t hover.

HELI SPHERE Helicopter doesn't fly forward fast enough.

HELI SPHERE Helicopter doesn’t fly backwards

HELI SPHERE Helicopter always turns.

1. HELI SPHERE Helicopter is not turned on.

2. Battery is not charged.

3. HELI SPHERE Helicopter was not set to off during charging.

4. Rotors locked for overload protection.

1. HELI SPHERE Helicopter's infrared link is not established with the IR Controller.

2. IR Controller is not turned on.

3. HELI SPHERE Helicopter’s battery is low.

1. Motor stall protection is activated.

2. HELI SPHERE Helicopter's Internal Battery power is low.

1. You need to reduce the Throttle Input.

1. Needs more power (Throttle Input).

2. The battery in the HELI SPHERE Helicopter is low.

1. The HELI SPHERE Helicopter drifts forwards/backwards.

1. The Internal Battery charge is getting low.

2. The Forward / Backward Rotor is damaged.

3. The HELI SPHERE Helicopter center of gravity is no longer correct.

4. The HELI SPHERE Helicopter is not designed for fast flight as it is an indoor toy.

1. The HELI SPHERE Helicopter only flies backwards briefly then spins to fly forward.

1. Trim Control is not set correctly.

2. The Main Rotor Blades have sustained damage / or wear from use.

1. Turn HELI SPHERE Helicopter on.

2. Charge Internal HELI SPHERE Helicopter Battery.

3. Ensure HELI SPHERE Helicopter is off and charge Internal HELI SPHERE Helicopter Battery.

4. Slide HELI SPHERE Helicopter's On / Off Switch to Off, then switch it On again.

1. Push Left Stick (Throttle) completely UP, then back DOWN to initialize infrared link and throttle control.

2. Turn on IR Controller.

3. Ensure HELI SPHERE Helicopter is off and charge Internal HELI SPHERE Helicopter Battery.

1. Reset the HELI SPHERE Helicopter by turning its power off and on.

2. Ensure the HELI SPHERE Helicopter is Off and recharge the Internal Battery.

1. Push the Left Stick (Throttle) gradually down.

1. Push the Left Stick (Throttle) gradually up.

2. Ensure the HELI SPHERE Helicopter is off and charge the Internal HELI SPHERE Helicopter Battery.

1. Push the right stick up or down to compensate and hold the HELI SPHERE Helicopter in position.

1. Turn the HELI SPHERE Helicopter off and charge the Internal HELI SPHERE Helicopter Battery.

2. Replace the Forward / Backward Rotor with a new one included with your HELI SPHERE Helicopter, or from the HELI SPHERE Replacement Part Kit (available in stores or online)

3. Use light adhesive tape to mount a clip on the front bottom of the HELI SPHERE Helicopter to add weight and adjust the center of gravity. See also “HELI SPHERE Helicopter doesn’t hover” issue.

4. If desired, add a small amount of weight to the bottom front area of the body by taping a paper clip or something similar in weight and size onto it. However, note that this will reduce the ability of the HELI SPHERE Helicopter to fly backwards.

1. Aerodynamics make flying backwards more difficult than flying forwards and this flight pattern is normal. Practice flying backward and control the left / right turning motion of the HELI SPHERE Helicopter to keep the rear of the HELI SPHERE pointed in the direction you desire.

1. Adjust the Trim Control Knob on the IR Controller.

2. Replace the damaged Rotor Blades! It is dangerous to fly with damaged Rotor Blades! Replacement Rotor Blades are not included, but can be purchased separately as part of the HELI SPHERE Replacement Part Kit.

The Main Rotor Blades spin erratically causing unpredictable flight characteristics.

1. The Balance Bar Connector is either broken or missing.

1. Install a new Balance Bar Connector using the instructions in the “REPLACING THE BALANCE BAR CONNECTOR” section. 2 Replacement Balance Bar Connectors are included and can also be purchased separately as part of the HELI SPHERE Replacement Part Kit.

IMPORTANT SAFETY INFORMATION

Keep the HELI SPHERE Helicopter away from face, eyes and hair at all times. Keep fingers away from moving rotors or propellers. Do not fly the HELI SPHERE Helicopter near or at other people or animals. Use caution when flying, make sure people around you know that you are playing with the HELI SPHERE Helicopter. Recommended for use indoors only in rooms without obstacles, breakable objects or fans. The IR Controller's built-in Charger provided in this package is for charging the HELI SPHERE Helicopter ONLY. Do not use any other source to charge the HELI SPHERE Helicopter. Do not attempt to overcharge your HELI SPHERE Helicopter. Do not attempt to charge any other products with the IR Controller's Charger. Any attempts to charge other products with the IR Controller's built-in Charger are strictly prohibited and will void the warranty! Follow the charging instructions provided in this Instruction Manual. Do not attempt to replace the Internal Lithium Polymer Rechargeable Battery inside the HELI SPHERE Helicopter! The HELI SPHERE Helicopter’s Lithium Polymer Rechargeable Internal Battery is sealed inside the unit and is not replaceable. Any attempts to replace the HELI SPHERE Helicopter's Lithium Polymer Rechargeable Internal Battery will void the warranty.

FCC NOTES

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These Limits are designed to provide reasonable protection against harmful interference in a residential installation. This generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turn the equipment off and on, the user is encouraged to try and correct the interference by one or

more of the following measures: •Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help.

PLEASE! DO NOT RETURN THIS PRODUCT TO ANY RETAIL STORE!

For any questions or problems with this product please contact us at:Email: info@interactivetoy.com

Phone: Inside North America: +1-416-444-6873 Outside North America: 1-866-214-2220

Address: Interactive Toy Concepts, 17 Vulcan Street, Toronto, Ontario, Canada. M9W 1L3 Website: www.interactivetoy.com

Limited 30-day warranty

Product is warranted by Interactive Toy Concepts Limited against manufacturing defects in material and workmanship under normal use for (30) days from the date of purchase.

Warranty is validated upon receipt of proof or purchase and confirmation of UPC code.

Manufactured by and distributed by Interactive Toy Concepts Ltd. Conforms to Safety Standards ASTM F963-03 Regulatory Requirements.

Products and colors may vary. MADE IN CHINA.

Proof of Purchase

INS-22008-130117-US

Welcome to the BladeRunner HELI SPHERE Helicopter. The HELI SPHERE brings advanced, 3-Channel, hobby-level flying technology to flyers who are looking for great performance from an indoor Helicopter. The HELI SPHERE has built-in advanced gyroscope

12+

Item# 22008

technology for providing an ultra-smooth flight and balance control assistance. In addition, the HELI SPHERE Helicopter has digital proportional control. The HELI SPHERE is available in Infrared Control Channels A and B. The compact and stylish design of the IR Controller has an integrated charging mechanism so that only 6 AA Batteries in total are required to charge and operate the HELI SPHERE Helicopter. Do not throw away this instruction manual as it contains valuable information for the operation of your HELI SPHERE Helicopter as well as warranty information. The helpful tips in this Instruction Manual will improve your skill and enhance your experience. Look for these symbols for extra help.

INSTRUCTION MANUAL

UNPACKING YOUR BLADERUNNER HELI SPHERE HELICOPTER:

WARNING:The HELI SPHERE is a delicate machine, before removing it from the packaging please read the instructions! To prevent damage during shipping, the HELI SPHERE is securely fastened in the package. Please ensure that all of the tie-down and fastening locations are unfastened before attempting to remove the HELI SPHERE Helicopter from the package. Be very careful when removing the HELI SPHERE to prevent damaging the Helicopter.

COMPLETE PACKAGE CONTENTS AND COMPONENT BREAKDOWN:

1. BladeRunner HELI SPHERE Helicopter

2. IR Controller

3. Instruction Manual

4. 1 Replacement Forward / Backward Rotor

5. 2 Replacement Balance Bar Connectors

IR Control Emitter Window

Left Stick

- Up / Down - Throttle

Charge

LED

Charge Cable

Compartment Door

Replacement Forward

/ Backward Rotor

Trim Control Knob

Right Stick

- Left / Right Steering Direction Control

Power Button

and Power LED

Balance Bar

Connector

2 Replacement

Balance Bar Connectors

Sphere-cage

Bottom Rotor

LED Lights

Charge Port

Forward / Backward Rotor

Forward / Backward

Motor

Top Rotor

Balance Bar

On/Off Switch

QUICK-START INSTRUCTIONS:

CHARGING THE BLADERUNNER HELI SPHERE HELICOPTER: -Contunied

FLYING THE HELI SPHERE HELICOPTER:

FLYING THE HELI SPHERE HELICOPTER: -Continued

1. The HELI SPHERE Helicopter needs to be charged once it is taken out of the box for optimal performance. It is necessary to charge the HELI SPHERE Helicopter for all subsequent flights where the Internal Battery has been depleted on the previous flight. Refer to the section “CHARGING YOUR BLADERUNNER HELI SPHERE HELICOPTER” for further information on recharging.

2. Turn on the HELI SPHERE Helicopter once fully charged and the IR Controller once the 6 AA Batteries are installed. Ensure that the HELI SPHERE Helicopter is positioned on a safe, sturdy, flat and level, indoor launching surface.

3. Push the Left Stick all the way up and down to initialize the throttle control between the IR Controller and the HELI SPHERE Helicopter.

4. Push the Left Stick up again gradually. The Main Rotors will start to spin and the HELI SPHERE Helicopter will lift off the ground.

5. If the HELI SPHERE Helicopter's body is spinning in the air, adjust this by dialling the Trim Control knob to counter the unwanted rotation.

6. Use the Right Stick to control the Forward, Reverse, and Left / Right steering of the HELI SPHERE Helicopter.

7. When finished flying, land your HELI SPHERE Helicopter by gently pushing the Left Stick all the way down.

IMPORTANT BATTERY INFORMATION:

Use only batteries recommended in this instruction manual. Do not mix old and new batteries. Do not mix alkaline, standard, lithium, rechargeable, or different types of batteries. Do not use rechargeable batteries. Be careful to install the batteries with the correct polarity, as indicated. Battery should be replaced by adults. Rechargeable batteries are only to be charged under adult supervision. Never leave a battery unattended while it is being charged. Never leave a battery unattended in the presence of children. Non-rechargeable batteries are not to be recharged. Rechargeable batteries are to be removed from the toy before being charged. Do not throw batteries into the fire. Exhausted batteries are to be removed from the toy. The supply terminals are not to be shortcircuited. The Controller uses 6 AA Batteries (sold separately).

INSTALLING BATTERIES:

The HELI SPHERE IR Controller requires 6 AA Batteries (sold separately). Install the Batteries as shown:

1. Unscrew the Retaining Screw on the bottom of the Battery Compartment Door using a Philips Screwdriver (not included). Open the Battery Compartment door on the bottom of the IR controller.

2. Insert the 6 AA Batteries as shown. Make sure to respect the polarity.

3. Replace the Battery Compartment door and tighten the Retaining Screw with the Philips Screwdriver. Do not over tighten.

CHARGING THE BLADERUNNER HELI SPHERE HELICOPTER:

The HELI SPHERE Helicopter is partially charged out of the box but it is recommended to charge your HELI SPHERE Helicopter prior to its first flight for optimal performance. Once the Internal Battery is depleted after your first flight and all subsequent flights, it will be necessary to recharge the HELI SPHERE Helicopter. Your IR Controller also serves as Charger for your HELI SPHERE Helicopter. Follow the simple instructions directly below to charge your HELI SPHERE Helicopter.

1. Ensure the HELI SPHERE Helicopter's On/Off Switch is in the OFF position. The LEDs at the front of the HELI SPHERE Helicopter will turn off when the HELI SPHERE Helicopter is turned off.

2. Locate the Charge Cable Compartment Door at the bottom front of the IR Controller. Place your thumb on the grip area of the Charge Cable Compartment Door and slide down to completely remove it.

3. Once the Charge Cable Compartment Door is removed, the Charge Cable will be completely exposed. Pull the Charge Cable out of the Charge Cable Compartment and pull it downwards gently.

4. Replace the Charge Cable Compartment Door back onto the IR Controller's Charge Cable Compartment, ensuring that the Charge Cable is able to protrude through the small opening at the bottom of the Charge Cable Compartment Door. Note, the small opening is just below the thumb grip area on the Charge Cable Compartment Door. This way you will be able to have the Charge Cable exposed and you will not misplace your Charge Cable Compartment Door.

Continued

5. Insert the Charge Cable's Connector onto the mating Charging Port located on the bottom of the HELI SPHERE Helicopter.

6. Press the Power Button on the IR Controller. The Power Button will light up in Red. the Green Charge LED will also light up. Charging will start automatically. Note, the Red LEDs at the front of the HELI SPHERE helicopter will remain turned off during charging.

Charging will take 30 – 45 minutes for up to 5 minutes of flight.

7. Once the charging is complete, the green LED on the IR Controller will turn off.

8. Unplug the Charge Cable from the HELI SPHERE Helicopter. The HELI SPHERE Helicopter is now ready to fly.

9. Conceal the IR Controller's Charge Cable in its location behind the Charge Cable Compartment Door. Concealment of the Charge Cable is the reverse of steps 2, 3, and 4.

10. Unless you plan on flying your HELI SPHERE Helicopter right away, press the Power Button on the IR Controller to turn it off.

CHARGE PORT AND ON/OFF SWITCH

HELI SPHERE IR Controller LED Functions: Red LED is On: Power Button is in "On" position. Red LED is Off: Power Button is in "Off" position. Green LED is ON: The Heli Sphere Helicopter is charging. Green LED is OFF: The Heli Sphere Helicopter is fully

charged or is not connected to the IR Controller's Charge Cable.

HELI SPHERE Helicopter LED Functions:

Charge Port

On/Off Switch

HELI SPHERE UNDERSIDE

LEDs are off: HELI SPHERE Helicopter is turned off and is either charging or not charging. It is also possible that the HELI SPHERE

Helicopter is turned on, but the Internal Battery charge is depleted.

LEDs flash rapidly: The HELI SPHERE Helicopter is turned on and is initializing its Gyro or the Internal Battery charge is low. LEDs are on: HELI SPHERE Helicopter is turned on.

CHARGE TIME VARIES BASED ON HELICOPTER’S INTERNAL BATTERY CHARGE CONDITIONS. TYPICALLY AFTER A 5 MINUTE FLIGHT THE HELICOPTER WILL NEED A 30 – 45 MINUTE CHARGE.

YOU DO NOT NEED TO WAIT FOR THE CHARGE TO BE COMPLETE TO FLY. SHORTER CHARGE TIMES = SHORTER FLIGHT TIMES. FOR THE LONGEST FLIGHT TIMES PLEASE LET THE HELI SPHERE HELICOPTER FINISH ITS CHARGE CYCLE.

CHOOSING A FLYING LOCATION:

Please note that the HELI SPHERE Helicopter is intended to be flown indoors only. The Indoor flying area should ideally be roughly 16’ x 16’ (5 meters x 5 meters) with the standard household ceiling height as a minimum. The Infrared control range of your HELI SPHERE helicopter is up to 20’ (6 meters), and varies depending on interference within the operational environment. The IR Controller uses a safe infrared beam to communicate with the HELI SPHERE Helicopter. An infrared beam is very similar to a beam of light so it is important to stay in visual range of the HELI SPHERE Helicopter at all times during flight or control will be lost. When flying your HELI SPHERE Helicopter be careful to avoid contact with any objects such as furniture, plants, electronics, and any other items which can break easily. The HELI SPHERE Helicopter has Rotor Blades that spin at relatively high speeds and could potentially damage some household objects. Avoid operating the HELI SPHERE Helicopter around pets or people, and especially crowds. If the HELI SPHERE is stepped on or otherwise crushed, it will sustain damage that would not be covered under warranty. Ensure that people around you are aware that you are playing with the HELI SPHERE Helicopter. Be aware of changes in your operational environment and play safe!

WARNING: The spinning Rotors of the HELI SPHERE Helicopter are capable of damaging or injuring plants, furniture, pets or people so fly carefully.

WARNING: Check the condition of all the rotor blades prior to each flight. Do not try to operate the HELI SPHERE Helicopter if any Rotor Blade has been damaged. Broken or damaged rotor blades may have sharp edges or corners and they will be spinning fast with a potential for injury! Flying the HELI SPHERE Helicopter with broken Rotor Blades can also make the it fly in an unstable or uncontrollable manner. This may cause damage to furniture and other property, as well as injury to plants, animals and people. Broken Rotor Blades can be easily replaced as described in the “REPLACING DAMAGED ROTOR BLADES” section elsewhere in this Instruction Manual.

Once you have installed Batteries into your IR Controller and your HELI SPHERE Helicopter's Internal Battery has a sufficient charge, you are ready to fly your HELI SPHERE Helicopter. Follow the steps below to start flying:

1. Slide the On / Off Switch on your HELI SPHERE Helicopter to the On position. The LEDs on the front of the HELI SPHERE Helicopter will turn on and will be flashing on and off for a few seconds as the HELI SPHERE Helicopter's Gyro initiates itself.

2. Position the HELI SPHERE Helicopter on a flat, safe, sturdy, and level launching surface. After a few seconds the LEDs on the HELI SPHERE Helicopter will stop flashing and will be on continuously.

3. Press the Power Button on the IR Controller. The Power LED will start flashing on and off.

4. Push the Left Stick all the way up and then back down to initialize throttle control. This is a safety feature to prevent accidental starts. The HELI SPHERE Helicopter will not move when you do this, but it will now be ready to fly. The LED on the IR Controller will stop flashing and will be on continuously.

5. Push the Left Stick up again gradually. This will start the Top and Bottom Rotors spinning. The HELI SPHERE will rise up off the ground and into the air. Increase or decrease throttle by pushing the Left Stick up and down. An increase or decrease in throttle will result in an increase or decrease in altitude (height). Adjust the Left Stick until you have reached your desired flight altitude

-Push the Left Stick up to increase Throttle and gain altitude.

-Push the Left Stick down to decrease Throttle and lose altitude.

6. Once flying at the desired altitude, the HELI SPHERE Helicopter may be spinning under the Main Rotors instead of holding a heading. Adjust the Trim Control Knob so that the HELI SPHERE Helicopter body does not spin. Use the below points as a guide for Trim Control adjustment.

-Dial the Trim Control Knob to the left if the body is spinning right (Clockwise)

-Dial the Trim Control Knob to the right if the body is spinning left (Counter Clockwise).

Many factors affect the Trim of the HELI SPHERE Helicopter such as Internal Battery condition, throttle setting and Rotor Blade wear. It may be required to adjust the Trim Control Knob more than once during a flight. Once

trimmed, minor corrections can be managed using the steering control (Right Stick). See the "FLYING TIPS" section for more information.

7. Steering your HELI SPHERE Helicopter is accomplished by pushing the Right Stick sideways, left or right.

-Push the Right Stick to the left to steer the HELI SPHERE Helicopter to the left.

-Push the Right Stick to the right to steer the HELI SPHERE Helicopter to the right.

WHEN THE HELICOPTER IS FLYING TOWARDS YOU, THE STEERING WILL APPEAR TO REVERSE. WHEN YOU PUSH THE RIGHT STICK TO THE RIGHT, THE STORM-WOLF HELICOPTER WILL TURN TO THE LEFT. WHEN YOU PUSH THE RIGHT STICK TO THE LEFT, THE STORM-WOLF HELICOPTER WILL TURN TO THE RIGHT. THIS IS NORMAL AND JUST TAKES SOME PRACTICE TO CONTROL.

8. Forward and reverse control of your HELI SPHERE Helicopter is accomplished by pushing the Right Stick up and down.

-Push the Right Stick up to make the HELI SPHERE Helicopter fly forward or increase forward speed.

-Push the Right Stick down to make the HELI SPHERE Helicopter fly backwards.

9. To land your HELI SPHERE Helicopter, gently and gradually push the Left Stick all the way down. This will slow the rotation of the Main Rotors and the HELI SPHERE Helicopter will land. It is very important to NOT push the Left Stick all the way down suddenly, as the Main Rotors will stop spinning instantly and the HELI SPHERE Helicopter will fall and possibly sustain damage.

10 - A. To fly again, it may or may not be necessary to recharge your HELI SPHERE Helicopter, depending on the charge that is remaining in the HELI SPHERE Helicopter’s Internal Lithium-Polymer Battery. Simply follow the steps described in the “CHARGING YOUR BLADERUNNER HELI SPHERE HELICOPTER” section above, to recharge your HELI SPHERE Helicopter.

10 - B. If you are finished playing, slide the HELI SPHERE Helicopter’s On / Off Switch to the Off position to turn it off. Then turn off the IR Controller by pressing the Power Button.

FLYING TIPS!:

Altitude Control - the Left Stick Throttle Control is a digital proportional system, therefore fine movement of the Left Stick will produce minor changes in the HELI SPHERE Helicopter’s altitude.

TAKE TIME TO PRACTICE CONTROLLING THE ALTITUDE AND GETTING ACCUSTOMED TO THE THROTTLE SENSITIVITY.

Trimming - Once flying at the desired height, the HELI SPHERE Helicopter may be spinning under the Rotors instead of holding a heading. Adjust the Trim Control Knob so that the HELI SPHERE Helicopter body does not spin. If the HELI SPHERE Helicopter is spinning to the left (counter clockwise) when it shouldn’t, dial the Trim Control Knob to the right (clockwise). If the HELI SPHERE Helicopter is spinning to the right (clockwise) when it shouldn’t, dial the Trim Control Knob to the left (counter-clockwise).

MANY FACTORS AFFECT THE TRIM OF THE HELI SPHERE HELICOPTER SUCH AS INTERNAL BATTERY CONDITION, THROTTLE SLIDER SETTING AND WEAR ON THE ROTORS. IT MAY BE REQUIRED TO ADJUST THE TRIM CONTROL KNOB MORE THAN ONCE DURING A FLIGHT. ONCE TRIMMED, MINOR CORRECTIONS CAN BE MANAGED USING THE RIGHT STICK'S STEERING INPUTS IN CONJUNCTION WITH THE TRIM CONTROL KNOB.

THE HELI SPHERE HELICOPTER SHOULD NEVER BE FLOWN WITH DAMAGED ROTOR BLADES. FLYING THE HELI SPHERE HELICOPTER WITH DAMAGED ROTOR BLADES IS VERY DANGEROUS. SEE “TROUBLESHOOTING” AND “REPLACING DAMAGED ROTOR BLADES” SECTIONS FOR MORE INFORMATION.

Forward Flight - The best forward flight motion is achieved by gently pushing the Right Stick up. Sharp or abrupt movements can cause the HELI SPHERE Helicopter to "porpoise" or swing, but might be required to overcome a slight wind or draft.

Direction Control - Direction Control convention is based as if you were sitting in the pilot's seat of the HELI SPHERE Helicopter.

Control Reversal - When the HELI SPHERE Helicopter is flying towards you, the steering will appear to reverse. This is normal and just takes some practice to control.

Infrared Control - The IR Controller uses a safe infrared beam to communicate flight instructions to the HELI SPHERE Helicopter. An infrared beam is very similar to a beam of light so it is important to stay in visual range of the HELI SPHERE Helicopter at all times during flight or control will be lost.

REPLACING DAMAGED ROTOR BLADES:

In the event that your main Rotor Blades or Forward / Backward Rotor sustain damage, they are very easy to replace by following these easy steps. (Note, replacement Main Rotor Blades not included, but can be purchased separately as part of the HELI SPHERE Replacement Part Kit.)

Main Rotor Blades:

1. Locate the broken Rotor Blade and use a fine Philips screw-driver (not included) to unscrew the tiny screw that holds the Rotor Blade in place on the Hub Mount. Be careful not to lose the screw as it is tiny.

Interactive Toy Concepts Heli Sphere User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
