The B-2® Spirit RC plane is a delicate machine. Before removing it from the packaging please read the instructions.
WARNING!
WARNING!
AGE 12+
AGE 12+
INSTRUCTION MANUAL
INSTRUCTION MANUAL
Congratulations on the purchase of your new B-2® Spirit Bomber RC Plane from Interactive Toy Concepts! The B-2® Spirit is the world’s premier bomber.
bomber capable of carrying large air-to-surface standoff weapons while under stealth configuration. Your RC version of the B-2® Spirit is designed for easy flight
with a short learning curve! The B-2® Spirit RC plane is available in two frequencies, 27MHz and 49MHz. Before taking to the
plane from Interactive Toy Concepts, please read through the instructions outlined in this manual.
GET IN THE AIR FAST!
GET IN THE AIR FAST!
CHARGE YOUR B-2® SPIRIT
CHARGE YOUR B-2® SPIRIT
Before flying, you will need to charge your plane.
Turn off your plane and the charger. Plug in the
charger (with 4 C-size batteries) into the bottom
of your plane and turn it on. Charging will start
immediately. Let your plane charge until the green
light on the charger goes out. It will take 30 to 60 minutes.
FLYING YOUR B-2® SPIRIT
FLYING YOUR B-2® SPIRIT
Once fully charged your plane will be ready to fly
outdoors in a safe grassy area with very moderate
conditions or a gentle breeze. Make sure your
controller has the antenna screwed in and fully
extended, and the 9-Volt battery correctly installed.
Turn on your plane and the controller. Hold the plane
firmly in one hand, and move the left stick all the way
up and down to initialize the throttle control. Move
the left stick (throttle) up and down again to make
sure that both propellers are working. Once you
are sure that the plane is working correctly, move
the left stick up to the maximum position and gently
toss the plane into the wind. Way to go! You are now flying!
3
SPEED AND ALTITUDE CONTROL
SPEED AND ALTITUDE CONTROL
To increase speed and altitude as desired, add more
throttle with the left stick. To slow down and land,
gently reduce the throttle input with the left stick.
LEFT AND RIGHT TURNS
LEFT AND RIGHT TURNS
To turn left and right, move the right stick from
sideways left or right.
Tip!
TRIMMING YOUR B-2® SPIRIT
TRIMMING YOUR B-2® SPIRIT
If you find that your plane is veering to the left or to the
right without any steering inputs, you can compensate
for this by rotating the trim knob to the left or right
as needed.
UNPACKING YOUR B-2®SPIRIT RC PLANE
UNPACKING YOUR B-2®SPIRIT RC PLANE
To prevent damage during shipping the B-2® Spirit is securely fastened
in the package. Please ensure that all of the fastening locations are
released before attempting to remove the B-2® Spirit. Be very careful
when removing the B-2® Spirit to prevent damaging it. While it is a state
of the art precision instrument, it is also a delicate device.
INS-44070-101215-US
