CS-840
CueServer Pro DIN
Overview
CueServer provides the most comprehensive combination
of stand-alone show playback, architectural features, show
control and web-based integration in a single, easy-to-use
package.
CueServer is a unique lighting control solution. At it’s heart,
it’s an Ethernet-based lighting console with all of it’s controls
accessible via easy to use built-in web pages. Additionally,
CueServer is a powerhouse of stand-alone, architectural and
show control features that can be mixed together to produce
elaborate playback systems.
CueServer is perfect for many lighting control applications,
such as LED displays, architectural lighting, retail projects,
museum attractions, theme parks, trade show exhibits,
sign animation, churches, water fountains and much more.
CueServer easily scales from the smallest single-xture project to large-scale networked solutions.
CueServer provides features not found in other lighting playback devices such as complete web-based operation, which means that nearly
any PC, Mac or even your iPhone® or iPad® can connect to CueServer and turn it into a full-featured wireless lighting console or remote
focus tool.
Use CueServer as a simple stand-alone playback controller, or as an architectural lighting processor, or as a show controller or even a
wireless remote lighting console. CueServer is an elegant platform for exible lighting control that can be customized to suit the needs of
system integrators, lighting technicians, consultants, show programmers, automation experts and more.
Features
• Completely self-contained lighting playback controller
• Seamlessly handles static scenes, crossfading and real-time
“streamed” DMX playback
• Web enabled “live” programming and operation
• Powerful CueScript scripting language
• Handles up to 4 independent timelines
• Locally program lighting scenes or snapshot from external
consoles
• Network multiple CueServer units together to control a large
number of channels or devices
• Synchronize playback to MIDI Timecode or SMPTE (via MTC)
• On-board real-time clock with astronomical functions and
365-day calendar events
• System integration via Ethernet, RS-232, Digital I/O and MIDI
• Easily interfaces with Crestron®, AMX®, Vantage® and
other automation systems
• Huge onbord memory and removable memory card
Applications
• Commercial
• Residential
• Architectural Lighting
• Entertainment Lighting
• Trade Shows
• Themed Entertainment
• Museum
• Building Management
Interactive Technologies, Inc.
5040 Magnolia Creek Drive
Cumming, GA 30028 USA
678-455-9019 (Phone)
678-455-9071 (Fax)
Catalog #: Project:
Prepared by: Date:
Specications
Ordering
Feature Detail Description
Capacity Playbacks 4
Cues 2000 (numbered 0.1 thru 6499.9)
Groups 100
Macros 200
Timers 100
DMX Input Triggers 256
Timecode Events 500
TCP/UDP Triggers 16
External CueStation Buttons 512
External Contect Closures 512
Protocols Ethernet UDP, TCP, HTTP, XML, Telnet, SNTP, CueScript,
CueStation
RS-232 User-Dened ASCII, CueScript, CueStation
Connections Power 2-Position Terminal Block or
2.1 mm DC Power Input Jack
Network RJ-45, 10/100 Base-T Ethernet
I/O 3 10-Position Pluggable Terminal Blocks provid-
ing signals for DMX Input, DMX Output, RS-232,
8 Contact Closure Inputs, 8 Low-Voltage Outputs,
Regulated 5V DC and Ground
User Interface LCD 40 Character x 2 Line (Black on White)
Menu Buttons Menu, Up, Down & Enter
Function Buttons 8 User-Programmable Function Buttons with LEDs
Power Input 6-30V DC (12V DC Nominal), 800mA @ 12V DC
Memory Internal 32 MB Flash
External xD Card Slot (128 MB Maximum)
Realtime Clock Standard Battery-backed, 1 second resolution
Event Triggers Time of day, day of week, day of month, date range,
astronomical time (relative to sunrise or sunset +/specied offset)
Physical Width 4.1” (104 mm)
Length 8.0” (204 mm)
Height 2.1” (54 mm)
Weight 1.0 lbs. (0.45 Kg)
Environmental Operating Temperature -40° to 158° F (-40° to 70° C) without optional xD
ash card, LCD may temporarily freeze
-4° to 158° F (-20° to 70°C) without optional xD ash
card installed
32° to 158° F (0° to 70° C) with optional xD ash
card installed
Storage Temperature -40° to 176° F (-40° to 80°C)
Humidity 5 to 95%, non-condensing
Altitude 10,000 feet maximum
CS-840 CueServer Pro DIN
(power supply not included)
Accessories
AC-12 12VDC Power Supply
AC-12-EURO 12VDC Supply (UK/Euro)
AC-12-AUST 12VDC Supply (Australia)
© 2011 Interactive Technologies, Inc. Interactive reserves the right to modify this document and/or the product(s) it describes without notice. In no event shall Interactive be liable
for incidental or consequential damages, or for the infringement of any patent rights or third party rights, due to the use of its products. D0458C 2/23/2012
