INTENSO TAB 814

V1.2

DE - 1

Bedienungsanleitung TAB 814

Vielen Dank, dass Sie sich für das TAB814 entschieden haben. Folgen Sie bitte dieser Anleitung, um
über die wichtigsten Funktionen des Gerätes informiert zu werden.

1.) Inhaltsverzeichnis

1.) Inhaltsverzeichnis .................................................................................................................................................................................. 1

2.) Hinweise ................................................................................................................................................................................................ 2

3.) Geräteüberblick ..................................................................................................................................................................................... 4

4.) Packungsinhalt ...................................................................................................................................................................................... 4

5.) Laden des Akkus ................................................................................................................................................................................... 5

6.) Nutzung einer Micro SD/SDHC Karte .................................................................................................................................................... 5

7.) Übertragung von Daten zwischen dem Gerät und einem Computer ..................................................................................................... 5

8.) Touchscreen .......................................................................................................................................................................................... 6

9.) Der Startbildschirm ................................................................................................................................................................................ 7

Ansicht ........................................................................................................................................................................................................ 7

Entsperren des Displays ............................................................................................................................................................................. 7

Statusleiste ................................................................................................................................................................................................. 8

Anpassung des Startbildschirms ................................................................................................................................................................. 8

Verschiedene Startbildschirme nutzen........................................................................................................................................................ 9

Vorinstallierte Anwendungen auf dem Startbildschirm ................................................................................................................................ 9

a) Suchleiste für die Google™ Suche ....................................................................................................................................................... 10

b) Anwendungsübersicht .......................................................................................................................................................................... 10

c) Wettervorschau ..................................................................................................................................................................................... 11

d) WIFI ...................................................................................................................................................................................................... 11

Automatische Verbindung ......................................................................................................................................................................... 11

Manuelle Verbindung ................................................................................................................................................................................ 12

e) Galerie .................................................................................................................................................................................................. 12

f) Musik ..................................................................................................................................................................................................... 13

g) Video .................................................................................................................................................................................................... 15

h) App Center ........................................................................................................................................................................................... 15

i) Web Browser ......................................................................................................................................................................................... 15

Nutzung der virtuellen Tastatur ................................................................................................................................................................. 15

Eingabe von Sonderzeichen ..................................................................................................................................................................... 16

Nutzung des Web Browsers ..................................................................................................................................................................... 16

j) Anwendungsübersicht............................................................................................................................................................................ 17

k) System Einstellungen ........................................................................................................................................................................... 17

Einstellungsübersicht ................................................................................................................................................................................ 18

10.) E-Book ............................................................................................................................................................................................... 19

Kopieren von E-Books zwischen Computer und Gerät ............................................................................................................................. 19

Download von E-Books und Übertragung auf das Gerät mit Hilfe von Adobe™ Digital Editions .............................................................. 19

Lesen starten ................................................................................................................................ ............................................................ 20

Wechsel zwischen Regalansicht und Listenansicht / Löschen von Ebooks ............................................................................................. 20

Seiten umblättern ...................................................................................................................................................................................... 21

Vergrößern der Schriftgröße ................................................................................................................................................................ ..... 21

Sprung zu einer bestimmten Seite ............................................................................................................................................................ 21

Nutzen von Lesezeichen........................................................................................................................................................................... 21

Anzeige des Inhaltsverzeichnisses ........................................................................................................................................................... 21

Anzeige der Buchinformation .................................................................................................................................................................... 21

11.) Versand / Empfang von E-Mails ........................................................................................................................................................ 22

Einrichtung Ihres E-Mail Postfaches ......................................................................................................................................................... 22

Verwaltung der E-Mail Accounts ............................................................................................................................................................... 23

Anzeige von E-Mail Nachrichten ............................................................................................................................................................... 23

Schreiben von E-Mail Nachrichten ............................................................................................................................................................ 23

12.) Verwaltung von Anwendungen .......................................................................................................................................................... 24

Installation von Anwendungen .................................................................................................................................................................. 24

DE - 2

Deinstallation von Anwendungen .............................................................................................................................................................. 24

13.) Lesen von Office Dokumenten .......................................................................................................................................................... 25

14.) Task Manager .................................................................................................................................................................................... 25

15.) Eingeschränkte Garantiebedingungen............................................................................................................................................... 26

16.) Technische Daten .............................................................................................................................................................................. 27

17.) Wartung des Gerätes ......................................................................................................................................................................... 27

18.) Säuberung des Gerätes ..................................................................................................................................................................... 27

19.) Entsorgung von Elektro-Altgeräten .................................................................................................................................................... 27

20.) Lizenzinformation............................................................................................................................................................................... 28

EG Konformitätserklärung ............................................................................................................................................................................ 32

Dieses Handbuch enthält unter Umständen nicht alle Funktionen Ihres Gerätes. Für die Nutzung von Anwendungen die von
Drittanbietern stammen, kontaktieren Sie bitte den Anbieter. Bitte beachten Sie, dass alle Angaben ohne vorherige
Ankündigung geändert werden können. Aktuelle Informationen finden Sie unter www.intenso.de

Markenzeichen

Google™, das Google™-Logo und Android™ sind Marken von Google™. Alle anderen Produkt- oder Servicenamen sind
Eigentum ihrer jeweiligen Inhaber.

2.) Hinweise

 Vermeiden Sie einen harten Aufprall des Gerätes. Legen Sie es nicht auf schräge Flächen, um

einen Sturz des Gerätes zu vermeiden.

 Verwenden Sie das Gerät nicht in extrem kalten, heißen, feuchten oder staubigen Gebieten.

Setzen Sie es ebenfalls keinen direkten Sonnenstrahlen aus.

 Vermeiden Sie die Nutzung auf sandigen Plätzen.
 Verwenden Sie das Gerät nicht in explosionsgefährdeten Umgebungen, wie zum Beispiel an

den Zapfsäulen einer Tankstelle.

 Vermeiden Sie die Benutzung auf Kissen, Sofas oder anderen Gegenständen, die eine

Wärmeentwicklung unterstützen, da die Gefahr einer Überhitzung des Gerätes besteht.

 Führen Sie häufiger Datensicherungen durch, um einen möglichen Datenverlust zu vermeiden.

Wir sind nicht haftbar für einen eventuellen Datenverlust.

 Trennen Sie die Verbindung nicht, wenn Daten übertragen werden oder das Gerät formatiert

wird. Dies kann zu Datenverlust führen.

 Bilder und Filme können durch Rechte Dritter geschützt sein. Das Abspielen ohne Lizenz kann

Copyright Rechte verletzen.

 Vermeiden Sie das Benutzen in stark magnetisierten Feldern.
 Schützen Sie das Gerät vor Nässe. Wenn Feuchtigkeit in das Gerät eintritt, schalten Sie es bitte

unverzüglich aus, danach säubern und trocknen Sie bitte das Gerät.

 Verwenden Sie bitte keine chemischen Lösungen, um das Gerät zu säubern. Hier bitte nur ein

trockenes Tuch verwenden.

 Keine offenen Flammen, beispielsweise angezündete Kerzen, in die Nähe oder auf dem Gerät

platzieren.

 Wir sind nicht haftbar für Schäden bei einer Fehlfunktion, für Datenverlust, fehlerhafter

Handhabung, eigenhändiger Reparatur des Geräts oder Wechseln des Akkus.

DE - 3

 Sollte das Gerät einmal nicht auf Ihre Eingaben reagieren, benutzen Sie bitte den Reset-Knopf

auf der Rückseite des Gerätes, um es neu zu starten.

 Bei Nichtverwendung trennen Sie bitte das Netzteil von der Stromversorgung.
 Die Steckdose muss sich in der Nähe des Gerätes befinden und leicht zugänglich sein.
 Betreiben Sie den Netzadapter nur an geerdeten Steckdosen mit AC 100-240V~, 50/60 Hz.

Wenn Sie sich der Stromversorgung am Aufstellungsort nicht sicher sind, fragen Sie beim
betreffenden Energieversorger nach.

 Benutzen Sie nur das beiliegende Netzadapter- und Netzanschlusskabel.
 Um die Stromversorgung zu Ihrem Gerät zu unterbrechen, ziehen Sie das Netzteil aus der

Steckdose. Halten Sie beim Abziehen immer das Netzteil selbst fest. Ziehen Sie nie an der
Leitung.

 Öffnen Sie nicht das Gehäuse des Netzadapters. Bei geöffnetem Gehäuse besteht

Lebensgefahr durch elektrischen Schlag. Es enthält keine zu wartenden Teile.

 Bei längerer Nichtverwendung entlädt sich der Akku des Gerätes langsam. Vor der

Wiederverwendung muss dieser erneut aufgeladen werden.

 Bitte beachten Sie die umweltgerechte Entsorgung des Gerätes oder des Akkus.
 Bitte zerlegen Sie das Gerät nicht in Einzelteile, und versuchen Sie bitte nicht, es selbst zu

reparieren, da die Garantie in diesem Fall erlischt.

 Nutzen Sie das Gerät nicht an Orten, wo die Nutzung von Mobilgeräten verboten ist. Nutzen Sie

das Gerät nicht in der Nähe anderer elektronischer Geräte, da es durch die
Hochfrequenzsignale zu Störungen kommen kann.

 Nutzen Sie das Gerät nicht in der Nähe eines Schrittmachers, in einem Krankenhaus oder in der

Nähe medizinischer Geräte, da es durch die Hochfrequenzsignale zu Störungen kommen kann.
Halten Sie mindestens 15cm Abstand von einem Schrittmacher. Wenden Sie sich bitte an den
Hersteller dieser Geräte, um Informationen über die gemeinsame Nutzung zu erhalten.

 Bei Verwendung von Ohr- oder Kopfhörern in zu hoher Lautstärke kann es zu einer dauerhaften

Schädigung des Gehörs kommen.

 Aus Gründen der Verkehrssicherheit darf das Gerät während der Fahrt nicht vom

Fahrzeugführer selbst bedient werden.

DE - 4

3.) Geräteüberblick

a) Touchscreen
b) Front Kamera
c) Ladestatus LED. Leuchtet während des

Ladens rot auf. Leuchtet gelb, sobald der
Akku vollständig aufladen wurde.

d) 3.5mm Kopfhörerbuchse
e) Integriertes Mikrofon
f) DC 5V 2A Eingang
g) Micro-USB Buchse

h) Ein / Aus Taste: Lange drücken, um das

Gerät auszuschalten; kurz drücken, um
das Display aus dem Ruhemodus zu
reaktivieren

i) Lautstärke +/­j) Lautsprecher
k) Reset Öffnung: Setzt das Gerät zurück,

wenn es nicht mehr reagieren sollte.

l) Micro-SD Kartenslot
m)HDMI

4.) Packungsinhalt

Bitte überprüfen Sie den Packungsinhalt auf Vollständigkeit:

 TAB 814
 Stereo-Kopfhörer
 USB Kabel
 Netzteil 5V 2.0A
 Bedienungsanleitung
 Tasche in Lederoptik

DE - 5

5.) Laden des Akkus

Bitte laden Sie den Akku des Gerätes vor der ersten Benutzung vollständig auf. Verbinden Sie
dazu das beiliegende Netzteil mit dem Gerät und einer Steckdose. Das vollständige Laden dauert
ca. 5 Stunden. Der Ladezustand wird an der vorderen, linken Seite des Geräts angezeigt. Die LED
leuchtet während des Aufladens Rot und wechselt zu Gelb, wenn der Akku vollständig geladen
ist.

Hinweise:

a. Bei 15% verbleibender Restleistung des Akkus erhalten Sie eine Warnmeldung auf das Display. Sie sollten das Gerät nun zum

Aufladen des Akkus über das Netzteil mit einer Steckdose verbinden, um eventuellen Datenverlust zu vermeiden und die
Lebensdauer des Akkus zu erhöhen.

b. Sie können das Gerät nutzen, während Sie die Batterie aufladen. Um eine langanhaltende Batterie-Lebensdauer zu gewährleisten,

bitten wir Sie, das Gerät nicht zu nutzen.

c. Um eine gute Performance zu gewährleisten, muss der eingebaute Akku häufig genutzt werden. Wenn Sie das Gerät nur selten

gebrauchen, laden Sie den Akku bitte mindestens einmal im Monat vollständig auf.

d. Stellen Sie sicher, dass Sie nur das mitgelieferte Netzteil zum Aufladen benutzen.

6.) Nutzung einer Micro SD/SDHC Karte

Dieses Gerät kann Daten direkt von einer Micro SD/SDHC Karte lesen.
Um eine Micro SD/SDHC Karte zu nutzen, stecken Sie bitte die Karte in das dafür vorgesehene Fach
auf der Unterseite des Gerätes (I). Nutzen Sie den vorinstallierten Explorer, um auf die auf der
Speicherkarte vorhandenen Daten zuzugreifen. Bitte wählen Sie hierzu im Explorer das
Verzeichnis „SD Card“ aus.

7.) Übertragung von Daten zwischen dem Gerät und einem Computer

1.) Verbinden Sie das Gerät mit Hilfe des beiliegenden USB Kabels mit einem Computer. Sollte das Gerät
vorher nicht eingeschaltet gewesen sein, startet es nun automatisch. Dies kann einen Moment
dauern, da das Betriebssystem erst hochgefahren werden muss. War das Gerät bereits
eingeschaltet, sollte der Computer es innerhalb weniger Sekunden automatisch erkennen.

2.) Auf dem Gerät wird nun der Bildschirm für die USB Verbindung angezeigt. Tippen Sie kurz auf „USB-

Speicher aktivieren“. Das Gerät wird als Wechseldatenträger erkannt und Sie erhalten die Info „USB-
Speicher in Verwendung“. Nach kurzem Tippen auf die Home-Taste können Sie Ihr Gerät normal
weiternutzen. Sie haben nun von Ihrem Computer Zugriff auf den internen Speicher des Gerätes

und können Dateien auf das Gerät kopieren, löschen oder verschieben.

3.) Wenn eine USB Verbindung mit dem Computer besteht, wird Ihnen in der Statusleiste ein USB Symbol
angezeigt. In der erweiterten Statusleiste (zum Öffnen bitte kurz auf die Uhr in der Statusleiste tippen)

bekommen Sie zusätzliche Informationen und können die USB Verbindung aktivieren bzw. deaktivieren.

DE - 6

 Um den Speicher zu deaktivieren, wählen Sie “USB-Speicher deaktivieren” aus.

 Wählen Sie beim Computer die Funktion „Sicher Entfernen“ aus, um das Gerät vom Computer zu

trennen.

Hinweis: Die vorinstallierten Anwendungen und das Android™ Betriebssystem nehmen einen Teil des vorhandenen internen
Speichers ein. Aus diesem Grunde steht Ihnen nicht der gesamte interne Speicher zur Verfügung.

8.) Touchscreen

Dieses Gerät wird über einen Touchscreen gesteuert. Sie können mit Ihren Fingern durch leichtes Tippen
auf den Touchscreen ganz einfach Anwendungen starten, Texte auf der virtuellen Tastatur eingeben
und durch wischen in die jeweilige Richtung zwischen den einzelnen Startbildschirmen wechseln.

Bitte entfernen Sie die Display Schutzfolie vor der Verwendung des Gerätes.
Der Touchscreen erkennt geringe elektrische Ladungen, wie sie beispielsweise vom menschlichen Finger

abgegeben wird und bestimmt so den Eingabepunkt.
Nutzen Sie für die Eingabe also idealerweise Ihre Fingerspitzen. Die Bedienung mit einem Stift oder
anderen spitzen Gegenständen ist nicht möglich.

Der Touchscreen sollte nicht mit Wasser oder anderen elektrischen Vorrichtungen in Berührung
kommen, um Fehlfunktionen und dauerhafte Defekte zu vermeiden.

Hinweise:
a. Wird der Touchscreen zwei Minuten lang nicht bedient, wechselt das Gerät in den Standby Modus. Drücken Sie kurz die Ein / Aus

Taste, um in den aktiven Modus zu wechseln.

b. Um ungewünschte Eingaben zu verhindern, ist automatisch eine Tastensperre aktiviert. Entriegeln Sie bitte die Tastensperre auf

dem Touchscreen. Berühren Sie das geschlossene Schloss auf dem Display und halten Sie dieses gedrückt. Ziehen Sie
nun das Schloss auf das soeben erschienende geöffnete Schloss und lösen Sie dann Ihren Finger vom Display. Der

Bildschirm ist nun entsperrt.

Sie können das Gerät in alle Richtungen drehen. Es verfügt über einen Sensor, der das Display
automatisch ausrichtet.

DE - 7

9.) Der Startbildschirm

Ansicht

Entsperren des Displays

Wird der Touchscreen zwei Minuten lang nicht bedient, wechselt das Gerät in den Standby
Modus. Drücken Sie kurz die Ein / Aus Taste, um in den aktiven Modus zu wechseln. Das Display
ist zum Schutz vor ungewünschten Eingaben gesperrt. Berühren Sie das geschlossene Schloss

auf dem Display und halten Sie dieses gedrückt. Ziehen Sie nun das Schloss auf das soeben

erschienende geöffnete Schloss und lösen Sie dann Ihren Finger vom Display. Der Bildschirm ist
nun entsperrt

Hinweis: Ziehen Sie das Schloss Symbol zum erscheinenden Kamera Symbol, um direkt die
Kameraanwendung zu öffnen.

Ziehen Sie das Schloss Symbol mit Ihrem Finger in Pfeilrichtung

DE - 8

Statusleiste
Die Statusleiste finden Sie im unteren Bereich des Startbildschirms. Sie besitzt folgende

Funktionalität:

Sie erhalten Informationen über:

 die zuletzt genutzten Programme
 die Signalstärke der aktuellen WLAN Verbindung
 die aktuelle Uhrzeit
 den aktuellen Batterieladestand

Sie können folgende Funktionen ausführen:

 Startbildschirm aufrufen
 im jeweilig aufgerufenem Menü einen Schritt zurückgehen
 die zuletzt genutzten Programme aufrufen

Durch kurzes Tippen auf die Uhr öffnen Sie die erweiterte Statusleiste. Hier werden Ihnen aktuelle
Statusmeldungen angezeigt. Durch nochmaliges Tippen auf die Uhr in der erweiterten Statusleiste
werden Ihnen verschiedene Schnellzugriffe, wie zum Beispiel der Zugang zu den Einstellungen,
angezeigt.

Anpassung des Startbildschirms

Sie können Ihren Startbildschirm ganz einfach an Ihre individuellen Bedürfnisse anpassen. Wenn Sie ein
Icon löschen möchten, tippen Sie etwas länger mit Ihrem Finger auf das Icon und schieben Sie es dann
in das eingeblendete X-Symbol. Nehmen Sie den Finger nun vom Touchscreen und das Icon wird
gelöscht.

Wenn Sie ein Icon aus der Anwendungsübersicht auf den Startbildschirm positionieren wollen, tippen
Sie in der Anwendungsübersicht etwas länger auf das Icon und der Startbildschirm erscheint. Schieben
Sie das Icon an die gewünschte Stelle und lösen Sie den Finger vom Touchscreen. Das Icon wurde nun
dem Startbildschirm hinzugefügt. Wenn Sie ein Icon auf ein anderes Icon legen, wird automatisch ein
Ordner mit beiden Icons angelegt. Tippen Sie auf den Ordner, um alle darin abgelegten Icons angezeigt zu
bekommen und wählen Sie dann das gewünschte Icon durch kurzes Tippen aus.

Sie können dem Startbildschirm außerdem Widgets hinzufügen. Tippen Sie dazu bitte auf die -Taste in
der rechten oberen Ecke des Startbildschirms, um das Anwendungsmenü zu öffnen. Tippen Sie als
nächstes auf das Wort Widgets. Es werden Ihnen nun alle auf dem Gerät verfügbaren Widgets angezeigt.
Das Hinzufügen eines Widgets auf den Startbildschirm funktioniert genau, wie das Hinzufügen eines
Icons.

Wenn Sie das Hintergrundbild ändern möchten, tippen Sie einfach auf eine freie Stelle auf einem
Startbildschirm und halten Sie den Finger solange auf das Display gedrückt, bis das
Hintergrundauswahlmenü erscheint. Wählen sie nun die Quelle des gewünschten Bildes aus und verfahren
Sie, wie folgt:

DE - 9

Verschiedene Startbildschirme nutzen

A Verknüpfung zur Google™ Suche

B Anwendungsübersicht

C Weltweite Wettervorhersage

D Apps auf dem Startbildschirm

E Statusleiste: Zurück, Home, zuletzt
genutzte Programme, Uhrzeit, Wlan,
Akkustatus

Ihnen stehen fünf individuell einzurichtende Startbildschirme zur Verfügung. Durch eine leichte
Wischbewegung nach links oder rechts, können Sie ganz leicht zwischen Ihnen wechseln.

Durch Drücken der Home-Taste gelangen Sie immer automatisch zum mittleren Startbildschirm zurück.

Vorinstallierte Anwendungen auf dem Startbildschirm

Auf dem Startbildschirm sind verschiedene Anwendungen bereits vorinstalliert:

- Suchleiste für die Google™ Suche

- Wettervorschau

- WIFI

- Galerie

- Musik

- Video

- AndroidPIT (App Center)

DE - 10

a) Suchleiste für die Google™ Suche

Tippen Sie kurz auf die Lupe, um die Google™ Suchfunktion zu öffnen. Geben Sie den gewünschten
Suchbegriff über die virtuelle Tastatur ein und drücken Sie auf Los. Es werden Ihnen nun die verfügbaren
Suchergebnisse der Google™ Suche angezeigt.

 Tipp: Durch eine schnelle Auf- oder Abwärtsbewegung, nach der Sie den

Finger vom Touchscreen lösen, scrollt das Gerät schnell durch eine Liste.

Hinweis: Für diese Funktion ist eine WLAN Verbindung zum Internet erforderlich.

b) Anwendungsübersicht

Dies funktioniert in allen Anzeigen, die größer als das Display sind.

Tippen Sie auf dieses Symbol, um die Anwendungsübersicht zu öffnen. Hier werden Ihnen alle auf dem
Gerät installierten Anwendungen angezeigt. Durch Tippen auf das dazugehörige Symbol können Sie die
gewünschte Anwendung direkt starten.

DE - 11

c) Wettervorschau

Das Wettervorschau Widget zeigt Ihnen auf einem Blick die aktuell eingestellte Uhrzeit, Datum,
Wetterlage sowie Temperatur am eingestellten Ort.

Um die Einstellungen zu ändern, wechseln Sie bitte in die Anwendungsübersicht und tippen Sie auf das
Wettervorschau Icon. Hier können Sie nun die gewünschten Änderungen vornehmen.

Einstellungsmenü der Wettervorschau

Hinweis: Für diese Funktion ist eine WLAN Verbindung zum Internet erforderlich.

d) WIFI

Um das Gerät mit dem Internet zu verbinden, benötigen Sie eine WLAN Verbindung. Um diese
herzustellen, tippen Sie bitte auf das WIFI Icon auf dem Startbildschirm, oder öffnen Sie in den
Einstellungen die WLAN Einstellungen.

Hinweis: Bitte beachten Sie, dass sich ein WLAN Netz in Reichweite ihrer aktuellen Position befinden
muss.

Automatische Verbindung

Öffnen Sie über das WIFI Icon oder über die Einstellungen die WLAN
Einstellungen. Hier können Sie die WLAN Funktion ganz einfach
aktivieren oder deaktivieren. Schieben Sie den virtuellen Schalter
einfach aus der Position „An“ nach links, um die WLAN Funktion zu
deaktivieren. Die Anzeige wechselt nun zu „Aus“.
Um die deaktivierte WLAN Funktion wieder zu aktivieren, schieben
Sie den virtuellen Schalter einfach nach rechts.

In den WLAN-Einstellungen werden Ihnen auf der rechten Seite alle verfügbaren Netzwerke sowie
alle bereits genutzten Netzwerke angezeigt.

Tippen Sie bitte auf das gewünschte Netzwerk und geben Sie gegebenenfalls den passenden
WLAN Schlüssel (Passwort) ein, um eine Verbindung herzustellen.

DE - 12

Bestätigen Sie das gegebenenfalls eingegebene Passwort durch tippen auf die Enter Taste und
tippen Sie nun auf Verbinden. Nach einem kurzen Moment ist die Verbindung hergestellt.

Hinweise:

a) Wenn das Gerät in den Standby Modus wechselt, wird WLAN automatisch deaktiviert. Dies

verringert den Stromverbrauch und führt so automatisch zu einer längeren Akkulaufzeit. Wenn
das Gerät wieder in den aktiven Modus wechselt, wird automatisch die WLAN Verbindung

wiederhergestellt. Dies kann einige Sekunden dauern.
b) Die Liste der aktuell auffindbaren WLAN Netzwerke wird automatisch aktualisiert.
c) Wenn die WLAN Funktion aktiviert ist, verbindet sich das Gerät automatisch mit einem bereits

konfigurierten Netzwerk, sofern es sich in Reichweite befindet.
d) Wenn sich ein unbekanntes WLAN Netzwerk in Reichweite befindet, wird ein Informationsfeld

eingeblendet.

Manuelle Verbindung

Um manuell nach einem erreichbaren WLAN Netz zu suchen, gehen Sie bitte wie folgt vor:
(1) Öffnen Sie die Einstellungen.
(2) Öffnen Sie jetzt die WLAN-Einstellungen und tippen Sie auf „Scannen“.
(3) Sollte das WLAN Netz nicht in der Liste der verfügbaren Netzwerke erscheinen, wählen Sie den Punkt

“Netzwerk hinzufügen” aus, um von Hand die Netzwerk SSID, das Sicherheitsprotokoll und das
gegebenenfalls zugehörige Passwort einzugeben. Zur Bestätigung Ihrer Eingaben tippen Sie bitte auf

„Speichern“.

e) Galerie

Tippen Sie kurz auf das Galerie Icon, um eine Übersicht aller vorhandenen Alben und Bilder zu
bekommen.

Wählen Sie die gewünschte Galerie und anschließend das gewünschte Bild durch erneutes, kurzes
Tippen aus. Das Bild wird Ihnen nun als Vollbild dargestellt.

Tippen Sie auf das Fotosymbol , um zwischen verschiedenen
Gruppierungsmöglichkeiten wählen.

DE - 13

Interpreten

Zeigt alle Musikdateien nach den einzelnen Interpreten sortiert an.

Alben

Zeigt alle Musikdateien nach den einzelnen Alben sortiert an.

Titel

Zeigt alle Musikdateien nach Titel sortiert an.

Playlists

Zeigt die erstellten Playlists an.

Aktuelle Wiedergabe

Springt direkt zur aktuellen Wiedergabe.

Um das nächste oder vorherige Bild angezeigt zu bekommen, schieben
Sie das aktuelle Bild mit dem Finger einfach nach links oder rechts aus
dem Display.

Legen Sie zwei Finger auf den Touchscreen und ziehen Sie diese
auseinander, um das Bild stufenlos zu vergrößern. Wenn Sie die Finger
wieder zusammenführen, wird das Bild stufenlos verkleinert. Tippen Sie

kurz und schnell doppelt auf den Touchscreen, wird das Bild automatisch
vergrößert und durch erneutes doppeltippen wieder in der
Ursprungsgröße angezeigt.

Durch kurzes Tippen auf den Touchscreen stehen Ihnen weitere Funktionen zur Verfügung.

Tippen Sie auf „Menü“-Symbol , um weitere Optionen zu
erhalten
Hier können Sie eine Diashow starten, das Bild bearbeiten,
drehen, zuschneiden, festlegen als Hintergrundbild und sich die
Details des Bildes anzeigen lassen.

Tippen Sie auf das Mülltonnen-Symbol , um das ausgewählte
Bild zu löschen.

Tippen Sie auf das Teilen-Symbol , um das Bild bspw. per
Email zu versenden.

f) Musik

Tippen Sie kurz auf das Musik Icon im Startbildschirm oder der Anwendungsübersicht, um die
Musikwiedergabe zu öffnen.

In der folgenden Übersicht haben Sie die Wahl, sich Ihre Musik nach Interpreten, Alben, Titel, Playlist
oder der aktuellen Wiedergabe sortiert anzeigen zu lassen. Tippen Sie dazu einfach kurz auf das
entsprechende Symbol.

Wählen Sie durch kurzes Tippen auf den Namen die gewünschte Datei und die Musikwiedergabe startet.

DE - 14

Wiedergabebildschirm

(1) Aktuelle Wiedergabe
(2) Zufallswiedergabe aktivieren / deaktivieren
(3) Wiederholungsoptionen:

a) Alle Titel werden wiederholt
b) Aktueller Titel wird wiederholt
c) Wiederholung ist deaktiviert

(4) Titeldetails
(5) Nächster / Vorheriger Titel
(6) Play / Pause
(7) Zeitleiste

 Tippen Sie auf das Pause Symbol , um die Wiedergabe anzuhalten.
 Um die Wiedergabe fortzusetzen, tippen Sie auf das Play Symbol .
 Tippen Sie auf das Vor- bzw. Zurück Symbol / , um den vorherigen oder nächsten Titel

abzuspielen.

 Tippen Sie auf eine Stelle der Zeitleiste, um die Wiedergabe direkt an dieser Stelle fortzusetzen.
 Drücken Sie die Lautstärke +/- Tasten an der Seite des Gerätes, um die Lautstärke anzupassen.
 Um die Vorschau der aktuellen Wiedergabeliste zu öffnen, tippen Sie bitte auf das

Wiedergabeliste Symbol . Tippen Sie auf einen Titel, um diesen direkt abzuspielen.

 Um den Wiederholungsmodus zu ändern, tippen Sie auf das Wiederholungsmodus Symbol .
 Um auf den Startbildschirm zu gelangen, tippen Sie kurz auf die Home-Taste . Die

Musikwiedergabe wird dadurch nicht gestoppt. So können Sie beispielsweise mit dem Browser im
Internet surfen und gleichzeitig Ihre Musik hören. Tippen Sie einfach erneut auf das Musik Icon

um Zurück zur Musikwiedergabe zu gelangen.

Im Wiedergabemodus können Sie weitere Einstellungen vornehmen. Tippen Sie dazu kurz auf die

Menü-Taste .

Bibliothek – Eine Übersicht aller vorhandenen Musikdateien wird angezeigt.
Party Mix – Den Party Mix Modus aktivieren bzw. deaktivieren.
Zur Playlist hinzufügen – Den aktuell gespielten Titel zu einer Playlist hinzufügen.
Löschen – Löschen des aktuell gespielten Titels.

Toneffekte – Einen Soundeffekt für die Musikwiedergabe festlegen.

DE - 15

g) Video

a. Caps Lock (Groß- und Kleinschreibung)
b. Rücksprungtaste
c. Aufruf des Menüs für die Nummern, Zeichen und

Sonderzeichen Eingabe
d. Space Taste (Leerzeicheneingabe)
e. Enter Taste ( Bestätigung Ihrer Eingabe)

Tippen Sie kurz auf das Video Icon im Startbildschirm oder der Anwendungsübersicht, um die
Videowiedergabe zu öffnen.

Es werden Ihnen nun die verfügbaren Videodateien in einer Liste angezeigt. Wählen Sie die gewünschte
Datei durch kurzes Antippen und das Video startet.

h) App Center

Auf dem Gerät ist das AndroidPIT App Center bereits vorinstalliert. Hier finden Sie verschiedene Apps,
Testberichte, einen Blog und ein Forum.
Für weitere Hinweise oder Hilfe zur Nutzung des App Centers besuchen Sie bitte die Homepage des
Anbieters unter www.androidpit.de.

Hinweis: Für diese Funktion ist eine WLAN Verbindung zum Internet erforderlich.

i) Web Browser

Um den Web Browser zu starten, tippen Sie bitte auf das Browser Icon in der Anwendungsübersicht.
Um eine Internetseite zu öffnen, tippen Sie bitte auf das Eingabefeld für die Internetadresse. Die virtuelle
Tastatur öffnet sich nun und Sie können jetzt die Adresse der gewünschten Internetseite eingeben. Tippen
Sie auf die Enter Taste, um Ihre Eingabe zu bestätigen und die Internetseite zu öffnen.

Hinweis: Nicht alle Netzwerke bieten einen Internetzugriff. Einige Netzwerke bieten nur einen Zugriff auf andere verbundene lokale
Rechner und keine Internetverbindung.

Nutzung der virtuellen Tastatur

Tippen Sie auf das Eingabefeld zum Öffnen der virtuellen Tastatur. Sie können nun Texte eingeben oder
Internetseiten aufrufen.

DE - 16

Eingabe von Sonderzeichen

Um ein Sonderzeichen wie etwa “ä” einzugeben, tippen Sie lange mit Ihrem Finger auf die Taste „a“ um
das Sonderzeichenmenü aufzurufen. Gleiten Sie nun mit dem Finger auf das gewünschte Sonderzeichen,
beispielsweise das „ä“ und lösen Sie den Finger wieder vom Display. Sie haben nun ein „ä“ eingeben.

Nutzung des Web Browsers

 Sie können durch die Anzeige im Display scrollen, indem Sie eine vertikale Wischbewegung mit Ihrem

Finger durchführen. Bitte beginnen Sie die Wischbewegung nicht auf einem Menüpunkt oder Link, da
ansonsten die vorhandene Verknüpfung geöffnet werden würde.

 Um einen Internetlink zu öffnen, tippen Sie ganz einfach auf den Link. Die neue Seite öffnet sich

automatisch.

 Um das Web Browser Menü zu öffnen, drücken Sie bitte die Menü-Taste . Hier stehen Ihnen

verschiedene Funktionen zur Verfügung. Unter anderem können Sie hier die geöffnete Webseite

aktualisieren, einen neuen Tab öffnen, Webseiten offline lesbar machen oder zu den Web Browser
Einstellungen wechseln.

 Um zu der vorherigen Seite zurückzugehen, drücken Sie bitte die Zurück-Taste .
 Um direkt zum Startbildschirm zurückzukehren, drücken Sie bitte auf die Home-Taste .

 Um einen Text einzugeben, tippen Sie auf das entsprechende Feld und nutzen Sie die virtuelle

Tastatur zur Eingabe des Textes.

Hinweis: Für diese Funktion ist eine WLAN Verbindung zum Internet erforderlich.

DE - 17

j) Anwendungsübersicht

Tippen Sie kurz auf das Anwendungsübersicht Icon , um die Anwendungsübersicht zu öffnen. Sie
sehen nun eine Übersicht aller vorinstallierten und bereits von Ihnen installierten Anwendungen. Öffnen
Sie die gewünschte Anwendung durch kurzes Tippen auf das entsprechende Icon.

Anwendungsübersicht

k) System Einstellungen

Tippen Sie im Anwendungsmenü auf das Einstellungen Icon, um die System Einstellungen aufzurufen.

 Auf der linken Seite des Menüs finden Sie die einzelnen Kategorien. Durch kurzes Drücken auf den

jeweils ausgewählten Menüeintrag, werden die verfügbaren Einstellmöglichkeiten angezeigt.
Beachten Sie bitte, dass eventuell nicht alle von Android™ angebotenen Funktionen mit diesem Gerät
kompatibel sind.

 Wenn Sie alle Einstellungen vorgenommen haben, können sie mit der Zurück Taste in das

zuletzt aufgerufene Menü zurückkehren, oder mit der Home Taste direkt auf den
Startbildschirm wechseln.Ihre getätigten Eingaben werden automatisch gespeichert.

DE - 18

Einstellungsübersicht

Drahtlos &
Netzwerke

WLAN

Nehmen Sie hier Ihre WLAN-Einstellungen vor.

Mehr

Hier können Sie weitere Netzwerkeinstellungen vornehmen.

Gerät

Töne

Stellen Sie hier die gewünschte Lautstärke und den gewünschten
Benachrichtigungston ein.
Weiterhin können Sie einen Bestätigungston bei Berührung des
Touchscreens und einen Hinweiston beim Entsperren der Displaysperre
aktivieren bzw. deaktivieren.

Display

Helligkeit – Displayhelligkeit anpassen.
Hintergrund – Auswahl des gewünschten Hintergrundes.
Display autom. drehen – Ein- und Ausschalten der automatischen

Ausrichtung des Displays beim Drehen des Gerätes.
Ruhezustand – Verzögerung vor der automatischen Displayabschaltung
anpassen.

Schriftgröße – Einstellen der gewünschten Schriftgröße.

Speicher

Hier bekommen Sie Informationen über den internen Speicher und - falls
eingesetzt - über Ihre MicroSD-Karte. Weiterhin können Sie den Inhalt des
Speichers löschen.

Akku

Hier bekommen Sie Informationen über den Ladezustand des eingebauten
Akkus.

Apps

Hier können Sie Ihre installierten Anwendungen verwalten und Informationen
über die Anwendungen erhalten.

Nutzer

Konten &
Synchronisierung

Hier können Sie festlegen, ob und wie oft die von Ihnen angelegten Konten
synchronisiert werden sollen.

Standortdienste

Hier können Sie diversen Android™ Anwendungen erlauben, Ihren aktuellen
Standort über Drahtlosnetzwerke festzustellen und zu nutzen (z.B. Google

Maps™). Sie können weiterhin festlegen, ob Google™ Suchergebnisse und

andere Dienste an Ihren Standort anpassen darf.

Sicherheit

Hier können Sie beispielsweise eine Bildschirmsperre einrichten und weitere
sicherheitsrelevante Einstellungen vornehmen.

Sprache & Eingabe

Hier können Sie beispielsweise Ihre bevorzugte Sprache einstellen, dem
persönlichen Wörterbuch verschiedene Wörter hinzufügen und diverse
Einstellungen an der Tastatur vornehmen.

Sichern &
Zurücksetzen

Hier können Sie Ihre Systemeinstellungen und Anwendungsdaten auf
Google™-Servern sichern. Des Weiteren können Sie die Werkseinstellungen
wiederherstellen. ACHTUNG: Dazu werden alle auf dem Gerät
gespeicherten Daten gelöscht.

System
Datum & Uhrzeit

Hier können Sie das Datum, die Uhrzeit, die Zeitzone und das Anzeigeformat
festlegen.

Über das Tablet

Zeigt Ihnen Informationen über das Gerät.

DE - 19

10.) E-Book

Dieses Gerät verfügt über einen vorinstallierten E-Book Reader.

Kopieren von E-Books zwischen Computer und Gerät

Sie können E-Books per USB Verbindung auf den internen Speicher ihres Gerätes kopieren. Bitte
schauen Sie sich dazu den Absatz „ Übertragung von Daten zwischen dem Gerät und einem Computer
per USB Kabel“ an.

Hinweis: Bitte stellen Sie sicher, dass das E-Book eines der folgenden Formate besitzt: PDF, EPUB, TXT, FB2, RTF, PDB.

Download von E-Books und Übertragung auf das Gerät mit Hilfe von Adobe™ Digital Editions

Die Adobe™ Digital Edition Anwendung ermöglicht es Ihnen DRM
geschützte E-Books mit Ihrem Computer herunterzuladen.

(1) Laden Sie die Webseite http://www.adobe.com/de/products/digitaleditions/

und installieren Sie die Adobe™ Digital Editions Software nach Anleitung.

(2) Autorisierung des Computers mit Ihrer Adobe™ ID und Passwort (sollten

Sie noch keine Adobe™ ID besitzen, melden Sie sich bitte auf der Adobe™
Seite für diesen Dienst an).

(3) Aktivieren Sie nun das Gerät. Verbinden Sie dazu das Gerät mit dem PC durch das mitgelieferte

USB Kabel und aktivieren Sie den USB Speicher. Starten Sie jetzt die Adobe™ Digital Editions
Software. Klicken Sie auf “Authorize Device”, um Ihr Gerät zu autorisieren.

 Die Adobe™ ID kann nur 6mal genutzt werden. Danach müssen Sie die ausgelaufene ID durch Drücken der CTRL+SHIFT+D

Tasten auf dem Computer oder durch die Einstellung Erase Activation Record auf dem Gerät löschen und eine neue ID anfordern.

 Das Tablet erinnert sich an die heruntergeladenen E-Books, die Sie mit der aktuell gültigen Lizenz heruntergeladen haben und

überschreibt die vorherigen Adobe™ ID’s.

(4) Besuchen Sie mit Ihrem Computer einen Online E-Book Store und wählen

Sie das gewünschte E-Book aus (bitte stellen Sie sicher, dass das E-Book
eines der folgenden Formate besitzt: PDF, EPUB, TXT, FB2, RTF, PDB).
Sollte das E-Book DRM geschützt sein, wird Ihnen diese Information in der
Regel angezeigt.

(5) Haben Sie das E-Book gekauft und auf Ihren Computer heruntergeladen,

sollten Sie es in der Adobe™ Digital Editions Anwendung finden können.

DE - 20

(6) Verbinden Sie Ihr Gerät nun per USB Kabel mit dem Computer. Die

Adobe™ Digital Edition Software sollte Ihr Gerät jetzt automatisch
erkennen.

(7) Ziehen Sie das Cover des E-Book auf Ihr Gerät, um die Datei zu

übertragen.

Lesen starten

Öffnen Sie die Anwendungsübersicht und tippen Sie auf das E-Book Reader Icon, um den E-Book
Reader zu öffnen. Wählen Sie aus den zur Verfügung stehenden E-Books das gewünschte Buch aus, um
direkt mit dem Lesen zu beginnen.

Wechsel zwischen Regalansicht und Listenansicht / Löschen von Ebooks

Tippen Sie einfach auf das Listen Symbol unter dem Bücherregal, um in die Listenansicht zu gelangen.

Wenn Sie auf das Mülltonnen Symbol tippen wird jedem Ebook ein rotes X hinzugefügt. Tippen Sie am
gewünschten Ebook auf das X und es wird direkt gelöscht.

Hinweis: Die Titelseite des E-Book wird mit einem Standardbild angezeigt, wenn dem Gerät keine Titelseiteninformationen vorliegen.
Deshalb können einige E-Books identische Titelseiten haben.

DE - 21

Seiten umblättern

Wenn Sie ein Buch lesen, können Sie mit dem Finger eine Wischbewegung
ausführen, um seitenweise zu blättern.
Sie können ebenfalls die Seiten automatisch umblättern lassen. Tippen Sie
dazu auf die Menü Taste , um zu den erweiterten Einstellungen zu
gelangen. Wählen Sie nun „Auto flip“ und anschließend die gewünschte

Intervallzeit durch kurzes Antippen aus.

Vergrößern der Schriftgröße

(1) Tippen Sie bitte während des Lesens auf die Menü Taste , um zu den erweiterten Einstellungen zu

gelangen.
(2) Tippen Sie auf “Zoom”, um die gewünschte Schriftgröße einzustellen.
(3) Bitte bestätigen Sie Ihre Auswahl mit “OK”.

Sprung zu einer bestimmten Seite

(1) Öffnen Sie während des Lesens die erweiterten Einstellungen mit der Menü Taste .
(2) Tippen Sie auf “Go To”.
(3) Geben Sie die gewünschte Seitenzahl ein.
(4) Bitte bestätigen Sie Ihre Auswahl mit “OK”.

Nutzen von Lesezeichen

Sie können Lesezeichen hinzufügen, löschen oder laden.
(1) Öffnen Sie während des Lesens die erweiterten Einstellungen mit der Menü Taste .
(2) Tippen Sie auf “Bookmarks”, um das Lesezeichenmenü aufzurufen. Hier können Sie Lesezeichen

hinzufügen, löschen oder anzeigen.

Anzeige des Inhaltsverzeichnisses

Sie können sich das Inhaltsverzeichnis des E-Book anzeigen lassen und dann direkt mit dem
gewünschten Kapitel oder Abschnitt beginnen, wenn das E-Book diese Funktion unterstützt.

(1) Öffnen Sie während des Lesens die erweiterten Einstellungen mit der Menü Taste .
(2) Tippen Sie auf “TOC” um das Inhaltsverzeichnis zu öffnen und anschließend auf das Kapitel oder den

Abschnitt, wo Sie mit dem Lesen beginnen möchten.

Anzeige der Buchinformation

Während des Lesens können Sie sich die verfügbaren Buchinformationen anzeigen lassen. Tippen Sie
dazu auf die Menü Taste und wählen Sie anschließend den Menüpunkt “BookInfo” aus.

DE - 22

11.) Versand / Empfang von E-Mails

Auf diesem Gerät ist eine E-Mail Anwendung vorinstalliert. Sie können damit Ihre bereits bestehende E-
Mail Adresse nutzen, um E-Mails zu versenden und zu empfangen.

Hinweis: Für diese Funktion ist eine WLAN Verbindung zum Internet erforderlich.

Öffnen Sie die Anwendung über das „E-Mail“ Icon, welches Sie im Anwendungsmenü finden.

Einrichtung Ihres E-Mail Postfaches

(1) Starten Sie die E-Mail Anwendung durch Tippen auf das E-Mail Symbol. Sie werden nun aufgefordert

Ihr E-Mail Postfach einzurichten.
(2) Geben Sie Ihre E-Mail Adresse sowie Ihr zugehöriges Passwort ein und tippen Sie dann auf „Weiter“.

Anschließend benennen Sie Ihr Konto und legen Ihren angezeigten Namen für ausgehende

Nachrichten fest. Tippen Sie auf „Fertig“ um die Einrichtung abzuschließen. Ihr E-Mail Postfach wird

als Standard Postfach ausgewählt, wenn Sie die Option “E-Mails standardmäßig von diesem Konto

senden” auswählen.
(3) Sie können Ihr E-Mail Postfach auch manuell einrichten. Geben Sie Ihre E-Mail Adresse und Ihr

zugehöriges Passwort ein und tippen Sie anschließend auf “Manuelles Setup”, um die E-Mail Server

Informationen einzugeben.

(4) Wählen Sie zwischen den Servertypen POP3, IMAP oder Exchange für eingehende E-Mails aus.

Hinweis: Wenn Sie nicht wissen, welche Einstellungen Sie vornehmen müssen, kontaktieren Sie bitte Ihren E-Mail Provider, Ihren

Netzwerkadministrator oder suchen Sie mit Begriffen wie etwa „POP Adresse“ und „Namen Ihres Provider“ nach den benötigten

Informationen im Internet.

(5) Geben Sie die benötigten Informationen ein (Server, Port etc.).
(6) Wählen Sie den Servertyp für ausgehende E-Mails aus und geben Sie die benötigten Informationen

ein.
(7) Tippen Sie “Weiter”, um im Menü fortzufahren. Die E-Mail Anwendung überprüft nun die getätigten

Server Einstellungen. Nach erfolgreichem Anlegen sehen Sie die Meldung “Your account is set up,

and email is on its way”. Ihr Konto ist jetzt eingerichtet.
(8) Vergeben Sie einen Namen für Ihr Postfach und tippen Sie auf „Fertig“, um den Vorgang

abzuschließen.

Hinweis: Sollten Sie mehr als einen Email Account besitzen, wird bei jedem Start der E-Mail Anwendung das Standard Konto
aufgerufen.

DE - 23

Verwaltung der E-Mail Accounts

Hinzufügen eines neuen Postfaches:

(1) Öffnen Sie die E-Mail Anwendung und tippen Sie auf die Menü Taste zum Anzeigen der weiteren

Optionen. Wählen Sie den Menüpunkt „Einstellungen und anschließend “Konto hinzufügen”, um ein

neues Postfach anzulegen.
(2) Folgen Sie dem Einrichtungsassistenten, um ein neues Postfach anzulegen.

Löschen eines Postfaches:

(1) Öffnen Sie die E-Mail Anwendung und tippen Sie auf die Menü Taste zum Anzeigen der weiteren

Optionen. Wählen Sie den Menüpunkt „Einstellungen“ und anschließend “Konto entfernen”, um das

gewünschte Postfach zu löschen.

Überprüfen der Kontoeigenschaften:

(1) Öffnen Sie die E-Mail Anwendung und tippen Sie auf die Menü Taste zum Anzeigen der weiteren

Optionen und wählen Sie „Einstellungen“ aus. Auf der linken Seite des Menüs werden jetzt alle

bereits angelegten Postfächer angezeigt.
(2) Tippen auf das gewünschte Postfach, um die Kontoeinstellungen anzuzeigen.
(3) Tippen Sie auf die zu ändernde “Kontoeinstellung“, um die gewünschten Einträge vorzunehmen.

Anzeige von E-Mail Nachrichten

Öffnen Sie die E-Mail Anwendung durch kurzes Tippen auf das E-Mail Icon. Ihr bereits angelegtes
Postfach wird nun angezeigt.

 Durch eine vertikale Wischbewegung können Sie durch Ihre E-Mails scrollen.
 Tippen Sie kurz auf eine bestimmte E-Mail, um diese zu öffnen.
 Tippen und halten Sie den Finger auf einer bestimmten E-Mail Nachricht, um weitere Optionen

angezeigt zu bekommen. Es erscheint nun ein Infofeld. Hier können Sie jetzt die E-Mail öffnen,

beantworten, weiterleiten oder löschen.

Schreiben von E-Mail Nachrichten

(1) Tippen Sie in der E-Mail Übersicht auf das Email Symbol in der oberen Menüleiste und es öffnet sich

ein neues Fenster, indem Sie eine neue Email verfassen können.
(2) Geben Sie nun die E-Mail Adresse des Empfängers, einen Betreff und den Text in die dafür

vorgesehen Felder ein. Sie können ebenfalls „Cc/Bcc“ hinzufügen, um eine E-Mail an mehrere User zu

schreiben.
(3) Tippen Sie auf „Senden“, um die E-Mail abzuschicken. Tippen Sie auf „Speichern“, um die

eingegebene E-Mail als Entwurf zu speichern. Wenn Sie auf das „Mülleimer Symbol“ tippen, wird die

aktuell eingegebene E-Mail wieder entfernt.

DE - 24

12.) Verwaltung von Anwendungen

Vorinstallierte Anwendungen

Dieses Gerät wird mit bereits vorinstallierten Anwendungen ausgeliefert. Eine Übersicht der bereits
installierten Anwendungen finden Sie in der Anwendungsübersicht . Hierzu gehören unter anderem
der Video Player, Audio Player, Internet Browser, Alarm, Rechner und noch einige mehr. Um eine dieser

Anwendungen zu öffnen, tippen Sie kurz auf das zugehörige Icon.

Installation von Anwendungen

Um Anwendungen auf dem Gerät zu installieren, führen Sie bitte die folgenden Schritte aus:
(1) Laden Sie die Software herunter (beispielsweise aus dem Androidpit Market). Stellen Sie sicher, dass

es sich um eine APK Datei handelt.
(2) Sollten Sie die Dateien auf Ihren Computer heruntergeladen haben, verbinden Sie das Gerät per USB

Kabel mit Ihrem Computer und kopieren Sie die Dateien auf den internen Speicher.
(3) Trennen Sie das Gerät vom Computer und öffnen Sie den Explorer, um die kopierten Dateien zu

öffnen.
(4) Folgen Sie den auf dem Display erscheinenden Installationsanweisungen, um die Anwendung zu

installieren.
(5) Nach erfolgreicher Installation finden Sie die neue Anwendung im Anwendungsmenü.

Deinstallation von Anwendungen

(1) Öffnen Sie bitte die System Einstellungen durch kurzes Tippen auf das Einstellungen Icon in der

Anwendungsübersicht.
(2) Tippen Sie jetzt kurz auf den Menüpunkt “Apps”, um in die Anwendungseinstellungen zu gelangen.
(3) Wählen Sie zwischen den Menüoberpunkten “Heruntergeladen, USB-Speicher, Aktiv und Alle” die

gewünschte Anwendungsübersicht durch kurzes Tippen aus.
(4) Wählen Sie als nächstes durch kurzes Tippen die Anwendung aus, die Sie deinstallieren möchten.
(5) Tippen Sie nun auf “Deinstallieren” und bestätigen Sie Ihre Eingabe mit OK, um die Anwendung vom

Gerät zu deinstallieren.

Hinweis: Sie können vorinstallierte Software nicht löschen.

DE - 25

13.) Lesen von Office Dokumenten

Auf diesem Gerät ist bereits die Anwendung “Office Suite” zum Lesen von Office Dokumenten
vorinstalliert. Sie können Word, Excel, oder Powerpoint Dateien lesen.

1.) Kopieren Sie die gewünschten Office Dateien auf das Gerät.

2.) Öffnen Sie die Anwendung „Office Suite“.

3.) Navigieren Sie mit dem Explorer zu der gewünschten Datei.

4.) Wählen Sie die gewünschte Datei durch kurzes Tippen aus und wischen Sie mit dem Finger
vertikal oder horizontal über das Display, um zwischen den einzelnen Seiten zu blättern.
Tippen Sie kurz auf die Menütaste, um weitere Optionen zu öffnen. Sie können zum Beispiel
nach einem bestimmten Text suchen oder Wörter zählen.

14.) Task Manager

Dieses Gerät ist Multitasking fähig. Sie können also zur gleichen Zeit mehrere Anwendungen
gleichzeitig öffnen. Sie können beispielsweise Musik hören und zur gleichen Zeit im Internet surfen oder
Bilder betrachten.

Unter Umständen kann es vorkommen, dass zu viele Anwendungen gleichzeitig im Hintergrund laufen. In
diesem Fall öffnen Sie bitte die Anwendung „Task Killer“ und beenden diejenigen Anwendungen, die Sie
im Augenblick nicht benötigen.

DE - 26

(1) Öffnen Sie die “Task Killer”

Anwendung.

(2) Wählen Sie die Anwendungen, die

Sie aktuell nicht benötigen.

(3) Zur Bestätigung Ihrer Auswahl tippen Sie bitte kurz auf das “Kill selected

apps” Symbol.

15.) Eingeschränkte Garantiebedingungen

Die Garantie deckt nur den Ersatz dieses Intenso Produkts ab. Die Garantie gilt nicht für normale
Verschleißerscheinungen, die sich aus fehlerhaftem, unsachgemäßem Gebrauch, Nachlässigkeit, Unfall,
Inkompatibilität, oder aus mangelhafter Leistung einer bestimmten Computer Hardware oder Computer
Software ergeben.

Es besteht kein Garantieanspruch bei Nichteinhaltung der Intenso Bedienungsanleitung sowie bei
unsachgemäßer Montage, Gebrauch oder bei Defekten durch andere Geräte.

Wird das Produkt Erschütterungen, elektrostatischer Entladungen, Wärme- oder Feuchtigkeitseinwirkungen
jenseits der Produktspezifikationen ausgesetzt, besteht kein Garantieanspruch.

Intenso haftet nicht für Datenverluste oder jegliche, auftretende Begleitschäden oder Folgeschäden, für die
Verletzung der Garantiebedingungen oder für sonstige Schäden, gleich welche Ursache zugrunde liegt.

Dieses Produkt ist nicht für eine kommerzielle Nutzung oder für medizinische und spezielle Anwendungen
vorgesehen, in denen der Ausfall des Produktes Verletzungen, Todesfälle oder erhebliche Sachschäden
verursachen kann.

DE - 27

16.) Technische Daten

CPU

1.5 GHz Dualcore based on Cortex A9

Arbeitsspeicher

1 GB DDR 3

Betriebssystem

Android 4.1.1

Kompatible Betriebssysteme

Windows XP / Vista / 7 / Linux 2,4 und höher / Mac 10.6
und höher

Anschlussmöglichkeiten

Kopfhörer, Micro SD (SDHC), micro USB, HDMI

WLAN

WiFi (802.11 b/g/n)

G-Sensor

360 Grad Rotation

E-Book

PDF / EPUB / TXT / PDB / RTF

Photo Format

JPEG, BMP, GIF, PNG

Audio Format

MP3, WMA, WAV, OGG, FLAC, APE

Video Format

MPEG1, MPEG 4, FLV

Display

TFT LCD Display, 1024 x 768 Pixel

Kamera

0,3 MP Front Kamera

SNR

>= 75 dB

Frequenzbereich

20 Hz – 20 KHz

Netzteil

(V) AC Adapter (Ktec KSAS0100500200HE): AC Input
100-240V～50/60Hz, DC Output 5V / 2A

Interne Batterie

Wiederaufladbarer Lithium-Ionen Polymer Akku

17.) Wartung des Gerätes

Sprühen oder Tragen Sie niemals eine Flüssigkeit direkt auf das Display oder
Gehäuse auf.

18.) Säuberung des Gerätes

Wischen Sie Gehäuse, Rahmen und Display vorsichtig mit einem weichen,
fussel- und chemikalienfreien Tuch ab. Verwenden Sie nur Reinigungsmittel,
die speziell für Displays bestimmt sind.

19.) Entsorgung von Elektro-Altgeräten

Die mit diesem Symbol gekennzeichneten Geräte unterliegen der
europäischen Richtlinie 2002/96/EC.
Alle Elektro- und Elektroaltgräte müssen getrennt vom Hausmüll über
die dafür vorgesehenen staatlichen Stellen entsorgt werden.
Mit der ordnungsgemäßen Entsorgung von Elektro-Altgeräten
vermeiden Sie Umweltschäden.

DE - 28

20.) Lizenzinformation

HINWEIS!

Sehr geehrte Kundin, sehr geehrter Kunde,
bei Interesse können Sie und jeder Dritte den Quelltext der verwendeten GPL/LGPL von der Intenso
Homepage http://www.intenso.de herunterladen. Der Quelltext des gesuchten Produkts ist für jeden
zugänglich über Auswahl der gültigen Produktkategorie und des gewünschten Gerätes. In den

Produktdetails finden Sie den Menüpunkt „Treiber“. Öffnen Sie dieses Menü, um den zugehörigen
GPL/LGPL Quelltext herunterzuladen. Gegen eine Kostenpauschale von 15 € ist es ebenfalls möglich diesen

Quelltext per Postzustellung zu erhalten.
Gerne können Sie uns auch telefonisch zu dem Thema erreichen unter der kostenpflichtigen Rufnummer
0900-1504030 (0,39€/Minute aus dem deutschen Festnetz. Mobilfunkpreise können abweichen.) oder per
Mail an [e-mail]
Weitere Informationen über die GPL/LGPL-Lizenzen finden Sie unter www.gnu.org

GNU GENERAL PUBLIC LICENSE

Version 2, June 1991
Copyright (C) 1989, 1991 Free Software Foundation, Inc.
51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA

Everyone is permitted to copy and distribute verbatim copies
of this license document, but changing it is not allowed.

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast,
the GNU General Public License is intended to guarantee your freedom to share and change free software-­to make sure the software is free for all its users. This General Public License applies to most of the Free
Software Foundation's software and to any other program whose authors commit to using it. (Some other
Free Software Foundation software is covered by the GNU Lesser General Public License instead.) You can
apply it to your programs, too.
When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are
designed to make sure that you have the freedom to distribute copies of free software (and charge for this
service if you wish), that you receive source code or can get it if you want it, that you can change the
software or use pieces of it in new free programs; and that you know you can do these things.
To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you
to surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of
the software, or if you modify it.
For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the
recipients all the rights that you have. You must make sure that they, too, receive or can get the source code.
And you must show them these terms so they know their rights.
We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives
you legal permission to copy, distribute and/or modify the software.
Also, for each author's protection and ours, we want to make certain that everyone understands that there is
no warranty for this free software. If the software is modified by someone else and passed on, we want its
recipients to know that what they have is not the original, so that any problems introduced by others will not
reflect on the original authors' reputations.
Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that
redistributors of a free program will individually obtain patent licenses, in effect making the program
proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use
or not licensed at all.
The precise terms and conditions for copying, distribution and modification follow.

TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This License applies to any program or other work which contains a notice placed by the copyright holder
saying it may be distributed under the terms of this General Public License. The "Program", below, refers to
any such program or work, and a "work based on the Program" means either the Program or any derivative
work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or
with modifications and/or translated into another language. (Hereinafter, translation is included without
limitation in the term "modification".) Each licensee is addressed as "you".
Activities other than copying, distribution and modification are not covered by this License; they are outside

DE - 29

its scope. The act of running the Program is not restricted, and the output from the Program is covered only if
its contents constitute a work based on the Program (independent of having been made by running the
Program). Whether that is true depends on what the Program does.

1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any
medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright
notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of
any warranty; and give any other recipients of the Program a copy of this License along with the Program.
You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty
protection in exchange for a fee.

2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the
Program, and copy and distribute such modifications or work under the terms of Section 1 above, provided
that you also meet all of these conditions:
a) You must cause the modified files to carry prominent notices stating that you changed the files and the
date of any change.
b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from
the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of
this License.
c) If the modified program normally reads commands interactively when run, you must cause it, when started
running for such interactive use in the most ordinary way, to print or display an announcement including an
appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a
warranty) and that users may redistribute the program under these conditions, and telling the user how to
view a copy of this License. (Exception: if the Program itself is interactive but does not normally print such an
announcement, your work based on the Program is not required to print an announcement.)
These requirements apply to the modified work as a whole. If identifiable sections of that work are not
derived from the Program, and can be reasonably considered independent and separate works in
themselves, then this License, and its terms, do not apply to those sections when you distribute them as
separate works. But when you distribute the same sections as part of a whole which is a work based on the
Program, the distribution of the whole must be on the terms of this License, whose permissions for other
licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.
Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you;
rather, the intent is to exercise the right to control the distribution of derivative or collective works based on
the Program.
In addition, mere aggregation of another work not based on the Program with the Program (or with a work
based on the Program) on a volume of a storage or distribution medium does not bring the other work under
the scope of this License.

3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or
executable form under the terms of Sections 1 and 2 above provided that you also do one of the following:
a) Accompany it with the complete corresponding machine-readable source code, which must be distributed
under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,
b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no
more than your cost of physically performing source distribution, a complete machine-readable copy of the
corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium
customarily used for software interchange; or,
c) Accompany it with the information you received as to the offer to distribute corresponding source code.
(This alternative is allowed only for noncommercial distribution and only if you received the program in object
code or executable form with such an offer, in accord with Subsection b above.)
The source code for a work means the preferred form of the work for making modifications to it. For an
executable work, complete source code means all the source code for all modules it contains, plus any
associated interface definition files, plus the scripts used to control compilation and installation of the
executable. However, as a special exception, the source code distributed need not include anything that is
normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on)
of the operating system on which the executable runs, unless that component itself accompanies the
executable.
If distribution of executable or object code is made by offering access to copy from a designated place, then
offering equivalent access to copy the source code from the same place counts as distribution of the source
code, even though third parties are not compelled to copy the source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this
License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will
automatically terminate your rights under this License. However, parties who have received copies, or rights,

DE - 30

from you under this License will not have their licenses terminated so long as such parties remain in full
compliance.

5. You are not required to accept this License, since you have not signed it. However, nothing else grants
you permission to modify or distribute the Program or its derivative works. These actions are prohibited by
law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based
on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for
copying, distributing or modifying the Program or works based on it.

6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically
receives a license from the original licensor to copy, distribute or modify the Program subject to these terms
and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted
herein. You are not responsible for enforcing compliance by third parties to this License.

7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not
limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise)
that contradict the conditions of this License, they do not excuse you from the conditions of this License. If
you cannot distribute so as to satisfy simultaneously your obligations under this License and any other
pertinent obligations, then as a consequence you may not distribute the Program at all. For example, if a
patent license would not permit royalty-free redistribution of the Program by all those who receive copies
directly or indirectly through you, then the only way you could satisfy both it and this License would be to
refrain entirely from distribution of the Program.
If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance
of the section is intended to apply and the section as a whole is intended to apply in other circumstances.
It is not the purpose of this section to induce you to infringe any patents or other property right claims or to
contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free
software distribution system, which is implemented by public license practices. Many people have made
generous contributions to the wide range of software distributed through that system in reliance on consistent
application of that system; it is up to the author/donor to decide if he or she is willing to distribute software
through any other system and a licensee cannot impose that choice.
This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this
License.

8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by
copyrighted interfaces, the original copyright holder who places the Program under this License may add an
explicit geographical distribution limitation excluding those countries, so that distribution is permitted only in
or among countries not thus excluded. In such case, this License incorporates the limitation as if written in
the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the General Public License
from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to
address new problems or concerns.
Each version is given a distinguishing version number. If the Program specifies a version number of this
License which applies to it and "any later version", you have the option of following the terms and conditions
either of that version or of any later version published by the Free Software Foundation. If the Program does
not specify a version number of this License, you may choose any version ever published by the Free
Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are
different, write to the author to ask for permission. For software which is copyrighted by the Free Software
Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will
be guided by the two goals of preserving the free status of all derivatives of our free software and of
promoting the sharing and reuse of software generally.
NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE
PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE
STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE
PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND
PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE,
YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY
COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE
PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL,

DE - 31

SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO
USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED
INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE
PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER
PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS
How to Apply These Terms to Your New Programs

If you develop a new program, and you want it to be of the greatest possible use to the public, the best way
to achieve this is to make it free software which everyone can redistribute and change under these terms.
To do so, attach the following notices to the program. It is safest to attach them to the start of each source
file to most effectively convey the exclusion of warranty; and each file should have at least the "copyright"
line and a pointer to where the full notice is found.

one line to give the program's name and an idea of what it does.
Copyright (C) yyyy name of author
This program is free software; you can redistribute it and/or
modify it under the terms of the GNU General Public License
as published by the Free Software Foundation; either version 2
of the License, or (at your option) any later version.

This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
GNU General Public License for more details.
You should have received a copy of the GNU General Public License
along with this program; if not, write to the Free Software
Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA.

Also add information on how to contact you by electronic and paper mail.
If the program is interactive, make it output a short notice like this when it starts in an interactive mode:

Gnomovision version 69, Copyright (C) year name of author
Gnomovision comes with ABSOLUTELY NO WARRANTY; for details
type `show w'. This is free software, and you are welcome
to redistribute it under certain conditions; type `show c'
for details.

The hypothetical commands `show w' and `show c' should show the appropriate parts of the General Public
License. Of course, the commands you use may be called something other than `show w' and `show c'; they
could even be mouse-clicks or menu items--whatever suits your program.
You should also get your employer (if you work as a programmer) or your school, if any, to sign a "copyright
disclaimer" for the program, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright
interest in the program `Gnomovision'
(which makes passes at compilers) written
by James Hacker.

signature of Ty Coon, 1 April 1989
Ty Coon, President of Vice

DE - 32

Datum: 12.07.2013

Intenso GmbH

EG Konformitätserklärung

Wir, die Intenso GmbH,
mit Sitz in der Diepholzerstr. 15 in 49377 Vechta, Deutschland

erklären auf eigene Verantwortung, dass das Produkt:

Modell: 8“ Intenso TAB814 (Artikel Nr. 5510862)
Beschreibung: Tablet-Computer

auf das sich diese Erklärung bezieht, mit den folgenden Richtlinien und Normen konform ist:

R&TTE Richtlinie 1999/5/EG

 EN 301 489-1 V1.9.2
 EN 301 489-17 V2.1.1
 EN 300 328 V1.7.1 : 2006-10
 EN 55022:2010 (Class B)
 EN 55024:2010
 EN 61000-3-2:2006+A1 :2009+A2 :2009 (Class D)
 EN 61000-3-3:2008

Niederspannungsrichtlinie 2006/95/EG

 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A12:Berichtigung 2012

Öko-Design Richtlinie 2009/125/EG

 1275/2008
 278/2009

ROHS Richtlinie 2011/65/EU

Die auf das oben angeführte Gerät bezogenen technischen Unterlagen sind an folgender Stelle
hinterlegt:

Intenso GmbH
Diepholzerstr. 15, 49377 Vechta, Deutschland

Autorisierte Person:

____________________________
Geschäftsführer: Thomas Pöhlking

EN - 1

Instruction manual TAB 814

Thank you for choosing the TAB814. Please follow these instructions in order to be informed about
the key functions of the device.

1.) Contents

1.) Contents ................................................................................................................................................................................................ 1

2.) Notes ..................................................................................................................................................................................................... 2

3.) Device overview..................................................................................................................................................................................... 4

4.) Package contents .................................................................................................................................................................................. 4

5.) Charging the battery .............................................................................................................................................................................. 5

6.) Using a Micro SD/SDHC Card ............................................................................................................................................................... 5

7.) Transfer of Data between Device and Computer ................................................................................................................................... 5

8.) Touchscreen .......................................................................................................................................................................................... 6

9.) The Home Screen.................................................................................................................................................................................. 7

View ............................................................................................................................................................................................................ 7

Unlocking the screen .................................................................................................................................................................................. 7

Status bar ................................................................................................................................................................................................... 8

Adjusting the main screen ........................................................................................................................................................................... 8

Using several home screens ....................................................................................................................................................................... 9

Pre-installed applications on the home screen ........................................................................................................................................... 9

a) Search bar for Google™ search ........................................................................................................................................................... 10

b) Applications overview ........................................................................................................................................................................... 10

c) Weather forecast................................................................................................................................................................................... 11

d) WiFi ...................................................................................................................................................................................................... 11

Automatic connection................................................................................................................................................................................ 11

Manual connection .................................................................................................................................................................................... 12

e) Gallery .................................................................................................................................................................................................. 12

f) Music ..................................................................................................................................................................................................... 13

g) Video .................................................................................................................................................................................................... 15

h) App Center ........................................................................................................................................................................................... 15

i) Web browser .......................................................................................................................................................................................... 15

Using the virtual keyboard ........................................................................................................................................................................ 15

Special character input ............................................................................................................................................................................. 16

Using the web browser ............................................................................................................................................................................. 16

j) Applications overview ............................................................................................................................................................................ 17

Applications overview ............................................................................................................................................................................... 17

k) System settings..................................................................................................................................................................................... 17

Settings overview ...................................................................................................................................................................................... 18

10.) E-Books ................................................................................................................................ ............................................................. 19

Copying e-books between computer and device ...................................................................................................................................... 19

Downloading e-books and transferring them to the device using Adobe™ Digital Editions ...................................................................... 19

Start reading ............................................................................................................................................................................................. 20

Switch from shelf view to list view / deleting E-books ............................................................................................................................... 20

Scrolling pages ......................................................................................................................................................................................... 20

Increasing font size ................................................................................................................................................................................... 20

Jumping to a specific page ....................................................................................................................................................................... 21

Using bookmarks ...................................................................................................................................................................................... 21

Displaying the contents ............................................................................................................................................................................. 21

Displaying book information ...................................................................................................................................................................... 21

11.) Sending / Receiving E-Mails .............................................................................................................................................................. 21

Setting up your e-mail box ........................................................................................................................................................................ 21

Managing email accounts ......................................................................................................................................................................... 22

Viewing e-mail messages ......................................................................................................................................................................... 23

Writing email messages ............................................................................................................................................................................ 23

12.) Managing Applications ....................................................................................................................................................................... 23

EN - 2

Installing applications ................................................................................................................................................................................ 23

Uninstalling applications ........................................................................................................................................................................... 23

13.) Reading Office Documents ................................................................................................................................................................ 24

14.) Task Manager .................................................................................................................................................................................... 24

15.) Limited Warranty Terms .................................................................................................................................................................... 25

16.) Technical Data ................................................................................................................................................................................... 26

17.) Maintenance of the Device ................................................................................................................................................................ 26

18.) Cleaning the Device........................................................................................................................................................................... 26

19.) Disposal of Used Electronic Equipment ............................................................................................................................................. 26

20.) Licenceinformation about GNU/LGPL................................................................................................................................................ 27

EC Declaration of Conformity........................................................................................................................................................................ 31

This manual may not contain all the features of your device. For the use of third-party applications, please contact the
respective manufacturer. Please note that all details can be modified without previous announcement. Current information

can be found at www.intenso.de.

Trademarks

Google™, the Google™ logo and Android ™ are trademarks of Google™. All other product or service names are the property

of their respective owners.

2.) Notes

 Avoid hard impacts to the device. Do not place it on inclined surfaces to prevent the device from

falling down.

 Do not use the device in extremely cold, hot, humid or dusty areas; also do not expose to direct

sunlight.

 Do not use it on sandy places.
 Do not use it in hazardous environments, such as fuelling pumps at petrol stations.
 Avoid using it on cushions, sofas or other objects that foster heat generation, due to the risk of

overheating.

 Perform frequent data backups to avoid potential data loss. We are not liable for any loss of

data.

 Do not disconnect when data is being transferred or the device formatted. This can cause data

loss.

 Images and movies can be protected by third-party rights. Playing without a license can violate

copyrights.

 Avoid use in highly magnetic fields.
 Protect the unit from moisture. Should moisture enter the unit, please turn it off immediately,

clean it and dry the unit.

 Please do not use chemical solvents to clean the device. Use only a dry cloth.
 Do not place open flames, such as lighted candles, near or on the device.
 We are not liable for damages caused by malfunctions, data losses, incorrect handling, own

repairs to the device or changing of the batteries.

EN - 3

 Should the device not respond to your requests, please restart the device by pressing the reset

button on the back of it.

 When not in use, please disconnect the mains adaptor from the power supply.
 The outlet must be near the equipment and easily accessible.
 Only use the AC adapter with grounded outlets with AC 100-240V, 50/60 Hz. If you are not sure

about the power supply at installation site, please ask the relevant energy services.

 Use only the included AC adapter and power cord.
 To interrupt the power supply to your unit, unplug the AC adapter from the outlet. Always hold

the adapter firmly when disconnecting the power supply. Never pull on the line.

 Do not open the housing of the power adapter. With open housing, there is danger of electrical

shock. It contains no user-serviceable parts.

 When not in use, the battery of the device discharges slowly. Prior to reuse it must be

recharged.

 Please observe environmentally sound disposal of the device and the battery.
 Please do not disassemble into parts or try to repair it yourself because in these cases the

warranty expires.

 Do not use the device in places where the use of mobile devices is prohibited. Do not use the

device in the vicinity of other electronic devices because the high-frequency signals can cause
interferences.

 Do not use it near a pacemaker, in a hospital or near medical equipment, because the high-

frequency signals may cause interferences. Keep a distance of at least 15 cm from a
pacemaker. Please contact the manufacturer of these devices to obtain information about joint
use.

 The use of earbuds or headphones at high volumes can lead to permanent hearing damage.
 For reasons of traffic safety, the device may not be operated by the driver himself while driving.

EN - 4

3.) Device overview

a) Touchscreen
b) Front Camera
c) Loading Status LED. A red light flashes

while loading. A yellow light flashes, as
soon as the battery is completely loaded

d) 3.5mm headphone jack
e) Built-in microphone
f) DC 5V 2A input
g) Micro USB Socket

h) On / Off button: Press and hold to turn

the unit off, press briefly to switch
between standby and active mode

i) Volume +/­j) Integrated speaker
k) Reset hole: Resets the unit should it no

longer respond.

l) Micro SD Card slot
m)HDMI

4.) Package contents

Please check if the contents are complete:

 TAB 814
 Stereo headphones
 USB cable
 Power supply 5V 2.0A
 User Manual
 Bag in leather look

EN - 5

5.) Charging the battery

Fully charge the battery of the device before using it for the first time. To this end connect the supplied
power cable with the device and a socket. The complete charging process takes about 5 hours. The
charging status is displayed at the front left side of the device. The LED lights up Red during the
charging process, and changes to Yellow as soon as the battery is fully charged.

Notes

a. With 15% remaining residual power of the battery you will get a warning message on the display. To recharge the battery, you

should now connect the device using the AC adapter to an electrical outlet to avoid possible data loss and increase the battery life.
b. You can use the device while charging the battery. To ensure long-lasting battery life, we ask you not to use the device.
c. To ensure good performance, the built-in battery must be used frequently. If you use the device often, please charge the battery

fully at least once a month.
d. Make sure you use only the included AC adapter for charging.

6.) Using a Micro SD/SDHC Card

This device is able to read data directly from a Micro SD/SDHC memory card.
In order to use a Micro SD/SDHC memory card, slide the card into the opening provided at the bottom of

the device (I). Use the pre-installed Explorer (more information is to be found in the extensive
operating instructions), to be able to access the data provided on the memory card. For this, please
select the “SD Card“ in the index of the Explorer.

7.) Transfer of Data between Device and Computer

1.) Connect the device using the included USB cable to a computer. Should the device not have been

previously switched on, it will start automatically. This may take a moment, because the operating
system must first boot up. If device was already switched on, the computer should automatically
detect it within a few seconds.

2.) On the device the screen for the USB connection is now displayed. Tap briefly "Turn on USB

Storage". The device is recognized as a removable disk and you get the info "USB memory in use".
After briefly tapping the home button you can continue to use your device normally. You have now
have access to the internal memory of the device from your computer and can copy, delete or
transfer files to your device.

3.) If an USB connection with the computer exists, the USB icon is displayed in the status bar. You can get
additional information in the extended status bar (click on the clock in the status bar to open it) and you

can activate or deactivate the USB connection.

EN - 6

 Select `Turn off USB storage´ to deactivate the memory.

Select the function `Remove safely´ on the computer to separate the device from the
computer.

Note: The pre-installed applications and the Android™ operating system take up some of the existing internal memory. For this reason,
you cannot dispose of the entire internal memory.

8.) Touchscreen

This device is operated via touchscreen. You can easily start applications by tapping the touchscreen
lightly with your fingers, enter texts on the virtual keyboard and switch between the individual main
screens by wiping in the respective direction.

Please remove the protective film from the display before using the device.
The touchscreen detects small electrical charges, as for example emitted by human fingers, and thus

determines the input point.
Use for input ideally your fingertips. Operation with a pen or other sharp objects is not possible.

The touchscreen should not be exposed to water or other electrical devices to avoid malfunctions and

permanent defects.

Notes
a. If the touchscreen is not operated for two minutes, the device goes into standby mode. Briefly press the on / off button to switch to

active mode.

b. To prevent unwanted input, a lock mode is activated automatically. Please unlock the keypad on the touchscreen by simply

dragging the lock icon from the bottom to the top of the screen. The device will now switch to the home screen. Touch the closed
lock on the display and keep it pressed. Draw the lock now to the open lock just appearing on the display and release

your finger from the display. The screen is now unlocked.

You can rotate the device in all directions. It has a sensor that directs the display automatically.

EN - 7

9.) The Home Screen

View

Unlocking the screen

If the touchscreen is not used for two minutes, the device changes into standby mode. Press the on/off
button for a short time to return to the active mode. The locked display is protecting against undesired
input. Touch the closed lock on the display and keep it pressed. Draw the lock now to the open lock

just appearing on the display and release your finger from the display. The screen is now unlocked.

Drag the lock icon with your finger in the direction of the arrow

Advice: Draw the lock symbol to the appearing camera symbol to open the camera application directly.

EN - 8

Status bar

back

Home screen

WLAN Connection

Time

Battery

Recently used
programs

The status bar is to be found in the lower section of the starting screen. It has the following functions:

Here you will receive information on:

 the last used programmes
 the signal strength of the present WIFI connection
 the time
 the present status of the battery

You can carry out the following functions:

 Call up the starting screen
 Go back one step in the relevant called up menu
 Call up the last used programmes

You can open the extended status bar with a short tap on the clock. Here the latest status messages
are displayed. Various quick accesses, for example access to the settings, are displayed, if you tap
the clock in the extended status bar again.

Adjusting the main screen

You can adjust the main screen easily to your individual needs. If you want to delete an icon, tap the icon
with your finger for a short while and then push it into the displayed X icon. Now take your finger from the
touchscreen and the icon is deleted.

If you want to position an icon from the application overview on the main screen, tap the icon in the

application overview for a short while and the main screen appears. Move the icon to the desired
position and take your finger from the touchscreen. The icon is now added to the main screen. If you

move an icon on another icon, a folder containing both icons is automatically created. Tap the folder to view
the containing icons and then select the desired icon by tapping it briefly.

You can also add widgets to the main screen. To do that, please tap the button in the top right corner
of the main screen and the application menu will be opened. Now tap the word widgets. All widgets

available on the device are now presented to you. Adding a widget to the main screen works exactly like
adding an icon.

If you want to change your background image, just tap a free place on the main screen and keep pressing
the display until the background selection menu appears. Now select the source of the desired image and
proceed as follows:

EN - 9

Using several home screens

A Link to Google™ search

B Application overview

C Global weather forecast

D Apps on the main screen

E Status bar: Back, Home, recently used
programmes, time, WiFi, battery status

Five main screens that can be individually set-up are provided. You can easily switch between them by
wiping the screen lightly to the left or right.

Pressing the home button will always take you automatically back to the middle home screen.

Pre-installed applications on the home screen

Various applications are pre-installed on the home screen:

- Search bar for the Google™ search

- Weather forecast

- WiFi

- Gallery

- Music

- Video

- AndroidPIT (App Center)

EN - 10

a) Search bar for Google™ search

Tap the magnifier briefly to open the Google™ search function. Enter the desired search item using the
virtual keyboard and then press go. All available search results of the Google™ search will now be

displayed.

 Tip: With a rapid upward or downward movement the device quickly

scrolls through a list, after releasing the finger from the touchscreen. This

Note: For this function, a wireless Internet connection is required.

b) Applications overview

works for all displays that are larger than the screen.

Tap this icon to open the application overview. Here all applications installed on the device will be displayed.
You can start any application by tapping the corresponding icon.

EN - 11

c) Weather forecast

The weather forecast widget shows you at a glance the current time, date, weather conditions and
temperature at the set location.

To change the settings, please go to the applications overview and tap the Weather Forecast icon.
You can now make the desired changes.

Setting menu of the weather forecast

Note: For this function, a wireless Internet connection is required.

d) WiFi

To connect your device with the internet, you require a WIFI connection. In order to establish this, touch
the WIFI icon on the starting screen, or open the WIFI setting within Settings.

Note: Please note that a wireless network must be located within the range of your current location.

Automatic connection

Open the WIFI settings via the WIFI icon or via Settings. Here you can quite simply activate or deactivate
the WIFI function. Simply slide the virtual key from its position “on“ to the left to deactivate the WIFI
function. The display changes to “off”.

To activate the deactivated WIFI function again, just slide the virtual key to the right.

On the right hand side of the WIFI settings, all available networks as well as all already used networks

are shown.

EN - 12

Tap on the desired network and, if required, enter the appropriate WiFi key (password) to establish a

connection.

Confirm the entered password, if necessary, by touching the enter key and then select Connect. After a
short while you are connected.

Notes

a) If the device goes into standby mode, WiFi is turned off automatically. This reduces power consumption and thus automatically

leads to a longer battery life. When the device returns to active mode, the WiFi will automatically re-connect. This may take a few

seconds.
b) The list of currently searchable WiFi networks will be updated automatically.
c) If the WiFi function is enabled, the device automatically connects to an already configured network, provided it is within range.
d) If an unknown wireless network is in range, an information box will appear.

Manual connection

In order to search for an accessible WiFi network manually, please proceed as follows:
(1) Open the settings.
(2) Now open the WiFi settings and tap `Scan´.
(3) Should the WiFi network not appear in the list of available networks then select the item `Add

network´ in order to enter the network SSID, the security protocol and the possibly related password.
Tap `Save´ to confirm your entries.

e) Gallery

Tap briefly on the Gallery icon to get an overview of all existing albums and images.
Select the desired gallery, and then again the desired image by short tapping. The image will now be

displayed full screen.

Tap the photo icon to choose between different grouping options.

EN - 13

Artists

Shows all music files sorted according to the
individual artists.

Albums

Shows all music files sorted according to the
individual albums.

Songs

Shows all music files sorted by title.

Playlists

Displays the created playlists.

Now Playing

Jumps directly to the current playback.

To view the next or previous image, just move the current image with
your finger to the left or right of the screen.

Place two fingers on the touchscreen and pull them apart to enlarge the
image continuously. If you merge the fingers again, the picture is infinitely

reduced. By tapping briefly twice on the touchscreen, the image is
automatically enlarged and by double-tapping again displayed in its

original size.

By briefly tapping the touchscreen, additional functions are available.

Tap the `Menu´ icon to get additional options
Here you can start a slide show, edit, rotate, and cut the image, set
it as background image or view the image details.

Tap the dustbin icon to delete the selected image.
Tap the sharing icon in order to send the image, for instance

via email.

f) Music

Briefly tap the Music icon on the home screen or applications overview to open the music player.
In the following view you can choose to display your music sorted by Artist, Album, Songs, Playlists or

Now playing. Just tap briefly on the icon.

Select by briefly tapping the name of the file and the music playback starts.

EN - 14

Playback Screen

(1) Now playing
(2) Shuffle activate / deactivate
(3) Repeat options:

a) all titles will be repeated
b) current title is repeated
c) repetition is disabled

(4) Title details
(5) Next / Previous track
(6) Play / Pause
(7) Timeline

 Tap the pause icon to pause playback.
 To resume playback, tap the play icon .
 Tap the forward or backward icon / to play the previous or next title.
 Tap a spot on the timeline to continue playing it right at this point.

 Press the volume +/- keys on the side of the device to adjust the volume.

 To open the preview the current playlist, tap on the playlist icon . Tap on a title to play it

directly.

 To change the repeat mode, tap the repeat mode icon .
 To go to the home screen, tap briefly on the home button . This will not stop the music

playback. You can for instance surf the browser on the Internet while listening to your music.
Just tap on the music icon again to go to back to playback.

In playback mode you can further adjust your settings. Tap briefly on the Menu button .

Library – a list of all existing music files will be displayed.
Party shuffle – turns on/off Party Shuffle mode.
Add to playlist – adds currently playing title to a playlist.
Delete – deletes the current title.

Sound effects – sets a sound effect to the music playback.

EN - 15

g) Video

a. Caps lock (case sensitive)
b. Return button
c. Calling up the menu for numbers, characters and

special character input
d. Space bar (no character input)
e. Go (confirmation of your input)

Tap briefly on the Video icon in the home screen or the applications overview, to open the video

playback.

It will now display the video files in a list. Select the desired file by briefly tapping and the video will start.

h) App Center

The AndroidPIT App Center is already installed on the device. Here you will find various apps, reviews, a

blog and a forum.

For further information or assistance on use of the App Center, please visit the homepage of the provider
under www.androidpit.de.

Note: For this function, a wireless Internet connection is necessary.

i) Web browser

To launch the web browser, tap on the Browser icon on the home screen.
To open a website, tap on the upper input field for the Internet address. The virtual keyboard now
opens and you can enter the address of the desired website. To open the website, tap "Go" or tap on
the arrow icon next to the input field.

Note: Not all networks provide Internet access. Some networks offer access only to other related local computers but not Internet
connection.

Using the virtual keyboard

Tap the box to open the virtual keyboard. You can now enter text or websites.

EN - 16

Special character input

In order to enter a special character such as `ä´, tap the `a´ key with your finger for a long time to call up
the special character menu. Now glide with your finger to the desired special character, for example an `ä´
and take your finger from the display. You now have entered an `ä´.

Using the web browser

 You can scroll through the display by performing a vertical sweeping motion with your finger.

Please do not start the sweeping motion on a menu item or link because otherwise the existing link

will open.

 To open an Internet link, simply tap on the link. The new page will open automatically.

 Press the menu key to open the web browser menu. Here multiple functions are provided. Among

other things you can refresh the opened website here, open a new tab, make offline websites
readable or switch to the web browser settings.

 To return to the previous page, please press the back button .
 To go directly back to home screen, press the home button .

 To enter a text, tap the appropriate field and use the virtual keyboard for entering the text.

Note: For this function, a wireless Internet connection is required.

EN - 17

j) Applications overview

Tap briefly on the applications overview icon to open the applications overview. You will see a list of
all pre-installed applications as well as those you have already installed. Open the desired application
by briefly tapping the appropriate icon.

Applications overview

k) System settings

Tap the settings icon in the application menu to call up the system settings.

 You can find the individual categories on the left side of the menu. The available setting options

are displayed by briefly pressing each selected menu item. Please note that possibly not all functions
offered by Android™ are compatible with the device.

 When you have adjusted all settings you can return to the previous menu with the Return key , or

switch to the main screen directly with the Home key . Your entries will be saved automatically.

EN - 18

Settings overview

WiFi & Networks

WiFi

Here you can adjust the WiFi settings.

More

Here you can adjust additional network settings.

Device

Sounds

Specify the desired volume and sound for messages here. Also you can
activate or deactivate a confirmation sound when touching the screen and an
indication sound when unlocking the display lock.

Display

Brightness – Adjust display brightness.
Background – Selection of the background.
Rotate display autom – Activation or deactivation of the automatic display

alignment when rotating the device.

Idle state– Adjust the delay before automatic display deactivation.
Font size – set-up of the desired font size.

Memory

Here you can get information about the internal memory and – if inserted –
about your MicroSD card. Also you can delete the memory content.

Battery

Here you can get information about the state of charge of the integrated
batteries.

Apps

Here you can manage installed applications and get information about them.

User

Accounts &
synchronisation

Here you can determine, if and how often the accounts created by you will be
synchronised.

Location services

Here you can allow multiple Android™ applications to determine and use you

current position via WiFi networks (e.g. Google Maps™). You can also

determine, if Google™ may adapt search results and other services to your
location.

Security

Here you can set-up a screen lock, for example, or implement other security­relevant settings.

Language & input

Here you can set your preferred language, for example, or add various words
to your personal dictionary or adjust.

Save & reset

Here you can save your system settings and application data on Google™

servers. Furthermore you can reset the factory settings. CAUTION: In doing
so, all data saved on the device will be deleted.

System
Date & time

Here you can set the date, time, time zone, and the display format.

About the Tablet

Shows additional information about the device.

EN - 19

10.) E-Books

This unit has a preloaded e-book reader.

Copying e-books between computer and device

You can copy e-books via a USB connection to the internal memory of your device. Please take a look

at the section "Transfer of Data between Device and Computer".

Note: Please make sure that the e-book has one of the following formats: PDF, EPUB, TXT, FB2, RTF, PDB.

Downloading e-books and transferring them to the device using Adobe™ Digital Editions

The Adobe™ Digital Editions application allows you to download DRM-protected
e-books to your computer.

(1) Download the website http://www.adobe.com/de/products/digitaleditions/

and install Adobe™ Digital Editions software according to instructions.

(2) Authorization of the computer with your Adobe™ ID and password (if

you do not yet have an Adobe™ ID, please register on the Adobe™ site
for this service).

(3) Now activate the device. Connect the device to the PC using the supplied USB cable and

activate the USB memory. Now, start the Adobe™ Digital Editions software. Click on "Authorize
Device", to authorize your device.

 The Adobe™ ID can be used only 6 times. Then you have to delete the ID by pressing the CTRL+SHIFT+D keys on the computer

or by the setting Erase Activation Record, and request a new ID.

 The tablet remembers the e-books downloaded with the current valid license and overwrites the previous Adobe™ IDs.

(4) Visit an online e-book store with your computer and select the desired e-

book (please make sure that the e-book has one of the following formats:
PDF, EPUB, TXT, FB2, RTF, PDB). If the e-book is DRM protected, usually

this information is shown.

(5) Once you have bought the e-book and downloaded it on your computer,

you should be able to view it on the Adobe™ Digital Editions application.

(6) Now connect your device via USB cable to the computer. The Adobe™

Digital Editions software should now automatically detect your device.

(7) Drag the cover of the e-book on to your device to transfer the file.

EN - 20

Start reading

Open the Application overview and tap the E-Book Reader Icon to open the E-Book Reader. Select the
desired book from the available E-books to begin reading it directly.

Switch from shelf view to list view / deleting E-books

Just tap the list icon below the book shelf to get to the list view.

When you tap the dustbin icon, a red X is added to every E-book. Tap the X on the desired E-book and it
will be directly deleted.

Scrolling pages

If you read a book, you can scroll page by page by swiping your finger.
You can also turn pages automatically. Tap on the menu button in
order to access advanced settings. Now select "Auto Flip" and the
desired time interval by briefly tapping it.

Increasing font size

(1) Please tap as you read on the menu button to access advanced settings.
(2) Tap on "Zoom" to adjust the desired font size.
(3) Please confirm your selection with "OK".

EN - 21

Jumping to a specific page

(1) While reading, open the advanced settings by tapping the menu button .
(2) Tap "Go to".
(3) Enter the desired page number.
(4) Confirm your selection with "OK".

Using bookmarks

You can add, delete or upload bookmarks.
(1) While reading, open advanced settings with the menu button .
(2) Tap on "Bookmarks" to access the bookmark menu. Here, you can add, delete or view

bookmarks.

Displaying the contents

You can display the contents of the e-book and then directly go to the desired chapter or section, if
the e-book supports this function.
(1) Open while reading advanced settings with the menu button .
(2) Tap on "TOC" to open the table of contents and then tap on the chapter or section where you

want to start reading.

Displaying book information

While reading, you can view the available book information. Tap the menu button and then select
the menu item "BookInfo".

11.) Sending / Receiving E-Mails

An e-mail application is pre-installed in this device. You can use your existing e-mail address to send
and receive e-mails.

Note: For this function, a wireless Internet connection is required.

Open the application with the "Email" icon which is found on the application menu.

Setting up your e-mail box

(1) Start the e-mail application by tapping on the Email icon. You are now prompted to set-up your e-mail

account.

(2) Enter your e-mail address and the corresponding password and then tap "Next". Then name your

account and fix the name that will be displayed on outgoing messages. Tap "Done" to complete
the set-up. Your e-mail mailbox is selected as the default mailbox if you select the option "Send e-
mails from this account by default".

(3) You can set up your e-mail account manually as well. Enter your e-mail address and associated

password and then tap on "Manual Setup" to enter the e-mail server information.

EN - 22

(4) Choose from the server types POP3, IMAP or Exchange for incoming e-mails.

Note: If you do not know what settings you need to make, please contact your e-mail provider, your network administrator or search
terms such as "POP address" and "name of your provider" for the required information on the Internet.

(5) Enter the required information (server, port, etc.).
(6) Select the server type for outgoing e-mails and enter the required information.
(7) Tap "Next" to continue in the menu. The e-mail application will check the server settings made.

After successful set-up you will see the message: "Your account is set up, and email is on its
way". Your account is now set up.

(8) Enter a name for your mailbox, then tap "Done" to complete the process.

Note: If you have more than one email account, each time you start the e-mail application, the default account is called up.

Managing email accounts

Adding a new mailbox:

(1) Open the email application and tap the menu key to display additional options. Select the menu

item `Settings´ and subsequently `Add account´ to create a new mailbox.

(2) Follow the instructions of the Setup Wizard to create a new mailbox.

Deleting a mailbox:

(1) Open the email application and tap the menu key to display additional options. Select the menu

item `Settings´ and subsequently `Delete account´ to delete the desired mailbox.

Checking the account properties:

(1) Open the email application and tap the menu key to display additional options and then select

`Settings´. All already created mailboxes will now be displayed on the left side of the menu.
(2) Tap the desired mailbox to display the account settings.
(3) Tap the `Account setting´ you wish to change in order to make the desired entries.

EN - 23

Viewing e-mail messages

Open the e-mail application by briefly tapping the e-mail icon. The mailbox you already created is

displayed.

 You can scroll through your e-mail with a vertical sweeping motion.
 Tap briefly on a particular e-mail to open it.
 Tap and hold your finger on a particular e-mail in order to display more options – an info box will

be displayed. You can now open, reply, forward or delete the e-mail.

Writing email messages

(1) Tap the Email icon in the top menu bar of the email overview and a new window will open, where you

can write a new email.
(2) Now enter the email address of the recipient, a subject line and the text into the designated fields.

You can also add `Cc/Bcc´ to send this email to several users.
(3) Tap `Send´ to send the email. Tap `Save´ to save the entered email as a draft. When you tap the

`dustbin´ icon, the currently entered email will be deleted.

12.) Managing Applications

Pre-installed applications

This device is delivered with pre-installed applications. You will find an overview of the applications
already installed in the application overview . These include the video player, audio player, Internet

browser, alarm, calculator and others. To open one of these applications, tap on the corresponding
icon.

Installing applications

To install applications on the device, perform the following steps:
(1) Download the software (for example, from the Androidpit Market). Make sure that it is an APK File.
(2) If you have downloaded the files on your computer, connect the device via USB cable to your

computer and copy the files to the internal memory.
(3) Unplug the unit from the computer and open the Explorer to open the copied files.
(4) To install the application, follow the installation instructions appearing on the screen.
(5) After successful installation, you will find the new application in the applications menu.

Uninstalling applications

(1) Open the system settings by briefly tapping the settings icon in the application overview.
(2) Now tap the menu item `Apps´ briefly to get to the application settings.
(3) Choose the desired application overview in the menu items `Download, USB memory, active and all´

by tapping it briefly.
(4) Now select the application you want to deinstall by tapping it briefly.
(5) Now tap `Deinstall´ and confirm your entry with OK to deinstall the application from the device.

Note: You cannot delete pre-installed software.

EN - 24

13.) Reading Office Documents

The application "Office Suite" for reading Office documents has been pre-installed in this device. You
can read Word, Excel, or PowerPoint files.

1.) Copy the desired Office files to the device.

2.) Open the application "Office Suite ".

3.) Navigate using the Explorer to the desired file.

4.) Select the desired file with a short tap and swipe your finger vertically or horizontally across
the screen to scroll between pages. Briefly tap the menu button to open more options.
You can, for example, search for a certain text or count words.

14.) Task Manager

This device is capable of multitasking, allowing you use several applications at once. For example, you
can listen to music and at the same time surf the Internet or view images.
In some circumstances it may happen that too many applications are running simultaneously in the
background. In this case, please open the application "Task Killer" and terminate those applications
you do not need right now.

EN - 25

(1) Open the "Task killer" application.

(2) Select the applications you do not

currently need.

(3) To confirm your selection, please tap briefly on the "Kill selected apps" icon.

15.) Limited Warranty Terms

The warranty covers only the replacement of this Intenso product. The warranty does not cover normal wear
and tear resulting from faulty, improper use, negligence, accident, incompatibility, or poor performance of
specific computer hardware or computer software.

There is no warranty in the case of non-compliance with the Intenso user manual, improper installation, use,
or defects caused by other equipment.

Warranty is also excluded if the product is subjected to the effects of vibration, electrostatic discharge, heat
or moisture beyond the product specifications.

Intenso is not liable for data loss or any collateral damage, or consequential damages, for breach of warranty
or for any other damage, whatever the underlying cause.

This product is not intended for commercial use or for medical and special applications in which the failure of
the product may cause injury, death or substantial property damage.

EN - 26

16.) Technical Data

CPU

1.5 GHz Dualcore based on Cortex A9

Main memory

1 GB DDR 3

Operating system

Android 4.1.1

Compatible operating systems

Windows XP / Vista / 7 / Linux 2.4 and higher / Mac 10.6 and
higher

Connection options

Headphone, Micro SD (SDHC), micro USB, HDMI

Wireless

WiFi (802.11 b/g/n)

G-Sensor

360 degree rotation

E-Book

PDF / EPUB / TXT / PDB / RTF

Photo format

JPEG, BMP, GIF, PNG

Audio format

MP3, WMA, WAV, OGG, FLAC, APE

Video format

MPEG1, MPEG 4, FLV

Display

TFT LCD Display, 1024 x 768 Pixel

Camera

0,3 MP front camera

SNR

>= 75 dB

Frequency range

20 Hz – 20 KHz

Power Supply

(V) AC adapter (Ktec KSAS0100500200HE): AC input 100-
240V～50/60Hz, DC output 5V / 2A

Internal Battery

Rechargeable lithium-ion polymer battery

17.) Maintenance of the Device

Never spray or apply a liquid directly onto the screen or casing.

18.) Cleaning the Device

Wipe the casing, frame and screen gently with a soft, lint-free cloth. Use only
detergents specifically designed for displays.

19.) Disposal of Used Electronic Equipment

Equipment marked with this symbol is subject to the European
Directive 2002/96/EC.
All electrical devices and used electrical equipment must be disposed
of separately from household waste over the appropriate government
agencies.
Proper disposal of old electronic equipment helps avoid
environmental damage.

EN - 27

20.) Licenceinformation about GNU/LGPL

Notice of GNU GENERAL PUBLIC LICENSE and LESSER GENERAL PUBLIC LICENCE

Dear Customer,
If interested, you and any third party can download the source code of used GPL / LGPL from Intenso
Webpage http://www.intenso.de . The source code of the desired product is available to anyone on the
selection of valid product category and the desired device. In the product details you will find the entry

"drivers". Open this menu to download the corresponding GPL / LGPL code. For a fee of 35 € (delivery to

another country as Germany), it is also possible to obtain this code by postal delivery. More information
about the GPL/LGPL-Licence can you find on following website www.gnu.org

GNU GENERAL PUBLIC LICENSE

Version 2, June 1991
Copyright (C) 1989, 1991 Free Software Foundation, Inc.
51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA

Everyone is permitted to copy and distribute verbatim copies
of this license document, but changing it is not allowed.

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast,
the GNU General Public License is intended to guarantee your freedom to share and change free software-­to make sure the software is free for all its users. This General Public License applies to most of the Free
Software Foundation's software and to any other program whose authors commit to using it. (Some other
Free Software Foundation software is covered by the GNU Lesser General Public License instead.) You can
apply it to your programs, too.
When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are
designed to make sure that you have the freedom to distribute copies of free software (and charge for this
service if you wish), that you receive source code or can get it if you want it, that you can change the
software or use pieces of it in new free programs; and that you know you can do these things.
To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you
to surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of
the software, or if you modify it.
For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the
recipients all the rights that you have. You must make sure that they, too, receive or can get the source code.
And you must show them these terms so they know their rights.
We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives
you legal permission to copy, distribute and/or modify the software.
Also, for each author's protection and ours, we want to make certain that everyone understands that there is
no warranty for this free software. If the software is modified by someone else and passed on, we want its
recipients to know that what they have is not the original, so that any problems introduced by others will not
reflect on the original authors' reputations.
Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that
redistributors of a free program will individually obtain patent licenses, in effect making the program
proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use
or not licensed at all.
The precise terms and conditions for copying, distribution and modification follow.

TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This License applies to any program or other work which contains a notice placed by the copyright holder
saying it may be distributed under the terms of this General Public License. The "Program", below, refers to
any such program or work, and a "work based on the Program" means either the Program or any derivative
work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or
with modifications and/or translated into another language. (Hereinafter, translation is included without
limitation in the term "modification".) Each licensee is addressed as "you".
Activities other than copying, distribution and modification are not covered by this License; they are outside
its scope. The act of running the Program is not restricted, and the output from the Program is covered only if
its contents constitute a work based on the Program (independent of having been made by running the
Program). Whether that is true depends on what the Program does.

1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any

EN - 28

medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright
notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of
any warranty; and give any other recipients of the Program a copy of this License along with the Program.
You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty
protection in exchange for a fee.

2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the
Program, and copy and distribute such modifications or work under the terms of Section 1 above, provided
that you also meet all of these conditions:
a) You must cause the modified files to carry prominent notices stating that you changed the files and the
date of any change.
b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from
the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of
this License.
c) If the modified program normally reads commands interactively when run, you must cause it, when started
running for such interactive use in the most ordinary way, to print or display an announcement including an
appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a
warranty) and that users may redistribute the program under these conditions, and telling the user how to
view a copy of this License. (Exception: if the Program itself is interactive but does not normally print such an
announcement, your work based on the Program is not required to print an announcement.)
These requirements apply to the modified work as a whole. If identifiable sections of that work are not
derived from the Program, and can be reasonably considered independent and separate works in
themselves, then this License, and its terms, do not apply to those sections when you distribute them as
separate works. But when you distribute the same sections as part of a whole which is a work based on the
Program, the distribution of the whole must be on the terms of this License, whose permissions for other
licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.
Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you;
rather, the intent is to exercise the right to control the distribution of derivative or collective works based on
the Program.
In addition, mere aggregation of another work not based on the Program with the Program (or with a work
based on the Program) on a volume of a storage or distribution medium does not bring the other work under
the scope of this License.

3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or
executable form under the terms of Sections 1 and 2 above provided that you also do one of the following:
a) Accompany it with the complete corresponding machine-readable source code, which must be distributed
under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,
b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no
more than your cost of physically performing source distribution, a complete machine-readable copy of the
corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium
customarily used for software interchange; or,
c) Accompany it with the information you received as to the offer to distribute corresponding source code.
(This alternative is allowed only for noncommercial distribution and only if you received the program in object
code or executable form with such an offer, in accord with Subsection b above.)
The source code for a work means the preferred form of the work for making modifications to it. For an
executable work, complete source code means all the source code for all modules it contains, plus any
associated interface definition files, plus the scripts used to control compilation and installation of the
executable. However, as a special exception, the source code distributed need not include anything that is
normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on)
of the operating system on which the executable runs, unless that component itself accompanies the
executable.
If distribution of executable or object code is made by offering access to copy from a designated place, then
offering equivalent access to copy the source code from the same place counts as distribution of the source
code, even though third parties are not compelled to copy the source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this
License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will
automatically terminate your rights under this License. However, parties who have received copies, or rights,
from you under this License will not have their licenses terminated so long as such parties remain in full
compliance.

5. You are not required to accept this License, since you have not signed it. However, nothing else grants
you permission to modify or distribute the Program or its derivative works. These actions are prohibited by

EN - 29

law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based
on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for
copying, distributing or modifying the Program or works based on it.

6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically
receives a license from the original licensor to copy, distribute or modify the Program subject to these terms
and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted
herein. You are not responsible for enforcing compliance by third parties to this License.

7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not
limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise)
that contradict the conditions of this License, they do not excuse you from the conditions of this License. If
you cannot distribute so as to satisfy simultaneously your obligations under this License and any other
pertinent obligations, then as a consequence you may not distribute the Program at all. For example, if a
patent license would not permit royalty-free redistribution of the Program by all those who receive copies
directly or indirectly through you, then the only way you could satisfy both it and this License would be to
refrain entirely from distribution of the Program.
If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance
of the section is intended to apply and the section as a whole is intended to apply in other circumstances.
It is not the purpose of this section to induce you to infringe any patents or other property right claims or to
contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free
software distribution system, which is implemented by public license practices. Many people have made
generous contributions to the wide range of software distributed through that system in reliance on consistent
application of that system; it is up to the author/donor to decide if he or she is willing to distribute software
through any other system and a licensee cannot impose that choice.
This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this
License.

8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by
copyrighted interfaces, the original copyright holder who places the Program under this License may add an
explicit geographical distribution limitation excluding those countries, so that distribution is permitted only in
or among countries not thus excluded. In such case, this License incorporates the limitation as if written in
the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the General Public License
from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to
address new problems or concerns.
Each version is given a distinguishing version number. If the Program specifies a version number of this
License which applies to it and "any later version", you have the option of following the terms and conditions
either of that version or of any later version published by the Free Software Foundation. If the Program does
not specify a version number of this License, you may choose any version ever published by the Free
Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are
different, write to the author to ask for permission. For software which is copyrighted by the Free Software
Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will
be guided by the two goals of preserving the free status of all derivatives of our free software and of
promoting the sharing and reuse of software generally.
NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE
PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE
STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE
PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND
PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE,
YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY
COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE
PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO
USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED
INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE
PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER

EN - 30

PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS
How to Apply These Terms to Your New Programs

If you develop a new program, and you want it to be of the greatest possible use to the public, the best way
to achieve this is to make it free software which everyone can redistribute and change under these terms.
To do so, attach the following notices to the program. It is safest to attach them to the start of each source
file to most effectively convey the exclusion of warranty; and each file should have at least the "copyright"
line and a pointer to where the full notice is found.

one line to give the program's name and an idea of what it does.
Copyright (C) yyyy name of author
This program is free software; you can redistribute it and/or
modify it under the terms of the GNU General Public License
as published by the Free Software Foundation; either version 2
of the License, or (at your option) any later version.

This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
GNU General Public License for more details.
You should have received a copy of the GNU General Public License
along with this program; if not, write to the Free Software
Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA.

Also add information on how to contact you by electronic and paper mail.
If the program is interactive, make it output a short notice like this when it starts in an interactive mode:

Gnomovision version 69, Copyright (C) year name of author
Gnomovision comes with ABSOLUTELY NO WARRANTY; for details
type `show w'. This is free software, and you are welcome
to redistribute it under certain conditions; type `show c'
for details.

The hypothetical commands `show w' and `show c' should show the appropriate parts of the General Public
License. Of course, the commands you use may be called something other than `show w' and `show c'; they
could even be mouse-clicks or menu items--whatever suits your program.
You should also get your employer (if you work as a programmer) or your school, if any, to sign a "copyright
disclaimer" for the program, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright
interest in the program `Gnomovision'
(which makes passes at compilers) written
by James Hacker.

signature of Ty Coon, 1 April 1989
Ty Coon, President of Vice

EN - 31

Date: 12

EC Declaration of Conformity

We, the company Intenso GmbH,
with headquarters located at:
Diepholzerstr. 15 in 49377 Vechta, Germany

Declare under our sole responsibility that the product:

Model: 8“ TAB 814 (item no. 5510862)
Description: Tablet computer

is in conformity with the provisions of the following Council Directives:

Directive R&TTE 1999/5/CE

 EN 301 489-1 V1.9.2
 EN 301 489-17 V2.1.1
 EN 300 328 V1.7.1 : 2006-10
 EN 55022:2010 (Class B)
 EN 55024:2010
 EN 61000-3-2:2006+A1 :2009+A2 :2009 (Class D)
 EN 61000-3-3:2008

Low Voltage Directive 2006/95/EC

 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A12: correction 2012

Ecodesign Directive 2009/125/EC

 1275/2008
 278/2009

ROHS Directive 2011/65/EU

The technical documents related to the device mentioned above have been deposited at:

Intenso GmbH
Diepholzerstr. 15, 49377 Vechta. Germany

Authorized Representative:

______________________________
Executive Director: Thomas Pöhlking

Intenso GmbH

th

July 2013

IT - 1

Istruzioni per l’uso di TAB 814

Molte grazie per aver scelto il TAB814. La invitiamo a leggere e seguire le presenti istruzioni, che Le
forniranno informazioni relativamente alle più importanti funzioni dell’apparecchio.

1.) Indice

1.) Indice ..................................................................................................................................................................................................... 1

2.) Note ....................................................................................................................................................................................................... 2

3.) Quadro generale dell’apparecchio ......................................................................................................................................................... 4

4.) Contenuto della confezione ................................................................................................................................................................... 4

5.) Caricamento della batteria ..................................................................................................................................................................... 5

6.) Utilizzo di una scheda Micro SD/SDHC ................................................................................................................................................. 5

7.) Trasmissione di dati tra l’apparecchio e un computer ............................................................................................................................ 5

8.) Touchscreen .......................................................................................................................................................................................... 6

9.) La schermata iniziale ............................................................................................................................................................................. 7

Visualizzazione ........................................................................................................................................................................................... 7

Sblocco del display ..................................................................................................................................................................................... 7

Barra di stato .............................................................................................................................................................................................. 8

Adattamento della schermata di avvio ........................................................................................................................................................ 8

Utilizzare diverse schermate iniziali ............................................................................................................................................................ 9

Applicazioni già installate sulla schermata iniziale ...................................................................................................................................... 9

a) Barra di ricerca per la ricerca Google™ ................................................................................................................................................ 10

b) Menù principale applicazioni ................................................................................................................................................................. 10

c) Previsioni meteo ................................................................................................................................................................................... 11

d) WIFI ...................................................................................................................................................................................................... 11

Connessione automatica .......................................................................................................................................................................... 11

Collegamento manuale ............................................................................................................................................................................. 12

e) Galleria ................................................................................................................................................................................................. 12

f) Musica ................................................................................................................................................................................................... 13

g) Video .................................................................................................................................................................................................... 15

h) Centro apps .......................................................................................................................................................................................... 15

i) Browser internet ..................................................................................................................................................................................... 15

Utilizzo della tastiera virtuale .................................................................................................................................................................... 15

Inserimento di caratteri speciali ................................................................................................................................................................ 16

Utilizzo del browser internet ...................................................................................................................................................................... 16

j) Menù principale applicazioni .................................................................................................................................................................. 17

k) Impostazioni sistema ............................................................................................................................................................................ 17

Impostazioni principali............................................................................................................................................................................... 18

10.) E-Book ............................................................................................................................................................................................... 19

Copia di e-books tra computer e apparecchio .......................................................................................................................................... 19

Download di e-books e trasferimento sull’apparecchio per mezzo di Adobe™ Digital Editions ................................................................ 19

Iniziare la lettura ....................................................................................................................................................................................... 20

Passare dalla visualizzazione scaffale alla visualizzazione liste / cancellazione di e-books ..................................................................... 20

Sfogliare le pagine .................................................................................................................................................................................... 21

Ingrandire la scrittura ................................................................................................................................................................................ 21

Saltare ad una determinata pagina ........................................................................................................................................................... 21

Utilizzo di segnalibri .................................................................................................................................................................................. 21

Visualizzazione dell’indice ........................................................................................................................................................................ 21

Visualizzazione delle informazioni sul libro ............................................................................................................................................... 21

11.) Invio / ricezione di e-mails ................................................................................................................................................................. 22

Configurazione della Sua casella di posta elettronica ............................................................................................................................... 22

Gestione degli account e-mail ................................................................................................................................................................... 23

Visualizzazione delle e-mails .................................................................................................................................................................... 23

Scrivere messaggi e-mail .......................................................................................................................................................................... 23

12.) Gestione di applicazioni ..................................................................................................................................................................... 24

Installazione di applicazioni ...................................................................................................................................................................... 24

IT - 2

Disinstallazione di applicazioni ................................................................................................................................................................. 24

13.) Lettura di documenti Office ................................................................................................................................................................ 25

14.) Task manager .................................................................................................................................................................................... 25

15.) Condizioni di garanzia limitate ........................................................................................................................................................... 26

16.) Dati tecnici ......................................................................................................................................................................................... 27

17.) Manutenzione dell’apparecchio ......................................................................................................................................................... 27

18.) Pulizia dell’apparecchio ..................................................................................................................................................................... 27

19.) Smaltimento di vecchi apparecchi elettrici ................................................................ ......................................................................... 27

20.) Licenza informazione ......................................................................................................................................................................... 28

Dichiarazione di conformità .......................................................................................................................................................................... 32

Questo manuale non contiene eventualmente tutte le funzioni del Suo apparecc hio. Per l’utilizzo di applicazioni derivanti da
fornitori terzi, contatti il rispettivo fornitore. Consideri che tutte le informazioni possono essere modificate senza preavviso.
Può trovare informazioni attuali su www.intenso.de.

Marchio di fabbrica

Google™, il logo Google™ e Android™ sono marchi di Google™. Tutti gli altri nomi di prodotti e servizi sono proprietà del
rispettivo possessore.

2.) Note

 Evitare forti impatti sull’apparecchio. Non depositarlo su superfici oblique al fine di evitare una

caduta.

 Non utilizzare l’apparecchio in zone estremamente fredde, calde, umide o polverose. Non

esporlo alla luce solare diretta.

 Evitare l’utilizzo in posti sabbiosi.
 Non utilizzare l’apparecchio in zone a rischio d’esplosione, come ad esempio distributori di

carburante presso una stazione di servizio.

 Evitare l’utilizzo su cuscini, divani o altri oggetti che supportano una potenziale fonte di calore, in

quanto si creerebbe pericolo di surriscaldamento dell’apparecchio.

 Esegua spesso il backup dei dati per evitare una loro possibile perdita. Non siamo responsabili

per eventuali perdite di dati.

 Non interrompere la connessione mentre i dati vengono trasmessi o l’apparecchio viene

formattato. Potrebbe verificarsi la perdita dei dati.

 Immagini e video possono essere protetti da diritti di terzi. La loro esecuzione senza licenza può

violare diritti di copyright.

 Evitare l’utilizzo in presenza di forti campi magnetici.
 Proteggere l’apparecchio dall’acqua. Se dell’umidità penetrasse nell’apparecchio, spegnerlo

immediatamente, quindi pulirlo e asciugarlo.

 Non utilizzare soluzioni chimiche per pulire l’apparecchio. Utilizzare solo un panno asciutto.
 Non collocare in prossimità dell’apparecchio fiamme aperte, ad esempio candele accese.
 Non siamo responsabili per danni causati da un malfunzionamento per perdita di dati, utilizzo

improprio, riparazione per conto proprio dell’apparecchio o sostituzione della batteria.

IT - 3

 Se l’apparecchio non dovesse reagire ai comandi, utilizzare il pulsante reset sul retro

dell’apparecchio per riavviarlo.

 Se l’apparecchio non viene utilizzato, staccare l’alimentatore della corrente.
 La presa deve trovarsi nei pressi dell’apparecchio ed essere facilmente accessibile.
 Utilizzare l’adattatore solo con prese con messa a terra da AC 100-240V~, 50/60 Hz. In caso

d’insicurezza riguardo l’alimentazione di corrente presso la collocazione dell’apparecchio,
informarsi presso il fornitore d’energia in questione.

 Utilizzare solo il cavo dell’adattatore e di rete in fornitura.
 Per interrompere l’alimentazione di corrente all’apparecchio, estrarre l’alimentatore dalla presa.

Tenere sempre ben fermo il trasformatore mentre lo si estrae. Non tirare mai il filo.

 Non aprire l’alloggiamento dell’adattatore. Aprendo l’alloggiamento sussiste pericolo di morte

per scossa elettrica. Non contiene componenti che possono essere riparate.

 Se non si utilizza l’apparecchio per lungo tempo, la batteria si scarica lentamente. Prima del

riutilizzo, quest’ultima dev’essere quindi ricaricata.

 Smaltire l’apparecchio o la batteria nel rispetto dell’ambiente.
 Non scomporre l’apparecchio in pezzi singoli e non cercare di ripararlo per conto proprio, in

quanto la garanzia in questo caso decadrebbe.

 Non utilizzare l’apparecchio in posti dove l’utilizzo di apparecchi mobili è vietato. Non utilizzare

l’apparecchio in prossimità di altri apparecchio elettronici, in quanto potrebbe verificarsi
un’interferenza col segnale d’alta frequenza.

 Non utilizzare l’apparecchio nei pressi di pacemaker, in un ospedale o nei pressi di apparecchi

medici, in quanto potrebbe verificarsi un’interferenza col segnale d’alta frequenza. Rivolgersi al

produttore di questo apparecchio per ricevere informazioni su un utilizzo in concomitanza con
altri dispositivi.

 Utilizzando cuffie e auricolari con un volume troppo alto, possono verificarsi danni permanenti

all’udito.

 Per motivi di sicurezza nel traffico, l’apparecchio non può essere utilizzato durante la guida dal

conducente stesso.

IT - 4

3.) Quadro generale dell’apparecchio

a) Touchscreen
b) Fotocamera frontale
c) Stato di carica LED. Si illumina in rosso

durante la ricarica. Si illumina in giallo,
non appena la batteria sarà
completamente ricaricata.

d) Porta 3.5mm per cuffie
e) Microfono integrato
f) Ingresso DC 5V 2A
g) Porta micro USB

h) Tasto On / Off: premere a lungo per

spegnere l’apparecchio; premere

brevemente per passare dalla modalità
standby alla modalità attiva

i) Volume +/-
j) Altoparlanti integrati.
k) Apertura Reset: resetta l’apparecchio se

non dovesse più reagire

l) Slot per micro scheda SD
m)HDMI

4.) Contenuto della confezione

Verificare la completezza del contenuto del pacchetto:

 TAB 814
 Cuffie stereo
 Cavo USB
 Trasformatore 5V 2.0A
 Istruzioni
 Borsa effetto pelle

IT - 5

5.) Caricamento della batteria

Ricaricare completamente la batteria prima del primo utilizzo. Collegare l’alimentatore in dotazione

all’apparecchio e a una presa. La ricarica completa dura circa 5 ore. Lo stato della ricarica viene
visualizzato sul lato anteriore sinistro dell’apparecchio. Il LED s’illumina di rosso durante la ricarica e
diventa giallo quando la batteria è completamente carica.

Nota:

a. Quando la carica rimasta della batteria raggiunge il 15%, riceverà un avviso sul display. Dovrebbe quindi ricaricare la batteria

tramite il trasformatore inserito in una presa, al fine di evitare la perdita di dati e aumentare la durata della batteria.

b. Può utilizzare l’apparecchio mentre la batteria viene ricaricata. Per garantire una lunga durata della batteria, è opportuno non

utilizzare l’apparecchio nel frattempo.

c. Per garantire una buona performance, la batteria incorporata dev’essere utilizzata spesso. Se utilizza solo raramente l’apparecchio,

carichi completamente la batteria minimo una volta al mese.

d. Si assicuri di utilizzare solo il trasformatore dotato in fornitura per il caricamento.

6.) Utilizzo di una scheda Micro SD/SDHC

Questo apparecchio può leggere dati direttamente da una micro scheda SD/SDHC.
Per utilizzare una micro scheda SD/SDHC, inserire la scheda nell’apposito vano sul lato posteriore

dell’apparecchio (I). Utilizzare l’Explorer già installato (ulteriori informazioni a riguardo sono
disponibili nel manuale d’istruzioni dettagliato) per accedere ai dati presenti sulla scheda di memoria.

Selezionare nell’Explorer la directory “SD Card”.

7.) Trasmissione di dati tra l’apparecchio e un computer

1.) Collegare l’apparecchio con l’aiuto del cavo USB allegato con un computer. Se l’apparecchio non
dovesse essere già acceso, si avvierà automaticamente. Questo può durare qualche momento, in
quanto il sistema operativo deve essere prima caricato. Se l’apparecchio era già acceso, il computer
dovrebbe riconoscerlo automaticamente entro pochi secondi.

2.) Sull’apparecchio comparirà quindi la schermata per il collegamento USB. Toccare brevemente

“Attivare memoria USB”. L’apparecchio verrà riconosciuto come supporto di memoria rimuovibile e
riceverà il messaggio “Memoria USB in utilizzo”. Dopo aver toccato brevemente il tasto Home, si

potrà continuare ad utilizzare normalmente l’apparecchio. Avrà ora accesso dal Suo computer alla
memoria interna dell’apparecchio e potrà copiare, cancellare o spostare files sull’apparecchio.

3.) Se vi è una connessione USB con il computer, nella barra di stato si vedrà il simbolo USB. Nella barra di
stato ampliata (per aprirla premere brevemente sull’orologio che si trova nella barra di stato) sono
disponibili maggiori informazioni ed è possibile attivare o disattivare la connessione USB.

IT - 6

 Per disattivare la memoria, selezionare “Disattiva memoria USB”.

 Sul computer selezionare la funzione „Rimozione sicura“ , per staccare il dispositivo dal

computer.

Nota: Le applicazioni già installate e il sistema operativo Android™ occupano una parte della memoria interna. Per questo motivo non
è a Sua disposizione l’intera memoria interna.

8.) Touchscreen

Questo dispositivo viene comandato mediante un touch screen. Toccando lievemente con le dita il touch
screen si possono avviare in modo molto semplice le applicazioni, inserire testi sulla tastiera virtuale e
scorrendo nella relativa direzione, si può navigare tra le diverse schermate.

Rimuova la pellicola di protezione dal display prima di utilizzare l’apparecchio.
Il touchscreen riconosce cariche elettriche minime, come ad esempio quella trasmessa dal dico umano e

stabilisce così il punto d’inserimento.
Si consiglia quindi di utilizzare la punta delle dita per l’inserimento. L’utilizzo con un pennino o un altro
oggetto appuntito non è possibile.

Il touchscreen non dovrebbe entrare in contatto con l’acqua o altri dispositivi elettrici, al fine di evitare
malfunzionamenti e difetti permanenti.

Nota:
a. Se il touchscreen non viene utilizzato per due minuti, l’apparecchio passa nella modalità standby. Premere brevemente il tasto On

/ Off per passare alla modalità attiva.

b. Per evitare inserimenti involontari, il blocco tasti si attiva automaticamente. Sbloccare i tasti dal touchscreen. Trascinare a questo

scopo il simbolo del lucchetto dal basso verso l’altro sul display. L’apparecchio passerà ora alla schermata iniziale. Toccare il
lucchetto chiuso sul display e tenerlo premuto. Trascinare quindi il lucchetto sul lucchetto aperto appena comparso e

rilasciare il dito dal display. Lo schermo è ora sbloccato.

Può girare l’apparecchio in tutte le direzioni. Dispone di un sensore che orienta automaticamente il
display.

IT - 7

9.) La schermata iniziale

Visualizzazione

Sblocco del display

Se il touchscreen non viene utilizzato per due minuti, l’apparecchio passa automaticamente alla modalità
standby. Premere brevemente il tasto on / off per passare alla modalità attiva. Il display è bloccato per
impedire digitazioni involontarie. Toccare il lucchetto chiuso sul display e tenerlo premuto.
Trascinare quindi il lucchetto sul lucchetto aperto appena comparso e rilasciare il dito dal display. Lo
schermo è ora sbloccato.

Trascini il simbolo del lucchetto con le dita nella direzione della freccia.

Nota: Trascinare il simbolo del lucchetto sul simbolo comparso della fotocamera per aprire direttamente
l’applicazione della fotocamera.

IT - 8

Barra di stato

Apre la schermata Home

Indietro

Collegamento WLAN

Batteria

Ora

Ultimi programmi
utilizzati

La barra di stato si trova nella parte inferiore dello schermo. Possiede le seguenti funzioni:

Qui ottenete informazioni riguardo:

 i programmi usati di recente
 la potenza del segnale dell’attuale connessione WIFI
 l’orario attuale
 lo stato di carica attuale della batteria

Potete eseguire le seguenti operazioni:

 avviare la schermata d’avvio
 tornare indietro di un passo nel menù attualmente aperto
 consultare i programmi usati di recente

Toccando delicatamente l’orologio si apre la barra di stato ampliata. Qui vengono visualizzati i
messaggi di stato correnti. Toccando ancora una volta l’orologio nella barra di stato ampliata vengono
visualizzati diversi accessi rapidi, come per esempio, l’accesso alle impostazioni

Adattamento della schermata di avvio

È possibile adattare la schermata di avvio alle proprie esigenze individuali in modo molto semplice. Se si
vuole cancellare un’icona, toccare un po’ più a lungo con il dito l’icona e spostarla sul simbolo X scoperto.
Togliere ora il dito dal touch screen e l’icona viene cancellata.

Se si desidera spostare un’icona dalla panoramica delle applicazioni alla schermata iniziale, premere un
pò più a lungo sull’icona nella panoramica delle applicazioni: comparirà la schermata iniziale. Spostare

l’icona nel punto desiderato e togliere il dito dal touch screen. L’icona è stata aggiunta alla schermata
iniziale. Se si posiziona un’icona su un’altra icona, viene creata automaticamente una cartella che contiene

le due icone. Toccare la cartella per visualizzare le icone in essa contenute e selezionare poi toccandola
brevemente l’icona desiderata.

È possibile anche aggiungere dei widgets alla schermata iniziale. Per farlo, toccare il nell’angolo
superiore destro della schermata iniziale per aprire il menu Applicazioni. Poi toccare la Widgets.
Verranno visualizzati tutti i widgets disponibili sul dispositivo. L’aggiunta di un widget alla schermata
iniziale si effettua esattamente come l’aggiunta di un’icona.

Se si desidera cambiare l’immagine dello sfondo, toccare semplicemente un punto libero della schermata
iniziale e tenere premuto il dito sul display fino a che compare il menu di selezione dello sfondo. Selezionare
ora la fonte dell’immagine desiderata e procedere come descritto di seguito:

IT - 9

Utilizzare diverse schermate iniziali

A Collegamento alla ricerca Google™

B Panoramica applicazioni

C Meteo mondiale

D Apps sulla schermata di avvio

E Barra di stato: Indietro, Home, ultimi
programmi usati, ora, Wifi, stato batteria

Sono a Sua disposizione cinque schermate individuali impostabili in modo personale. Con un leggero
sfioramento verso sinistra o destra, può passare facilmente da una all’altra.

Premendo il tasto Home tornerà sempre automaticamente alla fermata iniziale nel mezzo.

Applicazioni già installate sulla schermata iniziale

Sulla schermata iniziale sono già installate diverse applicazioni:

- Barra di ricerca per la ricerca Google™

- Previsioni meteo

- Wifi

- Galleria

- Musica

- Video

- AndroidPIT (App Center)

IT - 10

a) Barra di ricerca per la ricerca Google™

Toccare brevemente la lente di ingrandimento per aprire la funzione di ricerca di Google™. Digitare il
concetto da cercare sulla e premere Via. Vengono visualizzati ora i risultati di ricerca disponibili della
ricerca con Google™.

 Consiglio: Con un movimento rapido verso l’alto o il basso dopo che ha

rilasciato il dito dal touchscreen, l’apparecchio scorre velocemente
attraverso una lista. Questo funziona per tutte le visualizzazioni che sono
più grandi del Display.

Nota: Per questa funzione è necessario un collegamento WLAN ad internet.

b) Menù principale applicazioni

Toccare questo simbolo per aprire la panoramica delle applicazioni. Qui vengono mostrate tutte le

applicazioni installate nel dispositivo. Toccando il relativo simbolo s può avviare direttamente l’applicazione

desiderata.

IT - 11

c) Previsioni meteo

Il Widget previsioni meteo Le mostra in un’occhiata l’orario, la data, le condizioni metereologiche e la
temperatura attuali presso il luogo impostato.

Per modificare le impostazioni, passi al quadro generale delle applicazioni e tocchi l’icona Previsioni
meteo. Qui può effettuare le modifiche desiderate.

Menù impostazioni per le previsioni meteo

Nota: Per questa funzione è necessario un collegamento WLAN ad internet.

d) WIFI

Per collegare l’apparecchio a internet, è necessario una connessione WIFI. Per stabilire questo
collegamento, toccate l’icona WIFI sulla schermata d’avvio o aprite le impostazioni WIFI dalle

impostazioni.

Nota: Consideri che una rete WLAN deve trovarsi nel raggio della Sua posizione attuale.

Connessione automatica

Aprite le impostazioni WIFI tramite l’icona WIFI o le impostazioni. Qui potete semplicemente attivare o
disattivare la funzione WIFI. Spostate l’interruttore virtuale nella posizione “on” verso sinistra per
disattivare la funzione WIFI. La schermata passerà a “off”.

Per riattivare la funzione WIFI disattivata, spostare semplicemente l’interruttore virtuale verso destra.

Nelle impostazioni WIFI vengono visualizzate a destra tutte le reti disponibili e tutte le reti già utilizzate.

IT - 12

Tocchi la rete desiderata e inserisca eventualmente la chiave WLAN (password) corretta per stabilire una

connessione.

Confermate l’eventuale password inserita premendo il tasto Enter e premete Collega. Dopo breve tempo
la connessione è stabilita.

Nota:

a) Se l’apparecchio passa nella modalità standby, la WLAN viene disattivata automaticamente. Questo riduce il consumo di corrente

e contribuisce così ad una durata maggiore della batteria. Se l’apparecchio passa di nuovo nell a modalità attiva, il collegamento

WLAN verrà ripristinato automaticamente. Questo può durare qualche secondo.

b) La lista attuale delle reti WLAN trovate viene aggiornata automaticamente.
c) Se la funzione WLAND è attiva, l’apparecchio si collegherà automaticamente con una rete già configurata, se si trova nel suo

raggio.

d) Se una rete WLAN sconosciuta si trova nei paraggi, viene visualizzato un campo con le relative informazioni.

Collegamento manuale

Per cercare manualmente una rete Wifi raggiungibile, procedere come segue:
(1) Aprire le Impostazioni.
(2) Aprire ora le Impostazioni Wifi e toccare “Cerca“.
(3) Se la rete Wifi non compare nell’elenco delle reti disponibili, selezionare la voce “Aggiungi rete“ per

inserire manualmente la rete SSID, il protocollo di sicurezza ed eventualmente la relativa password. Per

confermare i dati inseriti, toccare “Salva“.

e) Galleria

Tocchi brevemente l’icona Galleria per ottenere un quadro d’insieme di tutti gli album e le immagini
presenti.

Selezioni la galleria desiderata ed infine l’immagine selezionata con un altro tocco breve. L’immagine
verrà ora visualizzata a schermo intero.

Toccare il simbolo della foto per scegliere tra le diverse possibilità di raggruppamento.

IT - 13

Interpreti

Mostra tutti i files musicali ordinati in base ai singoli interpreti.

Album

Mostra tutti i files musicali ordinati in base ai singoli album.

Titolo

Mostra tutti i files musicali ordinati per titolo.

Playlists

Mostra tutte le playlists presenti.

Elenco attuale

Va direttamente all’elenco attuale.

Per visualizzare l’immagine successiva o precedente, trascini l’immagine
attuale con il dito verso sinistra o destra dal display.

Metta due dita sul touchscreen e le trascini nella direzione opposta per

ingrandire l‘immagine progressivamente. Se ricongiunge nuovamente le dita,
l’immagine si rimpicciolirà progressivamente. Se tocca brevemente e

velocemente il touchscreen due volte, l’immagine s’ingrandirà
automaticamente e con un altro doppio tocco sarà visualizzata nella
grandezza originaria.

Toccando brevemente il touchscreen saranno a Sua disposizione ulteriori funzioni.

Toccare il simbolo “Menu” per ricevere altre opzioni.
Qui si possono attivare delle diapositive, elaborare l’immagine,

ruotarla, tagliarla, impostarla come immagine di sfondo e
visualizzare i dettagli dell’immagine.

Toccare il simbolo del bidone della spazzatura per cancellare
l’immagine selezionata.

Toccare il simbolo Condividi per inviare l’immagine, ad es.
via e-mail.

f) Musica

Tocchi brevemente l’icona della Musica nella schermata iniziale o nel menù principale delle
applicazioni per aprire la riproduzione musicale.

Nel seguente menù principale può scegliere di visualizzare la Sua musica in ordine secondo gli interpreti,
gli album, i titoli, la playlist o l’elenco attuale. Tocchi a questo scopo brevemente il simbolo
corrispondente.

Toccando brevemente, selezioni il nome del file desiderato e la riproduzione musicale verrà avviata.

IT - 14

Schermata di riproduzione

(1) Riproduzione attuale
(2) Attivare / Disattivare la riproduzione causale
(3) Opzioni di ripetizione:

a) Tutti i titoli vengono ripetuti
b) Il titolo attuale viene ripetuto

c) La ripetizione è disattivata
(4) Dettagli titolo
(5) Titolo successivo / precedente
(6) Play / Pausa
(7) Barra di avanzamento

 Tocchi il simbolo Pausa per arrestare la riproduzione.
 Per proseguire la riproduzione, tocchi il simbolo Play .
 Tocchi sul simbolo Avanti o Indietro / per riprodurre il titolo successivo o precedente.
 Tocchi su un punto della barra di scorrimento per proseguire la riproduzione direttamente da quel

punto.

 Premere i tasti volume +/- sul lato del dispositivo per regolare il volume.
 Per aprire l’anteprima della lista di riproduzione attuale, tocchi il simbolo della lista di

riproduzione . Tocchi un titolo per riprodurlo direttamente.

 Per modificare la modalità di riproduzione, tocchi il simbolo della modalità di riproduzione .
 Per raggiungere la schermata iniziale, tocchi il tasto Home . La riproduzione musicale non

viene in questo modo arrestata. In tal modo può ad esempio navigare in internet col browser e allo
stesso tempo ascoltare la musica. Tocchi di nuovo l’icona della Musica per ritornare alla
riproduzione musicale.

Nella modalità di riproduzione può effettuare ulteriori impostazioni. Tocchi a questo scopo brevemente il

Tasto di Menù .

Biblioteca – Viene visualizzato un quadro generale di tutti i files musicali presenti.
Party Shuffle – Attivare o disattivare la modalità Party Shuffle.
Aggiungere alla playlist – Aggiungere il titolo riprodotto al momento ad una playlist.
Cancellare – Cancellare il titolo riprodotto al momento.

Effetti sonori – Stabilire un effetto sonoro per la riproduzione musicale.

IT - 15

g) Video

a. Blocco maiuscole (caratteri minuscoli o maiuscoli)
b. Tasto per cancellare
c. Apertura del menù per inserire numeri, lettere e

caratteri speciali
d. Barra spaziatrice (inserimento di uno spazio)
e. Vai (Conferma dell’inserimento)

Tocchi brevemente l’icona del Video nella schermata iniziale o nel quadro generale delle applicazioni
per aprire la riproduzione video.

Vengono visualizzati ora i files video in una lista. Selezioni il file desiderato toccando brevemente e il video
inizierà.

h) Centro apps

Sull’apparecchio è già installato il centro apps AndroidPIT. Qui può trovare varie apps, report sui test, un
blog e un forum.
Per ulteriori informazioni o aiuti per l’utilizzo del centro apps, visiti per cortesia l’homepage del fornitore su
www.androidpit.de.

Nota: Per questa funzione è necessario un collegamento WLAN ad internet.

i) Browser internet

Per avviare il browser internet, tocchi l’icona del Browser nella schermata iniziale. Per aprire un
sito internet, tocchi il campo superiore per inserire l’indirizzo internet. La tastiera virtuale si aprirà e poi

potrà inserire l’indirizzo del sito internet desiderato. Clicchi su “Vai” o sul simbolo della freccia di fianco
al campo d’inserimento per aprire il sito internet.

Nota: Non tutte le reti offrono un accesso a internet. Alcune reti offrono un accesso ad altri computer collegati localmente e non un
collegamento a internet.

Utilizzo della tastiera virtuale

Tocchi il campo d’inserimento per aprire la tastiera virtuale. Può quindi inserire testi o aprire siti
internet.

IT - 16

Inserimento di caratteri speciali

Per inserire un carattere speciale, come per esempio “ä”, toccare a lungo col dito il tasto “a“ per richiamare
il menu dei segni speciali. Ora col dito trascinare il segno speciale che si desidera, per esempio “ä“ e
staccare di nuovo il dito dal display. È stata inserita una “ä“.

Utilizzo del browser internet

 Può far scorrere la visualizzazione sul display eseguendo un movimento di sfioramento in verticale

con il dito. Non inizi il movimento da un punto del menù o da un link, altrimenti verrà aperto il
collegamento presente.

 Per aprire un link, tocchi semplicemente il link. La nuova pagina si aprirà automaticamente.
 Per aprire il menu Web Browser, premere il tasto menu . Qui sono disponibili diverse funzioni. Fra le

altre cose, qui si può aggiornare il sito web aperto, aprire un nuovo tab, rendere leggibili i siti web
offline oppure passare alle Impostazioni del Web Browser.

 Per tornare indietro alla pagina precedente, prema il tasto Indietro .
 Per tornare indietro direttamente alla schermata iniziale, prema il tasto Home .

 Per inserire un testo, tocchi il campo corrispondente e utilizzi la tastiera virtuale per inserire il testo.

Nota: Per questa funzione è necessario un collegamento WLAN ad internet.

IT - 17

j) Menù principale applicazioni

Tocchi brevemente l’icona del Menù principale applicazioni per aprire il menù principale delle
applicazioni. Visualizzerà quindi un quadro d’insieme di tutte le applicazioni predefinite e da Lei già
installate. Apra l’applicazione desiderata toccando brevemente la relativa icona.

Menù principale applicazioni

k) Impostazioni sistema

Toccare nel menu Applicazioni l’icona Impostazioni per richiamare le impostazioni di sistema.

 Sul lato sinistro del menu si trovano le singole categorie. Premendo brevemente sulla voce di menu

che interessa, vengono visualizzate le possibilità di configurazione disponibili. Si prega di notare che
eventualmente alcune funzioni offerte da Android™ potrebbero non essere compatibili con questo
dispositivo.

 Una volta eseguite tutte le impostazioni, con il tasto Indietro si può tornare al menu richiamato

per ultimo, oppure con il tasto Home si può passare direttamente alla schemata di avvio. Gli
inserimenti eseguiti saranno salvati automaticamente.

IT - 18

Impostazioni principali

Wireless & reti

Wifi

Eseguire qui le proprie impostazioni Wifi.

Altro

Qui si possono eseguire altre impostazioni di rete.

Dispositivo

Suoni

Qui si imposta il volume desiderato e il tono di avviso desiderato.
È inoltre possibile attivare o disattivare un tono di conferma quando si tocca il
touch-screen e un tono di avviso quando si sblocca il blocco del display.

Display

Luminosità – adattamento della luminosità del display.
Sfondo – selezione dello sfondo preferito.
Rotazione autom. display – attivazione o disattivazione dell’allineamento

automatico del display quando si ruota l’apparecchio.

Riposo – adattamento del ritardo prima dello spegnimento automatico del
display.

Dimensione caratteri – impostazione della dimensione carattere desiderata.

Memoria

Qui si trovano informazioni sulla memoria interna e – se utilizzata – su una
scheda Micro SD. È inoltre possibile cancellare il contenuto della memoria.

Batteria

Qui si trovano informazioni sullo stato di carica della batteria integrata.

Apps

Qui si possono gestire le applicazioni installate e ricevere informazioni sulle
applicazioni.

Utente

Accounts &
sincronizzazione

Qui si può definire se e con quale frequenza debbano essere sincronizzati i
propri accounts.

Servizi sede

Qui si può permettere a diverse applicazioni Android™ di rilevare e usare la
Sua sede attuale per mezzo di reti wireless (p.es. Google Maps™). È inoltre

possibile definire se Google™ possa adattare i risultati di ricerca e altri
servizi alla Sua sede.

Sicurezza

Qui si può configurare ad esempio il blocco dello schermo ed eseguire altre
impostazioni importanti per la sicurezza.

Lingua &
inserimento

Qui si può impostare per esempio la propria lingua preferita, aggiungere
diverse voci al proprio vocabolario personale ed eseguire diverse
impostazioni per la tastiera.

Salvare & resettare

Qui si possono salvare le proprie impostazioni di sistema e i dati delle

applicazioni su server Google™. Inoltre si possono ripristinare le

impostazioni iniziali di fabbrica. ATTENZIONE: per farlo, vengono cancellati
tutti i dati salvati sul dispositivo.

Sistema
Data & ora

Qui si possono definire data, ora, fuso orario e formato della visualizzazione.

Info sul tablet

Mostra informazioni sul dispositivo.

IT - 19

10.) E-Book

Questo apparecchio dispone di un lettore e-book già installato.

Copia di e-books tra computer e apparecchio

Può copiare e-books tramite collegamento USB sulla memoria interna del Suo apparecchio. Consulti a
riguardo il paragrafo „Trasferimento di dati tra l’apparecchio e un computer tramite cavo USB“.

Nota: Si assicuri che l’e-book possieda uno dei seguenti formati: PDF, EPUB, TXT, FB2, RTF, PDB.

Download di e-books e trasferimento sull’apparecchio per mezzo di Adobe™ Digital Editions

L’applicazione Adobe™ Digital Edition Le permette di scaricare con il Suo
computer e-books protetti da DRM.

(1) Carichi il sito internet http://www.adobe.com/de/products/digitaleditions/ e

installi Adobe™ Digital Editions Software secondo le istruzioni.

(2) Autorizzazione del computer con il Suo ID di Adobe™ e password (se non

avesse ancora un ID Adobe™, si registri sul sito di per questo servizio).

(3) Attivi ora l’apparecchio. Colleghi a questo scopo l’apparecchio con il PC

tramite il cavo USB in dotazione e attivi la memoria USB. Avvii ora il software Adobe™ Digital
Editions. Clicchi su “Autorizza dispositivo” per autorizzare il Suo apparecchio.

 L’ID di Adobe™ può essere utilizzato solo 6 volte. Dopo deve cancellare l’ID scaduto premendo i tasti CTRL+SHIFT+D sul Suo

computer o impostando l’Erase Activation Record sull’apparecchio e richiedere un nuovo ID.

 il Tablet memorizza gli e-books scaricati che ha registrato con la licenza valida più recente e sovrascrive il precedente ID di

Adobe™.

(4) Visiti con il Suo computer un negozio online di e-books e selezioni l’e-

book desiderato (si assicuri che l’e-book possegga uno dei seguenti formati:
PDF, EPUB, TXT, FB2, RTF, PDB). Se l’e-book dovesse essere protetto da
DRM, questa informazione Le viene di solito mostrata.

(5) Se ha acquistato l’e-book e l’ha scaricato sul Suo computer, dovrebbe

riuscire a trovare l’applicazione Adobe™ Digital Editions.

IT - 20

(6) Colleghi il Suo apparecchio quindi tramite il cavo USB con il computer. Il

software Adobe™ Digital Edition dovrebbe ora riconoscere
automaticamente l’apparecchio.

(7) Trascini la copertina dell’e-book sul Suo apparecchio per trasferire il file.

Iniziare la lettura

Aprire la panoramica delle applicazioni e toccare l’icona e-Book reader, per aprire l’ e-book reader.
Selezionare tra gli e-books disponibili quello che si desidera, per iniziare direttamente la lettura.

Passare dalla visualizzazione scaffale alla visualizzazione liste / cancellazione di e-books

Toccare sul simbolo Liste sotto lo scaffale per arrivare alla visualizzazione delle liste.

Se si tocca il simbolo del bidone della spazzatura, ad ogni e-book viene aggiunta una X rossa. Toccare per

l’e-book desiderato la X ed esso sarà cancellato direttamente.

Nota: Il frontespizio dell’e-book viene visualizzato con un’immagine standard se l’apparecchio non dispone di informazioni riguardo il
frontespizio. Pertanto, alcuni e-books possono avere lo stesso identico frontespizio.

IT - 21

Sfogliare le pagine

Quando legge un libro, può eseguire un movimento di sfioramento col dito
per sfogliare pagina dopo pagina.

Può anche sfogliare le pagine automaticamente. Clicchi a questo scopo sul
tasto di Menù per accedere alle impostazioni avanzate. Selezioni quindi

“Auto flip” ed infine l’intervallo di tempo desiderato con un breve tocco.

Ingrandire la scrittura

(1) Tocchi durante la lettura il tasto di menù per accedere alle impostazioni avanzate.
(2) Tocchi “Zoom” per impostare la dimensione desiderata della scrittura.
(3) Confermi la Sua selezione con “OK”.

Saltare ad una determinata pagina

(1) Apra durante la lettura le impostazioni avanzate con il tasto di menù .
(2) Tocchi “Vai a”.
(3) Inserisca il numero di pagina desiderato.
(4) Confermi la Sua selezione con “OK”.

Utilizzo di segnalibri

Può aggiungere, cancellare o caricare segnalibri.
(1) Apra durante la lettura le impostazioni avanzate con il tasto di menù .
(2) Tocchi “Segnalibri” per aprire il menù dei segnalibri. Qui può aggiungere, cancellare o visualizzare

segnalibri.

Visualizzazione dell’indice

Può visualizzare l’indice dell’e-book e quindi iniziare direttamente dal capitolo o dal paragrafo desiderato
se l’e-book supporta questa funzione.

(1) Apra durante la lettura le impostazioni avanzate con il tasto di menù .
(2) Tocchi “TOC” per aprire l’indice e infine il capitolo o il paragrafo dal quale volete iniziare la lettura.

Visualizzazione delle informazioni sul libro

Durante la lettura può visualizzare le informazioni disponibili sul libro. Tocchi il tasto di menù e

selezioni infine l’opzione di menù “BookInfo”.

IT - 22

11.) Invio / ricezione di e-mails

Su questo apparecchio è già installata un’applicazione per le e-mails. Può in questo modo utilizzare i Suoi
account già esistenti per inviare e ricevere e-mails.

Nota: Per questa funzione è necessario un collegamento WLAN ad internet.

Apra l’applicazione tramite l’icona „E-Mail“ che si trova nel menù delle applicazioni.

Configurazione della Sua casella di posta elettronica

(1) Avvii l’applicazione dell’e-mail toccando il simbolo E-Mail. Le verrà quindi richiesto di configurare la

Sua casella di posta elettronica.

(2) Inserisca il Suo indirizzo e-mail e la relativa password, quindi tocchi “Avanti”. Infine dia un nome al

Suo account e stabilisca il Suo nome che deve essere visualizzato per la posta in uscita. Tocchi

“Finito” per concludere la configurazione. La Sua casella di posta elettronica viene selezionata come
casella standard se seleziona l’opzione “Inviare e-mails sempre da questo account”.

(3) Può configurare la Sua casella di posta elettronica anche manualmente. Inserisca il Suo indirizzo e-

mail e la relativa password, quindi tocchi infine “Setup manuale” per registrare le informazioni sul

server dell’account.

(4) Selezioni il tipo di server POP3, IMAP o Exchange per ricevere le e-mails.

Nota: Se non sa come configurare le impostazioni, contatti il gestore del Suo account, il Suo amministratore di rete oppure cerchi in
internet le relative informazioni necessarie indicando termini come „Indirizzo POP“ e „Nome del mio provider“.

(5) Inserisca le informazioni necessarie (server, porta ecc.).
(6) Selezioni il tipo di server per inviare le e-mails e inserisca le informazioni necessarie.
(7) Tocchi “Avanti” per procedere nel menù. L’applicazione dell’e-mail verificherà le impostazioni del

server dell’account. Dopo aver portato a buon fine la configurazione, visualizzerete il messaggio
“Your account is set up, and email is on its way”. Il Suo account è ora configurato.

(8) Dia un nome alla Sua casella di posta e tocchi „Finito“ per concludere la procedura.

Nota: Se dovesse possedere più di un account, ad ogni avvio dell’applicazione dell’e-mail verrà aperto l’account predefinito.

IT - 23

Gestione degli account e-mail

Aggiungere una nuova casella di posta:

(1) Aprire l’applicazione E-mail e toccare il tasto di menu per visualizzare le altre opzioni. Selezionare

la voce di menu “Impostazioni e poi “Aggiungi account”, per creare una nuova casella di posta.

(2) Seguire i tutorial di configurazione per creare una nuova casella di posta.

Cancellare una casella di posta:

(1) Aprire l’applicazione E-mail e toccare il tasto di menu per visualizzare le altre opzioni. Selezionare

la voce di menu “Impostazioni” e poi “Elimina account”, per cancellare la casella di posta desiderata.

Controllo delle caratteristiche dell’account:

(1) Aprire l’applicazione E-mail e toccare il tasto di menu per visualizzare le altre opzioni e

selezionare “Impostazioni“. Sul lato sinistro del menu vengono ora visualizzate tutte le caselle di
posta già create.

Toccare la casella di posta desiderata per visualizzare le impostazioni dell’account.

(2) Toccare l’“Impostazione account“ da cambiare, per eseguire le modifiche desiderate.

Visualizzazione delle e-mails

Apra l’applicazione dell’e-mail con un breve tocco sull’icona E-mail. Visualizzerà la casella di posta già
impostata.

 Con un movimento di sfioramento in verticale può far scorrere le e-mails.
 Tocchi brevemente una certa e-mail per aprirla.
 Tocchi e mantenga il dito su una certa e-mail per visualizzare le impostazioni avanzate. Apparirà

quindi un campo informativo. Qui può ora aprire l’e-mail, rispondere, inoltrarla o cancellarla.

Scrivere messaggi e-mail

(1) Nella schermata della e-mail, toccare il simbolo E-mail nella barra di menu superiore; si apre una

nuova finestra nella quale si può scrivere una nuova e-mail.

Inserire ora l’indirizzo e-mail del destinatario, un oggetto e il testo negli appositi campi. Si può
aggiungere anche „Cc/Bcc“ per inviare una e-mail a più destinatari.

(2) Toccare la voce “Invia“, per inviare l’e-mail. Toccare “Salva“, per salvare come bozza l’e-mail creata.

Toccando il “Simbolo cestino“ l’attuale e-mail viene eliminata.

IT - 24

12.) Gestione di applicazioni

Applicazioni già installate

Questo apparecchio viene fornito con delle applicazioni già installate. Può trovare una panoramica delle
applicazioni già installate nel menù principale delle applicazioni . Tra queste rientrano anche il video
player, l’audio player, il browser internet, la sveglia, la calcolatrice e altre ancora. Per aprire una di
queste applicazioni, tocchi brevemente la rispettiva icona.

Installazione di applicazioni

Per installare applicazioni sull’apparecchio, esegua i seguenti passi:
(1) Scarichi il software (ad esempio dall’Androipit Market). Si assicuri che si tratti di file APK.
(2) Una volta scaricato il file sul Suo computer, colleghi l’apparecchio al Suo computer tramite il cavo

USB e copi i files sulla memoria interna.
(3) Scolleghi l’apparecchio dal computer ed apra l’Explorer per aprire i files copiati.
(4) Segua le istruzioni per l’installazione che appaiono sul display per installare l’applicazione.
(5) Dopo un’installazione andata a buon fine potrà trovare la nuova applicazione nel menù delle

applicazioni.

Disinstallazione di applicazioni

(1) Aprire le Impostazioni di sistema toccando brevemente l’icona Impostazioni nella panoramica delle

applicazioni.
(2) Toccare ora la voce di menu “Apps”, per accedere alle Impostazioni delle applicazioni.
(3) Scegliere tra le voci principali di menu “Scaricato, memoria USB, attivo e” la panoramica applicazioni

desiderata toccandola brevemente.
(4) Poi, toccandola, selezionare l’applicazione che si vuole disinstallare.
(5) Toccare ora “Disinstalla” e confermare la scelta con OK, per disinstallare l’applicazione dal

dispositivo.

Nota: Non può eliminare software già installati in dotazione.

IT - 25

13.) Lettura di documenti Office

Su questo apparecchio è già installata l’applicazione “Office Suite” per leggere Documenti di Office. Può
leggere files Word, Excel o Powerpoint.

1.) Copi i files desiderati di Office sull’apparecchio.

2.) Apra l’applicazione „Office Suite“.

3.) Navighi con l’Explorer fino al file desiderato.

4.) Selezioni il file desiderato con un breve tocco e sfiori con il dito in verticale o orizzontale sul

display per sfogliare le singole pagine. Tocchi brevemente il tasto di menù per aprire ulteriori
opzioni. Può ad esempio cercare un determinato testo o contare le parole.

14.) Task manager

Questo apparecchio è multitasking. Può quindi aprire contemporaneamente più applicazioni. Può ad
esempio ascoltare musica e allo stesso tempo navigare in internet o guardare foto.
Può eventualmente capitare che troppe applicazioni siano attive contemporaneamente sullo sfondo. In
questo caso apra l’applicazione „Task Killer“ e termini quelle applicazioni di cui al momento non ha
bisogno.

IT - 26

(1) Apra l’applicazione “Task Killer”.

(2) Selezioni le applicazioni di cui al

momento non ha bisogno.

(3) Per confermare la Sua scelta, tocchi brevemente il simbolo “Kill selected

apps”.

15.) Condizioni di garanzia limitate

La garanzia copre solo la sostituzione di questo prodotto Intenso. La garanzia non vale per normale usura
derivante da uso errato o improprio, trascuratezza, incidente, incompatibilità o da altre prestazioni
manchevoli di un certo hardware o software.

Non sussiste garanzia col mancato rispetto delle istruzioni Intenso, così come col montaggio e uso improprio
o con difetti causati da altri apparecchi.

Se il prodotto viene esposto a scosse, scariche elettrostatiche, calore o umidità non in conformità alle
specifiche del prodotto, non sussiste alcuna garanzia.

Intenso non è responsabile per perdite di dati o per danni concomitanti e conseguenti, per la violazione delle
condizioni di garanzia o per altri danni indipendentemente dalla loro causa.

Questo prodotto non è previsto per un uso commerciale o per applicazioni mediche o di altro genere dove il
mancato funzionamento del prodotto possa causare ferimenti, morte o notevoli danni materiali.

IT - 27

16.) Dati tecnici

CPU

1.5 GHz Dualcore based on Cortex A9

Memoria

1 GB DDR 3

Sistema operativo

Android 4.1.1

Sistemi operativi compatibili

Windows XP / Vista / 7 / Linux 2,4 e più recenti / Mac 10.6 e più
recenti

Possibilità di collegamento

Cuffie, Micro SD (SDHC), micro USB, HDMI

WLAN

WiFi (802.11 b/g/n)

Sensore G

360 Grad Rotation

E-Book

PDF / EPUB / TXT / PDB / RTF

Formato foto

JPEG, BMP, GIF, PNG

Formato audio

MP3, WMA, WAV, OGG, FLAC, APE

Formato video

MPEG1, MPEG 4, FLV

Display

TFT LCD Display, 1024 x 768 Pixel

Fotocamera

Fotocamera frontale 0,3 MP

SNR

>= 75 dB

Campo di frequenza

20 Hz – 20 KHz

Trasformatore

Adattatore (V) AC (Ktec KSAS0100500200HE): AC Input 100­240V～50/60Hz, DC Output 5V / 2A

Batteria interna

Batteria ricaricabile agli ioni di litio-polimero

17.) Manutenzione dell’apparecchio

Non spruzzare o applicare mai un liquido direttamente sul display o
sull’ alloggiam ento.

18.) Pulizia dell’apparecchio

Pulisca l’allogg ia mento, il telai o e il displa y co n attenzion e tr am ite un pa nn o

morbido, non sfilacciato e privo di sostanze chimiche. Utilizzi detergenti solo
se sono previsti per displays.

19.) Smaltimento di vecchi apparecchi elettrici

Gli apparecchi contrassegnati da questo simbolo sono soggetti alla
direttiva europea 2002/96/EC.
Tutti gli apparecchi elettrici vecchi e non devono essere smaltiti
separatamente dai rifiuti domestici presso i luoghi previsti dallo stato.
Con uno smaltimento corretto dei vecchi apparecchi elettrici evita
danni all’ambiente.

IT - 28

20.) Licenza informazione

Notice of GNU GENERAL PUBLIC LICENSE and LESSER GENERAL PUBLIC LICENCE

Dear Customer,
If interested, you and any third party can download the source code of used GPL / LGPL from Intenso
Webpage http://www.intenso.de . The source code of the desired product is available to anyone on the
selection of valid product category and the desired device. In the product details you will find the entry

"drivers". Open this menu to download the corresponding GPL / LGPL code. For a fee of 35 € (delivery to

another country as Germany), it is also possible to obtain this code by postal delivery. More information
about the GPL/LGPL-Licence can you find on following website www.gnu.org

GNU GENERAL PUBLIC LICENSE

Version 2, June 1991
Copyright (C) 1989, 1991 Free Software Foundation, Inc.
51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA

Everyone is permitted to copy and distribute verbatim copies
of this license document, but changing it is not allowed.

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast,
the GNU General Public License is intended to guarantee your freedom to share and change free software-­to make sure the software is free for all its users. This General Public License applies to most of the Free
Software Foundation's software and to any other program whose authors commit to using it. (Some other
Free Software Foundation software is covered by the GNU Lesser General Public License instead.) You can
apply it to your programs, too.
When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are
designed to make sure that you have the freedom to distribute copies of free software (and charge for this
service if you wish), that you receive source code or can get it if you want it, that you can change the
software or use pieces of it in new free programs; and that you know you can do these things.
To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you
to surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of
the software, or if you modify it.
For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the
recipients all the rights that you have. You must make sure that they, too, receive or can get the source code.
And you must show them these terms so they know their rights.
We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives
you legal permission to copy, distribute and/or modify the software.
Also, for each author's protection and ours, we want to make certain that everyone understands that there is
no warranty for this free software. If the software is modified by someone else and passed on, we want its
recipients to know that what they have is not the original, so that any problems introduced by others will not
reflect on the original authors' reputations.
Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that
redistributors of a free program will individually obtain patent licenses, in effect making the program
proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use
or not licensed at all.
The precise terms and conditions for copying, distribution and modification follow.

TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION

0. This License applies to any program or other work which contains a notice placed by the copyright holder
saying it may be distributed under the terms of this General Public License. The "Program", below, refers to
any such program or work, and a "work based on the Program" means either the Program or any derivative
work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or
with modifications and/or translated into another language. (Hereinafter, translation is included without
limitation in the term "modification".) Each licensee is addressed as "you".
Activities other than copying, distribution and modification are not covered by this License; they are outside
its scope. The act of running the Program is not restricted, and the output from the Program is covered only if
its contents constitute a work based on the Program (independent of having been made by running the
Program). Whether that is true depends on what the Program does.

1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any

IT - 29

medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright
notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of
any warranty; and give any other recipients of the Program a copy of this License along with the Program.
You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty
protection in exchange for a fee.

2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the
Program, and copy and distribute such modifications or work under the terms of Section 1 above, provided
that you also meet all of these conditions:
a) You must cause the modified files to carry prominent notices stating that you changed the files and the
date of any change.
b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from
the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of
this License.
c) If the modified program normally reads commands interactively when run, you must cause it, when started
running for such interactive use in the most ordinary way, to print or display an announcement including an
appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a
warranty) and that users may redistribute the program under these conditions, and telling the user how to
view a copy of this License. (Exception: if the Program itself is interactive but does not normally print such an
announcement, your work based on the Program is not required to print an announcement.)
These requirements apply to the modified work as a whole. If identifiable sections of that work are not
derived from the Program, and can be reasonably considered independent and separate works in
themselves, then this License, and its terms, do not apply to those sections when you distribute them as
separate works. But when you distribute the same sections as part of a whole which is a work based on the
Program, the distribution of the whole must be on the terms of this License, whose permissions for other
licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.
Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you;
rather, the intent is to exercise the right to control the distribution of derivative or collective works based on
the Program.
In addition, mere aggregation of another work not based on the Program with the Program (or with a work
based on the Program) on a volume of a storage or distribution medium does not bring the other work under
the scope of this License.

3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or
executable form under the terms of Sections 1 and 2 above provided that you also do one of the following:
a) Accompany it with the complete corresponding machine-readable source code, which must be distributed
under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,
b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no
more than your cost of physically performing source distribution, a complete machine-readable copy of the
corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium
customarily used for software interchange; or,
c) Accompany it with the information you received as to the offer to distribute corresponding source code.
(This alternative is allowed only for noncommercial distribution and only if you received the program in object
code or executable form with such an offer, in accord with Subsection b above.)
The source code for a work means the preferred form of the work for making modifications to it. For an
executable work, complete source code means all the source code for all modules it contains, plus any
associated interface definition files, plus the scripts used to control compilation and installation of the
executable. However, as a special exception, the source code distributed need not include anything that is
normally distributed (in either source or binary form) with the major components (compiler, kernel, and so on)
of the operating system on which the executable runs, unless that component itself accompanies the
executable.
If distribution of executable or object code is made by offering access to copy from a designated place, then
offering equivalent access to copy the source code from the same place counts as distribution of the source
code, even though third parties are not compelled to copy the source along with the object code.

4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this
License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will
automatically terminate your rights under this License. However, parties who have received copies, or rights,
from you under this License will not have their licenses terminated so long as such parties remain in full
compliance.

5. You are not required to accept this License, since you have not signed it. However, nothing else grants
you permission to modify or distribute the Program or its derivative works. These actions are prohibited by

IT - 30

law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based
on the Program), you indicate your acceptance of this License to do so, and all its terms and conditions for
copying, distributing or modifying the Program or works based on it.

6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically
receives a license from the original licensor to copy, distribute or modify the Program subject to these terms
and conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted
herein. You are not responsible for enforcing compliance by third parties to this License.

7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not
limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise)
that contradict the conditions of this License, they do not excuse you from the conditions of this License. If
you cannot distribute so as to satisfy simultaneously your obligations under this License and any other
pertinent obligations, then as a consequence you may not distribute the Program at all. For example, if a
patent license would not permit royalty-free redistribution of the Program by all those who receive copies
directly or indirectly through you, then the only way you could satisfy both it and this License would be to
refrain entirely from distribution of the Program.
If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance
of the section is intended to apply and the section as a whole is intended to apply in other circumstances.
It is not the purpose of this section to induce you to infringe any patents or other property right claims or to
contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free
software distribution system, which is implemented by public license practices. Many people have made
generous contributions to the wide range of software distributed through that system in reliance on consistent
application of that system; it is up to the author/donor to decide if he or she is willing to distribute software
through any other system and a licensee cannot impose that choice.
This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this
License.

8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by
copyrighted interfaces, the original copyright holder who places the Program under this License may add an
explicit geographical distribution limitation excluding those countries, so that distribution is permitted only in
or among countries not thus excluded. In such case, this License incorporates the limitation as if written in
the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the General Public License
from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to
address new problems or concerns.
Each version is given a distinguishing version number. If the Program specifies a version number of this
License which applies to it and "any later version", you have the option of following the terms and conditions
either of that version or of any later version published by the Free Software Foundation. If the Program does
not specify a version number of this License, you may choose any version ever published by the Free
Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are
different, write to the author to ask for permission. For software which is copyrighted by the Free Software
Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will
be guided by the two goals of preserving the free status of all derivatives of our free software and of
promoting the sharing and reuse of software generally.
NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE
PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE
STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE
PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND
PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE,
YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY
COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE
PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO
USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED
INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE
PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER

IT - 31

PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS
How to Apply These Terms to Your New Programs

If you develop a new program, and you want it to be of the greatest possible use to the public, the best way
to achieve this is to make it free software which everyone can redistribute and change under these terms.
To do so, attach the following notices to the program. It is safest to attach them to the start of each source
file to most effectively convey the exclusion of warranty; and each file should have at least the "copyright"
line and a pointer to where the full notice is found.

one line to give the program's name and an idea of what it does.
Copyright (C) yyyy name of author
This program is free software; you can redistribute it and/or
modify it under the terms of the GNU General Public License
as published by the Free Software Foundation; either version 2
of the License, or (at your option) any later version.

This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
GNU General Public License for more details.
You should have received a copy of the GNU General Public License
along with this program; if not, write to the Free Software
Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA.

Also add information on how to contact you by electronic and paper mail.
If the program is interactive, make it output a short notice like this when it starts in an interactive mode:

Gnomovision version 69, Copyright (C) year name of author
Gnomovision comes with ABSOLUTELY NO WARRANTY; for details
type `show w'. This is free software, and you are welcome
to redistribute it under certain conditions; type `show c'
for details.

The hypothetical commands `show w' and `show c' should show the appropriate parts of the General Public
License. Of course, the commands you use may be called something other than `show w' and `show c'; they
could even be mouse-clicks or menu items--whatever suits your program.
You should also get your employer (if you work as a programmer) or your school, if any, to sign a "copyright
disclaimer" for the program, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright
interest in the program `Gnomovision'
(which makes passes at compilers) written
by James Hacker.

signature of Ty Coon, 1 April 1989
Ty Coon, President of Vice

IT - 32

Intenso GmbH

Data:12 luglio 2013

Dichiarazione di conformità

Noi, la Intenso GmbH,
con sede in Diepholzer Str. 15 a 49377 Vechta, Deutschland

dichiariamo su nostra responsabilità che il prodotto:

Modello: 8” TAB 814 (articolo n° 5510862)
Descrizione: Tablet computer

è conforme alle seguenti direttive e norme:

Direttiva R&TTE 1999/5/EG

 EN 301 489-1 V1.9.2
 EN 301 489-17 V2.1.1
 EN 300 328 V1.7.1 : 2006-10
 EN 55022:2010 (Class B)
 EN 55024:2010
 EN 61000-3-2:2006+A1 :2009+A2 :2009 (Class D)

 EN 61000-3-3:2008

Direttiva Bassa Tensione 2006/95/EG

 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A12:correzione 2012

Direttiva Ecodesign 2009/125/EG

 1275/2008
 278/2009

Direttiva ROHS 2011/65/EU

La documentazione tecnica riferita all’apparecchio sopra citato è stata depositata presso il
seguente luogo:

Intenso GmbH
Diepholzer Str. 15, 49377 Vechta, Deutschland

Persona autorizzata:

___________________________________
Amministratore delegato: Thomas Pöhlking

FR - 1

Mode d'emploi TAB 814

Merci d'avoir choisi TAB814. Suivez ces instructions pour connaître les fonctions clés de l'appareil.

1.) Contenu

1.) Contenu ................................................................................................................................................................................................ . 1

2.) Remarques ............................................................................................................................................................................................ 2

3.) Aperçu de l'appareil ............................................................................................................................................................................... 4

4.) Contenu de l'emballage ......................................................................................................................................................................... 4

5.) Chargement de la batterie ..................................................................................................................................................................... 5

6.) Utilisation d'une carte Micro SD / SDHC ................................................................................................................................................ 5

7.) Transmission de données entre l'appareil et un ordinateur ................................................................................................................... 5

8.) Écran tactile ........................................................................................................................................................................................... 6

9.) L'écran d'accueil .................................................................................................................................................................................... 7

Affichage ..................................................................................................................................................................................................... 7

Déverrouillage de l'écran ............................................................................................................................................................................ 7

Barre d'état ................................................................................................................................................................................................. 8

Réglage de l'écran principal ........................................................................................................................................................................ 8

Utiliser différents écrans d'accueil ............................................................................................................................................................... 9

Applications préinstallées sur l'écran d'accueil ........................................................................................................................................... 9

a) Barre de recherche pour la recherche sur Google ™ ........................................................................................................................... 10

b) Aperçu des applications ........................................................................................................................................................................ 10

c) Prévisions météorologiques .................................................................................................................................................................. 11

d) WIFI ...................................................................................................................................................................................................... 11

Connexion automatique ............................................................................................................................................................................ 11

Connexion manuelle ................................................................................................................................................................................. 12

e) Galerie .................................................................................................................................................................................................. 12

f) Musique ................................................................................................................................................................................................. 13

g) Vidéo .................................................................................................................................................................................................... 15

h) App Center ........................................................................................................................................................................................... 15

i) Navigateur Web ..................................................................................................................................................................................... 15

Utilisation du clavier virtuel ....................................................................................................................................................................... 15

Saisie de caractères spéciaux .................................................................................................................................................................. 16

Utilisation du navigateur Web ................................................................................................................................................................... 16

j) Aperçu des applications ......................................................................................................................................................................... 17

k) Paramètres système ............................................................................................................................................................................. 17

Aperçu des paramètres............................................................................................................................................................................. 18

10.) E-Book ............................................................................................................................................................................................... 19

Copie d'e-books entre l'ordinateur et le périphérique ................................................................................................................................ 19

Téléchargement d'e-books et transfert à l'appareil à l'aide d'Adobe ™ Digital Editions ............................................................................ 19

Commencez la lecture .............................................................................................................................................................................. 20

Passez de l'affichage étagère à la liste / suppression d'e-books. ............................................................................................................. 20

Tournez les pages .................................................................................................................................................................................... 21

Augmentation de la taille de police ........................................................................................................................................................... 21

Aller à une page spécifique ....................................................................................................................................................................... 21

Utilisation de signets ................................................................................................................................................................................. 21

Affichage de la table des matières ............................................................................................................................................................ 21

Affichage des informations sur le livre ...................................................................................................................................................... 21

11.) Expédition / réception des e-mails ..................................................................................................................................................... 22

Configuration de votre boîte aux lettres électronique ................................................................................................................................ 22

Gérer les comptes d'emails....................................................................................................................................................................... 23

Affichage des e-mails................................................................................................................................................................................ 23

Ecrire des messages d'email .................................................................................................................................................................... 23

12.) Gestion des applications .................................................................................................................................................................... 24

Installation des applications ...................................................................................................................................................................... 24

Désinstallation des applications ................................................................................................................................................................ 24

13.) Lecture de documents Office ............................................................................................................................................................. 25

14.) Gestionnaire des tâches ................................................................................................................................................................ .... 25

FR - 2

15.) Conditions de garantie limitée ........................................................................................................................................................... 26

16.) Données techniques .......................................................................................................................................................................... 27

18.) Entretien de l'appareil ........................................................................................................................................................................ 27

19.) Entretien de l'appareil ........................................................................................................................................................................ 27

20.) Élimination des vieux équipements électroniques ............................................................................................................................. 27

21.) Licence information............................................................................................................................................................................ 28

Déclaration de conformité CE ................................................................................................ ................................................................... 32

Ce manuel ne contient peut-être pas toutes les fonctions de votre appareil. Pour utilisation des applications de fournisseurs
tiers, veuillez contacter le fabricant. Veuillez noter que toutes les instructions peuvent être modifiées sans préavis. Vous
trouverez des informations actuelles à l'adresse www.intenso.de

Marques

Google ™, le logo Google ™ et Android ™ sont des marques commerciales de Google ™. Tous les autres noms de produits

ou de services sont la propriété de leurs propriétaires respectifs.

2.) Remarques

 Éviter les chocs violents sur l'appareil. Ne pas le poser sur des surfaces inclinées afin d'éviter

que l'appareil ne chute.

 Ne pas utiliser l'appareil dans des conditions extrêmement froides, chaudes, humides ou

poussiéreuses. Ne pas exposer non-plus au rayonnement solaire direct.

 Éviter d'utiliser sur des endroits sablonneux.
 Ne pas utiliser dans des environnements présentant un risque d'explosion, comme par exemple

aux pompes d'une station essence.

 Éviter l'utilisation de coussins, canapés ou autres objets qui favorisent un développement de la

chaleur, car il y a un risque de surchauffe de l'appareil.

 Effectuer de fréquentes sauvegardes de données, pour éviter d'éventuelles pertes de données.

Nous ne sommes pas responsables d’une perte de données éventuelle.

 Ne pas débrancher la connexion quand les données sont encours de transfert ou l'appareil en

cours de formatage. Ceci peut entraîner la perte de données.

 Les images et les films peuvent être protégés des tiers par des droits. Écouter sans licence peut

violer les droits d'auteur.

 Éviter l'utilisation dans des champs hautement magnétiques.
 Protéger l'appareil de l'humidité. Si l'humidité pénètre dans l'appareil, veuillez immédiatement

l’éteindre, puis veuillez nettoyer et sécher l'appareil.

 Veuillez ne pas utiliser de solvants chimiques pour nettoyer l'appareil. Veuillez n'utilisez ici qu'un

chiffon sec.

 Ne pas placer de flammes nues, telles que des bougies allumées, à proximité de l'appareil ou

sur celui-ci.

 Nous ne sommes pas responsables des dommages en cas de fonctionnement défectueux, ni

des pertes de données dues à une mauvaise manipulation, une réparation de l'appareil par vos
propres moyens ou un changement de batterie.

FR - 3

 Si pour une fois l'appareil venait à ne pas répondre à vos entrées, veuillez utiliser le bouton de

réinitialisation à l'arrière de l'appareil pour le faire redémarrer.

 Lorsqu'il n'est pas utilisé, veuillez débrancher l'adaptateur secteur de l'alimentation électrique.
 La prise doit se trouver dans les environs de l'appareil et être facilement accessible.
 N'utiliser l'adaptateur de courant que pour les prises reliées à la terre avec AC 100-240V~,

50/60 Hz Si vous n'êtes pas sûr de l'alimentation sur le lieu de montage, veuillez vous adresser
à votre fournisseur d'énergie concerné.

 Veuillez utiliser uniquement l’adaptateur de courant et le câble de raccordement au réseau

fournis.

 Pour interrompre l'alimentation de votre appareil, débranchez l'adaptateur secteur de la prise.

Tenir fermement l'adaptateur secteur en vous déconnectant. Ne tirez jamais sur le câble

 Ne pas ouvrir le boîtier de l'adaptateur de courant. Lorsque le boîtier est ouvert, il existe un

danger de mort par électrocution. Il ne contient aucune pièce réparable.

 Si elle n'est pas utilisée de façon prolongée, la batterie de l'appareil se décharge lentement.

Avant d'être réutilisée, celle-ci doit à nouveau rechargée.

 Veuillez respecter l'élimination écologique de l'appareil ou de la batterie.
 Veuillez ne pas démonter l'appareil en pièces détachées et veuillez ne pas tenter de le réparer

vous-même, la garantie expirant dans ce cas.

 Ne pas utiliser l'appareil dans des endroits où l'utilisation d'appareils mobiles est interdite. Ne

pas utiliser l'appareil à proximité d'autres appareils électroniques, car cela peut entraîner des
troubles dus aux signaux à haute fréquence.

 Ne pas utiliser l'appareil à proximité d'un stimulateur cardiaque, dans un hôpital ou à proximité

d'équipement médical, car cela peut entraîner des troubles dus aux signaux à haute fréquence.
Garder au moins 15cm de distance avec un stimulateur cardiaque. Veuillez contacter le
fabricant de ces appareils pour recevoir des informations concernant l'utilisation commune.

 Si vous utilisez des écouteurs ou un casque à un volume trop élevé, cela peut entraîner des

dommages auditifs permanents.

 Pour des raisons de sécurité routière, l'appareil ne peut pas être utilisé pendant la conduite par

le conducteur lui-même.

FR - 4

3.) Aperçu de l'appareil

a) Touchscreen
b) Caméra frontale
c) Etat de charge DEL : rouge s’allume

pendant le chargement. Une lumière

jaune s’allume quand la batterie sera

entièrement chargée

d) Prise casque de 3,5 mm
e) Microphone intégré
f) Entrée DC 5V 2A
g) Emplacement Micro USB

h) Touche On / Off : Appuyez longuement

pour mettre l'appareil hors tension,
appuyez brièvement pour alterner entre
le mode veille et actif.

i) Volume + / -
j) Haut-parleur intégré
k) Réinitialiser l'ouverture : Réinitialise

l'appareil s’il ne devait plus réagir.

l) Emplacement carte Micro SD
m)HDMI

4.) Contenu de l'emballage

Veuillez vérifier l'intégralité du contenu de l'emballage :

 TAB 814
 Casque stéréo
 Câble USB
 Adaptateur secteur 5V 2.0A
 Manuel d'utilisation
 Sac en simili cuir
