Inteltronic WL-XM92 Spec Sheet

Inteltronic Inc

29470 Union City Blvd, Union City, CA 94587

Office: [phone]; Fax: [phone]

Spec Sheet

Model: WL-XM92

UPC: 408320909205

z Specification:

♦ Input Power:

Electric Regulation

Item Specification Condition

Power supply

voltage

Input Power 1.5 Ampere Power= +12Vdc

Nominal Power

Supply

♦ Input Signal:

Signal Standard

Item Specification Condition

Raster Scan

Type

Input Signal

Format-1

Input Signal

Impedance

DC +10V～DC+14V

DC +12V

NTSC / PAL
System

Composite Video &

Auto
Switch

1.0 Vp-p

Burst Sync (CBVS)

75 Ohm

z Key Function

¾ Power Key
¾ Up Key
¾ Menu Key
¾ Down Key

z OSD Function

¾ Video Adjustment

(1) Brightness
(2) Color
(3) Contrast
(4) AV1 / AV2 / AV3 Select
(5) Reset
(6) Exit

¾ Audio Adjustment

(1) Volume Up (Up Key)
(2) Volume Down (Down Key)

¾ Earphone Jack (Stereo Audio Output)

z TFT LCD Panel Spec.

Display Model 9.2” color TFT LCD Monitor
Display Method TFT Active Matrix System
Dimension (mm) 228(W) x 13(D) x 144(H)
Screen Size 9.2” Diagonal / 16:9 Ratio
Resolution 1440(H) x 234(V) RGB stripe
View Angle 90° (Vertical) 120°(Horizon)

z Accessory:

¾ Instruction Manual
¾ AC Power Adapter
