WIRELESS 300N
DUAL-BAND
USB ADAPTER
USER
MANUAL
MODEL 524995
INT-524995-UM-0311-01
WASTE ELECTRICAL & ELECTRONIC EQUIPMENT
(applicable in the European Union and other European countries with separate collection systems)
ENGLISH
This symbol on the product or its packaging indicates that this product shall not be treated as household waste.
this product, contact your local city office, your household waste disposal service or the shop where you
purchased this product. In countries outside of the EU: If you wish to discard this product, contact your local
authorities and ask for the correct manner of disposal.
DEUTSCH
Dieses auf dem Produkt oder der Verpackung angebrachte Symbol zeigt an, dass dieses Produkt nicht mit
dem Hausmüll entsorgt werden darf. In Übereinstimmung mit der Richtlinie 2002/96/EG des Europäischen
Parlamentsund des Rates über Elektro- und Elektronik-Altgeräte (WEEE) darf dieses Elektrogerät nicht im
normalen Hausmüll oder dem Gelben Sack entsorgt werden. Wenn Sie dieses Produkt entsorgen möchten,
bringen Sie es bitte zur Verkaufsstelle zurück oder zum Recycling-Sammelpunkt Ihrer Gemeinde.
ESPAÑOL
Este símbolo en el producto o su embalaje indica que el producto no debe tratarse como residuo doméstico.
De conformidad con la Directiva 2002/96/CE de la UE sobre residuos de aparatos eléctricos y electrónicos
(RAEE), este producto eléctrico no puede desecharse con el resto de residuos no clasificados. Deshágase de
este producto devolviéndolo a su punto de venta o a un punto de recolección municipal para su reciclaje.
FRANÇAIS
Ce symbole sur Ie produit ou son emballage signifie que ce produit ne doit pas être traité comme un
déchet ménager. Conformément à la Directive 2002/96/EC sur les déchets d’équipements électriques et
électroniques (DEEE), ce produit électrique ne doit en aucun cas être mis au rebut sous forme de déchet
municipal non trié. Veuillez vous débarrasser de ce produit en Ie renvoyant à son point de vente ou au point
de ramassage local dans votre municipalité, à des fins de recyclage.
ITALIANO
Questo simbolo sui prodotto o sulla relativa confezione indica che il prodotto non va trattato come un rifiuto
domestico. In ottemperanza alla Direttiva UE 2002/96/EC sui rifiuti di apparecchiature elettriche ed
elettroniche (RAEE), questa prodotto elettrico non deve essere smaltito come rifiuto municipale misto. Si
prega di smaltire il prodotto riportandolo al punto vendita o al punto di raccolta municipale locale per un
opportuno riciclaggio.
POLSKI
Jeśli na produkcie lub jego opakowaniu umieszczono ten symbol, wówczas w czasie utylizacji nie wolno
wyrzucać tego produktu wraz z odpadami komunalnymi. Zgodnie z Dyrektywą Nr 2002/96/WE w sprawie
zużytego sprzętu elektrycznego i elektronicznego (WEEE), niniejszego produktu elektrycznego nie wolno
usuwać jako nie posortowanego odpadu komunalnego. Prosimy o usuniecie niniejszego produktu poprzez
jego zwrot do punktu zakupu lub oddanie do miejscowego komunalnego punktu zbiórki odpadów
przeznaczonych do recyklingu.
Disposal of Electric and Electronic Equipment
Instead, it should be taken to an applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences to the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. If your equipment contains easily removable batteries
or accumulators, dispose of these separately according to your local requirements. The recycling of
materials will help to conserve natural resources. For more detailed information about recycling of
Thank you for purchasing the INTELLINETTM Wireless 300N Dual-Band
USB Adapter, Model 524995.
This is a compact high-speed adapter that allows you to connect your
notebook or desktop PC to wireless networks at speeds faster than ever
before. Connect to a wireless network with link speeds of up to 300 Mbps
using the latest in wireless a/n dual-band technology to transfer or receive
digital images, videos and MP3 les, . This adapter is also compatible with
802.11b and 802.11g wireless access points and wireless routers, giving
you the exibility to start upgrading your
wireless network without the need to replace your existing equipment.
SyStem RequiRementS
• Notebook or Desktop PC with Pentium 1 GHz-compatible processor
or higher
• Windows XP/Vista and Windows 7
• Available Hi-Speed USB 2.0 type-A port
NOTE: Some screen images have been modied to t the format of this
manual.
FCC CeRtiFiCationS
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
3
CAUTION: Any changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to operate
the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference; and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC RF Radiation expoSuRe Statement
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment, and should be installed and operated with
a minimum distance of 2.5 cm (1 in.) between the radiator and your body.
SAR (specic absorption rate) compliance has been established in laptop
computer congurations with a USB port on the side near the center, as
tested in the application for certication, and can be used in laptops with
substantially similar physical dimensions, construction and electrical and
RF characteristics. Use in other devices, such as PDAs or lap pads, is
not authorized. This transmitter is restricted for use with the specic
antenna(s) tested in the application for certication. The antenna(s) used
for this transmitter must not be co-located or operated in conjunction with
any other antenna or transmitter.
R&tte ComplianCe Statement
This equipment complies with all the requirements of Directive 1999/5/EC
of the European Parliament and the Council of March 9, 1999, on radio
equipment and telecommunication terminal equipment (R&TTE) and the
mutual recognition of their conformity. The R&TTE directive repeals and
replaces Directive 98/13/EEC (Telecommunications Terminal Equipment
and Satellite Earth Station Equipment) as of April 8, 2000.
eu CountRieS intended FoR uSe
The ETSI version of this device is intended for home/ofce use in Austria,
Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy,
Luxembourg, the Netherlands, Portugal, Spain, Sweden and the U.K., and
is also authorized for use in EFTA member states Iceland, Liechtenstein,
Norway and Switzerland. (EU countries not intended for use: none.)
4
TABLE OF CONTENTS
section page
Hardware ............................................................................................ 6
Installation .......................................................................................... 6
Windows 7 ................................................................................... 6
Systems Other Than Windows 7 ................................................. 7
Conguration ....................................................................................9
Network ...................................................................................... 11
Prole ................................................................................................11
Prole Conguration ............................................................. 13
Prole Authentication & Encryption (Security) ...................... 14
802.1x Setting / Certication ................................................. 18
802.1x Setting / CA Server .................................................... 18
802.1x Setting / SSO ............................................................. 19
Statistics .................................................................................... 20
Advanced ................................................................................... 20
WMM.......................................................................................... 22
About.......................................................................................... 23
WPS Conguration .................................................................... 23
PBC ....................................................................................... 24
PIN Code ............................................................................... 25
Access Point / STA+AP Modes ............................................................. 26
Conguration .............................................................................26
Security Setting ......................................................................... 28
Access Control .......................................................................... 30
MAC Table .................................................................................31
Event Log ................................................................................... 31
Statistics .................................................................................... 32
About.......................................................................................... 32
Specications .................................................................................. 33
CONTENTS
5
HARDWARE
COMPONENTS
Protective cap
Link/Activity LED
WPS button
LED INDICATORS
If the Radio On/Off function is turned off (see WPS Conguration), the
wireless LAN function is disabled and the Link/Activity LED remains
unlit. If the Radio On/Off function is turned on, the Link /Activity LED will
indicate the status of the function as indicated below.
Function Status LED Indication
Radio on but Off Not linked to wireless access point or router
not linked Flashing Transmitting management information
Radio on; linked On Linked to wireless access point or router
to AP or router Flashing Transmitting data or management information*
* If WPS mode is activated, the LED will still ash.
INSTALLATION
WINDOWS 7
Windows 7 users should install the adapter using the steps in this
section. Users of other operating systems should refer to the next
section: For Operating Systems Other Than Win7.
1. Make sure your computer has a connection to the Internet.
2. Connect the USB adapter as outlined below in Steps 1 and 2 of the
next section: For Operating Systems Other Than Win7.
6
HARDWARE
3. Windows 7 will detect the new hardware and try to connect to the
Internet to download the latest driver. This may take a minute or so
depending on your Internet connection.
4. The installation is completed. You do not need to install any driver or
software from the installation CD.
This is the recommended method of installation for Windows 7. If this
procedure isn’t feasible (because your computer doesn’t have an Internet
connection, for example), install the driver from the installation CD (see
the Windows 7 quick installation guide on the CD for details).
FOR OPERATING SYSTEMS OTHER THAN WIN7
1. With your computer on, gently insert the
adapter into a USB port. NOTE: If the
adapter doesn’t easily slide into the port,
ip it over and try again.
2. The Welcome to the Found New Hardware
Wizard screen will display automatically.
Click “Cancel” to continue.
3. Insert the included setup CD and run the “autorun.exe” program. On
the main screen, click “Driver and WLAN Conguration Utility
IN STA LLATION
7
Installation.” Read the license agreement that displays; select “I accept
the terms of the license agreement”; click “Next” to continue.
4. On the Setup
Type screen,
select “Install
driver and
INTELLINET
WLAN Utility.”
Select “Install
driver only” if
you prefer to
use the Windows integrated WLAN function. Click “Next.”
5. In Windows XP and Vista, a “Microsoft Zero Conguration Tool” option
displays. It’s
recommended
the alternative
“INTELLINET
Conguration
Tool” option be
selected, as it
features more
functions. Click “ Next.”
6. Once the software installation is complete, select “Yes, I want to restart
my computer.” Once the reboot is complete, connect the adapter to
your computer. When the Found New Hardware Wizard screen displays,
select the option that allows Windows to automatically search for the
correct driver. Your adapter is now installed .NOTE: Depending on your
conguration,
you may not
see this
message and
may not need
to reboot your
computer.
8
IN STA LLATION
CONFIGURATION
The conguration utility — which displays automatically once the adapter
is connected — is a powerful application that helps you congure the
adapter and monitor link status and statistics during the communication
process. This adapter will auto-connect to the wireless device that has
the better signal strength and no wireless security setting.
The conguration utility appears as an icon in the Windows system tray
while the adapter is running. You can
open it by double-clicking on the icon.
In Windows XP, there is a “Windows Zero
Conguration Tool” option for setting up wireless clients. If you prefer to
use the conguration utility, there are two ways to switch to it instead of
using the Windows tool.
option 1
1. Right-click the utility icon in the
system tray and select “Use
INTELLINET Conguration
utility.”
option 2
1. Right-click the icon on the left side of the system tray and select “View
Available Wireless Networks.”
CONFIGURATION
9
2. Click “Change advanced settings.”
3. Uncheck “Use Windows
to congure my wireless
network settings” to
enable the utility for the
adapter. NOTE: If
“Wireless Zero
Conguration Tool” is
enabled, you can only
congure the advanced
settings or check the
link status and statistics
from the conguration
utility of the adapter.
10
CONFIGURATION
NETWORK
When you open the conguration utility, the system scans all the channels
to nd access points/stations within the accessible range of the adapter
and automatically connect to the wireless device with the highest signal
strength. On the Network screen, all the networks nearby are listed.
You can change the connection to another network or add one of the
networks to your own prole list.
Available Networks: AP List shows all available wireless networks within
the range of the adapter. It also displays network information: SSID,
BSSID, Signal Strength, Channel, Encryption, Authentication and
Network Type. To connect to a network on the list, double-click the
item and the adapter will connect automatically to it.
Rescan: Click “Rescan” to collect the new information of all the wireless
networks nearby.
Add to Prole: Click to add the selected network to the Prole list.
Connect: Click “Connect” to connect to the selected network.
PROFILE
The Prole screen is for managing networks you connect to frequently.
You can add, delete, edit and activate a prole on this screen.
Prole List: The Prole List displays all the proles and their related
settings, including Prole Name, SSID, Channel, Authentication,
CONFIGURATION
11
Encryption and Network Type.
Add, Edit, Delete: Click the corresponding button to add, edit or delete
the selected prole(s). Clicking “Add” displays the Add Prole screen,
which presents 1) Conguration and 2) Authentication and Encryption
(Security).
Import/Export: You can export individual wireless proles to your hard
drive with the export function. If you want to reload the conguration
later, perhaps for a different system, you can do that by using the
import function, which lets you reload the “.prof” le previously
exported.
Activate: To display status information about your current wireless
connection, select the prole and click “Activate.” When a prole is
activated, the adapter will be initially connected to it.
Status: This eld displays the SSID and MAC ID of the network the
adapter is connecting to.
12
CONFIGURATION
Extra Info: This eld displays the link status.
Channel: This eld displays the number of the radio channel and the
frequency used for the networking.
Link Speed (Mbps): These elds display the transmission (Tx) and the
reception (Rx) rates of the network. The maximum transmission rate
is 54 Mbps.
Throughput (Kbps): These elds display the speed of data being
transmitted (Tx) and received (Rx).
Link Quality: This status bar indicates the quality of the link. The
higher the percentage, the better the quality.
dBm: To display the signal strength measured in dBm (decibels in
milliwatts), click this box on the Network screen (see Page 9).
Signal Strength: This bar shows the signal strength level. The higher
the percentage being shown in the bar, the more radio signal being
received by the adapter. This indicator helps to nd the proper position
of the wireless device for quality network operation.
Noise Strength: This bar displays the noise level in the wireless
environment.
pRoFile ConFiguR ation
Prole Name: Dene easily recognizable prole names to identify the
different networks.
SSID: The SSID (up to 32 printable ASCII characters) is the unique name
identied in a WLAN. The ID prevents the unintentional merging of
two co-located WLANs. If you specify an SSID for the adapter, then
CONFIGURATION
13
only the device with the same SSID can interconnect to the adapter.
To add a nearby network to the prole list, pull down the menu to view
all the networks that can be selected.
Power Save Mode: The two power-saving functions are available only
when Network Type (see below) is set to “Infrastructure.”
• CAM (Constantly Awake Mode): With this selected, the adapter
will remain in an active mode.
• PSM (Power Save Mode): Enable the adapter in the power-save
mode when it is idle.
Network Type: Select from the drop-down menu.
• Infrastructure: This operation mode requires the presence of an
802.11 access point. All communication is done via the AP or router.
• Ad-Hoc: Select this mode to connect to another wireless station in
the wireless LAN network without using an access point or router.
Tx Power: To lower the transmit power of the adapter to reduce the power
used by the system, select a lower percentage from the drop-down
menu. NOTE: A lower power level will result in lower signal strength
and reduced coverage range.
RTS Threshold: This is the minimum packet size required for an RTS
(request to send). For packets smaller than this threshold, an RTS is
not sent and the packet is transmitted directly to the wireless network.
Select a setting within a range of 0 to 2347 bytes. NOTE: A minor
change is recommended.
Fragment Threshold: This value denes the maximum size of packets;
any packet size larger than the value will be fragmented. If you’ve
decreased this value and experience high packet-error rates, you
can increase it again, but it will likely decrease overall network
performance. Select a setting within a range of 256 to 2346 bytes.
NOTE: A minor change is recommended.
pRoFile authentiCation and enCRyption (SeCuRity)
Authentication Type: This pull-down menu setting has to be consistent
with the wireless networks that the adapter is intended to connect.
• Open: No authentication is needed within the wireless network.
• Shared: Only wireless devices using a shared key (WEP key
14
CONFIGURATION
identied) are allowed to connect to each other.
• LEAP: This is a pre-EAP, Cisco-proprietary protocol with many of
the features of EAP protocols. Cisco controls the ability of other
vendors to implement this protocol, so it should be selected for use
only when a limited vendor choice for client, access point and server
products is not a concern. When you’ve set up LEAP authentication,
you need to enter the username and password of your computer.
• W PA: WPA provides a scheme of mutual authentication using either
IEEE 802.1x/Extensible Authentication Protocol (EAP) authentication
or pre-shared key (PSK) technology. It provides a high level of
assurance to enterprises, small businesses and home users that
data will remain protected and that only authorized users may access
their networks. For enterprises that have already deployed IEEE
802.1x authentication, WPA offers the advantage of leveraging
existing authentication databases and infrastructure.
• W PA-PS K: This is a special mode designed for home and small
business users who do not have access to network authentication
servers. In this mode, known as Pre-Shared Key, you manually
enter the starting password in your access point or gateway, as
well as in each wireless station in the network. WPA-PSK takes
over automatically from that point, keeping unauthorized users who
don’t have the matching password from joining the network, while
encrypting the data traveling between authorized devices.
• WPA2: Like WPA, WPA2 supports IEEE 802.1x/EAP authentication,
CONFIGURATION
15
or PSK, technology. It also includes a new advanced encryption
mechanism using the Advanced Encryption Standard (AES). AES is
required for corporate or government users. The difference between
WPA and WPA2 is that WPA2 provides data encryption via AES. In
contrast, WPA uses the Temporal Key Integrity Protocol (TKIP).
• W PA 2-PSK: This is also for home and small business use. The
difference between WPA-PSK and WPA2-PSK is that WPA2-PSK
provides data encryption via the AES. In contrast, WPA-PSK uses
the Temporal Key Integrity Protocol (TKIP).
• CCKM: Cisco Centralized Key Management (CCKM) is a form of fast
roaming. When a wireless LAN is congured for fast reconnection,
a LEAP-enabled client device can roam from one access point to
another without involving the main server. Using CCKM, an access
point congured to provide wireless domain services (WDS) takes
the place of the RADIUS server and authenticates the client without
any perceptible delay in voice or other time-sensitive applications.”
802.1x Setting: When Authentication Type is set to “Open,” “Shared,”
“WPA” or “WPA2,” you can also enable IEEE 802.1x Setting to use the
authentication server or certication server to authenticate client users.
NOTE: See the two separate 802.1x Setting sections below for details.
Encryption: Select from the drop-down menu.
• None: Disables the encryption mode.
• WEP: Enables the WEP Data Encryption. When the item is selected,
you need to continue setting the WEP Encryption keys.
• TKIP: The Temporal Key Integrity Protocol changes the temporal key
every 10,000 packets (a kind of message transmitted over a network.)
This ensures much greater security than the standard WEP security.
• AES: AES has been developed to ensure the highest degree of
security and authenticity for digital information. It’s the most advanced
solution dened by IEEE 802.11i for security in the wireless network.
NOTE: All devices in the network should use the same encryption
method to ensure the security of communications.
WPA Pre-Shared Key: The WPA-PSK key can be 8 to 64 characters in
length and can be letters or numbers. This same key must be used on
all the wireless stations in the network.
WEP Key (Key#1– 4): WEP keys are used to encrypt data transmitted
16
CONFIGURATION
in the wireless network. There are two types of key length: 64-bit and
RADIUS
Server
Windows 2000 IAS
Access Point
RADIUS
Client
1
2
3
4
128-bit. Assign a default encryption key (Key#1 to Key#4) by clicking
on the corresponding radio button. To ll in each text eld:
• 64-bit: Input 10-digit hex values (in the A-F, a-f and 0-9 range) or
5-digit ASCII characters (a-z and 0-9) as the encryption keys.
For example: “0123456aef“ or “test1.”
• 128-bit: Input 26-digit hex values (in the A-F, a-f and 0-9 range) or
13-digit ASCII characters (“a-z” and “0-9”) as the encryption keys.
For example: “01234567890123456789abcdef“ or “administrator.”
The IEEE 802.1X specication describes a protocol that can be used for
authenticating both clients (802.1x Setting/Certication below) and servers
(802.1x Setting/CA Server below) on a network. The authentication
algorithms and methods are those provided by the Extensible Authentication
Protocol (EAP), a method of authentication that has been in use for a
number of years on networks that provide Point-to-Point Protocol (PPP)
support (as many Internet service providers and enterprises do). EAP
runs before network layer protocols transmit data over the link.
When an AP acting as an authenticator detects a wireless station on the
LAN, it sends an EAP request for the user’s identity to the device. In
turn, the device responds with its identity, and the AP relays this identity
to an authentication server (typically an external RADIUS server).
IEEE 802.1x Access Client RADIUS Client RADIUS Server
1
2
1 Client requests to log in to the net work 3 Username and password sent to RADIUS server
2 Log in with username and password 4 User login to the LAN approved or denied
3
4
CONFIGURATION
17
802.1x Setting / CeRtiFiCation
EAP Method: The EAP authentication protocols supported by this
adapter require that settings be consistent with the wireless access
points or routers that the adapter is intended to connect.
• PEAP & TTLS: These protocols are similar and easier to use than
TLS (below) in that they specify a stand-alone authentication protocol
to be used within an encrypted tunnel. TTLS supports any protocol
within its tunnel, including CHAP, MS-CHAP, MS-CHAPv2, PAP and
EAP-MD5. PEAP species that an EAP-compliant authentication
protocol be used; this adapter supports EAP-MSCHAP v2, EAP-TLS/
Smart Card and Generic Token Card. The client certicate is optional.
• TLS/Smart Card: This is the most secure of the EAP protocols, but
isn’t easy to use: It requires that digital certicates be exchanged in
the authentication phase. The server presents a certicate to the
client and, after validating the server’s certicate, the client presents
a client certicate to the server for validation.
Session Resumption: Click/check the box to activate or de-activate.
ID/Password: Enter the password as the identity for the server.
Client Certication: A client certicate is required for TLS, but is
optional for TTLS and PEAP. This forces a client certicate to be
selected from the appropriate Windows Certicate Store and made
available to the RADIUS server for certication.
Tunneled Authentication/Protocol: When the authentication type is
PEAP or TTLS, select a protocol for building the encrypted tunnel.
Tunnel Authentication: Select one of three options from the drop down menu: “EAP-MSCHAPv2,” “EAP-TLS/Smart card” or “Generic
Token Card.”
18
CONFIGURATION
802.1x Setting / Ca SeRveR
Use certicate chain: When the Extensible Authentication Protocol
(EAP) authentication type — such as TLS, TTLS or PEAP — is
selected and requires certication to tell the client what credentials to
accept from the authentication server in order to verify the server, you
need to enable this function. Choose the preferred server from the
drop-down menu to issue the certicate. If “Any Trusted CA” is
selected, any CA (certication authority) on the list (which is provided
by the Microsoft Certicate Store) is permitted.
Allow intermediate certicates: A server designates an issuer as a
trusted root authority by placing the issuer’s self-signed certicate,
which contains the issuer’s public key, into the trusted root certication
authority certicate store of the host computer. Intermediate or
subordinate certication authorities are trusted only if they have a
valid certication path from a trusted root certication authority.
Server Name: Enter the authentication server name.
802.1x Setting / SSo
With SSO (Single Sign-On), a user logs in once and gains access to
all systems without being prompted to log in again at each of them.
Once the user has successfully logged in to the operating system, he
or she has access to different services. NOTE: This tab is unavailable
in Windows 2000 and XP. In those systems, the SSO conguration
options are located on the SSO tab of the conguration utility’s main
navigation bar.
Enable SSO (Single Sign On): Click to turn on the SSO service.
CONFIGURATION
19
Allow Machine Authentication: Select this option to authenticate the
computer, not the user.
Authentication Type: Select the time at which wireless network
authentication will take place:
• Pre-logon: Before the user logs in to the operating system.
• Post-logon: After the user logs in to the operating system.
STATISTICS
This screen enables you to view/compare the transmit and receive
statistical information of the connection. To reset the counters, click
”Reset Counter.”
ADVANCED
This screen enables you to congure more advanced settings, such as
the wireless mode and the protection mode.
20
CONFIGURATION
Wireless Mode: Select the operation mode from the drop-down menu.
• 2.4G: The adapter can be operated in 802.11b/g/n wireless networks.
• 5G: The adapter can be operated in 802.11a/n wireless networks.
• 2.4 + 5G: The adapter can be operated in 802.11a/b/g/n wireless
networks.
Country Region Code: These values cannot be changed manually, as
they depend on your location.
Enable Tx Burst: Activate this option to accelerate the data transmit
rate. NOTE: This function may not work with all wireless access
points and wireless devices.
Enable TCP Window Size: Check this box to adjust the TCP window
size automatically for the best possible performance. It should be
safe for most of wireless environments; however, if you experience
problems with the wireless connection, you should disable the option.
Fast Roaming: Activate to control the threshold at which the adapter
should switch to another wireless access point with a better signal
quality. The adapter will fast roam when the receive sensitivity (signal
strength) is below the value entered. The lower the number entered,
the longer will the card stay connected to your current access point.
Enable CCX: This is Cisco Compatible Extensions, for radio monitoring
and fast roaming. This function is not available in Windows 7, and
you may not nd the options described below on the interface of
your utility.
Turn on CCKM: During normal operation, LEAP-enabled client devices
CONFIGURATION
21
mutually authenticate with a new AP by performing a complete LEAP
authentication, including communication with the main RADIUS server.
When a wireless LAN is congured for fast re-association, however,
LEAP-enabled client devices roam from one access point to another
without involving the main server. Using Cisco Centralized Key
Management (CCKM), an access point congured to provide wireless
domain services (WDS) takes the place of the RADIUS server and
authenticates the client so quickly that there is no perceptible delay
in voice or other time-sensitive applications.
Enable Radio Measurement: When this parameter is enabled, the Cisco
AP can run the radio monitoring through the associated CCX-compliant
clients to continuously monitor the WLAN radio environment and
discover any new APs that are transmitting beacons.
Non-Serving Channel Measurements: The Cisco access point can
perform monitoring measurements through the CCX-compliant clients
on the non-serving channels when this parameter is enabled.
Limit [xxx] milliseconds (0-2000): This setting limits the channel
measurement time. The default value is 250 milliseconds.
Turn off RF: Click to turn off the radio; click again to turn it back on.
WMM
This screen enables you to congure WMM (Wi-Fi Multimedia) and
other QoS settings, such as Power Save and Direct Link Setup.
22
CONFIGURATION
WMM Enable: Click the check box (then click “Apply”) to enable the WMM
function, which then lets you congure the WMM Power Save and
Direct Link Setup functions.
• WMM – Power Save Enable: Click the check box to enable, then
click “Setting” to further congure the function as “AC_BK,” “AC_BE,”
“AC_VI” or “AC_VO.”
• Direct Link Setup Enable: Click the check box to enable, then click
“Apply” to further congure the function (all within the Direct Link panel).
- MAC Address: Specify the MAC address of the client adapter you
want to direct link to and click “Apply” to add to the DLS Status
table (below).
- Timeout Value: Specify the timeout value for the direct link being
set up.
ABOUT
On this screen, you can click the hyperlink for information on the wireless
chipset manufacturer. Basic information about the utility (driver, EEPROM
version, etc.) also displays, as do various addresses for quick reference.
WPS CONFIGURATION
The adapter supports WPS (Wi-Fi Protected Setup), allowing connection
to wireless APs that also suppor t WPS without complicated procedures.
CONFIGURATION
23
Two WPS conguration methods are available when you click to display
this screen: PBC (push-button conguration) and PIN Code (an option
for older APs not equipped with the WPS push button but which may be
transformed into a WPS-enabled access point through a rmware upgrade).
pBC (puSh-Button ConFiguRation)
1. From the “Cong Mode” drop-down menu, select “Enrollee,” then press
the WPS button (or whichever button is used to activate the WPS
Standby mode) on your wireless access point. NOTE: Refer to your
wireless access point’s user manual for the specic procedure(s).
Alternatively, you can select “Registrar,” in which case this adapter
will wait for other WPS-enabled access points to send WPS pairing
requests. NOTE: Refer to your wireless access point’s user manual
to understand how to send WPS requests.
2. Before you start to establish the wireless connection using WPS, you
can click “Rescan” to search again for WPS-enabled access points
near you in order to make sure the WPS function of your access point
is activated. All access points with the WPS function enabled will be
displayed in the WPS AP List eld. If the access point you want to
connect to isn’t listed, click “Rescan” a few more times.
3. Begin the PBC pairing procedure on the access point side (again,
refer to your access point’s manufacturer’s instructions), then click
“PBC” to establish a wireless connection via WPS. NOTE: This may
require as much as a full minute to complete. When the “WPS status
is connected successfully” message displays, the connection between
the adapter and the access point has been successfully established
through WPS and information about the access point you connected
to will be displayed.
4. Should the WPS function fail, you may nd that clicking “PBC” a few
more times will result in a connection. When an AP is connected, you
can click “Disconnect” to break the connection, or you can highlight/
select another WPS-enabled wireless access point when more than
one is found, then click “Connect” to establish that connection. You
can also click “Rotate” to select the next AP on the list for connection.
24
CONFIGURATION
Information: Click to display a pop-up window describing a selection.
Detail: Click to show details of a selected WPS-enabled access point.
Export Prole: Click to save a highlighted connection on the list as a
prole, which will display on the WPS Prole list and which can be
retrieved in the Prole menu.
Delete: Delete the selected WPS-enabled access point from the list.
pin Code
1. Enter the 8-digit PIN code of the adapter in your wireless access point
as the WPS PIN code. NOTE: Refer to your wireless access point’s
user manual for instructions. If you have a problem with the PIN code
provided here, click “Renew” to get a new PIN code.
CONFIGURATION
25
2. Click “PIN.” After a short period (up to a minute), if a wireless access
point with the correct PIN code is found, you’ll be connected to that
access point. NOTE: As with PBC, you may need to click “PIN” a
number of times to make a connection. (It helps to conrm you’ve
entered the correct PIN code into the AP.)
Information: Click to display a pop-up window describing a selection.
Detail: Click to show details of a selected WPS-enabled access point.
Export Prole: Click to save a highlighted connection on the list as a
prole, which will display on the WPS Prole list and which can be
retrieved in the Prole menu.
Delete: Delete the selected WPS-enabled access point from the list.
ACCESS POINT / STA+AP MODES
This adapter can run as a wireless
access point (AP). Right-click the
conguration utility icon on the
Windows system tray and select
“Switch to AP Mode” (Windows
2000/XP) or “Switch to STA+AP
Mode” (Windows 7) to activate the software access point function.
CONFIGURATION
This screen enables you to congure the AP connection setting, the
Country Region Code and other advanced functions.
SSID: The SSID (up to 32 printable ASCII characters) is the unique
name identied in a wireless LAN. The ID prevents the unintentional
merging of two co-located WLANs. The default SSID of the AP is
“Soft AP-X.” (“X” is the last number of this adapter’s MAC address).
Wireless adapters connected to the access point should be set up
with the same SSID as the AP.
Channel: Select the number of the radio channel used by the access
point. Any wireless adapters connected to the AP should be set up
with the same channel.
26
AP / STA+AP
Wireless Mode: Selects the wireless mode supported by the AP.
Use MAC Address: Click to create a unique SSID based on the adapter’s
MAC address.
Security Setting: Click to further congure WLAN authentication and
security settings. (See the separate Security Setting section below.)
Country Region Code: Channel availability varies from country to
country; e.g., USA (FCC) channels are 1-11, while Europe’s (ETSI) are 1-13.
Beacon (ms): Dene the time between beacons (default is 100 ms.)
Tx Powe r : To lower the transmit power of the AP to reduce the power
used by the system, select a lower percentage from the drop-down
menu. NOTE: A lower power level will result in lower signal strength
and reduced coverage range.
Idle Time: Select the idle time for the wireless access point. The default
value is 300, and normally there is no need to change it.
No forwarding among wireless clients: Enable to prevent wireless
clients connected to this AP from sharing information with each other.
Hide SSID: When this box is checked, the AP will not appear in the site
survey list of any wireless clients, meaning only the wireless clients
set with the same SSID can connect to the AP. This prevents the AP
AP / STA+AP
27
being connected to by unauthorized users.
Allow BW 40 MHz: Check this box to allow BW 40 MHz capability.
Tx Burst: Check this box to accelerate the data transmit rate. It may not
work with all wireless access points and wireless devices.
Default: Click to use the default value.
Apply: Click to apply the setting change(s).
SECURITY SETTING
This screen — accessed by clicking “Security Setting” on the previous
Conguration screen — lets you to congure the authentication mode
and encryption algorithm used within the AP.
Pre-Shared Key
Authentication Type: Four types of authentication mode are
supported and presented in the drop-down menu.
28
AP / STA+AP
• Open: No authentication is needed within the wireless network.
• W PA-PS K: This is a special mode designed for home and small
business users who do not have access to network authentication
servers. In this mode, known as Pre-Shared Key, you manually
enter the starting password in your access point or gateway, as well
as in each wireless station in the network. WPA-PSK automatically
takes over from that point, keeping unauthorized users who don’t
have the matching password from joining the network, while
encrypting the data traveling between authorized devices.
• W PA 2-PSK: This is also for home and small business use.
• WPA-PSK/WPA2- PSK : When selecting this mode, the AP supports
both WPA-PSK and WPA2-PSK.
Encryption Type: Five options are available in the drop-down menu.
• Not Use: Disables the encryption mode.
• WEP: Enables WEP Data Encryption. When the item is selected,
continue setting the WEP Key.
• TKIP: The Temporal Key Integrity Protocol changes the temporal
key every 10,000 packets (a kind of message transmitted over a
network.) This ensures much greater security than standard WEP
secur ity.
• AES: Advanced Encryption Standard was developed to provide the
highest degree of security and authenticity for digital information.
It’s the most advanced solution dened by IEEE 802.11i for security
in a wireless network.
• BOTH: In this mode, the AP supports both TKIP and AES.
WPA Pre-Shared Key: The WPA-PSK key can be 8 to 64 characters in
length and can be letters or numbers. This same key must be used on
all the wireless stations in the network.
Group Rekey Interval: This function is available when using WPA-PSK
and WPA2-PSK encryption algorithms.
WEP Key (Key#1– 4): WEP keys are used to encrypt data transmitted
in the wireless network. There are two types of key length: 64-bit and
128-bit. Assign a default encryption key (Key#1 to Key#4) by clicking
on the corresponding radio button. To ll in each text eld:
• 64-bit: Input 10-digit hex values (in the A-F, a-f and 0-9 range) or
AP / STA+AP
29
5-digit ASCII characters (a-z and 0-9) as the encryption keys.
For example: “0123456aef” or “test1.”
• 128-bit: Input 26 -digit hex values (in the A-F, a-f and 0-9 range) or
13-digit ASCII characters (“a-z” and “0-9”) as the encryption keys.
For example: “01234567890123456789abcdef“ or “administrator.”
Show Password: The password will be displayed in clear text instead
of with asterisks.
ACCESS CONTROL
This screen lets you congure the access control policy used within the
access point.
MAC Table
Access Policy: Select from the drop-down menu.
• Disable: Disables the MAC address ltering function.
• Allow All: Only wireless adapters with a MAC address on the access
list can connect to the AP.
• Reject All: Wireless adapters with a MAC address on the access
list will be prevented from connecting to the AP.
MAC Address: This is the unique 12-digit hexadecimal identication for
hardware devices in the network.
30
AP / STA+AP
Access List: Displays all the MAC address that have been added.
• Ad d: Add the MAC address to the access list.
• Delete: Delete the selected MAC address from the access list.
• Remove All: Remove all MAC addresses from the access list.
Apply: Click to apply the setting change(s).
MAC TABLE
This screen displays details of the wireless adapters connected to the AP.
MAC Table
MAC Address: The addresses of wireless adapters connected to the AP.
AID: The Association ID of the current connection.
Power Saving Mode: The supporting status of the power saving mode
of the connected wireless adapter.
EVENT LOG
This screen displays event times and messages. Click “Clear” to remove
displayed information.
MAC Table
AP / STA+AP
31
STATISTICS
This screen displays the transmit and receive statistical information of
the AP. Click “Reset Counters” to clear the data.
ABOUT
This screen displays basic information about the utility, including the
MAC address.
MAC Table
32
AP / STA+AP
SPECIFICATIONS
Standards
• IEEE 802.11a (54 Mbps Wireless
LAN)
• IEEE 802.11b (11 Mbps Wireless
LAN)
• IEEE 802.11g (54 Mbps Wireless
LAN)
• IEEE 802.11n (300 Mbps
Wireless LAN)
General
• Interface: Hi-Speed USB 2.0
• Chipset: Ralink RT3572
• Frequency band:
- 2.4000 - 2.4835 GHz (Industrial
Scientic Medical Band)
- 5.1500 - 5.8250 GHz (Industrial
Scientic Medical Band)
• Modulation technologies:
- 802.11b: Direct Sequence
Spread Spectrum (DSSS):
DBPSK, DQPSK, CCK
- 802.11g: Orthogonal Frequency
Division Multiplexing (OFDM):
BPSK, QPSK, 16QAM, 64QAM
- 802.11n: Orthogonal Frequency
Division Multiplexing (OFDM):
BPSK, QPSK, 16QAM, 64QAM
• Security:
- 64/128-bit WEP data encryption
- WPA and WPA2
- Cisco CCX
• Transmit power 2.4 GHz:
- 11n: 13 dBm +/- 1.5 dBm
- 11g: 14 dBm +/- 1.5 dBm
- 11b: 17 dBm +/- 1.5 dBm
• Transmit power 5 GHz:
- 11n: 12 dBm +/- 1.5 dBm
- 11a: 12 dBm +/- 1.5 dBm
• Receive sensitivity:
- 11n 40 MHz: -066 dBm +/- 2 dBm
- 11n 20 MHz: -068 dBm +/- 2 dBm
- 11g: -76 dBm +/- 2 dBm
- 11b: -89 dBm +/- 2 dBm
- 11a: -72 dBm +/- 2 dBm
• Antennas: 2T2R mode, 2 printed
LEDs
• Link/Activity
Environmental
• Dimensions: 10 (H) x 28 (W) x
89.6 (L) mm (0.4 x 1.1 x 3.5 in.)
• Weight: 0.17 kg (0.4 lbs.)
• Operating temperature: 0 - 40°C
(32 - 104°F)
• Operating humidity: max. 95% RH,
non-condensing
System Requirements
• Notebook or Desktop PC with
Pentium 1 GHz-compatible
processor or higher
• Windows XP/Vista/7
• Hi-Speed USB 2.0 type-A port
Package Contents
• Wireless 300N Dual-Band USB
Adapter
• USB extension cable
• Setup CD with user manual;
quick installation guide
SPECIFI CATIONS
33
INTELLINET NETWORK SOLUTIONS™ offers a complete line
of active and passive networking products.
Ask your local computer dealer for more information or visit
www.intellinet-network.com.
All products mentioned are trademarks or registered trademarks of their respective owners.
Copyright © INTELLINET NETWORK
SOLUTIONS
Loading...
