NEW
Ultra Long Range
Outdoor Fast
Ethernet PoE+
Extender Kit
Model# 561952
The Intellinet Network Solutions Ultra Long Range Outdoor Fast Ethernet
PoE+ Extender Kit adds up to 1,000 m (3,280 ft.) to the connection dis-
tance from a PoE source to an output device via Cat5e or Cat6 cable. It
has an output power rating up to 30 watts, which is enough for many
power-hungry PoE devices. Its high range and weatherproof housing is
especially useful for outdoor IP surveillance camera deployments. This
PoE repeater delivers up to 30 W at 100 Mbps over 300 m (984 ft.) or up
to 15.4 W at 10 Mbps over 800 m (2625 ft.).
HIGHLIGHTS
• Extremely high PoE range and weatherproof housing ideal for IP
camera installations
• IP67-rated, dustproof and waterproof
• Delivers data up to 1000 m (3280 ft.) without packet loss
• Kit includes two modules for maximum distance capabilities
• Compatible with IEEE 802.3bt/at/af-compliant powered devices
(PD) such as network cameras, wireless access points, VoIP
phones and more
• Supports 10/100 Mbps data rates
• Short-circuit, overload and high-voltage protection
• Requires no additional power supply; draws power directly from
the PoE input
• Compatible with IEEE 802.3bt/at/af-compliant PoE injectors and
PoE switches (PSE)
• Plug-and-play installation; no configuration required
• Fully NDAA-compliant
• Three-year warranty
Ultra Long Distance Power over Ethernet
Extension / Repeater / Amplifier for a PoE
range up to 1,000 m (3,280 ft.) - even in
harsh outdoor conditions
manhattanproducts.us
intellinetsolutions.com
© 2023 IC Intracom. All rights reserved. Intellinet Solutions is a trademark of IC Intracom, registered in the U.S. and other countries. Other trademarks and trade names are the property of their respective owners.
