Cat6a Shielded Patch Panel
24-Port, FTP, 1 U, 90° Top-Entry Punch-Down Blocks, Black
Part No.: 720861
The Intellinet Network Solutions Cat6a Shielded Patch Panel helps IT staff create the right
Cat6a-compliant network for their organization. Whether wiring connection points for all
eligible pieces of equipment or adding more ports to the network with the latest Ethernet
cabling standard available, the Cat6a Shielded Patch Panel makes the evolution of your
network possible. The panel is designed for fully shielded twisted-pair Cat6a wires, and
compatible Krone punch-down tools will help get ports wired quickly. The Intellinet Network
Solutions Cat6a Shielded Patch Panel adheres to current industry standards and is
19"-rack compliant.
Features:
Solid and reliable terminations for copper cable, featuring a minimum of 3-micron
gold-plated jack contacts
Top-entry punch-down blocks simplify installation
Compatible with Krone punch-down tools
Supports 22 to 24 AWG stranded and solid wire
For use with fully shielded twisted pair (FTP) Cat6a network cable
Ideal for Ethernet, Fast Ethernet and Gigabit Ethernet network applications
Meets 19" rackmount standards
Lifetime warranty
Specifications:
Standards
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3ab (1000Base-T Gigabit Ethernet)
Certifications
• UL listed
• RoHS compliant
• CE
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.
Page 2
Environmental
• Dimensions: 98.5 (L) x 482 (W) x 44.3 (H) [mm] / 3.88 (L) x 18.98 (W) x 1.74 (H) [in]
• Horizontal distance between left and right mounting holes: 465 mm (18.3 in.)
• Vertical distance between top and bottom mounting holes: 32 mm (1.25 in.)
• Weight: 1.5 kg
• Operating temperature: 0 – 70°C (32 – 158°F)
Package Contents
• Cat6a Shielded Patch Panel
• Grounding wire
• Quick Install Guide
