Page 1
INT-523646/523653-UM-0107-03
5/8-PORT
FAST ETHERNET
OFFICE SWITCH
USER MANUAL
MODEL 523646/523653
Page 2
2
Thank you for purchasing the INTELLINET NETWORK SOLUTIONS™ Fast Ethernet Office
Switch, Model 523646 (5-port) or Model 523653 (8-port).
Use this manual for reference when setting up and operating this switch, and enjoy the benefits
of high-speed dynamic memory, which supports the packet store-and-forward architecture;
IEEE802.3x back-pressure flow control, which manages the data flow between sending and
receiving nodes to prevent packet loss; and these additional popular features:
• 10/100 auto-sensing ports automatically detect optimal network speeds
• Supports any combination of 10 Mbps or 100 Mbps network devices
• All RJ-45 ports with Auto-MDIX and NWay auto-negotiation support
• Compact case makes positioning easy
• 10/100 Mbps and half/full duplex
• NWay Auto-Negotiation
• Non-blocking design
• Supports Broadcast Storm control
• LEDs for power, link/activity
• Supports 1024 MAC address entries
• 128 kBytes buffer memory (5-port); 256 kBytes buffer memory (8-port)
• Lifetime Warranty
Page 3
3
FRONT PANEL
The front-panel LED indicators — POWER, LINK/ACT — allow for more convenient monitoring
and troubleshooting of the switch. The table below shows each LED function.
REAR PANEL
Power receptacle: Plug the female end of the power cord firmly into the receptacle and the
other end into an electrical outlet. Confirm that the power LED is lit for a normal power status.
NOTE: To ensure proper operation, use only the power cord included with the switch.
Ports: All the ports on the Fast Ethernet Office Switch support Auto-MDI/MDI-X functionality, so
crossover cables and uplink ports are not needed for connections to PCs, routers, hubs,
additional switches or other devices. Cat5/5e UTP/STP cables provide optimal performance;
if a front-panel LED corresponding to any of the ports in use doesn’t indicate a link or activity,
check the connected device for proper setup and operation.
System LED Status Operation
POWER Steady green Power on
Off Check AC connection; turn on power switch
LINK/ACT Steady green Valid port connection
Blinking green Valid port connection; data being transmitted/received
Page 4
4
INSTALLATION
1. Attach the included rubber feet to the bottom of the device to keep it from slipping. The
recommended positions are marked.
2. Place the device on a level surface that can support the weight of the switch (and any other
items that need to be considered).
Prior to use, it is recommended that the device be placed/positioned:
• with a minimum of 25 mm of clearance on the top and sides for adequate ventilation
• away from sources of electrical noise, such as radios, transmitters and broadband amplifiers
• where it cannot be affected by excessive moisture
Page 5
5
SPECIFICATIONS
Standards
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3x (flow control, full duplex mode)
General
• Media support:
- 10Base-T Cat3, 4, 5 UTP/STP RJ-45
- 100Base-TX Cat5 UTP/STP RJ-45
• Ports:
- 5-port version: 5 RJ-45 10/100 Mbps ports
- 8-port version: 8 RJ-45 10/100 Mbps ports
• Packet filter/forwarding rate:
- 148,800 pps (100 Mbps)
- 14,880 pps (10 Mbps)
• Switch architecture: store and forward
• Buffer memory: 128 kBytes (5-port); 256 kBytes (8-port);
• MAC address table: 1024 entries
• Certifications: FCC Class B, CE Mark
Page 6
6
LEDs
• POWER
• LINK/ACT
Power
• External power adapter, 9 V AC
• Power consumption: 2.5 Watts (maximum)
Environmental
• Plastic housing
• Dimensions, 5-port: 105 (L) x 77 (W) x 30 (H) mm (4.1 x 3 x 1.2 in.)
• Dimensions, 8-port: 127 (L) x 84 (W) x 30 (H) mm (5 x 3.3 x 1.2 in.)
• Weight: 500 g (1.1 lbs.)
• Operating temperature: 0° to 40°C (32° to 104°F)
• Operating humidity: 10% to 90% RH, non-condensing
• Storage temperature: -40° to 70°C (-40° to 158°F)
Package Contents
• Fast Ethernet Office Switch
• External power adapter
• User manual
Page 7
7
NOTES
Page 8
Are you completely satisfied with this product?
Please contact your INTELLINET NETWORK SOLUTIONS
™
dealer
with comments or questions.
Copyright © INTELLINET NETWORK
SOLUTIONS
All products mentioned are trademarks or registered trademarks of their respective owners.
www.intellinet-network.com
