Intelligent Dryflow Viper User Manual

Dryflow Viper

user manual

Dryflow Viper 2

1. It is equipped with an automatic infrared ray induction system,
which means you do not have to touch the unit at any time, so this
effectively avoids pathogen cross infection and re-contamination.

2. It has outstanding performance with advanced technology and
infrared sensor.

3. It has a high speed motor with RPM of 24,000.

4. This product comes with over current protection.

5. Easy to install. It is suitable for schools, factories, office buildings,
hotels and similar locations.

Air Speed

10 - 15 sec.

3 Intelligent Facility Solutions

Air outlet

1. Do not install above stainless steel or other locations with reflective surfaces, otherwise
the unit will be prone to self-operating.

2. The unit should be firmly fixed to a smooth, completely flat wall.

3. A minimum distance of 100mm should be left clear either side of the unit.

4. Avoid locations where people or doors might damage the unit.

5. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, unless they are supervised and instructed how to use the
appliance by the person responsible for their safety.

1. Do not install in the following places as this may cause the unit to malfunction and cause
accidents:

- In areas with temperatures below 10°C or above 40°C.

- Where the unit is likely to be splashed by water or can get excessively wet.

- In direct sunlight.

- In an area where there is condensation.

- In an area close to chemicals or gases.

- In altitude over the range of 0-2000m.

2. You must cut off the power before installation and maintenance.

3. Do not dismantle, repair or make alterations to this machine without authorisation, otherwise
there is a risk of electric shock, fire and other accidents.

4. The machine must have an earth connection.

5. If the power is over +/-10% the unit will malfunction. Using an incorrect power supply will
invalidate the guarantee.

Sensor

Mounting plate

Air intake grille

Filter

Components:

Dryflow Viper 4

5 Intelligent Facility Solutions

Attention: If the air flow becomes weak, please
clean the filter. Do not use water.

Unlock the filter grille and use
the ridge in the middle of the
filter grille to pull and remove.

Get the filter from
the filter grille.

Put the filter at the right
position in the filter
grille, and insert the
filter grille back onto the
unit, making sure to turn

Clean the dust on the filter, do not wash.
If there is too much dust, please replace the filter.

1. It is equipped with an automatic infrared ray induction system,
very easy to use, reducing waste, and no touching, which
effectively avoids pathogen cross infection and re-contamination.

2. It has outstanding performance with most advantage chip
control technology and infrared sensor.

3. It has unified high speed motor with RPM of 24,000.

4. This series product comes with over current protection, which
effectively eliminates accidents.

5. Easy to install. It is suitable for all departments in hospitals,
school, food and pharmaceutical manufacturers, airports, office
buildings, hotels, government agencies and research
institutions and other places.

Cleaning of Filter

the lock to secure in place.

The air filter must be installed

when operating the unit.

Dryflow Viper 6

1. Please cut off the power and clean the cover with neutral detergent using
a clean soft dry cloth when it is dirty. Do not use solvents, acid or alkaline
cleaners or hard brushes as these can damage the machine surface or cause
it to discolour;

2. When cleaning the cover prevent water droplets getting into the machine
to avoid electric shock or short circuit;

3. If the power cord is damaged, it must be replaced by the manufacturer,
its service agents or similar qualified person;

4. If the machine breaks down, cut off the power; please commission a
professional to repair it.

1. The product guarantee period is 3 years.

2. The guarantee period came into effect from the date of buying
the machine.

3. The following are not covered by the guarantee:

Improper use and fault caused by demolition, alteration
and repair by persons not technically qualified.

Fires, earthquakes, thunder and other natural disasters
causing faults and abnormal voltage.

Faults caused by non matching power.

Faults caused by excessive use in non optimal operating conditions.

Intelligent Facility Solutions Ltd

Electric Works
3 Concourse Way
Sheffield
S1 2BJ

[phone]
[e-mail]
intelligenthanddryers.com
