Intel® Solid-State Drive 330 Series
Product Specification
Capacity: 60/120/180/240 GB
Components:
—Intel
®
25nm NAND Flash Memory
— Multi-Level Cell (MLC)
Form Factor: 2.5-inch
Thickness: 9.5 mm
Weight: Up to 80 grams
SATA 6Gb/s Bandwidth Performance
(Iometer* Queue Depth 32)
— Sustained Sequential Read: 500 MB/s
— S ustained Sequential Write:450 MB/s
Read and Write IOPS
1
(Iometer Queue Depth 32)
— Random 4 KB Reads: 42,000 IOPS
— Random 4 KB Writes: 52,000 IOPS
Compatibility
—Intel
—Intel
—Intel
—Intel
®
SSD T oolbo x with Intel® SSD Optimizer
®
Data Migration Software
®
Rapid Storage Technology
®
6 Series Express Chipsets
(with SATA 6Gb/s)
—SATA Revision 3.0
— ACS-2 (ATA/ATAPI Command Set 2)
— Limited SMART ATA feature set
— Native Command Queuing (NCQ)
command set
— Data Set Management Command
Trim attribute
1
Power Management
— 5 V SATA Supply Rail
— SATA Link Power Management (LPM)
Power
— Act ive (MobileMark* 2007 Workload):
850 mW (TYP)
— Idle: 600 mW (TYP)
Temperature
—Operating: 0
— Non-Operating: -55
Certifications and Declarations:
o
C to 70o C
o
C to 95o C
—UL*
—CE*
—C-Tick*
—BSMI*
—KCC*
—Microsoft* WHQL
— VCCI*
—SATA-IO*
Product Ecological Compliance
—RoHS*
1. Performance values vary by capacity. See “Performance” on page 6 for details.
Order Number: 327030-002US
July 2012
L
Ordering Information
Contact your local Intel sales representative for ordering information.
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR
OTHERWISE, TO ANY INTELLEC TUAL PRO PER TY RIGHTS IS GRANT ED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS
OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING
TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE,
MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
A "Mission Critical Application" is any application in which failure of the Intel Product could result, direct ly or indirectly, in personal injury or death.
SHOULD YOU PURCHASE OR USE INTEL'S PRODUCTS FOR ANY SUCH MISSION CRITICAL APPLICATION, YOU SHALL INDEMNIFY AND HOLD INTEL AND
ITS SUBSIDIARIES, SUBCONTRACTORS AND AFFILIATES, AND THE DIRECTORS, OFFICERS, AND EMPLOYEES OF EACH, HARMLESS AGAINST ALL
CLAIMS COSTS, DAMAGES, AND EXPENSES AND REASONABLE ATTORNEYS' FEES ARISING OUT OF, DIRECTL Y OR INDIRECTL Y, ANY CLAIM OF PRODUCT
LIABILITY, PERSONAL INJURY, OR DEATH ARISING IN ANY WAY OUT OF SUCH MISSION CRITICAL APPLICATION, WHETHER OR NOT INTEL OR ITS
SUBCONTRACTOR WAS NEGLIGENT IN THE DESIGN, MANUFACTURE, OR WARNING OF THE INTEL PRODUCT OR ANY OF ITS PARTS.
Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the absence or characteristics
of any features or instructions marked "reserved" or "undefined". Intel reserves these for future definition and shall have no responsibility whatsoever
for conflicts or incompatibilities arising from future changes to them. The information here is subject to change without notice. Do not finalize a design
with this information.
The products described in this document may contain design defects or errors known as errata which may cause the product to deviate from published
specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained by calling 1-800-548-
4725, or go to: http://www.intel.com/design/literature.htm
Intel and the Intel logo are trademarks of Intel Corporation in the U.S. and/or other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2012 Intel Corporation. Al l rights reserved.
Intel® Solid-State Drive 330 Series
Product Specification July 2012
2 Order Number: 327030-002US
Intel® Solid-State Drive 330 Series
Contents
1.0 Overview...................................................................................................................5
2.0 Product Specifications ...............................................................................................6
2.1 Capacity ............................................................................................................6
2.2 Performance....................................................................................................... 6
2.3 Electrical Characteristics.......................................................................................7
2.4 Environmental Conditions........................................... .. .. ............................ .. ........7
2.5 Product Regulatory Compliance.............................................................................8
2.6 Reliability...........................................................................................................8
3.0 Mechanical Information.............................................................................................9
4.0 Pin and Signal Descriptions .......................................................................................9
5.0 SMART Attributes ......................................................................................................9
6.0 Certifications and Declarations................................................................................11
7.0 References ..............................................................................................................11
8.0 Terms and Acronyms ...............................................................................................12
9.0 Revision History ......................................................................................................12
July 2012 Product Specification
Order Number: 327030-002US 3
Intel® Solid-State Drive 330 Series
Intel® Solid-State Drive 330 Series
®
Solid-State Drive 330 Series
Intel
Product Specification July 2012
4 Order Number: 327030-002US
Intel® Solid-State Drive 330 Series
1.0 Overview
This document describes the specifications and capabilities of the Intel® Solid-State
Drive 330 Series (Intel
®
SSD 330 Series)1.
The Intel SSD 330 Series delivers leading performance for Serial Advanced Technology
Attachment (SATA)-based computers in capacities of 60 GB, 120 GB, 180 GB and 240
GB.
By combining Intel
®
25nm NAND Flash Memory technology with SA TA 6Gb/s interface
support, the Intel SSD 330 Series delivers sequential read speeds of 500 MB/s and
sequential write speeds2 of 450 MB/s.
The industry-standard 2.5-inch form factor enables interchangeability with existing
hard disk drives (HDDs) and native SATA HDD drop-in replacement with the enhanced
performance, reliability, and ruggedness offered by an SSD.
As compared to standard SATA HDDs, the Intel SSD 330 Series offers these key
features:
• High I/O and throughput performance
• Increased system responsiveness
• High reliability
• Enhanced ruggedness
1. The Intel SSD 330 Series is not currently validated for data center usage.
2. Performance values vary by capacity. See “Performance” on page 6 for details.
July 2012 Product Specification
Order Number: 327030-002US 5
Intel® Solid-State Drive 330 Series
®
Intel
Intel® Solid-State Drive 330 Series
Solid-State Drive 330 Series
2.0 Product Specifications
2.1 Capacity
Table 1. User Addressable Sectors
Intel SSD 330 Series
60 GB 117,231,408
120 GB 234,441,648
180 GB 351,651,888
240 GB 468,862,128
Notes: 1 GB = 1,000,000,000 bytes; 1 sector = 512 bytes.
LBA count shown represents total user storage capacity and will remain the same throughout the life of the drive.
The total usable capacity of the SSD may be less than the total physical capacity because a small portion of the capacity is
used for NAND flash management and maintenance purposes.
(Total User Addressable Sectors in LBA Mode)
2.2 Performance
Table 2. Random Read/Write Input/Output Operations Per Second (IOPS)
Unformatted Capacity
Specification Unit
Random 4 KB Read
Random 4 KB Write
Notes: 1. Performance measured using Iometer* with Queue Depth 32. Measurements are performed on 8 GB of Logical Block
Address (LBA) range on a full SSD.
1
1
IOPS 12,000 22,500 42,000 42,000
IOPS 20,500 33,000 52,000 52,000
60 GB 120 GB 180 GB 240 GB
Intel SSD 330 Series
Table 3. Sequential Read and Write Bandwidth
Specification Unit
1
Sequential Read (SATA 6Gb/s)
Sequential Write
Notes: 1. Performance measured using Iometer with Queue Depth 32.
(SATA 6Gb/s)
MB/s 500 500 500 500
1
MB/s 400 450 450 450
60 GB 120 GB 180 GB 240 GB
Intel SSD 330 Series
®
Solid-State Drive 330 Series
Intel
Product Specification July 2012
6 Order Number: 327030-002US
Intel® Solid-State Drive 330 Series
2.3 Electrical Characteristics
Table 4. Operating Voltage and Power Consumption
Electrical Characteristics Value
Operating Voltage for 5 V (±5%)
Min
Max
Power Consumption (TYP)
Notes:
1. Active power measured during execution of MobileMark* 2007 with SATA Link Power Management (LPM) enabled.
2. Idle power defined as SSD at idle with SATA Link Power Management (LPM) enabled.
Active
Idle
1
2
4.75 V
5.25 V
850 mW
600 mW
2.4 Environmental Conditions
Table 5. Temperature, Shock, Vibration
Temperature Range
Case Temperature
Operating
Non-operating
Temperature Gradient
Operating
Non-operating
Humidity
Operating
Non-operating
Shock and Vibration Range
2
Shock
Operating
Non-operating
Vibration
Notes:
1. Temperature gradient measured without condensation.
2. Shock specifications assume the SSD is mounted securely with the input vibration applied to the drive-mounting screws.
3. Vibration specifications assume the SSD is mounted securely with the input vibration applied to the drive-mounting
3
Operating
Non-operating
Stimulus may be applied in the X, Y or Z axis. Shock specification is measured using Root Mean Squared (RMS) value.
screws. Stimulus may be applied in the X, Y or Z axis. Vibration specification is measured using Root Mean Squared (RMS)
value.
1
30 (TYP) oC/hr
30 (TYP)
1,500 G (Max) at 0.5 msec
1,500 G (Max) at 0.5 msec
2.17 G
RMS
3.13 G
RMS
o
0 – 70
C
o
-55 – 95
5 – 95 %
5 – 95 %
C
o
C/hr
(5-700 Hz) Max
(5-800 Hz) Max
July 2012 Product Specification
Order Number: 327030-002US 7
Intel® Solid-State Drive 330 Series
2.5 Product Regulatory Compliance
The Intel SSD 330 Series meets or exceeds the regulatory or certification requirements
in Table 6.
Table 6. Product Regulatory Compliance Standards
®
Intel
Intel® Solid-State Drive 330 Series
Solid-State Drive 330 Series
Title Description
TITLE 47-Telecommunication CHAPTER I— FEDERAL
COMMUNICATIONS COMMISSION PAR T 15 — RADIO
FREQUENCY DEVICES
ICES-003, Issue 4 Interference-Causing Equipment
Standard Digital Apparatus
IEC 555024 Information Technology Equipment —
Immunity characteristics — Limits and methods of
measurement CISPR 24:2010
EN-55022 Information technology equipment —
Radio disturbance characteristics — Limits and
methods of measurement CISPR 22:2008 (Modified)
EN-60950-1 2nd Edition
UL/CSA 60950-1 2nd Edition
FCC Part 15B Class B
CAN/CSA-CEI/IEC CISPR 22:02. This is CISPR
22:1997 with Canadian modifications.
EN-55024: 1998 and its amendments European Union
EN-55022: 2006 and its amendments European Union
Information Technology Equipment — Safety —
Part 1: General Requirements
Information Technology Equipment — Safety —
Part 1: General Requirements
2.6 Reliability
The Intel SSD 330 Series meets or exceeds SSD endurance and data retention
requirements as specified in the JESD218 specification. Reliability specifications are
listed in Table 7.
Table 7. Reliability Specifications
Parameter Value
Uncorrectable Bit Error Rate (UBER)
Uncorrectable bit error rate will not exceed one sector in the
specified number of bits read. In the unlikely event of a
nonrecoverable read error, the SSD will report it as a read failure to
the host; the sector in error is considered corrupt and is not
returned to the host.
Mean Time Between Failures (MTBF)
Mean Time Between Failures is estimated based on Telcordia*
methodology and demonstrated through Reliability Demonstration
Test (RDT).
Minimum Useful Life/Endurance Rating
The SSD will have a minimum of three years of useful life under
typical client workloads with up to 20 GB of host writes per day.
Insertion Cycles
The SSD supports up to 250 insertion/removal cycles on SATA/
power cable.
< 1 sector per 10
1,200,000 hours
3 years
250 insertion/removal cycles
Region For Which
Conformity Declared
USA
Canada
USA/Canada
USA/Canada
16
bits read
®
Solid-State Drive 330 Series
Intel
Product Specification July 2012
8 Order Number: 327030-002US
Intel® Solid-State Drive 330 Series
3.0 Mechanical Information
The Intel SSD 330 Series meets the SFF-8201 specification for 9.5mm 2.5-inch drive
form factor and SFF-8223 specification for 2.5-inch Drive w/Serial Attachment
Connector.
4.0 Pin and Signal Descriptions
See the Serial ATA (SATA) Revision 3.0 specification for pin and signal descriptions.
5.0 SMART Attributes
Table 8 lists the limited SMART attributes supported by the Intel SSD 330 Series.
Table 8. SMART Attributes
ID Attribute
Re-allocated Sector Count
05h
09h
0Ch
C0h
E1h
The raw value of this attribute shows the
number of retired blocks since leaving the
factory (grown defect count).
Power-On Hours Count
The raw value reports two values: the first
4 bytes report the cumulative number of
power-on hours over the life of the device,
the remaining bytes report the number of
milliseconds since the last hour increment.
The On/Off status of the Device Initiated
Power Management (DIPM) feature will
affect the number of hours reported. If DIPM
is turned On, the recorded value for
power-on hours does not include the time
that the device is in a "slumber" state. If
DIPM is turned Off, the recorded value for
power-on hours should match the clock
time, as all three device states are counted:
active, idle and slumber.
Power Cycle Count
The raw value of this attribute reports the
cumulative number of power cycle events
over the life of the device.
Power-Off Retract Count (Unsafe Shutdown
Count)
The raw value of this attribute reports the
cumulative number of unsafe (unclean)
shutdown events over the life of the device.
An unsafe shutdown occurs whenever the
device is powered off without STANDBY
IMMEDIATE being the last command.
Host Writes
The raw value of this attribute reports the
total number of sectors written by the host
system. The raw value is increased by 1 for
every 65,536 sectors (32MB) written by
the host.
Status Flags
SP EC ER PE OC PW
110010 0 (none)
110010 0 (none)
110010 0 (none)
110010 0 (none)
110010 0 (none)
Threshold
July 2012 Product Specification
Order Number: 327030-002US 9
Intel® Solid-State Drive 330 Series
Table 8. SMART Attributes (Continued)
®
Intel
Intel® Solid-State Drive 330 Series
Solid-State Drive 330 Series
ID Attribute
Available Reserved Space
This attribute reports the number of reserve
E8h
blocks remaining. The normalized value
begins at 100 (64h), which corresponds to
100 percent availability of the reserved
space. The threshold value for this attribute
is 10 percent availability.
Media Wearout Indicator
This attribute reports the number of cycles
the NAND media has undergone. The
normalized value declines linearly from 100
E9h
to 1 as the average erase cycle count
increases from 0 to the maximum rated
cycles.
Once the normalized value reaches 1, the
number will not decrease, although it is likely
that significant additional wear can be put
on the device.
Total LBAs Written
The raw value of this attribute reports the
F1h
total number of sectors written by the host
system. The raw value is increased by 1 for
every 65,536 sectors (32MB) written by
the host.
Total LBAs Read
The raw value of this attribute reports the
F2h
total number of sectors read by the host
system. The raw value is increased by 1 for
every 65,536 sectors (32MB) read by
the host.
Total NAND Writes
F9h
Raw value reports the number of writes to
NAND in 1 GB increments.
Status Flags
SP EC ER PE OC PW
Threshold
110011 10
110010 0 (none)
110010 0 (none)
110010 0 (none)
110010 0 (none)
®
Solid-State Drive 330 Series
Intel
Product Specification July 2012
10 Order Number: 327030-002US
Intel® Solid-State Drive 330 Series
6.0 Certifications and Declarations
Table 9 describes the Device Certifications supported by the Intel SSD 330 Series.
Table 9. Device Certifications and Declarations
Certification Description
CE Compliant
UL Recognized
C-Tick Compliant
BSMI Compliant
KCC
VCCI
RoHS Compliant Restriction of Hazardous Substance Directive
WEEE Directive on Waste Electrical and Electronic Equipment
Low Voltage DIRECTIVE 2006/95/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL
of 12 December 2006, and EMC Directive 2004/108/EC OF THE EUROPEAN PARLIAMENT AND OF
THE COUNCIL of 15 December 2004.
Underwriters Laboratories, Inc. Bi-National Component Recognition; UL 60950-1, 2nd Edition,
2007-03-27 (Information Technology Equipment - Safety - Part 1: General Requirements)
CSA C22.2 No. 60950-1-07, 2nd Edition, 2007-03 (Information Technology Equipment - Safety -
Part 1: General Requirements)
Compliance with the Australia/New Zealand Standard AS/NZS3548 and Electromagnetic
Compatibility (EMC) Framework requirements of the Australian Communication Authority (ACA).
Compliance to the Taiwan EMC standard CNS 13438: Information technology equipment - Radio
disturbance Characteristics - limits and methods of measurement, as amended on June 1, 2006, is
harmonized with CISPR 22: 2005.04.
Compliance with paragraph 1 of Article 11 of the Electromagnetic Compatibility Control Regulation
and meets the Electromagnetic Compatibility (EMC) Framework requirements of the Radio Research
Laboratory (RRL) Ministry of Information and Communication Republic of Korea.
Voluntary Control Council for Interface to cope with disturbance problems caused by personal
computers or facsimile.
7.0 References
Table 10 identifies the standards information referenced in this document.
Table 10. Standards References
Date Title Location
Sept 2010
Dec 2008 VCCI http://www.vcci.jp/vcci_e/
June 2009 RoHS
August 2009 ACS-2-ATA/ATAPI Command Set 2 Specification http://www.t13.org/
June 2009 Serial ATA Revision 3.0 http://www.sata-io.org/
May 2006 SFF-8223, 2.5-inch Drive w/Serial Attachment Connector http://www.sffcommittee.org/
May 2005 SFF-8201, 2.5-inch drive form factor http://www.sffcommittee.org/
Solid-State Drive (SSD) Requi rements and Endura nce Test Method
(JESD218)
Compliance with EN 55022:1998 Information technology
equipment - Radio disturbance characteristics - Limits and
methods of measurement CISPR 22:1997 (Modified)
http://www.jedec.org/standardsdocuments/docs/jesd218/
http://qdms.intel.com/
Click Search MDDS Database and search
for material description datasheet
http://www.iec.ch/
8.0 Terms and Acronyms
Table 11 defines the terms and acronyms used in this document.
July 2012 Product Specification
Order Number: 327030-002US 11
Intel® Solid-State Drive 330 Series
Table 11. Glossary of Terms and Acronyms
Term Definition
ATA Advanced Technology Attachment
DIPM Device Initiated Power Management
GB
HDD Hard Disk Drive
HIPM Host Initiated Power Management
I/O Input/Output
IOPS Input/Output Operations Per Second
KB Kilobyte (1,024 bytes)
LBA Logical Block Address
LPM Link Power Management
MB Megabyte
MLC Multi-level Cell
MTBF Mean Time Between Failures
NCQ Native Command Queuing
NOP No Operation
RDT Reliability Demonstration Test
RMS Root Mean Squared
SATA Serial Advanced Technology Attachment
SMART Self-Monitoring, Analysis and Reporting Technology
SSD Solid-State Drive
TYP Typical
UBER Uncorrectable Bit Error Rate
Gigabyte
Note: The total usable capacity of the SSD may be less than the total physical capacity because a
small portion of the capacity is used for NAND flash management and maintenance purposes.
®
Intel
Intel® Solid-State Drive 330 Series
Solid-State Drive 330 Series
9.0 Revision History
Date Revision Description
April 2012 001 Initial release.
July 2012 002 Added information for new 240 GB capacity
®
Solid-State Drive 330 Series
Intel
Product Specification July 2012
12 Order Number: 327030-002US
Loading...
