Intel® Solid State Drive DC S3520 Series
Product Specification
Capacity:
2.5”: 240GB, 480GB, 800GB, 960GB,
1.2TB, 1.6TB
M.2: 240GB, 480GB, 760GB, 960GB
Components:
− 3D MLC NAND Flash Memory
− Standard Endurance Technology (SET)
Form Factor: 2.5–inch, M.2
Read and Write IOPS
1,2
(Full LBA Range, IOMeter* Queue Depth 32)
− Random 4KB
− Random 4KB Writes: Up to 17,500 IOPS
− Random 8KB
− Random 8KB Writes: Up to 9,500 IOPS
Bandwidth Performance
− Sustained Sequential Read: Up to 450 MB/s
− Sustained Sequential Write: Up to 380 MB/s
Endurance:
− Up to 2925 TBW (Terabytes Written)
− Up to 1 drive writes per day
− Up to 1.6 drive writes per day
Latency (average sequential)
− Read: 2.5” - 40 µs (TYP); M.2 – 46 µs (TYP)
− Write: 2.5” - 42 µs (TYP); M.2 – 50 µs (TYP)
Quality of Service
− Read/Write: 2.5” - 3 ms / <1.5 ms (99.9%);
M. 2 - TBD
Performance Consistency
− Read/Write: Up to 98%/85% (99.9%)
Self-Encrypting Drive (SED)
− AES 256-bit encryption
Altitude
− Operating: -1,000 to 10,000 ft
− Operating
− Non-operating: -1,000 to 40,000 ft
Product Ecological Compliance
− RoHS*
Compliance
− SATA Revision 3.2; compatible with SATA 6Gb/s,
3Gb/s and 1.5Gb/s interface rates
− ATA/ATAPI Command Set – 3 (ACS-3 Rev 5);
includes SCT (Smart Command Transport)
and device statistics log support
− Enhanced SMART ATA feature set
− Native Command Queuing (NCQ) command set
− Data set management Trim command
1. Performance values vary by capacity
2. Performance specifications apply to both compressible and incompressible data
3. 4KB = 4,096 bytes; 8KB = 8,192 bytes.
4.
MB/s = 1,000,000 bytes/second
5. Based on JESD218 standard.
6. Based on Random 4KB QD=1 workload, measured as the time taken for 99.9 percent ile of co mmands to finish the round-tr ip from host to drive and back to host
7. Based on Random 4KB QD=32 workload, me asured as the (IOPS in the 99.9th percen tile slowest 1-second interval)/ (average IOPS dur ing the te st)
8. Measurement taken once the workload has reached steady state but including all background activities required for normal operation and data reliability
9. Altitude pressur e is simulated in a test chamber; excludes soft error
10. Exten ded operatio n at a higher altitude might impact rel iability.
11. If both 12V and 5V power supplies are present, defaults to 5V+ 12V power supplies. Does not support 12 volt only.
12. Based on 5Vpower supply
13. Please contact your Intel representative for details on the non-operating temperature range
3
Reads: Up to 67,500 IOPS
3
Reads: Up to 45,000 IOPS
6,8
9
10
: 10,000 to 15,000 ft
1
5
for 5 years
5
7,8
for 3 years
4
Power Management
− 2.5” - 5V or 5V+12V SATA Supply Rail
11
− M.2 – 3.3V only
− SATA Interface Power Management
− OS-aware hot plug/removal
− Enhanced power-loss data protection feature
Power
12
− Active: Up to 3.5 W
8
(TYP)
− Idle: 2.5” - 600 mW; M.2 – 700 mW
Weight:
2.5”
− 240GB, 480GB: 62 grams ± 2 grams
− 800GB: 63 grams ± 2 grams
− 960GB, 1.2TB, 1.6TB: 66 grams ± 2 grams
M.2
− 240GB, 480GB, 760GB, 960GB: 9 grams ± 1 gram
Temperature
− Operating: 0°
− Non-Operating
− Temperature monitoring and logging
− Thermal throttling when approaching maximum operating
temperature
Shock (operating and non-operating):
1,000 G / 0.5 ms
Vibration
− Operating: 2.17 G
− Non-Operating
Reliability
− Uncorrectable Bit Error Rate (UBER):
1 sector per 10
− Mean Time Between Failures (MTBF): 2 million hours
− End-to-End data protection
Certifications and Declarations
− UL*, CE*, C-Tick*, BSMI*, KCC*, Microsoft* WHCK, VCCI*,
SATA-IO*
Compatibility
− Windows 8*, Windows 8.1*, Windows 10*
− Windows Server 2012*, 2012 R2*
− Windows Server 2008* Enterprise 32/64bit SP2
− Windows Server 2008* R2
− VMWare* 5.1, 5.5
− Red Hat* Enterprise Linux* 6.3, 6.5, 7.0
− SUSE* Linux* Enterprise Server 11 SP1, SP3
− CentOS* 64bit 6.3, 6.5
− VMWare* 6.0, 6.5
− Intel® SSD Toolbox with Intel® SSD Optimizer
C to 70° C
13
: -55° C to 95° C
(5-700 Hz)
RMS
: 3.13 G
RMS
^17
bits read
(5-800 Hz)
Intel Confidential Order Number: 334826-001US
Revision
Description
Date
Intel® Solid State Drive DC S3520 Series
Ordering Information
Contact your local Intel sales representative for ordering information.
Revision History
001 Initial release August 2016
Related Document
Document Name Date
Intel® SSD DC S3520 Series 150GB Product Specification August 2016
Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the absence or
characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for future definition and shall have no
responsibility whatsoever for conflicts or incompatibilities arising from future changes to them. The information here is subject to change without
notice. Do not finalize a design with this information.
Tests document performance of components on a particular test, in specific systems. Differences in hardware, software, or configuration will affect
actual performance. Consult other sources of information to evaluate performance as you consider your purchase.
System Configuration for all performance testing: Intel® Xeon® CPU E5-2699v3 @ 2.30GHz on Intel® S2600WT2 motherboard, Intel® C612 Chipset
(Intel® DH82029 PCH), BIOS Version SE5C610.86B.01.01.0014.121820151719 32GB DDR4, CentOS* 7, Kernel 4.3.3, FIO* 2.8, Intel® SSD DC S3520
FW N2010018
All documented endurance test results are obtained in compliance with JESD218 Standards; refer to individual sub-sections within this document for
specific methodologies. See www.jedec.org
The products described in this document may contain design defects or errors known as errata which may cause the product to deviate from published
specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Intel and the Intel logo are trademarks of Intel Corporation in the U.S. and other countries.
*Other names and brands may be claimed as the property of others.
Copyright © 2016 Intel Corporation. All rights reserved.
for detailed definitions of JESD218 Standards.
August 2016 Product Specification
334826-001US Intel Confidential 2
