Intel® Solid State Drive 750 Series
Capacities
400GB, 800GB, 1.2TB PCIe® Gen3 x4
Form Factor
2.5-inch Form Factor
15mm Z-height
U.2-compatible connector
Add-in Card (AIC) Form Factor
Half-height, Half-length
Single slot x4 connector
Performance1,2
Seq R/W: Up to 2500/1200 MB/s3
4K Random Read: Up to 460K
4K Random Write: Up to 290K
Latency (average sequential)
Read: 20 µs (TYP)
Write: 20 µs (TYP)
Components
Intel® 20nm MLC NAND Flash Memory Operating System Support:
Windows 7* 64 bit
Windows 8* 64 bit
Windows 8.1* 64 bit
Windows 10* 64 bit
Ubuntu 14.05 and 15.05
UEFI* 2.3.1 or later
Reliability
Uncorrectable Bit Error Rate (UBER): 1 sector per 1016 bits read
Mean Time Before Failure (MTBF): 1.2 million hours
Power
2.5-inch: 12V Supply Rail
AIC: 3.3V and 12V Supply Rail
Enhanced power-loss data protection
Active/Idle (TYP): 22W/4W (TYP)
Product Specification
Compliance
NVM ExpressTM 1.0
PCI Express® Base Specification Rev 3.0
SFF 8639 Enterprise SSD Form Factor Version 1.0a
PCI Express Card Electro-Mechanical* (CEM) Specification Rev 2.0
Certifications and Declarations
UL*, CE*, C-Tick*, BSMI*, KCC*, Microsoft WHQL*, VCCI*
Endurance Rating
70 GB Writes Per Day
Up to 127 TBW (Terabytes Written)5
Temperature Specification
Operating:
AIC: 0 to 55° C
2.5-inch: 0 to 70° C
Non-Operating6: -55 to 95° C
Temperature monitoring
Weight
AIC: up to 195 gm
2.5-inch: up to 125 gm
Shock
2.5-inch: 1,000 G/0.5msec
AIC: 50 G Trapezoidal, 170 in/s
Vibration
Operating: 2.17 GRMS (5-700Hz)
Non-Operating: 3.13 GRMS (5-800Hz)
Altitude (Simulated)
Operating: -1,000 to 10,000 ft
Non-Operating: -1,000 to 40,000 ft
Product Ecological Compliance
RoHS
1.Performance values vary by capacity and form factor
2.Performance specifications apply to both compressible and incompressible data
3.MB/s = 1,000,000 bytes/second
4.4KB = 4,096 bytes; 8 KB = 8,192 bytes
5.1PB = 1015 Bytes
6.Please contact your Intel representative for details on the non-operating temperature range
Order Number: 332059-004US
Intel® Solid State Drive 750 Series
Revision History
Revision |
Description |
Revision Date |
|
Number |
|||
|
|
||
|
|
|
|
001 |
Initial release |
April 2015 |
|
|
|
|
|
002 |
TBW Endurance Value Correction |
June 2015 |
|
Minor Documentation edit in SMART Attributes Table 14 |
|||
|
|
||
|
|
|
|
|
Amended with 800GB SKU information |
|
|
003 |
Updated Performance numbers |
August 2015 |
|
|
Included Ubuntu OS support |
|
|
|
|
|
|
004 |
Removed 3.3v from 2.5 FF |
October 2015 |
|
Added Windows 10 support |
|||
|
|
||
|
|
|
Ordering Information
Contact your local Intel sales representative for ordering information.
Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them. The information here is subject to change without notice. Do not finalize a design with this information.
Tests document performance of components on a particular test, in specific systems. Differences in hardware, software, or configuration will affect actual performance. Consult other sources of information to evaluate performance as you consider your purchase.
Test and System Configuration: Processor: Intel® Core™ i7-4790K, Speed: 4.0 GHz, Chipset: Intel® Z97, Motherboard: ASUS* z97-Deluxe, DRAM capacity: 4GB, DRAM Speed: DDR3 2133 MHz, OS: Windows* 8.1.
For more complete information about performance and benchmark results, visit http://www.intel.com/performance.
All documented endurance test results are obtained in compliance with JESD218 Standards; refer to individual sub-sections within this document for specific methodologies. See www.jedec.org for detailed definitions of JESD218 Standards.
The products described in this document may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order. This document contains information on products in the design phase of development.
Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained by calling 1-800-548-4725, or go to: http://www.intel.com/design/literature.htm
Intel and the Intel logo are trademarks of Intel Corporation in the U.S. and other countries.
*Other names and brands may be claimed as the property of others. Copyright © 2015 Intel Corporation. All rights reserved.
Product Specification |
October 2015 |
2 |
332059-004US |
Intel® Solid State Drive 750 Series
Contents
|
Revision History..................................................................................................................................................................................................... |
2 |
||
|
Ordering Information.......................................................................................................................................................................................... |
2 |
||
1 |
Overview |
............................................................................................................................................................................................................... |
5 |
|
|
1.1 |
References ................................................................................................................................................................................................. |
6 |
|
|
1.2 |
Terms and Acronyms............................................................................................................................................................................ |
7 |
|
2 |
Product Specifications ....................................................................................................................................................................................... |
8 |
||
|
2.1 |
Capacity ...................................................................................................................................................................................................... |
8 |
|
|
2.2 |
Performance ............................................................................................................................................................................................. |
8 |
|
|
2.3 |
Electrical Characteristics..................................................................................................................................................................... |
9 |
|
|
2.4 |
Environmental Conditions .............................................................................................................................................................. |
10 |
|
|
2.5 |
Product Regulatory Compliance .................................................................................................................................................. |
11 |
|
|
2.6 |
Reliability Specifications .................................................................................................................................................................. |
11 |
|
3 |
Mechanical Information.................................................................................................................................................................................. |
12 |
||
4 |
Pin and Signal Descriptions.......................................................................................................................................................................... |
14 |
||
|
4.1 |
2.5-inch Form Factor Pin Locations............................................................................................................................................ |
14 |
|
|
4.2 |
Pin Signal Definitions......................................................................................................................................................................... |
14 |
|
5 |
Supported Command Sets............................................................................................................................................................................ |
17 |
||
|
5.1 |
NVMe Admin Command Set........................................................................................................................................................... |
17 |
|
|
5.2 |
NVMe I/O Command Set.................................................................................................................................................................. |
17 |
|
|
5.3 |
Log Page Support................................................................................................................................................................................ |
18 |
|
|
5.4 |
SMART Attributes................................................................................................................................................................................ |
18 |
|
|
5.5 |
Temperature Statistics...................................................................................................................................................................... |
21 |
|
|
5.6 |
SET Feature Identifiers...................................................................................................................................................................... |
21 |
|
6 |
NVMe Driver Support ...................................................................................................................................................................................... |
23 |
||
7 |
Certifications and Declarations................................................................................................................................................................... |
24 |
||
Appendix A |
IDENTIFY Data Structure ........................................................................................................................................................ |
25 |
||
Appendix B |
PCIe ID............................................................................................................................................................................................. |
31 |
||
Appendix C |
SCSI Command Translation .................................................................................................................................................. |
32 |
||
Appendix D Add-in Card LED Decoder...................................................................................................................................................... |
33 |
October 2015 |
Product Specification |
332059-004US |
3 |
Intel® Solid State Drive 750 Series
Figures
Figure 3-1 |
Intel SSD 750 Series SFF Dimensions ...................................................................................................................... |
12 |
Figure 4-1 |
2.5-inch Form Factor Pin Locations........................................................................................................................... |
14 |
Figure A-1 |
LED Location......................................................................................................................................................................... |
33 |
Tables
Table 1: |
Standard Information Referenced in this Document ........................................................................................... |
6 |
Table 2: |
Glossary of Terms and Acronyms.................................................................................................................................. |
7 |
Table 3: |
User Addressable Sectors................................................................................................................................................. |
8 |
Table 4: |
Performance............................................................................................................................................................................ |
8 |
Table 5: |
Latency....................................................................................................................................................................................... |
9 |
Table 6: |
Operating Voltage................................................................................................................................................................. |
9 |
Table 7: |
Power Consumption ......................................................................................................................................................... |
10 |
Table 8: |
Temperature, Shock, Vibration.................................................................................................................................... |
10 |
Table 9: |
Product Regulatory Compliance Specifications................................................................................................... |
11 |
Table 10: |
Reliability Specifications................................................................................................................................................. |
11 |
Table 11: |
Pin Definition for 2.5-inch Form Factor (U.2 connector specification)...................................................... |
14 |
Table 12: |
Pin Definition for Add-In Card (Half Height Half Length) Form Factor...................................................... |
16 |
Table 13: |
SMART Attributes (Log Identifier 02h) ..................................................................................................................... |
18 |
Table 14: |
Additional SMART Attributes (Log Identifier CAh).............................................................................................. |
20 |
Table 15: |
Temperature Statistics (Log Identifier C5h)........................................................................................................... |
21 |
Table 16: |
Set Max LBA Setting - Command Dword 11 and Command Dword 12.................................................... |
22 |
Table 17: |
Status Code - Set Max LBA Command Specific Status Values...................................................................... |
22 |
Table 18: |
D5h - Reset Timed Workload Counters - Command Dword 11................................................................... |
22 |
Table 19: |
NVMe Driver Support ....................................................................................................................................................... |
23 |
Table 20: |
Device Certifications and Declarations .................................................................................................................... |
24 |
Table 21: |
Identify Controller.............................................................................................................................................................. |
25 |
Table 22: |
Power State Descriptor.................................................................................................................................................... |
28 |
Table 23: |
Identify Namespace........................................................................................................................................................... |
29 |
Table 24: |
LBA Format Data Structure............................................................................................................................................ |
30 |
Table 25: |
PCIe ID ..................................................................................................................................................................................... |
31 |
Table 26: |
LED Functionality ............................................................................................................................................................... |
33 |
§
Product Specification |
October 2015 |
4 |
332059-004US |
Intel® Solid State Drive 750 Series
1 Overview
This document describes the specifications and capabilities of the Intel® Solid State Drive 750 Series (Intel® SSD 750 Series).
The Intel SSD 750 Series is Intel’s first PCIe® Gen3 x4 SSD developed for the client enthusiast and workstation markets. The Intel SSD 750 Series is architected with the new high performance controller interface - Non-Volatile Memory Express™ (NVMe™) - delivering outstanding performance, low latency and Quality of Service. NVMe is a standardized interface that enables higher performance and lower latency than previous generations. The Intel SSD 750 Series offers capacities of 400GB, 800GB, and 1.2TB in Add-In card and 2.5-inch U.2 (formerly known as SFF-8639) form factors.
The Intel SSD 750 Series is Intel’s highest performing client drive specifically designed for the PC enthusiast and workstation systems with demanding storage workstation requirements. With PCIe Gen3 x4 support and NVMe queuing interface, the Intel SSD 750 Series delivers excellent sequential read performance of up to 2.5GB/s and sequential write speeds of up to 1.2 GB/s. The Intel SSD 750 Series delivers random read IOPS of up to 460K and random write IOPS of up to 290K for 4KB operations. Also, by taking advantage of the direct path from the storage to the CPU by means of NVMe, the Intel SSD 750 Series exhibits low latency of less than 20 μs for sequential access to the SSD.
Intel SSD 750 Series includes these key features:
PCIe Gen3 x4 with NVMe interface
Consistently Higher IOPS and throughput
Sustained low latency
Enhanced power-loss data protection
October 2015 |
Product Specification |
332059-004US |
5 |
Intel® Solid State Drive 750 Series
1.1References
Table 1: Standard Information Referenced in this Document
Date |
|
Title |
Location |
|
|
|
|
||
Jan 2013 |
SFF 8639 Enterprise SSD Form Factor Version 1.0a |
http://www.ssdformfactor.org |
||
|
|
|
||
Feb 2012 |
NVMe Revision 1.0c |
http://www.nvmexpress.org |
||
|
|
|
||
Nov 2010 |
PCIe Base Specification Revision 3.0 |
http://pcisig.com |
||
|
|
|
||
July 2012 |
Solid State Drive (SSD) Requirements and Endurance Test Method |
http://www.jedec.org/standards- |
||
(JESD219) |
documents/results/jesd219 |
|||
|
||||
|
|
|
||
Sept 2010 |
Solid State Drive (SSD) Requirements and Endurance Test Method |
http://www.jedec.org/standards- |
||
(JESD218) |
documents/docs/jesd218/ |
|||
|
||||
|
|
|
|
|
Dec 2008 |
VCCI |
|
http://www.vcci.jp/vcci_e/ |
|
|
|
|
|
|
|
|
|
http://qdms.intel.com/ |
|
June 2009 |
RoHS |
Click Search MDDS Database and |
||
search for material description |
||||
|
|
|
||
|
|
|
datasheet |
|
|
|
|
||
|
International Electrotechnical Commission EN 61000 |
|
||
1995 |
4-2 (Electrostatic discharge immunity test) |
|
||
1996 |
4-3 (Radiated, radio-frequency, electromagnetic field immunity test) |
|
||
1995 |
4-4 |
(Electrical fast transient/burst immunity test) |
|
|
|
|
|
http://www.iec.ch/ |
|
1995 |
4-5 |
(Surge immunity test) |
|
|
1997 |
4-6 |
(Immunity to conducted disturbances, induced by radio- |
|
|
|
|
frequency fields) |
|
|
1994 |
4-11 (Voltage Variations, voltage dips, short interruptions and voltage |
|
||
|
|
variations immunity tests) |
|
|
|
|
|
||
1995 |
ENV 50204 |
http://www.dbicorporation.com/ |
||
|
(Radiated electromagnetic field from digital radio telephones) |
radimmun.htm/ |
||
|
|
|
|
Product Specification |
October 2015 |
6 |
332059-004US |
Intel® Solid State Drive 750 Series
1.2Terms and Acronyms
Table 2: Glossary of Terms and Acronyms
Term |
Definition |
|
|
ATA |
Advanced Technology Attachment |
|
|
CRC |
Cyclic Redundancy Check |
|
|
DAS |
Device Activity Signal |
|
|
DMA |
Direct Memory Access |
|
|
ECC |
Error Correction Code |
|
|
EEPROM |
Electrically Erasable Programmable Read Only Memory |
EXT |
Extended |
FPDMA |
First Party Direct Memory Access |
|
Gigabyte |
GB |
Note: The total usable capacity of the SSD may be less than the total physical capacity because a |
|
small portion of the capacity is used for NAND flash management and maintenance purposes. |
|
|
Gb |
Gigabit |
|
|
HDD |
Hard Disk Drive |
HET |
High Endurance Technology |
KB |
Kilobyte |
I/O |
Input/Output |
IOPS |
Input/Output Operations Per Second |
ISO |
International Standards Organization |
LBA |
Logical Block Address |
MB |
Megabyte (1,000,000 bytes) |
|
|
MLC |
Multi-level Cell |
MTBF |
Mean Time Between Failures |
|
|
NOP |
No Operation |
|
|
NVMe |
Non-Volatile Memory Express |
|
|
PB |
Petabyte |
|
|
PCB |
Printed Circuit Board |
|
|
RDT |
Reliability Demonstration Test |
|
|
RMS |
Root Mean Square |
|
|
SSD |
Solid State Drive |
|
|
TB |
Terabyte |
|
|
TYP |
Typical |
|
|
UBER |
Uncorrectable Bit Error Rate |
|
|
VPD |
Vital Product Data |
|
|
§
October 2015 |
Product Specification |
332059-004US |
7 |
Intel® Solid State Drive 750 Series
2 Product Specifications
2.1 Capacity
Table 3: User Addressable Sectors
Intel SSD 750 Series |
Unformatted Capacity |
|
(Total User Addressable Sectors in LBA Mode) |
||
|
||
|
|
|
400GB |
781,422,768 |
|
|
|
|
800GB |
1,562,824,368 |
|
|
|
|
1.2TB |
2,344,225,968 |
|
|
|
NOTES:
1 GB = 1,000,000,000 bytes; 1 sector = 512 bytes
LBA count shown represents total user storage capacity and will remain the same throughout the life of the drive. The total usable capacity of the SSD may be less than the total physical capacity because a small portion
of the capacity is used for NAND media management and maintenance. IDEMA or JEDEC standard is used.
2.2Performance
Table 4: Performance1
|
|
|
Intel SSD 750 Series |
|
|
Specification1 |
Unit |
|
|
|
|
400GB |
800GB5 |
1.2TB |
|||
|
|
||||
|
|
|
|
|
|
Random 4KB2 Read (up to) |
IOPS |
430,000 |
420,000 |
460,000 |
|
|
|
|
|
|
|
Random 4KB Write (up to) |
IOPS |
230,000 |
210,000 |
290,000 |
|
|
|
|
|
|
|
Sequential 128KB Read3 |
MB/s4 |
2,200 |
2,100 |
2,500 |
|
|
|
|
|
|
|
Sequential 128KB Write |
MB/s |
900 |
800 |
1,200 |
|
|
|
|
|
|
NOTES:
1.Performance measured by Intel using IOMeter* on Intel provided NVMe driver with Queue Depth 128 (QD=32, workers=4). Measurements are performed on a contiguous 8GB span of the drive on a full SSD. Power mode set at 25W. Drive is unpartitioned.
2.4KB = 4,096 bytes
3.Performance measured by Intel using IOMeter* with 128 KB (131,072 bytes) of transfer size with Queue Depth 128. Power mode set at 25W.
4.MB/s = 1,000,000 bytes/second
5.Performance due to nonoptimal NAND layout
Product Specification |
October 2015 |
8 |
332059-004US |
Intel® Solid State Drive 750 Series
Table 5: |
Latency |
|
|
|
|
|
|
|
|
|
|
|
Intel SSD 750 Series |
|
|
Specification |
|
|
|
|
Sequential |
|
Random |
|
|
|
|
||
|
|
|
|
|
Read1 |
|
20 µs (TYP) |
|
120 µs (TYP) |
Write1 |
|
20 µs (TYP) |
|
45 µs (TYP) |
Typical Power On to First I/O |
|
Up to 10 seconds |
||
Completion2 |
|
|||
|
|
|
||
Typical Reset to First I/O |
|
Up to 15 seconds |
||
Completion3 |
|
|||
|
|
|
NOTES:
1.Device measured by Intel using IOMeter*. Latency measured using 4 KB (4,096 bytes) transfer size with Queue Depth equal to 1 using Windows 8.1 driver. Power mode set at 25W.
2.Assumes clean shutdown. Time to complete first I/O from complete power off state.
3.Time to complete first I/O after start of NVMe Controller Reset.
2.3Electrical Characteristics
Table 6: Operating Voltage
Electrical Characteristics |
Intel SSD 750 Series |
|
|
|
|
3.3V Operating Characteristics: (Add-in Card only) |
|
|
Operating Voltage range |
3.3 V (±10%) |
|
|
||
Rise time (Max/Min) |
50ms/1ms |
|
|
||
Fall time (Max/Min) |
1 |
5s/1ms |
|
|
|
Noise level |
|
300 mV pp 10Hz – 100 KHz |
|
|
50 mV pp 100KHz – 20 MHz |
Min Off time2 |
|
500 ms |
Max Average Current |
3.0 A |
|
|
|
|
12V Operating Characteristics: |
|
|
Operating Voltage range |
12 V (+10%/-20%) |
|
|
||
Rise time (Max/Min) |
50ms/1ms |
|
|
||
Fall time (Max/Min) |
1 |
5s/1ms |
|
|
|
Noise level |
|
1000 mV pp 10Hz – 100 KHz |
|
|
100 mV pp 100KHz – 20 MHz |
Min Off time2 |
|
500 ms |
Max Average Current |
2.1 A |
|
|
|
|
NOTES:
1.Fall time needs to be equal or better than minimum in order to guarantee full functionality of enhanced power loss management. Intel makes no claims on the success rate of its power loss protection feature. The power loss feature does not provide 100 percent protection on all power loss scenarios.
2.The drive must be powered off for at least 500msec before powering on.
October 2015 |
Product Specification |
332059-004US |
9 |
|
|
|
Intel® Solid State Drive 750 Series |
||
Table 7: Power Consumption |
|
|
|
|
|
|
|
|
|
|
|
Specification |
Unit |
|
Intel SSD 750 Series |
|
|
|
|
|
|
|
|
|
|
400GB |
800GB |
1.2TB |
|
|
|
|
|
|
|
Active Write – Average1 |
W |
12 |
15 |
22 |
|
Active Read – Average2 |
W |
9 |
9 |
10 |
|
Idle |
W |
4 |
4 |
4 |
|
|
|
|
|
|
|
NOTES:
1.The workload equates 64KB (65,536 bytes) Queue Depth equal to 128 sequential writes. Average power is measured by Intel using scope trigger over a 100 ms sample period.
2.The workload equates 64KB (65,536 bytes) Queue Depth equal to 128 sequential reads.
2.4Environmental Conditions
Table 8: Temperature, Shock, Vibration
Temperature |
Add-In card form factor |
|
2.5-inch form factor |
||||
|
|
|
|
|
|
|
|
Temperature |
|
|
|
|
|
|
|
Operating1 |
o |
|
|
0–35 |
o |
C |
|
Non-operating2 |
0 – 55 C |
|
|
||||
-55–95 |
o |
C |
|
0-70 |
o |
C |
|
|
|
|
|
||||
|
|
|
|
||||
Temperature Gradient3 |
30o C/hr (Typical) |
|
30o C/hr (Typical) |
||||
Operating |
30o C/hr (Typical) |
|
30o C/hr (Typical) |
||||
Non-operating |
|
|
|
|
|
|
|
Humidity |
5–95% |
|
5–95% |
||||
Operating |
|
||||||
5–95% |
|
5–95% |
|||||
Non-operating |
|
||||||
|
|
|
|
|
|
|
|
Shock and Vibration |
|
|
|
Range |
|
|
|
|
|
|
|
|
|
|
|
Shock4 |
50 G Trapezoidal, 170 in/s |
|
1,000 G (Max) at 0.5 msec |
||||
Operating |
|
||||||
50 G Trapezoidal, 170 in/s |
|
1,000 G (Max) at 0.5 msec |
|||||
Non-operating |
|
||||||
|
|
|
|
|
|
|
|
Vibration5 |
2.17 GRMS (5-700 Hz) Max |
|
2.17 GRMS (5-700 Hz) Max |
||||
Operating |
|
||||||
3.13 GRMS (5-800 Hz) Max |
|
3.13 GRMS (5-800 Hz) Max |
|||||
Non-operating |
|
||||||
|
|
|
|
|
|
|
|
NOTES:
1.Operating temperature implies ambient air temperature with any airflow conditions.
2.Please contact your Intel representative for details on the non-operating temperature range.
3.Temperature gradient measured without condensation.
4.Shock specifications assume the SSD is mounted securely with the input vibration applied to the drive-mounting screws. Stimulus may be applied in the X, Y or Z axis. Shock specification is measured using Root Mean Squared (RMS) value.
5.Vibration specifications assume the SSD is mounted securely with the input vibration applied to the drive-mounting screws. Stimulus may be applied in the X, Y or Z axis. Vibration specification is measured using RMS value.
Product Specification |
October 2015 |
10 |
332059-004US |
