Intel EtherExpress™ PRO/100
LAN+Modem56 PC Card
User’s Guide
How to Use This Manual
This Users Guide contains the latest information on the EtherExpress
PRO/100 LAN+Modem56 PC Card available at press time. It is designed
to help both new and experienced users with installation and configura-
tion.
Installation and Configuration Overview
For an overview, see the Quick Installation Card. For complete technical
details and troubleshooting information, see the chapter covering your
operating system (Chapter 2 Windows 95, Chapter 3 Windows NT, or
Chapter 4 Windows 3.x/MS-DOS) in this Users Guide.
How to Find More Information
Use the Table of Contents, Index, and page and text headings in this Users
Guide to help you find what you need. Check the README file on Disk 2,
Network Drivers disk. To check for updated drivers, visit our Customer
Support web site at:
http://support.intel.com
See Appendix A for additional support information.
ii PRO/100 LAN+Modem PC Card User's Guide
Copyright © 1997 Intel Corporation. All rights reserved.
Intel Corporation
5200 N.E. Elam Young Parkway
Hillsboro, OR 97124-6497
Intel Corporation assumes no responsibility for errors or omissions in this guide.
Nor does Intel make any commitment to update the information contained
herein.
*
Other product and corporate names may be trademarks of other companies
and are used only for explanation and to the owners benefit, without intent to
infringe.
September 1997 687759-001
Contents
Hardware Installation..................................... 1-1
Software Supplied...................................................................1-2
Hardware Installation ..............................................................1-3
Unpacking and Inspection.......................................................1-3
Other Required Equipment .....................................................1-4
Installing Card and Cables...................................................... 1-5
PRO/100 Modem and Ethernet Connections..........................1-6
Windows* 95 Installation ............................... 2-1
Which V ersion of Windows 95?...............................................2-1
How Can I Tell Which Version I Have? .................................... 2-1
Additional Information in this Chapter ..................................... 2-2
Windows 95 Installation (Retail Version).................................2-2
Windows 95 OSR2 Installation
(OEM V ersion) .................................................................. 2-4
How to Install for Windows 95 and NetWare* ......................... 2-8
Utilities.....................................................................................2-8
Power-Saving Modes ..............................................................2-9
Windows 95 Troubleshooting .................................................. 2-9
Troubleshooting Checklist .....................................................2-10
Windows 95 Driver Parameters Reference ...........................2-13
Windows NT Installation................................ 3-1
Which Version of Windows NT? .............................................. 3-1
How Can I Tell Which Version and Service Pack I Have? ....... 3-2
Additional Information in this Chapter ..................................... 3-2
Windows NT 4.0 Installation....................................................3-3
Windows NT 3.51 Installation..................................................3-5
Power-Saving Modes ..............................................................3-7
Utilities..................................................................................... 3-7
Windows NT Driver Parameters Reference ............................ 3-8
Windows 3.x/DOS Installation....................... 4-1
Installation under MS-DOS .....................................................4-2
Windows 3.x Modem Driver Settings .................................... 4-36
Windows 3.x Network Driver Parameters .............................4-37
ODI Settings (for M16BODI.COM)........................................4-38
Error Messages for Windows 3.x and MS-DOS Drivers ....... 4-47
iv PRO/100 LAN+Modem PC Card User's Guide
Windows 3.x Troubleshooting................................................4-51
Computer-Specific Application Notes (Windows 3.x)............4-60
Utilities and Applications .............................. 5-1
Utilities..................................................................................... 5-1
Country Identifier Utility...........................................................5-1
Modem Test Utility................................................................... 5-2
Diagnostic Test Utility (M16BTEST.EXE) ................................ 5-3
COM port monitor (Windows 3.x only) ....................................5-5
Communications Application Notes and Modem
Script Files ...................................................................... 5-6
Modem Reference .......................................... 6-1
Result Codes........................................................................... 6-1
AT Command Reference......................................................... 6-4
S-Register Reference............................................................6-25
Automated Customer Support..................... A-1
Specifications................................................ B-1
Limited Warranty ........................................... C-1
Agency Notices ............................................. D-1
Software License Agreement........................E-1
Index.........................................................Index-1
CHAPTER 1
Hardware Installation
Introduction
The PRO/100 PC Card is the ideal high-speed, multifunction solution for
portable PC users. It supports 10 and 100Mbps Ethernet networks and
modem speeds up to 56Kbps for high-performance connectivity in any
environment. The PRO/100 PC Card plugs into your computers Type II
PC Card slot for simultaneous connection to an Ethernet LAN and the
telephone network.
56K Technology
The PRO/100 PC Card uses K56flex* modem technology to reach speeds
up to 56Kbps. K56flex Technology enables notebook users to access
information and E-mail on corporate networks, the Internet and other
online services at speeds up to 56Kbps over standard phone lines.
These higher speeds are achieved by avoiding conversion from digital to
analog lines in the connection between the user and service provider.
Ordinary connections begin over an analog line, are converted to digital
by the phone company and are converted back to analog in the final
segment before arriving at the service provider. In order to achieve 56K
connections, there can only be one digital to analog conversion. This
requires the service provider to have a direct digital connection and
therefore, avoids one conversion of the signal. By avoiding this conver-
sion, data download speeds up to 56K are possible. Data sent upstream by
the user travels at the standard V.34 rate. Also, the modems at both ends
of the call must be compatible to achieve speeds up to 56K. If the
modems at both ends of the call are not compatible, they will negotiate a
standard V.34 connection.
1-2 PRO/100 LAN+Modem PC Card User’s Guide
With K56flex technology, current country-specific regulations may limit
download speeds. Additional factors such as phone line conditions, can
affect the performance of the PRO/100 PC Card. You can find more
detailed technical information on K56flex performance on Intel's support
web site, support.intel.com.
Model
MBLA1656 Combination card that provides access to
10Base-T and 100Base-TX networks and
modem speeds up to 56Kbps. An Ethernet
Adapter Cable (RJ-45) and Modem Cable
(RJ-11) are supplied. It provides access to
both 10Mbps and 100Mbps networks with a
single Ethernet Adapter Cable, and auto-
senses 10Mbps or 100Mbps network speed.
Requires Category 5 (data grade)
unshielded twisted pair (UTP) cabling
for 100Mbps network connections.
Software Supplied
Intel drivers and other software are supplied on 3.5-inch 1.44 megabyte
disks. All popular network operating systems, including NetWare, Win-
dows 95, Windows NT, Windows 3.x, and Windows for Workgroups are
supported.
An easy-to-use Installation Program for Windows 3.x is provided on the
Intel Installation Disk, which includes the country identifier utility for local
modem settings.
Additional Features
The PRO/100 PC Card is a Type II PC Card conforming to the Personal
Computer Memory Card International Association (PCMCIA) PC Card
Standard. It supports HotSwap, suspend/resume power management, full-
duplex transmission at 10Mbps, and Advanced Look-Ahead Pipelining.
Hardware Installation 1-3
HotSwap
This card supports HotSwap on a PC Card computer that is running
Microsoft Windows 95 or Windows 3.x/MS-DOS using Card and Socket
Services. This feature allows the PRO/100 PC Card to be removed from
the computer, temporarily replaced with another type of PC card, then
reinserted without loss of the local area network connection.
Power Management Suspend/Resume
Power management features such as suspend/resume are supported by the
PRO/100 PC Card on PCMCIA systems running Windows 95 or Win-
dows NT, or Windows 3.x/MS-DOS using Card and Socket Services. This
means that when the computer enters a reduced power or power saving
mode, an ongoing local area network connection will remain active for the
period of time allowed by the network operating system
Hardware Installation
Note
Hardware installation requirements may vary with different
operating systems. For example, if your system is configured for
automatic detection of the card (for example, under Windows
95), the computer should be ON and standard operating
software loaded when the card is inserted. For installation
instructions specific to your particular environment, see the
appropriate chapter: Chapter 2. Installation with Windows 95,
Chapter 3. Installation with Windows NT, and Chapter 4.
Installation with Windows 3.x/MS-DOS.
The PRO/100 PC Card is compatible with Type II PC Card slots. The
hardware installation procedures outlined here are typical. Installation and
removal procedures vary on different PC Card-capable computers and
under different operating systems.
Unpacking and Inspection
After opening the PRO/100 PC Card box, verify that all parts are included
and have not been damaged during transportation. Retain the packing
materials.
1-4 PRO/100 LAN+Modem PC Card User’s Guide
Package Contents
EtherExpress PRO/100 LAN+Modem PC Card PC Card (Model
MBLA1656)
Model MBLA-1656: Ethernet adapter cable with a 15-pin PC Card
connector at one end and female RJ-45 connector at the other for
10Base-T or 100Base-TX connectivity
Modem cable with RJ-11 telephone connector
Intel EtherExpress PRO/100 LAN+Modem PC Card User's
Guide
(this book)
Intel EtherExpress PRO/100 LAN+Modem PC Card Quick
Start card
Software on two 1.44 MB 3.5-inch diskettes
Protective adapter case
6-foot telephone cable
Product registration card
Other Required Equipment
1 For LAN operations: a local area network supporting 10 or
100Mbps Ethernet, as required, and a network operating system
supported by the PRO/100 PC Card.
Note
Since the PRO/100 PC Card automatically detects the speed of
the network to which it is connected, it may be safely connected
to either a 100Base-TX or 10Base-T network, as specified in
items 2 and 3 below.
2 For connection to a 100Base-TX Ethernet network, a Category 5
(data grade) unshielded twisted pair (UTP) network cable terminat-
ing in a male RJ-45 connector and connected to a 100Mbps hub or
switch.
3 For connection to a 10Base-T Ethernet network, a network cable
terminating in a male RJ-45 connector and connected to a 10Mbps
hub or switch.
Hardware Installation 1-5
4 For modem operations: an analog telephone line or PABX
connection (RJ-11), and if needed, an RJ-11 adapter for the local
telephone system.
Note
Do not connect to a digital telephone line or digital PABX
system. The hardware on the adapter will protect your modem
from inadvertent connection to a digital line.
Installing Card and Cables
Inserting the PRO/100 PC Card into the PC Card Slot
1 Grasp the PRO/100 PC Card by the edges with the Intel logo
facing upward and the 68-pin PC Card connector next to the card
slot.
2 Insert the card into the PC card slot and push it in until it is firmly
seated. If you have more than one PC card slot, the PRO/100 PC
Card will automatically detect which slot it is in.
Inserting the PRO/100 PC Card into the Computer.
1-6 PRO/100 LAN+Modem PC Card User’s Guide
Note
The PRO/100 PC Card may feel hot to the touch, after
prolonged periods of normal use in some environments. This is
normal and is not known to affect operation of the Intel card,
the host computer, or any other peripheral device. However, to
avoid discomfort, use caution when removing the card from your
computer after extended use (see your computer manual for
removal procedures).
PRO/100 Modem and Ethernet Connections
Connecting the Modem Cable to the PRO/100
Hold the PC Card with the top (card label and network graphic)
facing you. Grasp the flat connector on the end of the Modem
Cable with the network graphic on top, and plug it in to the
matching receptacle on the right side of the PRO/100 PC Card.
The cable connector will click into place. Do not force the connec-
tion.
MODEM CABLE
Attaching the Modem Cable to the PRO/100.
Connecting the Modem Cable to the Telephone Line
Plug one end of a male analog telephone line cable into the RJ-11
jack on the Modem Cable, and the other end into an analog (single-
line) RJ-11 telephone wall jack.
Hardware Installation 1-7
Caution
The PRO/100 PC Card will not work with digital telephone lines
or digital PABX systems. The adapter hardware will protect your
modem against damage from inadvertent connection to a digital
line.
TRANSMIT/RECEIVE
TELEPHONE
CABLE
(YELLOW)
CARRIER
DETECT
(GREEN)
MODEM CABLE
Connecting the Telephone Cable to the Modem Cable.
Connecting the Ethernet Adapter Cable to the PRO/100
Hold the PC Card with the top facing upward. Grasp the flat
connector on the end of the Ethernet Adapter Cable with the
network graphic on top, and plug it in to the matching receptacle on
the left side of the PRO/100 PC Card. The cable connector will
click into place. Do not force the connection.
ETHERNET
ADAPTER CABLE
Attaching the Ethernet Adapter Cable to the PRO/100.
PC-3808
1-8 PRO/100 LAN+Modem PC Card User’s Guide
Connecting to a Twisted Pair network.
Caution
For safety reasons, do not interchange the telephone (RJ-11) and
Ethernet (RJ-45) cables by forcing the Ethernet cable into the
modem sloton the PRO/100 PC Card.
Plug the male RJ-45 connector at the end of the network cable into
the female RJ-45 connector on the Ethernet Adapter Cable.
LAN ACTIVITY
(YELLOW)
LINK INTEGRITY
Orange = 100 Mbps
Green = 10 Mbps
RJ-45 TWISTED PAIR ETHERNET CONNECTOR
Connecting the Ethernet Adapter Cable to the Network.
CHAPTER 2
Windows 95 Installation
Which V ersion of Windows 95?
Two Versions and Two Installation Paths
Currently two versions of Windows 95 are available:
The standard retail version (designated 4.00.950 or 4.00.950a)
OEM Service Release Version 2 (designated 4.00.950b, also known
as OSR2)
Installation procedures are presented in two separate sections:
Windows 95 Installation (Retail Version)
Windows 95 OSR2 Installation (OEM Version)
How Can I Tell Which Version I Have?
1 In Windows 95, click Start, Settings, and Control Panel.
2 In Control Panel, double-click the System icon.
3 In the System Properties window, click the General tab (if not
already displayed) and view information under System.
For Microsoft Windows 95 4.00.950 or 4.00.950a, follow the
installation instructions under the heading Windows 95 Installation
(Retail Version)
2-2 PRO/100 LAN+Modem PC Card User’s Guide
For Microsoft Windows 95 4.00.950b, follow the installation
instructions under the heading Windows 95 OSR2 Installation
(OEM Version)
Additional Information in this Chapter
This chapter also contains the following Windows 95 information:
How to Install for Windows 95 and NetWare
Power Saving Modes
Utilities
Troubleshooting
Driver Parameters Reference
Windows 95 Installation (Retail Version)
Overview
Installation under the standard retail version of Windows 95 should be a
plug and play operation: Windows 95 should recognize the Intel card
when it is inserted and prompt for the Intel software disk. The Intel files
will be copied to the hard drive and the computer will restart. The country
identifier utility will launch automatically.
Important Notes
Please note the following important information before starting the install
process.
The usual path for Windows 95 files installed on your hard drive is
C:\WINDOWS\OPTIONS\CABS. The CAB files are com-
pressed versions of the Windows 95 distribution files. Organization
of the CD-ROM version of these files mirrors the diskette version:
If prompted to insert the disk labeled "Windows 95 Disk 1" the
corresponding CD-ROM file and path would be
"c:\windows\options\cabs\disk1.cab".
All the Intel files required for Windows 95 installation can be found
on Intel Disk 1.
Windows 95 Installation 2-3
Windows 95 troubleshooting information is provided in this chapter
following the installation sections.
Recommended Installation Steps
Insertion, Detection, and Prompt for Disk
1 With the computer powered-up and Windows 95 running, insert the
PRO/100 PC Card into the PC Card slot in the computer. Windows
95 will detect the insertion of the adapter. (If it does not, see item 3
of the Troubleshooting Checklist: Be sure that PCMCIA support is
enabled ... later in this chapter.)
2 At the New Hardware Found screen specifying Intel EtherExpress
PRO/100 LAN+Modem PC Card, select Driver from disk provided
by hardware manufacturer and click OK.
3 At the Install From Disk screen, insert Intel Disk 1, Installation
Disk and verify the specified path (for example: A:\). Click OK.
4 Intel files will be copied from the Intel disk and Windows 95 will
recognize the modem and network functionality of the Intel adapter.
Windows 95 Network Installation
In most cases Windows 95 network files will need to be installed, using
CAB files from diskette or CD-ROM. If another PC Card modem or
network adapter was installed previously on your system, some of these
files may already be present.
5 If prompted for Windows 95 networking files, click OK at the
Insert Disk screen.
6 At the Copying Files screen, specify the path to Windows 95
installation files (usually c:\windows\options\cabs) and click OK.
7 At the System Settings Change screen, remove the Intel disk from
the disk drive and click Yes. If Windows 95 networking was
installed, the computer will restart.
Country Identifier Utility
8 After the computer restarts and Windows 95 reloads, the country
identifier utility will be launched automatically. At the country
identifier utility screen, make the appropriate selection and complete
2-4 PRO/100 LAN+Modem PC Card User’s Guide
the program. (For details on this utility, see Chapter 5. Utilities and
Applications.)
Windows 95 OSR2 Installation
(OEM V ersion)
Overview
Installation under the OSR2 version of Windows 95 should be performed
using the Update Device Driver Wizard, as described below. Windows 95
will recognize the Intel card when it is inserted and display the Update
Device Driver Wizard window. Intel and Windows files will be located or
copied as required and the computer will restart. The Intel country
identifier utility will launch automatically.
Important Notes
Please note the following important information before starting the install
process.
You may be prompted more than once for Intel or Windows 95
files, due to limitations in OSR2.
The usual path for Windows 95 files installed on your hard drive is
C:\WINDOWS\OPTIONS\CABS. The "CAB" files are com-
pressed versions of the Windows 95 distribution files. Organization
of the CD-ROM version of these files mirrors the diskette version:
If prompted to insert the disk labeled "Windows 95 Disk 1" the
corresponding CD-ROM would typically be
c:\windows\options\cabs\disk1.cab.
All the Intel files required for Windows 95 OSR2 installation can be
found on Intel Disk 1.
Windows 95 troubleshooting information is provided in this chapter
following the installation sections.
Windows 95 Installation 2-5
Recommended Installation Steps
Insertion, Detection, and Prompt for Disk
1 With the computer powered-up and Windows 95 running, insert the
PRO/100 PC Card into the PC card slot in the computer.
2 Windows 95 will detect the Intel adapter and then display the
following Update Device Driver Wizard screen (if the adapter is not
detected, see Troubleshooting Item 3: Be sure that PCMCIA
support is enabled ... under Windows 95 Troubleshooting later in
this chapter).
3 Insert Intel Disk 1. Click Next>.
4 On the Update Device Driver Wizard screen click Finish.
2-6 PRO/100 LAN+Modem PC Card User’s Guide
Copying Intel Files
5 At the Insert Disk screen, click
OK.
6 At the Copying Files... screen, specify A:\ in the Copy files from:
box and click
OK.
Copying Windows 95 Network Files
In most cases Windows 95 network files will need to be installed, using
CAB files from diskette or CD-ROM. If another PC Card modem or
network adapter was installed previously on your system, some of these
files may already be present.
Windows 95 Installation 2-7
7 Windows 95 will detect new hardware and copy files. At the Insert
Disk screen, click OK.
8 At the Copying Files... screen, specify the path to the Windows 95
files (usually c:\windows\options\cabs) in the Copy files from: box
and click OK.
9 At the System Settings Change screen, remove the Intel disk from
the disk drive and click Yes. The computer will restart.
Country Identifier Utility
10 After the computer restarts and Windows 95 reloads, the country
identifier utility will launch automatically. At the country identifier
utility screen make the appropriate selection and complete the
program. (For details on this utility, see Chapter 5. Utilities and
Applications.)
2-8 PRO/100 LAN+Modem PC Card User’s Guide
How to Install for Windows 95 and NetWare
1 Install the PRO/100 PC Card driver and verify the installation as
described above in the installation procedures.
2 In the Control Panel, double-click the Network icon.
3 From the Configuration tab in the Network window, click Add.
4 From the Select Network Component Type window, select Client
and click Add.
5 Under Manufacturers in the Select Network Client window, select
Microsoft.
6 In the Network Clients window, select Client for NetWare Net-
works.
7 Click OK (you will be returned to the Network window).
8 From the Configuration tab in the Network window, click Add.
9 From the Select Network Component Type window, select Protocol
and click Add.
10 Select Microsoft as the manufacturer and IPX/SPX-compatible
Protocol under Network Protocols, then click OK to return to the
Network window.
11 Click OK to close the Network window, then restart the computer
when prompted.
Utilities
Several utilities are provided with the PRO/100 PC Card that run under
Microsoft Windows or MS-DOS. The utilities are:
Country Identifier Utility (Windows 95, NT, 3.x)
Modem Test (Windows 95, NT, 3.x)
Diagnostic Test (MS-DOS prompt required)
Windows 95 Installation 2-9
These utilities are automatically copied to your hard drive during installa-
tion under Windows 95, and icons for the utilities are installed in a
Windows program group at the time of installation. See Chapter 5.
Utilities and Applications for additional information.
Power-Saving Modes
The PRO/100 PC Card has two power-saving modes to reduce adapter
power consumption under certain conditions: Network-only mode and
Modem-only mode (Network & Modem is the default).
Network-only mode disables the modem function on the adapter. This
mode should only be used when the modem will not be needed. Modem-
only mode disables the network function on the adapter. It should only be
used when the network will not be needed. When the Intel adapter is set
to either Network-only or Modem-only mode, it remains in that mode
until re-configured to a different mode.
To specify a power-saving mode under Windows 95, select Network from
Control Panel, select the Configuration tab, select Intel EtherExpress
PRO/100 LAN+Modem PC Card and click Properties, select the
Advanced tab, and select a mode in the Function(s) property (Network &
Modem is the default).
Windows 95 Troubleshooting
Quick Troubleshooting (Device Conflicts)
1 To review the adapter configuration, right-click the My Computer
icon and select Properties.
2 Select the Device Manager tab.
3 Proceed according to your version of Windows 95 (see the begin-
ning of this chapter for information):
For Windows 95 (Retail Version), expand the item Multifunction
Adapters.
2-10 PRO/100 LAN+Modem PC Card User’s Guide
For Windows 95 OSR2 (OEM Version), expand the item
Modem.
4 For either version, select Intel EtherExpress PRO/100
LAN+Modem PC Card (Multi-function Parent Device) and click
Properties.
5 From the Properties window, select the Resources tab.
6 Confirm that there are no conflicts with other installed devices.
Troubleshooting Checklist
The following section suggests troubleshooting steps to follow when the
Intel PC Card adapter is not automatically detected or not correctly
identified. These conditions are generally resolved by one or more of the
measures below. Detailed instructions for each measure follow.
1 Be sure you have the latest firmware and driver.
2 Run the Intel diagnostic utility M16BTEST.
3 Be sure PCMCIA support is enabled in Windows 95.
4 Create C:\WINDOWS\MODEMLOG.TXT to help resolve issues
with the modem.
5 Check other sources for updated troubleshooting information.
Note
When these directions or Windows 95 prompts you to shut down
or restart the computer, select Start, Shut Down, Shut down the
computer? Leave the computer turned off for a few seconds, and
then turn it back on. Do not press CTRL+ALT+DEL or use
your computers reset button to restart your computer--this can
lead to device malfunctions. On some machines, all hardware is
not reset unless power is cycled.
Windows 95 Installation 2-11
1 Be sure you have the latest firmware and
driver.
To determine what firmware and driver version you have, click My
Computer, Control Panel, Modems, highlight the Intel EtherExpress
PRO 100 LAN+Modem PC Card (Modem), click Diagnostics, click the
Port the Intel modem is using, click More Info. The firmware information
for the adapter should display.
To find out what the latest versions are, and to download updated
versions if necessary, access the Intel BBS or web site (see the Intel
Automated Customer Support information toward the end of this guide).
2 Run the Intel diagnostic utility
M16BTEST.
To verify correct operation of the PRO/100 PC Card, run the Intel
diagnostic test utility provided on Disk 2, Network Drivers Disk. Follow
the steps below.
1 Shut down Windows 95 and power the machine off.
2 Restart Windows 95. Press the F8 key when the message Starting
Windows 95 appears on the screen. Choose Safe Mode Command
Prompt Only from the Startup menu (or press Shift+F5 to go
directly to the command prompt).
3 Run M16BTEST.EXE at the MS-DOS prompt. (See Chapter 5.
Utilities and Applications for more detailed instructions.)
4 If your Intel PC Card does not test properly, try the same procedure
on another computer. If the card still does not work, contact Intel
Customer Support.
3 Be sure that PCMCIA support is enabled
in Windows 95.
In some cases, Windows 95 PCMCIA support may not have been installed
or enabled during an upgrade or installation, due to previous machine
configurations or options selected during installation. If this Windows 95
support is not enabled, run the PCMCIA Wizard by double-clicking on
2-12 PRO/100 LAN+Modem PC Card User’s Guide
the PCMCIA icon in the Control Panel, so that Windows 95 will automati-
cally detect the type of PCMCIA controller in the machine.
4 Create C:\WINDOWS\MODEMLOG.TXT
to record the status of the modem.
Double-click My Computer, Control Panel, Modems, highlight the Intel
EtherExpress PRO 100 LAN+Modem PC Card (Modem), click Proper-
ties, Connection, Advanced, check the box Record a log file, remove any
modem strings in the box Extra settings, then click OK. If you try to dial
again and get disconnected, the file C:\WINDOWS\MODEMLOG.TXT
will be created. Review the information in that file with Intel Customer
Support.
5 Check other sources for updated
troubleshooting information.
The following information may also be helpful:
1 Review the HARDWARE.TXT file in the Windows 95 directory.
This file is written by Microsoft and describes machine specific
problems when the software was released.
2 Review the README.TXT file by clicking on the README icon
in the Program Group (or read from Intel Disk 1, Installation Disk).
This file will contain information about the driver that may not have
been available when this user manual was published.
3 Use the Intel BBS or website for updated troubleshooting informa-
tion for Windows 95. See Appendix A. Intel Automated Customer
Support, for access information.
4 Contact your computer vendor for updated information.
Windows 95 Installation 2-13
Windows 95 Driver Parameters Reference
Caution
Under most circumstances it will not be necessary to make
modifications directly to the registry. Incorrect settings can
result in undesirable changes to the configuration of Windows
95. Consult Intel Customer Support for assistance if you find it
necessary to modify the registry.
M16B.SYS (NDIS 3) Settings for Microsoft Windows 95
M16B.SYS is an NDIS 3 LAN adapter. It conforms to the Microsoft
Network Driver Interface Specification (NDIS). It supports both Win-
dows NT and Windows 95.
Windows 95 Support
The M16B.SYS driver also supports the networking environment in
Microsoft Windows 95.
The files necessary for using M16B.SYS with Windows 95 include:
NETM16B.INF Intel network installation file for Win-
dows 95
M16B.SYS Intel NDIS 3 driver for Windows 95
MDMM16B.INF Intel modem installation file
MFM16B.INF Intel multifunction installation file
2-14 PRO/100 LAN+Modem PC Card User’s Guide
There are user-configurable parameters for the M16B.SYS driver that can
be modified using the Network Control Panel applet built into Windows
95. This applet queries the user for parameter selections and then sets the
corresponding parameters in the registry. The user-configurable param-
eters are as follows:
Parameter Default Valid Values Registry Value
DIRECT ENABLE OFF OFF, ON 0
EARLY TRANSMIT ON OFF 0
ON 1
FULL DUPLEX OFF OFF 0
ON 1
FUNCTION(S) NETWORK&MODEM
NETWORK&MODEM 0
NETWORK ONLY 1
MODEM ONLY 2
LINE SPEED AUTO AUTO DETECT 0
10MBPS 1
100MBPS 2
LINK INTEGRITY ON OFF 0
ON 1
MODE I/O I/O 0
MEMORY MAPPED 1
NETWORKADDRESS
TRANSMITBUFFERSIZE 7168 1024-29696 1024-29696
The network node address can be modified by specifying a value for
NetworkAddress such as 00A0C9112233. If the user does NOT specify
a NetworkAddress then the M16B.SYS driver uses the network node
address contained in the PRO/100 Card information structure.
There are parameters in the Windows 95 registry which specify the
configuration of the EtherExpress PRO/100 LAN+Modem PC Card
hardware to the M16B.SYS driver. Many of these parameters correspond
directly to the user-configurable parameters. These parameters are found
in the registry at the following location:
HKEY_LOCAL_MACHINE\SYSTEM\CURRENTCONTROLSET\SERVICES\CLASS\NET\000X
Windows 95 Installation 2-15
Caution
Under most circumstances it will not be necessary to make
modifications directly to the registry. Incorrect settings can
result in undesirable changes to the configuration of Windows
95 or NT.
The registry parameters are as follows:
Keyword Default Valid Values
DEVICEVXDS M16B.SYS
DEVLOADER NDIS
DIRECTENABLE 0 0-1
DRIVERDESC INTEL ETHEREXPRESS PRO/100
LAN+MODEM PC CARD (NETWORK)
EARLYTRANSMIT 1 0-1
ENUMPROPPAGES NETDI.DLL,ENUMPROPPAGES
FULLDUPLEX 0 0-1
FUNCTIONENABLE 0 0 -2
INFPATH NETM16B.INF
INTERRUPTNUMBER 04 00 00 00
IOBASEADDRESS 02 00 00 00
LINESPEED 0 0 -2
LINKINTEGRITY 1 0 -1
MEMORYBASEADDRESS 01 00 00 00
MODE 0 0- 1
NETWORKADDRESS
PLATFORMTYPE 1 1
TRANSMITBUFFERSIZE 11264 1024-29696
InterruptNumber, IoBaseAddress, and MemoryBaseAddress are NOT
user-configurable and their values are assigned by the Windows 95
Configuration Manager.
2-16 PRO/100 LAN+Modem PC Card User’s Guide
CHAPTER 3
Windows NT Installation
Which V ersion of Windows NT?
Two Versions and Two Installation Paths
Installation of the PRO/100 PC Card is different for versions 4.0 and 3.51
of Windows NT. Before starting the installation you must know what
version of Windows NT you have. If youre using version 3.51, you must
also know the version of any software Service Pack installed.
Currently two versions of Windows NT are supported:
Windows NT Version 4.0
Windows NT Version 3.51 (including Service Packs)
Installation procedures are presented in two separate sections:
Windows NT 4.0 Installation
Windows NT 3.51 Installation
3-2 PRO/100 LAN+Modem PC Card User’s Guide
How Can I Tell Which Version and Service
Pack I Have?
If you don't know what version you have, follow the steps below.
If you know you have Version 4.0, skip to the Windows NT 4.0
Installation section. No additional version information is required.
If you know you have Version 3.51, follow the steps below to
determine what Service Pack version is installed. This information is
required in step 9 of the Windows NT 3.51 Installation section.
To obtain version and Service Pack information, proceed as follows:
1 Open the Windows NT Diagnostics application in the Administra-
tive Tools folder. The Administrative Tools folder can be found in
the Program Manager window (Windows NT 3.51 interface) or by
selecting Start and Programs (Windows NT 4.0 interface).
2 In the Diagnostics application, version information can be found
either by selecting the Version tab or by clicking the OS Version ...
button.
3 If the version is 3.51, be sure to note the value of the Service Pack
field:
For Windows NT Version 3.51 with Service Pack 5 or greater,
follow step 9a in the installation instructions for Windows NT
3.51.
For all other versions of Windows NT 3.51, follow step 9b in the
installation instructions for Windows NT 3.51.
Additional Information in this Chapter
This chapter also contains the following information:
Power Saving Modes
Utilities
Driver Parameters Reference
Loading...
