USER’S
MANUAL
PMB-531LF
Intel® Core Duo/Solo
Mini-ITX Motherboard
With VGA/Audio/LAN
PMB-531LF M3
PMB-531LF Intel® Core
Duo/Solo
Mini-ITX Motherboard
With VGA/ Sound/ LAN
OPERATION MANUAL
COPYRIGHT NOTICE
This operation manual is meant to assist both Embedded Computer
manufacturers and end users in installing and setting up the system. The
information contained in this document is subject to change without any
notice.
This manual is copyrighted in December, 2006. You may not reproduce or
transmit in any form or by any means, electronic, or mechanical, including
photocopying and recording.
ACKNOWLEDGEMENTS
All trademarks and registered trademarks mentioned herein are the
property of their respective owners.
CE NOTICE
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
Copyright Notice
Copyright Notice
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void
your authority to operate such equipment.
Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual ........................................................ 1-2
1-2 System Specification ...................................................... 1-3
1-3 Safety Precautions ......................................................... 1-6
CHAPTER 2 HARDWARE CONFIGURATION
2-1 Jumper & Connector Quick Reference Table ................ 2-2
2-2 Component Locations .................................................... 2-3
2-3 How to Set the Jumpers ................................................. 2-4
2-4 COM Port Connector ……..…………………………... 2-6
2-5 COM3/4 RI& Voltage Selection ………………………. 2-8
2-6 RS232/422/485(COM2) Selection ................................ 2-10
2-7 Keyboard and PS/2 Mouse Connector .....................….. 2-11
2-8 Reset Connector ............................................................ 2-11
2-9 Hard Disk Drive LED Connector .................................. 2-12
2-10 ATX Power Button ….................................................... 2-12
2-11 External Speaker Connector .......................................... 2-12
2-12 PLed Connector ……..................................................... 2-13
2-13 Clear CMOS Data Selection ………………………… 2-13
2-14 CPU Fan Connector ………………………………….. 2-14
2-15 System Fan Connector ………………………………… 2-14
2-16 Hard Disk Drive Connector ........................................... 2-15
2-17 VGA Connector …………………..…………………… 2-16
2-18 Serial ATA Connector ………………………………… 2-17
2-19 Universal Serial Bus Connector ……………………… 2-18
2-20 USB & LAN Connector ……………………………… 2-19
2-21 IrDA Connector ………………………………………. 2-20
2-22 ATX Power Connector ………………………………. 2-20
2-23 Sound Connector ……………………………………… 2-21
2-24 CD Audio-In Connector ………………………………. 2-22
2-25 LVDS Connector ……………………………………… 2-22
2-26 Inverter Connector …………………………………….. 2-23
2-27 LVDS Panel Voltage Selection ……………………….. 2-23
2-28 FSB Frequency Selection …………………………….. 2-24
2-29 Power State Selection ………………………………… 2-25
2-30 Reset/NMI Watchdog Selection ……………………… 2-26
2-31 CF Card Master/ Slave Selection …………………….. 2-27
2-32 TV Out Connector …………………………………….. 2-28
2-33 Memory Installation …………………………………… 2-28
Contents
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction …………..........................................…....... 3-2
3-2 VGA Driver Utility ……………………………….…… 3-3
3-3 Flash BIOS Update ..............................................…....... 3-4
3-4 LAN Driver Utility …...........................................…...... 3-6
3-5 Sound Driver Utility …………………………………… 3-7
3-6 Intel Chipset Software Installation Utility …..……..….. 3-8
3-7 USB2.0 Software Installation Utility ………………….. 3-9
3-8 RAID Software Installation Utility ……………………. 3-10
3-8 Watchdog Timer Configuration ……………………….. 3-11
CHAPTER 4 AWARD BIOS SETUP
4-1 Introduction ................................................................... 4-2
4-2 Entering Setup ............................................................... 4-3
4-3 The Standard CMOS Features ………............................ 4-4
4-4 The Advanced BIOS Features ....................................... 4-8
4-5 Advanced Chipset Features ........................................... 4-11
4-6 Integrated Peripherals …............................................... 4-14
4-7 Power Management Setup ............................................. 4-19
4-8 PNP/PCI Configuration …............................................. 4-20
4-9 PC Health Status …….................................................... 4-22
4-10 Load Fail-Safe Defaults ................................................. 4-23
4-11 Load Optimized Defaults .........................................…. 4-23
4-12 Password Setting ……………………………………… 4-24
4-13 Save & Exit Setup ......................................................... 4-25
4-14 Exit Without Saving ………………………………… 4-26
APPENDIX A EXPANSION BUS
Mini PCI Bus Pin Assignment ................................................... A-2
Compact Flash Card Connector Pin Assignment ……………... A-4
APPENDIX B TECHNICAL SUMMARY
Block Diagram ........................................................................... B-2
Interrupt Map ............................................................................ B-3
RTC & CMOS RAM Map ........................................................ B-4
Timer & DMA Channels Map .................................................. B-5
I/O & Memory Map ...............................................…................ B-6
INTRODUCTION
This chapter gives you the information for PMB-531LF. It also
outlines the System specifications.
Section includes:
z About This Manual
z System Specifications
z Safety Precautions
Experienced users can skip to chapter 2 on page 2-1
for a Quick Start.
CHAPTER
1
Page:1-1
Chapter 1 Introduction
1-1. ABOUT THIS MANUAL
Thank you for purchasing our PMB-531LF Intel® Core Duo/Solo
Mainboard enhanced with VGA/Sound/LAN, which is fully PC / AT
compatible. The PMB-531LF provides faster processing speed, greater
expandability and can handle more tasks than before. This manual is
designed to assist you how to install and set up the system. It contains four
chapters. The user can apply this manual for configuration according to the
following chapters:
Chapter 1 Introduction
This chapter introduces you to the background of this manual, and the
specifications for this system. The final page of this chapter will indicate
how to avoid damaging this board.
Chapter 2 Hardware Configuration
This chapter outlines the component locations and their functions. In the
end of this chapter, you will learn how to set jumper and how to configur e
this card to meet your own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the
VGA utility, LAN utility, Sound utility, and Flash BIOS Update. It also
describes the Watchdog-timer configuration.
Chapter 4 Award BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A Expansion Bus
This Appendix introduces you the expansion bus for PCI-E x16 BUS.
Appendix B Technical Summary
This section gives you the information about the Technical maps.
Page: 1-2
PMB-531LF USER
′
S MANUAL
1-2. SYSTEM SPECIFICATIONS
z CPU:
Intel® Core Duo up to 2.33GHz.
Intel® Core Solo up to 1.83GHz.
Intel® Core Duo ULV up to 1.2 GHz.
Intel® Core Solo ULV up to 1.2 GHz.
Auto detect voltage regulator.
z CHIPSET:
Intel® 945GM + ICH7R (FSB: 533/667MHz)
z MEMORY :
2 x 200-pin DDR2 SO-DIMM
Support DDR II 667 SDRAM up to 2GB.
z CACHE :
Built-in CPU.
z REAL-TIME CLOCK :
256-byte battery backed CMOS RAM.
Hardware implementation to indicate century rollover.
z BIOS :
Phoenix-AwardBIOS™ for plug & play function
4/8MB with VGA BIOS.
Easy update 512KB flash EEPROM.
Support S/IO Setup.
z KEYBOARD CONNECTOR :
Mini DIN connector.
Supports for AT/PS2 keyboard.
z MOUSE CONNECTOR :
Mini DIN connector.
Supports for PS/2 Mouse.
z BUS SUPPORT :
1 PCI-E (x16) Slot (SDVO), Mini-PCI, CF (only available if no IDE device
attached)
PMB-531LF USER′S MANUAL
Chapter 1 Introduction
.
Page: 1-3
Chapter 1 Introduction
z DISPLAY :
Built-in Intel 945GM, support for CRT, LVDS, TV-Out.
Onboard 15-pin VGA D-SUB connector, support for resolution on QXGA
Monitor.
z IDE INTERFACE :
One IDE ports support up to two IDE devices.
Supports Ultra DMA 33.
z SERIAL ATA PORT :
Two S-ATA connectors from ICH7R.
z USB CONNECTOR :
Support up to six USB 2.0 ports.
z LAN ADAPTER :
LAN: Intel® 82573V (10/100/1000 Mbps)
Support wake-on-LAN function.
z SERIAL PORT :
Four high speed 16550 Compatible UARTs with Send / Receive 16 Byte
FIFOs; COM1/3/4:RS-232; COM2: RS-232/422/485
MIDI Compatible
Programmable Baud Rate Generator
z SOUND :
Realtek ALC655 (AC’97 Codec).
Fully Compliant AC’97 Analog I/O Component
16-Bit Stereo Full-Duplex Codec
Four Analog Line-level Stereo Inputs for Connection.
High Quality CD Input with Ground Sense
Stereo Line-Level Output
Interface: Line-In, Line-Out, Microphone, and CD Audio-In.
z HARDWARE MONITORING FUNCTION :
Monitor Voltage, CPU temperature, & Cooling fan speed.
If CPU Temperature is over setting, the buzzer will send out a warming (only
under DOS system).
Page: 1-4
PMB-531LF USER
′
S MANUAL
z IRDA PORT :
5-pin Infrared port, support IrDA v1.0 SIR protocol
z GREEN FUNCTION :
Controlled by hardware and software.
z LED INDICATOR :
System power
Hard Disk access
LAN LED indicator
z DMA CONTROLLER :
8237 x 2
z DMA CHANNELS :
7
z INTERRUPT CONTROLLERS :
82C59 x 2
z INTERRUPT LEVELS :
15
z OPERATING TEMPERATURE :
0 to 60°C.
z BOARD DIMENSIONS :
170 mm x 170 mm, 6.69” x 6.69”
z BOARD NET WEIGHT :
810 gram.
Chapter 1 Introduction
PMB-531LF USER′S MANUAL
Page: 1-5
Chapter 1 Introduction
1-3. SAFETY PRECAUTIONS
Follow the messages below to avoid your systems from damage:
1. Keep your system away from static electricity on all occasions.
2. Prevent electric shock. Don‘t touch any components of this card when the
card is power-on. Always disconnect power when the system is not in use.
3. Disconnect power when you change any hardware devices. For instance,
when you connect a jumper or install any cards, a surge of power may
damage the electronic components or the whole system.
Page: 1-6
PMB-531LF USER
′
S MANUAL
HARDWARE
CONFIGURATION
** QUICK START **
Helpful information describes the jumper & connector settings, and
component locations.
Section includes:
z Jumper & Connector Quick Reference Table
z Component Locations
z Configuration and Jumper settings
z Connector’s Pin Assignments
CHAPTER
2
Page 2-1
Chapter 2 Hardware Configuration
2-1. JUMPER & CONNECTOR QUICK REFERENCE TABLE
COM Port Connector …………………………. COM1,COM2,COM3,COM4
COM3/4 Port RI/Voltage Selection …………... JP16,JP17
RS232/422/485 (COM2) Selection …………… JP15
Keyboard/Mouse Connector …………………. JKBMS1
Reset Connector ………………………………
Hard Disk Drive LED Connector …………….
Power Button ………………………………..
External Speaker Connector …………………
Power LED Connector ………………………
Clear CMOS Data Selection ………………… JP2
CPU Fan Connector ………………………… FAN1
System Fan Connector ……………………… FAN2, JCFAN1
Hard Disk Drive Connector ………………… IDE1
VGA Connector …………………………….. VGA1
Serial ATA Connector ……………………… SATA1,SATA2
Universal Serial Bus Connector …………….. USB1, USB2
USB & LAN Connector …………………….. J2
IRDA Connector ……………………………. IRDA1
ATX Power Connector ……………………… PW1, JATXPWR2
Sound Connector …………………………….. JAUDIO1
CD Audio-In Connector …………………….. JCDIN1
LVDS Connector ……………………………..
Inverter Connector …………………………… J4
LVDS Panel Voltage Selection ………………. JP4
FSB Frequency Selection ……………………..
Power State Selection …………………..……. JP21(1-2), JP22
Reset/NMI Watchdog Selection ……………… JP21
CF Card Master/ Slave Selecction ……………. JP14
TV Out Connector ……………………………. JP1
Memory Installation ………………………….. DIM1, DIM2
JPANEL1 ( 13，15 )
JPANEL1 ( 09，11 )
JPANEL1 ( 14，16 )
JPANEL1 ( 1，3，5，7 )
JPANEL1 ( 08，10，12 )
J1
JP5，JP6，JP7
Page: 2-2
′
PMB-531LF USER
S MANUAL
Chapter 2 Hardware Configuration
2-2. COMPONENT LOCATIONS
PMB-531LF Connector, Jumper and Component locations
PMB-531LF USER′S MANUAL
Page: 2-3
Chapter 2 Hardware Configuration
2-3. HOW TO SET THE JUMPERS
You can configure your board by setting jumpers. Jumper is consists of
two or three metal pins with a plastic base mounted on the card, and by
using a small plastic "cap", Also known as the jumper cap (with a metal
contact inside), you are able to connect the pins. So you can set-up your
hardware configuration by "open" or "close" pins.
The jumper can be combined into sets that called jumper blocks. When
the jumpers are all in the block, you have to put them together to set up
the hardware configuration. The figure below shows how this looks like.
JUMPERS AND CAPS
If a jumper has three pins (for examples, labelled PIN1, PIN2, and PIN3),
You can connect PIN1 & PIN2 to create one setting by shorting. You can
either connect PIN2 & PIN3 to create another setting. The same jumper
diagrams are applied all through this manual. The figure below shows
what the manual diagrams look and what they represent.
Page: 2-4
PMB-531LF USER
′
S MANUAL
JUMPER DIAGRAMS
JUMPER SETTINGS
Chapter 2 Hardware Configuration
Jumper Cap
looks like this
2 pin Jumper
looks like this
3 pin Jumper
looks like this
Jumper Bl ock
looks like this
2 pin Jumper close(enabled)
1
2-3 pin close(ena bled )
1
1-2 pin close(ena bled )
1
2
PMB-531LF USER′S MANUAL
Looks like this
3 pin Jumper
Looks like this
Jumper Block
Looks like this
1
1
12
Page: 2-5
Chapter 2 Hardware Configuration
2-4. COM PORT CONNECTOR
COM1 : COM1 Connector
COM1 is fixed as RS-232.
The pin assignment is as follows :
PIN ASSIGNMENT
1 DCD1
2 RX1
3 TX1
4 DTR1
5 GND
6 DSR1
7 RTS1
8 CTS1
9 RI1
COM2 : COM2 Connector
The COM2 is selectable as RS-232/422/485.
The pin assignment is as follows :
Page: 2-6
PIN
RS-232 RS-422 RS-485
ASSIGNMENT
1 DCD2 TX- TX2 RX2 TX+ TX+
3 TX2 RX+ RX+
4 DTR2 RX- RX5 GND GND GND
6 DSR2 RTS- NC
7 RTS2 RTS+ NC
8 CTS2 CTS+ NC
9 RI2 CTS- NC
PMB-531LF USER
′
S MANUAL
Chapter 2 Hardware Configuration
COM3 : COM3 Connector
COM3 is fixed as RS-232.
The pin assignment is as follows :
PIN ASSIGNMENT
1 DCD3
2 RX3
3 TX3
4 DTR3
5 GND
6 DSR3
7 RTS3
8 CTS3
9 RI3
10 NC
COM3’s pin 9 is selectable for RI, +5V or +12V. For more information,
please refer to our “2-5 COM RI and Voltage Selection”.
COM4 : COM4 Connector
COM4 is fixed as RS-232.
The pin assignment is as follows :
PIN ASSIGNMENT
1 DCD4
2 RX4
3 TX4
4 DTR4
5 GND
6 DSR4
7 RTS4
8 CTS4
9 RI4
10 NC
COM4’s pin 9 is selectable for RI, +5V or +12V. For more information,
please refer to our “2-5 COM RI and Voltage Selection”.
PMB-531LF USER′S MANUAL
Page: 2-7
Chapter 2 Hardware Configuration
2-5. COM3/4 RI & VOLTAGE SELECTION
JP16 : COM3 RI & Voltage Selection
The selections are as follows:
COM
COM3
SELECTION
5V
SETTINGS
5-6
12V 3-4
RI 1-2
JUMPER
JUMPER
ILLUSTRATION
***Manufacturing Default -- RI.
Page: 2-8
′
PMB-531LF USER
S MANUAL
Chapter 2 Hardware Configuration
JP17 : COM4 RI & Voltage Selection
The selections are as follows:
COM
COM4
SELECTION
5V
SETTINGS
5-6
12V 3-4
RI 1-2
JUMPER
JUMPER
ILLUSTRATION
***Manufacturing Default -- RI.
PMB-531LF USER′S MANUAL
Page: 2-9
Chapter 2 Hardware Configuration
2-6. RS232/422/485 (COM2) SELECTION
JP15 : RS-232/422/485 (COM2) Selection
This connector is used to set the COM2 function.
The jumper settings are as follows :
COM 2
Function
RS-232 All Open
RS-422 1-2, 3-4, 9-10
Jumper Settings
(pin closed)
Jumper
Illustrations
RS-485 1-2, 5-6, 7-8
*** Manufacturing default -- RS-232.
Page: 2-10
′
PMB-531LF USER
S MANUAL
Chapter 2 Hardware Configuration
2-7. PS/2 KEYBOARD AND MOUSE CONNECTOR
JKBMS1 : PS/2 Keyboard and Mouse Connector
The pin assignments are as follows :
PIN ASSIGNMENT
1 KBDATA
2 NC
3 GND
4 5VSB
5 KBCLK
6 NC
7 MSDATA
8 NC
9 GND
10 5VSB
11 MSCLK
12 NC
2-8. RESET CONNECTOR
JPANEL1 (13, 15) : Reset Connector.
The pin assignment is as follows :
PIN ASSIGNMENT
13 GND
15 RST_BTN
PMB-531LF USER′S MANUAL
Page: 2-11
Chapter 2 Hardware Configuration
2-9. HARD DISK DRIVE LED CONNECTOR
JPANEL1 (9, 11) : Hard Disk Drive LED Connector
The pin assignment is as follows :
PIN ASSIGNMENT
9 HD_LED+
11 HD_LED-
2-10. ATX POWER BUTTON
JPANEL1 (14, 16) : ATX Power Button
The pin assignment is as follows :
PIN ASSIGNMENT
14 PW_BN1
16 PW_BN2
2-11. EXTERNAL SPEAKER CONNECTOR
JPANEL1 (1, 3, 5, 7) : External Speaker Connector
The pin assignment is as follows :
PIN ASSIGNMENT
1 P_SPK
3 NC
5 NC
7 VCC
Page: 2-12
′
PMB-531LF USER
S MANUAL
Chapter 2 Hardware Configuration
2-12. POWER LED CONNECTOR
JPANEL1 (8, 10, 12) : Power LED Connector
The pin assignment is as follows:
PIN ASSIGNMENT
8 PW_LED+
10 PW_LED+
12 PW_LED-
2-13. CLEAR CMOS DATA SELECTION
JP2 : Clear CMOS Data Selection
The selections are as follows :
FUNCTION
Keep CMOS 1-2
Clear CMOS 2-3
*** Manufacturing Default – Keep CMOS.
Note: To clear CMOS data, user must power-off the computer and set
the jumper to “Clear CMOS” as illustrated above. After five to
six seconds, set the jumper back to “Normal” and power-on the
computer.
PMB-531LF USER′S MANUAL
JUMPER SETTING
(pin closed)
JUMPER
ILLUSTRATION
Page: 2-13
Chapter 2 Hardware Configuration
2-14. CPU FAN CONNECTOR
FAN1 : CPU Fan connector
The pin assignment is as follows:
PIN ASSIGNMENT
1 LPC1_FANPWM1
2 +12V
3 LPC1_FANIO1
2-15. SYSTEM FAN CONNECTOR
FAN2：System Fan connector
The pin assignment is as follows：
PIN ASSIGNMENT
1 LPC1_FANPWM2
2 +12V
3 LPC1_FANIO2
JCFAN1：System Fan connector
The pin assignment is as follows：
PIN ASSIGNMENT
1 GND
2 +12V
3 NC
Page: 2-14
′
PMB-531LF USER
S MANUAL
Chapter 2 Hardware Configuration
2-16. HARD DISK DRIVE CONNECTOR
The PMB-531LF possesses one HDD connector: IDE1.
IDE1: Hard Disk Drive Connector
The pin assignments are as follows:
PIN ASSIGNMENT PIN ASSIGNMENT
1 IDERST 2 GND
3 PDD7 4 PDD8
5 PDD6 6 PDD9
7 PDD5 8 PDD10
9 PDD4 10 PDD11
11 PDD3 12 PDD12
13 PDD2 14 PDD13
15 PDD1 16 PDD14
17 PDD0 18 PDD15
19 GND 20 NC
21 PDREQ 22 GND
23 PDIOW# 24 GND
25 PDIOR# 26 GND
27 PIORDY 28 PD_CSEL
29 PDDACK# 30 GND
31 IRQ14 32 NC
33 PDA1 34 P66 DETECT
35 PDA0 36 PDA2
37 PDCS1# 38 PDCS3#
39 IDEACTN 40 GND
41 VCC 42 VCC
43 GND 44 GND
PMB-531LF USER′S MANUAL
Page: 2-15
Chapter 2 Hardware Configuration
2-17. VGA CONNECTOR
VGA1: VGA Connector
The pin assignments are as follows:
PIN ASSIGNMENT
1 RED
2 GREEN
3 BLUE
4 NC
5 GND
6 GND
7 GND
8 GND
9 VCC
10 GND
11 NC
12 VGA IIC DATA
13 HSYNC
14 VSYNC
15 VGA IIC CLK
Page: 2-16
′
PMB-531LF USER
S MANUAL
Chapter 2 Hardware Configuration
2-18. SERIAL ATA CONNECTOR
SATA1~SATA2: The PMB-531LF possesses two Serial ATA
Connector, SATA1~SATA2. The pin assignments are as follows:
SATA1：SATA Connector
The pin assignments are as follows：
PIN ASSIGNMENT
1 GND
2 SATA_TXP0
3 SATA_TXN0
4 GND
5 SATA_RXN0
6 SATA_RXP0
7 GND
SATA2：SATA Connector
The pin assignments are as follows：
PIN ASSIGNMENT
1 GND
2 SATA_TXP1
3 SATA_TXN1
4 GND
5 SATA_RXN1
6 SATA_RXP1
7 GND
PMB-531LF USER′S MANUAL
Page: 2-17
Chapter 2 Hardware Configuration
2-19. UNIVERSAL SERIAL BUS CONNECTOR
USB1：Universal Serial Bus Connector
The pin assignments are as follows：
PIN ASSIGNMENT
1 VCCUSB2
2 VCCUSB2
3 USB4N
4 USB5N
5 USB4P
6 USB5P
7 GND
8 GND
9 GND
10 GND
JUSB2：Universal Serial Bus Connector
The pin assignments are as follows：
PIN ASSIGNMENT
A1 VCCUSB1
A2 USB0N
A3 USB0P
A4 GND
B1 VCCUSB1
B2 USB1N
B3 USB1P
B4 GND
Page: 2-18
′
PMB-531LF USER
S MANUAL
2-20. USB&LAN CONNECTOR
J2：USB & LAN Connector
The pin assignments are as follows：
LAN:
PIN ASSIGNMENT
1 MDI_0P
2 MDI_0N
3 MDI_1P
4 MDI_1N
5 MDI_2P
6 MDI_2N
7 MDI_3P
8 MDI_3N
LAN LED Indicator:
Left side LED:
Green Color on 10/100 LAN Speed Indicator
Orange Color on Giga LAN Speed Indicator
off No LAN switch/hub connected
Right side LED:
Yellow Color Blinking LAN Message Active
off No LAN Message Active
USB Signal：
PIN ASSIGNMENT
A1 VCCUSB0
A2 USB2N
A3 USB2P
A4 GND
B1 VCCUSB0
B2 USB3N
B3 USB3P
B4 GND
PMB-531LF USER′S MANUAL
Chapter 2 Hardware Configuration
Page: 2-19
Chapter 2 Hardware Configuration
2-21. IRDA CONNECTOR
IRDA1: IrDA (Infrared) Connector
The pin assignments are as follows:
PIN ASSIGNMENT
1 +5V
2 NC
3 IRRX
4 GND
5 IRTX
2-22. ATX POWER CONNECTOR
PW1：ATX 12V Connector
The pin assignments are as follows：
PIN ASSIGNMENT
1 VCC
2 VCC
3 GND
4 GND
5 +12V
6 +5V SB
7 VCC
8 GND
9 PS_ON
10 NC
Page: 2-20
′
PMB-531LF USER
S MANUAL
ATXPWR2：ATX Connector
The pin assignments are as follows：
PIN ASSIGNMENT
1 GND
2 GND
3 +12V
4 +12V
2-23. SOUND CONNECTOR
JAUDIO1 : Sound Connector
The pin assignments are as follows：
SPDIF (inside the Line-In hole)
PIN ASSIGNMENT
42 GND
43 VCC
44 AC_SPDIF0
Line-In: light blue color
PIN ASSIGNMENT
32 LINE_L
35 LINE_R
SPK-Out: light green color
PIN ASSIGNMENT
22 SPK_L
25 SPK_R
Mic-In: pink color
PIN ASSIGNMENT
1 GND
2 MIC_IN1
5 MIC_IN2
Chapter 2 Hardware Configuration
PMB-531LF USER′S MANUAL
Page: 2-21
Chapter 2 Hardware Configuration
2-24. AUDIO CD-IN CONNECTOR
JCDIN1：Audio CD-In Connector
The pin assignments are as follows：
PIN ASSIGNMENT
1 CD L
2 CDGND
3 CDGND
4 CD R
2-25. LVDS CONNECTOR
J1：LVDS CONNECTOR
The pin assignments are as follows：
PIN ASSIGNMENT PIN ASSIGNMENT
Page: 2-22
1 LVDS_VCC 2 GND
3 CLKBM 4 CLKBP
5 GND 6 YBM2
7 YBP2 8 GND
9 YBM1 10 YBP1
11 NC 12 NC
13 YBP0 14 YBM0
15 GND 16 CLKAP
17 CLKAM 18 GND
19 YAP2 20 YAM2
21 GND 22 YAP1
23 YAM1 24 GND
25 YAP0 26 YAM0
27 NC 28 NC
29 LVDS_VCC 30 LVDS_VCC
PMB-531LF USER
′
S MANUAL
Chapter 2 Hardware Configuration
2-26. INVERTER CONNECTOR
J4：LVDS Panel Voltage Selection.
The pin assignments are as follows：
PIN ASSIGNMENT
1 +12V
2 GND
3 VCC
4 GND
5 ENABKL (Inverter backlight
ON/OFF control signal)
2-27. LVDS PANEL VOLTAGE SELECTION
JP4：LVDS Panel Voltage Selection.
The pin assignments are as follows：
SELECTION
JUMPER SETTING
(pin closed)
ILLUSTRATION
JUMPER
+3.3V
+5V
*** Manufacturing Default – +3.3V.
PMB-531LF USER′S MANUAL
1-3
2-4
3-5
4-6
Page: 2-23
Chapter 2 Hardware Configuration
2-28. FSB FREQUENCY SELECTION
JP5, JP6, JP7：FSB Frequency Selections.
The pin assignments are as follows：
*** Manufacturing Default – 667 MHz.
SELECTION
JUMPER SETTING
(pin closed)
JP5 JP6 JP7
533 MHz 2-3 2-3 2-3
667 MHz 2-3 open 2-3
JUMPER
ILLUSTRATION
Page: 2-24
′
PMB-531LF USER
S MANUAL
Chapter 2 Hardware Configuration
2-29. POWER STATE SELECTION
JP21(1-2), JP22：Power State Selections.
The pin assignments are as follows：
Selections Jumper Setting Jumper Illustrations
ATX
JP21 (Open)
JP22 (1-2)
JP21 (1-2)
AT
JP22 (2-3)
*** Manufacturing Default – ATX.
PMB-531LF USER′S MANUAL
Page: 2-25
Chapter 2 Hardware Configuration
2-30. RESET/ NMI SELECTIONS
JP21：Reset/ NMI Selections.
The pin assignments are as follows：
Selections Jumper Setting Jumper Illustration
RESET 3-4 CLOSE
NMI 5-6 CLOSE
CLEAR WDG 7-8 CLOSE
GPIO For
Customer
9-10
Application
*** Manufacturing Default – Reset.
Page: 2-26
′
PMB-531LF USER
S MANUAL
Chapter 2 Hardware Configuration
2-31. CF CARD MASTER/SLAVE SELECTIONS
JP14：CF Card Master/ Slave Selection.
The pin assignments are as follows：
Selections Jumper Setting Jumper Illustration
Master Close
Slave Open
*** Manufacturing Default – Slave.
PMB-531LF USER′S MANUAL
Page: 2-27
Chapter 2 Hardware Configuration
2-32. TV OUT CONNECTOR
JP1：TV OUT CONNECTOR
The pin assignments are as follows：
PIN ASSIGNMENT
1 Luminance(Y)
2 CVBS
3 GND
4 GND
5 Chrominance(UV)
2-33. MEMORY INSTALLATION
PMB-531LF CPU Card can support up to 1GB in one SODIMM sockets.
DRAM BANK CONFIGURATION
DIMM1 DIMM2 Total memory size
256 MB 256 MB 512 MB
512 MB 512 MB 1GB
1GB 1GB 2GB
Page: 2-28
′
PMB-531LF USER
S MANUAL
SOFTWARE
CHAPTER
UTILITIES
This chapter comprises the detailed information of VGA driver, LAN
driver, and Flash BIOS update. It also describes how to install the
watchdog timer configuration.
Section includes:
z VGA Driver Utility
z Flash BIOS Update
z LAN Driver Utility
z Sound Driver Utility
z Intel® Chipset Software Installation Utility
z USB2.0 Chipset Software Installation Utility
z RAID Software Installation Utility
z Watchdog Timer Configuration
3
Page: 3-1
Chapter 3 Software Configuration
3-1. INTRODUCTION
Enclosed with our PMB-531LF package is our driver utility, which may
comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc
user, you will only need some of the files contained in the CD ROM disc,
please kindly refer to the following chart:
Filename
(Assume that CD ROM drive is D:)
D:\Driver\VGA Intel 945GM
D:\Driver\FLASH For BIOS update utility
D:\Driver\LAN For LAN Driver installation
D:\Driver\Sound Realtel ALC655 AC97
D:\Driver\UTILITY Intel® Chipset Software
D:\Driver\USB 2.0 USB 2.0 Software Installation
D:\Driver\F6f1PY32 For RAID driver disk installation
D:\Driver\RAID RAID software and driver.
User should remember to install the Utility right after the OS fully installed.
Purpose
For VGA driver installation
For Sound driver installation
Installation Utility
For Win 2000, XP,Server2003
Utility
For Win 2000, XP
in F6
The RAID controller management
for windows 2000, XP, server
2003
Page:3-2
′
PMB-531LF USER
S MANUAL
3-2. VGA DRIVER UTILITY
The VGA interface embedded with our PMB-531LF can support a wide
range of display. You can display CRT, PCI-E (SDVO) simultaneously
with the same mode.
Chapter 3 Software Configuration
3-2-1. Installation of VGA Driver:
To install the VGA Driver, simply follow the following steps:
1. Place insert the Utility Disk into Floppy Disk Drive A/B or CD
ROM drive.
2. Under Windows 2000/XP/2003 system, go to the directory where
VGA driver is located.
3. Click Setup.exe file for VGA driver installation.
4. Follow the instructions on the screen to complete the installation.
5. Once installation is completed, shut down the system and restart in
order for the changes to take effect.
PMB-531LF USER′S MANUAL
Page:3-3
Chapter 3 Software Configuration
3-3. FLASH BIOS UPDATE
3-3-1. System BIOS Update:
Users of PMB-531LF can use the program “Awdflash.exe” contained in
the Utility Disk for system BIOS and VGA BIOS update.
3-3-2. To update VGA BIOS for LCD Flat Panel Display:
As PMB-531LF user, you have to update the VGA BIOS for your
specific LCD flat panel you are going to use. For doing this, you need
two files. One is the “Awdflash.exe” file and the other is the VGA BIOS
for ATI Rage Mobility M6 file for LCD panel display. Both file must be
provided by the vendor or manufacturer. When you get these two files
ready, follow the following steps for updating your VGA BIOS:
1. Install “Awdflash.exe” from Utility Disk to Drive C.
2. Insert the VGA BIOS file you have obtained from the vendor.
Type the path to Awdflash.exe and execute the VGA BIOS update
with file B531xxxx.bin
3. C:\UTIL\AWDFLASH>AWDFLASH B531xxxx.bin
4. The screen will display as the table fount on the next page:
FLASH MEMORY WRITER v7.XX
(C) Award Software 2001 All Rights Reserved
Flash Type – SST 49LF004A /3.3V
File Name to Program: B531xxxx.bin
Checksum: XXXXX
Page:3-4
Error Message: Do You Want To Save BIOS (Y/N)
PMB-531LF USER
′
S MANUAL
Chapter 3 Software Configuration
If you want to save up the original BIOS, enter "Y" and press < Enter >.
If you choose "N", the following table will appear on screen.
FLASH MEMORY WRITER v7.XX
(C) Award Software 2001 All Rights Reserved
Flash Type – SST 49LF004A /3.3V
File Name to Program: B531xxxx.bin
Checksum: XXXXX
Error Message : Are You Sure To Program (Y/N)
Select "Y", and the BIOS will be renewed. When you are refreshing th e
BIOS, do not turn off or reset the system, or you will damage the BIOS.
After you have completed all the programming, the screen displays the
table below:
FLASH MEMORY WRITER v7.XX
(C) Award Software 2001 All Rights Reserved
Flash Type – SST 49LF004A /3.3V
File Name to Program: B531xxxx.bin
Reset System or Power off to
F1: Reset F10: Exit
Please reset or power off the system, and then the Flash BIOS is fully
implemented.
PMB-531LF USER′S MANUAL
Checksum: XXXXX
accomplish update process!
Page:3-5
Chapter 3 Software Configuration
3-4. LAN DRIVER UTILITY
3-4-1. Introduction
PMB-531LF is enhanced with LAN function that can support various
network adapters. Installation programs for LAN drivers are listed as
follows:
For more details on Installation procedure, please refer to Readme.txt
file found on LAN DRIVER UTILITY.
Page:3-6
′
PMB-531LF USER
S MANUAL
3-5. SOUND DRIVER UTILITY
3-5-1. Introduction
The Realtek ALC655 sound function enhanced in this system is fully
compatible with Windows 2000 and Windows XP. Below, you will find
the content of the Sound driver :
Chapter 3 Software Configuration
3-5-2. Installation Procedure for Windows 2000/XP/2003
1. From the task bar, click on Start, and then Run.
2. In the Run dialog box, type D:\Sound\path\setup, where
“D:\Sound\pathname” refers to the full path to the source files.
3. Click on the OK button or press the ENTER key.
4. Click on the “Next” and OK prompts as they appear.
5. Reboot the system to complete the driver installation.
PMB-531LF USER′S MANUAL
Page:3-7
Chapter 3 Software Configuration
3-6. INTEL® C HIPSET SOFTWARE INSTALLATION UTILITY
3-6-1. Introduction
The Intel® Chipset Software Installation Utility installs to the target
system the Windows* INF files that outline to the operating system how
the chipset components will be configured. This is needed for the
proper functioning of the following features:
- Core PCI and ISAPNP Services
- AGP Support
- IDE/ATA33/ATA66/ATA100 Storage Support
- USB Support
- Identification of Intel® Chipset Components in Device Manager
3-6-2. Installation of Utility for Windows 2000/XP/2003
The Utility Pack is to be installed only for Windows 2000 and XP
program.
It should be installed right after the OS installation, kindly follow the
following steps:
1. Place insert the Utility Disk into Floppy Disk Drive A/B or CD
ROM drive.
2. Under Windows 2000/XP/2003 system, go to the directory where
Utility Disc is located.
3. Click Setup.exe file for utility installation.
4. Follow the instructions on the screen to complete the installation.
5. Once installation is completed, shut down the system and restart in
order for the changes to take effect.
Page:3-8
′
PMB-531LF USER
S MANUAL
Chapter 3 Software Configuration
3-7. USB2.0 SOFTWARE INSTALLATION UTILITY
3-7-1. Installation of Utility for Windows 2000/XP
Intel USB 2.0 Enhanced Host Controller driver can only be used on
Windows 2000 and Windows XP on Intel Desktop boards. It should be
installed right after the OS installation, kindly follow the following steps:
1. Place insert the Utility Disk into Floppy Disk Drive A/B or CD
ROM drive.
2. Under Windows 2000, and XP system, go to the directory where
Utility Disc is located.
3. Start the “System” wizard in control panel. (Click
Start/Settings/Control Panel).
4. Select “Hardware” and click “Device Manager ” button.
5. Double Click “USB Root Hub”.
6. Select “Driver”.
7. Click “Install” to install the driver.
8. Follow the instructions on the screen to complete the installation.
9. Click “Finish” after the driver installation is complete.
PMB-531LF USER′S MANUAL
Page:3-9
Chapter 3 Software Configuration
3-8. RAID SOFTWARE INSTALLATION UTILITY
3-8-1. Installation of Utility for Windows 2000/2003/XP
The RAID controller management can be used on windows 2000 and
windows 2003 and windows XP. It should be installed right after the OS
installation.
For more details on Installation procedure, please refer to Readme.txt
file found on RAID DRIVER UTILITY.
Page:3-10
′
PMB-531LF USER
S MANUAL
Chapter 3 Software Configuration
3-9. WATCHDOG TIMER CONFIGURATION
The Watch-dog Timer has a programmable time-out ranging from 1 to 255 minutes
with one minute resolution, or 1 to 255 seconds with 1 second resolution. The units of
the WDT timeout value are selected via bit[7] of the WDT_TIMEOUT register,
which is located on I/O Port address 0x865h. The WDT time-out value is set through
the WDT_VAL Runtime register, which is located on I/O Port address 0x866h.
Setting the WDT_VAL register to 0x00 disables the WDT function Setting the
WDT_VAL to any other non-zero value will cause the WDT to reload and begin
counting down from the value loaded. Setting the Register located on I/O address
0x867h and 0x868h as 00h to finish timer configuration.
Example Code
(1)
;-------------------------Enable Watch-Dog Timer
;--------------------------
mov dx,(800h + 65h) ;Time counting Unit minute or second
mov al,80h ;al = 00h : unit minute
;al = 80h : unit second
out dx,al
mov dx,(800h + 66h) ;
mov al,20 ;al = Watch dog Timer Second(s), 20 sec(s)
out dx,al
mov dx,(800h + 67h)
mov al,00h
out dx,al
mov dx,(800h + 68h) ;Start Watch Dog Timer
mov al,00h
out dx,al
(2)
;-------------------------Disable Watch-Dog Timer
;--------------------------
mov dx,(800h + 66h) ;Disable Watch Dog Timer
PMB-531LF USER′S MANUAL
Page:3-11
Chapter 3 Software Configuration
mov al,00h
out dx,al
mov dx,(800h + 67h)
mov al,00h
out dx,al
mov dx,(800h + 68h) ;Clear Status Bit
mov al,00h
out dx,al
Page:3-12
′
PMB-531LF USER
S MANUAL
CHAPTER
AWARD
BIOS SETUP
This chapter shows how to set up the Award BIOS.
Section includes:
z Introduction
z Entering Setup
z The Standard CMOS Features
z The Advanced BIOS Features
z The Advanced Chipset Features
z Integrated Peripherals
z Power Management Setup
z PNP/PCI Configuration
z PC Health Status
z Load Fail-Safe Defaults
z Load Optimized Defaults
z Password Setting
z Save and Exit Setup
z Exit Without Saving
4
Page: 4-1
Chapter 4 Award BIOS Setup
4-1. INTRODUCTION
This chapter will show you the function of the BIOS in managing the
features of your system. The PMB-531LF Intel Core Duo/Solo ATX
Motherboard is equipped with the BIOS for system chipset from Phoenix Award Software Inc. This page briefly explains the function of the BIOS in
managing the special features of your system. The following pages describe
how to use the BIOS for system chipset Setup menu.
Your application programs (such as word processing, spreadsheets, and
games) rely on an operating system such as DOS or OS/2 to manage such
things as keyboard, monitor, disk drives, and memory.
The operating system relies on the BIOS (Basic Input and Output system), a
program stored on a ROM (Read-only Memory) chip, to initialize and
configure your computer's hardware. As the interface between the hardware
and the operating system, the BIOS enables you to make basic changes to
your system's hardware without having to write a new operating system.
The following diagram illustrates the interlocking relationships between the
system hardware, BIOS, operating system, and application program:
Page: 4-2
′
PMB-531LF USER
S MANUAL
Chapter 4 Award BIOS Setup
4-2. ENTERING SETUP
When the system is powered on, the BIOS will enter the Power-On Self
Test (POST) routines and the following message will appear on the lower
screen:
PRESS <DEL> TO ENTER SETUP, ESC TO SKIP MEMORY TEST
As long as this message is present on the screen you may press the <Del>
key (the one that shares the decimal point at the bottom of the number
keypad) to access the Setup program. In a moment, the main menu of the
Award SETUP program will appear on the screen:
Phoenix - AwardBIOS CMOS Setup Utility
►Standard CMOS Features
►Advanced BIOS Features
►Advanced Chipset Features
►Integrated Peripherals
►Power Management Setup
►PnP/PCI Configurations
►PC Health Status
Esc : Quit ↑↓→← : Select Item
F10 : Save & Exit Setup
Time, Date, Hard Disk Type .…
Setup program initial screen
You may use the cursor the up/down keys to highlight the individual menu
items. As you highlight each item, a brief description of the highlighted
selection will appear at the bottom of the screen.
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
Set User Password
Save & Exit Setup
Exit Without Saving
PMB-531LF USER′S MANUAL
Page: 4-3
Chapter 4 Award BIOS Setup
4-3. THE STANDARD CMOS FEATURES
Highlight the〝STANDARD CMOS FEATURES〞and press the <ENTER>
key and the screen will display the following table:
Phoenix - AwardBIOS CMOS Setup Utility
Standard CMOS Features
Date (mm:dd:yy)
Time (hh:mm:ss)
▶ IDE Channel 0 Master
▶ IDE Channel 0 Slave
▶ IDE Channel 1 Master
▶ IDE Channel 1 Slave
▶ IDE Channel 2 Master
▶ IDE Channel 2 Slave
▶ IDE Channel 3 Master
▶ IDE Channel 3 Slave
Video
Halt On
Base Memory
Extended Memory
Total Memory
Sun, Feb
2 2003
21 : 3 : 7
[ST320014A]
[None]
[ None]
[ None]
[HDS728080PLA380]
[HDS728080PLA380]
[HDS728080PLA380]
[HDS728080PLA380]
[EGA/VGA]
[All Errors]
640K
2006912K
2087936K
Item Help
Menu Level ►
Change the day,
month, year and
century
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
CMOS Setup screen
In the above Setup Menu, use the arrow keys to highlight the item and then use
the <PgUp> or <PgDn> keys to select the value you want in each item.
Date:
< Month >, < Date > and <Year >. Ranges for each value are in the CMOS
Setup Screen, and the week-day will skip automatically.
Page: 4-4
′
PMB-531LF USER
S MANUAL
Time:
< Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM
numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the
time as 16:30:00.
IDE Primary Master / Slave:
IDE Secondary Master / Slave:
The BIOS can automatically detect the specifications and optimal operating
mode of almost all IDE hard drives. When you select type AUTO for a hard
drive, the BIOS detect its specifications during POST, every time system
boots.
If you do not want to select drive type AUTO, other methods of selecting
drive type are available:
1. Match the specifications of your installed IDE hard drive(s) with the
preprogrammed values for hard drive types 1 through 45.
2. Select USER and enter values into each drive parameter field.
3. Use the IDE HDD AUTO DETECTION function in Setup.
Here is a brief explanation of drive specifications:
Type: The BIOS contains a table of pre-defined drive types. Each
defined drive type has a specified number of cylinders, number of heads,
write precompensation factor, landing zone, and number of sectors.
Drives whose specifications do not accommodate any predefine type are
classified as type USER.
Chapter 4 Award BIOS Setup
• Size: Disk drive capacity (approximate). Note that this size is usually
greater than the size of a formatted disk given by a disk-checking
program.
• Cyls: number of cylinders.
• Head: number of heads.
• Precomp: write precompensation cylinders.
• Landz: landing zone.
• Sector: number of sectors.
• Mode: Auto, Normal, Large or LBA.
Auto: The BIOS automatically determines the optimal mode.
PMB-531LF USER′S MANUAL
Page: 4-5
Chapter 4 Award BIOS Setup
Normal: Maximum number of cylinders, heads, sectors
supported are 1024, 16 and 63.
Large: For drives that do not support LBA and have more
than 1024 cylinders.
LBA (Logical Block Addressing): During drive accesses, the
IDE controller transforms the data address described by
sector, head and cylinder number into a physical block
address, significantly improving data transfer rates. For
drives greater than 1024 cylinders.
VIDEO:
This category selects the type of video adapter used for the primary system
monitor. Although secondary monitors are supported, you do not have to
select the type in Setup. Available Options are as follows:
EGA/VGA Enhanced Graphics Adapter/Video Graphics Array.
For EGA, VGA, SEGA, SVGA or PGA monitor
adapters.
CGA 40 Color Graphics Adapter, power up in 40 column mode.
CGA 80 Color Graphics Adapter, power up in 80 column mode.
MONO Monochrome adapter, includes high resolution
monochrome adapters.
HALT ON:
This category allows user to choose whether the computer will stop if an error
is detected during power up. Available options are “All errors”, “No errors”,
“All, But keyboard”, “All, But Diskette”, and “All But Disk/Key”.
BASE MEMORY:
Displays the amount of conventional memory detected during boot up.
EXTENDED MEMORY:
Displays the amount of extended memory detected during boot up.
TOTAL MEMORY:
Displays the total memory available in the system.
Page: 4-6
′
PMB-531LF USER
S MANUAL
HARD DISK ATTRIBUTES:
Type Cylinders Heads V-P comp LZone Sect Capacity
1 306 4 128 305 17 10
2 615 4 300 615 17 20
3 615 6 300 615 17 30
4 940 8 512 940 17 62
5 940 6 512 940 17 46
6 615 4 65535 615 17 20
7 642 8 256 511 17 30
8 733 5 65535 733 17 30
9 900 15 65535 901 17 112
10 820 3 65535 820 17 20
11 855 5 65535 855 17 35
12 855 7 65535 855 17 49
13 306 8 128 319 17 20
14 733 7 65535 733 17 42
15 000 0 0000 000 00 00
16 612 4 0000 663 17 20
17 977 5 300 977 17 40
18 977 7 65535 977 17 56
19 1024 7 512 1023 17 59
20 733 5 300 732 17 30
21 733 7 300 732 17 42
22 733 5 300 733 17 30
23 306 4 0000 336 17 10
24 977 5 65535 976 17 40
25 1024 9 65535 1023 17 76
26 1224 7 65535 1223 17 71
27 1224 11 65535 1223 17 111
28 1224 15 65535 1223 17 152
29 1024 8 65535 1023 17 68
30 1024 11 65535 1023 17 93
31 918 11 65535 1023 17 83
32 925 9 65535 926 17 69
33 1024 10 65535 1023 17 85
34 1024 12 65535 1023 17 102
35 1024 13 65535 1023 17 110
36 1024 14 65535 1023 17 119
37 1024 2 65535 1023 17 17
38 1024 16 65535 1023 17 136
39 918 15 65535 1023 17 114
40 820 6 65535 820 17 40
41 1024 5 65535 1023 17 42
42 1024 5 65535 1023 26 65
43 809 6 65535 852 17 40
44 809 6 65535 852 26 61
45 776 8 65335 775 33 100
47 AUTO
Chapter 4 Award BIOS Setup
Award Hard Disk Type Table
PMB-531LF USER′S MANUAL
Page: 4-7
Chapter 4 Award BIOS Setup
4-4. THE ADVANCED BIOS FEATURES
Choose the〝ADVANCED BIOS FEATURES〞in the main menu, the screen
shown as below.
Phoenix - AwardBIOS CMOS Setup Utility
Advanced BIOS Features
▶ CPU Feature
▶ Hard Disk Boot Priority
First Boot Device
Second Boot Device
Third Boot Device
Boot Other Device
Security Option
APIC Mode
MPS Version Control For OS
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
BIOS Features Setup Screen
The “BIOS FEATURES SETUP” allow you to configure your system for
basic operation. The user can select the system’s boot-up sequence and
security.
A brief introduction of each setting is given below.
[Press Enter]
[Press Enter]
[CDROM]
[Hard Disk]
[LS120]
[Enabled]
[Setup]
[Enabled]
[1.4]
Item Help
Menu Level ►
Page: 4-8
′
PMB-531LF USER
S MANUAL
CPU FEATURE:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
Delay Prior to Thermal
Thermal Management
X TM2 Bus Ratio
X TM2 Bus VID
C1E Function
Execute Disable Bit
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Descriptions on each item above are as follows:
1. Delay Prior to Thermal
The Delay Prior To Thermal BIOS feature controls the activation of
the Thermal Monitor's automatic mode. It allows you to determine
when the Pentium-M’s Thermal Monitor should be activated in
automatic mode after the system boots.
2. Thermal Management
The used Thermal Monitor
3. C1E Function
This is enabled to reduce power during idle operation
4. Execute Disable Bit
To select enable or disable the No-Execution Page Protection
Technology.
Chapter 4 Award BIOS Setup
Phoenix – Award CMOS Setup Utility
CPU Feature
[16 Min]
[Thermal Monitor 1]
12X
1.404V
[Auto]
[Enabled]
Item Help
Menu Level ►
PMB-531LF USER′S MANUAL
Page: 4-9
Chapter 4 Award BIOS Setup
HARD DISK BOOT PRIORITY:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
Phoenix – Award CMOS Setup Utility
Hard Disk Boot Priority
1. Ch0 M. : ST320014A
2. CH2 M. : HDS728080PLA380
3. CH3 M. : HDS728080PLA380
4. CH2 S. : HDS728080PLA380
5. CH3 S. : HDS728080PLA380
6. Bootable Add-in Cards
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Select Hard Disk Boot Device Priority
FIRST/SECOND/ THIRD/ OTHER BOOT DEVICE:
The BIOS attempt to load the operating system from the devices in the
sequence selected in these items.
SECURITY OPTION:
This category allows you to limit access to the system and Setup, or just to
Setup.
System The system will not boot and access to Setup will be
denied if the correct password is not entered at the
prompt.
Setup The system will boot, but access to Setup will be
denied if the correct password is not entered at the
prompt.
To disable security, select PASSWORD SETTING at Main Menu and
then you will be asked to enter password. Do not type anything and just
press <Enter>, it will disable security. Once the security is disabled, the
system will boot and you can enter Setup freely.
Page: 4-10
Item Help
Menu Level ►
Use<Ç> or <È> to select a
device, then press <+> to move
it up, or <-> to move it down
the list. Press <ESC> to exit
this menu.
′
PMB-531LF USER
S MANUAL
Chapter 4 Award BIOS Setup
APIC MODE:
To Enable Advanced Programmable Interrupt Controller
MPS VERSION CONTROL FOR OS:
This option is only valid for multiprocessor motherboards as it specifies the
version of the Multiprocessor Specification (MPS) that the motherboard will
use. The MPS is a specification by which PC manufacturers design and build
Intel architecture systems with two or more processors.
4-5. ADVANCED CHIPSET FEATURES
Choose the〝ADVANCED CHIPSET FEATURES〞from the main menu,
the screen shown as below.
Phoenix - AwardBIOS CMOS Setup Utility
Advanced Chipset Features
DRAM Timing Selectable
X CAS Latency Time
X DRAM RAS# to CAS# Delay
X DRAM RAS# Precharge
X Precharge dealy (tRAS)
System Memory Frequency
System BIOS Cacheable
Video BIOS Cacheable
Memory Hole At 15M-16M
** VGA Setting **
PEG/Onchip VGA Control
On-Chip Frame Buffer Size
DVMT Mode
DVMT/ FIXED Memory Size
Boot Display
Panel Type
TV Format
PCI SERR# NMI
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
Chipset Features Setup Screen
[By SPD]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
[Disabled]
[Disabled]
[Auto]
[8MB]
[DVMT]
[128 MB]
[CRT]
[640x480 18-bit]
[Auto]
[Disabled]
Item Help
Menu Level ►
PMB-531LF USER′S MANUAL
Page: 4-11
Chapter 4 Award BIOS Setup
This parameter allows you to configure the system based on the specific
features of the installed chipset. The chipset manages bus speed and
access to system memory resources, such as DRAM and the external cache.
It also coordinates communications between conventional ISA bus and the
PCI bus. It must be stated that these items should never need to be altered.
The default settings have been chosen because they provide the best operating conditions for the system. The only time you might consider making
any changes would be if you discovered that data was being lost while
using your system.
DRAM TIMEING SELECTABLE:
The value in this field depends on performance parameters of the installed
memory chips (DRAM). Do not change the value from the factory setting
unless you install new memory that has a different performance rating than
the original DRAMs.
CAS LATENCY TIME:
When synchronous DRAM is installed, the number of clock cycles of CAS
latency depends on the DRAM timing.
DRAM RAS# TO CAS# DELAY:
This item let you insert a timing delay between the CAS and RAS strobe
signals, used when DRAM is written to, read from, or refreshed. Fast
gives faster performance; and Slow gives more stable performance. This
field applies only when synchronous DRAM is installed in the system.
The choices are 2 and 3.
DRAM RAS# PRECHARGE TIME:
If an insufficient number of cycles is allowed for the RAS to accumulate its
charge before DRAM refresh, the refresh may be incomplete and the DRAM
may fail to retain data. Fast gives faster performance; and Slow gives more
stable performance. This field applies only when synchronous DRAM is
installed in the system. The choices are 2 & 3.
PRECHARGE DEALY (tRAS):
Precharge Delay This setting controls the precharge delay, which
determines the timing delay for DRAM precharge
System Memory Frequency:
Allow to choose different frequency of memory module.
Page: 4-12
′
PMB-531LF USER
S MANUAL
SYSTEM BIOS CACHEABLE:
Selecting Enabled allows caching of the system BIOS ROM at F0000hFFFFFh, resulting in better system performance. However, if any program
writes to this memory area, a system error may result.
VIDEO BIOS CACHEABLE:
Select Enabled allows caching of the video BIOS, resulting in better system
performance. However, if any program writes to this memory area, a system
error may result.
MEMORY HOLE AT 15-16M:
You can reserve this area of system memory for ISA adapter ROM. When
this area is reserved, it cannot be cached. The user information of
peripherals that need to use this area of system memory usually discusses their
memory requirements
PEG/ONCHIP VGA CONTROL:
To select the PCI-Express Graphics or onchip VGA Graphics.
ON-CHIP FRAME BUFFER SIZE:
The On-Chip Frame Buffer Size can be set as 32MB. This memory is shared
with the system memory.
DVMT MODE:
Intel Dynamic Video Memory Technology Mode.
DVMT/FIXED MEMORY SIZE:
DVMT Memory Size Select.
BOOT DISPLAY:
To select the boot-up display type.
Panel Type:
This field allows user to decide the LVDS panel resolution
TV FORMAT:
To select TV-Format type
PCI SERR# NMI:
To Enable/Disable the PCI SERR# interrupt
PMB-531LF USER′S MANUAL
Chapter 4 Award BIOS Setup
Page: 4-13
Chapter 4 Award BIOS Setup
4-6. INTEGRATED PERIPHERALS
Choose〝INTEGRATED PERIPHERALS〞from the main setup menu, a
display will be shown on screen as below:
Phoenix - AwardBIOS CMOS Setup Utility
Integrated Peripherals
X OnChip IDE Device
X Onboard Device
X SuperIO Device
Onboard Serial Port 3
Onboard Serial Port 4
WatchDog Support
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
Integrated Peripherals Setup Screen
By moving the cursor to the desired selection and by pressing the <F1> key,
the all options for the desired selection will be displayed for choice.
If bios setup menu item supports USB device boot, it will cause Win9x detects
the same storages twice when the system is rebooted, and USB HDD will fail.
Note: this cause just happen under Win9x, the phenomenon is a limitation.
[Press Enter]
[Press Enter]
[Press Enter]
[3E8/IRQ10]
[2E8/IRQ11]
[Disabled]
Item Help
Menu Level ►
Page: 4-14
′
PMB-531LF USER
S MANUAL
ONCHIP IDE DEVICE:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
Chapter 4 Award BIOS Setup
Phoenix – Award CMOS Setup Utility
OnChip IDE Device
IDE HDD Block Mode
IDE DMA transfer access
OnChip Primary PCI IDE
IDE Primary Master PIO
IDE Primary Slave PIO
IDE Primary Master UDMA
IDE Primary Slave UDMA
OnChip Secondary PCI IDE
IDE Secondary Master PIO
IDE Secondary Slave PIO
IDE Secondary Master UDMA
IDE Secondary Slave UDMA
*** On-Chip Serial ATA Setting ***
SATA Mode
On-Chip Serial ATA
X PATA IDE Mode
SATA Port
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Descriptions on each item above are as follows:
1. IDE HDD Block Mode
Block mode is also called block transfer, multiple commands, or
multiple sector read/write. If your IDE hard drive supports block mode
(most new drives do), select Enabled for automatic detection of the
optimal number of block read/writes per sector the drive can support
2. IDE DMA Transfer Access
To Enable/Disable the IDE DMA transfer access
3. OnChip Primary PCI IDE
The integrated peripheral controller contains an IDE interface with
support for two IDE channels. Select Enabled to activate each channel
separately.
4. Primary Master/Slave PIO
PMB-531LF USER′S MANUAL
[Enabled]
[Enabled]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[IDE]
[Auto]
Primary
P1, P3 is Secondary
Item Help
Menu Level ►
If your IDE hard
drive supports
block mode select
Enabled for
automatic
detection of the
optional number
of block
read/writes per
sector the drive
can support.
Page: 4-15
Chapter 4 Award BIOS Setup
Secondary Master/Slave PIO
The four IDE PIO fields allow you to set a PIO mode (0-4) for each of
the four IDE devices that the onboard IDE interface supports. Modes
0 through 4 provide successively increased performance. In Auto
mode, the system automatically determines the best mode for each
device.
5. SATA Mode:
Set the Serial ATA configuration. When set in Advanced Host
Controller Interface (AHCI) or RAID mode, the SATA controller is
set to Native mode. Configuration options: [IDE] [RAID] [AHCI].
6. Primary Master/Slave UDMA
Secondary Master/Slave UDMA
Ultra DMA/33 implementation is possible only if your IDE hard drive
supports it and the operating environment includes a DMA driver
(Windows 95 OSR2 or a third-party IDE bus master driver). If you
hard drive and your system software both support Ultra DMA/33,
select Auto to enable BIOS support.
7. On-Chip Serial ATA:
[Disabled]: Disabled SATA Controller.
[Auto]: Auto arrange by BIOS.
[Combined Mode]: PATA and SATA are combined. Max.of 2 IDE
drives in each channel.
[Enhanced Mode]: Enable both SATA and PATA. Max.of 6 IDE drives
are supported.
[SATA Only]: SATA is operating in legacy mode.
8. PATA IDE Mode
To select PATA IDE Mode sequence
9. SATA Port
According PATA IDE Mode to determine SATA sequence
Page: 4-16
′
PMB-531LF USER
S MANUAL
ONBOARD DEVICE:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
USB Controller
USB 2.0 Controller
USB Keyboard Support
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Descriptions on each item above are as follows:
1. USB Controller
This should be enabled if your system has a USB installed on the
system board and you want to use it. Even when so equipped, if you
add a higher performance controller, you will need to disable this
feature.
2. USB 2.0 Controller
Enable the USB 2.0 controller
3. USB Keyboard Support
Select Enabled if your system contains a Universal Serial Bus (USB)
controller and you have a USB keyboard.
Chapter 4 Award BIOS Setup
Phoenix – Award CMOS Setup Utility
Onboard Device
[Enabled]
[Enabled]
[Enabled]
Item Help
Menu Level ►
PMB-531LF USER′S MANUAL
Page: 4-17
Chapter 4 Award BIOS Setup
SUPER IO DEVICE:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
Phoenix – Award CMOS Setup Utility
Onboard Serial Port 1
Onboard Serial Port 2
UART Mode Select
TxD, RxD Polarity Active
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Descriptions on each item above are as follows:
1. Onboard Serial Port 1/2
Select an address and corresponding interrupt for the first and second
serial ports.
2. UART Mode Select
This item allows you to select UART mode.
3. TxD, RxD Polarity Active
This item allows you to determine the active of RxD, TxD
ONBOARD SERIAL PORT 3:
ONBOARD SERIAL PORT 4:
Select a logical COM port name and matching address for the third and
forth serial ports. Select an address and corresponding interrupt for third
and forth serial port.
WATCHDOG SUPPORT:
To select watch-dog times.
SuperIO Device
[3F8/IRQ4]
[2F8/IRQ3]
[Normal]
[Lo, Hi]
Item Help
Menu Level ►
Page: 4-18
′
PMB-531LF USER
S MANUAL
4-7. POWER MANAGEMENT SETUP
Choose〝POWER MANAGEMENT SETUP〞option on the main menu, a
display will be shown on screen as below :
Phoenix - AwardBIOS CMOS Setup Utility
Power Management Setup
ACPI Function
Video Off In Suspend
Soft-Off by PWR-BTTN
PWRON After PWR-Fail
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
Power Management Setup Screen
The “Power Management Setup” allows the user to configure the system to
the most effectively save energy while operating in a manner consistent with
your own style of computer use.
ACPI FUNCTION:
Users are allowed to enable or disable the Advanced Configuration and
Power Management (ACPI).
SOFT-OFF BY PWR-BTTN:
Pressing the power button for more than 4 seconds forces the system to
enter the Soft-Off state when the system has “hung”. The choices are
Delay 4 Sec and Instant-Off.
PWRON AFTER PWR-FAIL:
This item allows you to select if you want to power on the system after
power failure. The choice: Off and On
[Enabled]
[Yes]
[Instant-Off]
[Off]
Chapter 4 Award BIOS Setup
Item Help
Menu Level ►
PMB-531LF USER′S MANUAL
Page: 4-19
Chapter 4 Award BIOS Setup
4-8. PNP/PCI CONFIGURATION
Choose 〝PNP/PCI CONFIGURATION〞 from the main menu, a display
will be shown on screen as below:
Phoenix - AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
Init Display First
Reset Configuration Data
Resources Controlled By
x IRQ Resources
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
[PCI Slot]
[Disabled]
[Auto (ESCD)]
PNP/PCI Configuration Setup Screen
The PNP/PCI Configuration Setup describes how to configure PCI bus system.
PCI, also known as Personal Computer Interconnect, is a system, which
allows I/O devices to operate at speeds nearing the speed of the CPU itself
uses when communicating with its own special components.
This section covers technical items, which is strongly recommended for
experienced users only.
INIT DISPLAY FIRST:
This item allows you to decide to active whether PCI Slot or on-chip VGA
first.
RESET CONFIGURATION DATA:
Normally, you leave this field Disabled. Select Enabled to reset Extended
System Configuration Data (ESCD) when you exit Setup if you have
installed a new add-on and the system configuration has caused such a
serious conflict that the operating system cannot boot.
RESOURCE CONTROLLED BY:
The Award Plug and Play Bios can automatically configure all of the booth
and Plug and Play-compatible devices. However, this capability means
absolutely nothing unless you are using a Plug and Play operating system
Page: 4-20
Press Enter
Item Help
Menu Level ►
PMB-531LF USER
′
S MANUAL
such as Windows 95. By choosing “manual”, you are allowed to
configure the IRQ Resources and DMA Resources.
IRQ RESOURCES:
The options for these items are found in its sub menu. By pressing the
<ENTER> key, you are prompt to enter the sub menu of the detailed options
as shown below:
IRQ-3 assigned to
IRQ-4 assigned to
IRQ-5 assigned to
IRQ-7 assigned to
IRQ-9 assigned to
IRQ-10 assigned to
IRQ-11 assigned to
IRQ-12 assigned to
IRQ-14 assigned to
IRQ-15 assigned to
↑↓→←:Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Descriptions on each item above are as follows:
1. IRQ-n Assigned to:
You may assign each system interrupt a type, depending on the type of
device using the interrupt.
Chapter 4 Award BIOS Setup
Phoenix – Award CMOS Setup Utility
IRQ Resources
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
[PCI Device]
Menu Level ►
Legacy ISA for devices
compliant with the original PC
AT bus specification, PCI/ISA
PnP for devices compliant
with the Plug and Play
standard whether designed for
PCI or ISA bus architecture
Item Help
PMB-531LF USER′S MANUAL
Page: 4-21
Chapter 4 Award BIOS Setup
4-9. PC HEALTH STATUS
Choose 〝PC HEALTH STATUS〞 from the main menu, a display will
be shown on screen as below:
Phoenix - AwardBIOS CMOS Setup Utility
Shutdown Temperature
Current CPU Temerature
Vcore
5V
12V
Fan1 Speed
Fan2 Speed
↑↓→←: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
The PC Health Status Setup allows you to select whether to choose between
monitoring or to ignore the hardware monitoring function of your system.
SHUTDOWN TEMPERATURE:
This item allows you to set up the CPU shutdown Temperature.
CURRENT CPU TEMPERATURE:
This item shows you the current CPU temperature.
VCORE:
This item shows you the current system voltage.
5V / 12V :
Show you the voltage of5V/12V.
FAN1/FAN2 SPEED:
This item shows you the current CPU/ SYSTEM FAN speed.
PC Health Status Setup Screen
PC Health Status
[Disabled]
40 C
1.36V
5.01V
12.35V
0 RPM
0 RPM
Item Help
Menu Level ►
Page: 4-22
′
PMB-531LF USER
S MANUAL
4-10. LOAD FAIL-SAFE DEFAULTS
By pressing the <ENTER> key on this item, you get a confirmation dialog
box with a message similar to the following:
Load Fail-Safe Defaults ( Y/N ) ? N
To use the BIOS default values, change the prompt to "Y" and press the
<Enter > key. CMOS is loaded automatically when you power up the
system.
4-11. LOAD OPTIMIZED DEFAULTS
When you press <Enter> on this category, you get a confirmation dialog
box with a message similar to the following:
Load Optimized Defaults ( Y/N ) ? N
Pressing "Y" loads the default values that are factory setting for optimal
performance system operations.
Chapter 4 Award BIOS Setup
PMB-531LF USER′S MANUAL
Page: 4-23
Chapter 4 Award BIOS Setup
4-12. PASSWORD SETTING
User is allowed to set either supervisor or user password, or both of them.
The difference is that the supervisor password can enter and change the
options of the setup menus while the user password can enter only but do not
have the authority to change the options of the setup menus.
TO SET A PASSWORD
When you select this function, the following message will appear at the
center of the screen to assist you in creating a password.
Enter Password:
Type the password up to eight characters in length, and press < Enter >.
The password typed now will clear any previously entered password from
CMOS memory. You will be asked to confirm the password. Type the
password again and press the < Enter > key. You may also press < Esc >
to abort the selection and not enter a password.
User should bear in mind that when a password is set, you will be
asked to enter the password everything you enter CMOS setup Menu.
TO DISABLE THE PASSWORD
To disable the password, select this function (do not enter any key when
you are prompt to enter a password), and press the <Enter> key and a
message will appear at the center of the screen:
Press the < Enter > key again and the password will be disabled. Once the
password is disabled, you can enter Setup freely.
Page: 4-24
PASSWORD DISABLED!!!
Press any key to continue...
PMB-531LF USER
′
S MANUAL
4-13. SAVE & EXIT SETUP
After you have completed adjusting all the settings as required, you must
remember to save these setting into the CMOS RAM. To save the settings,
select “SAVE & EXIT SETUP” and press <Enter>, a display will be shown
as follows:
Phoenix - AwardBIOS CMOS Setup Utility
►Standard CMOS Features
►Advanced BIOS Features
►Advanced Chipset Features
►Integrated Peripherals
►Power Management
►PnP/PCI Configura
►PC Health Status
Esc : Quit ↑↓→← : Select Item
F10 : Save & Exit Setup
When you confirm that you wish to save the settings, your system will be
automatically restarted and the changes you have made will be implemented.
You may always call up the setup program at any time to adjust any of the
individual items by pressing the <Del> key during boot up.
Save to CMOS and EXIT Y/N)? Y
Chapter 4 Award BIOS Setup
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
word
etup
Saving
Save Data to CMOS
PMB-531LF USER′S MANUAL
Page: 4-25
Chapter 4 Award BIOS Setup
4-14. EXIT WITHOUT SAVING
If you wish to cancel any changes you have made, you may select the
“EXIT WITHOUT SAVING” and the original setting stored in the CMOS
will be retained. The screen will be shown as below:
Phoenix - AwardBIOS CMOS Setup Utility
►Standard CMOS Features
►Advanced BIOS Features
►Advanced Chipset Features
►Integrated Peripherals
►Power Management
►PnP/PCI Configura
►PC Health Status
Esc : Quit ↑↓→← : Select Item
F10 : Save & Exit Setup
Quit Without Saving (Y/N)? N
Abandon all Datas
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
word
etup
Saving
Page: 4-26
′
PMB-531LF USER
S MANUAL
APPENDIX
EXPANSION BUS
This appendix indicates the pin assignments.
Section includes:
z Mini-PCI BUS Pin Assignment
z Compact Flash Card Connector Pin Assignment
A
Page: A-1
Appendix A Expansion Bus
MINI-PCI BUS CONNECTOR PIN ASSIGNMENT
You will find a Mini-PCI connector in our PMB-531LF.
The pin assignments are as follows:
PIN ASSIGNMENT PIN ASSIGNMENT
1 NC 2 NC
3 NC 4 NC
5 NC 6 NC
7 NC 8 NC
9 NC 10 NC
11 NC 12 NC
13 NC 14 NC
15 NC 16 NC
17 PIRQJD 18 VCC
19 VCC3_3 20 PIRQJC
21 NC 22 NC
23 GND 24 VCC3_3SB
25 PPCLK 26 PCI_RSTJ
27 GND 28 VCC3_3
29 PREQJ2 30 PGNTJ2
31 VCC3_3 32 GND
33 AD31 34 PMEJ
35 AD29 36 NC
37 GND 38 AD30
39 AD27 40 VCC3_3
41 AD25 42 AD28
43 NC 44 AD26
45 C_BEJ3 46 AD24
47 AD23 48 IDSEL
49 GND 50 GND
51 AD21 52 AD22
53 AD19 54 AD20
55 GND 56 PAR
57 AD17 58 AD18
59 C_BEJ2 60 AD16
61 IRDYJ 62 GND
63 VCC3_3 64 FRAMEJ
65 NC 66 TRDYJ
67 SERRJ 68 STOPJ
69 GND 70 VCC3_3
Page: A-2
′
PMB-531LF USER
S MANUAL
Appendix A Expansion Bus
71 PERRJ 72 DEVSELJ
73 C_BEJ1 74 GND
75 AD14 76 AD15
77 GND 78 AD13
79 AD12 80 AD11
81 AD10 82 GND
83 GND 84 AD9
85 AD8 86 C_BEJ0
87 AD7 88 VCC3_3
89 VCC3_3 90 AD6
91 AD5 92 AD4
93 NC 94 AD2
95 AD3 96 AD0
97 VCC 98 NC
99 AD1 100 NC
101 GND 102 GND
103 NC 104 NC
105 NC 106 NC
107 NC 108 NC
109 NC 110 NC
111 NC 112 NC
113 NC 114 GND
115 NC 116 NC
117 NC 118 NC
119 NC 120 NC
121 NC 122 NC
123 NC 124 NC
PMB-531LF USER′S MANUAL
Page: A-3
Appendix A Expansion Bus
COMPACT FLASH CARD CONNECTOR PIN ASSIGNMENT
The pin assignments of Compact Flash Card connector are stated below.
PIN ASSIGNMENT PIN Assignment
1 GND 26 -CD1
2 D03 27 D11
3 D04 28 D12
4 D05 29 D13
5 D06 30 D14
6 D07 31 D15
7 -CS0 32 -CS1
8 A10 33 -VS1
9 -ATASEL 34 -IORD
10 A09 35 -IOWR
11 A08 36 -WE
12 A07 37 IRQ14
13 VCC 38 VCC
14 A06 39 -CSEL
15 A05 40 -VS2
16 A04 41 -RESET
17 A03 42 IORDY
18 A02 43 -INPACK
19 A01 44 -REG3
20 A00 45 -DASP
21 D00 46 -PDIAG
22 D01 47 D08
23 D02 48 D09
24 -IOCS16 49 D10
25 -CD2 50 GND
Page: A-4
′
PMB-531LF USER
S MANUAL
TECHNICAL
SUMMARY
This section introduce you the maps concisely.
Section includes:
z Block Diagram
z Interrupt Map
z RTC & CMOS RAM Map
z Timer & DMA Channels Map
z I / O & Memory Map
APPENDIX
B
Page: B-1
Appendix B Technical Summary
BLOCK DIAGRAM
Page: B-2
′
PMB-531LF USER
S MANUAL
INTERRUPT MAP
IRQ ASSIGNMENT
0 System TIMER
1 Keyboard
2 Cascade
3 Serial port 2
4 Serial port 1
5 Available
6 Floppy
7 Parallel port 1
8 RTC clock
9 Available
10 Available
11 Available
12 PS/2 Mouse
13 Math coprocessor
14 IDE1
15 IDE2
Appendix B Technical Summary
PMB-531LF USER′S MANUAL
Page: B-3
Appendix B Technical Summary
RTC & CMOS RAM MAP
CODE ASSIGNMENT
00 Seconds
01 Second alarm
02 Minutes
03 Minutes alarm
04 Hours
05 Hours alarm
06 Day of week
07 Day of month
08 Month
09 Year
0A Status register A
0B Status register B
0C Status register C
0D Status register D
0E Diagnostic status byte
0F Shutdown byte
10 Floppy Disk drive type byte
11 Reserve
12 Hard Disk type byte
13 Reserve
14 Equipment byte
15 Base memory low byte
16 Base memory high byte
17 Extension memory low byte
18 Extension memory high byte
30 Reserved for extension memory low byte
31 Reserved for extension memory high byte
32 Date Century byte
33 Information Flag
34-3F Reserve
40-7f Reserved for Chipset Setting Data
Page: B-4
′
PMB-531LF USER
S MANUAL
TIMER & DMA CHANNELS MAP
Timer Channel Map
Timer Channel Assignment
0 System timer interrupt
1 DRAM Refresh request
2 Speaker tone generator
DMA Channel Map
DMA Channel Assignment
0 Available
1 Available
2 Floppy
3 Available
4 Cascade
5 Available
6 Available
7 Available
:
:
Appendix B Technical Summary
PMB-531LF USER′S MANUAL
Page: B-5
Appendix B Technical Summary
I/O & MEMORY MAP
Memory Map :
MEMORY MAP ASSIGNMENT
0000000-009FFFF System memory used by DOS and
application
00A0000-00BFFFF Display buffer memory for VGA/ EGA /
CGA / MONOCHROME adapter
00C0000-00DFFFF Reserved for I/O device BIOS ROM or
RAM buffer.
00E0000-00EFFFF Reserved for PCI device ROM
00F0000-00FFFFF System BIOS ROM
0100000-FFFFFFF System extension memory
I/O Map :
I/O MAP ASSIGNMENT
000-01F DMA controller (Master)
020-021 Interrupt controller (Master)
022-023 Chipset controller registers I/O ports.
040-05F Timer control regsiters.
060-06F Key board interface controller (8042)
070-07F RTC ports & CMOS I/O ports
080-09F DMA register
0A0-0BF Interrupt controller (Slave)
0C0-0DF DMA controller (Slave)
0F0-0FF Math coprocessor
1F0-1F8 Hard Disk controller
278-27F Parallel port-2
2B0-2DF Graphics adapter controller
2F8-2FF Serial port-2
360-36F Net work ports
378-37F Parallel port-1
3B0-3BF Monochrome & Printer adapter
3C0-3CF EGA adapter
3D0-3DF CGA adapter
3F0-3F7 Floppy disk controller
3F8-3FF Serial port-1
Page: B-6
′
PMB-531LF USER
S MANUAL
Loading...
