Mainboard PM945GC(V2.0)

Chapter 1. Getting Started

Introduction

Thanks for choosing PM945GC(V2.0) Mainboard. It is based on Intel® 945GC Northbridge chipset and Intel Media Accelerator 950 for onboard graphics feature. It supports Intel Pentium

aforementioned processors must be rated at 65W or less)

1333 MHz (by overclocking)/ 1066 MHz (by overclocking)/ 800 MHz/ 533 MHz.

The PM945GC(V2.0) provides two DIMM (Dual In-Line Memory Modules) sockets which allowing you to install 240-pin, unbuffered non-ECC, DDRII 667 (by overclocking)/ DDRII 533 SDRAMs. It also supports Dual Channel Technology and allows you installing a total memory capacity of 4 GB.

This mainboard provides one PCI-Express interface slot up to x16 mode which is recommended that insert a graphics card onto the PCI-Espress x16 slot. In addition, two standard PCI slots for use with standard PCI expansion cards are also allowed.

The PM945GC(V2.0) provides one floppy disk drive connector that can be used with 360KB/720KB/1.2MB/1.44MB/2.88MB drives. It also has one IDE connector for IDE hard drives supporting Ultra ATA 100/66/33. Moreover, this mainboard comes with Serial ATA II support with four SATA II connectors which provide up to 3 Gbps data transfer rates.

The onboard High Definition Audio CODEC (ALC662) supports high quality performance 6-channel audio play <See Appendix I>. The mainboard also supports the Sony/Philips Digital Interfaces (S/PDIF) output function (optional).

The PM945GC(V2.0) also comes with an onboard 10/100 Mbps Ethernet LAN chip. There is a LAN port on the back panel of your case that you can directly plug into an Internet cable.

There are maximal eight USB2.0/ 1.1 ports which can be set up on this mainboard.

All the information (including hardware installation and software installation) in this manual are for reference only. The contents in this manual may be updated without notice. The company will not assume any responsibility for any errors or mistakes within.

ICH7 Southbridge chipset. In addition, it also supports integrated Graphics

CoreTM 2 Duo/

D/ Pentium® 4/ Celeron® D/ Celeron® Processors (The power consumption for the

with FSB (Front Side Bus) frequencies of

Mainboard PM945GC(V2.0)

Specification

CPU:

 Support Socket 775

 Support Intel

Processors (The power consumption for the aforementioned processors must be rated at 65W or less.)

 Support Hyper-Threading Technology

 Support 1333 MHz (by overclocking)/ 1066 MHz (by overclocking)/ 800 MHz/ 533 MHz

FSB (Front Side Bus) Frequencies

Chipset:

 Northbridge Chipset – Intel® 945GC

 Southbridge Chipset – Intel

 I/O Controller –Fintek

 High Definition Audio Codec – Realtek

 LAN Controller – Marvell

CoreTM 2 Duo/ Pentium® D/ Pentium® 4/ Celeron® D/ Celeron®

ICH7

F71872FG

ALC662

88E8042

Memory:

 Two DIMM sockets

 Supports unbuffered & non-ECC DDRII 667 (by overclocking)/ DDRII 533 SDRAM

 Supports a total memory capacity of up to 4 GB

 Supports Dual Channel data bus

Onboard HD Audio Codec (ALC 662):

 High performance Codec with high S/N ratio (>90 db)

 Supports 6/4/2 channel playback capability

 Supports jack sensing and re-tasking function

 Built-in Dolby Digital Live Technology

 Supports Sony/ Philips Digital Interfaces (S/PDIF) output function (Optional)

Slots:

 One PCI-Express x16 interface slot for graphics card or expansion card

 Two standard PCI slots for PCI standard expansion cards

Mainboard PM945GC(V2.0)

FDD Connector:

 Supports one FDD connector to set up to two floppy disk drives

 Supports 360KB/ 720KB/ 1.2MB/ 1.44MB/ 2.88MB

IDE Connector:

 One IDE connector

 Supports up to two IDE devices

 Supports Ultra ATA 33/66/100

 Supports high capacity hard disk drives

Serial ATA II Connector:

 Four SATA II connectors

 Supports SATA 2.0 specification and with transmit rate up to 3 Gbps

 One SATA connector can only support one SATA HDD

Onboard LAN Chip:

 10/100 Mbps Ethernet LAN supported

I/O facility Connectors

 Supports one PS/2 mouse port and one PS/2 keyboard port

 Supports one serial port

 Supports one VGA port (=D-Sub)

 Supports one parallel port（PARALLEL）header and one HDMI-SPDIF OUT (HDMI-SPDIF)

header with external devices connected

Universal Serial Bus:

 Four onboard USB 2.0/ 1.1 ports

 Two front USB headers come with this mainboard for additional four USB ports

 Support a maximum of eight USB ports to connect USB compliant devices

BIOS:

 Phoenix-Award™ BIOS

 Support APM1.2

 Support ACPI 2.0 power management

Mainboard PM945GC(V2.0)

Green Function:

 Supports Phoenix-Award™ BIOS power management function

 Supports system-wake-from-power-saving-mode by keyboard or mouse touching

Shadow RAM:

 Integrated memory controller provides shadow RAM functionality and supports ROM

BIOS

Flash Memory:

 Supports flash memory functionality

 Supports ESCD functionality

Hardware Monitor Function:

 Monitors CPU/ Chassis Fan Speed

 Monitors CPU and system temperature

 Monitors system voltages

Configuration

Layout of PM945GC (V2.0)

Mainboard PM945GC(V2.0)

Hardware Installation

This section will assist you in quickly installing your system hardware. Wear a wrist ground strap before handling components. Electrostatic discharge may damage the system’s components.

CPU Processor Installation

This mainboard supports Intel® CoreTM 2 Duo/ Pentium® D/ Pentium® 4/ Celeron® D/ Celeron® Processors using a Socket 775. Before building your system, we suggest you to visit the Intel website and review the processor installation procedures. http://www.intel.com

CPU Socket 775 Configuration Steps:

1. Locate the CPU socket 775 on your mainboard and nudge the lever away from the socket as shown. Then lift the lever to a 140-degree angle (A). Next, lift up the iron cover (B).

2. There are 2 distinctive marks located near the corners of the socket on the same side as the lever as shown (C). Match these marks with the marks on the CPU and carefully lower the CPU down onto the socket (D).

3. Replace the iron cover and then lower the lever until it snaps back into position (E). This will lock down the CPU (F).

4. Smear thermal grease on the top of the CPU. Lower the CPU fan onto the CPU/CPU socket and secure it using the attachments or screws provided on the fan. Finally, attach the fan power cord to the CPUFAN header.

Attention

DO NOT touch the CPU pins in case they are damaged. Also, make sure that you have completed all installation steps before powered on the system. Finally, double-check that the cooling fan is properly installed and the CPU fan power cord is securely attached, in case your CPU and other sensitive components are damaged because of high temperatures.
