Intel IB940 User Manual

IB940

LGA775 Core 2 Duo

Intel® Q965 Chipset

Full Size CPU Card

USER’S MANUAL

Version 1.0A

Acknowledgments

Award is a registered trademark of Award Software International, Inc. PS/2 is a trademark of International Business Machines Corporation. Intel and Core 2 Duo are registered trademarks of Intel Corporation. Microsoft Windows is a registered trademark of Microsoft Corporation. Winbond is a registered trademark of Winbond Electronics Corporation. All other product names or trademarks are properties of their respective owners.

ii IB940 User’s Manual

The IB940 CPU card is based on the Intel Q965 chipset and supports the Intel® Core™2 Duo processor with 1066/800/533 MHz System Bus. It supports the PCI Express x16 graphics interface for the latest high-performance graphics cards. The PCI Express x1 I/O ports offer up to 3.5X the bandwidth over traditional PCI architecture, delivering faster access to peripheral I/O devices.

The Intel GMA 3000 graphics on board supports Dual Independent Display and delivers richer visual color and picture clarity without the need for additional discrete graphics cards, and the integrated audio support enables premium digital sound and delivers advanced features such as multiple audio.

The CPU card also supports Dual-Channel DDR2 memory in four DIMM sockets and delivers up to 12.8 GB/s of bandwidth and 8 GB memory addressability for faster system responsiveness. Dimensions of the board are 338mm x 126mm.

The main features of the CPU card are:

y Intel Q965 Express Chipset Based y Support LGA775 Intel Core2 Duo Processors y Support FSB 1066/800/533MHz y Support up to 4GB DDRII 800/667/533 memory y 1 x Mini PCI Express Slot y Support one 10/100 or two Gigabit LAN on board y 4 x SATA II, 1 x IDE, 1x Floppy, 6 x USB 2.0, 2 x

COM, 1 x Parallel,

y 5.1Ch. Audio, 1 x TMDS y Dual channel LVDS support 18/24 bit

IB940 User’s Manual 1

INTRODUCTION

Checklist

Your IB940 Core 2 Duo CPU Card package should include the items listed below:

 The IB940 Card  This User’s manual  1 x IDE cable  1 x Floppy cable  1 x SATA cable  1 x TMDS cable  2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a

Mounting Bracket

 1 Y-Cable supporting a PS/2 Keyboard and a PS/2 Mouse  Audio cable with bracket (Audio-18K)  USB cable with bracket (USB2K-4)  1 CD containing the following:

 Chipset Drivers  Flash Memory Utility

 Optional SATA Power Cord (PW34)

2 IB940 User’s Manual

Specifications

Form Factor Processor

Full Size CPU Card (PICMG1.0) Support for Intel Core 2 Duo processor (Conroe core) in LGA775 socket

FSB Chipset

533/800/1066 MHz Intel Broadwater (Q965) Chipset consisting of:

 Intel Q965 Graphics Memory Controller Hub (GMCH)  Intel ICH8/ICH8DO I/O Controller Hub

BIOS

 Award BIOS: footprint for both SPI & LPC I/F  Support for ACPI, SMBIOS

Memory

Video DVI LVDS LAN

2x 240-pin DDRII 533/667/800 DIMM sockets, supports Intel Q965 integrated graphics subsystem GMA3000

Chrontel CH7307C x1 for DVI Chrontel CH7308B x1 for 24-bit single/dual channel LVDS LAN1: dual footprint support option:

LAN2: Intel 82573L PCI-e gigabit LAN (IB940F)

Audio

Intel ICH8 built-in high definition audio w/ Realtek ALC888 Codec supports 5.1 CH audio (line-out, line-in & mic)

LPC I/O

USB

SATA II IDE PCI-to-ISA

Winbond W83627EHG: IrDA x1, Parallel x1, COM1 (RS232),

Intel ICH8 built-in two High Speed USB host controller,

Intel ICH8 built-in SATA II controller (3.0Gb/sec) w/ 4 ports JMicron JM368 (PCI-e to PATA) x1 for 1 PATA channel ITE IT8888G x1 for high drive ISA bus

bridge Expansion

Mini PCI-express socket x1 for Wireless LAN or other module

Edge Connector

On Board Headers / Connectors

 PS/2 connector x1 for PS/2 keyboard & Mouse, DB15 x1  Standard SATA (7-pin shrouded vertical) connector x4

 40 pins, 0.1” pitch, standard box-header x1 for IDE  DF13-20 header x2 for LVDS  DF11-20 header x1 for DVI  34 pins box-header x1 for floppy  26 pins box-header x1 for printer  5x2 pins box-header x2 for COM1-2  4 pins pin-header x1 for CPU fan  3 pins pin-header x1 for system fan  4x2 pins pin-header x3 for USB1-6

RTC Watchdog Timer Digital IO System Voltage Board Size

ICH8 built-in RTC with on-board lithium battery Yes (256 segments, 0, 1, 2…255 sec/min) 4 in and 4 out +5V, +3.3V, +12V, -12V & 5VSB 338 x 122mm

INTRODUCTION

single channel, max. 4 GB

 Intel 82566DM Nineveh 10/100/1000 (IB940F)  Intel 82562V Ekron-N 10/100 (IB940)

COM2 (RS232/422/485), floppy, Hardware monitor (3 thermal inputs, 4 voltage monitor inputs & 2 fan headers)

supports 6 USB 2.0 ports (support for USB port disable) w/ over-current protection

for VGA, RJ45 x2 for LAN 1, 2

IB940 User’s Manual 3

INTRODUCTION

Board Dimensions

O

5

4

.

0

.

0

8

0

6

5.07

J

P 8

J

2

4

1

2

6

1

.

8

9

4

2

00

5.08

313.18

333.17

338.25

0

5

1

.

7

0

.

8

7

8

6

5

3

6

.

9

5

3

9

5

0

.

0

7

1

0

7

0

.

3

4

4 IB940 User’s Manual

338.25

1

2

1

.

9

2

INSTALLATIONS

Installations

This section provides information on how to use the jumpers and connectors on the IB940 in order to set up a workable system. The topics covered are:

Installing the CPU ........................................................................ 6

Installing the Memory .................................................................. 7

Setting the Jumpers ...................................................................... 8

Connectors on IB940 ................................................................. 12

IB940 User’s Manual 5

INSTALLATIONS

Installing the CPU

The IB940 CPU Card supports an LGA 775 processor socket for Intel® Core 2 Duo processors.

The LGA 775 processor socket comes with a lever to secure the processor. Refer to the pictures below, from left to right, on how to place the processor into the CPU socket. Please note that the cover of the

LGA775 socket must always be installed during transport to avoid damage to the socket.

6 IB940 User’s Manual

INSTALLATIONS

Installing the Memory

The IB940 CPU Card supports four DDR2 memory sockets for a maximum total memory of 4GB in DDR memory type. It supports DDR2 533/667/800.

Basically, the system memory interface has the following features:

Supports two 64-bit wide DDR data channels Available bandwidth up to 6.4GB/s (DDR2 800) for single-channel mode. Supports 256Mb, 512Mb, 1Gb DDR2 technologies. Supports only x8, x16, DDR2 devices with four banks Supports only unbuffered DIMMs Supports opportunistic refresh Up to 32 simultaneously open pages (four per row, four rows maximum)

Installing and Removing Memory Modules

To install the DDR2 modules, locate the memory slot on the board and perform the following steps:

1. Hold the DDR2 module so that the key of the DDR2 module align

with those on the memory slot.

2. Gently push the DDR2 m odule in an upright position until the clips of

the slot close to hold the DDR2 module in place when the DDR module touches the bottom of the slot.

3. To remove the DDR2 module, press the clips with both hands.

DDR2 Module

Lock Lock

IB940 User’s Manual 7

INSTALLATIONS

Setting the Jumpers

Jumpers are used on IB940 to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. The following lists the connectors on IB940 and their respective functions.

Jumper Locations on IB940 ................................................................... 9

JBAT1: Clear CMOS Contents ............................................................ 10

JP1, JP2, JP3: RS232/422/485 (COM2) Selection .............................. 10

JP4, JP5: COM1 / COM2 RS232 +5V/+12V Power Setting ............... 10

JP7: Processor Setting .......................................................................... 11

JP8: LVDS Panel Power Select ........................................................... 11

J25: Power Supply Type Select ........................................................... 11

8 IB940 User’s Manual

Jumper Locations on IB940

J

P 8

J

2 0

J

2

4

1

J

2 2

J

P 7

J

1 9

B A T 1

J

1 8

J

1 7

J

P 6

INSTALLATIONS

A T

C

X

P

1

U _ F A N 1

B Z 1

J

2

J

2 5

C P U 1

D

R

I

I2

1

J

1

F A

J

N

9

J

SATA3

B A T 1

J

1 5

J

1 1

SATA1

J

SATA2

SATA4

1 4

J

1

J

2

1 0

V G

J

A

1

3

1

J

6

8

F

I

D

E

C

1

J

7

J

4

J

P 4

J

P 5

J

3

J

5

JP1 JP2

JP3

Jumpers on IB940 ............................................................................. Page

JBAT1: Clear CMOS Contents ........................................................................ 10

JP1, JP2, JP3: RS232/422/485 (COM2) Selection ........................................... 10

JP4, JP5: COM1 / COM2 RS232 +5V/+12V Power Setting ........................... 10

JP7: Processor Setting ...................................................................................... 11

JP8: LVDS Panel Power Select ....................................................................... 11

J25: Power Supply Type Select ....................................................................... 11

IB940 User’s Manual 9

INSTALLATIONS

JBAT1: Clear CMOS Contents

Use JBAT1, a 3-pin header, to clear the CMOS contents. Note that the ATX-power connector should be disconnected from the CPU Card before clearing CMOS.

JBAT1 Setting Function

Pin 1-2

Short/Closed

Pin 2-3

Short/Closed

Normal

Clear CMOS

JP1, JP2, JP3: RS232/422/485 (COM2) Selection

COM1 is fixed for RS-232 use only. COM2 is selectable for RS232, RS-422 and RS-485. ID394: COM3 and COM4 are fixed for RS-232 use only. The fol lowing table describes the jumper settings for COM2 selection.

COM2

Function

Jumper Setting

(pin closed)

RS-232 RS-422 RS-485

JP1:

1-2

JP2:

3-5 & 4-6

JP3:

3-5 & 4-6

JP1:

3-4

JP2:

1-3 & 2-4

JP3:

1-3 & 2-4

JP1:

5-6

JP2:

1-3 & 2-4

JP3:

1-3 & 2-4

JP4, JP5: COM1 / COM2 RS232 +5V/+12V Power Setting

JP4 / JP5 Setting Function

Pin 1-2

Short/Closed

+12V

Pin 3-4

Short/Closed

Pin 5-6

Short/Closed

Normal

+5V

10 IB940 User’s Manual

INSTALLATIONS

JP7: Processor Setting

JP7 Setting Processor Used

Pin 1-2

Short/Closed

Pin 1-2

Open

Celeron D

Core 2 Duo,

Pentium D,

Pentium 4 HT

JP8: LVDS Panel Power Select

JP8 Setting Panel Voltage

Pin 1-2

Short/Closed

Pin 2-3

Short/Closed

3.3V (default)

5V

J25: Power Supply Type Select

Use J25, a 3-pin header, to select between AT and ATX power supply.

J25 Setting Power Supply Type

Pin 1-2

Short/Closed

Pin 2-3

Short/Closed

ATX

AT

IB940 User’s Manual 11

INSTALLATIONS

[

Connectors on IB940

The connectors on IB940 allows you to connect external devices such as keyboard, floppy disk drives, hard disk drives, printers, etc. The following table lists the connectors on IB940 and their respective functions.

Jumper Locations on IB940 ................................................................. 13

CPU_FAN1: CPU Fan Power Connector ........................................... 14

PWR_FAN1: SYSTEM Fan Power Connectors.................................. 14

VGA1: VGA CRT Connector .............................................................. 14

FDC1: Floppy Drive Connector .......................................................... 15

IDE1: Primary IDE Connectors ........................................................... 15

S_ATA1, S_ATA2, S_ATA3, S_ATA4: SATA HDD Connectors .... 16

ATX1: 12V/+12V Power Connector ................................................... 16

J1: TMDS Panel Connector ................................................................. 16

J2: System Function Connector ........................................................... 17

J3: Parallel Port Connector .................................................................. 19

J4, J5: COM1 and COM2 Serial Ports Connector ............................... 19

J6: Digital I/O Connector (4 in, 4 out) ................................................. 20

J7: Audio Connector for 5.1 channel ................................................... 20

J8: IrDA Connector .............................................................................. 20

J9: External ATX Power Connector .................................................... 20

J10: CD-In Audio Connector ............................................................... 21

J11, J12: External PS/2 Keyboard and Mouse Connector ................... 21

J13: PS/2 Keyboard and Mouse Connector ......................................... 21

J17, J15, J14: USB0/USB1 Connector ................................................ 21

J16: Intel 82562V 10/100 or Intel 82566DC GbE RJ-45 .................... 22

Note: 10/100 LAN for IB940; Gigabit LAN for IB940F ...................... 22

J18: Wake On LAN Connector ............................................................ 22

J19: SPI Flash Connector (factory use only) ....................................... 22

J20, J21: LVDS Connectors (1st channel, 2nd channel) ..................... 22

J22: Panel Inverter Power Connector .................................................. 23

J23: Intel PCI Express GbE RJ45 Connector ...................................... 23

U46: x1 Mini PCI Express Slot ........................................................... 23

12 IB940 User’s Manual

I

D E 1

J

3

Jumper Locations on IB940

J

P 8

J

2

J

2

4

0 J

2

1

J

2

J

P 7

INSTALLATIONS

A T

C

X

P

1

U _

F A N 1

B Z 1

J

2

J

2

5

C P U 1

D

R

I

II

I

2

1

J

1

9

B A T 1

J

SATA3

B A T 1

J

1

8

J

1

7

4

5

J

P 6

J

1

SATA1

SATA2

SATA4

J

1

J

2

1

0

J

P 4

V G

J

P

A

1

5

1

3

J

1

F A

J

N

9

1

J

8

6

F D C 1

J

7

J

4

J

5

JP1 JP2 JP3

IB940 User’s Manual 13

INSTALLATIONS

The connectors on IB940 allows you to connect external devices such as keyboard, floppy disk drives, hard disk drives, printers, etc. The following table lists the connectors on IB940 and their respective functions.

CPU_FAN1: CPU Fan Power Connector

Pin # Signal Name

4 Control 3 Sense 2 +12V 1 Ground

PWR_FAN1: SYSTEM Fan Power Connectors

Pin # Signal Name

1 Sense 2 +12V 3 Rotation detection

VGA1: VGA CRT Connector

VGA1 is a DB-15 VGA connector located beside the COM1 port. The following table shows the pin-out assignments of this connector.

Signal Name Pin # Pin # Signal Name

Red 1 2 Green

Blue 3 4 N.C. GND 5 6 GND GND 7 8 GND VCC 9 10 GND

N.C. 11 12 DDCDATA

HSYNC 13 14 VSYNC

DDCCLK 15

14 IB940 User’s Manual

N

t

N

t

y

FDC1: Floppy Drive Connector

Signal Name Pin # Pin # Signal Name

Ground 1 2 RM/LC Ground 3 4 No connect Ground 5 6 No connect Ground 7 8 Index Ground 9 10 Motor enable 0 Ground 11 12 Drive select 1 Ground 13 14 Drive select 0 Ground 15 16 Motor enable 1 Ground 17 18 Direction Ground 19 20 Step Ground 21 22 Write data Ground 23 24 Write gate Ground 25 26 Track 00 Ground 27 28 Write protect Ground 29 30 Read data Ground 31 32 Side 1 select Ground 33 34 Diskette change

IDE1: Primary IDE Connectors

Signal Name Pin # Pin # Signal Name

Reset IDE 1 2 Ground

Host data 7 3 4 Host data 8 Host data 6 5 6 Host data 9 Host data 5 7 8 Host data 10 Host data 4 9 10 Host data 11 Host data 3 11 1 2 Host data 12 Host data 2 13 1 4 Host data 13 Host data 1 15 1 6 Host data 14 Host data 0 17 1 8 Host data 15

Ground 19 20 Protect pin

DRQ0 21 22 Ground

Host IOW 23 24 Ground

Host IOR 25 26 Ground

IOCHRDY 27 28 Host ALE

DACK0 29 30 Ground

IRQ14 31 32

IDE1

Address 1 33 34

Address 0 35 36 Address 2

Chip select 0 37 38 Chip select 1

Activit

INSTALLATIONS

o connec o connec

39 40 Ground

IB940 User’s Manual 15

INSTALLATIONS

S_ATA1, S_ATA2, S_ATA3, S_ATA4: SATA HDD Connectors

Pin # Signal Name

1 Ground 2 TX+ 3 TX4 Ground 5 RX6 RX+ 7 Ground

ATX1: 12V/+12V Power Connector

Pin # Signal Name

1 Ground 2 Ground 3 +12V 4 +12V

J1: TMDS Panel Connector

TMDS stands Transition Minimized Differential Signaling.

Signal Name Pin # Pin # Signal Name

TX1P 1 11 TX2P TXIN 2 12 TX2N

GND 3 13 GND GND 4 14 GND

TXCP 5 15 TX0P

TXCN 6 16 TX0N

GND 7 17 NC

+5v 8 18 NC

J1

HTPG 9 19 DDCDATA

NC 10 20 DDCCLK

16 IB940 User’s Manual

INSTALLATIONS

J2: System Function Connector

J2 provides connectors for system indicators that provide light i ndication of the computer activities and switches to change the computer status. J1 is a 20-pin header that provides interfaces for the following functions.

Hard Disk Drive LED

Reset Switch

Not Defined

SMI / Hardware Switch

Speaker

ATX Power On Switch

Power LED

Speaker: Pins 1 - 4

This connector provides an interface to a speaker for audio tone generation. An 8-ohm speaker is recommended.

Pin # Signal Name

1 Speaker out 2 No connect 3 Ground 4 +5V

Power LED: Pins 11 - 15

The power LED indicates the status of the main power switch.

Pin # Signal Name

11 Power LED 12 No connect 13 Ground 14 No connect 15 Ground

IB940 User’s Manual 17

INSTALLATIONS

SMI/Hardware Switch: Pins 6 and 16

This connector supports the "Green Switch" on the control panel, which, when pressed, will force the system into the power-saving mode immediately.

Pin #

ATX Power ON Switch: Pins 7 and 17

This 2-pin connector is an “ATX Power Supply On/Off Switch” on the system that connects to the power switch on the case. When pressed, the power switch will force the system to power on. When pressed again, it will force the system to power off.

Reset Switch: Pins 9 and 19

The reset switch allows the user to reset the system without turning the main power switch off and then on again. Orientation is not required when making a connection to this header.

Signal Name

6 SMI

16 Ground

Hard Disk Drive LED Connector: Pins 10 and 20

This connector connects to the hard drive activity LED on control panel. This LED will flash when the HDD is being accessed.

Pin # Signal Name

10 HDD Active 20 5V

18 IB940 User’s Manual

INSTALLATIONS

J3: Parallel Port Connector

The following table describes the pin out assignments of this connector.

Signal Name Pin # Pin # Signal Name

Line printer strobe 1 14 AutoFeed PD0, parallel data 0 2 15 Error PD1, parallel data 1 3 16 Initialize PD2, parallel data 2 4 17 Select PD3, parallel data 3 5 18 Ground PD4, parallel data 4 6 19 Ground PD5, parallel data 5 7 20 Ground PD6, parallel data 6 8 21 Ground PD7, parallel data 7 9 22 Ground

J3

ACK, acknowledge 10 23 Ground

Busy 11 24 Ground

Paper empty 12 25 Ground

Select 13 N/A N/A

J4, J5: COM1 and COM2 Serial Ports Connector

J4 and J5 both 10-pin headers, are the onboard serial port connectors.

Fixed as

RS-232

Configurable

as RS-232/

RS-422/485

with jumpers

JP1/JP2/JP3

J4

J5

Pin # Signal Name

RS-232 RS-422 RS-485

1 DCD TX- DATA2 RX TX+ DATA+ 3 TX RX+ NC 4 DTR RX- NC 5 GND GND GND 6 DSR NC NC 7 RTS NC NC 8 CTS NC NC 9 RI NC NC

10 NC NC NC

IB940 User’s Manual 19

INSTALLATIONS

t

J6: Digital I/O Connector (4 in, 4 out)

This 10-pin digital I/O connector supports TTL levels and is used to control external devices requiring ON/OFF circuitry.

Signal Name Pin # Pin # Signal Name

Ground 1 2 +5V

Out3 3 4 Out1 Out2 5 6 Out0

IN3 7 8 IN1 IN2 9 10 IN0

J7: Audio Connector for 5.1 channel

Signal Name Pin # Pin # Signal Name

LINEOUT L 1 2 LINEOUT R

LINEOUT Detec

3 4 Ground

LINEIN L 5 6 LINEIN R

LINEIN Detec

7 8 Ground

MIC1 9 10 VREFOUT

MIC1 Detec

11 12 Ground

J8: IrDA Connector

J8 is used for an optional IrDA connector for wireless communication.

Pin # Signal Name

1 +5V 2 No connect 3 Ir RX 4 Ground 5 Ir TX

J9: External ATX Power Connector

Pin # Signal Name

1 Ground 2 PS-ON (soft on/off) 3 5VSB (Standby +5V)

20 IB940 User’s Manual

INSTALLATIONS

J10: CD-In Audio Connector

Pin # Signal Name

1 CD Audio R 2 Ground 3 Ground 4 CD Audio L

J11, J12: External PS/2 Keyboard and Mouse Connector

Pin # J11 J12

1 KB clock Mouse data 2 KB data N.C. 3 N.C. Ground 4 Ground Vcc 5 Vcc Mouse clock

J13: PS/2 Keyboard and Mouse Connector

J13 uses a Y-cable with dual D-connectors for a PS/2 keyboard and a PS/2 mouse.

Pin # Signal Name

1 Keyboard data 2 Mouse data 3 Ground 4 Vcc 5 Keyboard Clock 6 Mouse Clock

J17, J15, J14: USB0/USB1 Connector

Signal Name Pin Pin Signal Name

Vcc 1 2 Ground USB0- 3 4 USB1+ USB0+ 5 6 USB1-

Ground 7 8 Vcc

IB940 User’s Manual 21

INSTALLATIONS

J16: Intel 82562V 10/100 or Intel 82566DC GbE RJ-45

J16 is the 10/100 or Gigabit LAN RJ45 connector based on the Intel PCI Express 10/100 or GbE controller.

Note: 10/100 LAN for IB940; Gigabit LAN for IB940F J18: Wake On LAN Connector

J18 is a 3-pin header for the Wake On LAN function on the CPU Card. The following table shows the pin out assignments of this connector. Wake On LAN will function properly only with an ATX power supply with 5VSB that has 1A.

Pin # Signal Name

1 +5VSB 2 Ground 3 LAN Wakeup

J19: SPI Flash Connector (factory use only)

J20, J21: LVDS Connectors (1st channel, 2nd channel)

The LVDS connectors, DF13 20-pin mating connectors, are composed of the first channel (J5) and second channel (J10) to support 24-bit or 48-bit.

Signal Name Pin # Pin #

Signal Name

TX0- 2 1 TX0+

Ground 4 3 Ground

TX1- 6 5 TX1+

5V/3.3V 8 7 Ground

TX3- 10 9 TX3+ TX2- 12 11 TX2+

Ground 14 13 Ground

TXC- 16 15 TXC+

5V/3.3V 18 17 ENABKL

+12V 20 19 +12V

Remarks: Maximum current for +12V is 1A.

22 IB940 User’s Manual

INSTALLATIONS

J22: Panel Inverter Power Connector

Pin # Signal Name

1 +12V 2 ENABKL 3 Ground

Remarks: Maximum current is 1A.

J23: Intel PCI Express GbE RJ45 Connector

J23 is the Gigabit LAN RJ45 connector based on the Intel PCI Express GbE controller.

U46: x1 Mini PCI Express Slot

IB940 User’s Manual 23

INSTALLATIONS

This page is intentionally left blank.

24 IB940 User’s Manual

BIOS SETUP

BIOS Setup

This chapter describes the different settings available in the Award BIOS that comes with the board. The topics covered in this chapter are as follows:

BIOS Introduction ........................................................................ 26

BIOS Setup ................................................................................... 26

Standard CMOS Setup ................................................................. 28

Advanced BIOS Features ............................................................. 31

Advanced Chipset Features .......................................................... 34

Integrated Peripherals ................................................................... 35

Power Management Setup ............................................................ 38

PNP/PCI Configurations .............................................................. 41

PC Health Status ........................................................................... 42

Frequency/Voltage Control .......................................................... 43

Load Fail-Safe Defaults ................................................................ 44

Load Optimized Defaults ............................................................. 44

Set Supervisor/User Password ...................................................... 44

Save & Exit Setup ........................................................................ 44

Exit Without Saving ..................................................................... 44

IB940 User’s Manual 25

BIOS SETUP

BIOS Introduction

The Award BIOS (Basic Input/Output System) installed in your computer system’s ROM supports Intel processors. The BIOS provides critical low-level support for a standard device such as disk drives, serial ports and parallel ports. It also adds virus and password protection as well as special support for detailed fine-tuning of the chipset controlling the entire system.

BIOS Setup

The Award BIOS provides a Setup utility program for specifying the system configurations and settings. The BIOS ROM of the system stores the Setup utility. When you turn on the computer, the Award BIOS is immediately activated. Pressing the <Del> key immediately allows you to enter the Setup utility. If you are a little bit late pressing the <Del> key, POST (Power On Self Test) will continue with its test routines, thus preventing you from invoking the Setup. If you still wish to enter Setup, restart the system by pressing the ”Reset” button or simultaneously pressing the <Ctrl>, <Alt> and <Delete> keys. You can also restart by turning the system Off and back On again. The following message will appear on the screen:

Press <DEL> to Enter Setup

In general, you press the arrow keys to highlight items, <Enter> to select, the <PgUp> and <PgDn> keys to change entries, <F1> for help and <Esc> to quit.

When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select from various setup functions and exit choices.

26 IB940 User’s Manual

BIOS SETUP

Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save & Exit Setup PC Health Status Exit Without Saving ESC : Quit Ç È Æ Å : Select Item F10 : Save & Exit Setup

Phoenix - AwardBIOS CMOS Setup Utility

Time, Date, Hard Disk Type…

The section below the setup items of the Main Menu displays the control keys for this menu. At the bottom of the Main Menu just below the control keys section, there is another section, which displays information on the currently highlighted item in the list.

Note:

If the system cannot boot after making and saving system changes with Setup, the Award BIOS supports an override to the CMOS settings that resets your system to its default.

Warning:

It is strongly recommended that you avoid making any changes to the chipset defaults. These defaults have been carefully chosen by both Award and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could cause the system to become unstable and crash in some cases.

IB940 User’s Manual 27

BIOS SETUP

Standard CMOS Setup

“Standard CMOS Setup” choice allows you to record some basic hardware configurations in your computer system and set the system clock and error handling. If the motherboard is already installed in a working system, you will not need to select this option. You will need to run the Standard CMOS option, however, if you change your system hardware configurations, the onboard battery fails, or the configuration stored in the CMOS memory was lost or damaged.

Date (mm:dd:yy) Fri, Oct 20, 2006 Item Help Time (hh:mm:ss) 16 : 11 : 00 Menu Level >

IDE Channel 0 Master None Change the day, month,

IDE Channel 1 Master None IDE Channel 1 Slave IDE Channel 2 Master IDE Channel 3 Master IDE Channel 4 Master IDE Channel 4 Slave

Drive A 1.44M, 3.5 in Drive B None

Video EGA/VGA Halt On All , But Keyboard

Base Memory 640K Extended Memory 2086912K Total Memory 2087936K

At the bottom of the menu are the control keys for use on this menu. If you need any help in each item field, you can press the <F1> key. It will display the relevant information to help you. The memory display at the lower right-hand side of the menu is read-only. It will adjust automatically according to the memory changed. The following describes each item of this menu.

Date

The date format is:

Day : Sun to Sat Month : 1 to 12 Date : 1 to 31 Year : 1999 to 2099

Phoenix - AwardBIOS CMOS Setup Utility

Standard CMOS Features

None None None None None

Year and century IDE Channel 0 Slave None

28 IB940 User’s Manual

BIOS SETUP

To set the date, highlight the “Date” field and use the PageUp/ PageDown or +/- keys to set the current time.

Time

The time format is:

Minute : 00 to 59 Second : 00 to 59

Hour : 00 to 23

To set the time, highlight the “Time” field and use the <PgUp>/ <PgDn> or +/- keys to set the current time.

IDE Channel Master/Slave

The onboard Serial ATA connectors provide Primary and Secondary channels for connecting up to four Serial ATA hard disks . Each channel can support up to two hard disks; the first is the “Master” and the second is the “Slave”.

Press <Enter> to configure the hard disk. The selections include Auto, Manual, and None. Select ‘Manual’ to define the drive information manually. You will be asked to enter the following items.

Capacity : Capacity/size of the hard disk drive Cylinder : Number of cylinders Head : Number of read/write heads Precomp : Write precompensation Landing Zone : Landing zone Sector : Number of sectors

The Access Mode selections are as follows: CHS (HD < 528MB) LBA (HD > 528MB and supports Logical Block Addressing) Large (for MS-DOS only) Auto

Drive A / Drive B

These fields identify the types of floppy disk drive A or drive B that has been installed in the computer. The available specifications are: 360KB

5.25 in.

1.2MB

5.25 in.

720KB

3.5 in.

1.44MB

3.5 in.

2.88MB

3.5 in.

IB940 User’s Manual 29

BIOS SETUP

Video

This field selects the type of video di splay card instal led i n your syst em . You can choose the following video display cards: EGA/VGA For EGA, VGA, SEGA, SVGA or PGA monitor adapters. (default) CGA 40 Power up in 40 column mode. CGA 80 Power up in 80 column mode. MONO For Hercules or MDA adapters.

Halt On

This field determines whether or not the system will halt if an error is detected during power up. No errors The system boot will not be halted for any error

that may be detected.

All errors Whenever the BIOS detects a non-fatal error,

the system will stop and you will be prompted.

All, But Keyboard The system boot will not be halted for a

keyboard error; it will stop for all other errors

All, But Diskette The system boot will not be halted for a disk

error; it will stop for all other errors.

All, But Disk/Key The system boot will not be halted for a key-

board or disk error; it will stop for all others.

30 IB940 User’s Manual

BIOS SETUP

Advanced BIOS Features

This section allows you to configure and improve your system and allows you to set up some system features according to your preference.

CPU Feature Press Enter ITEM HELP Hard Disk Boot Priority Press Enter Virus Warning Disabled Menu Level > CPU L1 and L2 Cache CPU L3 Cache Quick Power On Self Test Enabled First Boot Device Floppy Second Boot Device Hard Disk Third Boot Device CDROM Boot Other Device Enabled Swap Floppy Drive Disabled Boot up Floppy Seek Disabled Boot Up NumLock Status On Gate A20 Option Fast Typematic Rate Setting Disabled Typematic Rate (Chars/Sec) 6 Typematic Delay (Msec) 250 Security Option Setup APIC Mode Enabled MPS Version Control for OS 1.4 OS Select For DRAM>64MB Non-OS2 Report No FDD for Win95 Yes Small Logo (EPA) Show Disabled

CPU Feature

Press Enter to configure the settings relevant to CPU Feature.

Hard Disk Boot Priority

With the field, there is the option to choose, aside from the hard disks connected, “Bootable add-in Cards” which refers to other external devices.

Virus Warning

If this option is enabled, an alarm message will be displayed when trying to write on the boot sector or on the partition table on the disk, which is typical of the virus.

CPU L1 / L2 / L3 Cache

Cache memory is additional memory that is much faster than conventional DRAM (system memory). CPUs from 486-type on up contain internal cache memory, and most, but not all, modern PCs have additional (external) cache memory. When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory, for even faster access by the CPU. These items allow you to enable (speed up memory access) or disable the cache function. By default, these items are Enabled.

Phoenix - AwardBIOS CMOS Setup Utility

Advanced BIOS Features

Enabled Enabled

IB940 User’s Manual 31

BIOS SETUP

Hyper-Threading Technology

Hyper-Threading Technology enables two logical processors on a single physical processor by replicating, partitioning, and sharing the resources within the Intel NetBurst microarchitecture pipeline.

Quick Power On Self Test

When enabled, this field speeds up the Power On Self Test (POST) after the system is turned on. If it is set to Enabled, BIOS will skip some items.

First/Second/Third Boot Device

These fields determine the drive that the system searches first for an operating system. The options available include LS120, Hard Disk, CDROM, ZIP100, USB-FDD, USB-ZIP, USB-CDROM and Disabled.

Boot Other Device

These fields allow the system to search for an OS from other devices other than the ones selected in the First/Second/Third Boot Device.

Swap Floppy Drive

The default setting is Disabled.

Boot up Floppy Seek

The default setting is Disabled.

Boot Up NumLock Status

This allows you to activate the NumLock function after you power up the system.

Gate A20 Option

This field allows you to select how Gate A20 is worked. Gate A20 is a device used to address memory above 1 MB.

Typematic Rate Setting

When disabled, continually holding dow n a key on your keyboard will generate only one instance. When enabled, you can set the two typematic controls listed next. By default, this field is set to Disabled.

Typematic Rate (Chars/Sec)

When the typematic rate is enabled, the system registers repeated keystrokes speeds. Settings are from 6 to 30 characters per second.

32 IB940 User’s Manual

BIOS SETUP

Typematic Delay (Msec)

When the typematic rate is enabled, this item allows you to set the time interval for displaying the first and second characters. By default, this item is set to 250msec.

Security Option

This field allows you to limit access to the System and Setup. The default value is Setup. When you select System, the system prompts for the User Password every time you boot up. When you select Setup, the system always boots up and prompts for the Supervisor Password only when the Setup utility is called up.

APIC Mode

APIC stands for Advanced Programmable Interrupt Controller. The default setting is Enabled.

MPS Version Control for OS

This option is specifies the MPS (Multiprocessor Specification) version for the OS. MPS version 1.4 added extended configuration tables to improve support for multiple PCI bus configurations and improve future expandability. The default setting is 1.4.

OS Select for DRAM > 64MB

This option allows the system to access greater than 64MB of DRAM memory when used with OS/2 that depends on certain BIOS calls to access memory. The default setting is Non-OS/2.

Report No FDD for Win95

The default setting is Yes.

Small Logo (EPA) Show

The EPA logo appears at the right side of the monitor screen when the system is boot up. The default setting is Disabled.

IB940 User’s Manual 33

BIOS SETUP

Advanced Chipset Features

This Setup menu controls the configuration of the chipset.

System BIOS Cacheable Enabled ITEM HELP Memory Hole at 15M-16M Disabled Menu Level > PCI Express Root Port Func Press Enter

** VGA Setting ** PEG/On Chip VGA Control Auto On-Chip Frame Buffer Size 8MB DVMT Mode DVMT DVMT/FIXED memory Size 128MB SDVO Device Setting None SDVO LVDS Protocol 1 Ch SPWG 18bit SDVO Panel Number 1024 x 768 Boot Display Auto

System BIOS Cacheable

The setting of Enabled allows caching of the system BIOS ROM at F000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result.

Memory Hole At 15M-16M

In order to improve performance, certain space in memory can be reserved for ISA cards. This memory must be mapped into the memory space below 16 MB. The choices are Enabled and Disabled.

Phoenix - AwardBIOS CMOS Setup Utility

Advanced Chipset Features

On-Chip VGA Setting

The fields under the On-Chip VGA Setting and their default settings are:

PEG/On Chip VGA Control: Auto On-Chip Frame Buffer Size: 8MB DVMT Mode: DVMT DVMT/Fixed Memory Size: 128MB

SDVO Device Setting

The default setting is None, and other options are LVDS, LVDS+DVI, and DVI.

Boot Display

The default setting is Auto and other options are CRT, LVDS, CRT+LVDS, DVI, and CRT+DVI.

34 IB940 User’s Manual

BIOS SETUP

Integrated Peripherals

This section sets configurations for your hard disk and other integrated peripherals. The first screen shows three main items for user to select. Once an item selected, a submenu appears. Details follow.

OnChip IDE Device SuperIO Device USB Device Setting

IDE HDD Block Mode IDE DMA transfer access IDE Primary Master PIO IDE Primary Slave PIO IDE Primary Master UDMA IDE Primary Slave UDMA On-Chip Secondary PCI IDE IDE Secondary Master PIO IDE Secondary Slave PIO IDE Secondary Master UDMA IDE Secondary Slave UDMA LEGACY Mode Support Enabled

POWER ON Function BUT TON ONLY

KB Power ON Password Enter Hot Key power ON Ctrl-F1 Onboard Serial Port 1 3F8/IRQ4 Onboard Serial Port 2 2F8/IRQ3 UART Mode Select Normal Onboard Parallel Port 378/IRQ7 Parallel Port Mode SPP PWRON After PWR-Fail Off

USB 1.0 Controller USB 2.0 Controller USB Keyboard Function USB Mouse Function USB Storage Function Enabled

*** USB Mass Storage Device Boot Setting ***

Phoenix - AwardBIOS CMOS Setup Utility

Integrated Peripherals Press Enter

Press Enter Press Enter Menu Level >

Phoenix - AwardBIOS CMOS Setup Utility

OnChip IDE Device

Enabled ITEM HELP Enabled Auto Menu Level > Auto Auto Auto Enabled Auto Auto Auto Auto

Phoenix - AwardBIOS CMOS Setup Utility

SuperIO Device

ITEM HELP

Menu Level >

Phoenix - AwardBIOS CMOS Setup Utility

USB Device Setting

Enabled ITEM HELP Enabled Menu Level > Disabled Disabled

IB940 User’s Manual 35

BIOS SETUP

IDE HDD Block Mode

This field allows your hard disk controller to use the fast block mode to transfer data to and from your hard disk drive.

IDE DMA Transfer Access

This field, by default, is enabled

OnChip Secondary PCI IDE

This field, by default, is enabled

IDE Primary/Secondary Master/Slave PIO

These fields allow your system hard disk controller to work faster. Rather than have the BIOS issue a series of commands that transfer to or from the disk drive, PIO (Programmed Input /Output) allows the BIOS to communicate with the controller and CPU directly.

The system supports five modes, numbered from 0 (default) to 4, which primarily differ in timing. When Auto is selected, the BIOS will select the best available mode.

IDE Primary/Secondary Master/Slave UDMA

These fields allow your system to improve disk I/O throughput to 33Mb/sec with the Ultra DMA/33 feature. The options are Auto and Disabled.

LEGACY Mode Support

When the Serial ATA (SATA) is set with the legacy mode enabled, then the SATA is set to the conventional IDE mode. Legacy mode is otherwise known as compatible mode.

Power ON Function

This field is related to how the system is powered on – such as with th e use of conventional power button, keyboard or hot keys. The default is BUTTON ONLY.

KB Power ON Password

This field allows users to set the password when keyboard power on is the mode of the Power ON function.

Hot Key Power ON

This field sets certain keys, also known as hot keys, on the keyboard that can be used as a ‘switch’ to power on the system.

36 IB940 User’s Manual

BIOS SETUP

Onboard Serial/Parallel Port

These fields allow you to select the onboard serial and parallel ports and their addresses. The default values for these ports are: Serial Port 1 3F8/IRQ4 Serial Port 2 2F8/IRQ3 Parallel Port 378H/IRQ7

UART Mode Select

This field determines the UART 2 mode in your computer. The default value is Normal. Other options include IrDA and ASKIR.

Parallel Port Mode

This field allows you to determine parallel port mode function. SPP Standard Printer Port EPP Enhanced Parallel Port ECP Extended Capabilities Port

PWRON After PWR-Fail

This field sets the system power status whether on or off when power returns to the system from a power failure situation.

USB 1.0 Controller

The options for this field are Enabled and Disabled. By default, this field is set to Enabled.

USB 2.0 Controller

The options for this field are Enabled and Disabled. By default, this field is set to Enabled. In order to use USB 2.0, necessary OS drivers must be installed first. Please update your system to Windows 2000 SP4 or Windows XP SP2.

USB Keyboard/Mouse/Storage Function

The options for this field are Enabled and Disabled. By default, this field is set to Disabled.

IB940 User’s Manual 37

BIOS SETUP

Power Management Setup

ACPI Function ACPI Suspend Power Management Video Off Method Video Off In Suspend Suspend Type Modem Use IRQ Suspend Mode HDD Power Down

Soft-Off by PWR-BTTN CPU THRM-Throttling Wake Up by PCI card Power On by Ring Resume by Alarm

Date (of Month) Alarm 0 Time (hh:mm:ss) Alarm 0 : 0 : 0

** Reload Global Timer Events ** Primary IDE 0 Primary IDE 1 Secondary IDE 0 Secondary IDE 1 FDD, COM, LPT Port PCI PIRQ[A-D] #

Phoenix - AwardBIOS CMOS Setup Utility

Power Management Setup

Enabled ITEM HELP S3(STR) User Define Menu Level > V/H SYNC+Blank Yes Stop Grant 3 Disabled Disabled

Instant-Off

75.0% Disabled Disabled Disabled

Disabled Disabled Disabled Disabled Disabled Disabled

ACPI Function

Enable this function to support ACPI (Advance Configuration and Power Interface).

ACPI Suspend

The default setting of the ACPI Suspend mode is S3(STR).

Power Management

This field allows you to select the type of power saving management modes. There are four selections for Power Management.

Min. Power Saving Minimum power management Max. Power Saving Maximum power management. User Define Each of the ranges is from 1 min. to

1hr. Except for HDD Power Down which ranges from 1 min. to 15 min.

38 IB940 User’s Manual

BIOS SETUP

Video Off Method

This field defines the Video Off features. There are three options.

V/H SYNC + Blank Default setting, blank the screen and turn

off vertical and horizontal scanning. DPMS Allows BIOS to control the video display. Blank Screen Writes blanks to the video buffer.

Video Off In Suspend

When enabled, the video is off in suspend mode.

Suspend Type

The default setting for the Suspend Type field is Stop Grant.

Modem Use IRQ

This field sets the IRQ used by the Modem. By default, the setting is 3.

Suspend Mode

When enabled, and after the set time of system inactivity, all devices except the CPU will be shut off.

HDD Power Down

When enabled, and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active.

Soft-Off by PWRBTN

This field defines the power-off mode when using an ATX power supply. The Instant Off mode allows powering off immediately upon pressing the power button. In the Delay 4 Sec mode, the system powers off when the power button is pressed for more than four seconds or enters the suspend mode when pressed for less than 4 seconds.

CPU THRM-Throttling

When the system enters Doze mode, t he CPU clock runs only part of the time. You may select the percent of time that the clock runs.

Wake Up by PCI card

The default setting is Disabled.

Power On by Ring

The default setting is Disabled.

IB940 User’s Manual 39

BIOS SETUP

Resume by Alarm

This field enables or disables the resumption of the system operation. When enabled, the user is allowed to set the Date and Time.

Reload Global Timer Events

The HDD, FDD, COM, LPT Ports, and PCI PIRQ are I/O events that can prevent the system from entering a power saving mode or can awaken the system from such a mode. When an I/O device wants to gain the attention of the operating system, it signals this by causing an IRQ to occur. When the operating system is ready to respond to the request, it interrupts itself and performs the service.

40 IB940 User’s Manual

BIOS SETUP

PNP/PCI Configurations

This option configures the PCI bus system. All PCI bus systems on the system use INT#, thus all installed PCI cards must be set to this value.

Init Display First Reset Configuration Data

Resources Controlled By IRQ Resources

PCI/VGA Palette Snoop INT Pin 1 Assignment INT Pin 2 Assignment INT Pin 3 Assignment

INT Pin 4 Assignment INT Pin 5 Assignment INT Pin 6 Assignment INT Pin 7 Assignment INT Pin 8 Assignment

**PCI Express relative items** Maximum Payload Size

Init Display First

The default setting is PCI Card.

Reset Configuration Data

The default value is Disabled.

Resources Controlled by

This PnP BIOS can configure all of the boot and compatible devices with the use of a PnP operating system such as Windows 95.

PCI/VGA Palette Snoop

Some non-standard VGA display cards may not show colors properly. This field allows you to set whether or not MPEG ISA/VESA VGA cards can work with PCI/VGA. When this field is enabled, a PCI/VGA can work with an MPEG ISA/VESA VGA card. When this field is disabled, a PCI/VGA cannot work with an MPEG ISA/VESA card.

Maximum Payload Size

The default setting of the PCI Express Maximum Payload Size is 128.

Phoenix - AwardBIOS CMOS Setup Utility

PnP/PCI Configurations

PCI Slot ITEM HELP Disabled Menu Level > Auto (ESCD) Press Enter

Disabled Auto Auto Auto

Auto Auto Auto Auto Auto

128

IB940 User’s Manual 41

BIOS SETUP

PC Health Status

Shutdown Temperature CPU Warning Temperature System Temp 32°C/89°F CPU Temp 39°C/102°F System Fan Speed 4000 RPM CPU Fan Speed 4000 RPM Vcore 1.24 V

12 V 12.03 V

1.8 V 1.92 V 5 V 4.99 V

3.3 V 3.15 V VBAT (V) 3.13 V 5VSB(V) 5.29 V

CPU Warning Temperature

This field allows the user to set the temperature so that when the temperature is reached, the system sounds a warning. This function can help prevent damage to the system that is caused by overheating.

Shutdown Temperature

This field allows the user to set the temperature by which the system automatically shuts down once the threshold temperature is reached. This function can help prevent damage to the system that is caused by overheating.

Temperatures/Fan Speeds/Voltages

These fields are the parameters of the hardware monitoring function feature of the board. The values are read-only values as monitored by the system and show the PC health status.

Phoenix - AwardBIOS CMOS Setup Utility

PC Health Status

Disabled Disabled

Menu Level >

ITEM HELP

42 IB940 User’s Manual

BIOS SETUP

Frequency/Voltage Control

CPU Clock Ratio Unlock CPU Clock Ratio Auto Detect PCI Clk Spread Spectrum CPU Host / SRC / PCI Clock

Phoenix - AwardBIOS CMOS Setup Utility

Frequency/Voltage Control

Disabled ITEM HELP 8x Menu Level > Disabled Disabled Default

CPU Clock Ratio Unlock

This field has a default setting of Disabled. When en abled , it allows the CPU clock ratio setting in the next field to be changed t o a ‘lower’ ratio.

Auto Detect PCI Clk

This field enables or disables the auto detection of the PCI clock.

Spread Spectrum

This field sets the value of the spread spectrum. The default setting is Disabled. This field is for CE testing use only

.

CPU Host / SRC / PCI Clock

This field has a default setting of Default.

IB940 User’s Manual 43

BIOS SETUP

Load Fail-Safe Defaults

This option allows you to load the troubleshooting default values permanently stored in the BIOS ROM. These default settings are non-optimal and disable all high-performance features.

Load Optimized Defaults

This option allows you to load the default values to your system configuration. These default settings are optimal and enable all high performance features.

Set Supervisor/User Password

These two options set the system password. Supervisor Password sets a password that will be used to protect the system and Setup utility. User Password sets a password that will be used exclusively on the system. To specify a password, highlight the type you want and press <Enter>. The Enter Password: message prompts on the screen. Type the password, up to eight characters in length, and press <Enter>. The system confirms your password by asking you to type it again. After setting a password, the screen automatically returns to the main screen.

To disable a password, just press the <Enter> key when you are prompted to enter the password. A message will confirm the password to be disabled. Once the password is disabled, the system will boot and you can enter Setup freely.

Save & Exit Setup

This option allows you to determine whether or not to accept the modifications. If you type “Y”, you will quit the setup utility and save all changes into the CMOS memory. If you type “N”, you will return to Setup utility.

Exit Without Saving

Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility.

44 IB940 User’s Manual

DRIVERS INSTALLATION

Drivers Installation

This section describes the installation procedures for software and drivers under the Windows 2000 and Windows XP. The software and drivers are included with the board. If you find the items mi ssing, please contact the vendor where you made the purchase. The contents of this section include the following:

Intel Q965 Chipset Software Installation Utility ............... 46

Intel Q965 Chipset Graphics Driver .................................. 48

Realtek Codec Audio Driver Installation .......................... 50

Intel LAN Drivers Installation .......................................... 51

IMPORTANT NOTE:

After installing your Windows operating system (Windows 2000/XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the drivers installation.

IB940 User’s Manual 45

DRIVERS INSTALLATION

Intel Q965 Chipset Software Installation Utility

The Intel® Q965 Chipset Drivers should be installed first before the software drivers to enable Plug & Play INF support for Intel chipset components. Follow the instructions below to complete the installation under Windows 2000/XP. (Before installed Intel Chipset Software Installation Utility,Please update your system to Windows 2000 SP4 or Windows XP SP1A)

1. Insert the CD that comes with the board and the screen below would appear. Click Intel (R) Q965 Chipset Drivers, then Intel(R) Chipset Software Installation Utility.

46 IB940 User’s Manual

DRIVERS INSTALLATION

2. When the Welcome screen appears, click Next to continue.

3. Click Yes to accept the software license agreement and proceed with the installation process.

4. On the Readme Information screen, click Next to continue the installation.

5. The Setup process is now complete. Click Finish to restart the computer and for changes to take effect.

IB940 User’s Manual 47

DRIVERS INSTALLATION

Intel Q965 Chipset Graphics Driver

Follow the instructions below to complete the installation under Windows 2000/XP.

1. Insert the CD that comes with the board and the screen below would appear. Click Intel (R) Q965 Chipset Drivers, then Intel (R) Q965 Chipset Family Graphics Driver.

2. When the Welcome screen appears, click Next to continue.

48 IB940 User’s Manual

DRIVERS INSTALLATION

3. Click Yes to accept the software license agreement and proceed with the installation process.

4. On Readme File Information screen, click Next to continue.

5. On Setup Progress screen, click Next to continue the installation.

6. The Setup process is now complete. Click Finish to restart the computer and for changes to take effect.

IB940 User’s Manual 49

DRIVERS INSTALLATION

Realtek Codec Audio Driver Installation

1. Insert the CD that comes with the board and the screen below would appear. Click Intel (R) Q965 Chipset Drivers, then Realtek High Definition Codec Audio Driver.

2. When the Welcome screen appears, click Next to continue.

3. The Setup process is now complete. Restart the computer when prompted for changes to take effect.

50 IB940 User’s Manual

DRIVERS INSTALLATION

Intel LAN Drivers Installation

Follow the steps below to start installing the Intel PCI Express Gig abit LAN drivers.

1. Insert the CD that comes with the board. On the initial screen, Click

Intel (R) Q965 Chipset Drivers, then Intel(R) PRO LAN Network Drivers.

2. On the next screen, click Install Drivers to start the drivers installation.

IB940 User’s Manual 51

DRIVERS INSTALLATION

3. When the Welcome screen appears, click Next to continue.

4. In the License Agreement screen, click I accept the terms in license agreement and Next to accept the software license agreement and proceed with the installation process.

5. When the Setup Type screen appears, click Complete and Next to continue.

6. When the Ready to Install the Program screen appears, click Install to continue.

7. The Setup process is now complete (InstallShield Wizard Completed). Click Finish to restart the computer and for changes to take effect.

52 IB940 User’s Manual

APPENDIX

Appendix

A. I/O Port Address Map

Each peripheral device in the system is assigned a set of I/O port addresses that also becomes the identity of the device. The followin g table lists the I/O port addresses used.

Address Device Description

000h - 01Fh DMA Controller #1 020h - 03Fh Interrupt Controller #1 040h - 05Fh Timer 060h - 06Fh Keyboard Controller 070h - 07Fh Real Time Clock, NMI 080h - 09Fh DMA Page Register 0A0h - 0BFh Interrupt Controller #2 0C0h - 0DFh DMA Controller #2 0F0h Clear Math Coprocessor Busy Signal 0F1h Reset Math Coprocessor 1F0h - 1F7h IDE Interface 278h - 27Fh Parallel Port #2(LPT2) 2F8h - 2FFh Serial Port #2(COM2) 2B0h - 2DFh Graphics adapter Controller 378h - 3FFh Parallel Port #1(LPT1) 360h - 36Fh Network Ports 3B0h - 3BFh Monochrome & Printer adapter 3C0h - 3CFh EGA adapter 3D0h - 3DFh CGA adapter 3F0h - 3F7h Floppy Disk Controller 3F8h - 3FFh Serial Port #1(COM1)

IB940 User’s Manual 53

APPENDIX

B. Interrupt Request Lines (IRQ)

Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board.

Level Function

IRQ0 System Timer Output IRQ1 Keyboard IRQ2 Interrupt Cascade IRQ3 Serial Port #2 IRQ4 Serial Port #1 IRQ5 Reserved IRQ6 Floppy Disk Controller IRQ7 Parallel Port #1 IRQ8 Real Time Clock IRQ9 Reserved IRQ10 Reserved IRQ11 Reserved IRQ12 PS/2 Mouse IRQ13 80287 IRQ14 Primary IDE IRQ15 Secondary IDE

54 IB940 User’s Manual

APPENDIX

C. Watchdog Timer Configuration

The WDT is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock. Under these sorts of circumstances, the timer will count to zero and the selected outputs will be driven. Under normal circumstance, the user will restart the WDT at regular intervals before the timer counts to zero.

SAMPLE CODE:

//======================================================================= // // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. // //======================================================================= ==== #include <stdio.h> #include <stdlib.h> #include "W627EHF.H" //======================================================================= ==== int main (int argc, char *argv[]); void copyright(void); void EnableWDT(int); void DisableWDT(void); //======================================================================= ==== int main (int argc, char *argv[]) { unsigned char bBuf; unsigned char bTime; char **endptr;

copyright();

if (argc != 2) { printf(" Parameter incorrect!!\n"); return 1; }

if (Init_W627EHF() == 0) { printf(" Winbond 83627HF is not detected, program abort.\n"); return 1; } bTime = strtol (argv[1], endptr, 10);

IB940 User’s Manual 55

APPENDIX

printf("System will reset after %d seconds\n", bTime);

EnableWDT(bTime);

return 0; } //======================================================================= void copyright(void) { printf("\n======== Winbond 83627EHF Watch Timer Tester (AUTO DETECT) ========\n"\ " Usage : W627E_WD reset_time\n"\ " Ex : W627E_WD 3 => reset system after 3 second\n"\ " W627E_WD 0 => disable watch dog timer\n"); } //======================================================================= void EnableWDT(int interval) { unsigned char bBuf;

bBuf = Get_W627EHF_Reg( 0x2D); bBuf &= (!0x01); Set_W627EHF_Reg( 0x2D, bBuf); //Enable WDTO

Set_W627EHF_LD( 0x08); //switch to logic device 8 Set_W627EHF_Reg( 0x30, 0x01); //enable timer

bBuf = Get_W627EHF_Reg( 0xF5); bBuf &= (!0x08); Set_W627EHF_Reg( 0xF5, bBuf); //count mode is second

Set_W627EHF_Reg( 0xF6, interval); //set timer } //======================================================================= void DisableWDT(void) { Set_W627EHF_LD(0x08); //switch to logic device 8 Set_W627EHF_Reg(0xF6, 0x00); //clear watchdog timer Set_W627EHF_Reg(0x30, 0x00); //watchdog disabled } //=======================================================================

56 IB940 User’s Manual

APPENDIX

//======================================================================= // // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. // //======================================================================= ==== #include "W627EHF.H" #include <dos.h> //======================================================================= ==== unsigned int W627EHF_BASE; void Unlock_W627EHF (void); void Lock_W627EHF (void); //======================================================================= unsigned int Init_W627EHF(void) { unsigned int result; unsigned char ucDid;

W627EHF_BASE = 0x2E; result = W627EHF_BASE;

ucDid = Get_W627EHF_Reg(0x20); if (ucDid == 0x88) { goto Init_Finish; }

W627EHF_BASE = 0x4E; result = W627EHF_BASE; ucDid = Get_W627EHF_Reg(0x20); if (ucDid == 0x88) { goto Init_Finish; }

W627EHF_BASE = 0x00; result = W627EHF_BASE;

Init_Finish: return (result); } //======================================================================= void Unlock_W627EHF (void) { outportb(W627EHF_INDEX_PORT, W627EHF_UNLOCK); outportb(W627EHF_INDEX_PORT, W627EHF_UNLOCK); } //======================================================================= ==== void Lock_W627EHF (void) { outportb(W627EHF_INDEX_PORT, W627EHF_LOCK); } //======================================================================= void Set_W627EHF_LD( unsigned char LD) { Unlock_W627EHF(); outportb(W627EHF_INDEX_PORT, W627EHF_REG_LD); outportb(W627EHF_DATA_PORT, LD);

IB940 User’s Manual 57

APPENDIX

Lock_W627EHF(); } //======================================================================= void Set_W627EHF_Reg( unsigned char REG, unsigned char DATA) { Unlock_W627EHF(); outportb(W627EHF_INDEX_PORT, REG); outportb(W627EHF_DATA_PORT, DATA); Lock_W627EHF(); } //======================================================================= unsigned char Get_W627EHF_Reg(unsigned char REG) { unsigned char Result; Unlock_W627EHF(); outportb(W627EHF_INDEX_PORT, REG); Result = inportb(W627EHF_DATA_PORT); Lock_W627EHF(); return Result; } //=======================================================================

//======================================================================= // // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. // //======================================================================= #ifndef __W627EHF_H #define __W627EHF_H 1 //======================================================================= #define W627EHF_INDEX_PORT (W627EHF_BASE) #define W627EHF_DATA_PORT (W627EHF_BASE+1) //======================================================================= #define W627EHF_REG_LD 0x07 //======================================================================= #define W627EHF_UNLOCK 0x87 #define W627EHF_LOCK 0xAA //======================================================================= unsigned int Init_W627EHF(void); void Set_W627EHF_LD( unsigned char); void Set_W627EHF_Reg( unsigned char, unsigned char); unsigned char Get_W627EHF_Reg( unsigned char); //======================================================================= #endif //__W627EHF_H

58 IB940 User’s Manual

APPENDIX

D. Digital I/O Sample Code

Filename: W627hf.h //===================================================================== // // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. // //===================================================================== #ifndef __W627HF_H #define __W627HF_H 1 //======================================================================= #define W627HF_INDEX_PORT (W627HF_BASE) #define W627HF_DATA_PORT (W627HF_BASE+1) //======================================================================= #define W627HF_REG_LD 0x07 //======================================================================= #define W627HF_UNLOCK 0x87 #define W627HF_LOCK 0xAA //======================================================================= unsigned int Init_W627HF(void); void Set_W627HF_LD( unsigned char); void Set_W627HF_Reg( unsigned char, unsigned char); unsigned char Get_W627HF_Reg( unsigned char); //======================================================================= #endif //__W627HF_H

IB940 User’s Manual 59

APPENDIX

Filename: W627hf.cpp //===================================================================== // // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. // //===================================================================== unsigned int W627HF_BASE; void Unlock_W627HF (void); void Lock_W627HF (void); //======================================================================= unsigned int Init_W627HF(void) { unsigned int result; //0=NA, 1=627HF, 2=627THF, 4=627EHF

// W627HF_BASE = 0x2E; W627HF_BASE = 0x4E; result = Get_W627HF_Reg(0x20); if (result == 0x52) { result = 1; goto Init_Finish; } else if (result == 0x82) { result = 2; goto Init_Finish; } else if (result == 0x88) { result = 4; goto Init_Finish; }

// W627HF_BASE = 0x4E; W627HF_BASE = 0x2E;

result = Get_W627HF_Reg(0x20); if (result == 0x52) { result = 1; goto Init_Finish; } else if (result == 0x82) { result = 2; goto Init_Finish; } else if (result == 0x88) { result = 4; goto Init_Finish; }

60 IB940 User’s Manual

APPENDIX

W627HF_BASE = 0x00; result = 0;

Init_Finish: return (result); } //======================================================================= void Unlock_W627HF (void) { outportb(W627HF_INDEX_PORT, W627HF_UNLOCK); outportb(W627HF_INDEX_PORT, W627HF_UNLOCK); } //======================================================================= void Lock_W627HF (void) { outportb(W627HF_INDEX_PORT, W627HF_LOCK); } //======================================================================= void Set_W627HF_LD( unsigned char LD) { Unlock_W627HF(); outportb(W627HF_INDEX_PORT, W627HF_REG_LD); outportb(W627HF_DATA_PORT, LD); Lock_W627HF(); } //======================================================================= void Set_W627HF_Reg( unsigned char REG, unsigned char DATA) { Unlock_W627HF(); outportb(W627HF_INDEX_PORT, REG); outportb(W627HF_DATA_PORT, DATA); Lock_W627HF(); } //======================================================================= unsigned char Get_W627HF_Reg(unsigned char REG) { unsigned char Result; Unlock_W627HF(); outportb(W627HF_INDEX_PORT, REG); Result = inportb(W627HF_DATA_PORT); Lock_W627HF(); return Result; } //=======================================================================

IB940 User’s Manual 61

APPENDIX

File of the Main.cpp //===================================================================== // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. //===================================================================== #include <dos.h> #include <conio.h> #include <stdio.h> #include <stdlib.h> #include "W627HF.H" //--------------------------------------------------------------------------void ClrKbBuf(void); int main (void); unsigned char GetDI(unsigned char); void SetDo(unsigned char, unsigned char); //--------------------------------------------------------------------------int main (void) { unsigned char ucDO = 0; //data for digital output unsigned char ucDI; //data for digital input unsigned char ucBuf; char SIO;

SIO = Init_W627HF(); if (SIO == 0) { printf("Can not detect Winbond 83627HF/83627THF/83627EHF, program abort.\n"); return(1); } switch (SIO) { //------------------------------------------------------------------ case 1: printf("Winbond 83627HF is detected .\n"); break; //------------------------------------------------------------------ case 2: printf("Winbond 83627THF is detected.\n"); break; //------------------------------------------------------------------ case 4: printf("Winbond 83627EHF is detected.\n"); break; //------------------------------------------------------------------ }

//bit 0..3 = input signal //bit 4..7 = output signal

ucDI = GetDI(0x0F); //get current DI status SetDo(ucDO, 0xF0); //set current DO status return 0; } //--------------------------------------------------------------------------unsigned char GetDI(unsigned char Mask) {

62 IB940 User’s Manual

APPENDIX

unsigned char result;

Set_W627HF_LD(0x07); //switch to logic device 7 Set_W627HF_Reg(0xF0, Mask); //set the DIO direction result = Get_W627HF_Reg(0xF1) & Mask; return (result); } //--------------------------------------------------------------------------void SetDo(unsigned char NewData, unsigned char Mask) { Set_W627HF_LD(0x07); //switch to logic device 7 Set_W627HF_Reg(0xF0, ~Mask); //set the DIO direction Set_W627HF_Reg(0xF1, NewData & Mask); } //--------------------------------------------------------------------------void ClrKbBuf(void) { while(kbhit()) { getch(); } } //---------------------------------------------------------------------------

IB940 User’s Manual 63

APPENDIX

This page is intentionally left blank.

64 IB940 User’s Manual

Intel IB940 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Pin # Signal Name

Pin # Signal Name

Pin # Signal Name
