TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
i865-Gi865-G
i865-G
i865-Gi865-G
mainboard mainboard
mainboard
mainboard mainboard
Manual Revision 1.1
November 12, 2003
DISCLAIMER OF WARRANTIES:
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE
DESCRIPTION ON THE FACE OF THE MANUFACTURER LIMITED
WARRANTY. THE MANUFACTURER EXPRESSLY EXCLUDES ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING ITS
PRODUCTS; INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR
NONINFRINGEMENT. THIS DISCLAIMER OF WARRANTIES SHALL
APPLY TO THE EXTENT ALLOWED UNDER LOCAL LAWS IN THE
COUNTRY PURCHASED IN WHICH LOCAL LAWS DO NOT ALLOW
OR LIMIT THE EXCLUSION OF THE IMPLIED WARRANTIES.
Section 1 Introduction
Package Contents ...................................................... 1-1
Intel Pentium 4 Processors......................................... 1-2
Chipset Components.................................................. 1-2
Accelerated Graphics Port ......................................... 1-3
Ultra ATA66/100 ........................................................ 1-3
Hardware Monitoring ................................................. 1-3
LAN (Optional) .......................................................... 1-3
Serial ATA .................................................................. 1-4
Mainboard Form-Factor ............................................. 1-5
I/O Shield Connector.................................................. 1-6
Power-On/Off (Remote) .............................................. 1-6
System Block Diagram ............................................... 1-7
Section 2 Features
Mainboard Features ................................................... 2-1
Table of Contents
Page
Section 3 Installation
Mainboard Layout ..................................................... 3-2
Easy Installation Procedure
CPU Installation ......................................................... 3-3
Jumper Settings .......................................................... 3-5
System Memory Configuration .................................. 3-6
Expansion slots .......................................................... 3-9
Device Connectors..................................................... 3-11
External Modem Ring-in Power ON and
Keyboard Power ON Function (KBPO) ..................... 3-16
STR (Suspend To RAM) Function .......................... 3-17
Section 4 Award BIOS Setup
Main Menu ................................................................ 4-1
Standard CMOS Setup ............................................... 4-2
Advanced BIOS Features .......................................... 4-3
Advanced Chipset Features ...................................... 4-6
Integrated Peripherals ................................................ 4-9
Power Management Setup ......................................... 4-17
PNP/PCI Configuration Setup .................................... 4-20
PC Health Status ........................................................ 4-22
Power BIOS Features ................................................. 4-24
Defaults Menu ........................................................... 4-28
Supervisor/User Password Setting ............................ 4-29
Exit Selecting .............................................................. 4-30
Section 5 Driver Installation
Easy Driver Installation .............................................. 5-1
C-Media Audio Configuration Brief Guide ................ 5-2
Appendix Appendix A
Update Your System BIOS ......................................... A-1
Appendix B
EEPROM BIOS Remover ........................................... B-1
Appendix C
GHOST 7 Quick User’s Guide (Optional) ................... C-1
Package Contents
Introduction
Section 1
INTRODUCTION
Contents
A. Mainboard
B. User’s manual
C. Floppy drive cable
D. HDD drive cable
E. CD or diskette (drivers and
utilities)
F. Game port cable
G. I/O Shield
H. S-ATA data and power cable
A
Other Optional Items
I. Extra USB2.0 port cable
J. S/PDIF Module
If you need the other optional item,
please contact your dealer for
assistance.
USER’S
MANUAL
B
C
or
E
D
G
F
H
J
I
Page 1-1
Introduction
Intel® Pentium® 4 processors
The Intel Pentium 4 processor, Intel's most advanced, most powerful processor for
desktop PCs and entry-level workstations, is based on Intel NetBurst
microarchitecture. The Pentium 4 processor is designed to deliver performance
across applications and usages where end-users can truly appreciate and experience
the performance. These applications include Internet audio and streaming video,
image processing, video content creation, speech, 3D, CAD, games, multimedia, and
multi-tasking user environments. The Pentium 4 processor delivers this world-class
performance for consumer enthusiasts and business professional desktop PC users
as well as for entry-level workstation users.
Intel adds support for Hyper-Threading Technology to the Pentium 4 processor
family. HT Technology allows a single, physical Pentium 4 processor to function as
two logical processor for next generation multi threaded application.
For more information about all the new features the Pentium 4 delivers check out
the Intel website at http://www.intel.com
TM
Chipset Components
This board is designed with Intel® 865G (Springdale-G) chipset. The Intel® 865G chipset
consists of the Graphic Memory Controller Hub (GMCH) and the I/O Controller Hub
(ICH5/R).
Graphic Memory Controller Hub (GMCH)
The GMCH provides the interconnect between the AGP, DDR SDRAM and the
system logic. It integrates:
- Supports for single processor with a data transfer rate of 400/533/800MHz.
- Supports dual channel of 266/333/400 DDR SDRAM up to 2GB.
- 8X/4X 1.5V AGP interface (Only support 1.5V on AGP interface).
- Downstream hub link for access to the ICH5/R.
I/O Controller Hub (ICH5/R)
The I/O controller Hub provides the I/O subsystem with access to the rest of the
system. Additionally, it integrates many I/O functions:
Page 1-2
Introduction
- Upstream hub link for access to the GMCH
- 2-Channel Ultra ATA/100 Bus Master IDE controller
- USB controller
- SMBus controller
- LPC / Flash BIOS interface
- PCI 2.3 interface
- Integrated System Management Controller
Accelerated Graphics Port (AGP)
The AGP slot on the board is compliant with the new AGP 3.0 specification. This
new specification enhances the functionality of the original AGP specification by
allowing 8X data transfers ( 8 data samples per clock) resulting in maximum band-
width of 2.1GB/s. In addition, it defines 1.5 volt power supply operation. Complying
with this specification, this board supports external AGP-8X/4X cards with Fast
Write Transactions. Only 1.5V AGP cards are supported.
Ultra ATA/66/100
The ICH5/R provides an Ultra ATA/66/100 Bus Master IDE controller. This controller
supports Ultra ATA/66/100 protocols which are ideal to support demanding applica-
tions such as real-time video, multimedia, and a high performance operating system.
A new IDE cable is required for Ultra ATA/66/100; this cable is an 80-pin conductor
cable which is backward compatible with ATA/33 connectors.
Hardware Monitoring
Hardware monitoring enables you to monitor various aspects of the system operation
and status. The features include CPU temperature, voltage and fan speed in RPMs.
LAN (Optional)
This mainboard is optionally mounted with a LAN chipset. It allows the mainboard to
connect to a local area network by means of a network hub.
Page 1-3
Introduction
Serial ATA
The evolutionary serial ATA interface replaces the standard parallel ATA physical
storage interface. The serial ATA specification provides scalability and allows
future enhancements to the computing platform. Serial technology overcomes
performance limits of parallel interface architecture, meeting the escalating need for
faster data throughput in servers and storage devices.
Serial ATA is completely software compatible with parallel ATA, requiring no
modification to your operating system. The serial ATA interface cable requires lower
voltages and uses smaller cable connectors, providing ease of installation. You can
easily upgrade storage devices that are compatible with the serial ATA interface
specification.
Page 1-4
Introduction
Mainboard Form-Factor
This board is designed with M-ATX form factor - the latest industry standard for
chassis design. The M-ATX form factor is essentially a Baby-AT baseboard
rotated 90 degrees within the chassis enclosure and a new mounting configuration for the power supply. With these changes the processor is relocated away
from the expansion slots, allowing them all to hold full length add-in cards.
M-ATX defines a double height aperture to the rear of the chassis which can be
used to host a wide range of onboard I/O. Only the size and position of this
aperture is defined, allowing PC manufacturers to add new I/O features (e.g.; TV
input, TV output, joystick, modem, LAN, audio, etc.) to systems. This will help
systems integrators differentiate their products in the marketplace, and better
meet your needs.
• By integrating more I/O down onto the board and better positioning the hard
drive and floppy connectors material cost of cables and add-in cards is
reduced.
• By reducing the number of cables and components in the system, manufacturing time and inventory holding costs are reduced and reliability will
increase.
• By using an optimized power supply, it's possible to reduce cooling costs
and lower acoustical noise. An ATX power supply, which has a sidemounted fan, allows direct cooling of the processor and add-in cards making
a secondary fan or active heatsink unnecessary in most system applications.
Expandable I/O
Single chassis
fan for system
ATX 12V power
connector
CPU socket
PCI slots
AGP slot
ATX
Power
Supply
IDE connectors
Floppy
connector
3 1/2-inch
Bay
Figure 2: Summary of ATX chassis features
5 1/4-inch
Bay
ATX power connector
Page 1-5
Introduction
I/O Shield Connector
The board is equipped with an I/O back panel (Figure 3). Ensure that your computer
case has the appropriate I/O cutout.
USB2.0
ports
RJ-45 LAN
(Optional)
USB2.0
ports
Line-in/Rear out (Light blue)
Line-out/Front out (Lime)
Mic-in/Center&Subwoofer (Pink)
PS/2
Mouse
PS/2
Keyboard
Parallel Port
COM1
VGA1
Figure 3: I/O ports
Power-On/Off (Remote)
This board has a 20-pin ATX and a 4-pin ATX12V power supply connector (Figure
4). For power supplies that support the Remote On/Off feature, this should be
connected to the mainboard front panel PW_ON connector for the computer power
On/Off button.
The board has been designed with “Soft Off" function. You can turn off the system
in two ways: by pressing the front panel power On/Off button or using the "Soft
Off" function (incorporated in the mainboard’s onboard circuit controller) that can
be controlled by an operating system such as Windows®XP/ME/2000/98/95.
Note: For maintaining the DDR SDRAM power during STR (ACPI S3) function, it is
strongly recommended to use power supplies that have a +5VSB current of (>
=) 2A. Please check the 5VSB’s specification that has been printed on the
power supply’s outer case.
Note: The board requires a minimum of 250 Watt power supply to operate. Your
system configuration (amount of memory, add-in cards, peripherals, etc.) may
exceed the minimum power requirement but to ensure that adequate power is
provided, use a 300 Watt (or greater) power supply. Also your power supply
must support 4-pin ATX 12V connector.
PW-ON
Page 1-6
12V 4-pin
POWER SUPPLY
20-pin
Case (chassis) Power ON/OFF button (PW-ON)
Figure 4: Simple ATX power ON/OFF controller
System Block Diagram
Introduction
Figure 5: System Block Diagram
Page 1-7
Introduction
Page Left Blank
Page 1-8
Mainboard Features
Processor
Socket 478 Intel® Pentium® 4 and Celeron processors from 1.7GHz up to
3.2+ GHz
Supports the following System Bus and Memory combination:
FSB400 / DDR266 (PC2100)
FSB533 / DDR266/333 (PC2100/PC2700)
FSB800 / DDR333 (PC2700)*
FSB800 / DDR400 (PC3200)
* When configured to FSB800/DDR333, adaptive synchronization aligns to the
closest FSB to memory clock ratio, setting memory channel to 320MHz.
Supports Hyper-Threading Technology
To enable the Hyper-Threading Technology function on your computer
system requires ALL of the following platform components:
)CPU: An Intel
)Chipset: An Intel
)BIOS: A BIOS that supports HT Technology and has it enabled.
)OS: An operating system that supports HT Technology.
Performance will vary depending on the specific hardware and software
you use. See <http://www.intel.com/info/hyperthreading> for information
including details on which processor support HT Technology.
Features
Section 2
FEATURES
®
Pentium® 4 Processor with HT Technology.
®
Chipset that supports HT Technology.
Chipset
Intel 865G Chipset (865G + ICH5/R)
- Built-in Intel Extreme Graphics
Main Memory
Two 184-pin DDR DIMM sockets for PC2100/2700/3200 (DDR266/333/400)
DIMMs
Page 2-1
Features
Supports 128-bit dual channel memory architecture
Supports up to 2GB memory size
BIOS
Flash EEPROM with Award BIOS
- ACPI v2.0 compliant
- S3 (Suspend to DRAM) sleep-state support
- SMBIOS (System Management BIOS) v2.2 compliant
- Supports Power failure recovery
- Able to wake the computer from specific states by LAN, Power switch,
PME#, RTC alarm, USB, PS2 K/B, PS2 Mouse, Modem Ring-in COM#1…
Onboard PCI Devices
LAN --> Integrates 10/100Mps Fast Ethernet controller with onboard
(Optional)
S-ATA --> 2 S-ATA Port for up to 150MB/sec transfer rate
IDE --> 2 ordinary IDE Port with PIO/Ultra DMA-33/66/100 for up to 4
Realtek RTL8101L LAN Chipset
devices
Legacy IO Controller
Winbond W83627HF LPC IO controller with floppy, printer, game, serial
and SIR interface
Audio
Six channel audio with analog and digital output using Cmedia CMI9739A
AC’97 CODEC
- AC’97 v2.2 compliant
- In 2-CH mode, supports Line-In (Light blue), Line-Out (Lime) and Mic-In
(Pink) at rear panel
- In 6-CH mode, supports Rear speaker-out (Light blue), Front speaker-out
(Lime) and Center&Subwoofer speaker-out (Pink) at rear panel
- Supports CD-In, Aux-In and S/PDIF-in/out interface
- Supports Line-out and Mic-In for front panel
Page 2-2
Peripheral Interfaces
) At Rear Panel
PS/2 keyboard and mouse ports
One Parallel (printer) port
One Serial port
One VGA port
One RJ45 LAN connector (Optional)
Four USB2.0 ports
Three Audio jacks
) Onboard connector and pin-header
One floppy drive connector
Two IDE connectors
Four extra USB2.0 ports
One CD-IN and One AuX-IN connector
One S/PDIF in/out connector
One IR connector
One Front Panel Audio connector
One Game port connector
One COM2 connector
Two S-ATA connectors
Two Fan connectors
Features
Front Panel Controller
Supports Reset & Soft-Off switches
Supports HDD & Power LEDs
Supports PC speaker
Expansion Slots
One AGP slot supporting 1.5v 4X/8X AGP card
- AGP v3.0 compliant
Page 2-3
Features
Three PCI slots with Bus Master support
- PCI v2.3 compliant
Other Features
Magic Health – a H/W monitoring software utility, for voltages, temperatures
and fan-speeds sensing
EZ Boot – An easy way let end-user can choose to boot from hard drive,
CD-ROM, floppy, …
Supports exclusive KBPO (Keyboard Power On) function
Excellent Overclocking capabilities through
- subtle frequency tuning on FSB
- Supports complete Asynchronous FSB/Memory and Asynchronous FSB/
AGP, PCI scheme for overclocking
Form Factor
245mm x 220 mm Micro ATX size
Page 2-4
Installation
Section 3
INSTALLATION
Page 3-1
Installation
Mainboard Layout
Page 3-2
Installation
Easy Installation Procedure
The following must be completed before powering on your new system:
3-1. CPU Installation
3-2. Jumper Settings
3-3. System Memory Configuration
3-4. Expansion Slots
3-5. Device Connectors
3-1 CPU Installation
Figure 1
Step 1
Open the socket by raising the actuation
lever.
Figure 2
Pin 1
Step 2
Align pin 1 on the CPU with pin 1 on
the CPU socket as shown in the
illustration above. The CPU is keyed to
prevent incorrect insertion. Don’t force
the processor into the socket. If it does
not go in easily, check for mis-orienta-
tion and reinsert the CPU.
Make sure the processor is fully
inserted into the socket.
Page 3-3
Installation
Figure 3
Step 3
Close the socket by lowering and
locking the actuation lever.
Step 4
Apply thermal compound to the top of
the CPU and install the heatsink as
Figure 4
shown.
Figure 5 Figure 6
Step 5
Install the cooling fan assembly. Press
the two clips in the direction of the
arrows shown in Figure 5 to secure the
Step 6
Plug the CPU fan into the CPU fan
connector.
The installation is complete.
assembly to the CPU socket.
NOTES:
• Damage to Intel Pentium
TM
4 processors might result if installed with
incorrect CPU fan and heatsink assemblies. Use Intel’s design thermal
solution shown in the illustrations above: an active heatsink; an extruded
aluminum heatsink base; and a fan attached to the top of the fin array.
• Apply heatsink thermal compound or paste to the CPU to avoid CPU
overheating and damage.
• In accordance with Intel Corp. specifications, do not install a CPU over
50 times to avoid bending the pins and damaging the CPU.
Page 3-4
3-2 Jumper Settings
Installation
JCMOS:
Clear CMOS data Jumper
If the CMOS data becomes corrupted or you
forgot the supervisor or user password,
clear the CMOS data to reconfigure the
system back to the default values stored in
the ROM BIOS.
Settings:
1
1-2: Normal (Default)
2-3: Clear CMOS
To CMOS Clear data, please follow the steps below.
1. Turn off the system.
2. Change the jumper from “1-2” to “2-3” position
for a few seconds.
3. Replace the jumper on to the “1-2” position.
4. Turn on the system and hold down the <Del>
key to enter BIOS setup.
Page 3-5
Installation
3-3 System Memory Configuration
Memory Layout
The mainboard accommodates two PC2100/PC2700/PC3200 184-pin DIMMs (Dual In-
line Memory Modules):
• Supports up to 2.0GB of 266/333/400MHz DDR SDRAM.
• Supports two 64-bit wide DDR data channels.
• Available bandwidth up to 3.2GB/s (DDR400) for single-channel mode and
6.4GB/s (DDR400) in dual-channel mode.
• Supports non ECC DIMMs.
• Registered DIMMs not supported.
• Supports 128-Mb, 256-Mb, 512Mb DDR technologies.
• Supports only x8, x16, DDR devices with four banks.
• SPD (Serial Presence Detect) scheme for DIMM detection support.
• Supports configurations defined in the JEDEC DDR1 DIMM specification
only.
Figure 6 and Table 1 show several possible memory configurations.
<Figure 6>
<Table 1>
* SS: Single-Sided DIMM, DS: Double-Sided DIMM
DDR-A1 DIMM 1
DDR-B1 DIMM 2
MMID1
)tib-46(
1#MMIDSD/SSSD/SS
2#MMIDSD/SSSD/SS
MMID2
)tib-821(
Page 3-6
Dual Channel
Installation
NOTES:
• When FSB is 400MHz, only DDR266 is support.
• When FSB is 533MHz, DDR266/333 are support.
• When FSB is 800MHz, the supports DDR333/400 (With DDR333, adaptive
synchronization aligns to the closest FSB to memory clock ratio, setting memory
channel to 320MHz)
• For one DIMM memory configuration, the DIMM can be located on any of
DIMM#1 to DIMM#2 in 64-bit mode.
• For two DIMMs memory configuration, it is recommended to mount the
DIMMs on slots of the same color to enable 128-bit mode. Only in keeping
those DIMMs in same type and same size are preferred.
• Using non-compliant memory with higher bus speeds (overclocking) may
severely compromise the integrity of the system.
Page 3-7
Installation
DIMM Module Installation
Figure 8 displays the notch on the DDR DIMM memory module.
DIMMs have 184 pins and one notch that matches with the DDR DIMM socket.
DIMM modules are installed by placing the chip firmly into the socket and
pressing straight down as shown in figure 9 until the white clips close and the
module fits tightly into the DIMM socket (figure 10).
CENTER KEY ZONE
(2.5 V DRAM)
Figure 8 - DIMM notch
Figure 9 - DIMM module clips before installation
Figure 10 - DIMM module clip after installation
To remove the DIMM module press down the white clips and the module will be
ejected from the socket.
Page 3-8
3-4 Expansion Slots
Installation
AGP Slot
The mainboard is equipped with an AGP
slot. Make sure you install a card that
supports the 1.5V specification.
AGP Slot
PCI Slots
PCI Slots
The mainboard is equipped with 3 PCI
slots.
Installing an Expansion Card
The steps below assume that the mainboard is already installed in the system chassis.
1. Make sure the PC and all other peripheral devices connected to its has been
powered down.
2. Disconnect all power cords and cables.
3. Remove the system unit cover.
4. Remove the bracket of the slot that you intend to use. (You need to remove the
screw in order to remove the bracket.)
5. Align the card above the slot then press it down firmly until it is completely
seated in the slot.
6. Secure the card to the chassis with the screw you removed in step 4.
7. Replace the system unit cover.
8. Power on the PC.
9. Enter the BIOS step program to make the necessary settings.
10. Save the settings and restart the PC.
11. Install the software drivers of the expansion cards, if necessary.
Page 3-9
Installation
AGP Card Installation Caution
1. AGP card component is blocked
by DIMM socket lock.
2. AGP slot clicker is not locked.
3. AGP card edge connector is not
inserted properly.
1. AGP card component is not
blocked by DIMM socket lock.
2. AGP slot clicker is locked.
3. AGP card edge connector is
inserted properly.
Page 3-10
1. AGP slot clicker is not locked.
2. AGP card edge connector is not
inserted properly.
1. AGP slot clicker is locked.
2. AGP card edge connector is
inserted properly.
3-5 Connectors
Installation
PS/2
Mouse
PS/2
Keyboard
COM1
JCPU_FAN
Parallel Port
VGA1
JPWR_FAN
RJ-45 LAN
(Optional)
Line-in/Rear out (Light blue)
Line-out/Front out (Lime)
Mic-in/Center&Subwoofer (Pink)
USB2.0
ports
USB2.0
ports
Figure 11 - I/O Ports
JCPU_FAN / JPWR_FAN:
CPU/Power Fan Power Connectors
JCPU_FAN: The CPU must be kept cool by using a
heatsink with fan assembly.
JPWR_FAN: If you are installing an additional fan in
the unit, connect to this fan connector.
JCPU_FAN
Sence
Ground
+12V
JPWR_FAN
Sence
Ground
+12V
S/PDIF: Sony/Philips Digital InterFace connector
This connector is the digital link between the
mainboard and your audio devices, such as CD
player, sampler or DAT recorder. It allows the
digital transmission of audio data in S/PDIF format.
SPDIF_OUT
2
1
VCC
GND
NC
6
5
SPDIF_IN
Page 3-11
Installation
34 33
1
2
FDD
40 39
2
IDE1/IDE2
FDD: Floppy Controller Connector
This mainboard is equipped with a floppy disk drive
connector for connecting up to 2 floppy disk drives.
IDE1
IDE2
IDE1/IDE2: Ultra DMA-66/100 Primary/Secondary
FDD
IDE Connector
This mainboard is equipped with 2 IDE disk connec-
tors for connecting up to 4 ATA-100 IDE drives.
It supports PIO and DMA mode operations for
maximum data transfer rate of 100MB/sec per channel.
When use two IDE drives, one must be set to Master
mode and the other one to Slave mode. Refer to your
1
disk drive user’s manual for information about selecting the proper drive switch settings.
ATX2
4
3
+12V+12V
GroundGround
2
1
ATX2
Page 3-12
10
20
1
11
ATX1
ATX1
ATX2: 4-pin ATX12V Power Connector
The mainboard is equipped with a standard 20-pin
ATX main power connector and a 4-pin +12V
power connector for connecting an ATX12V
power supply. The plugs of the power cables are
designed to fit in only one orientation. Find the
proper orientation then insert the plugs into the
connectors until they fit in place.
Caution:
The ATX1 and ATX2 Power Connector must be used simultaneously
ATX1: 20-pin ATX Power Connector
+5V+12V
+5V5VSB
-5VPW-OK
GroundGround
Ground+5V
GroundGround
PS-ON+5V
GroundGround
-12V3.3V
3.3V3.3V
or else this system will not boot-up.
The board requires a minimum of 250 Watt power
supply to operate. Your system configuration (amount
of memory, add-in cards, peripherals, etc.) may
exceed this minimum power requirement, power usage
therefore to ensure that adequate power is provided,
use a 300 Watt (or greater) power supply.
Installation
CFPA: Front Panel Audio Connector
When the jumpers are removed this connec-
tor can be used for front panel audio. The
front panel line-out phone jack should have
“normal close” switch . Without phone plug
inserted, the rear panel audio is enabled.
With phone plug inserted, the rear panel
audio will be disabled.
1
MIC_In
Front Line-out-R
Settings
Pins (5-6) & (9-10) Short (default): Only the onboard rear
panel audio jack can be used.
Pins (5-6) & (9-10) Open: Only front panel audio jack can
be used.
In 2-Channel audio mode, Mic-In is shared for both front panel and rear panel.
NC
Front Line-out-L
9210
In 6-Channel audio mode, the Mic-In is dedicated for front panel use, and rear
panel Mic-In function will switch to Center and Subwoofer support.
GND
+5V
Rear Line-out-FR
Key
Rear Line-out-FL
CD-IN
AUX-IN
CD-IN/AUX-IN: CD Audio_IN Connector
The CD-IN and AUX-IN connectors are used to
receive audio form a CD-ROM drive, TV tuner or
MPEG card.
CD-IN AUX-IN
1
CD_IN_Right
CD_Reference
CD_IN_Left
1
AUX_IN_Right
GND
AUX_IN_Left
Page 3-13
Installation
GAME1: Game/MIDI connector
This port works well with any application that is
compatible with the standard PC joystick.
12
1
2
COM2: Serial Port Connector
The serial ports can be used with modems, serial
printers, remote display terminals, and other serial
device.
RTS
RI
RXD
CTS
TXD
DTR
NC
Ground
10
9
DSR
2
1
DCD
SATA1 / SATA2: Serial ATA Connectors
Page 3-14
SATA2
SATA1
These connectors enable you to connect two Serial
ATA devices that conform to the Serial ATA
specification.
1
GND
B-B+
A+
GND
A-
GND
CUSB4
Installation
CUSB3/CUSB4: Four USB 2.0 ports
This mainboard includes 4 additional onboard USB
ports, identified by 2 10-pin connector.
If you wish to use the additional USB ports, install the
card-edge bracket to the system chassis then insert
its cables to this 10-pin connector.
CUSB3
USB2.0 allows data transfer speed up to 480Mbps.
1
VCC
Data0-
Data0+
GND
Key
9
Please make sure the USB cable has the same
pin assignment. A different pin assignment
may cause damage to the system.
If you need the USB cable, please contact our
retailer.
2
VCC
Data1-
Data1+
GND
NC
10
CAUTION !
Page 3-15
Installation
CFP
CSPK
CFP: Front Panel Connector
HD_LED
This LED will light up whenever the hard drive
is being accessed.
PWR_LED
This connects to the power button of the
system chassis
RST
CIR
CFP
This switch allows you to reboot without
having to power off the system thus prolonging
the life of the power supply or system.
PW_ON
This is connected to the power button on the
case. Using the Soft-Off by Pwr-BTTN feature,
you can choose either Instant Off (turns system
off immediately), or 4 sec delay (push the
button for 4 seconds before the system turns
off). When the system is in 4 sec delay mode,
suspend mode is enabled by pushing the
button momentarily.
CIR
CSPK
Page 3-16
CIR: IR connector
Connect your IrDA cable to this IR connector.
1. VCC 4. GND
2. NC 5. IRTX
3. IRRX
CSPK: Speaker
Connect to the system’s speaker for beeping
1. VCC 3. GND
2. NC 4. Speaker
Installation
3-6 External Modem Ring-in Power ON and
Keyboard Power ON Functions (KBPO)
Modem-Ring Power ON Function
The I/O chipset provides the two serial ports with the External Modem Ring-in Power
ON function. Once you connect an external modem to COM1 or COM2, the
mainboard enables you to turn on the system through remote and host dial-up
control.
Keyboard Power ON Function
The mainboard features a keyboard power on function that enables you to turn on
the power supply using a keypress. Follow these instructions to enable the Key-
board Power ON function .
Step : Use the Keyboard Power ON function (KBPO) to turn on the system by using
a key press, password, or hot key combination etc. as set in the BIOS Power
Management Setup menu (refer to the BIOS Power Management Setup for
details). The BIOS default setting is keyboard Hot key (<Ctrl> + <F1>). To power
off the system, use the Soft-OFF function under Windows XP/ME/2000/98.
(refer to Windows online help).
NOTES:
• Intel ATX version 2.0 specification recommends a power supply that
supplies >=2.0 A in 5.0 VSB. However, this mainboard supports a 5.0
VSB standby power supply > = 2A .
• We recommend you use the power supply with 2.0 A in 5.0 VSB, which
supports PCI 2.3 specification for remote power-on and wake-up
functions.
Page 3-17
Installation
3-7 STR (Suspend To RAM) Function
This mainboard supports the STR (Suspend To RAM) power management
scheme by maintaining the appropriate power states in the DDR SDRAM
interface signals. The power source to the DDR SDRAM must be kept active
during STR (ACPI S3). Advanced Configuration Power Interface (ACPI)
provides many Energy Saving Features for operating systems that support
Instant ON and QuickStartTM function.
1. To enable STR functionality to save system power :
a. Install ACPI certified add-on cards (such as AGP, LAN, and modem cards).
b. In BIOS under Power Management Setup (refer to Section 4), select “ACPI
Suspend Type: S3(STR)” and “USB Port Wake Up Control” (if you have a
USB mouse or keyboard device).
c. Install Windows® XP/2000/ME/98SE.
d. Restart the system.
e. Open the Control Panel Power Management application, and click the
Advanced tab. In the Power buttons section, select “Stand By” from the
drop-down lists.
2. To activate the STR function, click the START button and choose Shut Down.
In the Shut Down Windows dialog box, select the Stand By option to enter STR
mode.
The following lists the differences between STR power saving mode and Green
(or Suspend) mode:
a. STR is the most advanced Power Management mode.
b. STR cuts all the power supplied to peripherals except to memory - max. power
saving.
c. STR saves and keeps all on-screen data including any executed applications
to DDR SDRAM.
d. In STR mode, you must push the power button (connected to the onboard PW-
On of CFP pin), click your USB mouse buttons, or press your USB keyboard
keys to wake up your system to the last display.
Page 3-18
BIOS
Section 4
BIOS SETUP
Main Menu
The ROM BIOS provides a built-in Setup program which allows user to modify the
basic system configuration and hardware parameters. The modified data is stored in
a battery-backed CMOS, so that data will be retained even when the power is turned
off. In general, the information saved in the CMOS RAM will stay unchanged unless
there is a configuration change in the system, such as hard drive replacement or a
device is added.
It is possible for the CMOS battery to fail causing CMOS data loss. If this happens
you will need install a new CMOS battery and reconfigure your BIOS settings.
The BIOS setup screen and description are for reference only, and may
not exactly match what you see on your screen. The contents of BIOS are
subject to change without notice. Please visit our website for updates.
To enter the Setup Program :
Power on the computer and press the <Del> key during the POST (Power On Self
Test). The BIOS CMOS SETUP UTILITY opens. (Figure 1)
Figure 1: CMOS Setup Utility
Page 4-1
BIOS
The main menu displays all the major selection items. Select the item you need to
reconfigure. The selection is made by moving the cursor (press any direction (arrow
key ) to the item and pressing the ‘Enter’ key. An on-line help message is displayed
at the bottom of the screen as the cursor is moved to various items which provides a
better understanding of each function. When a selection is made, the menu of the
selected item will appear so that the user can modify associated configuration
parameters.
4-1 Standard CMOS Setup
Choose “STANDARD CMOS FEATURES” in the CMOS SETUP UTILITY Menu
(Figure 2). Standard CMOS Features Setup allows the user to configure system
settings such as the current date and time, type of hard disk drive installed, floppy
drive type, and display type. Memory size is auto-detected by the BIOS and
displayed for your reference. When a field is highlighted (use direction keys to move
the cursor and the <Enter> key to select), the entries in the field can be changed by
pressing the <PgDn> or the <PgUp> key.
Page 4-2
Figure 2: Standard CMOS Setup
BIOS
Notes:
• If the hard disk Primary Master/Slave and Secondary Master/Slave are
set to Auto, the hard disk size and model will be auto-detected.
• The “Halt On:” field is used to determine when the BIOS will halt the
system if an error occurs.
• Floppy 3 Mode support is a mode used to support a special 3.5-inch
drive used in Japan. This is a 3.5-inch disk that stores 1.2 MB. The
default setting for this is disabled.
4-2 Advanced BIOS Features
Selecting the “ADVANCED BIOS FEATURES” option in the CMOS SETUP UTILITY
menu allows users to change system related parameters in the displayed menu. This
menu shows all of the manufacturer’s default values for the board.
Pressing the [F1] key displays a help message for the selected item.
Figure 3: BIOS Features Setup
Page 4-3
BIOS
CPU L1 & L2 Cache
This controls the status of the processor’s internal Level One and Level Two cache.
The default is Enabled.
Options: Enables, Disabled.
Hyper-Threading Technology
Enables the CPU Hyper-Threading Technology.
Options: Enables, Disabled.
Note: It is recommend to enable Hyper-Threading Technology on system with
Windows XP and Linux 2.4 and disabling it for legacy OS.
Hard Disk Boot Priority
This item allows you to select the hard disk boot priority.
First /Second/Third/Other Boot Device
The BIOS attempts to load the operating system from the devices in the sequence
selected in these items.
Options: Floppy, LS120, Hard Disk, CDROM, ZIP100, USB-FDD, USB-ZIP, USB-
CDROM, USB-HDD, LAN, Disabled.
Boot Other Device
When enabled, the system searches all other possible locations for an operating
system if it fails to find one in the devices specified under the first, second, and third
boot devices. The default is Enabled.
Options: Enabled, Disabled.
Swap Floppy Drive
This will swap your physical drive letters A & B if you are using two floppy disks.
Options: Enables, Disabled.
Boot Up Floppy Seek
If this item is enabled, it checks the size of the floppy disk drives at start-up time.
You don’t need to enable this item unless you have a legacy diskette drive with
360K capacity. The default is Disabled.
Options: Enabled, Disabled.
Boot Up NumLock Status
This controls the state of the NumLock key when the system boots. The default is On.
On: The keypad acts as a 10-key pad.
Off: The keypad acts like cursor keys.
Page 4-4
BIOS
Security Option
This category allows you to limit access to the System and Setup, or just to Setup.
The default is Setup.
System: The system will not boot and access to Setup will be denied unless the
correct password is entered at the prompt.
Setup: The system will boot, but access to Setup will be denied unless the
correct password is entered at the prompt.
APIC Mode
This item allows you to enable APIC (Advanced Programmable Interrupt Controller)
functionality. APIC is an Intel chip that provides symmetric multiprocessing (SMP)
for its Pentium systems.
Options: Enabled, Disabled.
HDD S.M.A.R.T. Capability
The S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology) system is a
diagnostics technology that monitors and predicts device performance. S.M.A.R.T.
Software resides on both the disk drive and the host computer.
The disk drive software monitors the internal performance of the motors, media, heads,
and electronics of the drive. The host software monitors the overall reliability status of
the drive. If a device failure is predicted, the host software, through the Client WORKS
S.M.A.R.T applet, warns the user of the impending condition and advises appropriate
action to protect the data. The default is Disabled.
Options: Enabled, Disabled.
Full Screen LOGO Show
This item allows you determine Full Screen LOGO display during POST.
Options: Enabled, Disabled.
Page 4-5
BIOS
4-3 Advanced Chipset Features
Choose the “ADVANCED CHIPSET FEATURES” option in the CMOS SETUP
UTILITY menu to display following menu.
Figure 4: Chipset Features Setup
DRAM Timing Selectable
For setting DRAM Timing, select By SPD to follow Intel PC DDR SDRAM Serial
Presence Detect Specification.
Options: Manual, By SPD.
CAS Latency Time
Enables you to select the CAS latency time. The value is set at the factory depending
on the DRAM installed. Do not change the values in this field unless you change
specifications of the installed DRAM and DRAM clock from DRAM Timing Selectable.
The default is by DRAM SPD.
Options: 2, 2.5, 3.
Active to Precharge Delay
This item specifies the number of clock cycles needed after a bank active command
before a precharge can occur (sets the minimum RAS pulse width.). The default is by
DRAM SPD.
Options: 5, 6, 7, 8.
Page 4-6
BIOS
DRAM RAS# to CAS# Delay
This item sets the timing parameters for the system memory such as the CAS (Column
Address Strobe) and RAS (Row Address Strobe). The default is by DRAM SPD.
Options: 2, 3, 4.
DRAM RAS# Precharge
This item refers to the number of cycles required to return data to its original
location to close the bank or the number of cycles required to page memory before
the next bank activate command can be issued. The default is by DRAM SPD.
Options: 2, 3, 4.
Aggressive Memory Mode (AMM)
Aggressive Memory Mode reduces delays within the chipset to improve DDR
DRAM usage efficiency.
Options: Max, Turbo, Expert, Standard.
Performance upgrade using AMM will largely depend on hardware
availability within the chipset.
CPU Bus Park
Options: Disabled, Enabled.
Intel Fast CS
Options: Auto, Disabled, Enabled.
Intel CPC Function
Options: Auto, Disabled, Enabled.
System BIOS Cacheable
This item allows the system to be cached in memory for faster execution.
Options: Disabled, Enabled.
Video BIOS Cacheable
This item allows the video to be cached in memory for faster execution.
Options: Disabled, Enabled.
Delay Prior to Thermal
Set this item to enable the CPU Thermal function to engage after the specified time.
The default is 16 minutes.
Options: 4, 8, 16, 32 minutes.
Page 4-7
BIOS
AGP Aperture Size (MB)
This item defines the size of the aperture if you use an AGP graphics adapter. It
refers to a section of the PCI memory address range used for graphics memory.
Options: 4, 8, 16, 32, 64, 128, 256 MB.
Init Display First
If two video cards are used (1 AGP and 1 PCI) this specifies which one will be the
primary display adapter.
Options: PCI Slot, AGP.
** On-Chip VGA Settings **
On-Chip VGA
This item allows you to control the on-chip VGA.
Options: Enabled, Disabled.
On-Chip Frame Buffer Size
This item allows you to control the on-chip frame buffer size.
Options: 1MB, 8MB, 16MB.
Boot Display
This item allows you to selcet the boot display device.
Options: Auto, CRT, TV, EFP.
Page 4-8
4-4 Integrated Peripherals
Figure 5: Integrated Peripherals
RealTek Lan Boot ROM (Optional)
Enable/disable the onboard LAN Boot ROM. The default is Disabled.
Options: Enabled, Disabled.
BIOS
OnChip IDE Device
Scroll to OnChip IDE Device and press <Enter>. The following screen appears:
Page 4-9
BIOS
IDE HDD Block Mode
IDE Block Mode allows the controller to access blocks of sectors rather than a
single sector at a time. The default is Enabled.
Options: Enabled, Disabled.
IDE DMA transfer access
Automatic data transfer between system memory and IDE device with minimum
CPU intervention. This improves data throughput and frees CPU to perform other
tasks.
Options: Enabled, Disabled.
On-Chip Primary PCI IDE
The integrated peripheral controller contains an IDE interface with support for two
IDE channels. Select “Enabled” (default) to activate each channel separately.
Options: Enabled, Disabled.
Note: If you do not use the onboard IDE connector, then you will need to set the
Onboard Primary PCI IDE and Onboard Secondary PCI IDE to “Disabled”.
IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4)
for each of the four IDE devices that the onboard IDE interface supports. Modes 0
to 4 provide successively increased performance. In Auto mode, the system
automatically determines the best mode for each device.
Options: Auto, Mode 0 ~ 4.
IDE Primary/Secondary Master/Slave UDMA
This allows you to select the mode of operation for the IDE drive. Ultra DMA-33/
66/100 implementation is possible only if your IDE hard drive supports it and the
operating environment includes a DMA driver. If your hard drive and your system
software both support Ultra DMA-33/66/100, select Auto to enable UDMA mode
by BIOS or you can manually disable it.
Options: Auto, Disabled.
Page 4-10
BIOS
*** On-Chip Serial ATA Setting ***
SATA Mode (ICH5R only)
This item allows you to select Serial ATA Mode. When RAID is enabled, Serial
ATA ports 0 and 1 will default to "SATA0" and "SATA1".
Options: IDE, RAID.
Note: O/S driver for this RAID feature is available only for Windows XP, please
check future updates for other O/S support.
On-Chip Serial ATA
Applicable only when RAID function above is "Disabled". Assigning "Primary"
will make Serial ATA IDE the Primary port and in effect disable the Parallel-ATA
Primary port. Similarly, assigning "Secondary" will disable the Parallel-ATA
Secondary port.
Options: Enhanced Mode, Disabled, For Primary, For Secondary.
Serial ATA Port 0 /1 Mode
Display Serial ATA Port 0/1 assignment to IDE device.
The following screen shows SATA Mode "RAID".
<RAID Enhance Mode>
Display only
Page 4-11
BIOS
The following screen shows SATA Mode "IDE" and on-chip Serial ATA
assigned to "Enhanced Mode".
Note: Enhanced mode is available only for Windows2000 and XP.
Display only
<IDE Enhance Mode>
The following screen shows SATA Mode "IDE" and on-chip Serial ATA
assigned to "For Primary".
Page 4-12
Display only
<Compatible Mode>
The following screen shows SATA Mode "IDE" and on-chip Serial ATA
assigned to "For Secondary".
Display only
<Compatible Mode>
BIOS
Page 4-13
BIOS
Onboard PCI Device Setup
Scroll to Onboard PCI Device Setup and press <Enter>. The following screen appears:
USB Controller
Enables the USB controller.
Options: Disabled, Enabled.
USB 2.0 Controller
Enables the EHCI (USB2.0) controller.
Options: Disabled, Enabled.
USB Keyboard Support
Enable/Disable support for USB keyboard. The default is Auto detect.
Options: Auto, Enabled, Disabled.
USB Mouse Support
Enable/Disable support for USB mouse. The default is Disabled.
Options: Enabled, Disabled.
AC97 Audio
This item allows you disable the chipset on-chip support for AC97 Audio. The
system default is Auto.
Options: Auto, Disabled.
Game Port Address
Select an address for the Game port.
Options: 201, 209, Disabled.
Midi Port Address
Select an address for the Midi port.
Options: 290, 300, 330, Disabled.
Page 4-14
BIOS
Midi Port IRQ
Select an interrupt for the Midi port.
Options: 5, 10.
Onboard LAN Device (Optional)
Enables the onboard LAN feature.
Options: Enabled, Disabled.
Onboard I/O Chip Setup
Scroll to Onboard I/O Chip Setup and press <Enter>. The following screen appears:
Onboard FDC Controller
Select Enabled if your system has a floppy disk controller (FDC) installed on the
system board and you wish to use it. If you install add-in FDC or the system has
no floppy drive, select Disabled in this field.
Options: Enabled, Disabled.
Onboard Serial Port 1
Select an address and corresponding interrupt for the serial ports.
Options: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled, Auto.
Onboard IrDA Port
Select an address and corresponding interrupt for IrDA port.
Options: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled, Auto.
Onboard Parallel Port
This field allows the user to configure the LPT port.
Options: 378/IRQ7, 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
This field allows the user to select the parallel port mode.
Options: SPP, EPP, ECP, ECP+EPP.
Page 4-15
BIOS
EPP Mode Select
This item allows you to determine the IR transfer mode of onboard I/O chip.
Options: EPP1.9, EPP1.7.
ECP Mode USE DMA
This field allows the user to select DMA1 or DMA3 for the ECP mode.
Options: DMA1, DMA3.
Page 4-16
BIOS
4-5 Power Management Setup
Choose the “POWER MANAGEMENT SETUP” in the CMOS SETUP UTILITY to
display the following screen. This menu allows the user to modify the power
management parameters and IRQ signals. In general, these parameters should not be
changed unless it’s absolutely necessary.
Figure 6: Power Management
ACPI Suspend Type
This item allows you to select S1(POS) or S3(STR) function. When set to “S3(STR)”
or “S1&S3” the following two fields become available.
Options: S1(POS), S3(STR), S1&S3.
Run VGABIOS if S3 Resume
This determines whether or not to enable the system to run the VGA BIOS when
resuming from S3(STR) or S1&S3.
Options: Auto, Yes, No.
S3 KB Wake-up Function
This determines whether or not to enable keyboard/mouse activity to awaken the
system from S3(STR) or S1&S3.
Options: AnyKey or Mouse, By PowerOn Func., AnyKey, Mouse.
Page 4-17
BIOS
POWER ON Function
Enables computer power on by keyboard, mouse, or hotkey activity. The default is
Hot KEY.
Password: Requires you to enter a password when using the keyboard
to power on. Set the password in the next field “KB Power ON
Password.”
Hot KEY: Enables you to use a hot key combination to power on the
computer. Set the hot key combination in the “Hot Key Power
ON” field.
Any KEY: Enables you to set any keyboard activity to power on the
computer.
BUTTON ONLY: Requires you to push the computer power button to power on
the system.
Keyboard 98: Enables you to set the Windows 98 key to power on the system.
Keyboard Power ON Password
Press “Enter” to create a password that is required when you use the keyboard to
power on the system. You must set the POWER ON Function to “Password” to be
prompted for a password at power on.
Hot Key Power ON
Enables you to set a hot key combination to be used for powering on the system.
The default is Ctrl-F1.
Options: Ctrl+F1 ~ Ctrl+F12.
PWRON After PWR-Fail
This item enables your computer to automatically restart or return to its last operat-
ing status after power returns from a power failure.
Off: The system stays off after a power failure.
Former-Sts: The system returns to the state it was in just prior to the power
failure.
Power Management
Use this to select your Power Management selection. The default is User define.
Max. saving: Maximum power savings. Inactivity period is 1 minute in each mode.
Min. saving: Minimum power savings. Inactivity period is 1 hour in each mode.
User define: Allows user to define PM Timers parameters to control power saving
mode.
Page 4-18
BIOS
Video Off Method
This option allows you to select how the video will be disabled by the power
management. The default is V/H Sync + Blank
V/H Sync + Blank: System turns off vertical and horizontal synchronization ports
and writes blanks to the video buffer.
DPMS Support: Select this option if your monitor supports the Display Power
Management Signaling (DPMS) standard of the Video
Electronics Standards Association (VESA). Use the software
supplied for your video subsystem to select video power
management values.
Blank Screen: System only writes blanks to the video buffer.
HDD Power Down
When enabled and after the set time of system inactivity, the hard disk drive will be
powered down while all other devices remain active.
Options: Disabled, 1 ~ 15 Min.
Soft-Off by PWR-BTTN
Use this to select your soft-off function. The default is Instant Off.
Instant Off: Turns off the system instantly.
Delay 4 Second : Turns off the system after a 4 second delay. If momentary press
of button, the system will go into Suspend Mode. Press the
power button again to make system back to work.
CPU THRM-Throttling
This item sets the percentage of time that the CPU is idled if CPU throttling is
initiated by excess heat. The default setting is 50%.
Options: 12.5%, 25.0%, 37.5%, 50.0%, 62.5%, 75.0%, 87.5%.
PowerOn by PCI Card
An input signal form PME on the PCI card awakens the system from a soft off state.
Options: Enabled, Disabled.
Power On by Ring or WOL
When enabled, any modem or LAN activity awakens the system from power savings
mode.
Options: Enabled, Disabled.
Page 4-19
BIOS
USB Wake-Up From S3
When enabled, any USB activity awakens the system from S3 mode.
Options: Enabled, Disabled.
RTC Alarm Resume
When enabled, you can set the date and time in the following two fields. Any event
occurring at the specified date or time awakens the system from power savings
mode.
4-6 PNP/PCI Configuration
The PNP/PCI configuration program is for the user to modify the PCI/ISA IRQ
signals when various PCI/ISA cards are inserted in the PCI or ISA slots.
WARNING: Conflicting IRQ’s may cause the system to not find certain devices.
Figure 7: PNP/PCI Configuration Setup
Resources Controlled By
Determines what controls system PNP/PCI resources. The default is Auto (ESCD).
Manual: PNP Card’s resources are controlled manually. The “IRQ Resources” field
becomes available and you can set which IRQ-X and DMA-X are
assigned to PCI/ISA PNP or Legacy ISA Cards.
Page 4-20
BIOS
Auto: If your ISA card and PCI cards are all PNP cards, BIOS assigns the
interrupt resource automatically.
PCI/VGA Palette Snoop
This item is designed to overcome problems that may be caused by some nonstandard
VGA cards. This board includes a built-in VGA system that does not require palette
snooping therefore you must leave this item disabled.
Options: Enabled, Disabled.
AGP SLOT / AC97 / Slot 1 ~ Slot 3 / LAN INT Assignment
This setting enables the user to specify what IRQ will be assigned to the AGP/
AC97/PCI Slot 1 ~ PCI Slot 5/LAN devices in the chosen slot.
Options: Auto, 3, 4, 5, 7,9 ,10, 11, 12, 14 & 15. The default is Auto.
Interrupt requests are shared as shown below:
ATNIBTNICTNIDTNIETNIFTNIGTNIHTNI
tolSPGA
79CA
1tolS
2tolS
tolS3
)lanoitpO(NALdraobnO
1BSUdraobnO
2BSUdraobnO
3BSUdraobnO
4BSUdraobnO
0.2BSU
SUBMS
V
V
V
V
V
V
V
V
V
V
V
V
IMPORTANT!
If using PCI cards on shared slots, make sure that the drivers support “Shared IRQ”
or that the cards don’t need IRQ assignments. Conflicts will arise between the two
PCI groups that will make the system unstable or cards inoperable.
Page 4-21
BIOS
4-7 PC Health Status
Figure 8: PC Health Status
Show PC Health in POST
When this function is enabled the PC Health information is displayed during the
POST (Power On Self Test).
Options: Enabled, Disabled.
CPU Warning Temperature
Sets the temperature at which the computer will respond to an overheating CPU. The
default is Disabled.
Options: Disabled, 50OC/122OF ~ 70OC/158OF.
Current CPU Temperature
Displays the current CPU temperature.
Current System Temperature
Displays the current system temperature.
Current CPU/Chassis/Power FAN Speed
Displays the current speed of the CPU, chassis, and power fan speed in RPMs.
Vagp (V)
The voltage level of power supplied to AGP card.
Page 4-22
BIOS
Vcore (V)
The voltage level of the CPU(Vcore).
Vdimm(V)
The voltage level of the DRAM.
VBAT(V)
The voltage level of the battery.
+ 5V, + 12V, 5VSB(V)
The voltage level of the switching power supply.
ACPI Shutdown Temperature
This is the temperature that the computer will turn off the power to combat the
effects of an overheating system. (requires ACPI to be enabled in Power Manage-
ment BIOS and ACPI compliant operating system.) The default is Disabled.
Options available are 60oC/140oF to 95oC/203oF in increments of 5oC.
Page 4-23
BIOS
4-8 Power BIOS Features
400
66
Figure 9: Frequency/Voltage Control
Watching-Dog Function
If you select “Enabled” and overclock fail before POST code 26h, the system will
reset automatically by default configuration.
Options: Enabled, Disabled.
33
CPU FSB/SPEED
Enables you to set the CPU front side bus speed at increments of 1MHz step. The
default is 100 MHz. Press <Enter> to display the following screen:
Key in the DEC (decimal) number for the CPU FSB/SPEED.
Page 4-24
BIOS
Note: Overclocking failure will result in no display on the monitor. At this
moment, press <Insert> key to return to the initial or default setting
to boot up your system.
Memory Frequency
Enables you to select a ratio of the DDR DRAM to match the installed DRAM
frequency 266/333/400MHz. We recommend that you leave this item at the default
value.
When the FSB is 400MHz the options will display 3:4 =>DDR266.
When the FSB is 533MHz the options will display 1:1 =>DDR266, 4:5 =>DDR333 and
Auto =>DDR333 (by SPD).
When the FSB is 800MHz the options will display 1:1=>DDR400, 5:4=>DDR320 and
Auto=>DDR400 (by SPD).
CPU Clock Ratio
Use this item to select a multiplier for the system front side bus (FSB) frequency.
The value of the multiplier must be set so that:
Multiplier x Front side Bus Frequency = CPU Clock Speed
For example, if you have a processor that is rated to run at 800 MHz and the
system is running a front side bus frequency of 100 MHz, you should select a
multiplier of 8 so that:
8 (Multiplier) x 100 MHz (front side bus) = 800 MHz (CPU clock)
Key in the DEC (decimal) number for the CPU Clock Ratio.
Page 4-25
BIOS
AGP/PCI Clock
Enables you to set the host clock to work concurrently with the PCI bus or the AGP
bus. The default is AUTO.
AUTO: The system sets the item automatically.
AGP-FSB*2/3 PCI-FSB/3: The system sets the host clock to work with the PCI
and AGP bus.
AGP-FSB*2/4 PCI-FSB/4: The system sets the host clock to work with the PCI
and AGP bus.
By subtle tuning item: The system sets the host clock according to the
number produced by the subtle tuning item.
AGP/PCI subtle tuning
Enables you to subtle tune the AGP/PCI frequency at increments of 1MHz step. The
default is 66 MHz. Press <Enter> to display the following screen:
Key in the DEC (decimal) number for the AGP/PCI subtle tuning.
Clock Generation for EMI
Scroll to Clock Generation for EMI and press <Enter>. The following screen
appears:
Auto Detect PCI Clk
When enabled the mainboard automatically disables the clock source for a PCI
slot which does not have a module in it, reducing EMI (ElectroMagnetic
Interference).
Page 4-26
BIOS
Spread Spectrum Modulated
If you enable spread spectrum, it can significantly reduce the EMI
(ElectroMagnetic Interference) generated by the system.
4-9 Defaults Menu
Selecting “Defaults” from the main menu shows you two options which are de-
scribed below
Load Fail-Safe Defaults
When you press <Enter> on this item you get a confirmation dialog box:
Load Fail-Safe Defaults (Y/N) ? N
Pressing ‘Y’ loads the BIOS default values for the most stable, minimal-performance
system operations.
Load Optimized Defaults
When you press <Enter> on this item you get a confirmation dialog box:
Load Optimized Defaults (Y/N) ? N
Pressing ‘Y’ loads the default values that are factory settings for optimal perfor-
mance system operations.
Page 4-27
BIOS
4-10 Supervisor/User Password Setting
These items are used to install a password. A Supervisor password takes prece-
dence over a User password, and the Supervisor limits the activities of a User.
You can set either a supervisor or user password, or both of them:
Supervisor password: authorized to enter and change the options of the setup
menus.
User password: authorized to enter, but not authorized to change the
options of the setup menus.
When you select Set User/Supervisor Password, the following message appears
prompting you to type a password:
ENTER PASSWORD:
Type the password, up to eight characters in length, and press <Enter>. The password
typed now clears any previously entered password from CMOS memory. You will be
prompted to confirm the password. Type the password and press <Enter>. You may
also press <Esc> to abort the selection and not enter a password.
To disable a password, press <Enter> when you are prompted to enter the password.
A message will confirm the password is disabled:
PASSWORD DISABLED.
Once the password is disabled, the system will boot and you can enter Setup freely.
When a password has been enabled, you will be prompted to enter it every time you
try to enter Setup. This prevents an unauthorized person from changing any part of
your system configuration.
Additionally, when a password is enabled, you can also require the BIOS to request
a password every time your system is rebooted. This prevents unauthorized use of
your computer.
You determine when the password is required within the BIOS Features Setup menu
“Security” option. If the Security option is set to “System”, the password will be
required both at boot and at entry to Setup. If set to “Setup”, prompting only
occurs when trying to enter Setup.
Page 4-28
BIOS
4-11 Exiting BIOS
Save & Exit Setup
Pressing <Enter> on this item asks for confirmation:
Save to CMOS and EXIT (Y/N)? Y
Pressing “Y” stores the selections made in the menus in CMOS – a special section
of memory that stays on after you turn your system off. The next time you boot
your computer, the BIOS configures your system according to the Setup selections
stored in CMOS. After saving the values the system is restarted again.
Exit Without Saving
Pressing <Enter> on this item asks for confirmation:
Quit without saving (Y/N)? Y
This allows you to exit Setup without storing in CMOS any change. The previous
selections remain in effect. This exits the Setup utility and restarts your computer.
Page 4-29
BIOS
Page Left Blank
Page 4-30
Easy Driver Installation
INTEL SPRINGDALE SERIES (865) CHIPSET DRIVER
INTEL CHIPSET INF FILES
GRAPHICS DRIVER
C-MEDIA AUDIO DRIVER
USB V2.0 (README.HTM)
Drivers Installation
Section 5
Driver Installation
(Optional)
REALTEK LAN DRIVER
DRIVER MANUAL
CD EXPLORER EXIT
Insert the bundled CD-disk, the main menu screen will appear. The main menu
displays buttons that link you to the supported drivers, utilities and software.
Step 1 : Click “INTEL CHIPSET INF FILES” to install chipset driver.
Step 2 : Click “GRAPHICS DRIVER” to install graphical driver.
Step 3 : Click “C-MEDIA AUDIO DRIVER” to install audio driver.
Step 4 : Click “USB V2.0 DRIVER (README.HTM)” for installation introduction
to install USB V2.0 driver.
Step 5 : Click “REALTEK LAN DRIVER” to install LAN driver. (Optional)
Page 5-1
Drivers Installation
C-Media Audio Configuation Brief GuideC-Media Audio Configuation Brief Guide
C-Media Audio Configuation Brief Guide
C-Media Audio Configuation Brief GuideC-Media Audio Configuation Brief Guide
Below is list brief guide of C-Media Audio Configuration. For more detailed
information, please refer to user’s manual in the attached CD.
You are able to access the control panel from two places:
a) The system tray in the right-bottom of your screen. You can click right button
of the mouse on it to get an audio-related pop-up menu as follows
b) In the “Control Panel” (Start=>Setting=>Control Panel), double-click “CMI
Audio Config” to open it.
Page 5-2
Drivers Installation
1. Speaker output:
When you open the “3D Audio Configuration”, you will see the default Output
tab as the figure below. “Speaker Output” tab collects main setting/options for
analog output to speakers.
<2 channel mode>
<6 channel mode>
Page 5-3
Drivers Installation
2. S/PDIF:
C-Media driver supports digital S/PDIF output (Sony/Philips Digital InterFace,
developed by SONY/PHILIPS to provide a low-distortion digital data transfer
between audio devices). There may be an optical or coaxial connector for S/PDIF
on your system. When you select S/PDIF tab, you will see the setting page as the
figure below.
3. Volume Control:
C-Media driver provides the digital volume control for all 6 channels in 3D
Audio Configuration. You can regulate each volume to the speaker for current
playing digital sound sources. It’s not effective for analog input sources.
Page 5-4
Drivers Installation
4. Microphone:
C-Media driver provides microphone setting in 3D Audio Configuration directly
for more convenience. You can control microphone options in the tab though
you can also reach them in Microsoft volume control.
5. Xear 3D:
C-Media driver now supports Xear 3D- 5.1 Virtual SPEAKER SHIFTER and
sound effects. Just click the left button in Xear 3D tab and then the new
friendly/fancy graphic user interface will pop up.
Click this
Page 5-5
Drivers Installation
Xear 3D - 5.1 Virtual SPEAKER SFIFTER:
The SPEAKER SHIFTER block provides an advanced, amazing and considerate
feature- dynamically adjustable multi-channel sound system no matter what
listening appliance you use and what application you are running. You do NOT
have to endure unbalanced speaker placement due to spatial limitation. You can
enjoy multi-channel surround sound with even an earphone or usual 2 speakers.
Xear 3D - Sound Effect:
Xear 3D Advanced Program provides another functional block- Sound Effect.
You can create a different feeling for your music including 27 Environment
Effects, Environment Size & 10-Band Equalizer with 12 pre-set models.
Page 5-6
Drivers Installation
Xear 3D - Multi-channel Music Demo:
This demo program provides each speaker testing and three 5.1-channel music.
You can get feeling about 5.1-channel surround music and use it to test
SPEAKER SHIFTER, too. All demo music/sound here will repeat playing if you
don’t press “Stop” button.
Xear 3D - Play3D Demo:
Xear 3D Advanced Program also provides interesting Play3D demo programs as
below. After installing the program with setup program, you will find the
program from the path: “Start->Programs->C-Media 3D Audio->Play3D Demo”.
Page 5-7
Drivers Installation
6. Information :
There is a C-Media audio-related Information tab in 3D Audio Configuration.
You can get a whole picture about the audio chip, driver version, 3D Audio
Engine, Microsoft DirectX Version, and Configuration Version itself.
Page 5-8
Appendix
Appendix A
A-1 Update Your System BIOS
Download the xxxxx.EXE file corresponding to your model from our website to an
empty directory on your hard disk or floppy. Run the downloaded xxxxx.EXE file and
it will self extract. Copy these extracted files to a bootable DOS floppy disk.
Note: The DOS floppy disk should contain NO device drivers or other programs.
1. Type “A:\AWDFLASH and press <Enter> Key.
2. You will see the following setup screen.
3. Please key in the xxxxx.bin BIOS file name.
XXXX
4. If you want to save the previous BIOS data to the diskette, please key in [Y],
otherwise please key in [N].
XXXX
XXXXX
xxxxx.bin
A-1
Appendix
5. Key in File Name to save previous BIOS to file.
XXXX
XXXXX
xxxxx.bin
xxxxx.bin
6. To confirm and proceed, please key in [Y] to start the programming.
XXXX
XXXXX
xxxxx.bin
xxxxx.bin
7. The BIOS update is finished.
A-2
F1 : Reset
XXXX
XXXXX
xxxxx.bin
F10 : Exit
Appendix
Appendix B
B-1 EEPROM BIOS Remover
Do not remove the BIOS chip, unless instructed by a technician and only with a
PLCC IC extractor tool.
The BIOS socket is fragile may be damaged if an improper method to
replace the BIOS chip is applied.
B-1
Appendix
Page Left Blank
B-2
Appendix
Appendix C
C-1 GHOST 7 Quick User’s Guide (Optional)
Installation is very easy. You only need to copy the Ghost7 folder or Ghost.exe to
your hard disk.
Main Menu
Description of Menu
Ghost clones and backs up Disk and Partition.
In which Disk indicates hard disk options
Partition indicates partition options
Check indicates check options
Disk
C-1
Appendix
There are 3 hard disk functions:
1. Disk To Disk (disk cloning)
2. Disk To Image (disk backup)
3. Disk From Image (restore backup)
Important!
1. To use this function, the system must have at least 2 disks. Press the Tab key to
move the cursor.
2. When restoring to a destination disk, all data in that disk will be completely
destroyed.
Disk To Disk (Disk Cloning)
1. Select the location of the Source drive.
2. Select the location of the Destination drive.
3. When cloning a disk or restoring the backup, set the required partition size as
shown in the following figure.
4. Click OK to display the following confirmation screen. Select Yes to start.
C-2
Appendix
Disk To Image (Disk Backup)
1. Select the location of the Source drive.
2. Select the location for storing the backup file.
3. Click OK to display the following confirmation screen. Select Yes to start.
Disk From Image (Restore Backup)
1. Select the Restoring file.
C-3
Appendix
2. Select the Destination drive of the disk to be restored.
3. When restoring disk backup, set the required partition size as shown in the
following figure.
4. Click OK to display the following confirmation screen. Select Yes to start.
Partition
C-4
Appendix
There are 3 partition functions:
1. Partition To Partition (partition cloning)
2. Partition To Image (partition backup)
3. Partition From Image (restore partition)
Partition To Partition (Partition Cloning)
The basic unit for partition cloning is a “partition”. Refer to “disk cloning” for the
operating method.
Partition To Image (Partition Backup)
1. Select the disk to be backed up.
2. Select the first partition to be backed up. This is usually where the operating
system and programs are stored.
3. Select the path and file name to store the backup file.
C-5
Appendix
4. Is the file compressed? There are 3 options:
(1) No: do not compress data during backup
(2) Fast: Small volume compression
(3) High: high ratio compression. File can be compressed to its minimum, but
requiring longer execution time.
5. Select Yes to start performing backup.
Partition From Image (Restore Partition)
1. Select the backup file to be restored.
2. Select the source partition.
C-6
3. Select the disk to be restored.
4. Select the partition to be restored.
5. Select Yes to start restoring.
Appendix
Check
This function is to check possible error caused by defective FAT or
track during backup or restoring.
C-7
Appendix
How to Reinstall Windows in 2 Minutes
This chapter guides you how to setup your computer properly and, if
necessary, reinstall Windows in 2 minutes. Ghost provides different
methods to complete this task. The following two sections explain how to
create an emergency Recover Floppy and Recover CD:
Emergency Recover Floppy
Divide a hard disk into two partitions. The first partition is to store the
operating system and application programs. The second partition is to back
up the operating system and data. The size of the partition can be
determined according to the backup requirements. For example, the
Windows operating system needs 200MB of hard disk space, Plus
complete Office programs require 360MB. The remaining space can be
used to store data.
After installing Windows, use Ghost to create a backup area for the system
and to store the file (Image file) in drive D. The file is named Original.gho.
Then, create a recover floppy disk containing:
Bootable files (Command.com, Io.sys, and MSDOS.SYS )
Config.sys (configuration setup file)
Autoexec.bat (auto-execution batch file)
Ghost.exe (Ghost execution file)
There are two ways to create the content of the recover floppy for
restoring:
(1)To load Windows automatically after booting, store the Autoexec.
bat file with a command line:
Ghost.exe clone, mode=pload, src=d:\original.gho:2,dst=1:1 -fx -sure -rb
Command Description: Runs the restore function automatically with
the Image File. Stored in drive D. After execution, it will exit Ghost
and boots the system.
Refer to the [Introducing Ghosts Functions] for details.
C-8
Appendix
(2) After booting, the screen displays the Menu. Select Backup or Restore:
Since the user may install other applications in the future, he/she may
alter Autoexec.bat file to back up or restore the user-defined Image
file as follows:
BackupBackup
Backup
BackupBackup
Back up Windows and application programs as a file (Recent.
gho). Command is:
Ghost –clone,mode=pdump,src=1:1,dst=d:\Recent.gho -fx -
sure -rb
RestoreRestore
Restore
RestoreRestore
Restore types include [General Windows] and [Windows and
Application Programs]. If you select [General Windows],
the system is restored to the general Windows operation
condition. The command is:
Ghost.exe -clone,mode=pload,src=d:\Original.gho,dst=1:1 -fx
-sure -rb
If you select [Windows and Application Programs], the latest
backup file (Recent.gho) is restored, skipping the installation
and setup of application programs.
For description of related parameters, refer to [Introducing Ghosts
Functions].
For more information about menu design, refer to Config.sys and
Autoexec.bat under /Menu in the CD. You can also create a backup CD
containing Ghost.exe and these two files.
C-9
Appendix
Recover CD
The following is a simple guide to create a recover CD:
1. First, create a recover floppy disk contains the following with any
copy program such as “Easy CD Create” (Note 2) :
Bootable files (Command.com and Io.sys and MSDOS.SYS)
Config.sys (Configuration setup file)
Autoexec.bat (Auto-execution batch file)
Mscdex.exe (CD-Rom execution file)
Ghost.exe (Ghost execution file)
Oakcdrom.sys (ATAPI CD-ROM compatible driver)
The content of Config.sys is:
DEVICE=Oakcdrom.sys /d:idecd001
The content of Autoexec.bat includes:
MSCDEX.EXE /D:IDECD001 /L:Z
Ghost.exe clone,mode=load,src=z:\original.gho,dst=1 -sure -rb
2. Write the backup image file (original.gho) of the entire hard disk or
partition into the recover CD. Use the Recover CD to boot up the
system and restore the backup files automatically.
For description of related parameters, refer to [Introducing Ghosts
Functions].
Note: For more details about copy the creation program and method to create a
recover CD, please refer to the releated software and its associated
operating manual.
Note: Ghost may be executed in interactive or in batch mode. Most of the Ghost
switches are used to assist in batch mode operation. To list switches, type
ghost.exe -h.
C-10
Loading...
