Mobile 4th Generation Intel® Core

™

Processor Family, Mobile Intel

Pentium® Processor Family, and Mobile Intel® Celeron® Processor Family

Datasheet – Volume 1 of 2

Supporting 4th Generation Intel® Core™ processor based on Mobile M-Processor and H-Processor Lines

Supporting Mobile Intel® Pentium® Processor and Mobile Intel Celeron® Processor Families

July 2014

Order No.: 328901-007

By using this document, in addition to any agreements you have with Intel, you accept the terms set forth below.

You may not use or facilitate the use of this document in connection with any infringement or other legal analysis concerning Intel products described herein. You agree to grant Intel a non-exclusive, royalty-free license to any patent claim thereafter drafted which includes subject matter disclosed herein.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

A "Mission Critical Application" is any application in which failure of the Intel Product could result, directly or indirectly, in personal injury or death. SHOULD YOU PURCHASE OR USE INTEL'S PRODUCTS FOR ANY SUCH MISSION CRITICAL APPLICATION, YOU SHALL INDEMNIFY AND HOLD INTEL AND ITS SUBSIDIARIES, SUBCONTRACTORS AND AFFILIATES, AND THE DIRECTORS, OFFICERS, AND EMPLOYEES OF EACH, HARMLESS AGAINST ALL CLAIMS COSTS, DAMAGES, AND EXPENSES AND REASONABLE ATTORNEYS' FEES ARISING OUT OF, DIRECTLY OR INDIRECTLY, ANY CLAIM OF PRODUCT LIABILITY, PERSONAL INJURY, OR DEATH ARISING IN ANY WAY OUT OF SUCH MISSION CRITICAL APPLICATION, WHETHER OR NOT INTEL OR ITS SUBCONTRACTOR WAS NEGLIGENT IN THE DESIGN, MANUFACTURE, OR WARNING OF THE INTEL PRODUCT OR ANY OF ITS PARTS.

Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined". Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them. The information here is subject to change without notice. Do not finalize a design with this information.

The products described in this document may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained by calling 1-800-548-4725, or go to: http://www.intel.com/design/literature.htm

Any software source code reprinted in this document is furnished for informational purposes only and may only be used or copied and no license, express or implied, by estoppel or otherwise, to any of the reprinted source code is granted by this document.

Any software source code reprinted in this document is furnished under a software license and may only be used or copied in accordance with the terms of that license.

This document contains information on products in the design phase of development.

Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each processor family, not across different processor families: Go to: http://www.intel.com/products/processor_number

Code Names are only for use by Intel to identify products, platforms, programs, services, etc. ("products") in development by Intel that have not been made commercially available to the public, i.e., announced, launched or shipped. They are never to be used as "commercial" names for products. Also, they are not intended to function as trademarks.

Intel® Hyper-Threading Technology (Intel® HT Technology) is available on select Intel® Core™ processors. It requires an Intel® HT Technology enabled system. Consult your PC manufacturer. Performance will vary depending on the specific hardware and software used. Not available on Intel® Core i5-750. For more information including details on which processors support Intel® HT Technology, visit http://www.intel.com/info/hyperthreading.

Intel® 64 architecture requires a system with a 64-bit enabled processor, chipset, BIOS and software. Performance will vary depending on the specific hardware and software you use. Consult your PC manufacturer for more information. For more information, visit http://www.intel.com/

content/www/us/en/architecture-and-technology/microarchitecture/intel-64-architecture-general.html.

No computer system can provide absolute security under all conditions. Intel® Trusted Execution Technology (Intel® TXT) requires a computer with Intel® Virtualization Technology, an Intel TXT-enabled processor, chipset, BIOS, Authenticated Code Modules and an Intel TXT-compatible measured launched environment (MLE). Intel TXT also requires the system to contain a TPM v1.s. For more information, visit http://www.intel.com/technology/

security.

Intel® Virtualization Technology (Intel® VT) requires a computer system with an enabled Intel® processor, BIOS, and virtual machine monitor (VMM). Functionality, performance or other benefits will vary depending on hardware and software configurations. Software applications may not be compatible with all operating systems. Consult your PC manufacturer. For more information, visit http://www.intel.com/go/virtualization.

Requires a system with Intel® Turbo Boost Technology. Intel Turbo Boost Technology and Intel Turbo Boost Technology 2.0 are only available on select Intel® processors. Consult your PC manufacturer. Performance varies depending on hardware, software, and system configuration. For more information, visit http://www.intel.com/go/turbo.

Requires activation and a system with a corporate network connection, an Intel® AMT-enabled chipset, network hardware and software. For notebooks, Intel AMT may be unavailable or limited over a host OS-based VPN, when connecting wirelessly, on battery power, sleeping, hibernating or powered off. Results dependent upon hardware, setup and configuration.

Intel, Intel Core, Celeron, Pentium and the Intel logo are trademarks of Intel Corporation in the U.S. and/or other countries.

*Other names and brands may be claimed as the property of others.

™

Mobile 4th Generation Intel

Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family Datasheet – Volume 1 of 2 July 2014 2 Order No.: 328901-007

Contents—Processor

Revision History..................................................................................................................9

1.0 Introduction................................................................................................................10

1.1 Supported Technologies.........................................................................................11

1.2 Interfaces............................................................................................................ 12

1.3 Power Management Support...................................................................................12

1.4 Thermal Management Support................................................................................13

1.5 Package Support...................................................................................................13

1.6 Processor Testability............................................................................................. 13

1.7 Terminology.........................................................................................................13

1.8 Related Documents............................................................................................... 17

2.0 Interfaces................................................................................................................... 18

2.1 System Memory Interface...................................................................................... 18

2.1.1 System Memory Technology Supported.......................................................18

2.1.2 System Memory Timing Support................................................................. 19

2.1.3 System Memory Organization Modes........................................................... 20

2.1.4 System Memory Frequency........................................................................ 21

2.1.5 Intel® Fast Memory Access (Intel® FMA) Technology Enhancements............... 21

2.1.6 Data Scrambling...................................................................................... 22

2.1.7 DRAM Clock Generation............................................................................. 22

2.1.8 DRAM Reference Voltage Generation........................................................... 22

2.2 PCI Express* Interface.......................................................................................... 23

2.2.1 PCI Express* Support................................................................................23

2.2.2 PCI Express* Architecture.......................................................................... 24

2.2.3 PCI Express* Configuration Mechanism........................................................ 24

2.3 Direct Media Interface (DMI).................................................................................. 26

2.4 Processor Graphics................................................................................................28

2.5 Processor Graphics Controller (GT)..........................................................................28

2.5.1 3D and Video Engines for Graphics Processing.............................................. 29

2.5.2 Multi Graphics Controllers Multi-Monitor Support........................................... 31

2.6 Digital Display Interface (DDI)................................................................................31

2.7 Intel® Flexible Display Interface (Intel® FDI)............................................................37

2.8 Platform Environmental Control Interface (PECI)....................................................... 38

2.8.1 PECI Bus Architecture................................................................................38

3.0 Technologies...............................................................................................................40

3.1 Intel® Virtualization Technology (Intel® VT)............................................................. 40

3.2 Intel® Trusted Execution Technology (Intel® TXT).....................................................44

3.3 Intel® Hyper-Threading Technology (Intel® HT Technology)....................................... 45

3.4 Intel® Turbo Boost Technology 2.0..........................................................................46

3.5 Intel® Advanced Vector Extensions 2.0 (Intel® AVX2)................................................47

3.6 Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI).......................47

3.7 Intel® Transactional Synchronization Extensions - New Instructions (Intel® TSX-NI)..... 48

3.8 Intel® 64 Architecture x2APIC................................................................................ 48

3.9 Power Aware Interrupt Routing (PAIR)....................................................................49

3.10 Execute Disable Bit..............................................................................................49

3.11 Supervisor Mode Execution Protection (SMEP)........................................................50

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 3

Processor—Contents

4.0 Power Management.................................................................................................... 51

4.1 Advanced Configuration and Power Interface (ACPI) States Supported......................... 52

4.2 Processor Core Power Management......................................................................... 53

4.2.1 Enhanced Intel® SpeedStep® Technology Key Features..................................53

4.2.2 Low-Power Idle States............................................................................... 54

4.2.3 Requesting Low-Power Idle States...............................................................55

4.2.4 Core C-State Rules....................................................................................56

4.2.5 Package C-States......................................................................................57

4.2.6 Package C-States and Display Resolutions....................................................61

4.3 Integrated Memory Controller (IMC) Power Management............................................63

4.3.1 Disabling Unused System Memory Outputs...................................................63

4.3.2 DRAM Power Management and Initialization..................................................63

4.3.3 DRAM Running Average Power Limitation (RAPL) .........................................66

4.3.4 DDR Electrical Power Gating (EPG).............................................................. 66

4.4 PCI Express* Power Management............................................................................66

4.5 Direct Media Interface (DMI) Power Management...................................................... 66

4.6 Graphics Power Management..................................................................................66

4.6.1 Intel® Rapid Memory Power Management (Intel® RMPM)................................66

4.6.2 Graphics Render C-State............................................................................67

4.6.3 Intel® Smart 2D Display Technology (Intel® S2DDT)..................................... 67

4.6.4 Intel® Graphics Dynamic Frequency............................................................ 67

4.6.5 Intel® Display Power Saving Technology (Intel® DPST)................................. 67

4.6.6 Intel® Automatic Display Brightness ........................................................... 68

4.6.7 Intel® Seamless Display Refresh Rate Technology (Intel® SDRRS

Technology)............................................................................................ 68

5.0 Thermal Management................................................................................................. 69

5.1 Thermal Considerations......................................................................................... 69

5.2 Intel® Turbo Boost Technology 2.0 Power Monitoring.................................................70

5.3 Intel® Turbo Boost Technology 2.0 Power Control..................................................... 70

5.3.1 Package Power Control.............................................................................. 70

5.3.2 Turbo Time Parameter............................................................................... 71

5.4 Configurable TDP (cTDP) and Low-Power Mode......................................................... 71

5.4.1 Configurable TDP...................................................................................... 71

5.4.2 Low-Power Mode.......................................................................................72

5.5 Thermal and Power Specifications........................................................................... 72

5.6 Thermal Management Features...............................................................................76

5.6.1 Adaptive Thermal Monitor.......................................................................... 76

5.6.2 Digital Thermal Sensor.............................................................................. 78

5.6.3 PROCHOT# Signal.....................................................................................79

5.6.4 On-Demand Mode..................................................................................... 81

5.6.5 Intel® Memory Thermal Management.......................................................... 81

6.0 Signal Description....................................................................................................... 83

6.1 System Memory Interface Signals........................................................................... 84

6.2 Memory Reference Compensation Signals.................................................................86

6.3 Reset and Miscellaneous Signals............................................................................. 86

6.4 PCI Express* Interface Signals............................................................................... 87

6.5 embedded DisplayPort* (eDP*) Signals....................................................................87

6.6 Display Interface Signals....................................................................................... 88

6.7 Direct Media Interface (DMI).................................................................................. 88

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 4 Order No.: 328901-007

Contents—Processor

6.8 Phase Locked Loop (PLL) Signals.............................................................................88

6.9 Testability Signals.................................................................................................89

6.10 Error and Thermal Protection Signals..................................................................... 90

6.11 Power Sequencing Signals.................................................................................... 90

6.12 Processor Power Signals.......................................................................................91

6.13 Sense Signals..................................................................................................... 91

6.14 Ground and Non-Critical to Function (NCTF) Signals.................................................91

6.15 Processor Internal Pull-Up / Pull-Down Terminations................................................ 92

7.0 Electrical Specifications.............................................................................................. 93

7.1 Integrated Voltage Regulator..................................................................................93

7.2 Power and Ground Pins..........................................................................................93

7.3 VCC Voltage Identification (VID).............................................................................. 93

7.4 Reserved or Unused Signals................................................................................... 98

7.5 Signal Groups.......................................................................................................98

7.6 Test Access Port (TAP) Connection........................................................................ 100

7.7 DC Specifications............................................................................................... 100

7.8 Voltage and Current Specifications........................................................................ 101

7.8.1 Platform Environment Control Interface (PECI) DC Characteristics................. 106

7.8.2 Input Device Hysteresis........................................................................... 107

8.0 Package Specifications..............................................................................................108

8.1 Package Mechanical Specifications.........................................................................108

8.1.1 Processor Mass....................................................................................... 110

8.2 Package Loading Specifications............................................................................. 110

8.3 Package Storage Specifications............................................................................. 111

9.0 Processor Pin and Signal Information....................................................................... 112

10.0 DDR Data Swizzling.................................................................................................135

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 5

Processor—Figures

Figures

1 Platform Block Diagram............................................................................................ 11

2 Intel® Flex Memory Technology Operations................................................................. 21

3 PCI Express* Related Register Structures in the Processor............................................ 25

4 PCI Express* Typical Operation 16 Lanes Mapping....................................................... 26

5 Processor Graphics Controller Unit Block Diagram........................................................ 29

6 Processor Display Architecture...................................................................................33

7 DisplayPort* Overview............................................................................................. 34

8 HDMI* Overview..................................................................................................... 35

9 PECI Host-Clients Connection Example....................................................................... 39

10 Device to Domain Mapping Structures........................................................................ 43

11 Processor Power States............................................................................................ 51

12 Idle Power Management Breakdown of the Processor Cores ..........................................54

13 Thread and Core C-State Entry and Exit......................................................................55

14 Package C-State Entry and Exit................................................................................. 59

15 Package Power Control............................................................................................. 71

16 Input Device Hysteresis.......................................................................................... 107

17 BGA Package.........................................................................................................109

18 rPGA Package........................................................................................................109

19 rPGA946B/947 Socket............................................................................................ 110

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 6 Order No.: 328901-007

Tables—Processor

Tables

1 Terminology........................................................................................................... 13

2 Related Documents..................................................................................................17

3 Processor DIMM Support Summary by Product............................................................ 18

4 Supported SO-DIMM Module Configurations ............................................................... 19

5 Supported Maximum Memory Size Per DIMM...............................................................19

6 DDR3L / DDR3L-RS System Memory Timing Support.................................................... 20

7 PCI Express* Supported Configurations in Mobile Products............................................ 23

8 Processor Supported Audio Formats over HDMI*and DisplayPort*.................................. 36

9 Valid Three Display Configurations through the Processor..............................................36

10 DisplayPort and embedded DisplayPort* Resolutions for 1, 2, 4 Lanes – Link Data

Rate of RBR, HBR, and HBR2.....................................................................................37

11 System States.........................................................................................................52

12 Processor Core / Package State Support..................................................................... 52

13 Integrated Memory Controller States..........................................................................52

14 PCI Express* Link States.......................................................................................... 52

15 Direct Media Interface (DMI) States........................................................................... 53

16 G, S, and C Interface State Combinations .................................................................. 53

17 D, S, and C Interface State Combination.....................................................................53

18 Coordination of Thread Power States at the Core Level................................................. 55

19 Coordination of Core Power States at the Package Level............................................... 58

20 Deepest Package C-State Available – M-Processor Line................................................. 61

21 Targeted Memory State Conditions............................................................................ 65

22 Intel® Turbo Boost Technology 2.0 Package Power Control Settings............................... 70

23 Configurable TDP Modes........................................................................................... 72

24 Thermal Design Power (TDP) Specifications.................................................................73

25 Junction Temperature Specification............................................................................ 74

26 Idle Power Specifications.......................................................................................... 75

27 Signal Description Buffer Types................................................................................. 83

28 Memory Channel A Signals........................................................................................84

29 Memory Channel B Signals........................................................................................85

30 Memory Reference and Compensation Signals............................................................. 86

31 Reset and Miscellaneous Signals................................................................................ 86

32 PCI Express* Graphics Interface Signals..................................................................... 87

33 embedded Display Port* Signals................................................................................ 87

34 Display Interface Signals.......................................................................................... 88

35 Direct Media Interface (DMI) – Processor to PCH Serial Interface................................... 88

36 Phase Locked Loop (PLL) Signals............................................................................... 88

37 Testability Signals....................................................................................................89

38 Error and Thermal Protection Signals..........................................................................90

39 Power Sequencing Signals........................................................................................ 90

40 Processor Power Signals........................................................................................... 91

41 Sense Signals......................................................................................................... 91

42 Ground and Non-Critical to Function (NCTF) Signals..................................................... 91

43 Processor Internal Pull-Up / Pull-Down Terminations.................................................... 92

44 Voltage Regulator (VR) 12.5 Voltage Identification....................................................... 94

45 Signal Groups......................................................................................................... 98

46 Processor Core (VCC) Active and Idle Mode DC Voltage and Current Specifications.......... 101

47 Memory Controller (V

48 VCCIO_OUT, VCOMP_OUT, and VCCIO_TERM ........................................................... 102

49 DDR3L / DDR3L-RS Signal Group DC Specifications.................................................... 103

50 Digital Display Interface Group DC Specifications....................................................... 104

51 embedded DisplayPort* (eDP*) Group DC Specifications............................................. 104

52 CMOS Signal Group DC Specifications.......................................................................105

53 GTL Signal Group and Open Drain Signal Group DC Specifications................................ 105

) Supply DC Voltage and Current Specifications....................... 102

DDQ

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 7

Processor—Tables

54 PCI Express* DC Specifications................................................................................106

55 Platform Environment Control Interface (PECI) DC Electrical Limits...............................106

56 Package Mechanical Attributes.................................................................................108

57 Processor Mass......................................................................................................110

58 Package Loading Specifications................................................................................110

59 BGA and rPGA Package Storage Conditions................................................................111

60 rPGA946B/947 Processor Pin List by Signal Name.......................................................112

61 BGA1364 Processor Ball List by Signal Name............................................................. 121

62 DDR Data Swizzling Table – Channel A..................................................................... 135

63 DDR Data Swizzling Table – Channel B..................................................................... 136

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 8 Order No.: 328901-007

Revision History—Processor

Revision History

Revision Description Date

001 • Initial Release June 2013

002

003 • Minor updates throughout for clarity. November 2013

004 • Minor updates throughout for clarity. December 2013

005 • Updated table 37, "Testability Signals" March 2014

006

007

• Added Mobile 4th Generation Intel® Core™ i7-4960HQ, i7-4600M, i5-4330M, i5-4300M, i5-4200H, i5-4200M, i3-4100M, i3-4000M processors

• Added Mobile Intel® Pentium® 3550M processor

• Added Mobile Intel® Celeron® 2950M processor

• Added Section 4.2.6, "Package C-States and Display Resolutions".

• Added Mobile 4th Generation Intel® Core™ i7-4760HQ, i7-4712HQ, i7-4710HQ, i7-4712MQ, i7-4710MQ, i5-4210M, i3-4110M, i3-4100M processors

• Added Mobile Intel® Pentium® 3560M processor

• Added Mobile Intel® Celeron® 2970M processor

• Added Mobile 4th Generation Intel® Core™ i7-4980HQ, i7-4870HQ, i7-4770HQ, i5-4210H processors

• Updated Table 24, Thermal Design Power (TDP) Specifications

• Updated Table 25, Junction Temperature Specification

• Updated Table 26, Idle Power Specifications

September 2013

April 2014

July 2014

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 9

1.0 Introduction

Processor—Introduction

The 4th Generation Intel® Core™ processor based on Mobile M-Processor and HProcessor Lines, Mobile Intel® Pentium® processor family, and Mobile Intel® Celeron

processor family are 64-bit, multi-core processors built on 22-nanometer process technology.

The processors are designed for a two-chip platform consisting of a processor and Platform Controller Hub (PCH). The processors are designed to be used with the Mobile chipset. See the following figure for an example platform block diagram.

Throughout this document, the 4th Generation Intel® Core™ processor based on Mobile M-Processor and H-Processor Lines, Mobile Intel® Pentium® processor family, and Mobile Intel® Celeron® processor family may be referred to simply as "processor".

Throughout this document, the Intel® 8 Series chipset may be referred to simply as "PCH".

Throughout this document, the 4th Generation Intel® Core™ processor based on Mobile M-Processor and H-Processor Lines refers to the Mobile 4th Generation Intel

Core™ i7-4980HQ, i7-4960HQ, i7-4950HQ, i7-4930MX, i7-4900MQ, i7-4870HQ, i7-4850HQ, i7-4800MQ, i7-4770HQ, i7-4760HQ, i7-4712HQ, i7-4712MQ, i7-4710HQ, i7-4710MQ, i7-4702HQ, i7-4702MQ, i7-4700HQ, i7-4700MQ, i7-4750HQ, i7-4600M, i5-4330M, i5-4300M, i5-4210M, i5-4210H, i3-4110M, and i3-4100M processors.

Throughout this document, the Mobile Mobile Intel® Pentium® processor family refers to the Intel® Pentium® 3560M, 3550M processors.

Throughout this document, the Mobile Intel® Celeron® processor family refers to the Intel® Celeron® 2970M, 2950M processor.

Note: Some processor features are not available on all platforms. Refer to the processor

Specification Update document for details.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 10 Order No.: 328901-007

Processor

PCI Express* 3.0

Digital Display

Interface (DDI)

(3 interfaces)

Embedded

DisplayPort*

(x4)

System Memory

1333 / 1600 MT/s

2 DIMMs / CH

CH A CH B

Note: 2 DIMMs / CH is not supported on all SKUs.

Intel® Flexible Display

Interface (Intel® FDI)

(x2)

Direct Media Interface 2.0

(DMI 2.0) (x4)

Platform Controller

Hub (PCH)

SATA, 6 GB/s (up to 6 Ports)

Analog Display

(VGA)

SPI Flash

Super IO / EC

Trusted Platform

Module (TPM) 1.2

LPC

Intel® High

Definition Audio

(Intel® HD Audio)

Integrated LAN

USB 3.0

(up to 6 Ports)

USB 2.0 (8 Ports)

PCI Express* 2.0

(up to 8 Ports)

SPI

SMBus 2.0

GPIOs

Introduction—Processor

Figure 1. Platform Block Diagram

1.1

Supported Technologies

• Intel® Virtualization Technology (Intel® VT)

• Intel® Active Management Technology 9.5 (Intel® AMT 9.5 )

• Intel® Trusted Execution Technology (Intel® TXT)

• Intel® Streaming SIMD Extensions 4.2 (Intel® SSE4.2)

• Intel® Hyper-Threading Technology (Intel® HT Technology)

• Intel® 64 Architecture

• Execute Disable Bit

• Intel® Turbo Boost Technology 2.0

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 11

• Intel® Advanced Vector Extensions 2.0 (Intel® AVX2)

Processor Family

• Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI)

• PCLMULQDQ Instruction

• Intel® Secure Key

• Intel® Transactional Synchronization Extensions - New Instructions (Intel® TSXNI)

• PAIR – Power Aware Interrupt Routing

• SMEP – Supervisor Mode Execution Protection

Note: The availability of the features may vary between processor SKUs.

Processor—Introduction

1.2

1.3

Interfaces

The processor supports the following interfaces:

• DDR3L/DDR3L-RS

• Direct Media Interface (DMI)

• Digital Display Interface (DDI)

• PCI Express*

Power Management Support

Processor Core

• Full support of ACPI C-states as implemented by the following processor C-states:

— C0, C1, C1E, C3, C6, C7

• Enhanced Intel SpeedStep® Technology

System

• S0, S3, S4, S5

Memory Controller

• Conditional self-refresh

• Dynamic power-down

PCI Express*

• L0s and L1 ASPM power management capability

DMI

• L0s and L1 ASPM power management capability

Processor Graphics Controller

• Intel® Rapid Memory Power Management (Intel® RMPM)

• Intel® Smart 2D Display Technology (Intel® S2DDT)

• Graphics Render C-state (RC6)

• Intel® Seamless Display Refresh Rate Switching with eDP port

• Intel® Display Power Saving Technology (Intel® DPST)

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 12 Order No.: 328901-007

Introduction—Processor

1.4

1.5

1.6

Thermal Management Support

• Digital Thermal Sensor

• Adaptive Thermal Monitor

• THERMTRIP# and PROCHOT# support

• On-Demand Mode

• Memory Open and Closed Loop Throttling

• Memory Thermal Throttling

• External Thermal Sensor (TS-on-DIMM and TS-on-Board)

• Render Thermal Throttling

• Fan speed control with DTS

Package Support

The Mobile processor is available in two packages:

• A 37.5 mm x 37.5 mm rPGA package (rPGA946B/947)

• A 37.5 mm x 32 mm BGA package (BGA1364)

Processor Testability

The processor includes boundary-scan for board and system level testability.

1.7

Terminology

Table 1. Terminology

Term Description

APD Active Power-down

B/D/F Bus/Device/Function

BGA Ball Grid Array

BLC Backlight Compensation

BLT Block Level Transfer

BPP Bits per pixel

CKE Clock Enable

CLTM Closed Loop Thermal Management

DDI Digital Display Interface

DDR3 Third-generation Double Data Rate SDRAM memory technology

DDR3L DDR3 Low Voltage

DDR3L-RS DDR3 Low Voltage Reduced Standby Power

DLL Delay-Locked Loop

DMA Direct Memory Access

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 13

Processor—Introduction

Term Description

DMI Direct Media Interface

DP DisplayPort*

DTS Digital Thermal Sensor

DVI*

Digital Visual Interface. DVI* is the interface specified by the DDWG (Digital Display Working Group)

EC Embedded Controller

ECC Error Correction Code

eDP* embedded DisplayPort*

EPG Electrical Power Gating

EU Execution Unit

FMA Floating-point fused Multiply Add instructions

FSC Fan Speed Control

HDCP High-bandwidth Digital Content Protection

HDMI* High Definition Multimedia Interface

HFM High Frequency Mode

iDCT Inverse Discrete

IHS Integrated Heat Spreader

GFX Graphics

GSA Graphics in System Agent

GUI Graphical User Interface

IMC Integrated Memory Controller

Intel® 64

64-bit memory extensions to the IA-32 architecture

Technology

Intel® DPST Intel Display Power Saving Technology

Intel® FDI Intel Flexible Display Interface

Intel® TSX-NI Intel Transactional Synchronization Extensions - New Instructions

Intel® TXT Intel Trusted Execution Technology

Intel Virtualization Technology. Processor virtualization, when used in conjunction

Intel® VT

with Virtual Machine Monitor software, enables multiple, robust independent software environments inside a single platform.

Intel Virtualization Technology (Intel VT) for Directed I/O. Intel VT-d is a hardware

Intel® VT-d

assist, under system software (Virtual Machine Manager or OS) control, for enabling I/O device virtualization. Intel VT-d also brings robust security by providing protection from errant DMAs by using DMA remapping, a key feature of Intel VT-d.

IOV I/O Virtualization

ISI Inter-Symbol Interference

ITPM Integrated Trusted Platform Module

LCD Liquid Crystal Display

LFM

Low Frequency Mode. LFM is Pn in the P-state table. It can be read at MSR CEh [47:40].

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family Datasheet – Volume 1 of 2 July 2014 14 Order No.: 328901-007

Introduction—Processor

LFP Local Flat Panel

LPDDR3 Low-Power Third-generation Double Data Rate SDRAM memory technology

MCP Multi-Chip Package

MFM

MLE Measured Launched Environment

MLC Mid-Level Cache

MSI Message Signaled Interrupt

MSL Moisture Sensitive Labeling

MSR Model Specific Registers

NCTF

ODT On-Die Termination

OLTM Open Loop Thermal Management

PCG

PCH

PECI

PEG

PL1, PL2 Power Limit 1 and Power Limit 2

PPD Pre-charge Power-down

Processor The 64-bit multi-core component (package)

Processor Core

Processor Graphics Intel Processor Graphics

Rank

SCI System Control Interrupt. SCI is used in the ACPI protocol.

SF Strips and Fans

SMM System Management Mode

SMX Safer Mode Extensions

Term Description

Minimum Frequency Mode. MFM is the minimum ratio supported by the processor and can be read from MSR CEh [55:48].

Non-Critical to Function. NCTF locations are typically redundant ground or non-critical reserved, so the loss of the solder joint continuity at end of life conditions will not affect the overall product functionality.

Platform Compatibility Guide (PCG) (previously known as FMB) provides a design target for meeting all planned processor frequency requirements.

Platform Controller Hub. The chipset with centralized platform capabilities including the main I/O interfaces along with display connectivity, audio features, power management, manageability, security, and storage features.

The Platform Environment Control Interface (PECI) is a one-wire interface that provides a communication channel between Intel processor and chipset components to external monitoring devices.

Case-to-ambient thermal characterization parameter (psi). A measure of thermal solution performance using total package power. Defined as (T Package Power. The heat source should always be specified for Y measurements.

PCI Express* Graphics. External Graphics using PCI Express* Architecture. It is a high-speed serial interface where configuration is software compatible with the existing PCI specifications.

The term “processor core” refers to Si die itself, which can contain multiple execution cores. Each execution core has an instruction cache, data cache, and 256-KB L2 cache. All execution cores share the L3 cache.

A unit of DRAM corresponding to four to eight devices in parallel, ignoring ECC. These devices are usually, but not always, mounted on a single side of a SO-DIMM.

- TLA ) / Total

CASE

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 15

Term Description

A non-operational state. The processor may be installed in a platform, in a tray, or loose. Processors may be sealed in packaging or exposed to free air. Under these conditions, processor landings should not be connected to any supply voltages, have

Storage Conditions

any I/Os biased, or receive any clocks. Upon exposure to “free air” (that is, unsealed packaging or a device removed from packaging material), the processor must be handled in accordance with moisture sensitivity labeling (MSL) as indicated on the packaging material.

SVID Serial Voltage Identification

TAC Thermal Averaging Constant

TAP Test Access Point

CASE

The case temperature of the processor, measured at the geometric center of the topside of the TTV IHS.

TCC Thermal Control Circuit

is a static value that is below the TCC activation temperature and used as a

CONTROL

TDP

trigger point for fan speed control. When DTS > T to the TTV thermal profile.

Thermal Design Power: Thermal solution should be designed to dissipate this target power level. TDP is not the maximum power that the processor can dissipate.

TLB Translation Look-aside Buffer

TTV

DDQ

Thermal Test Vehicle. A mechanically equivalent package that contains a resistive heater in the die to evaluate thermal solutions.

Thermal Monitor. A power reduction feature designed to decrease temperature after the processor has reached its maximum operating temperature.

Processor core power supply

DDR3L power supply.

VF Vertex Fetch

VID Voltage Identification

VS Vertex Shader

VLD Variable Length Decoding

VMM Virtual Machine Monitor

VR Voltage Regulator

Processor ground

x1 Refers to a Link or Port with one Physical Lane

x2 Refers to a Link or Port with two Physical Lanes

x4 Refers to a Link or Port with four Physical Lanes

x8 Refers to a Link or Port with eight Physical Lanes

x16 Refers to a Link or Port with sixteen Physical Lanes

Processor—Introduction

, the processor must comply

CONTROL

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family Datasheet – Volume 1 of 2 July 2014 16 Order No.: 328901-007

Introduction—Processor

1.8

2.0 Interfaces

Processor—Interfaces

2.1

System Memory Interface

• Two channels of DDR3L/DDR3L-RS memory with Unbuffered Small Outline Dual In-Line Memory Modules (SO-DIMM) with a maximum of two DIMMs per channel Two DIMMs per channel is only supported in Quad Core package

• Single-channel and dual-channel memory organization modes

• Data burst length of eight for all memory organization modes

• DDR3L/DDR3L-RS I/O Voltage of 1.35V

• 64-bit wide channels

• Non-ECC, Unbuffered DDR3L/DDR3L-RS SO-DIMMs only

• Theoretical maximum memory bandwidth of:

— 21.3 GB/s in dual-channel mode assuming DDR3L/DDR3L-RS 1333 MT/s

— 25.6 GB/s in dual-channel mode assuming DDR3L/DDR3L-RS 1600 MT/s

2.1.1

System Memory Technology Supported

The Integrated Memory Controller (IMC) supports DDR3L/DDR3L-RS protocols with two independent, 64-bit wide channels each accessing one or two DIMMs. The IMC supports one or two unbuffered non-ECC DDR3L/DDR3L-RS DIMM per channel; thus, allowing up to four device ranks per channel.

Note: 2 DIMMs per channel is only supported in Quad-Core package.

Table 3. Processor DIMM Support Summary by Product

Processors Package DIMM per channel DDR3L / DDR3L-RS

Quad Core rPGA, BGA

1 DPC 1333/1600

2 DPC 1333/1600

DDR3L/DDR3L-RS Data Transfer Rates:

• 1333 MT/s (PC3-10600)

• 1600 MT/s (PC3-12800)

DDR3L/DDR3L-RS SO-DIMM Modules:

• Raw Card B – Single Ranked x8 unbuffered non-ECC

• Raw Card F – Dual Ranked x8 (planar) unbuffered non-ECC

DRAM Device Technology:

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 18 Order No.: 328901-007

Interfaces—Processor

• Standard 1Gb, 2Gb, and 4Gb technologies and addressing are supported for x8 devices. There is no support for memory modules with different technologies or capacities on opposite sides of the same memory module. If one side of a memory module is populated, the other side is either identical or empty.

Table 4. Supported SO-DIMM Module Configurations

Raw Card

Version

DIMM

Capacity

1 GB 128 M x 8 8 14/10 8 8K

2 GB 256 M x 8 8 15/10 8 8K

4 GB 512 M x 8 8 16/10 8 8K

2 GB 128 M x 8 16 14/10 8 8K

4 GB 256 M x 8 16 15/10 8 8K

8 GB 512 M x 8 16 16/10 8 8K

DRAM

Organization

# of DRAM

Devices

# of Row/Col

Address Bits

# of Banks

Inside DRAM

Page Size

Table 5. Supported Maximum Memory Size Per DIMM

Platform Package Memory DDR3L

(note 1)

DDR3L-RS

(note 2)

SODIMM RC B

Mobile MProcessor / Mobile HProcessor

Notes: 1. The maximum High Density memory capacity is achieved using 4 Gigabit memory technology devices (1 and 2

2. DDR3L-RS is supported as a POR memory configuration as Intel expects these parts to be electrically and software

3. Raw Cards x16 SO-DIMM modules are not supported.

4. 1 DPC on 4SODIMM Board (2 total memory DIMMs populated) is supported.

5. Memory Down using DDR3L 2Rx8 and 1Rx32 (DDP) configurations are supported using a white paper design

rPGA, BGA

Gigabit devices are also supported).

identical to DDR3L. Actual validation checkout would depend on parts and vendor availability. PMO list for actual vendors and parts validated is available at https://www-ssl.intel.com/content/www/us/en/platform-memory/

platform-memory.html.

guidance.

(1Rx8) (note 3)

SODIMM RC F (2Rx8)

(note 3, 5)

Maximim Size

per DIMM

[GB]

4 4 8 8 16

8 8 16 16 32

Maximum Size Per Configuration [GB]

1 Ch

1 DPC

1 Ch

2 DPC

(note 4)

2 Ch

1 DPC

2 Ch

2 DPC

2.1.2

System Memory Timing Support

The IMC supports the following DDR3L/DDR3L-RS Speed Bin, CAS Write Latency (CWL), and command signal mode timings on the main memory interface:

• tCL = CAS Latency

• tRCD = Activate Command to READ or WRITE Command delay

• tRP = PRECHARGE Command Period

• CWL = CAS Write Latency

• Command Signal modes = 1N indicates a new command may be issued every clock and 2N indicates a new command may be issued every 2 clocks. Command launch mode programming depends on the transfer rate and memory configuration.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 19

Processor Family

Table 6. DDR3L / DDR3L-RS System Memory Timing Support

Processor—Interfaces

Segment Transfer

Quad Core BGA Processor with GT3/GT2 Graphics

(H-Processor) Quad Core rPGA Processor with

GT2 Graphics (M-Processor)

Rate

(MT/s)

1333 8/9 8/9 8/9 7

1600 10/11 10/11 10/11 8

tCL

(tCK)

tRCD

(tCK)

tRP

(tCK)

CWL

(tCK)

DPC CMD

1 1N/2N

2 2N

1 1N/2N

2 2N

Note: System memory timing support is based on availability and is subject to change

2.1.3

System Memory Organization Modes

The Integrated Memory Controller (IMC) supports two memory organization modes – single-channel and dual-channel. Depending upon how the DIMM Modules are populated in each memory channel, a number of different configurations can exist.

Single-Channel Mode

In this mode, all memory cycles are directed to a single-channel. Single-channel mode is used when either Channel A or Channel B DIMM connectors are populated in any order, but not both.

Dual-Channel Mode – Intel® Flex Memory Technology Mode

The IMC supports Intel Flex Memory Technology Mode. Memory is divided into symmetric and asymmetric zones. The symmetric zone starts at the lowest address in each channel and is contiguous until the asymmetric zone begins or until the top address of the channel with the smaller capacity is reached. In this mode, the system runs with one zone of dual-channel mode and one zone of single-channel mode, simultaneously, across the whole memory array.

Mode

Note: Channels A and B can be mapped for physical channel 0 and 1 respectively or vice

versa; however, channel A size must be greater or equal to channel B size.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 20 Order No.: 328901-007

CH BCH A

B B

Non interleaved access

Dual channel interleaved access

TOM

CH A and CH B can be configured to be physical channels 0 or 1 B – The largest physical memory amount of the smaller size memory module C – The remaining physical memory amount of the larger size memory module

Interfaces—Processor

Figure 2. Intel® Flex Memory Technology Operations

Dual-Channel Symmetric Mode

Dual-Channel Symmetric mode, also known as interleaved mode, provides maximum performance on real world applications. Addresses are ping-ponged between the channels after each cache line (64-byte boundary). If there are two requests, and the second request is to an address on the opposite channel from the first, that request can be sent before data from the first request has returned. If two consecutive cache lines are requested, both may be retrieved simultaneously, since they are ensured to be on opposite channels. Use Dual-Channel Symmetric mode when both Channel A and Channel B DIMM connectors are populated in any order, with the total amount of memory in each channel being the same.

When both channels are populated with the same memory capacity and the boundary between the dual channel zone and the single channel zone is the top of memory, the IMC operates completely in Dual-Channel Symmetric mode.

Note: The DRAM device technology and width may vary from one channel to the other.

2.1.4

System Memory Frequency

In all modes, the frequency of system memory is the lowest frequency of all memory modules placed in the system, as determined through the SPD registers on the memory modules. The system memory controller supports up to two DIMM connectors per channel. If DIMMs with different latency are populated across the channels, the BIOS will use the slower of the two latencies for both channels. For dual-channel mode both channels must have a DIMM connector populated. For single-channel mode, only a single channel can have a DIMM connector populated.

2.1.5

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 21

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Intel® Fast Memory Access (Intel® FMA) Technology Enhancements

The following sections describe the Just-in-Time Scheduling, Command Overlap, and Out-of-Order Scheduling Intel FMA technology enhancements.

Processor Family

Processor—Interfaces

Just-in-Time Command Scheduling

The memory controller has an advanced command scheduler where all pending requests are examined simultaneously to determine the most efficient request to be issued next. The most efficient request is picked from all pending requests and issued to system memory Just-in-Time to make optimal use of Command Overlapping. Thus, instead of having all memory access requests go individually through an arbitration mechanism forcing requests to be executed one at a time, the requests can be started without interfering with the current request allowing for concurrent issuing of requests. This allows for optimized bandwidth and reduced latency while maintaining appropriate command spacing to meet system memory protocol.

Command Overlap

Command Overlap allows the insertion of the DRAM commands between the Activate, Pre-charge, and Read/Write commands normally used, as long as the inserted commands do not affect the currently executing command. Multiple commands can be issued in an overlapping manner, increasing the efficiency of system memory protocol.

Out-of-Order Scheduling

While leveraging the Just-in-Time Scheduling and Command Overlap enhancements, the IMC continuously monitors pending requests to system memory for the best use of bandwidth and reduction of latency. If there are multiple requests to the same open page, these requests would be launched in a back-to-back manner to make optimum use of the open memory page. This ability to reorder requests on the fly allows the IMC to further reduce latency and increase bandwidth efficiency.

2.1.6

2.1.7

2.1.8

Data Scrambling

The system memory controller incorporates a Data Scrambling feature to minimize the impact of excessive di/dt on the platform system memory VRs due to successive 1s and 0s on the data bus. Past experience has demonstrated that traffic on the data bus is not random and can have energy concentrated at specific spectral harmonics creating high di/dt, which is generally limited by data patterns that excite resonance between the package inductance and on die capacitances. As a result, the system memory controller uses a data scrambling feature to create pseudo-random patterns on the system memory data bus to reduce the impact of any excessive di/dt.

DRAM Clock Generation

Every supported DIMM has two differential clock pairs. There are a total of four clock pairs driven directly by the processor to two DIMMs.

DRAM Reference Voltage Generation

The memory controller has the capability of generating the DDR3L/DDR3L-RS Reference Voltage (VREF) internally for both read (RDVREF) and write (VREFDQ) operations. The generated VREF can be changed in small steps, and an optimum VREF value is determined for both during a cold boot through advanced DDR3L/DDR3L-RS training procedures to provide the best voltage and signal margins.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 22 Order No.: 328901-007

Interfaces—Processor

2.2

PCI Express* Interface

This section describes the PCI Express* interface capabilities of the processor. See the PCI Express Base* Specification 3.0 for details on PCI Express*.

2.2.1

PCI Express* Support

The PCI Express* lanes (PEG[15:0] TX and RX) are fully-compliant to the PCI Express Base Specification, Revision 3.0.

The 4th Generation Intel® Core™ processor based on Mobile M-Processor and HProcessor Lines with Mobile PCH supports the configurations shown in the following table (may vary depending on PCH SKUs).

Table 7. PCI Express* Supported Configurations in Mobile Products

Configuration Mobile

1x8, 2x4 GFX, I/O

2x8 GFX, I/O

1x16 GFX, I/O

• The port may negotiate down to narrower widths.

— Support for x16/x8/x4/x2/x1 widths for a single PCI Express* mode.

• 2.5 GT/s, 5.0 GT/s and 8 GT/s PCI Express* bit rates are supported.

• Gen1 Raw bit-rate on the data pins of 2.5 GT/s, resulting in a real bandwidth per pair of 250 MB/s given the 8b/10b encoding used to transmit data across this interface. This also does not account for packet overhead and link maintenance. Maximum theoretical bandwidth on the interface of 4 GB/s in each direction simultaneously, for an aggregate of 8 GB/s when x16 Gen 1.

• Gen 2 Raw bit-rate on the data pins of 5.0 GT/s, resulting in a real bandwidth per pair of 500 MB/s given the 8b/10b encoding used to transmit data across this interface. This also does not account for packet overhead and link maintenance. Maximum theoretical bandwidth on the interface of 8 GB/s in each direction simultaneously, for an aggregate of 16 GB/s when x16 Gen 2.

• Gen 3 raw bit-rate on the data pins of 8.0 GT/s, resulting in a real bandwidth per pair of 984 MB/s using 128b/130b encoding to transmit data across this interface. This also does not account for packet overhead and link maintenance. Maximum theoretical bandwidth on the interface of 16 GB/s in each direction simultaneously, for an aggregate of 32 GB/s when x16 Gen 3.

• Hierarchical PCI-compliant configuration mechanism for downstream devices.

• Traditional PCI style traffic (asynchronous snooped, PCI ordering).

• PCI Express* extended configuration space. The first 256 bytes of configuration space aliases directly to the PCI Compatibility configuration space. The remaining portion of the fixed 4-KB block of memory-mapped space above that (starting at 100h) is known as extended configuration space.

• PCI Express* Enhanced Access Mechanism. Accessing the device configuration space in a flat memory mapped fashion.

• Automatic discovery, negotiation, and training of link out of reset.

• Traditional AGP style traffic (asynchronous non-snooped, PCI-X Relaxed ordering).

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 23

Processor—Interfaces

• Peer segment destination posted write traffic (no peer-to-peer read traffic) in Virtual Channel 0:

— DMI -> PCI Express* Port 0

— DMI -> PCI Express* Port 1

— PCI Express* Port 0 -> DMI

— PCI Express* Port 1 -> DMI

• 64-bit downstream address format, but the processor never generates an address above 64 GB (Bits 63:36 will always be zeros).

• 64-bit upstream address format, but the processor responds to upstream read transactions to addresses above 64 GB (addresses where any of Bits 63:36 are nonzero) with an Unsupported Request response. Upstream write transactions to addresses above 64 GB will be dropped.

• Re-issues Configuration cycles that have been previously completed with the Configuration Retry status.

• PCI Express* reference clock is 100-MHz differential clock.

• Power Management Event (PME) functions.

• Dynamic width capability.

• Message Signaled Interrupt (MSI and MSI-X) messages.

• Polarity inversion

• Dynamic lane numbering reversal as defined by the PCI Express Base Specification.

• Static lane numbering reversal. Does not support dynamic lane reversal, as defined (optional) by the PCI Express Base Specification.

• Supports Half Swing “low-power/low-voltage” mode.

Note: The processor does not support PCI Express* Hot-Plug.

2.2.2

PCI Express* Architecture

Compatibility with the PCI addressing model is maintained to ensure that all existing applications and drivers operate unchanged.

The PCI Express* configuration uses standard mechanisms as defined in the PCI Plugand-Play specification. The processor PCI Express* ports support Gen 3. At 8 GT/s, Gen 3 operation results in twice as much bandwidth per lane as compared to Gen 2 operation. The 16 lanes PEG can operate at 2.5 GT/s, 5 GT/s, or 8 GT/s.

Gen 3 PCI Express* uses a 128b/130b encoding that is about 23% more efficient than the 8b/10b encoding used in Gen 1 and Gen 2.

The PCI Express* architecture is specified in three layers – Transaction Layer, Data Link Layer, and Physical Layer. See the PCI Express Base Specification 3.0 for details of PCI Express* architecture.

2.2.3

PCI Express* Configuration Mechanism

The PCI Express* (external graphics) link is mapped through a PCI-to-PCI bridge structure.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 24 Order No.: 328901-007

PCI-PCI

Bridge

representing

root PCI Express ports (Device 1 and

Device 6)

PCI

Compatible

Host Bridge

Device

(Device 0)

PCI

Express*

Device

PEG0

DMI

Interfaces—Processor

Figure 3. PCI Express* Related Register Structures in the Processor

PCI Express* extends the configuration space to 4096 bytes per-device/function, as compared to 256 bytes allowed by the conventional PCI specification. PCI Express* configuration space is divided into a PCI-compatible region (that consists of the first 256 bytes of a logical device's configuration space) and an extended PCI Express* region (that consists of the remaining configuration space). The PCI-compatible region can be accessed using either the mechanisms defined in the PCI specification or using the enhanced PCI Express* configuration access mechanism described in the PCI Express* Enhanced Configuration Mechanism section.

The PCI Express* Host Bridge is required to translate the memory-mapped PCI Express* configuration space accesses from the host processor to PCI Express* configuration cycles. To maintain compatibility with PCI configuration addressing mechanisms, it is recommended that system software access the enhanced configuration space using 32-bit operations (32-bit aligned) only. See the PCI Express Base Specification for details of both the PCI-compatible and PCI Express* Enhanced configuration mechanisms and transaction rules.

PCI Express* Graphics

The external graphics attach (PEG) on the processor is a single, 16-lane (x16) port. The PEG port is designed to be compliant with the PCI Express Base Specification, Revision 3.0.

PCI Express* Lanes Connection

The following figure demonstrates the PCIe* lane mapping.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 25

Processor Family

Figure 4. PCI Express* Typical Operation 16 Lanes Mapping

1 X 16

ntroller

Lane 0

Lane 1

Lane 2

Lane 3

Lane 4

Lane 5

Lane 6

Lane 7

Lane 8

Lane 9

Lane 10

Lane 11

Lane 12

Lane 13

Lane 14

Lane 15

1 X 8 Controller

1 X 4 Cont

ller

Processor—Interfaces

2.3

Direct Media Interface (DMI)

Direct Media Interface (DMI) connects the processor and the PCH. Next generation DMI2 is supported.

Note: Only DMI x4 configuration is supported.

• DMI 2.0 support.

• Compliant to Direct Media Interface Second Generation (DMI2).

• Four lanes in each direction.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 26 Order No.: 328901-007

Interfaces—Processor

• 5 GT/s point-to-point DMI interface to PCH is supported.

• Raw bit-rate on the data pins of 5.0 GB/s, resulting in a real bandwidth per pair of

• Maximum theoretical bandwidth on interface of 2 GB/s in each direction

• Shares 100-MHz PCI Express* reference clock.

• 64-bit downstream address format, but the processor never generates an address

• 64-bit upstream address format, but the processor responds to upstream read

• Supports the following traffic types to or from the PCH:

• APIC and MSI interrupt messaging support:

• Downstream SMI, SCI and SERR error indication.

• Legacy support for ISA regime protocol (PHOLD/PHOLDA) required for parallel port

• DC coupling – no capacitors between the processor and the PCH.

• Polarity inversion.

• PCH end-to-end lane reversal across the link.

• Supports Half Swing “low-power/low-voltage”.

500 MB/s given the 8b/10b encoding used to transmit data across this interface. Does not account for packet overhead and link maintenance.

simultaneously, for an aggregate of 4 GB/s when DMI x4.

above 64 GB (Bits 63:36 will always be zeros).

transactions to addresses above 64 GB (addresses where any of Bits 63:36 are nonzero) with an Unsupported Request response. Upstream write transactions to addresses above 64 GB will be dropped.

— DMI -> DRAM

— DMI -> processor core (Virtual Legacy Wires (VLWs), Resetwarn, or MSIs

only)

— Processor core -> DMI

— Message Signaled Interrupt (MSI and MSI-X) messages

DMA, floppy drive, and LPC bus masters.

DMI Error Flow

DMI can only generate SERR in response to errors, never SCI, SMI, MSI, PCI INT, or GPE. Any DMI related SERR activity is associated with Device 0.

DMI Link Down

The DMI link going down is a fatal, unrecoverable error. If the DMI data link goes to data link down, after the link was up, then the DMI link hangs the system by not allowing the link to retrain to prevent data corruption. This link behavior is controlled by the PCH.

Downstream transactions that had been successfully transmitted across the link prior to the link going down may be processed as normal. No completions from downstream, non-posted transactions are returned upstream over the DMI link after a link down event.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 27

Processor—Interfaces

2.4

Processor Graphics

The processor graphics contains a generation 7.5 graphics core architecture. This enables substantial gains in performance and lower power consumption over previous generations. Up to 40 Execution Units are supported depending on the processor SKU.

• Next Generation Intel Clear Video Technology HD Support is a collection of video playback and enhancement features that improve the end user’s viewing experience

— Encode / transcode HD content

— Playback of high definition content including Blu-ray Disc*

— Superior image quality with sharper, more colorful images

— Playback of Blu-ray* disc S3D content using HDMI (1.4a specification

compliant with 3D)

• DirectX* Video Acceleration (DXVA) support for accelerating video processing

— Full AVC/VC1/MPEG2 HW Decode

• Advanced Scheduler 2.0, 1.0, XPDM support

• Windows* 8, Windows* 7, OSX, Linux* operating system support

• DirectX* 11.1, DirectX* 11, DirectX* 10.1, DirectX* 10, DirectX* 9 support.

• OpenGL* 4.0, support

• Switchable Graphics muxless support for mobile platforms

2.5

Processor Graphics Controller (GT)

The Graphics Engine Architecture includes 3D compute elements, Multi-format HW assisted decode/encode pipeline, and Mid-Level Cache (MLC) for superior high definition playback, video quality, and improved 3D performance and media.

The Display Engine handles delivering the pixels to the screen. GSA (Graphics in System Agent) is the primary channel interface for display memory accesses and “PCI-like” traffic in and out.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 28 Order No.: 328901-007

Interfaces—Processor

Figure 5. Processor Graphics Controller Unit Block Diagram

2.5.1

3D and Video Engines for Graphics Processing

The Gen 7.5 3D engine provides the following performance and power-management enhancements.

3D Pipeline

The 3D graphics pipeline architecture simultaneously operates on different primitives or on different portions of the same primitive. All the cores are fully programmable, increasing the versatility of the 3D Engine.

3D Engine Execution Units

• Supports up to 40 EUs. . The EUs perform 128-bit wide execution per clock.

• Support SIMD8 instructions for vertex processing and SIMD16 instructions for pixel processing.

Vertex Fetch (VF) Stage

The VF stage executes 3DPRIMITIVE commands. Some enhancements have been included to better support legacy D3D APIs as well as SGI OpenGL*.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 29

Processor Family

Processor—Interfaces

Vertex Shader (VS) Stage

The VS stage performs shading of vertices output by the VF function. The VS unit produces an output vertex reference for every input vertex reference received from the VF unit, in the order received.

Geometry Shader (GS) Stage

The GS stage receives inputs from the VS stage. Compiled application-provided GS programs, specifying an algorithm to convert the vertices of an input object into some output primitives. For example, a GS shader may convert lines of a line strip into polygons representing a corresponding segment of a blade of grass centered on the line. Or it could use adjacency information to detect silhouette edges of triangles and output polygons extruding out from the edges.

Clip Stage

The Clip stage performs general processing on incoming 3D objects. However, it also includes specialized logic to perform a Clip Test function on incoming objects. The Clip Test optimizes generalized 3D Clipping. The Clip unit examines the position of incoming vertices, and accepts/rejects 3D objects based on its Clip algorithm.

Strips and Fans (SF) Stage

The SF stage performs setup operations required to rasterize 3D objects. The outputs from the SF stage to the Windower stage contain implementation-specific information required for the rasterization of objects and also supports clipping of primitives to some extent.

Windower / IZ (WIZ) Stage

The WIZ unit performs an early depth test, which removes failing pixels and eliminates unnecessary processing overhead.

The Windower uses the parameters provided by the SF unit in the object-specific rasterization algorithms. The WIZ unit rasterizes objects into the corresponding set of pixels. The Windower is also capable of performing dithering, whereby the illusion of a higher resolution when using low-bpp channels in color buffers is possible. Color dithering diffuses the sharp color bands seen on smooth-shaded objects.

Video Engine

The Video Engine handles the non-3D (media/video) applications. It includes support for VLD and MPEG2 decode in hardware.

2D Engine

The 2D Engine contains BLT (Block Level Transfer) functionality and an extensive set of 2D instructions. To take advantage of the 3D during engine’s functionality, some BLT functions make use of the 3D renderer.

Processor Graphics VGA Registers

The 2D registers consists of original VGA registers and others to support graphics modes that have color depths, resolutions, and hardware acceleration features that go beyond the original VGA standard.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 30 Order No.: 328901-007

Interfaces—Processor

Logical 128-Bit Fixed BLT and 256 Fill Engine

This BLT engine accelerates the GUI of Microsoft Windows* operating systems. The 128-bit BLT engine provides hardware acceleration of block transfers of pixel data for many common Windows operations. The BLT engine can be used for the following:

• Move rectangular blocks of data between memory locations

• Data alignment

• To perform logical operations (raster ops)

The rectangular block of data does not change, as it is transferred between memory locations. The allowable memory transfers are between: cacheable system memory and frame buffer memory, frame buffer memory and frame buffer memory, and within system memory. Data to be transferred can consist of regions of memory, patterns, or solid color fills. A pattern is always 8 x 8 pixels wide and may be 8, 16, or 32 bits per pixel.

The BLT engine expands monochrome data into a color depth of 8, 16, or 32 bits. BLTs can be either opaque or transparent. Opaque transfers move the data specified to the destination. Transparent transfers compare destination color to source color and write according to the mode of transparency selected.

Data is horizontally and vertically aligned at the destination. If the destination for the BLT overlaps with the source memory location, the BLT engine specifies which area in memory to begin the BLT transfer. Hardware is included for all 256 raster operations (source, pattern, and destination) defined by Microsoft*, including transparent BLT.

The BLT engine has instructions to invoke BLT and stretch BLT operations, permitting software to set up instruction buffers and use batch processing. The BLT engine can perform hardware clipping during BLTs.

2.5.2

Multi Graphics Controllers Multi-Monitor Support

The processor supports simultaneous use of the Processor Graphics Controller (GT) and a x16 PCI Express* Graphics (PEG) device. The processor supports a maximum of 2 displays connected to the PEG card in parallel with up to 2 displays connected to the processor and PCH.

Note: When supporting Multi Graphics Multi Monitors, "drag and drop" between monitors and

the 2x8PEG is not supported.

2.6

Digital Display Interface (DDI)

• The processor supports:

— Three Digital Display (x4 DDI) interfaces that can be configured as

DisplayPort*, HDMI*, or DVI. DisplayPort* can be configured to use 1, 2, or 4 lanes depending on the bandwidth requirements and link data rate of RBR (1.62 GT/s), HBR (2.7 GT/s) and HBR2 (5.4 GT/s). When configured as HDMI*, DDIx4 port can support 2.97 GT/s. Built-in displays are only supported on eDP.

— In addition, the processor supports a dedicated embedded DisplayPort*

(eDPx4) interface. eDPx4 can be configured in one of the following ways:

1. One x2 embedded DisplayPort* and one x2 FDI (FDI Port for legacy VGA support on PCH).

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 31

Processor—Interfaces

• FDI_TXN0 and FDI_TXP0 should be routed to EDP_TXN2 and EDP_TXP2, respectively

• FDI_TXN1 and FDI_TXP1 should be routed to EDP_TXN3 and EDP_TXP3, respectively

2. One x4 embedded DisplayPort* and no FDI (no VGA support from PCH in

this configuration)

Note: One of the two configurations of eDP can be selected using VBIOS Tool

(VBT) and hardware gets programmed to function as x4 eDP or x2 eDP and x2 FDI by VBIOS during boot time.

• The HDMI* interface supports HDMI with 3D, 4K, Deep Color, and x.v.Color. The DisplayPort* interface supports the VESA DisplayPort* Standard Version 1, Revision 2.

• The processor supports High-bandwidth Digital Content Protection (HDCP) for high-definition content playback over digital interfaces.

• The processor also integrates dedicated a Mini HD audio controller to drive audio on integrated digital display interfaces, such as HDMI* and DisplayPort*. The HD audio controller on the PCH would continue to support down CODECs, and so on. The processor Mini HD audio controller supports two High-Definition Audio streams simultaneously on any of the three digital ports.

• The processor supports streaming any 3 independent and simultaneous display combination of DisplayPort*/HDMI*/DVI/eDP*/VGA monitors with the exception of 3 simultaneous display support of HDMI*/DVI . In the case of 3 simultaneous displays, two High Definition Audio streams over the digital display interfaces are supported.

• Each digital port is capable of driving resolutions up to 3840x2160 at 60 Hz through DisplayPort* and 4096x2304 at 24 Hz/2560x1600 at 60 Hz using HDMI*.

• DisplayPort* Aux CH, DDC channel, Panel power sequencing, and HPD are supported through the PCH.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 32 Order No.: 328901-007

Memory \ Config Interface

Display

Pipe A

Display

Pipe B

Display

Pipe C

Panel Fitting

HD Audio Controller

Transcoder A

DP / HDMI

Timing, VDIP

Transcoder B

DP / HDMI

Timing, VDIP

Transcoder C

DP / HDMI

Timing, VDIP

eDP Mux

Transcoder eDP*

DP encoder

Timing, VDIP

DPT, SRID

Port Mux

Audio

Codec

Aux

eDP

X4 eDP

X2 eDP

and X2 FDI

PCH Display

DDI Ports B, C, and D

X4 DP /

HDMI /

DVI

X4 DP / HDMI /

DVI

FDI

FDI RX

X4 DP / HDMI /

DVI

Interfaces—Processor

Figure 6. Processor Display Architecture

Display is the presentation stage of graphics. This involves:

• Pulling rendered data from memory

• Converting raw data into pixels

• Blending surfaces into a frame

• Organizing pixels into frames

• Optionally scaling the image to the desired size

• Re-timing data for the intended target

• Formatting data according to the port output standard

DisplayPort*

DisplayPort* is a digital communication interface that uses differential signaling to achieve a high-bandwidth bus interface designed to support connections between PCs and monitors, projectors, and TV displays. DisplayPort* is also suitable for display connections between consumer electronics devices, such as high-definition optical disc players, set top boxes, and TV displays.

A DisplayPort* consists of a Main Link, Auxiliary channel, and a Hot-Plug Detect signal. The Main Link is a unidirectional, high-bandwidth, and low latency channel used for transport of isochronous data streams such as uncompressed video and audio. The Auxiliary Channel (AUX CH) is a half-duplex bidirectional channel used for link management and device control. The Hot-Plug Detect (HPD) signal serves as an interrupt request for the sink device.

The processor is designed in accordance with the VESA DisplayPort* Standard Version

1.2a. The processor supports VESA DisplayPort* PHY Compliance Test Specification

1.2a and VESA DisplayPort* Link Layer Compliance Test Specification 1.2a.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 33

Processor Family

Figure 7. DisplayPort* Overview

Source Device Sink Device

Main Link

(Isochronous Streams)

AUX CH

(Link/Device Managemet)

Hot-Plug Detect

(Interrupt Request)

DisplayPort Tx

DisplayPort Rx

High-Definition Multimedia Interface (HDMI*)

The High-Definition Multimedia Interface* (HDMI*) is provided for transmitting uncompressed digital audio and video signals from DVD players, set-top boxes, and other audiovisual sources to television sets, projectors, and other video displays. It can carry high quality multi-channel audio data and all standard and high-definition consumer electronics video formats. The HDMI display interface connecting the processor and display devices uses transition minimized differential signaling (TMDS) to carry audiovisual information through the same HDMI cable.

Processor—Interfaces

HDMI includes three separate communications channels — TMDS, DDC, and the optional CEC (consumer electronics control). CEC is not supported on the processor. As shown in the following figure, the HDMI cable carries four differential pairs that make up the TMDS data and clock channels. These channels are used to carry video, audio, and auxiliary data. In addition, HDMI carries a VESA DDC. The DDC is used by an HDMI Source to determine the capabilities and characteristics of the Sink.

Audio, video, and auxiliary (control/status) data is transmitted across the three TMDS data channels. The video pixel clock is transmitted on the TMDS clock channel and is used by the receiver for data recovery on the three data channels. The digital display data signals driven natively through the PCH are AC coupled and needs level shifting to convert the AC coupled signals to the HDMI compliant digital signals.

The processor HDMI interface is designed in accordance with the High-Definition Multimedia Interface with 3D, 4K, Deep Color, and x.v.Color.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 34 Order No.: 328901-007

HDMI Source

HDMI Sink

TMDS Data Channel 0

Hot-Plug Detect

HDMI Tx HDMI Rx

TMDS

Data

Channel

TMDS Data Channel 2

TMDS Clock Channel

CEC Line (optional)

Display Data Channel (DDC)

Interfaces—Processor

Figure 8. HDMI* Overview

Digital Video Interface

The processor Digital Ports can be configured to drive DVI-D. DVI uses TMDS for transmitting data from the transmitter to the receiver, which is similar to the HDMI protocol except for the audio and CEC. Refer to the HDMI section for more information on the signals and data transmission. To drive DVI-I through the back panel the VGA DDC signals are connected along with the digital data and clock signals from one of the Digital Ports. When a system has support for a DVI-I port, then either VGA or the DVI-D through a single DVI-I connector can be driven, but not both simultaneously.

The digital display data signals driven natively through the processor are AC coupled and need level shifting to convert the AC coupled signals to the HDMI compliant digital signals.

embedded DisplayPort*

embedded DisplayPort* (eDP*) is an embedded version of the DisplayPort standard oriented towards applications such as notebook and All-In-One PCs. The processor supports dedicated eDP. Like DisplayPort, embedded DisplayPort also consists of a Main Link, Auxiliary channel, and an optional Hot-Plug Detect signal.

The eDP on the processor can be configured for 2 lanes using a dedicated eDPx2 port on the processor or 4 lanes by configuring the Intel FDI port as eDPx2 in addition to dedicated eDPx2 port on processor.

Processor supports embedded DisplayPort* (eDP*) Standard Version 1.3 and VESA embedded DisplayPort* Standard Version 1.3.

Integrated Audio

• HDMI and display port interfaces carry audio along with video.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 35

Processor Family

Processor—Interfaces

• Processor supports two DMA controllers to output two High Definition audio

streams on two digital ports simultaneously.

• Supports only the internal HDMI and DP CODECs.

Table 8. Processor Supported Audio Formats over HDMI*and DisplayPort*

Audio Formats HDMI* DisplayPort*

AC-3 Dolby* Digital Yes Yes

Dolby Digital Plus Yes Yes

DTS-HD* Yes Yes

LPCM, 192 kHz/24 bit, 8 Channel Yes Yes

Dolby TrueHD, DTS-HD Master Audio* (Lossless Blu-Ray Disc* Audio Format)

Yes Yes

The processor will continue to support Silent stream. Silent stream is an integrated audio feature that enables short audio streams, such as system events to be heard over the HDMI and DisplayPort monitors. The processor supports silent streams over the HDMI and DisplayPort interfaces at 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz,

176.4 kHz, and 192 kHz sampling rates.

Multiple Display Configurations

The following multiple display configuration modes are supported (with appropriate driver software):

• Single Display is a mode with one display port activated to display the output to

one display device.

• Intel Display Clone is a mode with up to three display ports activated to drive the

display content of same color depth setting but potentially different refresh rate and resolution settings to all the active display devices connected.

• Extended Desktop is a mode with up to three display ports activated to drive the

content with potentially different color depth, refresh rate, and resolution settings on each of the active display devices connected.

The digital ports on the processor can be configured to support DisplayPort*/HDMI/ DVI. The following table shows examples of valid three display configurations through the processor.

Table 9. Valid Three Display Configurations through the Processor

Display 1 Display 2 Display 3 Maximum

HDMI HDMI DP

DVI DVI DP 1920x1200 @ 60 Hz 3840x2160 @ 60 Hz

DP DP DP 3840x2160 @ 60 Hz

VGA DP HDMI 1920x1200 @ 60 Hz

eDP DP HDMI 3840x2160 @ 60 Hz

Resolution Display

4096x2304 @ 24 Hz 2560x1600 @ 60 Hz

Maximum

Resolution

Display 2

3840x2160 @

60 Hz

3840x2160 @

60 Hz

Maximum

Resolution Display

3840x2160 @ 60 Hz

4096x2304 @ 24 Hz 2560x1600 @ 60 Hz

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 36 Order No.: 328901-007

Interfaces—Processor

Display 1 Display 2 Display 3 Maximum

Resolution Display

eDP DP DP 3840x2160 @ 60 Hz 3840x2160 @ 60 Hz

eDP HDMI HDMI 3840x2160 @ 60 Hz

Notes: 1. Requires support of 2 channel DDR3L/DDR3L-RS 1600 MT/s configuration for driving 3

simultaneous 3840x2160 @ 60 Hz display resolutions

2. DP and eDP resolutions in the above table are supported for 4 lanes with link data rate HBR2.

Maximum

Resolution

Display 2

4096x2304 @ 24 Hz 2560x1600 @ 60 Hz

Maximum

Resolution Display

The following table shows the DP/eDP resolutions supported for 1, 2, or 4 lanes depending on link data rate of RBR, HBR, and HBR2.

Table 10. DisplayPort and embedded DisplayPort* Resolutions for 1, 2, 4 Lanes – Link

Data Rate of RBR, HBR, and HBR2

Link Data Rate Lane Count

1 2 4

RBR 1064x600 1400x1050 2240x1400

HBR 1280x960 1920x1200 2880x1800

HBR2 1920x1200 2880x1800 3840x2160

Any 3 displays can be supported simultaneously using the following rules:

• Maximum of 2 HDMIs

• Maximum of 2 DVIs

• Maximum of 1 HDMI and 1 DVI

• Any 3 DisplayPort

• One VGA

• One eDP

High-bandwidth Digital Content Protection (HDCP)

HDCP is the technology for protecting high-definition content against unauthorized copy or unreceptive between a source (computer, digital set top boxes, and so on) and the sink (panels, monitor, and TVs). The processor supports HDCP 1.4 for content protection over wired displays (HDMI*, DVI, and DisplayPort*).

The HDCP 1.4 keys are integrated into the processor and customers are not required to physically configure or handle the keys.

2.7

Intel® Flexible Display Interface (Intel® FDI)

• The Intel Flexible Display Interface (Intel FDI) passes display data from the processor (source) to the PCH (sink) for display through a display interface on the PCH.

• Intel FDI supports 2 lanes at 2.7 GT/s fixed frequency. This can be configured to 1 or 2 lanes depending on the bandwidth requirements.

• Intel FDI supports 8 bits per color only.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 37

Processor Family

Processor—Interfaces

• Side band sync pin (FDI_CSYNC).

• Side band interrupt pin (DISP_INT). This carries combined interrupt for HPDs of all the ports, AUX and I2C completion events, and so on.

• Intel FDI is not encrypted as it drives only VGA and content protection is not supported on VGA.

2.8

2.8.1

Platform Environmental Control Interface (PECI)

PECI is an Intel proprietary interface that provides a communication channel between Intel processors and external components, like Super I/O (SIO) and Embedded Controllers (EC), to provide processor temperature, Turbo, Configurable TDP, and memory throttling control mechanisms and many other services. PECI is used for platform thermal management and real time control and configuration of processor features and performance.

PECI Bus Architecture

The PECI architecture is based on a wired-OR bus that the clients (as processor PECI) can pull up high (with strong drive).

The idle state on the bus is near zero.

The following figure demonstrates PECI design and connectivity. While the host/ originator can be a third party PECI host, one of the PECI clients is a processor PECI device.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 38 Order No.: 328901-007

Host / Originator

PECI

<10pF/Node

PECI Client

Additional

PECI Clients

Interfaces—Processor

Figure 9. PECI Host-Clients Connection Example

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 39

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family

3.0 Technologies

This chapter provides a high-level description of Intel technologies implemented in the processor.

The implementation of the features may vary between the processor SKUs.

Details on the different technologies of Intel processors and other relevant external notes are located at the Intel technology web site: http://www.intel.com/technology/

Processor—Technologies

3.1

Intel® Virtualization Technology (Intel® VT)

Intel® Virtualization Technology (Intel® VT) makes a single system appear as multiple independent systems to software. This allows multiple, independent operating systems to run simultaneously on a single system. Intel VT comprises technology components to support virtualization of platforms based on Intel architecture microprocessors and chipsets.

Intel® Virtualization Technology (Intel® VT) for IA-32, Intel® 64 and Intel Architecture (Intel® VT-x) added hardware support in the processor to improve the virtualization performance and robustness. Intel® Virtualization Technology for Directed I/O (Intel VT-d) extends Intel® VT-x by adding hardware assisted support to improve I/O device virtualization performance.

Intel® VT-x specifications and functional descriptions are included in the Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 3B and is available at:

http://www.intel.com/products/processor/manuals/index.htm

The Intel VT-d specification and other Intel VT documents can be referenced at:

http://www.intel.com/technology/virtualization/index.htm

https://sharedspaces.intel.com/sites/PCDC/SitePages/Ingredients/ingredient.aspx? ing=VT

Intel® VT-x Objectives

Intel VT-x provides hardware acceleration for virtualization of IA platforms. Virtual Machine Monitor (VMM) can use Intel VT-x features to provide an improved reliable virtualized platform. By using Intel VT-x, a VMM is:

• Robust: VMMs no longer need to use paravirtualization or binary translation. This means that off-the-shelf operating systems and applications can be run without any special steps.

• Enhanced: Intel VT enables VMMs to run 64-bit guest operating systems on IA x86 processors.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 40 Order No.: 328901-007

Technologies—Processor

• More reliable: Due to the hardware support, VMMs can now be smaller, less complex, and more efficient. This improves reliability and availability and reduces the potential for software conflicts.

• More secure: The use of hardware transitions in the VMM strengthens the isolation of VMs and further prevents corruption of one VM from affecting others on the same system.

Intel® VT-x Features

The processor supports the following Intel VT-x features:

• Extended Page Table (EPT) Accessed and Dirty Bits

— EPT A/D bits enabled VMMs to efficiently implement memory management and

• Extended Page Table Pointer (EPTP) switching

— EPTP switching is a specific VM function. EPTP switching allows guest software

• Pause loop exiting

— Support VMM schedulers seeking to determine when a virtual processor of a

page classification algorithms to optimize VM memory operations, such as defragmentation, paging, live migration, and check-pointing. Without hardware support for EPT A/D bits, VMMs may need to emulate A/D bits by marking EPT paging-structures as not-present or read-only, and incur the overhead of EPT page-fault VM exits and associated software processing.

(in VMX non-root operation, supported by EPT) to request a different EPT paging-structure hierarchy. This is a feature by which software in VMX nonroot operation can request a change of EPTP without a VM exit. Software can choose among a set of potential EPTP values determined in advance by software in VMX root operation.

multiprocessor virtual machine is not performing useful work. This situation may occur when not all virtual processors of the virtual machine are currently scheduled and when the virtual processor in question is in a loop involving the PAUSE instruction. The new feature allows detection of such loops and is thus called PAUSE-loop exiting.

The processor core supports the following Intel VT-x features:

• Extended Page Tables (EPT)

— EPT is hardware assisted page table virtualization.

— It eliminates VM exits from the guest operating system to the VMM for shadow

page-table maintenance.

• Virtual Processor IDs (VPID)

— Ability to assign a VM ID to tag processor core hardware structures (such as

TLBs).

— This avoids flushes on VM transitions to give a lower-cost VM transition time

and an overall reduction in virtualization overhead.

• Guest Preemption Timer

— Mechanism for a VMM to preempt the execution of a guest operating system

after an amount of time specified by the VMM. The VMM sets a timer value before entering a guest.

— The feature aids VMM developers in flexibility and Quality of Service (QoS)

guarantees.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 41

Processor—Technologies

• Descriptor-Table Exiting

— Descriptor-table exiting allows a VMM to protect a guest operating system

from an internal (malicious software based) attack by preventing relocation of key system data structures like IDT (interrupt descriptor table), GDT (global descriptor table), LDT (local descriptor table), and TSS (task segment selector).

— A VMM using this feature can intercept (by a VM exit) attempts to relocate

these data structures and prevent them from being tampered by malicious software.

Intel® VT-d Objectives

The key Intel VT-d objectives are domain-based isolation and hardware-based virtualization. A domain can be abstractly defined as an isolated environment in a platform to which a subset of host physical memory is allocated. Intel VT-d provides accelerated I/O performance for a virtualized platform and provides software with the following capabilities:

• I/O device assignment and security: for flexibly assigning I/O devices to VMs and extending the protection and isolation properties of VMs for I/O operations.

• DMA remapping: for supporting independent address translations for Direct Memory Accesses (DMA) from devices.

• Interrupt remapping: for supporting isolation and routing of interrupts from devices and external interrupt controllers to appropriate VMs.

• Reliability: for recording and reporting to system software DMA and interrupt errors that may otherwise corrupt memory or impact VM isolation.

Intel VT-d accomplishes address translation by associating a transaction from a given I/O device to a translation table associated with the Guest to which the device is assigned. It does this by means of the data structure in the following illustration. This table creates an association between the device's PCI Express* Bus/Device/Function (B/D/F) number and the base address of a translation table. This data structure is populated by a VMM to map devices to translation tables in accordance with the device assignment restrictions above, and to include a multi-level translation table (VT-d Table) that contains Guest specific address translations.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 42 Order No.: 328901-007

Root entry 0

Root entry N

Root entry 255

Context entry 0

Context entry 255

Context entry 0

Context entry 255

(Bus 255)

(Bus N)

(Bus 0)

Root entry table

(Dev 31, Func 7)

(Dev 0, Func 1)

(Dev 0, Func 0)

Context entry Table

For bus N

Context entry Table

For bus 0

Address Translation

Structures for Domain A

Address Translation

Structures for Domain B

Technologies—Processor

Figure 10. Device to Domain Mapping Structures

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 43

Intel VT-d functionality, often referred to as an Intel VT-d Engine, has typically been implemented at or near a PCI Express host bridge component of a computer system. This might be in a chipset component or in the PCI Express functionality of a processor with integrated I/O. When one such Intel VT-d engine receives a PCI Express transaction from a PCI Express bus, it uses the B/D/F number associated with the transaction to search for an Intel VT-d translation table. In doing so, it uses the B/D/F number to traverse the data structure shown in the above figure. If it finds a valid Intel VT-d table in this data structure, it uses that table to translate the address provided on the PCI Express bus. If it does not find a valid translation table for a given translation, this results in an Intel VT-d fault. If Intel VT-d translation is required, the Intel VT-d engine performs an N-level table walk.

For more information, refer to Intel® Virtualization Technology for Directed I/O Architecture Specification http://download.intel.com/technology/computing/vptech/

Intel(r)_VT_for_Direct_IO.pdf

Intel® VT-d Features

The processor supports the following Intel VT-d features:

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family

Processor—Technologies

• Memory controller and processor graphics comply with the Intel VT-d 1.2 Specification

• Two Intel VT-d DMA remap engines

— iGFX DMA remap engine

— Default DMA remap engine (covers all devices except iGFX)

• Support for root entry, context entry, and default context

• 39-bit guest physical address and host physical address widths

• Support for 4 KB page sizes

• Support for register-based fault recording only (for single entry only) and support for MSI interrupts for faults

• Support for both leaf and non-leaf caching

• Support for boot protection of default page table

• Support for non-caching of invalid page table entries

• Support for hardware-based flushing of translated but pending writes and pending reads, on IOTLB invalidation

• Support for Global, Domain specific, and Page specific IOTLB invalidation

• MSI cycles (MemWr to address FEEx_xxxxh) not translated

— Translation faults result in cycle forwarding to VBIOS region (byte enables

masked for writes). Returned data may be bogus for internal agents; PEG/DMI interfaces return unsupported request status

• Interrupt remapping is supported

• Queued invalidation is supported

• Intel VT-d translation bypass address range is supported (Pass Through)

The processor supports the following added new Intel VT-d features:

• 4-level Intel VT-d Page walk: Both default Intel VT-d engine, as well as the IGD Intel VT-d engine, are upgraded to support 4-level Intel VT-d tables (adjusted guest address width 48 bits)

• Intel VT-d superpage: support of Intel VT-d superpage (2 MB, 1 GB) for the default Intel VT-d engine (that covers all devices except IGD)

IGD Intel VT-d engine does not support superpage and BIOS should disable superpage in default Intel VT-d engine when iGFX is enabled.

Note: Intel VT-d Technology may not be available on all SKUs.

3.2

Intel® Trusted Execution Technology (Intel® TXT)

Intel Trusted Execution Technology (Intel TXT) defines platform-level enhancements that provide the building blocks for creating trusted platforms.

The Intel TXT platform helps to provide the authenticity of the controlling environment such that those wishing to rely on the platform can make an appropriate trust decision. The Intel TXT platform determines the identity of the controlling environment by accurately measuring and verifying the controlling software.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 44 Order No.: 328901-007

Technologies—Processor

Another aspect of the trust decision is the ability of the platform to resist attempts to change the controlling environment. The Intel TXT platform will resist attempts by software processes to change the controlling environment or bypass the bounds set by the controlling environment.

Intel TXT is a set of extensions designed to provide a measured and controlled launch of system software that will then establish a protected environment for itself and any additional software that it may execute.

These extensions enhance two areas:

• The launching of the Measured Launched Environment (MLE).

• The protection of the MLE from potential corruption.

The enhanced platform provides these launch and control interfaces using Safer Mode Extensions (SMX).

The SMX interface includes the following functions:

• Measured/Verified launch of the MLE.

• Mechanisms to ensure the above measurement is protected and stored in a secure location.

• Protection mechanisms that allow the MLE to control attempts to modify itself.

3.3

The processor also offers additional enhancements to System Management Mode (SMM) architecture for enhanced security and performance. The processor provides new MSRs to:

• Enable a second SMM range

• Enable SMM code execution range checking

• Select whether SMM Save State is to be written to legacy SMRAM or to MSRs

• Determine if a thread is going to be delayed entering SMM

• Determine if a thread is blocked from entering SMM

• Targeted SMI, enable/disable threads from responding to SMIs both VLWs and IPI

For the above features, BIOS must test the associated capability bit before attempting to access any of the above registers.

For more information, refer to the Intel® Trusted Execution Technology Measured

Launched Environment Programming Guide.

Intel® Hyper-Threading Technology (Intel® HT Technology)

The processor supports Intel Hyper-Threading Technology (Intel HT Technology) that allows an execution core to function as two logical processors. While some execution resources, such as caches, execution units, and buses are shared, each logical processor has its own architectural state with its own set of general-purpose registers and control registers. This feature must be enabled using the BIOS and requires operating system support.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 45

Processor—Technologies

Intel recommends enabling Intel HT Technology with Microsoft Windows* 8 and Microsoft Windows* 7 and disabling Intel HT Technology using the BIOS for all previous versions of Windows* operating systems. For more information on Intel HT Technology, see http://www.intel.com/technology/platform-technology/hyper-

threading/.

3.4

Intel® Turbo Boost Technology 2.0

The Intel Turbo Boost Technology 2.0 allows the processor core to opportunistically and automatically run faster than its rated operating frequency/render clock, if it is operating below power, temperature, and current limits. The Intel Turbo Boost Technology 2.0 feature is designed to increase performance of both multi-threaded and single-threaded workloads.

The processor supports a Turbo mode in which the processor can use the thermal capacity associated with the package and run at power levels higher than TDP power for short durations. This improves the system responsiveness for short, bursty usage conditions. The turbo feature needs to be properly enabled by BIOS for the processor to operate with maximum performance. Since the turbo feature is configurable and dependent on many platform design limits outside of the processor control, the maximum performance cannot be ensured.

Turbo Mode availability is independent of the number of active cores; however, the Turbo Mode frequency is dynamic and dependent on the instantaneous application power load, the number of active cores, user configurable settings, operating environment, and system design.

Compared with previous generation products, Intel Turbo Boost Technology 2.0 will increase the ratio of application power to TDP. Thus, thermal solutions and platform cooling that are designed to less than thermal design guidance might experience thermal and performance issues since more applications will tend to run at the maximum power limit for significant periods of time.

Note: Intel Turbo Boost Technology 2.0 may not be available on all SKUs.

Intel® Turbo Boost Technology 2.0 Frequency

The processor rated frequency assumes that all execution cores are active and are at the sustained thermal design power (TDP). However, under typical operation not all cores are active or at executing a high power workload. Therefore, most applications are consuming less than the TDP at the rated frequency. Intel Turbo Boost Technology

2.0 takes advantage of the available TDP headroom and active cores are able to increase their operating frequency.

To determine the highest performance frequency amongst active cores, the processor takes the following into consideration to recalculate turbo frequency during runtime:

• The number of cores operating in the C0 state.

• The estimated core current consumption.

• The estimated package prior and present power consumption.

• The package temperature.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 46 Order No.: 328901-007

Technologies—Processor

Any of these factors can affect the maximum frequency for a given workload. If the power, current, or thermal limit is reached, the processor will automatically reduce the frequency to stay within its TDP limit. Turbo processor frequencies are only active if the operating system is requesting the P0 state. For more information on P-states and C-states, see Power Management on page 51.

3.5

3.6

Intel® Advanced Vector Extensions 2.0 (Intel® AVX2)

Intel Advanced Vector Extensions 2.0 (Intel AVX2) is the latest expansion of the Intel instruction set. Intel AVX2 extends the Intel Advanced Vector Extensions (Intel AVX) with 256-bit integer instructions, floating-point fused multiply add (FMA) instructions, and gather operations. The 256-bit integer vectors benefit math, codec, image, and digital signal processing software. FMA improves performance in face detection, professional imaging, and high performance computing. Gather operations increase vectorization opportunities for many applications. In addition to the vector extensions, this generation of Intel processors adds new bit manipulation instructions useful in compression, encryption, and general purpose software.

For more information on Intel AVX, see http://www.intel.com/software/avx

Intel® Advanced Encryption Standard New Instructions (Intel® AES-NI)

The processor supports Intel Advanced Encryption Standard New Instructions (Intel AES-NI) that are a set of Single Instruction Multiple Data (SIMD) instructions that enable fast and secure data encryption and decryption based on the Advanced Encryption Standard (AES). Intel AES-NI are valuable for a wide range of cryptographic applications, such as applications that perform bulk encryption/ decryption, authentication, random number generation, and authenticated encryption. AES is broadly accepted as the standard for both government and industry applications, and is widely deployed in various protocols.

Intel AES-NI consists of six Intel SSE instructions. Four instructions, AESENC, AESENCLAST, AESDEC, and AESDELAST facilitate high performance AES encryption and decryption. The other two, AESIMC and AESKEYGENASSIST, support the AES key expansion procedure. Together, these instructions provide a full hardware for supporting AES; offering security, high performance, and a great deal of flexibility.

PCLMULQDQ Instruction

The processor supports the carry-less multiplication instruction, PCLMULQDQ. PCLMULQDQ is a Single Instruction Multiple Data (SIMD) instruction that computes the 128-bit carry-less multiplication of two, 64-bit operands without generating and propagating carries. Carry-less multiplication is an essential processing component of several cryptographic systems and standards. Hence, accelerating carry-less multiplication can significantly contribute to achieving high speed secure computing and communication.

Intel® Secure Key

The processor supports Intel® Secure Key (formerly known as Digital Random Number Generator (DRNG)), a software visible random number generation mechanism supported by a high quality entropy source. This capability is available to

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 47

Processor—Technologies

programmers through the RDRAND instruction. The resultant random number generation capability is designed to comply with existing industry standards in this regard (ANSI X9.82 and NIST SP 800-90).

Some possible usages of the RDRAND instruction include cryptographic key generation as used in a variety of applications, including communication, digital signatures, secure storage, and so on.

3.7

3.8

Intel® Transactional Synchronization Extensions - New Instructions (Intel® TSX-NI)

Intel Transactional Synchronization Extensions - New Instructions (Intel TSX-NI). Intel TSX-NI provides a set of instruction extensions that allow programmers to specify regions of code for transactional synchronization. Programmers can use these extensions to achieve the performance of fine-grain locking while actually programming using coarse-grain locks. Details on Intel TSX-NI are in the Intel

Architecture Instruction Set Extensions Programming Reference.

Intel® 64 Architecture x2APIC

The x2APIC architecture extends the xAPIC architecture that provides key mechanisms for interrupt delivery. This extension is primarily intended to increase processor addressability.

Specifically, x2APIC:

• Retains all key elements of compatibility to the xAPIC architecture:

— Delivery modes

— Interrupt and processor priorities

— Interrupt sources

— Interrupt destination types

• Provides extensions to scale processor addressability for both the logical and physical destination modes

• Adds new features to enhance performance of interrupt delivery

• Reduces complexity of logical destination mode interrupt delivery on link based architectures

The key enhancements provided by the x2APIC architecture over xAPIC are the following:

• Support for two modes of operation to provide backward compatibility and extensibility for future platform innovations:

— In xAPIC compatibility mode, APIC registers are accessed through memory

mapped interface to a 4K-Byte page, identical to the xAPIC architecture.

— In x2APIC mode, APIC registers are accessed through Model Specific Register

(MSR) interfaces. In this mode, the x2APIC architecture provides significantly increased processor addressability and some enhancements on interrupt delivery.

• Increased range of processor addressability in x2APIC mode:

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 48 Order No.: 328901-007

Technologies—Processor

— Physical xAPIC ID field increases from 8 bits to 32 bits, allowing for interrupt

— Logical xAPIC ID field increases from 8 bits to 32 bits. The 32-bit logical

• More efficient MSR interface to access APIC registers:

— To enhance inter-processor and self-directed interrupt delivery as well as the

• The semantics for accessing APIC registers have been revised to simplify the programming of frequently-used APIC registers by system software. Specifically, the software semantics for using the Interrupt Command Register (ICR) and End Of Interrupt (EOI) registers have been modified to allow for more efficient delivery and dispatching of interrupts.

• The x2APIC extensions are made available to system software by enabling the local x2APIC unit in the “x2APIC” mode. To benefit from x2APIC capabilities, a new operating system and a new BIOS are both needed, with special support for x2APIC mode.

• The x2APIC architecture provides backward compatibility to the xAPIC architecture and forward extendible for future Intel platform innovations.

processor addressability up to 4G–1 processors in physical destination mode. A processor implementation of x2APIC architecture can support fewer than 32bits in a software transparent fashion.

x2APIC ID is partitioned into two sub-fields – a 16-bit cluster ID and a 16-bit logical ID within the cluster. Consequently, ((2^20) – 16) processors can be addressed in logical destination mode. Processor implementations can support fewer than 16 bits in the cluster ID sub-field and logical ID sub-field in a software agnostic fashion.

ability to virtualize the local APIC, the APIC register set can be accessed only through MSR-based interfaces in x2APIC mode. The Memory Mapped IO (MMIO) interface used by xAPIC is not supported in x2APIC mode.

Note: Intel x2APIC Technology may not be available on all SKUs.

For more information, see the Intel® 64 Architecture x2APIC Specification at http://

www.intel.com/products/processor/manuals/.

3.9

Power Aware Interrupt Routing (PAIR)

The processor includes enhanced power-performance technology that routes interrupts to threads or cores based on their sleep states. As an example, for energy savings, it routes the interrupt to the active cores without waking the deep idle cores. For performance, it routes the interrupt to the idle (C1) cores without interrupting the already heavily loaded cores. This enhancement is mostly beneficial for high-interrupt scenarios like Gigabit LAN, WLAN peripherals, and so on.

3.10

Execute Disable Bit

The Execute Disable Bit allows memory to be marked as executable when combined with a supporting operating system. If code attempts to run in non-executable memory, the processor raises an error to the operating system. This feature can prevent some classes of viruses or worms that exploit buffer overrun vulnerabilities and can thus help improve the overall security of the system. See the Intel® 64 and IA-32 Architectures Software Developer's Manuals for more detailed information.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 49

Processor—Technologies

3.11

Supervisor Mode Execution Protection (SMEP)

Supervisor Mode Execution Protection provides the next level of system protection by blocking malicious software attacks from user mode code when the system is running in the highest privilege level. This technology helps to protect from virus attacks and unwanted code from harming the system. For more information, refer to Intel® 64 and IA-32 Architectures Software Developer's Manual, Volume 3A at: http://

www.intel.com/Assets/PDF/manual/253668.pdf

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 50 Order No.: 328901-007

G0 - Working

S0 – Processor Fully powered on (full on mode / connected standby mode)

C0 – Active mode

C1 – Auto Halt

C1E – Auto Halt, Low freq, low voltage

C3 – L1/L2 caches flush, clocks off

C6 – Save core states before shutdown

C7 – Similar to C6, L3 flush

G1 – Sleeping

Note: Power states availability may vary between the different SKUs

S3 Cold – Sleep – Suspend to Ram (STR)

S4 – Hibernate – Suspend to Disk (STD), Wakeup on PCH

S5 – Soft Off – no power, Wakeup on PCH

G3 – Mechanical OFF

Power Management—Processor

4.0 Power Management

This chapter provides information on the following power management topics:

• Advanced Configuration and Power Interface (ACPI) States

• Processor Core

• Integrated Memory Controller (IMC)

• PCI Express*

• Direct Media Interface (DMI)

• Processor Graphics Controller

Figure 11. Processor Power States

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 51

Processor Family

Processor—Power Management

4.1

Advanced Configuration and Power Interface (ACPI) States Supported

This section describes the ACPI states supported by the processor.

Table 11. System States

State Description

G0/S0 Full On Mode, Display On.

G0/S0 Connected Standby Mode, Display Off.

G1/S3-Cold

G1/S4 Suspend-to-Disk (STD). All power lost (except wakeup on PCH).

G2/S5 Soft off. All power lost (except wakeup on PCH). Total reboot.

G3 Mechanical off. All power (AC and battery) removed from system.

Table 12. Processor Core / Package State Support

State Description

C0 Active mode, processor executing code.

C1 AutoHALT state.

C1E AutoHALT state with lowest frequency and voltage operating point.

C6 Execution cores in this state save their architectural state before removing core voltage.

Suspend-to-RAM (STR). Context saved to memory (S3-Hot state is not supported by the processor).

Execution cores in C3 state flush their L1 instruction cache, L1 data cache, and L2 cache to the L3 shared cache. Clocks are shut off to each core.

Execution cores in this state behave similarly to the C6 state. If all execution cores request C7 state, L3 cache ways are flushed until it is cleared. If the entire L3 cache is flushed, voltage will be removed from the L3 cache. Power removal to SA, Cores and L3 will reduce power consumption.

Table 13. Integrated Memory Controller States

State Description

Power up CKE asserted. Active mode.

Pre-charge

Power-down

Active Power-

down

Self-Refresh CKE de-asserted using device self-refresh.

CKE de-asserted (not self-refresh) with all banks closed.

CKE de-asserted (not self-refresh) with minimum one bank active.

Table 14. PCI Express* Link States

State Description

L0 Full on – Active transfer state.

L0s First Active Power Management low-power state – Low exit latency.

L1 Lowest Active Power Management – Longer exit latency.

L3 Lowest power state (power-off) – Longest exit latency.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 52 Order No.: 328901-007

Power Management—Processor

Table 15. Direct Media Interface (DMI) States

State Description

L0 Full on – Active transfer state.

L0s First Active Power Management low-power state – Low exit latency.

L1 Lowest Active Power Management – Longer exit latency.

L3 Lowest power state (power-off) – Longest exit latency.

Table 16. G, S, and C Interface State Combinations

Global

(G)

State

G0 S0 C0 Full On On Full On

G0 S0 C1/C1E Auto-Halt On Auto-Halt

G0 S0 C3 Deep Sleep On Deep Sleep

G0 S0 C6/C7

G1 S3 Power off Off, except RTC Suspend to RAM

G1 S4 Power off Off, except RTC Suspend to Disk

G2 S5 Power off Off, except RTC Soft Off

G3 NA Power off Power off Hard off

Sleep (S)

State

Processor

Package (C)

State

Deep Power-

Table 17. D, S, and C Interface State Combination

Graphics

Adapter (D)

State

D0 S0 C0 Full On, Displaying.

D0 S0 C1/C1E Auto-Halt, Displaying.

D0 S0 C3 Deep sleep, Displaying.

D0 S0 C6/C7 Deep Power-down, Displaying.

D3 S0 Any Not displaying.

D3 S3 N/A Not displaying, Graphics Core is powered off.

D3 S4 N/A Not displaying, suspend to disk.

Sleep (S)

State

Package (C)

State

Processor

State

down

System Clocks Description

On Deep Power-down

Description

4.2

Processor Core Power Management

While executing code, Enhanced Intel SpeedStep® Technology optimizes the processor’s frequency and core voltage based on workload. Each frequency and voltage operating point is defined by ACPI as a P-state. When the processor is not executing code, it is idle. A low-power idle state is defined by ACPI as a C-state. In general, deeper power C-states have longer entry and exit latencies.

4.2.1

Enhanced Intel® SpeedStep® Technology Key Features

The following are the key features of Enhanced Intel SpeedStep Technology:

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 53

Processor Family

Thread 0 Thread 1

Core 0 State

Thread 0 Thread 1

Core N State

Processor Package State

Processor—Power Management

• Multiple frequency and voltage points for optimal performance and power efficiency. These operating points are known as P-states.

• Frequency selection is software controlled by writing to processor MSRs. The voltage is optimized based on the selected frequency and the number of active processor cores.

— Once the voltage is established, the PLL locks on to the target frequency.

— All active processor cores share the same frequency and voltage. In a multi-

core processor, the highest frequency P-state requested among all active cores is selected.

— Software-requested transitions are accepted at any time. If a previous

transition is in progress, the new transition is deferred until the previous transition is completed.

• The processor controls voltage ramp rates internally to ensure glitch-free transitions.

• Because there is low transition latency between P-states, a significant number of transitions per-second are possible.

4.2.2

Low-Power Idle States

When the processor is idle, low-power idle states (C-states) are used to save power. More power savings actions are taken for numerically higher C-states. However, higher C-states have longer exit and entry latencies. Resolution of C-states occur at the thread, processor core, and processor package level. Thread-level C-states are available if Intel Hyper-Threading Technology is enabled.

Caution: Long term reliability cannot be assured unless all the Low-Power Idle States are

enabled.

Figure 12. Idle Power Management Breakdown of the Processor Cores

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 54 Order No.: 328901-007

Entry and exit of the C-states at the thread and core level are shown in the following figure.

C1 C1E C7C6C3

MWAIT(C1), HLT

MWAIT(C7),

P_LV L4 I/O R ead

MWAIT(C6),

P_LV L3 I/O R ead

MWAIT(C3),

P_LV L2 I/O R ead

MWAIT (C1), HL T

(C1E Enabled)

Power Management—Processor

Figure 13. Thread and Core C-State Entry and Exit

While individual threads can request low-power C-states, power saving actions only take place once the core C-state is resolved. Core C-states are automatically resolved by the processor. For thread and core C-states, a transition to and from C0 is required before entering any other C-state.

Table 18. Coordination of Thread Power States at the Core Level

Processor Core C-State Thread 1

Thread 0

Note: 1. If enabled, the core C-state will be C1E if all cores have resolved a core C1 state or higher.

4.2.3

Requesting Low-Power Idle States

The primary software interfaces for requesting low-power idle states are through the MWAIT instruction with sub-state hints and the HLT instruction (for C1 and C1E). However, software may make C-state requests using the legacy method of I/O reads from the ACPI-defined processor clock control registers, referred to as P_LVLx. This method of requesting C-states provides legacy support for operating systems that initiate C-state transitions using I/O reads.

For legacy operating systems, P_LVLx I/O reads are converted within the processor to the equivalent MWAIT C-state request. Therefore, P_LVLx reads do not directly result in I/O reads to the system. The feature, known as I/O MWAIT redirection, must be enabled in the BIOS.

The BIOS can write to the C-state range field of the PMG_IO_CAPTURE MSR to restrict the range of I/O addresses that are trapped and emulate MWAIT like functionality. Any P_LVLx reads outside of this range do not cause an I/O redirection to MWAIT(Cx)

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 55

like request. The reads fall through like a normal I/O instruction.

C0 C1 C3 C6 C7

C0 C0 C0 C0 C0 C0

C1 C0 C1

C3 C0 C1

C6 C0 C1

C7 C0 C1

C3 C3 C3

C3 C6 C6

C3 C6 C7

Processor Family

Processor—Power Management

Note: When P_LVLx I/O instructions are used, MWAIT sub-states cannot be defined. The

MWAIT sub-state is always zero if I/O MWAIT redirection is used. By default, P_LVLx I/O redirections enable the MWAIT 'break on EFLAGS.IF’ feature that triggers a wakeup on an interrupt, even if interrupts are masked by EFLAGS.IF.

4.2.4

Core C-State Rules

The following are general rules for all core C-states, unless specified otherwise:

• A core C-state is determined by the lowest numerical thread state (such as Thread 0 requests C1E state while Thread 1 requests C3 state, resulting in a core C1E state). See the G, S, and C Interface State Combinations table.

• A core transitions to C0 state when:

— An interrupt occurs

— There is an access to the monitored address if the state was entered using an

MWAIT/Timed MWAIT instruction

— The deadline corresponding to the Timed MWAIT instruction expires

• An interrupt directed toward a single thread wakes only that thread.

• If any thread in a core is in active (in C0 state), the core's C-state will resolve to C0 state.

• Any interrupt coming into the processor package may wake any core.

• A system reset re-initializes all processor cores.

Core C0 State

The normal operating state of a core where code is being executed.

Core C1/C1E State

C1/C1E is a low power state entered when all threads within a core execute a HLT or MWAIT(C1/C1E) instruction.

A System Management Interrupt (SMI) handler returns execution to either Normal state or the C1/C1E state. See the Intel® 64 and IA-32 Architectures Software Developer’s Manual for more information.

While a core is in C1/C1E state, it processes bus snoops and snoops from other threads. For more information on C1E state, see Package C-States on page 57.

Core C3 State

Individual threads of a core can enter the C3 state by initiating a P_LVL2 I/O read to the P_BLK or an MWAIT(C3) instruction. A core in C3 state flushes the contents of its L1 instruction cache, L1 data cache, and L2 cache to the shared L3 cache, while maintaining its architectural state. All core clocks are stopped at this point. Because the core’s caches are flushed, the processor does not wake any core that is in the C3 state when either a snoop is detected or when another core accesses cacheable memory.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 56 Order No.: 328901-007

Power Management—Processor

Core C6 State

Individual threads of a core can enter the C6 state by initiating a P_LVL3 I/O read or an MWAIT(C6) instruction. Before entering core C6 state, the core will save its architectural state to a dedicated SRAM. Once complete, a core will have its voltage reduced to zero volts. During exit, the core is powered on and its architectural state is restored.

Core C7 State

Individual threads of a core can enter the C7 state by initiating a P_LVL4 I/O read to the P_BLK or by an MWAIT(C7) instruction. The core C7 state exhibits the same behavior as the core C6 state.

C-State Auto-Demotion

In general, deeper C-states, such as C6 or C7 state, have long latencies and have higher energy entry/exit costs. The resulting performance and energy penalties become significant when the entry/exit frequency of a deeper C-state is high. Therefore, incorrect or inefficient usage of deeper C-states have a negative impact on battery life and idle power. To increase residency and improve battery life and idle power in deeper C-states, the processor supports C-state auto-demotion.

There are two C-state auto-demotion options:

• C7/C6 to C3 state

• C7/C6/C3 To C1 state

4.2.5

The decision to demote a core from C6/C7 to C3 or C3/C6/C7 to C1 state is based on each core’s immediate residency history and interrupt rate . If the interrupt rate experienced on a core is high and the residence in a deep C-state between such interrupts is low, the core can be demoted to a C3 or C1 state. A higher interrupt pattern is required to demote a core to C1 state as compared to C3 state.

This feature is disabled by default. BIOS must enable it in the PMG_CST_CONFIG_CONTROL register. The auto-demotion policy is also configured by this register.

Package C-States

The processor supports C0, C1/C1E, C3, C6, and C7 power states.The following is a summary of the general rules for package C-state entry. These apply to all package Cstates, unless specified otherwise:

• A package C-state request is determined by the lowest numerical core C-state amongst all cores.

• A package C-state is automatically resolved by the processor depending on the core idle power states and the status of the platform components.

— Each core can be at a lower idle power state than the package if the platform

does not grant the processor permission to enter a requested package C-state.

— The platform may allow additional power savings to be realized in the

processor.

— For package C-states, the processor is not required to enter C0 state before

entering any other C-state.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 57

Processor—Power Management

— Entry into a package C-state may be subject to auto-demotion – that is, the

processor may keep the package in a deeper package C-state than requested by the operating system if the processor determines, using heuristics, that the deeper C-state results in better power/performance.

The processor exits a package C-state when a break event is detected. Depending on the type of break event, the processor does the following:

• If a core break event is received, the target core is activated and the break event message is forwarded to the target core.

— If the break event is not masked, the target core enters the core C0 state and

the processor enters package C0 state.

— If the break event is masked, the processor attempts to re-enter its previous

package state.

• If the break event was due to a memory access or snoop request,

— But the platform did not request to keep the processor in a higher package C-

state, the package returns to its previous C-state.

— And the platform requests a higher power C-state, the memory access or

snoop request is serviced and the package remains in the higher power Cstate.

The following table shows package C-state resolution for a dual-core processor. The following figure summarizes package C-state transitions.

Table 19. Coordination of Core Power States at the Package Level

Package C-State Core 1

C0 C1 C3 C6 C7

C0 C0 C0 C0 C0 C0

C1 C0 C1

Core 0

Note: 1. If enabled, the package C-state will be C1E if all cores have resolved a core C1 state or higher.

C3 C0 C1

C6 C0 C1

C7 C0 C1

C3 C3 C3

C3 C6 C6

C3 C6 C7

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 58 Order No.: 328901-007

Power Management—Processor

Figure 14. Package C-State Entry and Exit

Package C0 State

This is the normal operating state for the processor. The processor remains in the normal state when at least one of its cores is in the C0 or C1 state or when the platform has not granted permission to the processor to go into a low-power state. Individual cores may be in lower power idle states while the package is in C0 state.

Package C1/C1E State

No additional power reduction actions are taken in the package C1 state. However, if the C1E sub-state is enabled, the processor automatically transitions to the lowest supported core clock frequency, followed by a reduction in voltage.

The package enters the C1 low-power state when:

• At least one core is in the C1 state.

• The other cores are in a C1 or deeper power state.

The package enters the C1E state when:

• All cores have directly requested C1E using MWAIT(C1) with a C1E sub-state hint.

• All cores are in a power state deeper than C1/C1E state; however, the package low-power state is limited to C1/C1E using the PMG_CST_CONFIG_CONTROL MSR.

• All cores have requested C1 state using HLT or MWAIT(C1) and C1E autopromotion is enabled in IA32_MISC_ENABLES.

No notification to the system occurs upon entry to C1/C1E state.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 59

Processor—Power Management

Package C2 State

Package C2 state is an internal processor state that cannot be explicitly requested by software. A processor enters Package C2 state when:

• All cores and graphics have requested a C3 or deeper power state; however, constraints (LTR, programmed timer events in the near future, and so on) prevent entry to any state deeper than C 2 state. Or,

• All cores and graphics are in the C3 or deeper power states, and a memory access request is received. Upon completion of all outstanding memory requests, the processor transitions back into a deeper package C-state.

Package C3 State

A processor enters the package C3 low-power state when:

• At least one core is in the C3 state.

• The other cores are in a C3 state or deeper power state and the processor has been granted permission by the platform.

• The platform has not granted a request to a package C6/C7 or deeper state, however, has allowed a package C6 state.

In package C3 state, the L3 shared cache is valid.

Package C6 State

A processor enters the package C6 low-power state when:

• At least one core is in the C6 state.

• The other cores are in a C6 or deeper power state and the processor has been granted permission by the platform.

• The platform has not granted a package C7 state or deeper request; however, has allowed a package C6 state.

• If the cores are requesting C7 state, but the platform is limiting to a package C6 state, the last level cache in this case can be flushed.

In package C6 state all cores have saved their architectural state and have had their core voltages reduced to zero volts. It is possible the L3 shared cache is flushed and turned off in package C6 state. If at least one core is requesting C6 state, the L3 cache will not be flushed.

Package C7 State

The processor enters the package C7 low-power state when all cores are in the C7 state. In package C7, the processor will take action to remove power from portions of the system agent.

Core break events are handled the same way as in package C3 or C6 state.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 60 Order No.: 328901-007

Power Management—Processor

Note: Package C6 state is the deepest C-state supported on discrete graphics systems with

PCI Express Graphics (PEG).

Package C7 state is the deepest C-state supported on integrated graphics systems (or switchable graphics systems during integrated graphics mode). However, in most configurations, package C6 will be more energy efficient than package C7 state. As a result, package C7 state residency is expected to be very low or zero in most scenarios where the display is enabled. Logic internal to the processor will determine whether package C6 or package C7 state is the most efficient. There is no need to make changes in BIOS or system software to prioritize package C6 state over package C7 state.

Dynamic L3 Cache Sizing

When all cores request C7 or deeper C-state, internal heuristics is dynamically flushes the L3 cache. Once the cores enter a deep C-state, depending on their MWAIT substate request, the L3 cache is either gradually flushed N-ways at a time or flushed all at once. Upon the cores exiting to C0, the L3 cache is gradually expanded based on internal heuristics.

4.2.6

Package C-States and Display Resolutions

The integrated graphics engine has the frame buffer located in system memory. When the display is updated, the graphics engine fetches display data from system memory. Different screen resolutions and refresh rates have different memory latency requirements. These requirements may limit the deepest Package C-state the processor can enter. Other elements that may affect the deepest Package C-state available are the following:

• Display is on or off

• Single or multiple displays

• Native or non-native resolution

• Panel Self Refresh (PSR) technology

Note: Display resolution is not the only factor influencing the deepest Package C-state the

processor can get into. Device latencies, interrupt response latencies, and core Cstates are among other factors that influence the final package C-state the processor can enter.

The following table lists display resolutions and deepest available package C-State. The display resolutions are examples using common values for blanking and pixel rate. Actual results will vary. The table shows the deepest possible Package C-state. System workload, system idle, and AC or DC power also affect the deepest possible Package C-state.

Table 20. Deepest Package C-State Available – M-Processor Line

Panel Self Refresh

(PSR)

Disabled Single 800x600 60 Hz PC6

Disabled Single 1024x768 60 Hz PC6

Disabled Single 1280x1024 60 Hz PC6

Number of Displays

Native Resolution

Deepest Available

Package C-State

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 61

Processor—Power Management

Panel Self Refresh

Number of Displays

Native Resolution

(PSR)

Disabled Single 1920x1080 60 Hz PC6

Disabled Single 1920x1200 60 Hz PC6

Disabled Single 1920x1440 60 Hz PC6

Disabled Single 2048x1536 60 Hz PC6

Disabled Single 2560x1600 60 Hz PC6

Disabled Single 2560x1920 60 Hz PC3

Disabled Single 2880x1620 60 Hz PC3

Disabled Single 2880x1800 60 Hz PC3

Disabled Single 3200x1800 60 Hz PC3

Disabled Single 3200x2000 60 Hz PC3

Disabled Single 3840x2160 60 Hz PC3

Disabled Single 3840x2160 30 Hz PC3

Disabled Single 4096x2160 24 Hz PC3

Disabled Multiple 800x600 60 Hz PC6

Disabled Multiple 1024x768 60 Hz PC6

Disabled Multiple 1280x1024 60 Hz PC6

Disabled Multiple 1920x1080 60 Hz PC3

Disabled Multiple 1920x1200 60 Hz PC3

Disabled Multiple 1920x1440 60 Hz PC3

Disabled Multiple 2048x1536 60 Hz PC3

Disabled Multiple 2560x1600 60 Hz PC2

Disabled Multiple 2560x1920 60 Hz PC2

Disabled Multiple 2880x1620 60 Hz PC2

Disabled Multiple 2880x1800 60 Hz PC2

Disabled Multiple 3200x1800 60 Hz PC2

Disabled Multiple 3200x2000 60 Hz PC2

Disabled Multiple 3840x2160 60 Hz PC2

Disabled Multiple 3840x2160 30 Hz PC2

Disabled Multiple 4096x2160 24 Hz PC2

Deepest Available

Package C-State

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family Datasheet – Volume 1 of 2 July 2014 62 Order No.: 328901-007

Power Management—Processor

4.3

4.3.1

Panel Self Refresh

(PSR)

Enabled Single Any native resolution

Enabled Multiple Any native resolution

Notes: 1. For multiple display cases, the resolution listed is the highest native resolution of all enabled

displays, and PSR is internally disabled; that is, dual display with one 800x600 60 Hz display and one 2560x1600 60 Hz display will result in a deepest available package C-state of PC2.

2. For non-native resolutions, PSR is internally disabled, and the deepest available package C-State will be between that of the PSR disabled native resolution and the PSR disabled non-native resolution; that is, a native 3200x1800 60 Hz panel using non-native 1920x1080 60 Hz resolution will result in a deepest available package C-State between PC3 and PC6.

3. Microcode Update Revision 00000010 or newer must be used.

Number of Displays

Native Resolution

Deepest Available

Package C-State

Same as PSR disabled for

the given resolution with

PC7

multiple displays

Integrated Memory Controller (IMC) Power Management

The main memory is power managed during normal operation and in low-power ACPI Cx states.

Disabling Unused System Memory Outputs

Any system memory (SM) interface signal that goes to a memory module connector in which it is not connected to any actual memory devices (such as SO-DIMM connector is unpopulated, or is single-sided) is tri-stated. The benefits of disabling unused SM signals are:

• Reduced power consumption.

• Reduced possible overshoot/undershoot signal quality issues seen by the processor I/O buffer receivers caused by reflections from potentially unterminated transmission lines.

When a given rank is not populated, the corresponding chip select and CKE signals are not driven.

At reset, all rows must be assumed to be populated, until it can be determined that the rows are not populated. This is due to the fact that when CKE is tri-stated with an SO-DIMM present, the SO-DIMM is not ensured to maintain data integrity.

CKE tristate should be enabled by BIOS where appropriate, since at reset all rows must be assumed to be populated.

4.3.2

DRAM Power Management and Initialization

The processor implements extensive support for power management on the SDRAM interface. There are four SDRAM operations associated with the Clock Enable (CKE) signals, which the SDRAM controller supports. The processor drives four CKE pins to perform these operations.

The CKE is one of the power-save means. When CKE is off, the internal DDR clock is disabled and the DDR power is reduced. The power-saving differs according to the selected mode and the DDR type used. For more information, refer to the IDD table in the DDR specification.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 63

Processor Family

Processor—Power Management

The processor supports three different types of power-down modes in package C0. The different power-down modes can be enabled through configuring "PM_PDWN_config_0_0_0_MCHBAR". The type of CKE power-down can be configured through PDWN_mode (bits 15:12) and the idle timer can be configured through PDWN_idle_counter (bits 11:0). The different power-down modes supported are:

• No power-down (CKE disable)

• Active power-down (APD): This mode is entered if there are open pages when de-asserting CKE. In this mode the open pages are retained. Power-saving in this mode is the lowest. Power consumption of DDR is defined by IDD3P. Exiting this mode is defined by tXP – small number of cycles. For this mode, DRAM DLL must be on.

• PPD/DLL-off: In this mode the data-in DLLs on DDR are off. Power-saving in this mode is the best among all power modes. Power consumption is defined by IDD2P1. Exiting this mode is defined by tXP, but also tXPDLL (10–20 according to DDR type) cycles until first data transfer is allowed. For this mode, DRAM DLL must be off.

The CKE is determined per rank, whenever it is inactive. Each rank has an idlecounter. The idle-counter starts counting as soon as the rank has no accesses, and if it expires, the rank may enter power-down while no new transactions to the rank arrives to queues. The idle-counter begins counting at the last incoming transaction arrival.

It is important to understand that since the power-down decision is per rank, the IMC can find many opportunities to power down ranks, even while running memory intensive applications; the savings are significant (may be few Watts, according to the DDR specification). This is significant when each channel is populated with more ranks.

Selection of power modes should be according to power-performance or thermal trade-offs of a given system:

• When trying to achieve maximum performance and power or thermal consideration is not an issue – use no power-down

• In a system which tries to minimize power-consumption, try using the deepest power-down mode possible – PPD/DLL-off with a low idle timer value

• In high-performance systems with dense packaging (that is, tricky thermal design) the power-down mode should be considered in order to reduce the heating and avoid DDR throttling caused by the heating.

The default value that BIOS configures in "PM_PDWN_config_0_0_0_MCHBAR" is 6080h – that is, PPD/DLL-off mode with idle timer of 80h, or 128 DCLKs. This is a balanced setting with deep power-down mode and moderate idle timer value.

The idle timer expiration count defines the # of DCKLs that a rank is idle that causes entry to the selected powermode. As this timer is set to a shorter time, the IMC will have more opportunities to put DDR in power-down. There is no BIOS hook to set this register. Customers choosing to change the value of this register can do it by changing it in the BIOS. For experiments, this register can be modified in real time if BIOS does not lock the IMC registers.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 64 Order No.: 328901-007

Power Management—Processor

4.3.2.1

Initialization Role of CKE

During power-up, CKE is the only input to the SDRAM that has its level recognized (other than the DDR3L/DDR3L-RS reset pin) once power is applied. It must be driven LOW by the DDR controller to make sure the SDRAM components float DQ and DQS during power-up. CKE signals remain LOW (while any reset is active) until the BIOS writes to a configuration register. Using this method, CKE is ensured to remain inactive for much longer than the specified 200 micro-seconds after power and clocks to SDRAM devices are stable.

4.3.2.2

Conditional Self-Refresh

During S0 idle state, system memory may be conditionally placed into self-refresh state when the processor is in package C3 or deeper power state. Refer to Intel

Rapid Memory Power Management (Intel® RMPM) for more details on conditional self-

refresh with Intel HD Graphics enabled.

When entering the S3 – Suspend-to-RAM (STR) state or S0 conditional self-refresh, the processor core flushes pending cycles and then enters SDRAM ranks that are not used by Intel graphics memory into self-refresh. The CKE signals remain LOW so the SDRAM devices perform self-refresh.

The target behavior is to enter self-refresh for package C3 or deeper power states as long as there are no memory requests to service. The target usage is shown in the following table.

Table 21. Targeted Memory State Conditions

4.3.2.3

Mode Memory State with Processor Graphics Memory State with External Graphics

C0, C1, C1E

C3, C6, C7

S3 Self-Refresh Mode Self-Refresh Mode

S4 Memory power-down (contents lost) Memory power-down (contents lost)

Dynamic memory rank power-down based on idle conditions.

If the processor graphics engine is idle and there are no pending display requests, then enter self-refresh. Otherwise, use dynamic memory rank power-down based on idle conditions.

Dynamic memory rank power-down based on idle conditions.

If there are no memory requests, then enter self-refresh. Otherwise, use dynamic memory rank power-down based on idle conditions.

Dynamic Power-Down

Dynamic power-down of memory is employed during normal operation. Based on idle conditions, a given memory rank may be powered down. The IMC implements aggressive CKE control to dynamically put the DRAM devices in a power-down state. The processor core controller can be configured to put the devices in active powerdown (CKE de-assertion with open pages) or pre-charge power-down (CKE deassertion with all pages closed). Pre-charge power-down provides greater power savings, but has a bigger performance impact since all pages will first be closed before putting the devices in power-down mode.

If dynamic power-down is enabled, all ranks are powered up before doing a refresh cycle and all ranks are powered down at the end of refresh.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 65

Processor—Power Management

4.3.2.4

4.3.3

4.3.4

DRAM I/O Power Management

Unused signals should be disabled to save power and reduce electromagnetic interference. This includes all signals associated with an unused memory channel. Clocks, CKE, ODE, and CS signals are controlled per DIMM rank and will be powered down for unused ranks.

The I/O buffer for an unused signal should be tri-stated (output driver disabled), the input receiver (differential sense-amp) should be disabled, and any DLL circuitry related ONLY to unused signals should be disabled. The input path must be gated to prevent spurious results due to noise on the unused signals (typically handled automatically when input receiver is disabled).

DRAM Running Average Power Limitation (RAPL)

RAPL is a power and time constant pair. DRAM RAPL defines an average power constraint for the DRAM domain. Constraint is controlled by the PCU. Platform entities (PECI or in-band power driver) can specify a power limit for the DRAM domain. PCU continuously monitors the extant of DRAM throttling due to the power limit and rebudgets the limit between DIMMs.

DDR Electrical Power Gating (EPG)

The DDR I/O of the processor supports Electrical Power Gating (DDR-EPG) while the processor is at C3 or deeper power state.

In C3 or deeper power state, the processor internally gates V the logic to reduce idle power while keeping all critical DDR pins such as SM_DRAMRST#, CKE and VREF in the appropriate state.

for the majority of

DDQ

4.4

4.5

4.6

4.6.1

In C7, the processor internally gates V power.

In S3 or C-state transitions, the DDR does not go through training mode and will restore the previous training information.

CCIO_TERM

for all non-critical state to reduce idle

PCI Express* Power Management

• Active power management is supported using L0s, and L1 states.

• All inputs and outputs disabled in L2/L3 Ready state.

Direct Media Interface (DMI) Power Management

Active power management is supported using L0s/L1 state.

Graphics Power Management

Intel® Rapid Memory Power Management (Intel® RMPM)

Intel Rapid Memory Power Management (Intel RMPM) conditionally places memory into self-refresh when the processor is in package C3 or deeper power state to allow the system to remain in the lower power states longer for memory not reserved for

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 66 Order No.: 328901-007

Power Management—Processor

graphics memory. Intel RMPM functionality depends on graphics/display state (relevant only when processor graphics is being used), as well as memory traffic patterns generated by other connected I/O devices.

4.6.2

4.6.3

4.6.4

Graphics Render C-State

Render C-state (RC6) is a technique designed to optimize the average power to the graphics render engine during times of idleness. RC6 is entered when the graphics render engine, blitter engine, and the video engine have no workload being currently worked on and no outstanding graphics memory transactions. When the idleness condition is met, the processor graphics will program the graphics render engine internal power rail into a low voltage state.

Intel® Smart 2D Display Technology (Intel® S2DDT)

Intel S2DDT reduces display refresh memory traffic by reducing memory reads required for display refresh. Power consumption is reduced by less accesses to the IMC. Intel S2DDT is only enabled in single pipe mode.

Intel S2DDT is most effective with:

• Display images well suited to compression, such as text windows, slide shows, and so on. Poor examples are 3D games.

• Static screens such as screens with significant portions of the background showing 2D applications, processor benchmarks, and so on, or conditions when the processor is idle. Poor examples are full-screen 3D games and benchmarks that flip the display image at or near display refresh rates.

Intel® Graphics Dynamic Frequency

Intel Graphics Dynamic Frequency Technology is the ability of the processor and graphics cores to opportunistically increase frequency and/or voltage above the guaranteed processor and graphics frequency for the given part. Intel Graphics Dynamic Frequency Technology is a performance feature that makes use of unused package power and thermals to increase application performance. The increase in frequency is determined by how much power and thermal budget is available in the package, and the application demand for additional processor or graphics performance. The processor core control is maintained by an embedded controller. The graphics driver dynamically adjusts between P-States to maintain optimal performance, power, and thermals. The graphics driver will always try to place the graphics engine in the most energy efficient P-state.

4.6.5

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 67

Intel® Display Power Saving Technology (Intel® DPST)

The Intel DPST technique achieves backlight power savings while maintaining a good visual experience. This is accomplished by adaptively enhancing the displayed image while decreasing the backlight brightness simultaneously. The goal of this technique is to provide equivalent end-user-perceived image quality at a decreased backlight power level.

1. The original (input) image produced by the operating system or application is analyzed by the Intel DPST subsystem. An interrupt to Intel DPST software is generated whenever a meaningful change in the image attributes is detected. (A

Processor Family

Processor—Power Management

meaningful change is when the Intel DPST software algorithm determines that enough brightness, contrast, or color change has occurred to the displaying images that the image enhancement and backlight control needs to be altered.)

2. Intel DPST subsystem applies an image-specific enhancement to increase image contrast, brightness, and other attributes.

3. A corresponding decrease to the backlight brightness is applied simultaneously to produce an image with similar user-perceived quality (such as brightness) as the original image.

Intel DPST 6.0 has improved the software algorithms and has minor hardware changes to better handle backlight phase-in and ensures the documented and validated method to interrupt hardware phase-in.

4.6.6

4.6.7

Intel® Automatic Display Brightness

The Intel Automatic Display Brightness feature dynamically adjusts the backlight brightness based upon the current ambient light environment. This feature requires an additional sensor to be on the panel front. The sensor receives the changing ambient light conditions and sends the interrupts to the Intel Graphics driver. As per the change in Lux, (current ambient light illuminance), the new backlight setting can be adjusted through BLC. The converse applies for a brightly lit environment. Intel Automatic Display Brightness increases the backlight setting.

Intel® Seamless Display Refresh Rate Technology (Intel

SDRRS Technology)

When a Local Flat Panel (LFP) supports multiple refresh rates, the Intel Display Refresh Rate Switching power conservation feature can be enabled. The higher refresh rate will be used when plugged in with an AC power adaptor or when the end user has not selected/enabled this feature. The graphics software will automatically switch to a lower refresh rate for maximum battery life when the notebook is on battery power and when the user has selected/enabled this feature. There are two distinct implementations of Intel DRRS – static and seamless. The static Intel DRRS method uses a mode change to assign the new refresh rate. The seamless Intel DRRS method is able to accomplish the refresh rate assignment without a mode change and therefore does not experience some of the visual artifacts associated with the mode change (SetMode) method.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 68 Order No.: 328901-007

Thermal Management—Processor

5.0 Thermal Management

The thermal solution provides both component-level and system-level thermal management. To allow for the optimal operation and long-term reliability of Intel processor-based systems, the system/processor thermal solution should be designed so that the processor:

• Remains below the maximum junction temperature (Tj maximum thermal design power (TDP).

• Conforms to system constraints, such as system acoustics, system skintemperatures, and exhaust-temperature requirements.

Caution: Thermal specifications given in this chapter are on the component and package level and apply specifically to the processor. Operating the processor outside the specified limits may result in permanent damage to the processor and potentially other components in the system.

) specification at the

Max

5.1

Thermal Considerations

The processor TDP is the maximum sustained power that should be used for design of the processor thermal solution. TDP represents an expected maximum sustained power from realistic applications. TDP may be exceeded for short periods of time or if running a "power virus" workload.

The processor integrates multiple processing and graphics cores on a single die.This may result in differences in the power distribution across the die and must be considered when designing the thermal solution.

Intel® Turbo Boost Technology 2.0 allows processor cores and processor graphics cores to run faster than the guaranteed frequency. It is invoked opportunistically and automatically as long as the processor is conforming to its temperature, power delivery, and current specification limits. When Intel Turbo Boost Technology 2.0 is enabled:

• Applications are expected to run closer to TDP more often as the processor will attempt to maximize performance by taking advantage of available TDP headroom in the processor package.

• The processor may exceed the TDP for short durations to use any available thermal capacitance within the thermal solution. The duration and time of such operation can be limited by platform runtime configurable registers within the processor.

• Thermal solutions and platform cooling that are designed to less than thermal design guidance may experience thermal and performance issues since more applications will tend to run at or near TDP for significant periods of time.

Note:

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 69

Intel Turbo Boost Technology 2.0 availability may vary between the different SKUs.

Processor Family

Processor—Thermal Management

5.2

Intel® Turbo Boost Technology 2.0 Power Monitoring

When operating in turbo mode, the processor monitors its own power and adjusts the turbo frequencies to maintain the average power within limits over a thermally significant time period. The processor calculates the package power that consists of the processor core power and graphics core power. In the event that a workload causes the power to exceed program power limits, the processor will protect itself using the Adaptive Thermal Monitor.

5.3

Intel® Turbo Boost Technology 2.0 Power Control

Illustration of Intel Turbo Boost Technology 2.0 power control is shown in the following sections and figures. Multiple controls operate simultaneously allowing for customization for multiple system thermal and power limitations. These controls allow for turbo optimizations within system constraints and are accessible using MSR, MMIO, or PECI interfaces

5.3.1

Package Power Control

The package power control allows for customization to implement optimal turbo within platform power delivery and package thermal solution limitations.

Table 22. Intel® Turbo Boost Technology 2.0 Package Power Control Settings

MSR: Address:

Control Bit Default Description

POWER_LIMIT_1 (PL1) 14:0 SKU TDP

POWER_LIMIT_1_TIME (Turbo Time Parameter)

POWER_LIMIT_2 (PL2) 46:32 1.25 x TDP

MSR_TURBO_POWER_LIMIT 610h

23:17 1 sec

• This value sets the average power limit over a long time period. This is normally aligned to the TDP of the part and steady-state cooling capability of the thermal solution. The default value is the TDP for the SKU.

• PL1 limit may be set lower than TDP in real time for specific needs, such as responding to a thermal event. If it is set lower than TDP, the processor may require to use frequencies below the guaranteed P1 frequency to control the low-power limits. The PL1 Clamp bit [16] should be set to enable the processor to use frequencies below P1 to control the setpower limit.

• PL1 limit may be set higher than TDP. If set higher than TDP, the processor could stay at that power level continuously and cooling solution improvements may be required.

This value is a time parameter that adjusts the algorithm behavior to maintain time averaged power at or below PL1. The hardware default value is 1 second; however, 28 seconds is recommended for most mobile applications.

PL2 establishes the upper power limit of turbo operation above TDP, primarily for platform power supply considerations. Power may exceed this limit for up to 10 ms. The default for this limit is

1.25 x TDP; however, the BIOS may reprogram the default value

to maximize the performance within platform power supply considerations. Setting this limit to TDP will limit the processor to only operate up to the TDP. It does not disable turbo because turbo is opportunistic and power/temperature dependent. Many workloads will allow some turbo frequencies for powers at or below TDP.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 70 Order No.: 328901-007

Thermal Management—Processor

Figure 15. Package Power Control

5.3.2

5.4

Turbo Time Parameter

Turbo Time Parameter is a mathematical parameter (units in seconds) that controls the Intel Turbo Boost Technology 2.0 algorithm using moving average of energy usage. During a maximum power turbo event of about 1.25 x TDP, the processor could sustain PL2 for up to approximately 1.5 times the Turbo Time Parameter. If the power value and/or Turbo Time Parameter is changed during runtime, it may take approximately 3 to 5 times the Turbo Time Parameter for the algorithm to settle at the new control limits. The time varies depending on the magnitude of the change and other factors. There is an individual Turbo Time Parameter associated with Package Power Control.

Configurable TDP (cTDP) and Low-Power Mode

Configurable TDP (cTDP) and Low-Power Mode (LPM) form a design vector where the processor's behavior and package TDP are dynamically adjusted to a desired system performance and power envelope. Configurable TDP and Low-Power Mode technologies offer opportunities to differentiate system design while running active workloads on select processor SKUs through scalability, configuration and adaptability. The scenarios or methods by which each technology is used are customizable but typically involve changes to PL1 and associated frequencies for the scenario with a resultant change in performance depending on system's usage. Either technology can be triggered by (but are not limited to) changes in OS power policies or hardware events such as docking a system, flipping a switch or pressing a button. cTDP and LPM are designed to be configured dynamically and do not require an operating system reboot.

Note: Configurable TDP and Low-Power Mode technologies are not battery life improvement

technologies.

5.4.1

Note: Configurable TDP availability may vary between the different SKUs.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 71

Configurable TDP

With cTDP, the processor is now capable of altering the maximum sustained power with an alternate IA core base frequency. Configurable TDP allows operation in situations where extra cooling is available or situations where a cooler and quieter mode of operation is desired. Configurable TDP can be enabled using Intel's DPTF driver or through HW/EC firmware. Enabling cTDP using the DPTF driver is recommended as Intel does not provide specific application or EC source code.

Processor Family

cTDP consists of three modes as shown in the following table.

Table 23. Configurable TDP Modes

Mode Description

Nominal This is the processor's rated frequency and TDP.

TDP-Up When extra cooling is available, this mode specifies a higher TDP and higher

guaranteed frequency versus the nominal mode.

TDP-Down When a cooler or quieter mode of operation is desired, this mode specifies a lower TDP

and lower guaranteed frequency versus the nominal mode.

In each mode, the Intel Turbo Boost Technology 2.0 power and frequency ranges are reprogrammed and the OS is given a new effective HFM operating point. The driver assists in all these operations. The cTDP mode does not change the max per-core turbo frequency.

Processor—Thermal Management

5.4.2

Low-Power Mode

Low-Power Mode (LPM) can provide cooler and quieter system operation. By combining several active power limiting techniques, the processor can consume less power while running at equivalent low frequencies. Active power is defined as processor power consumed while a workload is running and does not refer to the power consumed during idle modes of operation. LPM is only available using the Intel DPTF driver.

Through the DPTF driver, LPM can be configured to use each of the following methods to reduce active power:

• Restricting Intel Turbo Boost Power limits and IA core Turbo Boost availability

• Off-Lining core activity (Move processor traffic to a subset of cores)

• Placing an IA Core at LFM or LSF (Lowest Supported Frequency)

• Utilizing IA clock modulation

Off-lining core activity is the ability to dynamically scale a workload to a limited subset of cores in conjunction with a lower turbo power limit. It is one of the main vectors available to reduce active power. However, not all processor activity is ensured to be able to shift to a subset of cores. Shifting a workload to a limited subset of cores allows other cores to remain idle and save power. Therefore, when LPM is enabled, less power is consumed at equivalent frequencies.

Minimum Frequency Mode (MFM) of operation, which is the lowest supported frequency (LSF) at the LFM voltage, has been made available for use under LPM for further reduction in active power beyond LFM capability to enable cooler and quieter modes of operation.

5.5

Thermal and Power Specifications

The following notes apply to Table 24 on page 73 and Table 25 on page 74.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 72 Order No.: 328901-007

Thermal Management—Processor

Note Definition

The TDPs given are not the maximum power the processor can generate. Analysis indicates that real applications are unlikely to cause the processor to consume the theoretical maximum power dissipation for sustained periods of

time.

2 TDP workload may consist of a combination of processor-core intensive and graphics-core intensive applications.

The thermal solution needs to ensure that the processor temperature does not exceed the maximum junction

temperature (Tj

The processor junction temperature is monitored by Digital Temperature Sensors (DTS). For DTS accuracy, refer to

Digital Thermal Sensor Accuracy (Taccuracy) on page 79.

Digital Thermal Sensor (DTS) based fan speed control is required to achieve optimal thermal performance. Intel

recommends full cooling capability well before the DTS reading reaches Tj

The idle power specifications are not 100% tested. These power specifications are determined by the

characterization at higher temperatures and extrapolating the values for the junction temperature indicated.

7 At Tj of Tj

MAX

) limit, as measured by the DTS and the critical temperature bit.

MAX

. An example of this is Tj

MAX

8 At Tj of 50 ºC

9 At Tj of 35 ºC

10 Can be modified at runtime by MSR writes, with MMIO and with PECI commands.

'Turbo Time Parameter' is a mathematical parameter (unit in seconds) that controls the processor turbo algorithm using a moving average of energy usage. Do not set the Turbo Time Parameter to a value less than 0.1 seconds.

Refer to Turbo Time Parameter on page 71 for further information.

Shown limit is a time averaged power, based upon the Turbo Time Parameter. Absolute product power may exceed

the set limits for short durations or under virus or uncharacterized workloads.

Processor will be controlled to specified power limit as described in Intel Turbo Boost Technology 2.0 Power

Monitoring on page 70. If the power value and/or 'Turbo Time Parameter' is changed during runtime, it may take a

short period of time (approximately 3 to 5 times the 'Turbo Time Parameter') for the algorithm to settle at the new control limits.

14 This is a hardware default setting and not a behavioral characteristic of the part.

15 For controllable turbo workloads, limit may be exceeded for up to 10 ms.

16 Refer to Table 23 on page 72 for the definitions of 'TDP-Nominal', 'TDP-Up', 'TDP-Down'.

17 LPM power level is an opportunistic power and is not a guaranteed value as usages and implementations may vary.

Power limits may vary depending on if the product supports the 'TDP-up' and/or 'TDP-down' modes. Default power

limits can be found in the PKG_PWR_SKU MSR (614h).

– 10 ºC.

Table 24. Thermal Design Power (TDP) Specifications

Segment State Processor Core

Frequency

TDP-Up

Quad Core rPGA Processor with GT2 Graphics

(M-Processor) (XE)

TDPNominal/HFM

TDP-Down 47

LFM 800 MHz 200 MHz 42

3.0 GHz up to

3.9 GHz

LPM 800 MHz 200 MHz 37

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 73

Processor Graphics

Core Frequency

400 MHz up to

1350 MHz

Thermal Design

Power

Units Notes

1, 2, 7,

16, 17,

continued...

Processor Family

Processor—Thermal Management

Segment State Processor Core

Frequency

Quad Core BGA Processor with GT3 Graphics

HFM

2.0 GHz up to

(H-Processor) (47W)

Quad Core BGA Processor with GT2

LFM 800 MHz 200 MHz 37

HFM

2.4 GHz up to

Graphics (H-Processor) (47W)

Quad Core rPGA Processor with GT2

LFM 800MHz 200 MHz 37

HFM

2.4 GHz up to

Graphics (M-Processor) (47W)

Quad Core BGA Processor with GT2

LFM 800 MHz 200 MHz 37

HFM

2.2 GHz up to

Graphics (H-Processor) (37W)

Dual Core BGA Processor with GT2

LFM 800 MHz 200 MHz 32

HFM

2.8 GHz up to

Graphics (H-Processor) (47W)

Quad Core rPGA Processor with GT2

LFM 800 MHz 200 MHz —

HFM

2.2 GHz up to

Graphics (M-Processor) (37W)

Dual Core rPGA Processor with

LFM 800 MHz 200 MHz 32

HFM

2.0 GHz up to

GT2/GT1 Graphics (M-Processor) (37W)

LFM 800 MHz 200 MHz 32

3.6 GHz

3.4 GHz

3.8 GHz

3.2 GHz

3.4 GHz

3.2 GHz

3.6 GHz

Processor Graphics

Core Frequency

200 MHz up to

1300 MHz

400 MHz up to

1200 MHz

400 MHz up to

1300 MHz

400 MHz up to

1150 MHz

400 MHz up to

1150 MHz

400 MHz up to

1150 MHz

400 MHz up to

1300 MHz

Thermal Design

Power

Package: 47

Processor Die: 47

On-package Cache

Memory Die: 5

Units Notes

W 1, 2, 7

Table 25. Junction Temperature Specification

Segment Symbol Package Turbo

Parameter

Quad Core rPGA Processor with GT2 Graphics

(M-Processor)

Junction temperature limit

(XE)

Quad Core BGA Processor with GT3 Graphics

(H-Processor)

Junction temperature limit

(47W)

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 74 Order No.: 328901-007

Min Default Max Units Notes

0 — 100 ºC 3, 4, 5

Processor Die: 100

0 —

On-package Cache

ºC 3, 4, 5

Memory Die: 93

continued...

Thermal Management—Processor

Segment Symbol Package Turbo

Quad Core BGA Processor with GT2 Graphics

(H-Processor)

Junction temperature limit

(47W)

Quad Core rPGA Processor with GT2 Graphics

(M-Processor)

Junction temperature limit

(47W)

Quad Core BGA Processor with GT2 Graphics

(H-Processor)

Junction temperature limit

(37W)

Dual Core BGA Processor with GT2 Graphics

(H-Processor)

Junction temperature limit

(47W)

Quad Core rPGA Processor with GT2 Graphics

(M-Processor)

Junction temperature limit

(37W)

Dual Core rPGA Processor with GT2/GT1 Graphics

(M-Processor)

Junction temperature limit

(37W)

Parameter

Min Default Max Units Notes

0 — 100 ºC 3, 4, 5

Table 26. Idle Power Specifications

Segment Symbol Idle Parameter Min Typ Max Units Notes

Quad Core rPGA Processor with GT2 Graphics

(M-Processor) (XE)

Quad Core BGA Processor with GT3 Graphics

(H-Processor) (47W)

Quad Core BGA Processor with GT2 Graphics

(H-Processor) (47W)

Quad Core rPGA Processor with GT2 Graphics

(M-Processor) (47W)

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 75

Idle power in the Package C6 state

Idle power in the Package C7 state

Idle power in the Package C6 state

Idle power in the Package C7 state

Idle power in the Package C6 state

Idle power in the Package C7 state

Idle power in the Package C6 state

Idle power in the Package C7 state

0 — 2.5 W 6, 8

0 — 2.4 W 6, 9

0 — 2.5 W 6, 8

0 — 2.4 W 6, 9

0 — 2.5 W 6, 8

0 — 2.4 W 6, 9

0 — 2.5 W 6, 8

0 — 2.4 W 6, 9

continued...

Processor Family

Segment Symbol Idle Parameter Min Typ Max Units Notes

Quad Core BGA Processor with GT2 Graphics

(H-Processor) (37W)

Dual Core BGA Processor with GT2 Graphics

(H-Processor) (47W)

Quad Core rPGA Processor with GT2 Graphics

(M-Processor) (37W)

Dual Core rPGA Processor with GT2/GT1 Graphics

(M-Processor) (37W)

Processor—Thermal Management

Idle power in the Package C6 state

Idle power in the Package C7 state

Idle power in the Package C6 state

Idle power in the Package C7 state

Idle power in the Package C6 state

Idle power in the Package C7 state

Idle power in the Package C6 state

Idle power in the Package C7 state

0 — 2.5 W 6, 8

0 — 2.4 W 6, 9

0 — 2.5 W 6, 8

0 — 2.4 W 6, 9

0 — 2.5 W 6, 8

0 — 2.4 W 6, 9

0 — 2.5 W 6, 8

0 — 2.4 W 6, 9

5.6

5.6.1

Thermal Management Features

Occasionally the processor may operate in conditions that are near to its maximum operating temperature. This can be due to internal overheating or overheating within the platform. To protect the processor and the platform from thermal failure, several thermal management features exist to reduce package power consumption and thereby temperature in order to remain within normal operating limits. Furthermore, the processor supports several methods to reduce memory power.

Adaptive Thermal Monitor

The purpose of the Adaptive Thermal Monitor is to reduce processor core power consumption and temperature until it operates at or below its maximum operating temperature. Processor core power reduction is achieved by:

• Adjusting the operating frequency (using the core ratio multiplier) and voltage.

• Modulating (starting and stopping) the internal processor core clocks (duty cycle).

The Adaptive Thermal Monitor can be activated when the package temperature, monitored by any digital thermal sensor (DTS) meets or exceeds its maximum operating temperature. The maximum operating temperature implies either maximum junction temperature Tj

Exceeding the maximum operating temperature activates the thermal control circuit (TCC), if enabled. When activated the thermal control circuit (TCC) causes both the processor core and graphics core to reduce frequency and voltage adaptively. The Adaptive Thermal Monitor will remain active as long as the package temperature exceeds its specified limit. Therefore, the Adaptive Thermal Monitor will continue to reduce the package frequency and voltage until the TCC is de-activated.

MAX

, or Tj

minus TCC Activation offset.

MAX

is factory calibrated and is not user configurable. The default value is software

MAX

visible in the TEMPERATURE_TARGET (0x1A2) MSR, bits [23:16]. The TEMPERATURE_TARGET value stays the same when TCC Activation offset is enabled.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 76 Order No.: 328901-007

Thermal Management—Processor

The Adaptive Thermal Monitor does not require any additional hardware, software drivers, or interrupt handling routines. It is not intended as a mechanism to maintain processor TDP. The system design should provide a thermal solution that can maintain TDP within its intended usage range.

Note: Adaptive Thermal Monitor protection is always enabled.

5.6.1.1

5.6.1.2

Thermal Control Circuit (TCC) Activation Offset

TCC Activation Offset can be used to activate the Adaptive Thermal Monitor at temperatures lower than Tj

. It is the preferred thermal protection mechanism for

MAX

Intel Turbo Boost Technology 2.0 operation since ACPI passive throttling states will pull the processor out of turbo mode operation when triggered. An offset (in degrees Celsius) can be written to the TEMPERATURE_TARGET (0x1A2) MSR, bits [27:24]. This value will be subtracted from the value found in bits [23:16]. The default offset is 0 °C, TCC activation will occur at Tj

. The offset should be set lower than any other

MAX

protection such as ACPI _PSV trip points.

Frequency / Voltage Control

Upon Adaptive Thermal Monitor activation, the processor core attempts to dynamically reduce processor core power by lowering the frequency and voltage operating point. The operating points are automatically calculated by the processor core itself and do not require the BIOS to program them as with previous generations of Intel processors. The processor core will scale the operating points such that:

• The voltage will be optimized according to the temperature, the core bus ratio, and number of cores in deep C-states.

• The core power and temperature are reduced while minimizing performance degradation.

Once the temperature has dropped below the maximum operating temperature, the operating frequency and voltage will transition back to the normal system operating point.

Once a target frequency/bus ratio is resolved, the processor core will transition to the new target automatically.

• On an upward operating point transition, the voltage transition precedes the frequency transition.

• On a downward transition, the frequency transition precedes the voltage transition.

• The processor continues to execute instructions. However, the processor will halt instruction execution for frequency transitions.

If a processor load-based Enhanced Intel SpeedStep Technology/P-state transition (through MSR write) is initiated while the Adaptive Thermal Monitor is active, there are two possible outcomes:

• If the P-state target frequency is higher than the processor core optimized target frequency, the P-state transition will be deferred until the thermal event has been completed.

• If the P-state target frequency is lower than the processor core optimized target frequency, the processor will transition to the P-state operating point.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 77

Processor—Thermal Management

5.6.1.3

5.6.2

Clock Modulation

If the frequency/voltage changes are unable to end an Adaptive Thermal Monitor event, the Adaptive Thermal Monitor will utilize clock modulation. Clock modulation is done by alternately turning the clocks off and on at a duty cycle (ratio between clock "on" time and total time) specific to the processor. The duty cycle is factory configured to 25% on and 75% off and cannot be modified. The period of the duty cycle is configured to 32 microseconds when the Adaptive Thermal Monitor is active. Cycle times are independent of processor frequency. A small amount of hysteresis has been included to prevent excessive clock modulation when the processor temperature is near its maximum operating temperature. Once the temperature has dropped below the maximum operating temperature, and the hysteresis timer has expired, the Adaptive Thermal Monitor goes inactive and clock modulation ceases. Clock modulation is automatically engaged as part of the Adaptive Thermal Monitor activation when the frequency/voltage targets are at their minimum settings. Processor performance will be decreased by the same amount as the duty cycle when clock modulation is active. Snooping and interrupt processing are performed in the normal manner while the Adaptive Thermal Monitor is active.

Digital Thermal Sensor

Each processor execution core has an on-die Digital Thermal Sensor (DTS) that detects the core's instantaneous temperature. The DTS is the preferred method of monitoring processor die temperature because:

• It is located near the hottest portions of the die.

• It can accurately track the die temperature and ensure that the Adaptive Thermal Monitor is not excessively activated.

Temperature values from the DTS can be retrieved through:

• A software interface using processor Model Specific Register (MSR).

• A processor hardware interface as described in Platform Environmental Control

Interface (PECI) on page 38.

When temperature is retrieved by the processor MSR, it is the instantaneous temperature of the given core. When temperature is retrieved using PECI, it is the average of the highest DTS temperature in the package over a 256 ms time window. Intel recommends using the PECI reported temperature for platform thermal control that benefits from averaging, such as fan speed control. The average DTS temperature may not be a good indicator of package Adaptive Thermal Monitor activation or rapid increases in temperature that triggers the Out of Specification status bit within the PACKAGE_THERM_STATUS MSR 1B1h and IA32_THERM_STATUS MSR 19Ch.

Code execution is halted in C1 or deeper C-states. Package temperature can still be monitored through PECI in lower C-states.

Unlike traditional thermal devices, the DTS outputs a temperature relative to the maximum supported operating temperature of the processor (Tj

), regardless of

MAX

TCC activation offset. It is the responsibility of software to convert the relative temperature to an absolute temperature. The absolute reference temperature is readable in the TEMPERATURE_TARGET MSR 1A2h. The temperature returned by the DTS is an implied negative integer indicating the relative offset from Tj does not report temperatures greater than Tj

. The DTS-relative temperature

MAX

. The DTS

MAX

readout directly impacts the Adaptive Thermal Monitor trigger point. When a package

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 78 Order No.: 328901-007

Thermal Management—Processor

DTS indicates that it has reached the TCC activation (a reading of 0h, except when the TCC activation offset is changed), the TCC will activate and indicate an Adaptive Thermal Monitor event. A TCC activation will lower both IA core and graphics core frequency, voltage, or both. Changes to the temperature can be detected using two programmable thresholds located in the processor thermal MSRs. These thresholds have the capability of generating interrupts using the core's local APIC. Refer to the Intel® 64 and IA-32 Architectures Software Developer’s Manual for specific register and programming details.

5.6.2.1

5.6.2.2

5.6.3

5.6.3.1

Digital Thermal Sensor Accuracy (Taccuracy)

The error associated with DTS measurements will not exceed ±5 °C within the entire operating range.

Fan Speed Control with Digital Thermal Sensor

Digital Thermal Sensor based fan speed control (T achieve optimal thermal performance. At the T cooling capability well before the DTS reading reaches Tj

) is a recommended feature to

FAN

temperature, Intel recommends full

FAN

MAX

PROCHOT# Signal

PROCHOT# (processor hot) is asserted when the processor temperature has reached its maximum operating temperature (Tj package level. When any core arrives at the TCC activation point, the PROCHOT# signal will be asserted. PROCHOT# assertion policies are independent of Adaptive Thermal Monitor enabling.

Bi-Directional PROCHOT#

By default, the PROCHOT# signal is set to bi-directional. However, it is recommended to configure the signal as an input only. When configured as an input or bi-directional signal, PROCHOT# can be used for thermally protecting other platform components in case the components overheat as well. When PROCHOT# is driven by an external device:

• The package will immediately transition to the lowest P-State (Pn) supported by the processor and graphics cores. This is contrary to the internally-generated Adaptive Thermal Monitor response.

• Clock modulation is not activated.

). Only a single PROCHOT# pin exists at a

MAX

The processor package will remain at the lowest supported P-state until the system de-asserts PROCHOT#. The processor can be configured to generate an interrupt upon assertion and de-assertion of the PROCHOT# signal.

Note: When PROCHOT# is configured as a bi-directional signal and PROCHOT# is asserted

by the processor, it is impossible for the processor to detect a system assertion of PROCHOT#. The system assertion will have to wait until the processor de-asserts PROCHOT# before PROCHOT# action can occur due to the system assertion. While the processor is hot and asserting PROCHOT#, the power is reduced; however, the reduction rate is slower than the system PROCHOT# response of < 100 us. The processor thermal control is staged in smaller increments over many milliseconds. This may cause several milliseconds of delay to a system assertion of PROCHOT# while the output function is asserted.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 79

Processor—Thermal Management

5.6.3.2

5.6.3.3

Voltage Regulator Protection using PROCHOT#

PROCHOT# may be used for thermal protection of voltage regulators (VR). System designers can create a circuit to monitor the VR temperature and assert PROCHOT# and, if enabled, activate the TCC when the temperature limit of the VR is reached. When PROCHOT# is configured as a bi-directional or input only signal, if the system assertion of PROCHOT# is recognized by the processor, it will result in an immediate transition to the lowest P-State (Pn) supported by the processor and graphics cores. Systems should still provide proper cooling for the VR and rely on bi-directional PROCHOT# only as a backup in case of system cooling failure. Overall, the system thermal design should allow the power delivery circuitry to operate within its temperature specification even while the processor is operating at its TDP.

Thermal Solution Design and PROCHOT# Behavior

With a properly designed and characterized thermal solution, it is anticipated that PROCHOT# will only be asserted for very short periods of time when running the most power intensive applications. The processor performance impact due to these brief periods of TCC activation is expected to be so minor that it would be immeasurable. However, an under-designed thermal solution that is not able to prevent excessive assertion of PROCHOT# in the anticipated ambient environment may:

• Cause a noticeable performance loss.

• Result in prolonged operation at or above the specified maximum junction temperature and affect the long-term reliability of the processor.

• May be incapable of cooling the processor even when the TCC is active continuously (in extreme situations).

5.6.3.4

5.6.3.5

5.6.3.6

Low-Power States and PROCHOT# Behavior

Depending on package power levels during package C-states, outbound PROCHOT# may de-assert while the processor is idle as power is removed from the signal. Upon wakeup, if the processor is still hot, the PROCHOT# will re-assert, although typically package idle state residency should resolve any thermal issues. The PECI interface is fully operational during all C-states and it is expected that the platform continues to manage processor core and package thermals even during idle states by regularly polling for thermal data over PECI.

THERMTRIP# Signal

Regardless of enabling the automatic or on-demand modes, in the event of a catastrophic cooling failure, the package will automatically shut down when the silicon has reached an elevated temperature that risks physical damage to the product. At this point the THERMTRIP# signal will go active.

Critical Temperature Detection

Critical Temperature detection is performed by monitoring the package temperature. This feature is intended for graceful shutdown before the THERMTRIP# is activated. However, the processor execution is not guaranteed between critical temperature and THERMTRIP#. If the Adaptive Thermal Monitor is triggered and the temperature remains high, a critical temperature status and sticky bit are latched in the PACKAGE_THERM_STATUS MSR 1B1h and the condition also generates a thermal interrupt, if enabled. For more details on the interrupt mechanism, refer to the Intel

64 and IA-32 Architectures Software Developer’s Manual.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 80 Order No.: 328901-007

Thermal Management—Processor

5.6.4

5.6.4.1

5.6.4.2

On-Demand Mode

The processor provides an auxiliary mechanism that allows system software to force the processor to reduce its power consumption using clock modulation. This mechanism is referred to as "On-Demand" mode and is distinct from Adaptive Thermal Monitor and bi-directional PROCHOT#. The processor platforms must not rely on software usage of this mechanism to limit the processor temperature. On-Demand Mode can be accomplished using processor MSR or chipset I/O emulation. On-Demand Mode may be used in conjunction with the Adaptive Thermal Monitor. However, if the system software tries to enable On-Demand mode at the same time the TCC is engaged, the factory configured duty cycle of the TCC will override the duty cycle selected by the On-Demand mode. If the I/O based and MSR-based On-Demand modes are in conflict, the duty cycle selected by the I/O emulation-based On-Demand mode will take precedence over the MSR-based On-Demand Mode.

MSR Based On-Demand Mode

If Bit 4 of the IA32_CLOCK_MODULATION MSR is set to a 1, the processor will immediately reduce its power consumption using modulation of the internal core clock, independent of the processor temperature. The duty cycle of the clock modulation is programmable using bits [3:1] of the same IA32_CLOCK_MODULATION MSR. In this mode, the duty cycle can be programmed in either 12.5% or 6.25% increments (discoverable using CPUID). Thermal throttling using this method will modulate each processor core's clock independently.

I/O Emulation-Based On-Demand Mode

5.6.5

I/O emulation-based clock modulation provides legacy support for operating system software that initiates clock modulation through I/O writes to ACPI defined processor clock control registers on the chipset (PROC_CNT). Thermal throttling using this method will modulate all processor cores simultaneously.

Intel® Memory Thermal Management

The processor provides thermal protection for system memory by throttling memory traffic when using either DIMM modules or a memory down implementation. Two levels of throttling are supported by the processor – either a warm threshold or hot threshold that is customizable through memory mapped I/O registers. Throttling based on the warm threshold should be an intermediate level of throttling. Throttling based on the hot threshold should be the most severe. The amount of throttling is dynamically controlled by the processor.

Memory temperature can be acquired through an on-board thermal sensor (TS-onBoard), retrieved by an embedded controller and reported to the processor through the PECI 3.0 interface. This methodology is known as PECI injected temperatures and is a method of Closed Loop Thermal Management (CLTM). CLTM requires the use of a physical thermal sensor. EXTTS# is another method of CLTM; however, it is only capable of reporting memory thermal status to the processor. EXTTS# consists of two GPIO pins on the PCH where the state of the pins is communicated internally to the processor.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 81

Processor—Thermal Management

When a physical thermal sensor is not available to report temperature, the processor supports Open Loop Thermal Management (OLTM) that estimates the power consumed per rank of the memory using the processor DRAM power meter. A per rank power is associated with the warm and hot thresholds that, when exceeded, may trigger memory thermal throttling.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 82 Order No.: 328901-007

Signal Description—Processor

6.0 Signal Description

This chapter describes the processor signals. The signals are arranged in functional groups according to the associated interface or category. The following notations are used to describe the signal type.

Notation

I Input pin

O Output pin

I/O Bi-directional Input/Output pin

The signal description also includes the type of buffer used for the particular signal (see the following table).

Table 27. Signal Description Buffer Types

Signal Description

PCI Express* interface signals. These signals are compatible with PCI Express 3.0

PCI Express*

eDP

FDI

DMI

CMOS CMOS buffers. 1.05V- tolerant

DDR3L/DDR3L-RSDDR3L/DDR3L-RS buffers: 1.35 V- tolerant

Signaling Environment AC Specifications and are AC coupled. The buffers are not 3.3 Vtolerant. See the PCI Express Base Specification 3.0.

Embedded Display Port interface signals. These signals are compatible with VESA Rev 1.3 eDP specifications and the interface is AC coupled. The buffers are not 3.3V- tolerant.

Intel Flexible Display interface signals. These signals are based on PCI Express 2.0 Signaling Environment AC Specifications (2.7 GT/s), but are DC coupled. The buffers are not 3.3 V- tolerant.

Direct Media Interface signals. These signals are compatible with PCI Express 2.0 Signaling Environment AC Specifications, but are DC coupled. The buffers are not 3.3 Vtolerant.

Signal Type

GTL Gunning Transceiver Logic signaling technology

Ref Voltage reference signal

Asynchronous 1Signal has no timing relationship with any reference clock.

1. Qualifier for a buffer type.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 83

Analog reference or output. May be used as a threshold voltage or for buffer compensation

Processor Family

Processor—Signal Description

6.1

System Memory Interface Signals

Table 28. Memory Channel A Signals

Signal Name Description Direction / Buffer

Bank Select: These signals define which banks are selected

SA_BS[2:0]

SA_WE#

SA_RAS#

SA_CAS#

SA_DQSP[7:0] SA_DQSN[7:0]

SA_DQ[63:0]

SA_MA[15:0]

SA_CKP[3:0] SA_CKN[3:0]

SA_CKE[3:0]

SA_CS#[3:0]

SA_ODT[3:0]

within each SDRAM rank.

Write Enable Control Signal: This signal is used with SA_RAS# and SA_CAS# (along with SA_CS#) to define the SDRAM Commands.

RAS Control Signal: This signal is used with SA_CAS# and SA_WE# (along with SA_CS#) to define the SRAM Commands.

CAS Control Signal: This signal is used with SA_RAS# and SA_WE# (along with SA_CS#) to define the SRAM Commands.

Data Strobes: SA_DQS[7:0] and its complement signal group make up a differential strobe pair. The data is captured at the crossing point of SA_DQS[7:0] and SA_DQS#[7:0] during read and write transactions.

Data Bus: Channel A data signal interface to the SDRAM data bus.

Memory Address: These signals are used to provide the multiplexed row and column address to the SDRAM.

SDRAM Differential Clock: These signals are Channel A SDRAM Differential clock signal pairs. The crossing of the positive edge of SA_CKP and the negative edge of its complement SA_CKN are used to sample the command and control signals on the SDRAM. Bits [3:2] are used only for 2 DPC system.

Clock Enable: (1 per rank). These signals are used to:

• Initialize the SDRAMs during power-up

• Power-down SDRAM ranks

• Place all SDRAM ranks into and out of self-refresh during STR

-Bits [3:2] used only for 2 DPC system

Chip Select: (1 per rank). These signals are used to select particular SDRAM components during the active state. There is one Chip Select for each SDRAM rank. Bits [3:2] are used only for 2 DPC system.

On Die Termination: Active Termination Control. Bits [3:2] are used only for 2 DPC system.

Type

DDR3L

/DDR3L-RS

DDR3L

/DDR3L-RS

DDR3L

/DDR3L-RS

DDR3L

/DDR3L-RS

I/O

DDR3L/DDR3L-RS

I/O

DDR3L

/DDR3L-RS

DDR3L

/DDR3L-RS

DDR3L/DDR3L-RS

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 84 Order No.: 328901-007

Signal Description—Processor

Table 29. Memory Channel B Signals

Signal Name Description Direction / Buffer

Bank Select: These signals define which banks are selected

SB_BS[2:0]

SB_WE#

SB_RAS#

SB_CAS#

SB_DQSP[7:0] SB_DQSN[7:0]

SB_DQ[63:0]

SB_MA[15:0]

SB_CKP[3:0] SB_CKN[3:0]

SB_CKE[3:0]

SB_CS#[3:0]

SB_ODT[3:0]

within each SDRAM rank.

Write Enable Control Signal: This signal is used with SB_RAS# and SB_CAS# (along with SB_CS#) to define the SDRAM Commands.

RAS Control Signal: This signal is used with SB_CAS# and SB_WE# (along with SB_CS#) to define the SRAM Commands.

CAS Control Signal: This signal is used with SB_RAS# and SB_WE# (along with SB_CS#) to define the SRAM Commands.

Data Strobes: SB_DQS[7:0] and its complement signal group make up a differential strobe pair. The data is captured at the crossing point of SB_DQS[8:0] and its SB_DQS#[7:0] during read and write transactions.

Data Bus: Channel B data signal interface to the SDRAM data bus.

Memory Address: These signals are used to provide the multiplexed row and column address to the SDRAM.

SDRAM Differential Clock: Channel B SDRAM Differential clock signal pair. The crossing of the positive edge of SB_CKP and the negative edge of its complement SB_CKN are used to sample the command and control signals on the SDRAM. Bits [3:2] used only for 2 DPC system.

Clock Enable: (1 per rank). These signals are used to:

• Initialize the SDRAMs during power-up.

• Power-down SDRAM ranks.

• Place all SDRAM ranks into and out of self-refresh during STR.

• Bits [3:2] used only for 2 DPC system

On Die Termination: Active Termination Control. Signals [3:2] are used only for 2 DPC system.

Type

DDR3L

/DDR3L-RS

DDR3L

/DDR3L-RS

DDR3L

/DDR3L-RS

DDR3L

/DDR3L-RS

I/O

DDR3L/DDR3L-RS

I/O

DDR3L

/DDR3L-RS

DDR3L

/DDR3L-RS

DDR3L/DDR3L-RS

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 85

Processor—Signal Description

6.2

Memory Reference Compensation Signals

Table 30. Memory Reference and Compensation Signals

Signal Name Description Direction /

System Memory Impedance Compensation: I

DDR3L Reference Voltage: This signal is used as a

reference voltage to the DDR3L/DDR3L-RS controller and is defined as V

Memory Channel A/B DIMM DQ Voltage Reference:

The output pins are connected to the DIMMs, and holds V

/2 as reference voltage.

DDQ

/2.

6.3

SM_RCOMP[2:0]

SM_VREF

SA_DIMM_VREFDQ SB_DIMM_VREFDQ

Reset and Miscellaneous Signals

Table 31. Reset and Miscellaneous Signals

Signal Name Description Direction /

Configuration Signals: The CFG signals have a default value of

'1' if not terminated on the board.

• CFG[1:0]: Reserved configuration lane. A test point may be placed on the board for these lanes.

• CFG[2]: PCI Express* Static x16 Lane Numbering Reversal. — 1 = Normal operation — 0 = Lane numbers reversed.

• CFG[3]: MSR Privacy Bit Feature — 1 = Debug capability is determined by

IA32_Debug_Interface_MSR (C80h) bit[0] setting

CFG[19:0]

CFG_RCOMP

FC_x

PM_SYNC

PWR_DEBUG#

— 0 = IA32_Debug_Interface_MSR (C80h) bit[0] default

setting overridden

• CFG[4]: eDP enable — 1 = Disabled — 0 = Enabled

• CFG[6:5]: PCI Express* Bifurcation: — 00 = 1 x8, 2 x4 PCI Express* — 01 = reserved — 10 = 2 x8 PCI Express* — 11 = 1 x16 PCI Express*

• CFG[19:7]: Reserved configuration lanes. A test point may be placed on the board for these lands.

Configuration resistance compensation. Use a 49.9 Ω ±1% resistor to ground.

FC (Future Compatibility) signals are signals that are available for compatibility with other processors. A test point may be placed on the board for these lands.

Power Management Sync: A sideband signal to communicate power management status from the platform to the processor.

Signal is for debug. I

Buffer Type

DDR3L/DDR3L-RS

DDR3L

/DDR3L-RS

Buffer Type

I/O GTL

—

CMOS

Asynchronous

CMOS

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 86 Order No.: 328901-007

Signal Description—Processor

Signal Name Description Direction /

Signal is for IFDIM testing only. I

Signal is for debug. If both THERMTRIP# and this signal are simultaneously asserted, the processor has encountered an unrecoverable power delivery fault and has engaged automatic shutdown as a result.

Platform Reset pin driven by the PCH. I

RESERVED: All signals that are RSVD and RSVD_NCTF must be left unconnected on the board. Intel recommends that all RSVD_TP signals have via test points.

DRAM Reset: Reset signal from processor to DRAM devices. One signal common to all channels.

TESTLO should be individually connected to VSS through a resistor.

6.4

IST_TRIGGER

IVR_ERROR

RESET#

RSVD RSVD_TP RSVD_NCTF

SM_DRAMRST#

TESTLO_x

PCI Express* Interface Signals

Table 32. PCI Express* Graphics Interface Signals

Signal Name Description Direction / Buffer Type

PEG_RCOMP

PEG_RXP[15:0] PEG_RXN[15:0]

PEG_TXP[15:0] PEG_TXN[15:0]

PCI Express Resistance Compensation I

PCI Express Receive Differential Pair I

PCI Express Transmit Differential Pair O

Buffer Type

CMOS

No Connect

Test Point

Non-Critical to

Function

CMOS

PCI Express

6.5

embedded DisplayPort* (eDP*) Signals

Table 33. embedded Display Port* Signals

Signal Name Description Direction / Buffer Type

eDP_TXP[1:0] eDP_TXN[1:0]

eDP_AUXP eDP_AUXN

eDP_HPD

eDP_RCOMP

eDP_DISP_UTIL

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 87

embedded DisplayPort Transmit Differential Pair O

eDP

embedded DisplayPort Auxiliary Differential Pair O

eDP

embedded DisplayPort Hot-Plug Detect. The polarity of this signal is active low.

embedded DisplayPort Current Compensation I/O

Low voltage multipurpose DISP_UTIL pin on the processor for backlight modulation control of embedded panels and S3D device control for active shutter glasses. This pin will co-exist with functionality similar to existing BKLTCTL pin on the PCH.

Asynchronous CMOS

Processor Family

Processor—Signal Description

6.6

Display Interface Signals

Table 34. Display Interface Signals

Signal Name Description Direction / Buffer

6.7

FDI_TXP[1:0] FDI_TXN[1:0]

DDIB_TXP[3:0] DDIB_TXN[3:0]

DDIC_TXP[3:0] DDIC_TXN[3:0]

DDID_TXP[3:0] DDID_TXN[3:0]

FDI_CSYNC

DISP_INT

Direct Media Interface (DMI)

Intel Flexible Display Interface Transmit Differential Pair O

Digital Display Interface Transmit Differential Pair O

Intel Flexible Display Interface Sync I

Intel Flexible Display Interface Hot-Plug Interrupt I

Table 35. Direct Media Interface (DMI) – Processor to PCH Serial Interface

Signal Name Description Direction / Buffer

DMI_RXP[3:0] DMI_RXN[3:0]

DMI_TXP[3:0] DMI_TXN[3:0]

DMI Input from PCH: Direct Media Interface receive differential pair.

DMI Output to PCH: Direct Media Interface transmit differential pair.

Type

FDI

CMOS

Asynchronous

CMOS

Type

DMI

6.8

Phase Locked Loop (PLL) Signals

Table 36. Phase Locked Loop (PLL) Signals

Signal Name Description Direction / Buffer

BCLKP BCLKN

DPLL_REF_CLKP DPLL_REF_CLKN

SSC_DPLL_REF_CLKP SSC_ DPLL_REF_CLKN

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 88 Order No.: 328901-007

Differential bus clock input to the processor I

Embedded Display Port PLL Differential Clock In: 135 MHz

Spread Spectrum Embedded DisplayPort PLL Differential Clock In: 135 MHz

Type

Diff Clk

Signal Description—Processor

6.9

Testability Signals

Table 37. Testability Signals

Signal Name Description Direction / Buffer

BPM#[7:0]

DBR#

PRDY#

PREQ#

TCK

TDI

TDO

TMS

TRST#

Breakpoint and Performance Monitor Signals:

Outputs from the processor that indicate the status of breakpoints and programmable counters used for monitoring processor performance.

Debug Reset: This signal is used only in systems where no debug port is implemented on the system board. DBR# is used by a debug port interposer so that an intarget probe can drive system reset.

Processor Ready: This signal is a processor output used by debug tools to determine processor debug readiness.

Processor Request: This signal is used by debug tools to request debug operation of the processor.

Test Clock: This signal provides the clock input for the processor Test Bus (also known as the Test Access Port). This signal must be driven low or allowed to float during power on Reset.

Test Data In: This signal transfers serial test data into the processor. This signal provides the serial input needed for JTAG specification support.

Test Data Out: This signal transfers serial test data out of the processor. This signal provides the serial output needed for JTAG specification support.

Test Mode Select: This is a JTAG specification supported signal used by debug tools.

Test Reset: This signal resets the Test Access Port (TAP) logic. This signal must be driven low during power on Reset.

Type

I/O

GTL

Open Drain

GTL

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 89

Processor—Signal Description

6.10

Error and Thermal Protection Signals

Table 38. Error and Thermal Protection Signals

Signal Name Description Direction / Buffer

Catastrophic Error: This signal indicates that the system has

experienced a catastrophic error and cannot continue to operate. The processor will set this for non-recoverable

CATERR#

PECI

PROCHOT#

THERMTRIP#

machine check errors or other unrecoverable internal errors. CATERR# is used for signaling the following types of errors: Legacy MCERRs, CATERR# is asserted for 16 BCLKs. Legacy IERRs, CATERR# remains asserted until warm or cold reset.

Platform Environment Control Interface: A serial sideband interface to the processor, it is used primarily for thermal, power, and error management.

Processor Hot: PROCHOT# goes active when the processor temperature monitoring sensor(s) detects that the processor has reached its maximum safe operating temperature. This indicates that the processor Thermal Control Circuit (TCC) has been activated, if enabled. This signal can also be driven to the processor to activate the TCC.

Thermal Trip: The processor protects itself from catastrophic overheating by use of an internal thermal sensor. This sensor is set well above the normal operating temperature to ensure that there are no false trips. The processor will stop all execution when the junction temperature exceeds approximately 130 °C. This is signaled to the system by the THERMTRIP# pin.

Type

GTL

I/O

Asynchronous

GTL Input

Open-Drain Output

Asynchronous OD

Asynchronous CMOS

6.11

Power Sequencing Signals

Table 39. Power Sequencing Signals

Signal Name Description Direction / Buffer

SM_DRAMPWROK

PWRGOOD

SKTOCC# (rPGA) PROC_DETECT# (BGA)

SM_DRAMPWROK Processor Input: This signal connects to the PCH DRAMPWROK.

The processor requires this input signal to be a clean indication that the VCC and V stable and within specifications. This requirement applies regardless of the S-state of the processor. 'Clean' implies that the signal will remain low (capable of sinking leakage current), without glitches, from the time that the power supplies are turned on until the supplies come within specification. The signal must then transition monotonically to a high state.

SKTOCC# (Socket Occupied)/PROC_DETECT#: (Processor Detect): This signal is pulled down

directly (0 Ohms) on the processor package to ground. There is no connection to the processor silicon for this signal. System board designers may use this signal to determine if the processor is present.

power supplies are

DDQ

Type

Asynchronous CMOS

—

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 90 Order No.: 328901-007

Signal Description—Processor

6.12

Processor Power Signals

Table 40. Processor Power Signals

Signal Name Description Direction / Buffer

VCC Processor core power rail. Ref

VCCIO_OUT Processor power reference for I/O. Ref

VDDQ Processor I/O supply voltage for . Ref

VCOMP_OUT Processor power reference for PEG/Display RCOMP. Ref

VIDALERT#, VIDSCLK, and VIDSCLK comprise a three signal serial synchronous interface used to transfer power management information between the processor and the voltage regulator controllers.

6.13

VIDSOUT VIDSCLK VIDALERT#

Sense Signals

Table 41. Sense Signals

Signal Name Description Direction /

VCC_SENSE VSS_SENSE

VCC_SENSE and VSS_SENSE provide an isolated, lowimpedance connection to the processor input VCC voltage and ground. The signals can be used to sense or measure voltage near the silicon.

Type

Input GTL/ Output Open

Drain

Output Open Drain

Input CMOS

Buffer Type

O A

6.14

Ground and Non-Critical to Function (NCTF) Signals

Table 42. Ground and Non-Critical to Function (NCTF) Signals

Signal Name Description Direction /

VSS Processor ground node GND

VSS_NCTF

DAISY_CHAIN_NCTF_[Ball #]

Non-Critical to Function: These pins are for package mechanical reliability.

Daisy Chain Non-Critical to Function: These signals are for assessing the connectivity of corner BGA solder joints during manufacturing or reliability testing and are noncritical to the function of the processor.

These signals are connected on the processor package as follows:

• Package A1 Corner

• DAISY_CHAIN_NCTF_A4 to DAISY_CHAIN_NCTF_A3

• DAISY_CHAIN_NCTF_B3 to DAISY_CHAIN_NCTF_C3

• DAISY_CHAIN_NCTF_B2 to DAISY_CHAIN_NCTF_C2

• DAISY_CHAIN_NCTF_C1 to DAISY_CHAIN_NCTF_D1

• Package A54 Corner

• DAISY_CHAIN_NCTF_A51 to DAISY_CHAIN_NCTF_A52

• DAISY_CHAIN_NCTF_B52 to DAISY_CHAIN_NCTF_A53

• DAISY_CHAIN_NCTF_B53 to DAISY_CHAIN_NCTF_B54

• DAISY_CHAIN_NCTF_C54 to DAISY_CHAIN_NCTF_D54

• Package BF1 Corner

Buffer Type

—

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 91

Processor—Signal Description

Signal Name Description Direction /

• DAISY_CHAIN_NCTF_BC1 to DAISY_CHAIN_NCTF_BD1

• DAISY_CHAIN_NCTF_BE1 to DAISY_CHAIN_NCTF_BE2

• DAISY_CHAIN_NCTF_BF2 to DAISY_CHAIN_NCTF_BE3

• DAISY_CHAIN_NCTF_BF3 to DAISY_CHAIN_NCTF_BF4

• Package BF54 Corner

• DAISY_CHAIN_NCTF_BF51 to DAISY_CHAIN_NCTF_BF52

• DAISY_CHAIN_NCTF_BE52 to DAISY_CHAIN_NCTF_BE53

• DAISY_CHAIN_NCTF_BF53 to DAISY_CHAIN_NCTF_BE54

• DAISY_CHAIN_NCTF_BD54 to DAISY_CHAIN_NCTF_BC54

6.15

Processor Internal Pull-Up / Pull-Down Terminations

Table 43. Processor Internal Pull-Up / Pull-Down Terminations

Signal Name Pull Up / Pull Down Rail Value

BPM[7:0] Pull Up VCCIO_TERM 40–60 Ω

PREQ# Pull Up VCCIO_TERM 40–60 Ω

TDI Pull Up VCCIO_TERM 30–70 Ω

TMS Pull Up VCCIO_TERM 30–70 Ω

CFG[17:0] Pull Up VCCIO_OUT 5–8 kΩ

CATERR# Pull Up VCCIO_TERM 30–70 Ω

Buffer Type

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 92 Order No.: 328901-007

Electrical Specifications—Processor

7.0 Electrical Specifications

This chapter provides the processor electrical specifications including integrated voltage regulator (VR), VCC Voltage Identification (VID), reserved and unused signals, signal groups, Test Access Points (TAP), and DC specifications.

7.1

7.2

7.3

Integrated Voltage Regulator

A new feature to the processor is the integration of platform voltage regulators into the processor. Due to this integration, the processor has one main voltage rail (VCC) and a voltage rail for the memory interface (V previous processors. The VCC voltage rail will supply the integrated voltage regulators which in turn will regulate to the appropriate voltages for the cores, cache, system agent, and graphics. This integration allows the processor to better control on-die voltages to optimize between performance and power savings. The processor VCC rail will remain a VID-based voltage with a loadline similar to the core voltage rail (also called VCC) in previous processors.

) , compared to six voltage rails on

DDQ

Power and Ground Pins

The processor has VCC, VDDQ, and VSS (ground) pins for on-chip power distribution. All power pins must be connected to their respective processor power planes; all VSS pins must be connected to the system ground plane. Use of multiple power and ground planes is recommended to reduce I*R drop. The VCC pins must be supplied with the voltage determined by the processor Serial Voltage IDentification (SVID) interface. Table 44 on page 94 specifies the voltage level for the various VIDs.

VCC Voltage Identification (VID)

The processor uses three signals for the serial voltage identification interface to support automatic selection of voltages. The following table specifies the voltage level corresponding to the 8-bit VID value transmitted over serial VID. A ‘1’ in this table refers to a high voltage level and a ‘0’ refers to a low voltage level. If the voltage regulation circuit cannot supply the voltage that is requested, the voltage regulator must disable itself. VID signals are CMOS push/pull drivers. See the Voltage and Current Specifications section for the DC specifications for these signals. The VID codes will change due to temperature and/or current load changes to minimize the power of the part. A voltage range is provided in the Voltage and Current Specifications section. The specifications are set so that one voltage regulator can operate with all supported frequencies.

Individual processor VID values may be set during manufacturing so that two devices at the same core frequency may have different default VID settings. This is shown in the VID range values in the Voltage and Current Specifications section. The processor provides the ability to operate while transitioning to an adjacent VID and its associated voltage. This will represent a DC shift in the loadline.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 93

Table 44. Voltage Regulator (VR) 12.5 Voltage Identification

0 0 0 0 0 0 0 0 00h 0.0000

0 0 0 0 0 0 0 1 01h 0.5000

0 0 0 0 0 0 1 0 02h 0.5100

0 0 0 0 0 0 1 1 03h 0.5200

0 0 0 0 0 1 0 0 04h 0.5300

0 0 0 0 0 1 0 1 05h 0.5400

0 0 0 0 0 1 1 0 06h 0.5500

0 0 0 0 0 1 1 1 07h 0.5600

0 0 0 0 1 0 0 0 08h 0.5700

0 0 0 0 1 0 0 1 09h 0.5800

0 0 0 0 1 0 1 0 0Ah 0.5900

0 0 0 0 1 0 1 1 0Bh 0.6000

0 0 0 0 1 1 0 0 0Ch 0.6100

0 0 0 0 1 1 0 1 0Dh 0.6200

0 0 0 0 1 1 1 0 0Eh 0.6300

0 0 0 0 1 1 1 1 0Fh 0.6400

0 0 0 1 0 0 0 0 10h 0.6500

0 0 0 1 0 0 0 1 11h 0.6600

0 0 0 1 0 0 1 0 12h 0.6700

0 0 0 1 0 0 1 1 13h 0.6800

0 0 0 1 0 1 0 0 14h 0.6900

0 0 0 1 0 1 0 1 15h 0.7000

0 0 0 1 0 1 1 0 16h 0.7100

0 0 0 1 0 1 1 1 17h 0.7200

0 0 0 1 1 0 0 0 18h 0.7300

0 0 0 1 1 0 0 1 19h 0.7400

0 0 0 1 1 0 1 0 1Ah 0.7500

0 0 0 1 1 0 1 1 1Bh 0.7600

0 0 0 1 1 1 0 0 1Ch 0.7700

0 0 0 1 1 1 0 1 1Dh 0.7800

0 0 0 1 1 1 1 0 1Eh 0.7900

0 0 0 1 1 1 1 1 1Fh 0.8000

0 0 1 0 0 0 0 0 20h 0.8100

continued...

Hex V

0 0 1 0 0 0 0 1 21h 0.8200

0 0 1 0 0 0 1 0 22h 0.8300

0 0 1 0 0 0 1 1 23h 0.8400

0 0 1 0 0 1 0 0 24h 0.8500

0 0 1 0 0 1 0 1 25h 0.8600

0 0 1 0 0 1 1 0 26h 0.8700

0 0 1 0 0 1 1 1 27h 0.8800

0 0 1 0 1 0 0 0 28h 0.8900

0 0 1 0 1 0 0 1 29h 0.9000

0 0 1 0 1 0 1 0 2Ah 0.9100

0 0 1 0 1 0 1 1 2Bh 0.9200

0 0 1 0 1 1 0 0 2Ch 0.9300

0 0 1 0 1 1 0 1 2Dh 0.9400

0 0 1 0 1 1 1 0 2Eh 0.9500

0 0 1 0 1 1 1 1 2Fh 0.9600

0 0 1 1 0 0 0 0 30h 0.9700

0 0 1 1 0 0 0 1 31h 0.9800

0 0 1 1 0 0 1 0 32h 0.9900

0 0 1 1 0 0 1 1 33h 1.0000

0 0 1 1 0 1 0 0 34h 1.0100

0 0 1 1 0 1 0 1 35h 1.0200

0 0 1 1 0 1 1 0 36h 1.0300

0 0 1 1 0 1 1 1 37h 1.0400

0 0 1 1 1 0 0 0 38h 1.0500

0 0 1 1 1 0 0 1 39h 1.0600

0 0 1 1 1 0 1 0 3Ah 1.0700

0 0 1 1 1 0 1 1 3Bh 1.0800

0 0 1 1 1 1 0 0 3Ch 1.0900

0 0 1 1 1 1 0 1 3Dh 1.1000

0 0 1 1 1 1 1 0 3Eh 1.1100

0 0 1 1 1 1 1 1 3Fh 1.1200

0 1 0 0 0 0 0 0 40h 1.1300

0 1 0 0 0 0 0 1 41h 1.1400

Processor—Electrical Specifications

Hex V

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family Datasheet – Volume 1 of 2 July 2014 94 Order No.: 328901-007

Electrical Specifications—Processor

Hex V i t

0 1 0 0 0 0 1 0 42h 1.1500

0 1 0 0 0 0 1 1 43h 1.1600

0 1 0 0 0 1 0 0 44h 1.1700

0 1 0 0 0 1 0 1 45h 1.1800

0 1 0 0 0 1 1 0 46h 1.1900

0 1 0 0 0 1 1 1 47h 1.2000

0 1 0 0 1 0 0 0 48h 1.2100

0 1 0 0 1 0 0 1 49h 1.2200

0 1 0 0 1 0 1 0 4Ah 1.2300

0 1 0 0 1 0 1 1 4Bh 1.2400

0 1 0 0 1 1 0 0 4Ch 1.2500

0 1 0 0 1 1 0 1 4Dh 1.2600

0 1 0 0 1 1 1 0 4Eh 1.2700

0 1 0 0 1 1 1 1 4Fh 1.2800

0 1 0 1 0 0 0 0 50h 1.2900

0 1 0 1 0 0 0 1 51h 1.3000

0 1 0 1 0 0 1 0 52h 1.3100

0 1 0 1 0 0 1 1 53h 1.3200

0 1 0 1 0 1 0 0 54h 1.3300

0 1 0 1 0 1 0 1 55h 1.3400

0 1 0 1 0 1 1 0 56h 1.3500

0 1 0 1 0 1 1 1 57h 1.3600

0 1 0 1 1 0 0 0 58h 1.3700

0 1 0 1 1 0 0 1 59h 1.3800

0 1 0 1 1 0 1 0 5Ah 1.3900

0 1 0 1 1 0 1 1 5Bh 1.4000

0 1 0 1 1 1 0 0 5Ch 1.4100

0 1 0 1 1 1 0 1 5Dh 1.4200

0 1 0 1 1 1 1 0 5Eh 1.4300

0 1 0 1 1 1 1 1 5Fh 1.4400

0 1 1 0 0 0 0 0 60h 1.4500

0 1 1 0 0 0 0 1 61h 1.4600

0 1 1 0 0 0 1 0 62h 1.4700

0 1 1 0 0 0 1 1 63h 1.4800

continued...

Hex V i t

0 1 1 0 0 1 0 0 64h 1.4900

0 1 1 0 0 1 0 1 65h 1.5000

0 1 1 0 0 1 1 0 66h 1.5100

0 1 1 0 0 1 1 1 67h 1.5200

0 1 1 0 1 0 0 0 68h 1.5300

0 1 1 0 1 0 0 1 69h 1.5400

0 1 1 0 1 0 1 0 6Ah 1.5500

0 1 1 0 1 0 1 1 6Bh 1.5600

0 1 1 0 1 1 0 0 6Ch 1.5700

0 1 1 0 1 1 0 1 6Dh 1.5800

0 1 1 0 1 1 1 0 6Eh 1.5900

0 1 1 0 1 1 1 1 6Fh 1.6000

0 1 1 1 0 0 0 0 70h 1.6100

0 1 1 1 0 0 0 1 71h 1.6200

0 1 1 1 0 0 1 0 72h 1.6300

0 1 1 1 0 0 1 1 73h 1.6400

0 1 1 1 0 1 0 0 74h 1.6500

0 1 1 1 0 1 0 1 75h 1.6600

0 1 1 1 0 1 1 0 76h 1.6700

0 1 1 1 0 1 1 1 77h 1.6800

0 1 1 1 1 0 0 0 78h 1.6900

0 1 1 1 1 0 0 1 79h 1.7000

0 1 1 1 1 0 1 0 7Ah 1.7100

0 1 1 1 1 0 1 1 7Bh 1.7200

0 1 1 1 1 1 0 0 7Ch 1.7300

0 1 1 1 1 1 0 1 7Dh 1.7400

0 1 1 1 1 1 1 0 7Eh 1.7500

0 1 1 1 1 1 1 1 7Fh 1.7600

1 0 0 0 0 0 0 0 80h 1.7700

1 0 0 0 0 0 0 1 81h 1.7800

1 0 0 0 0 0 1 0 82h 1.7900

1 0 0 0 0 0 1 1 83h 1.8000

1 0 0 0 0 1 0 0 84h 1.8100

1 0 0 0 0 1 0 1 85h 1.8200

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 95

Hex V

i t 0

1 0 0 0 0 1 1 0 86h 1.8300

1 0 0 0 0 1 1 1 87h 1.8400

1 0 0 0 1 0 0 0 88h 1.8500

1 0 0 0 1 0 0 1 89h 1.8600

1 0 0 0 1 0 1 0 8Ah 1.8700

1 0 0 0 1 0 1 1 8Bh 1.8800

1 0 0 0 1 1 0 0 8Ch 1.8900

1 0 0 0 1 1 0 1 8Dh 1.9000

1 0 0 0 1 1 1 0 8Eh 1.9100

1 0 0 0 1 1 1 1 8Fh 1.9200

1 0 0 1 0 0 0 0 90h 1.9300

1 0 0 1 0 0 0 1 91h 1.9400

1 0 0 1 0 0 1 0 92h 1.9500

1 0 0 1 0 0 1 1 93h 1.9600

1 0 0 1 0 1 0 0 94h 1.9700

1 0 0 1 0 1 0 1 95h 1.9800

1 0 0 1 0 1 1 0 96h 1.9900

1 0 0 1 0 1 1 1 97h 2.0000

1 0 0 1 1 0 0 0 98h 2.0100

1 0 0 1 1 0 0 1 99h 2.0200

1 0 0 1 1 0 1 0 9Ah 2.0300

1 0 0 1 1 0 1 1 9Bh 2.0400

1 0 0 1 1 1 0 0 9Ch 2.0500

1 0 0 1 1 1 0 1 9Dh 2.0600

1 0 0 1 1 1 1 0 9Eh 2.0700

1 0 0 1 1 1 1 1 9Fh 2.0800

1 0 1 0 0 0 0 0 A0h 2.0900

1 0 1 0 0 0 0 1 A1h 2.1000

1 0 1 0 0 0 1 0 A2h 2.1100

1 0 1 0 0 0 1 1 A3h 2.1200

1 0 1 0 0 1 0 0 A4h 2.1300

1 0 1 0 0 1 0 1 A5h 2.1400

1 0 1 0 0 1 1 0 A6h 2.1500

1 0 1 0 0 1 1 1 A7h 2.1600

continued...

Processor—Electrical Specifications

Hex V i t

1 0 1 0 1 0 0 0 A8h 2.1700

1 0 1 0 1 0 0 1 A9h 2.1800

1 0 1 0 1 0 1 0 AAh 2.1900

1 0 1 0 1 0 1 1 ABh 2.2000

1 0 1 0 1 1 0 0 ACh 2.2100

1 0 1 0 1 1 0 1 ADh 2.2200

1 0 1 0 1 1 1 0 AEh 2.2300

1 0 1 0 1 1 1 1 AFh 2.2400

1 0 1 1 0 0 0 0 B0h 2.2500

1 0 1 1 0 0 0 1 B1h 2.2600

1 0 1 1 0 0 1 0 B2h 2.2700

1 0 1 1 0 0 1 1 B3h 2.2800

1 0 1 1 0 1 0 0 B4h 2.2900

1 0 1 1 0 1 0 1 B5h 2.3000

1 0 1 1 0 1 1 0 B6h 2.3100

1 0 1 1 0 1 1 1 B7h 2.3200

1 0 1 1 1 0 0 0 B8h 2.3300

1 0 1 1 1 0 0 1 B9h 2.3400

1 0 1 1 1 0 1 0 BAh 2.3500

1 0 1 1 1 0 1 1 BBh 2.3600

1 0 1 1 1 1 0 0 BCh 2.3700

1 0 1 1 1 1 0 1 BDh 2.3800

1 0 1 1 1 1 1 0 BEh 2.3900

1 0 1 1 1 1 1 1 BFh 2.4000

1 1 0 0 0 0 0 0 C0h 2.4100

1 1 0 0 0 0 0 1 C1h 2.4200

1 1 0 0 0 0 1 0 C2h 2.4300

1 1 0 0 0 0 1 1 C3h 2.4400

1 1 0 0 0 1 0 0 C4h 2.4500

1 1 0 0 0 1 0 1 C5h 2.4600

1 1 0 0 0 1 1 0 C6h 2.4700

1 1 0 0 0 1 1 1 C7h 2.4800

1 1 0 0 1 0 0 0 C8h 2.4900

1 1 0 0 1 0 0 1 C9h 2.5000

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family Datasheet – Volume 1 of 2 July 2014 96 Order No.: 328901-007

Electrical Specifications—Processor

Hex V i t

1 1 0 0 1 0 1 0 CAh 2.5100

1 1 0 0 1 0 1 1 CBh 2.5200

1 1 0 0 1 1 0 0 CCh 2.5300

1 1 0 0 1 1 0 1 CDh 2.5400

1 1 0 0 1 1 1 0 CEh 2.5500

1 1 0 0 1 1 1 1 CFh 2.5600

1 1 0 1 0 0 0 0 D0h 2.5700

1 1 0 1 0 0 0 1 D1h 2.5800

1 1 0 1 0 0 1 0 D2h 2.5900

1 1 0 1 0 0 1 1 D3h 2.6000

1 1 0 1 0 1 0 0 D4h 2.6100

1 1 0 1 0 1 0 1 D5h 2.6200

1 1 0 1 0 1 1 0 D6h 2.6300

1 1 0 1 0 1 1 1 D7h 2.6400

1 1 0 1 1 0 0 0 D8h 2.6500

1 1 0 1 1 0 0 1 D9h 2.6600

1 1 0 1 1 0 1 0 DAh 2.6700

1 1 0 1 1 0 1 1 DBh 2.6800

1 1 0 1 1 1 0 0 DCh 2.6900

1 1 0 1 1 1 0 1 DDh 2.7000

1 1 0 1 1 1 1 0 DEh 2.7100

1 1 0 1 1 1 1 1 DFh 2.7200

1 1 1 0 0 0 0 0 E0h 2.7300

1 1 1 0 0 0 0 1 E1h 2.7400

1 1 1 0 0 0 1 0 E2h 2.7500

1 1 1 0 0 0 1 1 E3h 2.7600

1 1 1 0 0 1 0 0 E4h 2.7700

1 1 1 0 0 1 0 1 E5h 2.7800

1 1 1 0 0 1 1 0 E6h 2.7900

1 1 1 0 0 1 1 1 E7h 2.8000

1 1 1 0 1 0 0 0 E8h 2.8100

1 1 1 0 1 0 0 1 E9h 2.8200

1 1 1 0 1 0 1 0 EAh 2.8300

1 1 1 0 1 0 1 1 EBh 2.8400

continued...

Hex V i t

1 1 1 0 1 1 0 0 ECh 2.8500

1 1 1 0 1 1 0 1 EDh 2.8600

1 1 1 0 1 1 1 0 EEh 2.8700

1 1 1 0 1 1 1 1 EFh 2.8800

1 1 1 1 0 0 0 0 F0h 2.8900

1 1 1 1 0 0 0 1 F1h 2.9000

1 1 1 1 0 0 1 0 F2h 2.9100

1 1 1 1 0 0 1 1 F3h 2.9200

1 1 1 1 0 1 0 0 F4h 2.9300

1 1 1 1 0 1 0 1 F5h 2.9400

1 1 1 1 0 1 1 0 F6h 2.9500

1 1 1 1 0 1 1 1 F7h 2.9600

1 1 1 1 1 0 0 0 F8h 2.9700

1 1 1 1 1 0 0 1 F9h 2.9800

1 1 1 1 1 0 1 0 FAh 2.9900

1 1 1 1 1 0 1 1 FBh 3.0000

1 1 1 1 1 1 0 0 FCh 3.0100

1 1 1 1 1 1 0 1 FDh 3.0200

1 1 1 1 1 1 1 0 FEh 3.0300

1 1 1 1 1 1 1 1 FFh 3.0400

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 97

Processor—Electrical Specifications

7.4

7.5

Reserved or Unused Signals

The following are the general types of reserved (RSVD) signals and connection guidelines:

• RSVD – these signals should not be connected

• RSVD_TP – these signals should be routed to a test point

• RSVD_NCTF – these signals are non-critical to function and may be left unconnected

Arbitrary connection of these signals to VCC, VDDQ, VSS, or to any other signal (including each other) may result in component malfunction or incompatibility with future processors. See Signal Description on page 83 for a pin listing of the processor and the location of all reserved signals.

For reliable operation, always connect unused inputs or bi-directional signals to an appropriate signal level. Unused active high inputs should be connected through a resistor to ground (VSS). Unused outputs maybe left unconnected; however, this may interfere with some Test Access Port (TAP) functions, complicate debug probing, and prevent boundary scan testing. A resistor must be used when tying bi-directional signals to power or ground. When tying any signal to power or ground, a resistor will also allow for system testability.

Signal Groups

Signals are grouped by buffer type and similar characteristics as listed in the following table. The buffer type indicates which signaling technology and specifications apply to the signals. All the differential signals and selected DDR3L/DDR3L-RS and Control Sideband signals have On-Die Termination (ODT) resistors. Some signals do not have ODT and need to be terminated on the board.

Note: All Control Sideband Asynchronous signals are required to be asserted/de-asserted for

at least 10 BCLKs with maximum Trise/Tfall of 6 ns for the processor to recognize the proper signal state. See the DC Specifications section and AC Specifications section.

Table 45. Signal Groups

Signal Group Type Signals

System Reference Clock

Differential CMOS Input BCLKP, BCLKN, DPLL_REF_CLKP, DPLL_REF_CLKN,

DDR3L / DDR3L-RS Reference Clocks

Differential DDR3L/DDR3L-RS

Output

DDR3L / DDR3L-RS Command Signals

Single ended DDR3L/DDR3L-RS

Output

DDR3L / DDR3L-RS Control Signals

Single ended DDR3L/DDR3L-RS

Output

Single ended CMOS Output SM_DRAMRST#

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 98 Order No.: 328901-007

SSC_DPLL_REF_CLKP, SSC_DPLL_REF_CLKN

SA_CKP[3:0], SA_CKN[3:0], SB_CKP[3:0], SB_CKN[3:0]

SA_BS[2:0], SB_BS[2:0], SA_WE#, SB_WE#, SA_RAS#, SB_RAS#, SA_CAS#, SB_CAS#, SA_MA[15:0], SB_MA[15:0]

SA_CKE[3:0], SB_CKE[3:0], SA_CS#[3:0], SB_CS#[3:0], SA_ODT[3:0], SB_ODT[3:0]

continued...

Electrical Specifications—Processor

Signal Group Type Signals

DDR3L / DDR3L-RS Data Signals

Single ended DDR3L/DDR3L-RS

Differential DDR3L/DDR3L-RS

DDR3L / DDR3L-RS Compensation

DDR3L / DDR3L-RS Reference Voltage Signals

Testability (ITP/XDP)

Single ended CMOS Input TCK, TDI, TMS, TRST#

Single ended GTL TDO

Single ended Output DBR#

Single ended GTL BPM#[7:0]

Single ended GTL PREQ#

Single ended GTL PRDY#

Control Sideband

Single ended GTL Input/Open

Single ended Asynchronous

Single ended GTL CATERR#

Single ended Asynchronous

Single ended Asynchronous Bi-

Single ended GTL Bi-directional CFG[19:0]

Single ended Analog Input SM_RCOMP[2:0]

Voltage Regulator

Single ended CMOS Input VR_READY

Single ended CMOS Input VIDALERT#

Single ended Open Drain Output VIDSCLK

Single ended GTL Input/Open

Differential Analog Output VCC_SENSE, VSS_SENSE

Power / Ground / Other

Single ended Power VCC, VDDQ

SA_DQ[63:0], SB_DQ[63:0]

Bi-directional

SA_DQSP[7:0], SA_DQSN[7:0], SB_DQSP[7:0], SB_DQSN[7:0]

Bi-directional

Analog Input SM_RCOMP[2:0]

DDR3L/DDR3L-RS

SM_VREF, SA_DIMM_VREFDQ, SB_DIMM_VREFDQ

Output

PROCHOT#

Drain Output

THERMTRIP#, IVR_ERROR

CMOS Output

PM_SYNC,RESET#, PWRGOOD, PWR_DEBUG#

CMOS Input

PECI

directional

VIDSOUT

Drain Output

Ground VSS, VSS_NCTF

No Connect RSVD, RSVD_NCTF

continued...

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron

Processor Family July 2014 Datasheet – Volume 1 of 2 Order No.: 328901-007 99

Processor—Electrical Specifications

Signal Group Type Signals

Test Point RSVD_TP

Other SKTOCC#, PROC_DETECT#3

PCI Express* Graphics

Differential PCI Express Input PEG_RXP[15:0], PEG_RXN[15:0]

Differential PCI Express Output PEG_TXP[15:0], PEG_TXN[15:0]

Single ended Analog Input PEG_RCOMP

Embedded DisplayPort*

Differential eDP Output eDP_TXP[3:0], eDP_TXN[3:0]

Single ended Asynchronous

CMOS Input

Single ended Analog Input/

Output

Digital Media Interface (DMI)

Differential DMI Input DMI_RXP[3:0], DMI_RXN[3:0]

Differential DMI Output DMI_TXP[3:0], DMI_TXN[3:0]

Digital Display Interface

Differential DDI Output DDIB_TXP[3:0], DDIB_TXN[3:0], DDIC_TXP[3:0],

Intel® FDI

Single ended CMOS Input FDI_CSYNC

Single ended Asynchronous

CMOS Input

Differential FDI Output FDI_TXP[1:0], FDI_TXN[1:0]

Notes: 1. See Signal Description on page 83 for signal description details.

2. SA and SB refer to DDR3L/DDR3L-RS Channel A and DDR3L/DDR3L-RS Channel B.

3. These signals only apply to BGA packages.

eDP_HPD

eDP_RCOMP

DDIC_TXN[3:0], DDID_TXP[3:0], DDID_TXN[3:0]

DISP_INT

7.6

Test Access Port (TAP) Connection

Due to the voltage levels supported by other components in the Test Access Port (TAP) logic, Intel recommends the processor be first in the TAP chain, followed by any other components within the system. A translation buffer should be used to connect to the rest of the chain unless one of the other components is capable of accepting an input of the appropriate voltage. Two copies of each signal may be required with each driving a different voltage level.

The processor supports Boundary Scan (JTAG) IEEE 1149.1-2001 and IEEE

1149.6-2003 standards. A few of the I/O pins may support only one of those standards.

7.7

DC Specifications

The processor DC specifications in this section are defined at the processor pins, unless noted otherwise. See Signal Description on page 83 for the processor pin listings and signal definitions.

Mobile 4th Generation Intel® Core™ Processor Family, Mobile Intel® Pentium® Processor Family, and Mobile Intel® Celeron Processor Family Datasheet – Volume 1 of 2 July 2014 100 Order No.: 328901-007

Intel i5-4570TE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Figures

Tables

Revision History

1.0 Introduction

Supported Technologies

Interfaces

Power Management Support

Thermal Management Support

Package Support

Processor Testability

Terminology

Related Documents
